Package ContentsThe mSeries package includes:●Power cables (2x)●Rack mounting bracket ears with screws●Ethernet cable●mSeries appliancemSeries rear and front panelsRear PanelFront Panel Console Console portUSB USB portsEth8 LAN port (not configured)Reset Reset switch Power indicatorSystem status indicatorHDD indicatorLCD keypad arrowsInstallation●Prepare the appliance for rack installation by fastening the bracket ears to the sides of the chassis using the provided hardware. ●Mount the appliance to your rack enclosure using the provided hardware. ●Connect the ethernet cable from your Internet modem or router to the farthest left port on the lower quad port module. ●Connect the ethernet cable from your LAN switch to the second port from the left on the lower quad port module. ●Plug in both power cables to a power source and connect them to the AC power inputs located on the rear panel. ●Review the power indicator on the front of the appliance. If the indicator is lit, the appliance is powered on. ●If the appliance is not powered on, toggle the power switch located on the rear panel.Connect to the applianceYou can connect to your appliance via the online C ommand Center portal at h ttps:///cmd . Alternatively, you can connect to your appliance from the local network, or directly using a monitor, keyboard, and mouse.Via Command CenterProvisioning a new mSeries appliance via Command Center is a convenient way to deploy and configure NG Firewall. To set up and manage your new appliance from Command Center follow these steps:1.Navigate your web browser to h ttps:///cmd.2.Log in with your Untangle Command Center account, or click C reate Account to set up an account.3.In Command Center, click A dd in the Appliances screen.4.Enter the serial number located on the side panel of your appliance.5.Click A dd to confirm the new appliance.6.After the appliance successfully adds to your account, you can select it from the list of appliances.7.Click R emote Access to connect to the administration of your new appliance.8.Continue to the setup wizard.Via network connectionAlternatively, you can connect to your NG Firewall management interface from the local area network. This is useful for example if your NG Firewall appliance cannot reach the Internet and you require local administration to configure the TCP/IP settings. To access theadministration from a local network follow these steps:1.Connect your management system to the network attached to the LAN port (Internal) of the appliance.2.Check the network status of your management system and confirm that you receive an IPv4 address in the subnet of192.168.2.0/24 (e.g. 192.168.2.100).3.In a browser, navigate to 192.168.2.1.4.Accept the SSL certificate notice in your browser and continue to the setup wizard.Via direct connectionIf neither of the previous options is available, you can connect to your appliance directly by attaching a display to the VGA port and a keyboard and mouse to any of the USB ports. At the menu on the bottom of the screen, click L aunch Client to open the administration in a browser and continue to the setup wizard.Configure the setup wizardWhen you connect to the administration for the first time, the setup wizard prompts you to configure the essential parameters to get your appliance up and running.Get StartedNG Firewall packages its premium features as apps. During your first login NG Firewall prompts you to install the recommended apps. If you do not have a license, some of the recommended apps run as a 14 day trial. The trial converts to a subscription once you apply a valid license. You can learn more about NG Firewall apps at h ttps:///untangle-ng-firewall/applications/.WarrantyThis appliance is covered by a one, two or three year manufacturer warranty based on the option chosen at the time of purchase. For a description of the warranty policy visit h ttp:///refund-return-policy.Support & DocumentationFor technical support availability, contact information, and troubleshooting tips visit h ttp://. Help resources are available in the online help system at h ttp://.。
