彩屏“长气王”——飞利浦Fisio820

Philips LCD TV66 cm (26")HD Ready digital TV26PFL3404DClearly a smart choiceWith easy-to-use and future-proof technologyExperience great picture and sound quality with this HD 1366 x 768p display. So easy to enjoy, with high quality standard, you can be sure that you make the right choice with this PHILIPS Flat TV.Easy to connect and enjoy•Enjoy photo and music playback via USB•2 HDMI inputs with Easylink for a full HD connection •PC input (HDMI)•Smart Picture and Smart Sound to personalise your viewing Ready for the future•Integrated Digital Tuner for DVB-T receptionVivid and razor sharp pictures•Digital Crystal Clear for detail depth and clarity •HD LCD display, with a 1366 x 768p resolution •28.9 billion colours for brilliant natural images•Active Control optimises picture quality whatever the source Crisp and Clear sound•Incredible Surround for enhanced audio enjoyment •2 x 5 W RMS audio powerHighlightsDigital Crystal ClearDigital Crystal Clear is a package of picture innovations that digitally adjusts and optimises picture quality to optimal contrast, colour and sharpness levels. It's like watching vivid cinema-like images.LCD display, 1366 x 768pThis WXGA display with state-of-the-art LCD screen technology gives you widescreen HD resolution of 1366 x 768p pixels. It produces brilliant flicker-free progressive scan pictures with optimum brightness and superb colours. This vibrant and sharp image will provide you with an enhanced viewing experience.28.9 billion coloursVibrant and natural images from the most advanced colour processing. The 3 colour channels (RGB) are optimised for a total processing power of 28.9 billion colours. The advanced algorithms detect even the subtlest shades and skin tones, creating the best colour possible.Incredible SurroundIncredible Surround is an audio technology from Philips that dramatically magnifies the sound field to immerse you in the audio. Using state-of-the-art electronic phase shifting, Incredible Surround mixes sounds from left and right in such a way that it expands the virtual distance between the two speakers. This wider spread greatly enhances the stereo effect and creates a more natural sounddimension. Incredible Surround allows you to experience total surround with greater depth and width of sound, without the use of additional speakers.2 x 5 W RMS audio power 2 x 5 W RMS audio powerUSB for photo and music playbackThe USB connector allows access to jpeg photos and mp3 music of most USB-sticks (USB memory-class device). Plug the USB into the slot at the side of the TV and access the multimedia content using the easy on screen content browser. You can now view and share your photos and music.2 HDMI inputs with EasyLinkEasyLink uses the HDMI CEC industry standard protocol to share functionalitybetween connected devices and the TV. With Easylink, only one remote control is needed to operate main functionalities on your TV and connected devices. HDMI makes anuncompressed digital RGB connection from the source to the screen for the ultimate picture quality. HDMI uses HDCP copy protection. With 1 HDMI input on the back and 1 HDMI on the side of the TV you can connect multiple HD sources, such as an HD set-top box, a Blu-ray player and a Game Console or Digital Camcorder.PC input (HDMI)With PC input you can use your TV as a PC monitor via an HDMI-DVI cable/converter.Smart Picture and Smart SoundPhilips pre-set modes for Smart Picture and Smart Sound provide you with direct access via a single key on the remote control. You can select optimised picture and sound settings for the various picture and sound modes.Active ControlActive Control ensures that noise and sharpness improvements are continuously made at a rate of 60 times per second. By continually adjusting the picture setting over 3000 times per minute, Active Control Plus ensures that the viewing experience