9260集中器程序升级(烧写)说明

S920软件升级说明书
目录
S920软件升级说明书 (1)
目录 (1)
第一章升级前软硬件准备 (2)
1.1 软件准备工作 (2)
1.2 硬件准备工作 (2)
第二章软件升级设备连接示例 (3)
第三章驱动安装 (4)
第四章软件升级 (4)
第一章升级前软硬件准备1.1 软件准备工作
1.1.1 升级工具软件
1.1.2 升级数据线驱动程序
1.2 硬件准备工作
1.2.1 升级数据线
第二章软件升级设备连接示例
GB 5pin-USB数据线
数据线I/O接口
连接到手机
数据线的USB端口
连接到电脑
第三章驱动安装
1、手机关机，用升级线连接手机和电脑，当PC未安装过驱动时会弹出新硬件向导，如下图：
2、选择“自动安装软件（推荐）”进行驱动安装
第四章软件升级
1、点击运行程序“Flash_tool”（路径：S920官方刷机工具_内附驱动和说明\MIUI-recovery for S920\MT6589_Android_scatter_emmc.txt），初始界面如下图：
2、升级成功界面如下：
3、上面三个步骤都操作完了之后，才通过USB连接线，连接上手机（此时手机必须是关机状态），连接手机后，会自动下载程序到手机里，成功会有一个绿色的圆圈，然后就可以拔掉USB数据
连接线，此时不要开机，如果立即开机会导致才安装好的REC丢失，应直接同时按电源键和
音量加减键，进入到REC工程模式进行一次刷机。

注意：安装MIUI-recovery for S920前请提前把你要卡刷的刷机包ROM放到你的内置储存卡或外置储存卡里，方便安装REC成功后马上刷机。

3G监控盘程序升级说明1.到达现场后，首先联机设备：根据实际机型选择相应的DCF文件，如下：本说明以CDMA干线放大器为例。

A.打开DCF文件后用RS232串口线联机，联机成功后，勾选“高级操作”选项，点击界面上“监控参量列表（F5）”，清空右边的设备参量列表，然后点击“查询参量列表”，查询设备参量，查询参量完毕后，点击“刷新界面”，刷新设备参量，如下图所示：B.勾选“基本信息”栏中的所有参量进行查询，如下图所示：D.勾选“告警状态和使能”栏中的所有参量进行查询，如下图所示：F.查询完后，点击LMS界面左上角“系统”，将其保存为DCF格式的文件，如下图所示：G.保存好之后，开始升级监控盘程序，升级方法如下：USB直接烧写镜像操作步骤：1硬件连接1.1使用USB-A+M头连接线，将USB-HUB（品牌：UNITEK）连上电脑，A头连接电脑USB插座，Mini口连接USB-HUB的USB-Mini插座；1.2将USB-A+B头连接线的A型插头插入USB-HUB的任一A型USB插座；1.3关闭监控盘电源；1.4拔下监控盘电源插头J603，使用短接块短接J101端子，插上监控盘电源插头J603；1.5将USB-A+B连接线的B型插头插入监控盘的B型USB插座（USB Device J401），此时，电脑自动安装USB-HUB驱动，待驱动安装完毕。

2软件烧录2.1打开监控盘电源，系统提示找到新硬件“3G Rpt Control&Monitor Board”，如图2-1所示，选择“从列表或指定位置安装（高级）（S）”，单击“下一步”，进入自动安装界面，如图2-2所示；图2-1 找到新硬件界面图2-2 Windows自动安装硬件驱动界面2.2待安装完成后，进入完成界面，如图2-3所示，单击“完成”完成硬件安装；图2-3 硬件驱动安装完成2.3将文件夹“USB-Dfu_9200”文件夹复制到硬盘上，本文以D盘为例，文件夹位置为“D：\USB-Dfu_9200”；2.4打开“USB-Dfu_9200”文件夹，运行程序“isp3G-USB”，出现如图2-4所示界面；图2-4 监控盘固件下载烧录界面2.5单击“设置与说明”按钮，打开路径加载设置界面，如图2-5所示；图2-5 “设置”界面2.6“设置”界面主要用于选择固件文件路径，在“一级文件”下选择bootloader文件（即“（usb）5.283.215.bin”）路径（本例中为“D：\usbDfu_9200\（usb）5.283.215.bin”），在“二级文件”下选择待烧录ISP文件（本例中即“WKE（W）5.283.494.bin”）路径（本例中为“D：\usbDfu_9200\ WKE（W）5.283.494.bin”）。

Title Date Event venue, Author
10
ThyssenKrupp Elevator (China)
I. 如何安装程序烧写软件工具 - MPLAB IDE
步骤7
在弹出的窗口中，选择“I accept the terms of the license agreement”， 并使用鼠标点击“Next >”按钮，如下图所示：
Title Date Event venue, Author
6
ThyssenKrupp Elevator (China)
I. 如何安装程序烧写软件工具 - MPLAB IDE
步骤3
安装软件启动后，会弹出如下窗口，使用鼠标点击“运行”按钮：
Title Date Event venue, Author
12
2
ThyssenKrupp Elevator (China)
I. 如何安装程序烧写软件工具 - MPLAB IDE
步骤9
在弹出的窗口中，使用鼠标点击“Next >”按钮，如下图所示：
Title Date Event venue, Author
13
ThyssenKrupp Elevator (China)
步骤5
随后将出现如下所示的窗口，开始拷贝安装文件；
Title Date Event venue, Author
9
ThyssenKrupp Elevator (China)
I. 如何安装程序烧写软件工具 - MPLAB IDE
步骤6
当安装文件拷贝完成后，将出现如下所示的窗口，使用鼠标点击 “Next >”按钮；
步骤1
将如下图所示安装光盘插入电脑光驱中，等待片刻，电脑将自动 进入软件安装引导界面；

