952SXLONER ®T emperature ControlledSoldering Stationmade in U S A•COMPLIES WITH MIL-S-45743E, MIL-STD-2000, DOD-STD-2000-1B,WS6536E AND ESD SPEC, DOD-STD-1686, DOD-HDBK-263instruction manualSpecifications for Model 952SXPower Requirements120V, 50/60 HzPower Rating15W - 220WHeater Rating120V, 95WTemperature Range400°F-800°F/205°C-427°C Temperature Regulation±6°F/±3°CTip-to-Ground VoltageLeakage/Resistance< 2mV/< 2 ohmsOverall Dimension 4.1"W x 8.2"H x 10"D104 mm x 208 mm x 254 mmWeight 3.1 lbs/1.4 kgContents952SX includes 1 - LT375 Soldering Tip1 - LT337BC Soldering TipPD528Tool PodSH230Sponge Holder(Includes RS199 Cleaning Sponge,RS243 Leveling Pad, LN230 Liner)WP556WIGAPRY Low Static Computer AidWARNING:CAUTION:Over-filling can cause thermal shock to the tip or heating element during tip• Replace RS199 Cleaning Sponge 1. Fill water only up to the top of the RS243Leveling Pad.• Replace SC581 Solder Collector 1. Hold the Housing firm and turn Capcounter-clockwiseand pull it away from the Housing.2. Remove used SC581 and replace with a new one.3. Reassemble Pod with TOP of the Cap inMAINTENANCESH230ToolPower SwitchSolderFrontThermalt o ma t c h t e mp e r a t u r e ma r k i n g s o n t h e f r o n t p a n e l.)M E T E RCHANGING TIP1. MAKE SURE YOUR TOOL IS COOL!2. Turn Retaining Sleeve counter-clockwise to remove.3. Remove old Soldering Tip.4.Insert new Tip.5.Install Retaining Sleeve. (should be "finger" tight only.)Large and heavy tip for heavy duty soldering.Fine point tip for SMD soldering.*AN122 Anti-Seize Compound comes in syringe dispenser.DO NOT USE the soldering tool if soldering tip is loose. This will cause the heater element to break.Retaining SleeveRS271- for Heavy Duty TipSoldering Tip952SX LONER® SOLDERING STATION SPARE PARTS LIST1PD528Tool Pod21A SR042Thermal Housing for Tool Pod 21B SC581Solder Collector for Tool Pod 21C SR043Front Housing for Tool Pod22SH230General Purpose Sponge Holder 12A RS199Cleaning Sponge12B RS243Leveling Pad for SH23012C LN230Liner for SH23012D SH230-1Sponge Holder Tray 13SR303Control Panel Label14SR452Power Switch, Illuminated 15SR068Knob, Temperature Control26SR2435K Potentiometer, Temperature Control 27SR015Flat Head Screw- Slotted #6 - 32 x 1/249SR467Hex Nut- #6 - 32410SR781Top Case 111SR019Dove Tail Mount 11215002W95Circuit Board213SR573LED Assy.214SR052Bottom Base115SR011Pan Head Screw- Phillip #6 - 18 x 5/8516SR054Bottom Weight 117SR313Power Cord Assy.118SR251Rubber Foot41920SR241Strain Relief for Power Cord 121SR249Fuse, 250V, 1 A (5mm x 20 mm)222SR298Soldering Tool, Complete Assembly 222A SR057Handle for Tool 222B SR058Cord Strain Relief122C SR280Tool Cord Assy., Burn Proof222D SR060Heater Element Assembly Kit (O-Ring (22E) & Collar (22g) Included 222E SR062O-Ring222F SR063Vinyl Sleeve 222G SR064Collar222H LT375LONER ® Standard Spade Tip 122I RS382Retaining Sleeve 122J RB386Retaining Bushing122K SR525Silicone Hose, Low Static (sold per foot)5-1/4"23SR053Strain Relief for Tool Cord 124SR255Spacer for Potentiometer225SR310Label, Calibration Pot, Right Front or Left Rear 126SR311Label, Calibration Pot, Left Front or Right Rear 127LT337BC Heavy Duty Soldering Tip 128RS271Retaining Sleeve, Heavy Duty1ITEM NO.PART NO.DESCRIPTIONQTY REQ'D952SXi.pdf FORM.952SX instruction manualALL RIGHTS RESERVED.NO PART OF THIS PUBLICATION INCLUDING THE INDIVIDUAL ICONS MAY BE REPRODUCED OR UTILIZED IN ANY FORM OR BY ANY MEANSWITHOUT THE PERMISSION OF EDSYN, INC.THE NAMES LONER, SOLDAPULLT, SOLDAVAC, ATMOSCOPE, AUTO-VAC, IDLE-REST,OCTAVAC AND KLATCHARE REGISTERED TRADEMARKS OF EDSYN, INC.MOST PRODUCTS ARE COVERED BY U.S. AND FOREIGN PATENTS AND PENDING APPLICATIONS.DESIGN, COLOR AND MATERIALSSUBJECT TO CHANGE WITHOUT NOTICE.TIP STYLE ON SOLDERING, DESOLDERING AND HOT AIR TOOLS MAY VARY.PRINTED IN U.S.A.©Copyright EDSYN, Inc. 2002IntellectualProperty。

Blocking test at ± 10MHz
To Be Defin.