Product Features• 60W and 90W• Single and multi-port (1/6/12/24)• Indoor, outdoor and industrial rated• Power management (cloud based SNMPv3)• Dual power supply (AC and DC)Target ApplicationsChallenges Addressed• Unique ability to support new IEEE 802.3bt compliant devices and existing pre-bt solutions (as default in the1-ports, user option via NMS in the multi-ports)• IEEE 802.3bt standard compliant, backwards compatible to IEEE 802.3af/at• Power outdoor devices, wireless access points, wireless radios and surveillance cameras with outdoor rated PoE systems • Remotely manage the power network and overcome troubleshooting challengesWhy Microchip mPoE?Microchip mPoE powers any wired network device seamlessly and efficiently, making it the ideal solution for Ethernet-based applications. Leveraging a uniquely designed algorithm, this technology enables backward compatibility with pre-standard devices while supporting all IEEE PoE standards. Microchip mPoE technology solves interoperability issues between different PoE standards/legacy solutions and eliminates the dependency on AC infrastructure and its variations to provide an international network power standard.The Sales PitchPower-over-Ethernet technology is becoming the most used and efficient power source for IT networks. Microchip mPoE IEEE 802.3bt compliant solutions deliver up to 90W and are backward compatible with pre-standard devices and enable most enterprise devices to be powered by PoE. Microchip's PoE systems are IEEE standards compliant, tested and approved by industry leading vendors and have millions of ports installed worldwide. Microchip offers a com-plete product portfolio, from single-ports to 24-ports, indoor, outdoor and industrial rated PoE systems with significant differentiators and unique features, enabling you to succeed.• 5G • IoT • Lighting • Smart City • Switching • WirelessSolution OverviewDiscover how to power your high-power Ethernet-based applications with Microchip multi-Power over Ethernet (mPoE) technology; an excellent solution for traditional network devices such as IP phones, Wireless Access Points (WAPs), and IP surveillance cameras, as well as 5G small cells, LoRa® gateways, LED luminaires, access control terminals and other Internet of Things (IoT) devices. Microchip mPoE products also enable backward compatibility with pre-standard devices while supporting all IEEE® PoE standards. The Power Solution for Wired Ethernet NetworksEthernet SwitchPoE MidspanThe Microchip name and logo and the Microchip logo are registered trademarks of Microchip Technology Incorporated in the U.S.A. and other countries. The LoRa name and associated logo are trademarks of Semtech Corporation or its subsidiaries. All other trademarks mentioned herein are property of their respective companies. © 2020, Microchip Technology Incorporated. All Rights Reserved. 10/20 DS00003685AMicrochip mPoE Product Selection Guide*PoE switch with 2 x Uplinks (10/100/1000 Copper) and 1x SFP (Fiber/Copper)OutdoorIndustrial。
Copyright © 2012 SMSC or its subsidiaries. All rights reserved.Circuit diagrams and other information relating to SMSC products are included as a means of illustrating typical applications. Consequently, complete information sufficient for construction purposes is not necessarily given. Although the information has been checked and is believed to be accurate, no responsibility is assumed for inaccuracies. SMSC reserves the right to make changes to specifications and product descriptions at any time without notice. Contact your local SMSC sales office to obtain the latest specifications before placing your product