is optimised.Integrated Digital DVB-T tunerThe integrated Digital DVB-T tuner lets you receive digital terrestrial TV without anadditional set top box. Enjoy quality TV clutterfree.Issue date 2023-07-30Version: 6.1.9EAN: 87 12581 46091 4© 2023 Koninklijke Philips N.V.All Rights reserved.Specifications are subject to change without notice. Trademarks are the property of Koninklijke Philips N.V. or their respective owners.SpecificationsPicture/Display•Aspect ratio: Widescreen•Diagonal screen size (inch): 26 inch •Diagonal screen size (metric): 66 cm•Colour cabinet: High gloss black deco front with black cabinet•Panel resolution: 1366 x 768p •Brightness: 400 cd/m²•Picture enhancement: 3/2 - 2/2 motion pull down, 3D Combfilter, 3D MA deinterlacing, ActiveControl, Colour Enhancement, Colour Transient Improvement, Digital Crystal Clear, Digital Noise Reduction, Dynamic contrast enhancement,Luminance Transient Improver, Progressive scan, Sharpness Adjustment, Automatic skin tonecorrection, 1080p 24/25/30 Hz processing, 1080p 50/60 Hz processing•Display screen type: LCD WXGA+ Active Matrix TFT•Dynamic screen contrast: 4000:1•Response time (typical): 5 ms •Viewing angle: 178º (H)/178º (V)•Screen enhancement: Anti-Reflection coated screenSupported Display Resolution•Computer formats: 640 x 480, 60 Hz, 800 x 600, 60 Hz, 1024 x 768, 60 Hz, 1280 x 720, 60 Hz, 1280 x 768, 60 Hz, 1280 x 1024, 60 Hz, 1360 x 768, 60 Hz, Via HDMI/DVI input,•Video formats: 480i, 60 Hz, 480p, 60 Hz, 576i, 50 Hz, 576p, 50 Hz, 720p, 50, 60 Hz, 1080i, 50, 60 Hz, 1080p, 24, 50, 60 Hz, 1080p, 24, 25, 30, 50, 60 HzTuner/Reception/Transmission•Aerial Input: 75 ohm coaxial (IEC75)•Tuner bands: Hyperband, S-Channel, UHF, VHF •TV system: PAL I, PAL B/G, SECAM B/G, SECAM L/L', DVB COFDM 2K/8K •Digital TV: DVB Terrestrial*•Video Playback: NTSC, SECAM, PALMultimedia Applications•Multimedia connections: USB•Playback Formats: MP3, JPEG Still picturesConvenience•Child Protection: Child Lock+Parental Control•Ease of Installation: Auto Programme Naming, Automatic Channel Install (ACI), AutomaticTuning System (ATS), Autostore, Fine Tuning, PLL Digital Tuning, Plug and Play•Ease of Use: Auto Volume Leveller (AVL), Graphical User Interface, On-Screen Display, Programme List, Settings assistant Wizard, Side Control•Clock: Sleep Timer, Wake-up Clock •Connection Enhancement: Easy link•Screen Format Adjustments: 4:3, Auto Format, Movie expand 14:9, Movie expand 16:9, Subtitle Zoom, Super Zoom, Widescreen•Electronic Programme Guide: Now + Next EPG, 8-day Electronic Programme Guide*•Remote Control: TV•Remote control type: RCPF01E09B •Teletext: 1000-page Hypertext •Picture in Picture: Text dual screen•Teletext enhancements: Programme information Line•Smart mode: Game, Movie, Personal, Energy saving, Standard, VividSound•Output power (RMS): 2 x 5 W •Sound System: Nicam Stereo•Sound Enhancement: Auto Volume Leveller, Incredible Surround, Smart SoundConnectivity•Audio Output - Digital: Coaxial (cinch)•Number of Scarts:2•EasyLink (HDMI-CEC): One touch play, EasyLink •Front/Side connections: HDMI v1.3, CVBS in, Audio L/R in, USB 2.0•Ext 1 Scart: Audio L/R, RGB •HDMI 1:HDMI v1.3•Ext 2 Scart: Audio L/R•Other connections: S/PDIF out (coaxial), Common Interface•Ext 3: YPbPr, Audio L/R inPower•Mains power: 220–240 V, 50 Hz •Ambient temperature: 5°C to 40°C •Standby power consumption: 0.30 W •Power consumption (typical): 67 WAccessories•Included accessories: Tabletop stand, Power cord, Quick start guide, User Manual, Warrantycertificate, Remote Control, 2 x AAA Batteries, Software declarationDimensions•Set Width: 671.8 mm •Set Height: 458.7 mm •Set Depth: 77 mm •Product weight: 6.9 kg•Set width (with stand): 671.8 mm •Set height (with stand): 520 mm •Set depth (with stand): 220 mm •Product weight (+stand): 8.4 kg •Box width: 800 mm •Box height: 210 mm •Box depth: 580 mm•Wall-mount compatible: 200 x 100 mm。