dB
See note 3
Image frequency rejection
To Be Defin.
dB
See note 2
Output square wave
0,05
1
3
KHz
Input square wave
0,01
3
kHz
RSSI (pin 8)
AUR.EL RTX-MID-868-FSK
AUR.EL RTX-MID-868-OOK
---------------------------------------------------------------------------------------------------------------------------------------------------来自-109-111
dBm
RF irradiated power (OOK and FSK)
7
8,5
10
dBm
FSK ∆F deviation
±25
KHz
See note 1
OOK Modulation
100
%
Blocking test at ± 2MHz
To Be Defin.
dB
See note 3
MECHANICAL DIMENSIONS and PIN-OUT
Pin-Out
1) RF INPUT/OUTPUT 2) GND 3) PIN NOT CONNECTED 4) INPUT DIGITAL DATA 5) TX/RX 6) ENABLE 7) GND 8) RSSI OUT 9) OUTPUT DIGITAL DATA 10) +Vcc

Copyright 2007 Carrier CorporationForm 33CS-33PSThe PremierLink retrofit controllers offer:•continuous monitoring and regulation of the rooftop unit•compatibility with Carrier diagnostic display tools•other devices can read and write data to the controller•ability to connect unit to the Carrier Comfort Network® (CCN) systemFeatures/BenefitsThe PremierLink retrofit rooftop controller is an intelligent control thatcontinuously monitors and regulates rooftop operation with reliability and precision that minimizes downtime to ensure maximum occupant comfort.The PremierLink controller is compati-ble with the Carrier ComfortNetwork (CCN) system. Carrier’s diag-nostic standard tier display tools such as System Pilot™ or Touch Pilot™ device can be used with the PremierLink con-troller. User interfaces include the CCN Service Tool, ComfortVIEW™ and ComfortWORKS ® software.When the PremierLink controller is used as part of the CCN system, otherdevices such as the CCN data transfer, 3V™ linkage coordinator, or Comfort Controller can read data from or write data to the retrofit controller.PREMIERLINK™Retrofit RooftopController33CSPREMLKProductSpecificationa33-91472Extensive control capabilitiesThe 33CSPREMLK retrofit controller provides the following features and benefits:•provides software clock and local occupancy schedule for local occu-pancy control (requires time broad-caster and hardware clock from another device in the system)•uses remote timeclock input to pro-vide occupancy control through exter-nal contacts or this input can be reconfigured for use with a door or window switch to disable heating and cooling if a door or window is left open•provides continous or intermittent fan operation in the occupied mode•features supply air temperature limit-ing and integrated safeties for DX (direct expansion), gas, electric and heat pump units•provides field tests that enables the user to check output points and verify their functionality•controls two stages of DX cooling to maintain space temperature set point •ability to provide occupied and unoc-cupied dehumidification•controls up to 3 stages of gas heat or combination of mechanical and elec-tric heat to maintain space tempera-ture set point•ability to control exhaust fan based on economizer or occupancy on 2-stage heat units•ability to control reversing valve on heat pump units•provides temperature compensated start of heating or cooling to achieve set point by the start of the sched- uled occupied time•provides alarms for analog tempera-ture input(s) out of range•provides alarm for space tempera-ture deviation from desired set point •adjustable filter maintenance timer •allows manual and system overrides of selected input/output channels•supports CCN remote timed override, set point adjustment and manual fan control override•provides Broadcast Acknowledger capability for CCN (configuration)•conforms to the general require- ments for CCN devices•modulates control of economizer to assist mechanical cooling without adversely affecting compressor performance•provides ventilation monitoring with optional CO 2 ventilation sensor •compatible with T55 space sensor and T56 space sensor with set point adjustment, timed override and ser-vice port jack•compatibility with T58 communicat-ing sensor provides set point adjust-ment, timed override, force fan, and read equipment mode•compatibility with System Pilot