order. The provision of this information does not convey to the purchaser of the described semiconductor devices any licenses under any patent rights or other intellectual property rights of SMSC or others. All sales are expressly conditional on your agreement to the terms and conditions of the most recently dated version of SMSC's standard Terms of Sale Agreement dated before the date of your order (the "Terms of Sale Agreement").The product may contain design defects or errors known as anomalies which may cause the product's functions to deviate from published specifications. Anomaly sheets are available upon request. SMSC products are not designed, intended, authorized or warranted for use in any life support or other application where product failure could cause or contribute to personal injury or severe property damage. Any and all such uses without prior written approval of an Officer of SMSC and further testing and/or modification will be fully at the risk of the customer. Copies of this document or other SMSC literature, as well as the Terms of Sale Agreement, may be obtained by visiting SMSC’s website at . SMSC is a registered trademark of Standard Microsystems Corporation (“SMSC”). Product names and company names are the trademarks of their respective holders.The Microchip name and logo, and the Microchip logo are registered trademarks of Microchip Technology Incorporated in the U.S.A. and other countries.SMSC DISCLAIMS AND EXCLUDES ANY AND ALL WARRANTIES, INCLUDING WITHOUT LIMITATION ANY AND ALL IMPLIED WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, TITLE, AND AGAINST INFRINGEMENT AND THE LIKE, AND ANY AND ALL WARRANTIES ARISING FROM ANY COURSE OF DEALING OR USAGE OF TRADE. IN NO EVENT SHALL SMSC BE LIABLE FOR ANY DIRECT, INCIDENTAL, INDIRECT,SPECIAL, PUNITIVE, OR CONSEQUENTIAL DAMAGES; OR FOR LOST DATA, PROFITS, SAVINGS OR REVENUES OF ANY KIND; REGARDLESS OF THE FORM OF ACTION, WHETHER BASED ON CONTRACT; TORT; NEGLIGENCE OF SMSC OR OTHERS; STRICT LIABILITY; BREACH OF WARRANTY; OR OTHERWISE; WHETHER OR NOT ANY REMEDY OF BUYER IS HELD TO HAVE FAILED OF ITS ESSENTIAL PURPOSE, AND WHETHER OR NOT SMSC HASBEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.EVB-LAN7500 Evaluation Board User ManualEVB-LAN7500 Evaluation Board User Manual1 IntroductionThe LAN7500 is a high performance Hi-Speed USB 2.0 to 10/100/1000 Ethernet controller. Withapplications ranging from embedded systems, set-top boxes, and PVR’s, to USB port replicators, USBto Ethernet dongles and test instrumentation, the device is a high performance and cost competitiveUSB to Ethernet connectivity solution.The LAN7500 contains an integrated 10/100/1000 Ethernet MAC and PHY, Filtering Engine, USB PHY,Hi-Speed USB 2.0 device controller, TAP controller, EEPROM controller, and a FIFO controller with atotal of 32 KB of internal packet buffering.The internal USB 2.0 device controller and USB PHY are compliant with the USB 2.0 Hi-Speedstandard. The device implements Control, Interrupt, Bulk-in, and Bulk-out USB Endpoints.The Ethernet controller supports auto-negotiation, auto-polarity correction, HP Auto-MDIX, and iscompliant with the IEEE 802.3, IEEE 802.3u, IEEE 802.3ab standards. ARP and NS offload is alsosupported.The EVB-LAN7500 is an Evaluation Board (EVB) that utilizes the LAN7500 to provide a fully functionalUSB to Ethernet interface. The EVB-LAN7500 provides a fully integrated Ethernet port and USB portvia the onboard RJ45 and USB Type B connectors. The EVB-LAN7500 is fully configurable for bothself- and bus-powered modes of operation and provides an external +5V power supply barrelconnector for use with a wall-mounted power supply when in self-powered mode. Additional headersprovide access to the LAN7500 GPIO/LEDs. The onboard 4K EEPROM can be used to load the EVB-LAN7500’s USB configuration parameters and MAC address. The EEPROM