Philips OLED 9 series 4K UHD Android TV - Bowers&Wilkins Sound with Ambilight 4-sidedP5 AI dual picture engine Sound by Bowers & WilkinsAmbilight 4-sided139 cm (55") Android TV 55OLED935Breathtaking picture. Cinematic sound. 4K UHD OLED Android TVGive your movies the TV they deserve. This stunning Philips OLED+ TV boasts up-firing Bowers & Wilkins speakers, and the latest P5 picture processing with AI. You get a lifelike picture and thrilling sound with crystal-clear dialogue.Designed to thrill.•Philips OLED+ TV with HDR. The difference is real.•The magic of Ambilight. Only from Philips.•Immersive sound. Bowers & Wilkins meets Dolby Atmos.•Kvadrat speaker cloth. Muirhead leather-backed remoteIncredible picture. Bowers & Wilkins sound.•P5 engine with AI. Whatever you watch, a picture so real.•Dolby Vision and Dolby Atmos. Cinematic vision and sound.•3.1.2 sound system. Up-firing speakers for Dolby Atmos.•Integrated sub-woofer and full-range drivers.•Separate central tweeter for pristine dialogue.Content at your command.•Voice control. Google Assistant built-in. Works with Alexa.•DTS Play-Fi. Multi-room audio.•Android TV. Simply smart.HighlightsP5 engine with AIPhilips P5 processor with AI dual picture engine delivers a picture so real it feels like you could step right into it. A deep-learning AI algorithm processes images in a manner similar to the human brain. No matter what you're watching, you get lifelike detail and contrast, rich color, and smooth motion.Sound by Bowers & WilkinsAn exclusive speaker design by legendary audio engineers Bowers & Wilkins delivers thrillingly lifelike performance. Up-firing speakers let you get the most out of Dolby Atmos. A central tweeter keeps the dialogue pristine no matter how intense the drama gets.Ambilight 4-sidedWith Philips 4-sided Ambilight, every moment feels closer. Intelligent LEDs around the edgeof the TV respond to the on-screen action and emit an immersive glow that's simplycaptivating. Experience it once and wonder how you enjoyed TV without it.Philips OLED+ TVA Philips 4K UHD OLED+ TV is compatible with all major HDR formats. Whether it's a must-watch series or the latest video game, shadows will be deeper. Bright surfaces will shine. Colors will be truer. Motion is incredibly smooth.Tactile harmonyPremium materials make all the difference to your Philips TV. Kvadrat's acousticallytransparent wool-blend speaker fabric allows the sound to flow freely into the room. Responsibly sourced Muirhead leather and backlit keys add a sophisticated finish to the remote control.Voice assistantControl your Philips Android TV with your voice. Want to play a game, watch Netflix, or find content and apps in the Google Play store? Just tell your TV. You can even command all Google Assistant-compatible smart home devices, like dimming the lights and setting the thermostat on movie night. Without leaving the sofa. The days of searching for the TVremote are over. Now you can use your voice to control your Philips smart TV via Alexa-enabled devices, like Amazon Echo. Turn your TV on, change the channel, switch to your gaming console and more with Alexa.DTS Play-FiWith DTS Play-Fi on your Philips TV you can connect to compatible speakers in any room. Got wireless speakers in the kitchen? Listen to the movie while you make a snack, or keep up with the sports commentary while you get everyone a drink.Android TVYour Philips Android TV gives you the content you want-when you want it. You cancustomize the home screen to display your favorite apps, making it simple to startstreaming the movies and shows you love. Orpick up where you left off.Issue date 2022-10-25 Version: 6.0.112 NC: 8670 001 74981 EAN: 87 18863 02892 6© 2022 Koninklijke Philips N.V.All Rights reserved.Specifications are subject to change without notice. Trademarks are the property of Koninklijke Philips N.V. or their respective owners.SpecificationsAmbilight•Ambilight Version: 4-sided•Ambilight Features: Built in Ambilight+hue, Ambilight Music, Game Mode, Wall colour adaptive, Lounge mode, AmbiSleep, Sunrise Alarm Picture/Display•Display: 4K Ultra HD OLED•Panel resolution: 