as a communicating sensor providing set point adjustment, timed override, and a user interface for programming, configuration, and monitoring and forcing points•support a local or global occupancy schedule or remote start input status to determine occupancy•individual fan start delay for each Premierlink™ board upon occupancy change.Available for wide range of rooftop applicationsThe PremierLink controller is available as a field retrofit application and can control one or several rooftop units with (multiple controllers) from 3 to 25 tons. In addition, it has an integrated economizer controller that eliminates the need for a separate cir-cuit board.The PremierLink controller can be installed on the following Carrier rooftop units: 48/50HE (2 to 5 tons), 50HEQ (2 to 5 tons), 48/50HJ (3 to 25 tons),50HJQ (3 to 15 tons), 48TF/50TFF (3 to 121/2 tons), 50TFQ (3 to 10 tons), 48/50TJ (121/2 to 25 tons), and 48/50TM (3 to 25 tons). Other Carrier equipment and non-Carrier equipment can also be controlled by PremierLink controller. Con-tact a Carrier Factory Sales representative for more information.Flexibility for every applicationThe PremierLink controller is an ad- vanced microprocessor-based control. PremierLink is precision controlled to send heating and cooling only when needed, reducing energy use and operat-ing costs.Carrier linkage compatibilityWhen used as the air source for a 3V™ zoning system, the PremierLink control-ler will use occupancy schedules, zone temperature, and set points from the 3V linkage coordinator. The PremierLink controller provides the 3V linkage coordi-nator with the unit’s operating mode and supply-air temperature to provide coordi-nation of the individual member zone's local mode with the system mode.Additional control featuresThe PremierLink controller provides addi-tional control features such as Occupied/Unoccupied schedulinginitialized via the network. The Premier-Link controller offers override invoked from a wall sensor during unoccupied hours from 1 to 4 hours in 1-hour increments.The PremierLink controller offers venti-lation monitoring with an optional CO 2 ventilation sensor. The CO 2 ventilation sensor measures the amount of ventilation needed by the space and a proportional integral derivative loop (PID) calculation makes adjustments to the economizer minimum position during occupied opera-tion. The indoor CO 2 will be compared to an outdoor CO 2 reference before making adjustments to the economizer minimum position.Using a space sensor with set point adjustment, timed override and service port jack, the PremierLink controller will provide intelligent compressor staging and economizer operation.Modulating control of the economizer will assist mechanical cooling without adversely affecting compressor perfor-mance. Economizer assisted cooling is determined from a comparison of space temperature, outside air temperature and an enthalpy switch input. The switch input can also be used for differential enthalpy input, meeting ASHRAE (American Soci-ety of Heating, Refrigeration, and Air Conditioning Engineers) Standard 90.1. The T58 Communicating Space tem-perature sensor with service port jack pro-vides set point adjustment, timed override, force fan and read equipment mode and measures and maintains room tempera-ture by communicating with the Premier-Link controller.Using an optional indoor humidity sensor, the PremierLink control can providedehumidification control on units that are equipped to provide dehumidification.Simple mounting and ease of installationThe PremierLink controller has an inte-grated plastic cover with secured with two plastic tabs that can be removed for ease of installation.For ease of installation, the PremierLink controller is provided with removable Molex connectors which include pigtails for easy installation to unit or sensors using spade connectors or wire nuts. The removable connectors are designed so that they can be inserted one way so as to prevent installation errors. The Premier-Link controller also provides an RJ-11 modular phone jack for the