0引言随着社会的发展，下一代通信设备对传输容量需求越来越大，并需要对语音、数据、图像和视频的传输和处理，因此对宽带平台的信号带宽和通道数提出了很高的要求。
现阶段的通信平台一般采用超外差和零中频两种架构实现，超外差架构存在不可在线编程、扩展性差、体积大、功耗高等缺陷[1]，零中频架构一般采用最新的捷变频收发器芯片AD3961实现，但是AD9361带宽最高支持56MHz 信号带宽，也不满足宽带通信平台的要求。
综上所述，新一代宽带通信平台必须具备具有多通道、宽频段、高动态范围、轻量化、通用化、硬件可配置、软件即插即用等技术特征。
本文提出一种基于集成射频芯片AD9371和Zynq UltraScale+MPSOC 的下一代多通道宽带通信平台设计方案，可满足新一代宽带通信设备的应用需求，在军民用无线通信领域具有广阔的应用前景。
1硬件架构1.1集成射频处理芯片结构AD9371是一款高集成度的宽带RF 收发器，提供双通道的发射器和接收器、集成式频率合成器、测试和信号处理功能。
AD9371提供FDD 和TDD 应用中的3G/4G 微基站和宏基站设备所需的灵活性能和低功耗组合。
该器件的工作频率为300MHz~6000MHz，AD9371作者简介:苏兆忠(1984-)，男，山东菏泽人，硕士研究生，工程师，从事机载通信电子设备的硬件研发工作，主要研究方向为高速总线传输、嵌入式系统、数模混合电路设计。
基于AD9371和Zynq UltraScale+MPSOC 的多通道宽带通信平台The Multi-Channel Broadband Communication Platform Based on AD9371and Zynq UltraScale+MPSOC苏兆忠(中国西南电子技术研究所,四川成都610036)Su Zhao-zhong (Southwest China Institute of Electronic Technology,Sichun Chengdu 610036)摘要：该文分析了多通道宽带通信平台需求和技术特征，提出了一种基于集成射频芯片AD9371和Zynq UltraScale+MPSOC 的多通道宽带通信平台解决方案，详细介绍了集成射频芯片AD9371和Zynq UltraScale+MPSOC 内部组成原理，并且基于该平台进行了QPSK 算法验证，结果表明该平台性能优越，满足下一代宽带通信平台需求。
