锅炉词汇英中对照

锅炉有关术语第一章锅炉类型一、锅炉boiler利用燃料燃烧释放的热能或其它来源的热能，将水或其它工质加热到一定温度和压力的换热设备。

二、锅炉机组boiler unit锅炉本体、锅炉范围内管道、烟风道、燃料制备系统及设备、测量仪表和其它锅炉附属机械的总称。

三、固定式锅炉stationary boiler安装于固定基础上的不可移动的锅炉。

四、蒸汽锅炉steam boiler用以产生规定参数（温度、压力）蒸汽的锅炉。

纳入安全监察范围的蒸汽锅炉为水容量大于或等于30L的承压的蒸汽锅炉。

五、电站锅炉power station boiler产生的蒸汽用以推动汽轮发电机组产生电力的锅炉。

六、工业锅炉industrial boiler为工业、企业提供热源（蒸汽或热水）的锅炉。

七、生活锅炉domestic boiler用于提供开水、洗澡和其它生活用水的锅炉。

八、热水锅炉hot water boiler提供一定温度和压力的热水的锅炉。

纳入安全监察范围的热水锅炉为额定出水压力大于或等于0.1MPa（表压）且额定热功率大于或等于0.1MW的以水为介质的热水锅炉。

九、船用锅炉marine boiler装置于船舶上，用作提供船舶动力和生活用热的锅炉。

十、快装锅炉package boiler在制造厂把锅炉零部件总装成整台发运的锅炉。

十一、组装锅炉shop-assembled boiler在制造厂内把锅炉零部件装配成几个大件，运到工地后再将各大件方便地组装成整台的锅炉。

十二、散装锅炉field-assembled boiler锅炉的零部件在工地进行安装成整体的锅炉。

十三、常压热水锅炉atmospheric pressure hot water boiler锅炉本体上开孔或者用连通管与大气相通，在任何情况下，锅炉本体顶部表压为零的热水锅炉。