Resolution for 6Gb RAID UpdatesThe new driver (2.10) and new flash bundle (June 22, 2011) have been causing issues for some end users. So here is a troubleshooting guide. The proper way to update from the previous version is as follows:1.Current driver must be2.07 and current flash must be April 18, 2011. This combination does notcause any issues.2.First, update the driver to 2.10. When the driver successfully installs, do NOT restart.3.Flash the card through the ATTO Configuration Tool. The process should take about a minute.When that updates successfully, THEN restart.4.When you boot up into the OS, no issues should occur. Open the ATTO Configuration Tool. Makesure the driver version is properly displayed (2.10) and the flash date is displayed (June 22,2011). This will indicate that the card is working normally.There may be some scenarios where the update did not follow this procedure. This will help you get the card functioning again.WINDOWS & LINUXFlashing the card with the latest flash (2011_06_22) and then restarting before updating to the latest driver (2.10) causes either the system to hang before booting into Windows or not booting into Windows at all. If you have the same setup in Linux, the system might hang briefly as well. You can force a restart in both OS’s if needed. In this case version 2.07 is already installed on the machine. If you do get into Windows and/or Linux, and in some cases you will, the adapter will show up as degraded in the ATTO Configuration Tool.There have been a few exceptions where I have been able to get the card out of degraded mode without hard flashing from the ISO.SIMPLE PROCEDURE (WINDOWS & LINUX) (*May not always work):1.If you can not boot into Windows or Linux with R680 installed, then follow the steps in the HARDFLASH PROCEDURE below. If you can get into Windows or Linux (it may take a few minutes) but the R680 is in degraded mode, go to step 2.2.Install driver 2.10 with the R680 in the machine. If driver does not successfully install, you willhave to follow the steps in the HARD FLASH PROCEDURE below.3.If flash date is shown (June 22, 2011) in the ATTO Configuration Tool along with a proper driverversion then the card is out of degraded mode and functioning normally. If flash date is notshown then flash card with 2011_06_22 flash bundle through ATTO Configuration Tool. Choose the appropriate bundle depending on what your specific OS is.4.If flash is successful then restart. Check ATTO Configuration Tool. If proper driver version andflash are displayed, then card is functioning normally. If flash is not successful, card will have to be hard flashed with 2011_06_22 flash ISO.MACIf you have this setup (2.07, 2011_06_22 flash) in Mac OS, a kernel panic will occur as soon as the machine boots into the OS.SIMPLE PROCEDURE (MAC ONLY) (*May not always work):1.When the panic occurs, force shutdown.2. Take the R680 out of the Mac and reboot. This will prevent the panic from keeping you out ofthe OS. The card should have the latest flash (2011_06_22) and the driver should be 2.07.3.Install driver 2.10 without the R680 installed in the Mac. (Note: This can only be done in Mac.) Iffor some reason you can not install driver 2.10, then you will have to follow the steps in theHARD FLASH PROCEDURE below.4.After the driver installs, shut down the Mac.5.Re-insert the R680 into the Mac and power back on. If you successfully boot into the OS (nokernel panic), check the ATTO Configuration Tool to see if the driver version and flash date are displayed. If both of them are displayed properly, then the card is functioning normally.HARD FLASH PROCEDURE - Please follow the necessary steps to solve this issue:1.Make sure driver2.07 is already installed is in the machine you are using with the R680.2.Burn the .iso (2011_04_18) file as a disk image to a blank cd with any burning program. This willbe used to hard flash the card back to the previous flash.3.When the burn completes, put the CD in a PC or Intel-based Mac. You will need one of thesemachines because the hard flashing utility uses DOS.4.Insert the R680 into the PC or Intel-based Mac and boot from the CD.Note: To boot from a CD on a Mac, hold down the "C" key when the computer is starting up.Note: To boot from a CD on a PC, this *must* be enabled in the BIOS boot sequence, or yourBIOS *must* have a boot menu option. On Dell BIOS's this is usually done by pressing the F11 key at POST. ASUS usually uses the F8 key at POST. When the menu comes up, choose theCDROM drive (optical drive) as the boot device.5.If the boot is successful, you will see a blue screen that will ask you to press the Enter key within30 seconds to boot to DOS.Note: If you do not press the Enter key within 30 seconds it will boot to your hard drive6.After DOS loads, the ATTO Flash Program will automatically start. You will see 6 options:1. Flash with BIOS2. Flash with x863. Flash with x644. Flash without BIOS or EFI5. Erase boot images without updating6. QuitChoose the option that corresponds to the OS or machine you are running. x64 for 64-bit, x86 for 32-bit.7.The Flash of the ATTO adapter will now be modified. The ATTO Flash Program should tell youwhat it is doing.8.After a successful flash, you should see a PASS banner and the computer will tell you to restart.9.Reboot into your operating system and open the ATTO Configuration Tool -- it should nowreport a proper driver (2.07) and a flash version (April 18, 2011).10.Now install the new driver (2.10). Make sure it is the appropriate driver if it is 32-bit (x86) or 64-bit (x64). When this is finished installing, do NOT restart.11.Now flash the card with the latest flash bundle (2011_06_22). Make sure you use the EFI-x64 for64-bit, x86 for 32-bit. It should take about a minute or so to flash the card. After the ATTOConfiguration Tool says that the flash has been successfully update, reboot the machine.12.The machine should boot into Windows normally. When Windows boots up, open the ATTOConfiguration Tool and check if the driver (2.10) and the flash (June 22, 2011) are beingdisplayed. This indicates the card is functioning normally.。