Network Ser-vice Tool connection to the module via the Carrier Comfort Network® (CCN) communications.Features/Benefits (cont)3User interfaceThe PremierLink™ controller is designed to allow a service person or building owner to configure and operate the unit through the CCN user interface. A user interface is not required for day-to-day operation. All maintenance, config-uration, setup, and diagnostic information is available through the L evel II communications port to allow data access by an attached computer running Network Service Tool, ComfortVIEW ™, or ComfortWORKS ® software.Data access also can be obtained from System Pilot™ or Touch Pilot™ devices.Wiring connectionsField wiring is 18 to 22 AWG (American Wire Gage). The PremierLink controller is a NEC (National Electrical Code)Class 2 rated device.Inputs•space temperature sensor •set point adjustment•outdoor air temperature sensor •indoor air quality sensor•outdoor air quality sensor/indoor humidity sensor •compressor lockout •fire shutdown •supply fan status•remote time clock/door switch •enthalpy status Outputs•economizer •fan•cool stage 1•cool stage 2•heat stage 1•heat stage 2•heat stage 3/exhaust/reversing valve/dehumidify/occupiedPower supply2-wire, 24 VAC ± 15% at 40 va, 60 HzPower consumptionNormal operating supply range is 18 to 32 VAC with mini-mum consumption of 10 VAHardware (memory)Internal flash memory of 64KSpecified sensing temperature rangeThe PremierL ink controller space temperature range is –40 to 245 F (–40 to 118 C). The PremierLink controller has an allowable control set point range from 40 to 90 F(4 to 32 C) for heating and 45 to 99 F (7 to 37 C) for cooling.CommunicationsThe number of PremierLink controllers is limited only by the maximum number of controllers allowed on a CCN sys-tem. Bus length may not exceed 4000 ft (1219 m), with no more than 60 devices on any 1000 ft (305 m) section.Optically isolated RS-485 repeaters are required every 1000 ft (305 m). Status and control data is transmitted at a baud rate of between 9600 and 38.4K.Activity indicatorsTwo activity indicators present on the PremierLink control-ler indicate activity. A green LED will indicate activity on the communication port and a red LED will indicate status of processor operation.DimensionsHeight: 53/4-in. (146 mm)Width: 81/2-in. (216 mm)Depth: 3-in. (76 mm)Minimum service dimensionsHeight: 7-in. (178 mm)Width: 9-in. (229 mm)Depth: 4-in. (102 mm)Environmental ratingsOperating Temperature: –40 to 158 F (–40 to 70 C) at 10to 95% RH (non-condensing)Storage Temperature: –40 to 185 F (–40 to 85 C) at 10 to 95% RH (non-condensing)VibrationPerformance vibration: all planes/directions, 1.5G at 20to 300 HzShockOperation: all planes/directions, 5G peak, 11 ms Storage: all planes/directions, 100G peak, 11 msCorrosionOffice environment. Indoor use only.ApprovalsL isted under UL 873, UL 94-V0/5VB (plastic), and UL ,Canada.Standard complianceCE Mark, ASHRAE 90 and ASHRAE 62-99 compliant.NOTE: Compliance standards subject to change without notice.Field-installed accessoriesSupply air temperature sensor — The 33ZCSENSAT supply air temperature sensor is required for all applica-tions to monitor the temperature of the air delivered. A second supply air temperature sensor set to thermostat mode (or a space temperature sensor) must be installed in the return air for proper economizer and IAQ (indoor air quality) control.Space temperature sensor with override button —The space temperature sensor monitors room temperature which is used by the PremierLink controller to determine the temperature of conditioned air that is allowed into the space.SpecificationsManufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations.New Pg 4Catalog No. 04-52330009-01Printed in U.S.A. Form 33CS-33PSReplaces: 33CS-19PS Book 14Tab 11a 13aCarrier Corporation • Syracuse, New Y ork 132216-07Book 1Tab 1CS1a33-9142The 33ZCT55SPT (T55) space temperature sensor with override button is required for all applications. The space temperature sensor monitors room temperature which is used by the PremierLink™ controller to deter-mine the temperature of conditioned air that is allowed into the space.Space te mperature sensor with override button and se t point adjustme nt — The 33ZCT56SPT (T56) space temperature sensor with override button and set point adjustment can be used in place of the 33ZCT55SPT (T55) space temperature sensor if local set point adjustment is required. The space temperature sensor monitors room temperature which is used by the PremierLink controller to determine the temperature of conditioned air that is allowed into the space.T58 communicating sensor with override button,set point adjustment, and manual fan control —The 33ZCT58SPT (T58) communicating room sensor with override button, set point adjustment, and manual fan control can be used in place of the 33ZCT55SPT space temperature sensor. The T58 communicating room sensor measures and maintains room temperature by communicating with the controller.Syste m Pilot™ (33PILOT-01) — The System Pilot device is a communicating room sensor with override button and set point adjustment that can be used in place of the T56 space temperature sensor. The System Pilot communicating room sensor measures and main-tains room temperature by communicating with the controller.The System Pilot device can be also be used to install,commission, and monitor a PremierL ink controller, a 3V™ zoning system, a universal controller, and all other devices operating on the CCN system. The System Pilot device has a hardware clock and can be used as CCN time broadcaster.Humidity se nsor — The relative humidity sensor (33ZCSENSRH-01) is required for dehumidification control. The rooftoop unit must be equiped with neces-sary accesories to perfom dehumidification. The sensor can also be used for monitoring only.NOTE: The relative humidity sensor and outdoor CO 2sensor cannot be installed on the same zone controller.CO 2 sensor — Three different CO 2 sensors are avail-able for monitoring space indoor-air quality.The 33ZCSENCO2 sensor is an indoor, wall-mount-ed sensor with an L ED (light-emitting diode) display.The sensor has an analog output (0 to 10 vdc or 4 to 20mA) over a range of 0 to 2000 ppm. An SPDT contact is provided to close at 1000 ppm with a hysteresis of 50 ppm.The 33ZCT55CO2 sensor is an indoor, wall-mounted sensor without display. The CO 2 sensor also includes a space temperature sensor with override button.The 33ZCT56CO2 sensor is an indoor, wall-mounted sensor without display. The CO 2 sensor also includes a space temperature sensor with override button and tem-perature offset.DimensionsField-installed accessories (cont)。

BCL 308i SF 100Stationary bar code readerFigure can varyTechnical dataBasic dataSeries BCL 300iFunctionsFunctions Reference code comparisonLED indicatorAlignment modeAutoReflActCode fragment technologyAutoControlAutoConfigCharacteristic parametersMTTF110 yearsRead dataCode types, readable Code 392/5 InterleavedCode 93UPCCodabarGS1 Databar LimitedCode 128GS1 Databar OmnidirectionalGS1 Databar ExpandedEAN 8/13Scanning rate, typical1,000 scans/sBar codes per reading gate, max. number64 Piece(s)Optical dataReading distance70 ... 445 mmLight source Laser,RedLaser light wavelength655 nmLaser class2,IEC/EN 60825-1:2007Transmitted-signal shape ContinuousUsable opening angle (reading field opening)60 °Module size0.3 ... 0.5 mmReading method Line scanner with deflecting mirrorBeam deflection By means of rotating polygon mirror wheel + deflecting mirror Light beam exit Lateral with deflecting mirrorElectrical dataProtective circuit Polarity reversal protectionPerformance dataSupply voltage18 ... 