十四、低压锅炉low pressure boiler出口工质压力不大于2.5MPa的锅炉。

种类水管锅炉 water tube boiler自然循环锅炉 natural circulation boiler强制循环锅炉 forced circulation boiler 直流锅炉 once-through boiler废热锅炉 waster heat boiler乏气锅炉 exhaust gas boiler正压锅炉 supercharged boiler燃煤锅炉 coal fired boiler重油锅炉 heavy oil boiler燃气锅炉 gas fired boiler混烧锅炉 multi-fuel fired boiler超临界压力锅炉 supercritical pressure boiler 亚临界压力锅炉 subcritical pressure boiler汽包锅炉 drum boiler辐射式锅炉 radiant boiler室内锅炉 indoor boiler露天锅炉 outdoor boiler辅助锅炉 auxiliary boiler常压流化床Atmospheric fluidized bed combustion （AFBC）循环流化床circulating fluidized bed combustion (CFBC)四角燃烧锅炉 corner fired boilerFURNACE 炉膛BURNNER 燃烧器SH ；SUPERHEATER 过热器RH ；REHEATER 再热器PLATEN SUPERHEATER 屏过PENDANT 悬吊管WATERWALL 水冷壁DOWM COMER 下降管HEADER 联箱、母管STEAM DRUM 汽包ATTEMPERATOR 减温器SPRAY 喷水ECONIMIZER 省煤器AIR PREHEATER 空预器ELECTROSTATIC PRECIPITATOR 静电除尘器INDUCED DRAFT FAN 引风机FORCED DRAFT FAN 送风机PRIMARY AIR FAN 一次风机SECONDARY AIR 二次风SEAL AIR FAN 密封风机PULVERIZER 磨煤机COAL FEEDER 给煤机IGNITOR 点火器，油枪INITIATE 启动、引燃、激发、触发CLEAN 清扫ISOLATION 隔离绝缘LIGHT OIL 轻油CHIMINEY STACK 烟囱COMBUSTION 燃烧FLUE GAS 烟气WATER 水STEAM 蒸汽SOOT BLOWER 吹灰器CRUSHER 破碎机SAFETY VALVE 安全阀PURGE 吹扫BOILER EFFLUENT STORAGE POOL 锅炉废水池SPARK 火花，点火花DRAIN & VENT 疏水和排气ASH—HOPPER 灰斗COAL BANKER 煤仓STONE COAL 无烟煤GAS COAL 烟煤UNLOADER 卸煤机STACKER RECLAIMER 堆取料机CONVEYOR 皮带机MMMC＝MILLIMETER MERCURY ；MMH2O 毫米汞柱；毫米水柱ALARM LIMITS 报警限制PRESSURE DIFFERENCE 压差LFO .DISCH .PRESS 轻油出口压力AUX .ST SPLY FOR ATOMIZ辅助蒸汽供雾化蒸汽AIR SVCE SUPPLY 服务空气SEAL AIR FAN PRESS 密封风机压力MAINTAINED IGNITORS PULVERIZER A 磨煤机A油枪操作LIGHT OIL SEL GRP 1 第一组轻油枪选择STOP IGNITORS GRP 1 第一组油枪停止PULVERIZER SELECTION A 磨煤机A选择FEEDER LOCAL SELECT 给煤机就地控制选择FEEDER REMOTE SELECT 给煤机遥控选择PULVERIZER M/A SELECT磨煤机手/自动选择PULVERIZER INERT MODE SELECT 磨煤机惰性方式选择PULVERIZER NORMAL MODE SELECT 磨煤机正常方式选择LUB OIL PUMP 润滑油泵START IGNITOR GRP 1 第一组油枪点火STOP/START SEQUENCE PULVERIZER A 磨煤机A程序停止/启动STOP/START PULVERIZER 磨煤机停止/启动STOP/START IGNITORS 油枪停止/启动STOP/START FEEDER 给煤机停止/启动STOP/START MILL 磨组停止/启动STOP/START PA FLOW 一次风停止/启动OPEN/CLOSE SWING VLVS 摆阀开/关PULVERIZER EMERGENCE TRIP 磨煤机紧急跳闸BOILER TRIP RESET 锅炉跳闸复位ALL AIR HTRS RUNNING 各空预器运行EITHER ID FAN RUNNING 任一吸风机运行EITHER FAN RUNNING 任一风机运行BOILER AIR REQUIRED 锅炉风量需求（>30%）ALL PULV GRP SHUTDOWN 所有磨组停运OPERATE MODE SELECT 运行方式选择MANUAL MODE 手动方式TURBINE FOLLOW MODE 机跟随方式BOILER FOLLOW MODE 炉跟随方式COORDINATE MODE 协调方式SLIDING PRESS MODE 滑压运行方式DECR/INCR PRESS AT FIX LOAD 固定负荷方式增减压力SECONDARY SH INLET TEMP 二级过热器进口温度SEC SH OUT STEAM TEM二级过热器出口蒸汽温度MAIN STEAM TEMP/PRESSURE/FLOW 主汽温度/压力/流量FEED WATER FLOW 给水流量ACTUAL MEGAWATT 有功THROTTLE PRESS 节流压力TURB FIRST STAGE PRESS汽机第一级(调节级)压力PRI AIR DUCT PRESS 一次风管压力SEC AIR DUCT PRESS 二次风管压力PRI/SEC AIR FLOW MILL A A磨组一次/二次风流量FURNACE PRESS 炉膛压力SH/RH SPRAY CONTROL VLVS SELECT 过热器/再热器减温水控制阀选择PLATEN SPARY CONTROL VLVS SIDE A 屏过减温水A侧控制阀SEC SH SPARY CONT VLVS SIDE A 二级过热器减温水A侧控制阀SH/RH SPARY WATER STOP