3840x2160•Aspect ratio: 16:9•Picture engine: P5 AI Perfect Picture Engine •Picture enhancement: Ultra Resolution, Wide Color Gamut 99% DCI/P3, Dolby Vision, Perfect Natural Motion, Super Resolution Supported Display Resolution •Computer inputs on all HDMI: up to 4K UHD 3840x2160 @60Hz, HDR supported, HDR10+/ HLG, HDR supported, HDR10/ HLG•Video inputs on all HDMI: up to 4K UHD3840x2160@60Hz, HDR supported, HDR10/HLG (Hybrid Log Gamma), HDR10+/Dolby Vision Android TV•OS: Android TV™ 9 (Pie)•Pre-installed apps: Google Play Movies*, Google Play Music*, Google Search, YouTube, BBC iplayer, Netflix, Amazon Prime Video•Memory size(Flash): 16GB*Smart TV Features•Program: Pause TV, USB recording*•Ease of Installation: Auto detect Philips devices, Device connection wizard, Network installation wizard, Settings assistant wizard•Ease of Use: One-stop smart menu button, Onscreen usermanual•Firmware upgradeable: Firmware auto upgrade wizard, Firmware upgradeable via USB, Online firmware upgrade•Screen Format Adjustments: Basic - Fill Screen, Fit to screen, Advance - Shift, Zoom, stretch, Wide screen•Remote Control: with Voice, with Key light •User Interaction: SimplyShare•Voice assistant*: Google Assistant built-in, RC with Mic., Works with AlexaProcessing•Processing Power: Quad Core Tuner/Reception/Transmission•HEVC support•Digital TV: DVB-T/T2•MPEG Support: MPEG2, MPEG4•Video Playback: PAL, SECAM•TV Program guide*: 8 day Electronic ProgramGuide•Signal strength indication•Teletext: 1000 page HypertextConnectivity•Number of HDMI connections: 4•Number of USBs: 2•Wireless connection: Bluetooth 4.2, Wi-Fi802.11ac, 2x2, Dual band•Other connections: Digital audio out (optical),Ethernet-LAN RJ-45, Headphone out•HDMI features: 4K, Audio Return Channel•EasyLink (HDMI-CEC): Remote control pass-through, System audio control, System standby,One touch play•HDCP 2.3: Yes on all HDMIMultimedia Applications•Video Playback Formats: Containers: AVI, MKV,H264/MPEG-4 AVC, MPEG-1, MPEG-2, MPEG-4,WMV9/VC1, VP9, HEVC (H.265)•Subtitles Formats Support: .SRT, .SUB, .TXT, .SMI•Music Playback Formats: AAC, MP3, WAV, WMA(v2 up to v9.2), WMA-PRO (v9 and v10)•Picture Playback Formats: JPEG, BMP, GIF, PNG,360 photo, HEIFPower•Mains power: AC 220 - 240 V 50/60Hz•Standby power consumption: <0.3W•Ambient temperature: 5 °C to 35 °C•Power Saving Features: Auto switch-off timer,Light sensor, Picture mute (for radio), Eco modeSound•Audio: Sound by Bowers & Wilkins, 3.1.2 Channel,Output power : 70 Watt (RMS)•Codec: AC-4, Dolby Atmos, Dolby Digital MS12V2.3, DTS-HD(M6)•Speaker configuration: 10W x2, 5W x1, woofer20W, height 12.5W x2•Sound Enhancement: 5 Band Equalizer, A.I. Sound,Clear Dialogue, Dolby Atmos, Dolby BassEnhancement, Dolby Volume Leveler, Night mode,Auto Volume Leveler, Bass EnhancementDimensions•Box dimensions(W x H x D):1400.0 x 953.0 x 174.0 mm•Set dimensions(W x H x D):1227.8 x 705.6 x 49.3 mm•Set dimensions with stand (W x H x D):1227.8 x 805.5 x 260.7 mm•Product weight: 21.0 kg•Product weight (+stand): 28.1 kg•Weight incl. Packaging: 32.7 kg•Wall mount compatible: 300 x 300 mmAccessories•Included Accessories: Legal and safety brochure,Power cord, Quick start guide (x1), Stand withsound solution, 2 x AAA Batteries, RemoteControlEU Energy card•Panel technology used: OLED*EPG and actual visibility (up to 8 days) is country and operatordependent.*Android App offerings vary per country. For more details please visityour local Google Play Store.*Philips TV Remote app and related functionalities vary per TV model,operator, and country, as well as smart device model and OS. Formore details please visit: /TVRemoteapp.*Smart TV app offerings vary per TV model and country. For moredetails please visit: /smarttv.*Its functionality is subject to ChromeCast built-in apps and smartdevises. For more details, please visit ChromeCast built-in productpages.*Memory size (Flash) : 16G, the actual available disc space may differ(dependant on e.g. (pre-)installed apps, installed operating system,etc.)*Image depicted on the website are non-contractual pictures. Pleasealways refer to the actual TV that are sold in the retail or stores.。