30 V,DCPower consumption, max. 4.5 WInputs/outputs selectableCurrent, max.60 mANumber of inputs/outputs selectable 2 Piece(s)Input current, max.8 mAInterfaceType EthernetEthernetArchitecture ServerClientAddress assignment Manual address assignmentDHCP Transmission speed10 Mbit/s100 Mbit/s Function ProcessSwitch functionality IntegratedTransmission protocol TCP/IP , UDPService interfaceType USBUSBFunction Configuration via softwareServiceConnectionNumber of connections 1 Piece(s) Connection 1Type of connection Plug connectorFunction BUS INBUS OUTConnection to devicePWR / SW IN/OUTService interfaceData interface No. of pins32 -pinType MaleMechanical dataDesign CubicDimension (W x H x L)103 mm x44 mm x96 mm Housing material Metal,Diecast aluminum Lens cover material GlassNet weight350 gHousing color RedBlackType of fastening Dovetail groovesVia optional mounting deviceFastening on backOperation and displayType of display LEDNumber of LEDs 2 Piece(s)Type of configuration Via web browserEnvironmental dataAmbient temperature, operation0 ... 40 °CAmbient temperature, storage-20 ... 70 °CRelative humidity (non-condensing)0 ... 90 %CertificationsDegree of protection IP 65Protection class IIICertifications c UL USTest procedure for EMC in accordance with standard EN 55022EN 61000-4-2, 3, -4, -6 Test procedure for shock in accordance with standard IEC 60068-2-27, test Ea Test procedure for continuous shock in accordance with standard IEC 60068-2-29, test Eb Test procedure for vibration in accordance with standard IEC 60068-2-6, test FcClassification*********27280102*********27280102ETIM 5.0EC002550Dimensioned drawingsAll dimensions in millimetersElectrical connectionConnection 1Type of connection Plug connector Function BUS INBUS OUTConnection to devicePWR / SW IN/OUTService interfaceData interfaceNo. of pins32 -pinType Male DiagramsReading field curvex Reading field distance [mm]y Reading field width [mm]Operation and displayLEDsLED Display Meaning1PWR Green, flashing Device ok, initialization phase Green, continuous light Device OKGreen, briefly off - on Reading successfulgreen, briefly off - briefly red - on Reading not successfulOrange, continuous light Service modeRed, flashing Device OK, warning setRed, continuous light Error, device error2BUS Green, flashing InitializationGreen, continuous light Bus operation okRed, flashing Communication errorRed, continuous light Bus errorAccessoriesConnection technology - Connection cablesPart no.Designation Article Description50132077KD U-M12-5A-V1-020Connection cable Connection 1: Connector, M12, Axial, Female, A-coded, 5 -pin Connection 2: Open endShielded: NoCable length: 2,000 mmSheathing material: PVC50132079KD U-M12-5A-V1-050Connection cable Connection 1: Connector, M12, Axial, Female, A-coded, 5 -pin Connection 2: Open endShielded: NoCable length: 5,000 mmSheathing material: PVC50132080KD U-M12-5A-V1-100Connection cable Connection 1: Connector, M12, Axial, Female, A-coded, 5 -pin Connection 2: Open endShielded: NoCable length: 10,000 mmSheathing material: PVC50132432KD U-M12-5A-V1-300Connection cable Connection 1: Connector, M12, Axial, Female, A-coded, 5 -pin Connection 2: Open endShielded: NoCable length: 30,000 mmSheathing material: PVC50135073KS ET-M12-4A-P7-020Connection cable Suitable for interface: EthernetConnection 1: Connector, M12, Axial, Male, D-coded, 4 -pinConnection 2: Open endShielded: YesCable length: 2,000 mmSheathing material: PUR50135074KS ET-M12-4A-P7-050Connection cable Suitable for interface: EthernetConnection 1: Connector, M12, Axial, Male, D-coded, 4 -pinConnection 2: Open endShielded: YesCable length: 5,000 mmSheathing material: PUR50135075KS ET-M12-4A-P7-100Connection cable Suitable for interface: EthernetConnection 1: Connector, M12, Axial, Male, D-coded, 4 -pinConnection 2: Open endShielded: YesCable length: 10,000 mmSheathing material: PUR50135076KS ET-M12-4A-P7-150Connection cable Suitable for interface: EthernetConnection 1: Connector, M12, Axial, Male, D-coded, 4 -pinConnection 2: Open endShielded: YesCable length: 15,000 mmSheathing material: PUR50135077KS ET-M12-4A-P7-300Connection cable Suitable for interface: EthernetConnection 1: Connector, M12, Axial, Male, D-coded, 4 -pinConnection 2: Open endShielded: YesCable length: 30,000 mmSheathing material: PURConnection technology - Interconnection cablesPart no.Designation Article Description50106901KBET-10000-SSA InterconnectioncableSuitable for interface: EthernetConnection 1: Connector, M12, Axial, Male, D-coded, 4 -pinConnection 2: