Project : Shanxi North Digester feed P.O.no.: SEPI-LNJBLY-04-001 Pump serial no. : 5200885/1+2+3Client : Shandong Electric Power International Corp.Pumptype: TZPM 2000Document descriptionDocument nr.00Initial issueR. Keijers03.01.05 FvO 814.200885.02 Rev Change desc. PreparedDateIssued byInstrument and equipment listSheet 1 of 7806.e n g .022 GCopyright by Weir Netherlands b.v., all rights reserved. This document isprotected by copyright laws and international copyright treaties as well as other intellectual property laws and treaties. This document should not be reproduced without the prior written permission by Weir Netherlands b.v.Weir Netherlands b.v.P.O. Box 249NL – 5900 AE VenloTAG No. P & I No. DESCRIPTION MFR./SUPPL. MODEL/TYPE RANGE SETPOINT REMARKS RevPOWER END LUBRICATION UNITSuction filter Hydac 0050 S 125 W Filter element 125 µmFISLL 2 Flow switch IFM SI 1002 0.03 – 3 m/s 0.18 m/s8 l/min 24VDCLubrication oil flow low, -too lowLI 2 Oil level indicator Overtoom G2"-240M2 Auxiliary motor WEG IEC80 0.75kW – 1500 rpm,380V-3ph-50HzGear pump Steimel SF 2/10 0 – 2500 kPa 1500 kPa Relief valve settingLPF240G E XX B1.0 0 – 5000 kPa HousingDischarge oil filter Hydac0240 D020 BN3HC 0 – 2500 kPa Element, 20 µm PI 2 Pressure gauge Econosto Fig.1382 0 – 1600 kPa ∅ 100 mm, 1/2"BSP,Stainless Steel, Liq.filled TC 2 Electric heaterThermostatic switchSchniewindt CSN-ERCT/60 0 …. 40°C 15°C 380V-3ph-50Hz,900WattDISCHARGE PULSATION DAMPENERPulsation dampener GEHO 150/160 150 L - 16000 kPa 60% Percentage of workingpressure (Pw%)Precharge, nitrogen onlyInstrument and equipment list Doc. 814.200885.02 Page 2 of 7TAG No. P & I No. DESCRIPTION MFR./SUPPL. MODEL/TYPE RANGE SETPOINT REMARKS RevPT 3 Pressure transmitter Bourdon E913 0-10000 kPa 8190 kPa8580 kPa Dis. pressure high Dis. pressure too highPI 3 Pressure gauge Econosto Fig.1382 0-10000 kPa ∅ 100 mm, 1/2"BSP,Stainless Steel, Liq.filledSUCTION AIRVESSELPI 8 Pressure gauge Econosto Fig.1382 0-1000 kPa ∅ 100 mm, 1/2"BSP,Stainless Steel, Liq.filledRELIEF VALVE SYSTEM based on 7800 kPa dis. pressurePSV5 Relief valve Leser 4582.6142 9000 kPa Excessive dischargepressure PI 5 Pressure gauge Econosto Fig.1382 0-10000 kPa ∅ 100 mm, 1/2"BSP,Stainless Steel, Liq.filledPROPELLING LIQUID SYSTEM based on max 200 kPa suc. pressureLI 6 Level indicator Stauf SNA Transparant tube Suction filter Hydac 0050 S 125 W Filter element 125 µm M 6 Auxiliary motor WEG IEC80 0.75kW – 1500 rpm,380V-3ph-50HzGear pump Steimel SF 2/6 0 – 2000 kPa 1400 kPa Relief valve settingInstrument and equipment list Doc. 814.200885.02 Page 3 of 7TAG No. P & I No. DESCRIPTION MFR./SUPPL. MODEL/TYPE RANGE SETPOINT REMARKS RevFISLL 6 Flow switch IFM SI 1002 0.03 – 3 m/s 0.38 m/s7 l/min 24 VDCPiston-lub. oil flow low – too lowLPF240G E XX B1.0 0 – 5000 kPa HousingDischarge oil filter Hydac0240 D020 BN3HC 0 – 2500 kPa Element, 20 µm Accumulator Hydac SB 330-6A1/112-330A6ltr-33 MPa 350 kPa Precharge, nitrogen onlyPT 6 Pressure transmitter Bourdon E913 0 – 1600 kPa 400 kPa500 kPa1000 