飞利浦宽屏幕液晶显示器19 英寸宽屏幕WSXGA+190EW8FB1宽屏幕液晶显示器，物超所值这款高分辨率 1680x1050 大尺寸宽屏幕显示器简单易用、价廉物美，必将给您带来更多乐趣！同时运行多个程序，尽情体验飞利浦 190EW8-PLUS 的快速响应时间和单触式自动调整。

出众的屏幕性能•大尺寸宽屏幕：在同一屏幕上发送即时消息（IM）、写邮件、观看视频•5 毫秒快速响应时间•WSXGA+，宽屏 1680x1050 分辨率，显示更清晰•sRGB 确保显示与打印输出之间的色彩匹配卓越的便利性•通过 Windows Vista 认证•单键式亮度和对比度控制•嵌入式电源使您无需使用外部电源适配器•单键自动调整只需按一个键即可获得优异的画面显示环保设计•确保使用安全：宇航合成防火外壳•无铅设计，保护我们的环境•低于业内平均水平的功耗*精于心简于形产品亮点宽屏幕设计大尺寸宽屏幕具有较大的宽高比，能显示更多的娱乐画面或信息，让您更充分地享受生活，更出色地完成工作。

5 毫秒响应时间开/关响应时间是指液晶晶元从活动（黑色）变为不活动（白色），然后再变回活动（黑色）所需的时间。

它是以毫秒计量的。

响应越快越好：响应时间越短，则说明过渡越快，从而使文本和图形过渡显示中的可见伪像更少。

在文档、图形和照片等商业内容的显示方面，开/关响应时间是一项尤其重要的衡量标准。

WSXGA+，宽屏 1680x1050宽屏、超级扩展图形阵列 (WSXGA) 是一种具有 1680 x 1050 分辨率或接近 170 万像素的显示器规格。

sRGB 就绪sRGB 是一种行业标准，可确保屏幕上显示的色彩与打印输出色彩之间的最佳匹配。

无铅无铅显示器的产品设计与生产是严格按照欧盟有害物质限制 (RoHS) 标准进行的，杜绝了铅和其它对环境有害的一切有毒物质。

降低功耗操作设备所需电能更低。

通过Windows Vista认证飞利浦 Vista 预置显示器支持这款视觉效果突出、对配置要求极高的全新 Windows操作系统，能够显示特有的鲜艳色彩以及令人赞叹的画面，为您带来前所未有的娱乐体验，使您不仅更有工作效率，同时帮助您在家中和办公室内控制计算机操作体验，更轻松快捷地浏览、查找和整理工作或娱乐信息。

精致影像精“智”之美飞利浦HD15高端智能彩色超声诊断系统面向临床应您所需随着病人数量的不断增加，诊断要求的不断提高，医生的压力与日俱增；而检查时复杂的操作，清晰度差的图像，无形中增加了超声医生的工作负荷；全科医院的复杂病种与专科检查的特殊需要，难以在一台设备上得到满足，让医生本就繁忙的工作更加忙碌。

您是否期待有这样一台超声系统，它操作简便，图像清晰，应用全面，并可为您提供多种定量及科研工具？飞利浦全新HD15彩色智能超声诊断系统，既可以帮助您高效地扫查大量门诊病人，又可以使您轻松自信地完成对疑难病例的诊断及评估。

它拥有您所期待的卓越成像品质和临床性能，具有您日常工作所需的各种临床设置。

多种智能优化工具及清晰的图像质量提高了工作效率，而多种定量工具及先进成像技术提供了更多的诊断信息。

HD15拥有不断拓展的科研能力，为您提供敏感的造影成像以及造影定量分析工具，与介入相结合，带来超声诊断及治疗的新境界。

先进的容积成像技术为您提供全新的三维及四维诊断视野，为腹部、胎儿、妇科等诊断提供更多信息和数据。

成像技术• 微细灰阶聚焦• SonoCT• XRES• 组织谐波超宽液晶显示器以轨迹球为中心的用户界面及使用状态显示iSCAN智能优化设计USB接口DVD/CD-RW 驱动器可调节的控制面板和显示器（调整高低和旋转）探头接口万向旋转轮优异的图像质量和HD15的设计宗旨是为了让您的超声检查更加轻松便捷，同时为您提供高水平的图像信息，使您的诊断更加准确。