Connector, M12, Axial, Male, D-coded, 4 -pinShielded: YesCable length: 10,000 mmSheathing material: PUR50106902KBET-15000-SSA InterconnectioncableSuitable for interface: EthernetConnection 1: Connector, M12, Axial, Male, D-coded, 4 -pinConnection 2: Connector, M12, Axial, Male, D-coded, 4 -pinShielded: YesCable length: 15,000 mmSheathing material: PUR50106899KB ET-2000-SSA Interconnectioncable Suitable for interface: EthernetConnection 1: Connector, M12, Axial, Male, D-coded, 4 -pin Connection 2: Connector, M12, Axial, Male, D-coded, 4 -pin Shielded: YesCable length: 2,000 mmSheathing material: PUR50106905KBET-30000-SSA InterconnectioncableSuitable for interface: EthernetConnection 1: Connector, M12, Axial, Male, D-coded, 4 -pinConnection 2: Connector, M12, Axial, Male, D-coded, 4 -pinShielded: YesCable length: 30,000 mmSheathing material: PUR50106900KB ET-5000-SSA Interconnectioncable Suitable for interface: EthernetConnection 1: Connector, M12, Axial, Male, D-coded, 4 -pin Connection 2: Connector, M12, Axial, Male, D-coded, 4 -pin Shielded: YesCable length: 5,000 mmSheathing material: PUR50117011KB USB A - USBminiB Service line Suitable for interface: USBConnection 1: USBConnection 2: USBShielded: YesCable length: 1,500 mmSheathing material: PVC50135080KSS ET-M12-4A-RJ45-A-P7-020InterconnectioncableSuitable for interface: EthernetConnection 1: Connector, M12, Axial, Male, D-coded, 4 -pinConnection 2: RJ45Shielded: YesCable length: 2,000 mmSheathing material: PUR50135081KSS ET-M12-4A-RJ45-A-P7-050InterconnectioncableSuitable for interface: EthernetConnection 1: Connector, M12, Axial, Male, D-coded, 4 -pinConnection 2: RJ45Shielded: YesCable length: 5,000 mmSheathing material: PUR50135082KSS ET-M12-4A-RJ45-A-P7-100InterconnectioncableSuitable for interface: EthernetConnection 1: Connector, M12, Axial, Male, D-coded, 4 -pinConnection 2: RJ45Shielded: YesCable length: 10,000 mmSheathing material: PUR50135083KSS ET-M12-4A-RJ45-A-P7-150InterconnectioncableSuitable for interface: EthernetConnection 1: Connector, M12, Axial, Male, D-coded, 4 -pinConnection 2: RJ45Shielded: YesCable length: 15,000 mmSheathing material: PUR50135084KSS ET-M12-4A-RJ45-A-P7-300InterconnectioncableSuitable for interface: EthernetConnection 1: Connector, M12, Axial, Male, D-coded, 4 -pinConnection 2: RJ45Shielded: YesCable length: 30,000 mmSheathing material: PURConnection technology - ConnectorsPart no.Designation Article Description50108991D-ET1Connector Suitable for interface: EthernetConnection: RJ4550020501KD 095-5A Connector Connection: Connector, M12, Axial, Female, A-coded, 5 -pin50112155S-M12A-ET Connector Suitable for interface: EthernetConnection: Connector, M12, Axial, Male, D-coded, 4 -pinConnection technology - Terminal boxesPart no.Designation Article Description50131255*ME 308 103Connection unit Suitable for: BCL 308iSuitable for interface: EthernetNumber of connections: 4 Piece(s)Connection: Cable with connector, M12, 900 mm 50131254*ME 308 104Connection unit Suitable for: BCL 308iSuitable for interface: EthernetNumber of connections: 5 Piece(s)Connection: Cable with connector, M12, 900 mm 50116466*MK 308Connection unit Suitable for: BCL 308iSuitable for interface: EthernetNumber of connections: 4 Piece(s)Connection: Terminal50114823*MS 308Connection unit Suitable for: BCL 308iSuitable for interface: EthernetNumber of connections: 4 Piece(s)Connection: Connector, M12* Necessary accessories, please order separatelyConnection technology - AdaptersPart no.Designation Article Description50109832KDS ET-M12 /RJ45 W-4P Adapter Suitable for: EthernetNumber of connections: 2 Piece(s)Connection 1: Connector, M12, Angled, Female, D-coded, 4 -pinConnection 2: RJ45Mounting technology - Mounting bracketsPart no.Designation Article Description50121433BT 300 W Mounting device Contains: 4x M4 x 10 screw, 4x position washers, 4x lockwashersDesign of mounting device: Angle, L-shapeMounting bracket, at system: Through-hole mountingMounting bracket, at device: Screw typeType of mounting device: AdjustableMaterial: MetalMounting technology - Rod mountsPart