当前位置：文档之家 › VW 01029 螺丝扳手,所需空间-英文

VW 01029 螺丝扳手,所需空间-英文

  • 格式：pdf
  • 大小：60.93 KB
  • 文档页数：5

Confidential.All rights reserved.No part of this document may be transmitted or reproduced without prior permission of a Standards Department of the Volkswagen Group.Parties to a contract can only obtain this standard via the B2B supplier platform “”.©VOLKSWAGEN AGC h e c k s t a n d a r d f o r c u r r e n t i s s u e p r i o r t o u s a g e .T h e E n g l i s h t r a n s l a t i o n i s b e l i e v e d t o b e a c c u r a t e .I n c a s e o f d i s c r e p a n c i e s t h e G e r m a n v e r s i o n s h a l l g o v e r n .Q U E L L E : N O L I SPage 2VW 01029:2005-033Requirements3.1Clearance for open-end wrenchesThe values in Table 1and Figures 1and 2are based on the dimensions from DIN 894,DIN 895and ISO 3318.The combinations of thread sizes and widths across flats are the only permissible combinations according to VW 60361.Figure 1-Wrench turn at 120°for open-end wrench Figure 2-Wrench turn at 60°for open-end wrenchTable 1-Clearance for open-end wrenchesDimensions in mmabc 1c 2r 1r 2Thread sizeWidth acrossflatsMinimum clearances Maximum clearancesM4781318128M588.51519139M6101018 1.5101610M81312.5232121812M101616263152214M121817273162214M142118314182316M162421354212818M203025426253522Preferred values according to VW 60361are printed in bold type.Page 3VW 01029:2005-033.2Clearance for ring wrenchesThe values in Table 2and Figures 3and 4are based on the measured dimensions from DIN 837,DIN 838and ISO 3111.Figure 3-Wrench turn at 120°for ring wrench Figure 4-Wrench turn at 60°for ring wrenchTable 2-Minimum and maximum clearances for ring wrenchesDimensions in mmr 3c 3c 4Thread sizeWidth acrossflatsMinimum clearances Maximum clearanceM477.5 2.52M58833M6109.543M81312 4.54M10161556M12181658M14211869M162420.569M203025712Preferred values according to VW 60361are printed in bold type.Page4VW01029:2005-033.3Clearance for socket wrenches with external driveThe values in Table3are based on the dimensions from DIN659,DIN896,DIN3112and ISO2236.Table3Thread size Width acrossr4min.flatsM477M587.5M6109M81311.5M101613.5M121815M142117M162419M203023Preferred values according to VW60361are printedin bold type.3.4Clearance for socket wrench inserts with external drive;manually operated andmachine-operatedThe values in Table4are based on the dimensions from DIN3124and DIN3129.Table4Thread size Width acrossr5min.flatsM4711M5813.5M61013.5M81313.5M101616.5M121816.5M142117M162419M203023.5Preferred values according to VW60361are printedin bold type.Page5VW01029:2005-033.5Clearance for socket wrenches and wrench inserts with internal driveThe values in Table5are based on the measured dimensions from VW01043and VW01048.Table5Thread size Drive r6min.M4T20 2.5M5T25 3.0M6T30 4.0M8N10 5.0M10N12 6.0M12N147.0M14N168.0M16N189.0Preferred values according to VW60361are printedin bold type.4Referenced standards1DIN659Tubular Single End Tee Socket WrenchesDIN837Box Wrenches,Double Head,with Unequal Openings;Test Torques Series BDIN838Box Wrenches,Double Head,Deep Offset,with Unequal Openings;Test Torques Series ADIN894Single-Head Engineers Jaw Wrenches;Test Torques Series DDIN895Engineers Wrenches,Double Head,Open End,with Unequal Jaw Widths;Test Torques Series DDIN896Tee Handled Socket Wrenches;Double End;Test Torques Series ADIN898Assembly Tools for Screws and Nuts-Survey,Terms and DefinitionsDIN3111Box Wrenches;Single End;Test Torques Series ADIN3112Tee Handled Socket Wrenches,Single EndDIN3124Square Drive Socket Wrenches for Hexagon Bolts,Hand-OperatedDIN3129Power Square Drive Socket WrenchesISO2236Assembly Tools for Screws and Nuts;Forged and Tubular Socket Wrenches;Maximum Outside Head DimensionsISO3318Assembly Tools for Screws and Nuts;Double-Headed Open-Ended Wrenches, Double-Headed Ring Wrenches and Combination Wrenches;Maximum Widths ofHeadsVW01043Multipoint Socket Profile;Drive Shape for Threaded PartsVW01048Round Hexagon Socket;Drive Shape for Threaded PartsVW60361Mechanical Joining Elements;Parts Reduction;General Guidelines1In this section terminological inconsistencies may occur as the original titles are used.。
