DATASHEETDataOrdering dataProduct type description MZM 100 B ST-1P2PW2RE-A Article number (order number)101211068EAN (European Article Number)4030661389103eCl@ss number, version 9.027-27-26-03eCl@ss number, version 11.027-27-26-03eCl@ss number, version 12.027-27-26-03ETIM number, version 7.0EC002593ETIM number, version 6.0EC002593Approvals - StandardsCertificates TÜVcULusEACGeneral dataStandards EN 60947-5-3EN ISO 13849-1EN ISO 14119IEC 61508Coding Universal codingLowCoding level according to ISO14119Working principle inductiveEnclosure material Glass-fibre, reinforced thermoplastic Gross weight645 gTime to readiness, maximum4,000 msReaction time, maximum150 msDuration of risk, maximum150 msGeneral data - FeaturesPower to lock YesActuator monitored YesLatching YesShort circuit detection YesCross-circuit detection YesSeries-wiring YesSafety functions YesIntegral system diagnostics, status YesNumber of safety contacts2Number of series-wiring of sensors31Safety classificationStandards EN ISO 13849-1IEC 61508Safety classification - Interlocking functionPerformance Level, up to eCategory4PFH value 3.54 x 10⁻⁹ /hSafety Integrity Level (SIL),3suitable for applications inMission time20 Year(s)Mechanical dataMechanical life, minimum1,000,000 OperationsNote (Mechanical life)Actuating speedOperations for door weights ≤ 5 kg Holding force, typically750 NHolding force, guaranteed500 NLatching force, minimum30 NLatching force, maximum100 NMechanical data - Connection techniqueType of connection Connector M23, 8+1-poleMechanical data - DimensionsLength of sensor40 mmWidth of sensor40 mmHeight of sensor179 mmAmbient conditionsDegree of protection IP65IP67Ambient temperature, minimum-25 °CAmbient temperature, maximum+55 °CStorage and transport-25 °Ctemperature, minimum+70 °CStorage and transporttemperature, maximumRelative humidity, minimum30 %Relative humidity, maximum95 %Note (Relative humidity)non-condensingnon-icingResistance to vibration to EN10 … 150 Hz, amplitude 0.35 mm60068-2-6Restistance to shock30 g / 11 msProtection class IIIAmbient conditions - Insulation valuesRated insulation voltage U32 VDCiRated impulse withstand voltage U0.8 kVimpOvervoltage category IIIDegree of pollution to VDE 01003Electrical dataOperating voltage, minimum20.4 VDCOperating voltage, maximum26.4 VDC600 mANo-load supply current, maximum IOperating current50 mARequired rated short-circuit100 Acurrent to EN 60947-5-1Note Cable length and cable section alter the voltage drop depending on the outputcurrentSwitching frequency, maximum 1 HzElectrical data - Magnet controlSwitching thresholds-3 V … 5 V (Low)15 V … 30 V (High) Classification ZVEI CB24I, Sink C0Classification ZVEI CB24I, Source C1C2C3Electrical data - Safety digital inputsSwitching thresholds−3 V … 5 V (Low)15 V … 30 V (High) Classification ZVEI CB24I, Sink C1Classification ZVEI CB24I, Source C1C2C3Electrical data - Safety digital outputs250 mARated operating current (safetyoutputs), maximum 1 VVoltage drop Ud0.5 mALeakage current IrVoltage, Utilisation category DC-1324 VDCCurrent, Utilisation category DC-130.25 A Classification ZVEI CB24I, Source C1Classification ZVEI CB24I, Sink C1Electrical data - Diagnostic outputs, maximum 2 VVoltage drop UdVoltage, Utilisation