针对技术上更有挑战性的困难病人和复杂疾病，多种先进成像技术及定量工具为您的诊断提供更多信息。

作为一个全新的平台，HD15集飞利浦多年实践验证的先进技术于一身，拥有革命性的主机架构、领先的技术性能以及卓越的图像质量，为您带来更多的诊断信息及更高的检查效率。

精于技术智于应用飞利浦的技术复杂精密，使用却十分简单，二者在HD15上达到了完美的结合，为您提供强大而稳固的系统用于疾病诊断及定量。

⽆情拆解飞利浦HUE 神灯初现端倪经过King和包租婆的各⽅奔⾛，囊中羞涩的我们（仅2W项⽬经费）总算了找到了以下单位提供的免费样品，真是感激淋涕啊！1、欧司朗中国提供的R,G,B,W灯珠2、忆光提供的R,G,B,W灯珠3、信驰达科技提供的CC2540 蓝⽛模块4、四正节能提供的散热器5、进强提供的PVC灯罩⼩组各成员经过通过了⼀周的玩命学习，貌似回到的⾼考前的冲刺，（加班熬夜⾃然不⽤说，还好包租婆带着⼩嫩妞给予男同胞们精神上和物质上的⿎励，⽐如半夜发放⽅便⾯福利，以保证⼤家不⾄于饿到眼冒⾦星）从⽹上的数据⼿册，2.4G信号在封闭空间的驻波⼲扰，到LED灯的光通性，LED散热，甚⾄到美国1939年三原⾊的混⾊⽂献，可以说是花⾜了功夫。

、电源部分电源部分、、⼿机软件对我们来讲只是时间问题，不存在设计问题，⽽对于光学知识来的结论是：⽆线控制、，⼤家得到的结论是：⽆线控制最终最终，⼤家得到讲我们就真的成了门外汉。

因为可借鉴的产品不多，我们便⽆情的拆解了HUE（199⼑的⼀半就糟蹋了），并做了详细的分析和测试。

⽆情拆解飞利浦HUE：⼀流灯具⼚商、⼆流⽆线⽔平Hue在⽩⾊全亮的情况下功率可达到8W，散热器表⾯温度72摄⽒度，跟其宣传的30⼏项散热专利以及良好的散热效果，外⾏⼈可能联系不到⼀起，但是当你测试它内部导热胶以及控制板上的温度时候，你会发现，只有30-50度之间的温度变化。

在如此狭⼩的空间内可以说把导热和散热做到了极致。

⽽Hue的外壳很对⼈会误认为是⾦属外壳，其实它是⼀个塑料外壳，⾥⾯是⼀圈圈环状的铝制材料，在接近灯头卡扣的位置有⼀个镂空部分，这就是⽆线信号从封闭的散热器⾥⾯传出来的窗户。

但实际测试的Hue的室内通信距离实际并不理想，只有不到20⽶的可视距离，我们亲爱的屌丝男很有信⼼在距离上完全超越Hue。

在灯珠的选择上飞利浦没有选择RGB，也没有⽤⽩⾊灯珠，他所呈现的⽩⾊是⼀种暖⽩，是由其他颜⾊混⾊⽽成，其灯罩做⼯也是相当精湛，采⽤的是玻璃加荧光图层的⽅式，颜⾊⾮常均匀，看不到灯珠的聚光点和暗区。

Philips Fisio 820 机构分析报告By Tekey heFisio820是PHILIPS首款内建GPRS技术的彩色屏幕手机，并且还内建了蓝牙可在近距离（10米）内实现无綫传输质料。