can be optionally disabledvia a jumper.LAN7500 software drivers are available for Windows XP, Windows Vista, Mac OSX, Linux, and WinCE. Additional manufacturing and diagnostic tools are available for debugging and external EEPROMconfiguration.A simplified block diagram of the EVB-LAN7500 can be seen in Figure1.1.Figure1.1 EVB-LAN7500 Block DiagramEVB-LAN7500 Evaluation Board User Manual1.1 ReferencesConcepts and material available in the following documents may be helpful when using the EVB-LAN7500.2 Board DetailsThe following sections describe the various board features including jumpers, LEDs, test points and system connections. A top view of the EVB-LAN7500 is shown in Figure 2.1.Table 1.1 ReferencesDOCUMENTLOCATIONSMSC LAN7500 Datasheet /lan7500AN8-13 Suggested Magnetics/lan7500SMSC EVB-LAN7500 Evaluation Board Schematic/lan7500Figure 2.1 EVB-LAN7500 Top ViewUSB Type B ConnectorSMSC LAN7500JP1RJ45 Ethernet PortTP2Fuse TP3LED1-LED5J2: GPIO/LEDHeader JP3TP1JP2Power SwitchLED6+5V Power InputEVB-LAN7500 Evaluation Board User Manual2.1 JumpersThe following tables describe the default settings and jumper descriptions for the EVB-LAN7500.These defaults are the recommended configurations for evaluation of the EVB-LAN7500. Thesesettings may be changed as needed, however, any deviation from the default settings should beapproached with care and knowledge of the schematics and datasheet. An incorrect jumper settingmay disable the board.Note:The EVB-LAN7500 jumpers and EEPROM are programmed for self-powered operation by default. To operate in bus-powered mode, the jumpers must be reconfigured and the EEPROMmust be reprogrammed using the SMSC Windows Manufacturing Utility or DOS Utility Suite.Refer to for additional information.Note: A dashed line in the Settings column indicates the board’s default jumper setting.2.2 LEDs Table2.1 JumpersJUMPER PAIR DESCRIPTION SETTINGSJP1 VBUS_DET Select 1 2Bus-Powered Operation 2---3Self-Powered OperationJP2+5V Power Select 1 2Bus-Powered Operation 2---3Self-Powered OperationJP3EEPROM Enable/Disable1---2IN: EEPROM EnabledOUT: EEPROM DisabledTable2.2 LEDsREFERENCE INDICATIONLED1Ethernet Full DuplexLED2Ethernet LinkLED3Ethernet ActivityLED4Speed 0This signal, combined with Speed 1, indicates the current Ethernet link speed. The speed is indicated as shown below:SPEED (Mbps)SPEED 0 (LED4)SPEED 1 (LED5)No Link Off Off10 On Off100Off On1000On OnEVB-LAN7500 Evaluation Board User Manual2.3 Test Points2.4 System Connections2.5 HeadersLED5Speed 1This signal, combined with Speed 0, indicates the current Ethernet link speed. Refer to the LED4 (Speed 0) description for additional information.LED63.3V Power GoodNote:When measuring the suspend current, LED6 or R27 must be unpopulated.Table 2.3 Test PointsTEST POINTDESCRIPTIONCONNECTIONTP1Unpopulated nRESET testpointnRESET TP2Single pin populated gold post GND testpoint GND TP3Single pin populated gold post GND testpointGNDTable 2.4 System ConnectionsCONNECTORDESCRIPTION PARTP1RJ45Stewart SS-6488S-A-NF P2USB Type-B Plug (Right Angle)AMP 292304-1P3+5V Power Supply Barrel Connector (for self-powered mode only)CUI PJ-102AHTable 2.5 HeadersHEADERDESCRIPTIONJ1Internal use only (DNP)J2GPIO header J3+2.5V power header J4+3.3V power header J5+1.2V power headerJ6JTAG interface - Internal use onlyTable 2.2 LEDs (continued)REFERENCEINDICATIONEVB-LAN7500 Evaluation Board User Manual.2.6 SwitchesNote:The EVB-LAN7500 includes a 3A fuse (F1) to protect from overcurrent conditions. If this fusebecomes damaged, it can be replace with a 3A Littlefuse-154003.2.7 MechanicalsFigure 2.2 details the EVB-LAN7500 mechanical dimensions.Table 2.6 GPIO/LED J2 Header PinoutHEADER PIN DESCRIPTIONHEADER PIN DESCRIPTION1VDDVARIO: +2.5V 9GPIO72VDDVARIO: +2.5V 10GPIO63GPIO1/LED111GPIO94GPIO0/LED012GPIO85GPIO3/LED313GPIO116GPIO2/LED214GPIO107GPIO515Ground 8GPIO4/LED416GroundTable 2.7 Power SwitchSWITCH DESCRIPTIONFUNCTIONS1SPDT tiny toggle power switchConnects +5V brick power to boardFigure 2.2 EVB-LAN7500 MechanicalsEVB-LAN7500 Evaluation Board User Manual 3 User Manual Revision HistoryTable3.1 Customer Revision HistoryREVISION LEVEL & DATE SECTION/FIGURE/ENTRY CORRECTIONDocument co-branded: Microchip logo added, modification to legal disclaimer.Rev. 1.0(11-29-12)Initial release.Rev. 1.0(11-03-10)。