kPa System pressure low START fill. accumulator STOP fill. accumulatorPI 6 Pressure gauge Econosto Fig.1382 0 – 1600 kPa ∅ 100 mm, 1/2"BSP,Stainless Steel, Liq.filledFI 6ABC Flow indicator Transparant hoseHV 1-3 Filling valves GEHO 2/2 way valve NW 7, Normally Open;Air to Close.HV 5-7 Outlet valves GEHO 2/2 way valve NW 7, Normally Open;Air to Close.SV 1-3 SV 5-7 3/2 solenoid valves Norgren XF V61 B* NW 6, 24VDC, NormallyOpen; Power to closeZSH 1-3 ZSL 1-3 Outlet proximity switchFilling proximity switchGEHO 24VDC Continuous for 3min: alarmHV 9 Propelling liquid supply valve GEHO 2/2 way valve NW 7, Normally Closed;Air to openInstrument and equipment list Doc. 814.200885.02 Page 4 of 7TAG No. P & I No. DESCRIPTION MFR./SUPPL. MODEL/TYPE RANGE SETPOINT REMARKS RevSV 9 3/2 Solenoid valve Norgren XF V61 B* NW 6, 24VDC, NormallyClosed;Power to OpenPT 7 Pressure transmitter Bourdon E913 0 – 1600 kPa 450 kPa400 kPa Air pressure low Air pressure too lowPI 7 Pressure gauge Econosto Fig.13820 – 1600 kPa ∅ 63 mm, 1/4 "BSP,Stainless Steel, Liq.filled SV 15 3/2 Solenoid valve Norgren XF V61 B* NW 6, 24VDC, NormallyClosed;Power to open HV 15 Change-over valve GEHO 2/2 way valve NW 7, Normally Open;Air to closeVent/filter Mahle PI 0114 MIC Connection, 3/4” BSP GEARBOXZS 10 Limit Switch Honeywell 2LS1 Protection guard closed. GEARBOX COOLING SYSTEMM 10A Auxiliary motor, gear pump Hansen 112M 4kW, 380V, 50Hz, 3ph,1440 rpm M 10B Auxiliary motor, cooling fan Hansen 1.1kW, 380V, 50Hz,3ph, 1500rpmGear pump Kracht 110-KF40R502PSV 10 Relief valve, gear pump Kracht 110-KF40R5028 bar Oil pressure too highInstrument and equipment list Doc. 814.200885.02 Page 5 of 7TAG No. P & I No. DESCRIPTION MFR./SUPPL. MODEL/TYPE RANGE SETPOINT REMARKS RevDouble change-over filter Mahle 256-5208400 60 µm filtration PDSH 10 Pressure differential switch Mahle 256-5208400 Filter contaminationTCV 10 Temperature control valve Behr-thomson 275-2530550 55°C Start to openHeat exchanger, oil to air Bugge 277-BKL600XTI 10 Temperature indicator Kobold 235-2338001 0-120°C Oil temperatureFSL 10 Flow switch Meister 308-DKME150010 38.5 l/m Alarm, oil flow lowTSH10 Temperature switch Kobold 315-TF20M90 90°C Oil temperature highMAIN DRIVE MOTOR, SIEMENS 1PQ4504-4CM00-ZTE 1ABC Temperature element Siemens Pt 100 130° C Wdg. Temp high (alarm)TE 1DEF Temperature element Siemens Pt 100 150° C Wdg. Temp too high (shutdown) M1B Cooling fan motor Siemens 690V,50Hz, 3ph,……kW Space heater, not used Siemens …. W, 220V, 50Hz, 1 ph TRANSFORMER, SIEMENSTI 11 Temperature indicator Oil temperaturePSL 11 Bucholz relay Sudden pressure rise orsignificant oil level drop LI 11 Level gauge Oil levelDehydrating breatherGENERALNon-return valve Walpro P-RV C-steelInstrument and equipment list Doc. 814.200885.02 Page 6 of 7TAG No. P & I No. DESCRIPTION MFR./SUPPL. MODEL/TYPE RANGE SETPOINT REMARKS RevTubing Walpro Ø6,12,28 C-steelBlock valve Pister BKH C-steelTubing fittings Walpro C-steelInstrument and equipment list Doc. 814.200885.02 Page 7 of 7。