VLVS 过热器/再热器减温水截止阀MAIN STEAM STOP VLV 主蒸汽截止阀SH STEAM ELECTR VLV 过热器电磁阀AIR DRAFT SEQUENCE 风机程序控制（顺控）TRANSPORT AIR SEQUENCE 风量程序控制（顺控）PRIMARY AIR SEQUENCE 一次风控制AIR HEATER A MOTER 空预器马达AAIR HEATER MOTOR LEAD 空预器马达选择AIR HEATER LOC/REM SELECT 空预器就地/遥控选择SCANNER BLOWERS 火检吹扫器INDUCED&FORCED DRAFTS 吸送风机SPEED CHANGE (NOT) PERMISSIVE 速度切换（不）允许MILL A GROUP MASTER A 磨组主控器PRI AIR FLOW MILL A CONT DAMPER 磨组一次风控制挡板MILL A OUT TEMP CONT DAMPER A磨组出口温度控制挡板BOIL MILL A GR1 WDBOX PR炉A磨组第一组风箱压力BOIL MILL A BNR MET TEMP炉A磨组喷燃器金属温度MILL A LOAD A磨组负荷SEC AIR FLOW MILL A CONT DAMPER A磨组二次风流量控制挡板TWIN FLOW AIR HTR A CONT VLV 双流式空预器控制阀PRI AIR FAN A CONT DAMPER A侧一次风机控制挡板FD FAN/ID FAN A CONT DAMPER A送/吸风机控制挡板FD FAN A FLOW A送风机流量O2 IN THE FUEL GAS 烟气含氧量FUEL GAS ID FAN A OUTLET PRESS A吸风机出口压力PRI AIR FAN A OUTLET PRESS A一次风机出口压力AIR HTR A SEC AIR OUT TEM空预器A二次风出口温度MANUAL LOAD SET/RATE 手动负荷设定/负荷率MIN MAX LOAD（LIMITS）最大最小负荷（限制）MANUAL THROTTEL PRESS SET POINT 手动节流压力设定值BOILER MASTER 锅炉主控器TURBINE MASTER 汽机主控器SH STEAM TEMP SET POINT 过热温度设定点SH STEAM FINAL TEMP 过热汽出口温度收到基 as-received basis , ar空气干燥基 air-dried basis , ad 干燥基 dry basis ,d干燥无灰基 dry and ash-free basis ,daf 水分 moisture灰分 ash 挥发分 volatile matter 固定碳 fixed carbon弹筒发热量 bomb calorific value高位发热量 gross calorific value低位发热量 net calorific value 灰变形温度 ash deformation temperature灰软化温度 ash softening temperature灰流动温度 ash fluid temperature贫煤 Meagre coal贫瘦煤 Meager-lean coal 瘦煤 Lean coal焦煤 Coking coal肥煤 Fat coal气肥煤 Gas-fat coal气煤 gas coal中粘煤 Medium caking coal弱粘煤 Poor caking coal不粘煤 Noncaking coal长焰煤 Long flame coal燃料消耗量 fuel consumption rate火道锅炉Flame tube boiler疏水器、疏水阀steam trap饱和蒸汽saturated steam过热蒸汽superheated steam震动炉篦Oscillating bar grate链条炉蓖Chain grate, travelling grate 省煤器economizer减速器speed reducer螺旋除渣机screw slag remover除尘器dust collector引风机combustion air fan鼓风机exhausting fan上煤机coal conveyor尖端的、高科技的Hi-tech节能的energy-saving高效的high-efficiency低噪声的low noise耐用的、持久的durable蒸发evaporation额定的rated热效率thermal efficiency碳化物carbide碳化硅silicon carbide一氧化物monoxide一氧化碳carbon monoxide二氧化碳dioxide二氧化碳亚临界压力锅炉carbon dioxide subcritical pressure boiler燃煤锅炉 coal-fired boiler启动锅炉 start-up boiler炉墙 furnace wall管束（排） tube bundle管屏 tube platen下降管 downcomer上升管 riser省煤器管 economizer tube再热器管 reheater tube过热器管 superheated tube蛇形管 coil吊挂管 supporting tube水冷壁管 water wall tube饱和蒸汽管saturated steam pipe水冷壁 water wall鳍片管finned tube, fin tube, gilled tube 联箱 header锅炉本体 boiler proper锅炉机组 boiler unit炉膛 boiler framework燃烧器 furnace燃烧室 combustion chamber油枪 oil gun torch风门 damper管板 tube plate煤粉管道pulverized coal piping过热器superheater沸点boiling temperature吹灰器soot blower包墙过热器wall enclosure superheater再热器 reheater炉膛容积furnace volume再热器冷段 primary reheater汽水分离器steam separator, moisture separator 再热器热段final reheater省煤器economizer空气预热器air preheater安全门 safety valve防暴门 explosion vent检查孔 inspection hole三通阀 three-way valve事故喷水阀emergency water spray