category DC-1324 VDCCurrent, Utilisation category DC-130.05 AStatus indicationNote (LED switching conditions display)Operating condition: LED green Error / functional defect: LED red Supply voltage UB: LED greenPin assignmentPIN 1A1 Supply voltage UBPIN 2X1 Safety input 1PIN 3A2 GNDPIN 4Y1 Safety output 1PIN 5OUT Diagnostic outputPIN 6X2 Safety input 2PIN 7Y2 Safety output 2PIN 8IN Solenoid controlPIN 9without functionScope of deliveryScope of delivery Actuators must be ordered separately.AccessoryRecommendation (actuator)MZM 100-B1.1NoteNote (General)As long as the actuating unit is applied to the solenoid interlock, the unlockedsafety guard can be relocked. In this case, the safety outputs are re-enabled, sothat the safety guard must not be opened.Ordering codeProduct type description:MZM 100(1)(2)(3)(4)(5)(1)without Solenoid interlock monitoredB Actuator monitored(2)ST2Connector plug M12, 8-poleST Connector plug M23, 8+1-pole(3)1P2P 1 p-type diagnostic output and 2 p-type safety outputs(only in connection with "Solenoid interlock monitored") 1P2PW serial diagnostic output and 2 p-type safety outputs(4)without electrically adjustable latching force 30 … 100 N(5)PicturesProduct picture (catalogue individual photo)ID: kmzm1f08| 1.4 MB | .jpg | 216.253 x 833.261 mm - 613 x 2362 px - 72 dpi| 235.7 kB | .png | 74.083 x 285.397 mm - 210 x 809 px - 72 dpiDimensional drawing basic componentID: 1mzm1g14| 20.7 kB | .swf || 5.2 kB | .png | 74.083 x 50.8 mm - 210 x 144 px - 72 dpi| 160.8 kB | .jpg | 352.778 x 242.358 mm - 1000 x 687 px - 72dpiDimensional drawing miscellaneousID: 1mzm1g15| 12.9 kB | .swf || 290.8 kB | .jpg | 352.425 x 362.656 mm - 999 x 1028 px - 72dpiWiring exampleID: kmzm1l03| 37.0 kB | .cdr || 86.9 kB | .jpg | 352.778 x 161.572 mm - 1000 x 458 px - 72 dpiContact arrangementID: km23-k9d| 18.5 kB | .cdr || 5.4 kB | .png | 74.083 x 77.611 mm - 210 x 220 px - 72 dpi| 149.1 kB | .jpg | 352.778 x 369.711 mm - 1000 x 1048 px - 72dpiSchmersal, Inc., 15 Skyline Drive, Hawthorne, NY 10532The details and data referred to have been carefully checked. Images may diverge from original. Further technical data can be found in the manual. Technical amendments and errors possible.Generated on: 6/28/2022, 2:51 AM。
DAM2400继电器控制卡说明书V1.1北京聚英翱翔电子有限责任公司2015年01月目录一、产品特点 (1)二、产品功能 (1)三、产品选型 (1)四、主要参数 (1)五、接口说明 (2)六、通讯接线说明 (2)1、RS232接线方式 (2)2、RS485级联接线方式 (2)七、输出接线 (3)1、继电器接线说明 (3)八、测试软件说明 (3)1、软件下载 (3)2、软件界面 (4)3、通讯测试 (4)九、参数配置 (5)1、设备地址 (5)2、波特率的读取与设置 (7)3、闪开闪断功能及设置 (7)十、开发资料说明 (8)1、通讯协议说明 (8)2、Modbus寄存器说明 (8)3、指令生成说明 (10)4、指令列表 (11)5、指令详解 (12)十一、常见问题与解决方法 (14)十二、技术支持联系方式 (15)一、产品特点●DC5V/12V/24V（默认12V）；●继电器输出触点隔离；●通讯接口支持RS485、RS232；●通信波特率：2400,4800,9600,19200,38400（可以通过软件修改，默认9600）；●通信协议：支持标准modbus RTU协议；●可以设置0-255个设备地址，8位地址拨码开关可以设置1-254地址码；●具有闪开、闪断功能，可以在指令里边带参数、操作继电器开一段时间自动关闭；●具有频闪功能，可以控制器继电器周期性开关。
二、产品功能●二十四路继电器控制；●支持电脑软件手动控制；●支持顺序启动模式；●支持流水循环模式；●支持跑马循环模式。
三、产品选型型号modbus RS232RS485USB WiFi继电器DAM3200-RS232+485●●●32四、主要参数参数说明触点容量10A/30VDC10A/250VAC耐久性10万次数据接口RS485、RS232、以太网接口供电电压DC5V/12V/24V默认为12V电源指示1路红色LED指示（不通信时常亮，通信时闪烁）通讯指示与电源指示灯共用输出指示24路红色LED指示温度范围工业级，-40℃～85℃尺寸300*110*60mm重量500g默认通讯格式9600,n,8,1波特率2400,4800,9600,19200,38400,软件支持配套配置软件、控制软件；支持各家组态软件；支持Labviewd等五、接口说明六、通讯接线说明1、RS232接线方式RS232接线为标准DB9母头接口，为直连线。