在外形设计上显得简洁明快，特别是这款顔色为火星红的手机更显青春活力。

机身的正反面采用相同烤漆，中间壳体为银色。

下面我们主要针对这款手机的机构部分作探讨。

1．整机外观：这款手机的尺寸比较小（98mm╳47mm╳21mm）,重量也很轻（85g）。

采用256色LCD（112╳112像素）。

参考价：2800 RMB2．FRONT HOUSING:REVEIVER手机前盖结构比较简单，平均厚度为1mm，通过四个螺钉和两个卡勾与後盖连接固定。

特别的是RECEIVER竖着放置，而不像一般机型的RECEIVER水平放置。

可能是这款手机的结构特点决定的，因爲它的长度尺寸很短。

但箭头所指地方的功用不太清楚，它是一块金属薄片，底部固定在FRONT HOUSING上，顶部弹片与PCB板接触。

3．REAR HOUSING:由图片可清晰的看到REAR HOUSING的结构机特点。

箭头所指为电池卡勾，位置倾斜这便於与电池上的一个弹片相配合，使电池装配较紧。

SIM卡装配入口处有一倾斜角便於SIM卡滑入，SIM DOOR有三个图点以压紧SIM卡。

4．BATTERY:BATTERY与BATTERY COVER做成一体，箭头所指弹片与REAR HOUSING 上卡勾配合，使电池安装可靠。

据介绍这款手机的待机时间可达300小时，这是飞利浦手机一贯的优势。

5．KEY PAD:这款手机的KEY PAD最据特色，字键同时也作爲方向键（2、4、6、8）大大增加了可操作性。

KEY PAD与 METAL DOME、PCB板成爲一体，箭头所指10个PIN再通过导电橡胶（是否为导电橡胶还值得研究）与主PCB板上相对应的PIN相连接。

这一块板安装在KEY PAD 与PCB板之间。

PhilipsLED TV with Digital Crystal Clear48 cm (19")HD Ready19PFL3405Ideal for any roomWith true to life LED picture performanceWhether movies, sports or games, experience great LED pictures with the Philips 48 cm (19") LED HD ready TV. With Philips LED quality and its sophisticated design this television is the right choice for any room of your house.A clear, vivid LCD picture everytime •Digital Crystal Clear for depth and clarity•HD Ready for the highest quality display of HD signals •Brilliant LED images with low power consumption •28.9 billion colors for brilliant natural images•Dynamic contrast 150.000:1 for incredible rich black details Rich and clear sound.•Incredible Surround for powerful soundComplete connectivity made simple•Seamless connectivity with 1 HDMI input and Easylink •PC-input allows you to use your TV as a PC monitor Greener every day•Energy efficiency through LED technologyHighlightsDigital Crystal ClearDigital Crystal Clear is a package of picture innovations that digitally adjusts and optimizes picture quality to optimal contrast, color and sharpness levels. The result is extremely clear pictures from any source.HD ReadyEnjoy the exceptional picture quality of High Definition pictures and be fully prepared for HD sources like HDTV settop box or Blu-ray disc. HD Ready is a protected label that offers picture quality beyond that of progressive scan. It conforms to strict standards laid out by EICTA to offer a HD screen that displays the benefits of resolution and picture quality of a High Definition signal. It has a universal connection for both analog YPbPr anduncompressed Digital connection of DVI or HDMI, supporting HDCP. It can display 720p, and 1080i signals at 50 and 60Hz.LEDThe most advanced LED lighting technology in this TV combines an eye-catching minimalistic design with stunning image quality as well as the lowest power consumption in its category.On top of that, LED lighting technology does not contain any hazardous materials. Thus, with LED backlight you can enjoy low power consumption, high brightness, incredible contrast, sharpness and vibrant colors.28.9 billion colors Vibrant and natural images from the most advanced color processing. The 3 color channels (RGB) are optimized for a total processing power of 28.9 billion colors. The advanced algorithms detect even the subtlest shades and skin tones, creating the best color possible.Incredible SurroundFeel the power of the music beat and the atmosphere of the movies. Incredible Surround allows you to experience total surround with greater depth and width of sound. It gives a clear and spacious sound stage complementary to the rich viewing experience.1 HDMI inputs with EasylinkHDMI is a single cable to carry both picture and audio signals from your devices to yourTV, helping avoid cable clutter. It carries uncompressed signals, ensuring the highest quality from source to screen. Together with Philips Easylink, you need only one remote control to perform most operations on your TV, DVD, BluRay, set top box or home theatre system.PC input (VGA)With PC input you can connect your TV to a computer by a VGA cable and use the TV as a PC monitor.Dynamic Contrast 150.000:1You want the LCD flat display with the highest contrast and most vibrant images. Philips advanced video processing