恩智浦半导体数据手册：技术数据文件编号：IMXBMMCEC第0.2版，2019年4月MIMX8MM6DVTLZAAMIMX8MM4DVTLZAAMIMX8MM2DVTLZAAMIMX8MM5DVTLZAAMIMX8MM3DVTLZAAMIMX8MM1DVTLZAA适用于消费电子产品的i.MX 8M Mini应用处理器数据手册封装信息塑料封装FCBGA 14 x 14 mm，0.5 mm间距订购信息参见第6页的表21 i.MX 8M Mini简介i.MX 8M Mini应用处理器是能够带来最新视频和音频体验的恩智浦产品，具有最先进的特定媒体功能，采用高性能处理技术，同时优化了功耗。
i.MX 8M Mini系列处理器采用先进的四核Arm® Cortex®-A53内核，运行速度高达1.8 GHz。
一个通用型Cortex®-M4 400 MHz内核处理器用于低功耗处理。
DRAM控制器支持32位/16位LPDDR4、DDR4和DDR3L存储器。
可提供多种音频接口，包括I2S、AC97、TDM和S/PDIF。
提供许多其他接口用于连接外围设备，如USB、PCIe和以太网。
1. i.MX 8M Mini简介 (1)1.1. 功能框图 (5)1.2. 订购信息 (6)2. 模块列表 (8)2.1. 未使用的输入/输出的推荐连接 (12)i.MX 8M Mini简介表1. 特性i.MX 8M Mini简介表1. 特性（续）i.MX 8M Mini简介表1. 特性（续）注意实际功能集取决于产品型号（如表2所述）。
某些特定产品型号可能并未启用某些功能，如显示器和摄像头接口以及连接接口。
i.MX 8M Mini简介1.1 功能框图图1显示了i.MX 8M Mini应用处理器系统的功能模块。
图1. i.MX 8M Mini系统功能框图i.MX 8M Mini简介1.2 订购信息表2所示为本数据手册中包含的可订购样品型号的示例。
P R O F E S S I O N A LTECHNICAL DATAControlSpace EX-1280 digital signal processorApplicationsPerformance venues Stadiums and arenas Places of worshipResorts and Hospitality Venues Multipurpose spacesKey FeaturesOpen-architecture , 1RU design built for general-purpose and PA applications USB connection facilitates easy integration with PC audio sourcesDante audio networking supports 64 x 64 audio channels for connection to other Dante-enabled products, including native Dante-integrated microphones, amplifiers, mixers, and end pointsBose AmpLink port provides 8 channels of uncompressed, low-latency digital audio to AmpLink-equipped Bose amplifiersFront-panel interface features a large OLED display and rotary encoder for setting network parameters and monitoring channel activityGPIO (5 in/5 out) and Serial for interfacing with external devices and control systemsHigh-quality analog circuitry offers both mic and line-level I/O, operates with ultra-low noise and 118 dB dynamic range.Bose ControlSpace Designer software enables a large set of signal processing modules, such as automatic micmixing, multiband graphic and parametric EQs, Bose loudspeaker libraries, signal generators, routers, mixers, AGCs, duckers, gates, compressors, source selectors, delays and logicA variety of control options— compatible with the programmable Bose CC-64 and CC-16 controllers, ControlCenter digital zone controllers, and ControlSpace Remote clientsSupports industry-standard control systems using a comprehensive serial protocol through onboard RS-232 and Ethernet ports, with available drivers for AMX and Crestron-based systemsProduct OverviewWith an open-architecture, single-rack-unit design, the ControlSpace EX-1280 is a robust digital signal processor equipped for general-purpose audio processing applications. Twelve mic/line analog inputs, eight analog outputs, a Bose AmpLink output, and 64 x 64 Dante® connectivity allow for flexible configuration and high-quality sound system control. ControlSpace Designer software simplifies the setup process with drag-and-drop programming, making configuration quick and easy.Technical Specificationsq Front-panel OLED Display and Encoder – 256 x 64 display for metering and network info. Rotary/press knob for IP setupq Balanced Analog I/O – 12 inputs, 8 outputswG PIO – 5 x 5 general-purpose control eC ontrolSpace Network Port – ControlSpace/Dante secondary when configured for redundant mode r Dante Network Port – ControlSpace/Dante Primary by defaulttU SB Port – Micro-B USB for PC with stereo input and output y USB Port – Future useuB ose Amplink – 8-channel uncompressed, low-latency digital audio output iS erial Port – 3-wire RS-232C (DTE) serial interface connection oC C-16 – Supports Bose CC-16 user controls qq w r t y u i oeDante is a registered trademark of Audinate Pty Ltd. For additional specifications and application information, please visit . Specificationssubject to change without notice. 