●根据甲方生产车间使用要求，完全就是一套带有净化功能的精密空调系统。
由
于前期建造时未达到使用要求，仅仅配置了2台柜式空调，移动式小型除湿机2台，室内无新风引入,室内无排风，焊接烟气及其它有害气体无法排出，湿度达不到电子元器件使用要求，为此需做出相应的改造，需要达到的使用要求分别是A：温度恒定在22℃-25℃.B：相对湿度恒定在35％—40%.C:有净化新风引入，以利于工作人员健康。
D：室内有害气体需要置换到室外。
E：PM2。
5等颗粒物需要通过吸附过滤等方式得到净化。
●依据以上特殊要求并结合施工工艺难易程度做出如下三种方案对比，由甲方根
据实际情况做出相应决策.
设计方案对照表
建议：
1、如若新建生产车间，可采用全风系统恒温恒湿净化型精密空调。
室内仅有送回风管和可调型风口，设备置于室外的组合风柜,实现湿度、温度、新风补偿、过滤、净化等精密控制的组合风柜，增加所需要的各功能段。
比如：回风段，二次回风及新风混合段、预热段、初效过滤段（板式过滤段）、冷水盘管段、热水盘管段、除湿段、热回收段、自净高效筒式过滤段、健康杀菌单元电子净化段、活性炭吸附段、臭氧发生段、喷淋段、送风机段、出风段、消声段等，根据需要取舍后组合成一套可以精确控制温度、湿度、和洁净度的整体风柜。
甚至可采用变风量或者定风量系统设计方式,精确控制室内大气压。
一台组合风柜根据需要即可负载几百至几千平方米的生产车间。