combined with unique extreme dimming and backlightboosting technology results in vibrant images. Dynamic Contrast will increase the contrast with excellent blacklevel and accuraterendition of dark shades and colors. It gives a bright, lifelike picture with high contrast andvibrant colors.Issue date 2022-07-14 Version: 14.3.812 NC: 8670 000 59839 EAN: 87 12581 52469 2© 2022 Koninklijke Philips N.V.All Rights reserved.Specifications are subject to change without notice. Trademarks are the property of Koninklijke Philips N.V. or their respective owners.SpecificationsPicture/Display•Aspect ratio: Widescreen•Brightness: 300 cd/m²•Dynamic screen contrast: 150,000:1•Response time (typical): 6 ms•Viewing angle: 170º (H) / 160º (V)•Diagonal screen size: 19 inch / 48 cm •Display screen type: LCD WXGA+ Active Matrix TFT•Panel resolution: 1366 x 768p•Picture enhancement: 3/2 - 2/2 motion pull down, 3D Combfilter, 3D MA deinterlacing, Active Control, Color Enhancement, Color Transient Improvement, Digital Crystal Clear, Digital Noise Reduction, Dynamic contrast enhancement, Progressive scan, Sharpness Adjustment, Automatic skin tone correction, 1080p 24/25/30Hz processing, 1080p 50/60Hz processing •Screen enhancement: Anti-Reflection coated screen•Peak Luminance ratio: 65 %•Color cabinet: Whiskey tint deco front with high gloss black cabinetSupported Display Resolution •Computer formatsResolution Refresh rate640 x 480 60Hz800 x 600 60Hz1024 x 768 60Hz1280 x 720 60Hz1280 x 768 60Hz1280 x 1024 60Hz1360 x 768 60HzVia HDMI/DVIinput•Video formatsResolution Refresh rate480i 60Hz480p 60Hz576i 50Hz576p 50Hz720p 50, 60Hz1080i 50, 60Hz1080p 24, 50, 60Hz1080p 24, 25, 30, 50, 60HzSound•Output power (RMS): 2 x 3W •Sound Enhancement: Auto Volume Leveler,Incredible Surround, Smart Sound•Sound System: Nicam StereoConvenience•Child Protection: Child Lock+Parental Control•Clock: Sleep Timer, Wake up Clock, Wake UpTimer•Connection Enhancement: Easy link•Ease of Installation: Auto Program Naming,Automatic Channel Install(ACI), Automatic TuningSystem (ATS), Autostore, Fine Tuning, PLL DigitalTuning, Plug & Play•Ease of Use: Auto Volume Leveller (AVL),Graphical User Interface, On Screen Display, SideControl•Remote Control: TV•Screen Format Adjustments: 4:3, Auto Format,Super Zoom, Movie expand 14:9, Movie expand16:9, Subtitle Zoom, Widescreen•Teletext: 1000 page Hypertext•Teletext enhancements: Fast text, Programinformation Line•Smart mode: Personal, Vivid, Natural, Cinema,Game, Energy saving, Standard, MovieTuner/Reception/Transmission•Aerial Input: 75 ohm coaxial (IEC75)•TV system: PAL I, PAL B/G, SECAM B/G, SECAML/L'•Video Playback: NTSC, SECAM, PAL•Tuner bands: Hyperband, S-Channel, UHF, VHFConnectivity•Ext 1 Scart: Audio L/R, RGB•Number of Scarts:1•Ext 2: YPbPr in, Audio L/R in•HDMI1:HDMI v1.3•Front/Side connections: CVBS in, Audio L/R in,Headphone Out, USB 2.0•EasyLink (HDMI-CEC): One touch play, Systemstandby, EasyLink•Other connections: Composite video (CVBS) out,PC-in VGA + Audio L/R inPower•Ambient temperature: 5 °C to 40 °C•Mains power: 220-240V, 50Hz•Power consumption (typical): 30 W•Standby power consumption: 0.3W•Annual energy consumption: 43.8 kW·h•Presence of lead: Yes*Dimensions•Set dimensions(W x H x D): 455 x 303 x 56 mm•Set dimensions with stand (W x H x D):455 x 329 x 138 mm•Product weight: 3.16 kg•Product weight (+stand): 3.32 kg•Box dimensions(W x H x D):585 x 409 x 130 mm•Wall mount compatible: 75 x 75 mmAccessories•Included accessories: Table top stand, Power cord,Quick start guide, User Manual, Warrantycertificate, Remote Control, 2 x AAA Batteries,Software declaration*Typical on-mode power consumption measured according toIEC62087 Ed 2.*Energy consumption in kWh per year, based on the powerconsumption of the television operating 4 hours per day for 365days. The actual energy consumption will depend on how thetelevision is used.*This television contains lead only in certain parts or componentswhere no technology alternatives exist in accordance with existingexemption clauses under the RoHS Directive.。