06/2019Product CodesControlSpace EX-1280 digital signal processor US-120V 834317-1110EU-230V 834317-2110JP-100V 834317-3110UK-230V834317-4110AU-240V 834317-5110AccessoriesControlSpace EX-UH USB/Headset Dante endpoint 771784-0110ControlSpace EX-4ML 4-ch mic/GPIO Dante endpoint 771783-0110ControlSpace EX-8ML 8-ch mic/GPIO Dante endpoint772045-0110。
MGate5122Series1-port CANopen/J1939-to-EtherNet/IP gatewaysFeatures and Benefits•Simultaneous protocol conversions from CANopen and J1939to EtherNet/IPand SNMP•Supports EtherNet/IP adapter and SNMP agent•Supports CANopen master and J1939•Flexible deployment with Ethernet cascading and dual subnet•Embedded traffic monitoring/diagnostic information for easy troubleshooting•Easy device configuration via a web-based console•microSD card for configuration backup/duplication•Supports dual redundant DC power inputs and1relay output•CAN port with2-kV isolation protection•-40to75°C wide operating temperature models available•Developed according to IEC62443-4-2with Secure BootCertificationsIntroductionThe MGate5122is an industrial Ethernet gateway for converting CANopen or J1939to EtherNet/IP network communications.To integrate existing CANopen or J1939devices onto an EtherNet/IP network,use the MGate5122as a CANopen or J1939master to collect data and exchange data with the EtherNet/IP scanner.All models are protected by a rugged and compact metal housing and are DIN-rail mountable.The rugged design is suitable for industrial applications such as factory automation and other process automation industries.Easy ConfigurationThe MGate5122gateways are provided with a web console to make configuration easy without having to install an extra utility.In addition,HTTPS encryption of communication ensures higher network security.In most data-acquisition applications,configuration of CANopen devices can be time-consuming and increase costs.The MGate5122gateways provide EDS file import function and user can auto scan the CANopen devices to help complete the settings quickly.The MGate gateways provide software-configurable termination resistor settings for CANbus to reduce efforts by eliminating the need to open the chassis.Easy TroubleshootingThe MGate5122gateways provide a variety of maintenance functions to reduce troubleshooting time and cost,including LED indicators,protocol diagnostics,traffic monitor,and tag view.These tools help you capture and check data to easily identify the root cause of issues,especially during the installation stage.The MGate gateways also come with status monitoring and fault protection functions.The status monitoring function notifies a PLC/DCS/SCADA system when a CAN device gets disconnected or does not respond,in which case the process PLC/DCS gets the status of each end device and then issues alarms to notify operators.The fault protection function executes actions pre-defined by the user when a host gets disconnected to prevent the end devices from going offline for long periods of time.SpecificationsEthernet Interface10/100BaseT(X)Ports(RJ45connector)2Auto MDI/MDI-X connectionMagnetic Isolation Protection 1.5kV(built-in)Ethernet Software FeaturesIndustrial Protocols EtherNet/IP AdapterConfiguration Options Web Console(HTTPS)Device Search Utility(DSU)Management ARPDHCP ClientDNSHTTPHTTPSSMTPSNMP TrapSNMPv1/v2c/v3TCP/IPUDPMIB RFC1213Time Management NTP ClientSecurity FunctionsAuthentication Local databaseEncryption HTTPSAES-128AES-256SHA-256Security Protocols SNMPv3SNMPv2c TrapHTTPS(TLS1.3)CAN InterfaceNo.of