no.Designation Article Description50121434BT 300 - 1Mounting device Contains: 4x M4 x 10 screw, 4x position washers, 4x lockwashersDesign of mounting device: Mounting systemMounting bracket, at system: For 12 mm rod, For 14 mm rod,For 16 mm rodMounting bracket, at device: Screw typeType of mounting device: Turning, 360°, AdjustableMaterial: MetalPart no.Designation Article Description50027375BT 56Mounting device Design of mounting device: Mounting systemMounting bracket, at system: For 16 mm rod, For 18 mm rod,For 20 mm rodMounting bracket, at device: ClampableMaterial: MetalTightening torque of the clamping jaws: 8 N·mFunctions: Static applications50121435BT 56 - 1Mounting device Design of mounting device: Mounting systemMounting bracket, at system: For 12 mm rod, For 14 mm rod,For 16 mm rodMounting bracket, at device: ClampableMaterial: MetalTightening torque of the clamping jaws: 8 N·mFunctions: Static applicationsMounting technology - OtherPart no.Designation Article Description50111224BT 59Mounting bracket Mounting bracket, at system: Groove mountingMounting bracket, at device: ClampableMaterial: Metal50124941BTU 0300M-W Mounting device Mounting bracket, at system: Through-hole mountingMounting bracket, at device: Clampable, Groove mountingMaterial: MetalReflective tapes for standard applicationsPart no.Designation Article Description50106119REF 4-A-100x100Reflective tape Design: RectangularReflective surface: 100 mm x 100 mmMaterial: PlasticChemical designation of the material: PMMAFastening: Self-adhesiveGeneralPart no.Designation Article Description50120731Housing BCL 300iV2A Protective housing Suitable for: BCL 3xxi series bar code reader, deflecting mirror Length: 63 mmHousing material: Stainless steelStandard designation, housing: V2ALens cover material: GlassDegree of protection: IP 67, IP 69KNotesObserve intended use!•This product is not a safety sensor and is not intended as personnel protection.•The product may only be put into operation by competent persons.•Only use the product in accordance with its intended use.WARNING! LASER RADIATION – LASER CLASS 2Never look directly into the beam!The device satisfies the requirements of IEC60825-1:2007 (EN60825-1:2007) safety regulations for a product of laser class2as well as the U.S.21CFR1040.10 regulations with deviations corresponding to "Laser Notice No.50" from June 24, 2007.•Never look directly into the laser beam or in the direction of reflected laser beams! If you look into the beam path over a longer time period, there is a risk of injury to the retina.•Do not point the laser beam of the device at persons!•Interrupt the laser beam using a non-transparent, non-reflective object if the laser beam is accidentally directed towards a person.•When mounting and aligning the device, avoid reflections of the laser beam off reflective surfaces!•CAUTION! Use of controls or adjustments or performance of procedures other than specified herein may result in hazardous light exposure.•Observe the applicable statutory and local laser protection regulations.•The device must not be tampered with and must not be changed in any way.There are no user-serviceable parts inside the device.Repairs must only be performed by Leuze electronic GmbH + Co. KG.NOTEAffix laser information and warning signs!Laser information and warning signs are affixed to the device. In addition, self-adhesive laser information and warning signs (stick-on labels) are supplied in several languages.•Affix the laser information sheet to the device in the language appropriate for the place of use. When using the device in the US, use the stick-on label with the "Complies with 21CFR1040.10" note.•Affix the laser information and warning signs near the device if no signs are attached to the device (e.g. because the device is too small) or if the attached laser information and warning signs are concealed due to the installation position.•Affix the laser information and warning signs so that they are legible without exposing the reader to the laser radiation of the device or other optical radiation.。