Ports1Connector Spring-type Euroblock terminalStandards ISO11898-2Baudrate CANopen:10kbps,20kbps,50kbps,125kbps,250kbps,500kbps,800kbps,1MbpsJ1939:250kbps,500kbps,1MbpsTerminator120ohmssoftware configurableSignals CAN_H,CAN_L,GND,Ext_CAN_H,Ext_CAN_L,CAN_ShieldCAN Software FeaturesIndustrial Protocols CANopen master,J1939CANopenMode MasterMax No.of Nodes64Max No.of Receive PDOs256Max No.of Transmit PDOs256SDOs SupportedInput Data Size2048bytesOutput Data Size2048bytesJ1939Max.No.of Commands256Input Data Size2048bytesOutput Data Size2048bytesEtherNet/IPMode AdapterCIP Objects Supported IdentityMessage RouterAssemblyConnection ManagerTCP/IP interfaceEthernet linkPortMax.No.of Scanner Connections4Input Data Size496bytes(bytes/connection,total:1984bytes) Output Data Size496bytes(bytes/connection,total:1984bytes) MemorymicroSD Slot Up to32GB(SD2.0compatible) Power ParametersInput Voltage12to48VDCInput Current455mA(max)Power Connector Spring-type Euroblock terminalRelaysContact Current Rating Resistive load:2A@30VDCPhysical CharacteristicsHousing MetalIP Rating IP30Dimensions25x90x129.6mm(0.98x3.54x5.1in) Weight294g(0.65lb)Environmental LimitsOperating Temperature MGate5122:-10to60°C(14to140°F)MGate5122-T:-40to75°C(-40to167°F) Storage Temperature(package included)-40to85°C(-40to185°F)Ambient Relative Humidity5to95%(non-condensing) Standards and CertificationsSafety EN61010-2-201UL61010-2-201EMC EN61000-6-2/-6-4EMI FCC Part15B Class AEMS IEC61000-4-2ESD:Contact:8kV;Air:15kVIEC61000-4-3RS:80MHz to1GHz:10V/mIEC61000-4-4EFT:Power:4kV;Signal:2kVIEC61000-4-5Surge:Power:2kV;Signal:2kVIEC61000-4-6CS:150kHz to80MHz:10V/m;Signal:10V/mIEC61000-4-8PFMFFreefall IEC60068-2-31Shock IEC60068-2-27Vibration IEC60068-2-6IEC60068-2-64MTBFTime1,408,984hrs hrsStandards Telcordia SR332WarrantyWarranty Period5yearsDetails See /warrantyPackage ContentsDevice1x MGate5122Series gatewayDocumentation1x quick installation guide1x warranty cardDimensionsOrdering InformationModel Name No.of Serial Ports Operating Temperature MGate51221-10to60°C MGate5122-T1-40to75°CAccessories(sold separately)Wall-Mounting KitsWK-25Wall-mounting kit,2plates,4screws,25x43x2mm©Moxa Inc.All rights reserved.Updated Jun28,2023.This document and any portion thereof may not be reproduced or used in any manner whatsoever without the express written permission of Moxa Inc.Product specifications subject to change without notice.Visit our website for the most up-to-date product information.。
产品数据表00813-0506-4410, Rev AC9 月年 2019 年月Emerson Wireless 1410H 网关，配备 781 现场链路■网关使Wireless HART®自组织网络与任意主机系统相连■便于自组网络的组态和管理■便于通过串行和以太网连接集成到控制系统和数据应用中■无缝集成到 AMS 设备管理器■数据可靠性高于 99%，安全性经过业界实践检验■无线能力把 Plantweb™架构的全部优点延伸到以前难以到达的地点9 月年 2019 年月艾默生无线解决方案IEC62591(Wireless HART)...行业标准自组织、自适应网格路由■不需要无线专业知识，网络自动寻找最佳通讯路径■自组织、自修复网络为任何特定设备管理多个通讯路径。
如果网络中出现阻塞，数据仍能继续流动，因为设备已经建立了其他的路径。
然后，网络会根据需要为该设备布置更多的通讯路径可靠的无线架构■标准 IEEE 802.15.4 无线电■ 2.4 GHz ISM 频段划分为15 个无线信道■采用时间同步信道跳频技术，避免其它无线设备、Wi-Fi®和 EMC 源的干扰，提高可靠性■直接序列扩频 (DSSS) 技术可在苛刻的无线电环境中提供高可靠性艾默生智能无线通过 LAN 或串行通讯无缝集成到所有已有主机系统■透明、无缝地集成到 Ovation™和 DeltaV™中■网关通过行业标准协议（包括 OPC DA、Modbus® TCP/IP、Ethernet/IP 和 HART-IP 以及 Modbus RTU 与现有主机系统进行 LAN 或串行通讯交互多层安全保障您的网络安全■所有无线数据都经过 128 位 AES 加密以保障数据安全■所有无线设备均经过身份验证以便您准确了解网络上的内容■第三方安全认证（包括 Achilles 和 FIPS-197 认证）体现出艾默生对安全性的承诺■使用网关安全 web 界面对网络进行完整管控SmartPower 解决方案■在硬件和软件上优化艾默生仪表，以延长电源模块的寿命■SmartPower™技术支持可预测的电源寿命内容艾默生无线解决方案 (2)功能与优点 (3)订购信息 (4)规格 (7)产品认证 (12)功能与优点获得实时过程数据，无线数据可靠性高于 99%■配备 781 现场链路的 Emerson Wireless 1410H 网关能自动管理不断变化之环境中的无线通讯■通过以太网使用 Modbus TCP 、OPC 、EtherNet/IP ™ 以及 HART -IP ® 协议或串行 Modbus RTU (RS485) 连接数据历史库、传统主机系统及其他应用程序通过冗余无线网关保障系统可靠性■具有热备能力和自动故障检测能力，从不丧失无线网络■无线网关为单个系统，不再需要双主机集成■一键组态和即插即用结构每个网关随带整套无线网络组态工具■利用集成 Web 界面可轻松组态无线网络与数据集成，无需安装额外软件■随赠的 AMS 无线组态程序软件提供艾默生设备仪表板，可组态 Wireless HART 设备和查看诊断数据■拖放式设备设置功能提供向无线现场网络添加新无线设备的安全方法9 月 年 2019 年 月9 月年 2019 年月订购信息Emerson Wireless 1410H 网关设备购买方必须提供产品材料、选件或组件的规格和选型。