valve 锅炉排污 blowdown大板梁plate girder, upper beam灰斗 ash hopper空气压缩机 air compressor混合器 mixer磨煤机coal pulverizer, coal mill一次风机 primary air fan送风机forced draft fan, force fan人孔门 man hole引风机induced draft fan, induced fan 膨胀补偿节 expansion joint原煤斗raw coal bunker, raw coal silo结渣 lagging煤粉仓pulverized coal bunker看火孔 observation hole水循环 water circulation风道 air duct除尘器dust collector, precipitator 灰渣泵 ash pump, slag pump风道 air duct轴封泵 shaft sealing pump伸缩节 expansion joint灰浆泵 ash slurry pump风管道 air piping保温材料heat-insulating material 除灰管道 ash piping稳定燃烧 stable combustion烟囱 chimney, stack支吊架 supports and hangers燃烧 combustion水压试验 hydraulic test负压 negative pressure点火 ignition正压 positive pressure着火点firing point, ignition temperature冷风 cold air锅炉上水 boiler water filling热风 hot air点火用油 fuel oil for ignition停炉 boiler shutdown熄火 fire-offALL AIR HTRS RUNNING 各空预器运行EITHER ID FAN RUNNING 任一吸风机运行EITHER FAN RUNNING 任一风机运行BOILER AIR REQUIRED 锅炉风量需求（>30%）ALL PULV GRP SHUTDOWN 所有磨组停运OPERATE MODE SELECT 运行方式选择MANUAL MODE 手动方式TURBINE FOLLOW MODE 机跟随方式BOILER FOLLOW MODE 炉跟随方式COORDINATE MODE 协调方式SLIDING PRESS MODE 滑压运行方式DECR/INCR PRESS AT FIX LOAD 固定负荷方式增减压力SECONDARY SH INLET TEMP 二级过热器进口温度SEC SH OUT STEAM TEM二级过热器出口蒸汽温度MAIN STEAM TEMP/PRESSURE/FLOW 主汽温度/压力/流量FEED WATER FLOW 给水流量ACTUAL MEGAWATT 有功THROTTLE PRESS 节流压力TURB FIRST STAGE PRESS汽机第一级(调节级)压力PRI AIR DUCT PRESS 一次风管压力SEC AIR DUCT PRESS 二次风管压力PRI/SEC AIR FLOW MILL A A磨组一次/二次风流量FURNACE PRESS 炉膛压力SH/RH SPRAY CONTROL VLVS SELECT 过热器/再热器减温水控制阀选择PLATEN SPARY CONTROL VLVS SIDE A 屏过减温水A侧控制阀SEC SH SPARY CONT VLVS SIDE A 二级过热器减温水A侧控制阀SH/RH SPARY WATER STOP VLVS 过热器/再热器减温水截止阀MAIN STEAM STOP VLV 主蒸汽截止阀SH STEAM ELECTR VLV 过热器电磁阀AIR DRAFT SEQUENCE 风机程序控制（顺控）TRANSPORT AIR SEQUENCE 风量程序控制（顺控）PRIMARY AIR SEQUENCE 一次风控制AIR HEATER A MOTER 空预器马达AAIR HEATER MOTOR LEAD 空预器马达选择AIR HEATER LOC/REM SELECT 空预器就地/遥控选择SCANNER BLOWERS 火检吹扫器INDUCED&FORCED DRAFTS 吸送风机SPEED CHANGE (NOT) PERMISSIVE 速度切换（不）允许MILL A GROUP MASTER A 磨组主控器PRI AIR FLOW MILL A CONT DAMPER 磨组一次风控制挡板MILL A OUT TEMP CONT DAMPER A磨组出口温度控制挡板BOIL MILL A GR1 WDBOX PR炉A磨组第一组风箱压力BOIL MILL A BNR MET TEMP炉A磨组喷燃器金属温度MILL A LOAD A磨组负荷SEC AIR FLOW MILL A CONT DAMPER A磨组二次风流量控制挡板TWIN FLOW AIR HTR A CONT VLV 双流式空预器控制阀PRI AIR FAN A CONT DAMPER A侧一次风机控制挡板FD FAN/ID FAN A CONT DAMPER A送/吸风机控制挡板FD FAN A FLOW A送风机流量O2 IN THE FUEL GAS 烟气含氧量FUEL GAS ID FAN A OUTLET PRESS A吸风机出口压力PRI AIR FAN A OUTLET PRESS A一次风机出口压力AIR HTR A SEC AIR OUT TEM空预器A二次风出口温度MANUAL LOAD SET/RATE 手动负荷设定/负荷率MIN MAX LOAD（LIMITS）最大最小负荷（限制）MANUAL THROTTEL PRESS SET POINT 手动节流压力设定值BOILER MASTER 锅炉主控器TURBINE MASTER 汽机主控器SH STEAM TEMP SET POINT 过热温度设定点SH STEAM FINAL TEMP 过热汽出口温度锅炉 boiler锅炉机组 boiler unit固定式锅炉 stationary boiler蒸汽锅炉 steam boiler电站锅炉 power station boiler工业锅炉 industrial boiler生活锅炉 domestic boiler热水锅炉 hot water boiler船用锅炉 marine boiler快装锅炉 package boiler组装锅炉 shop-assembled boiler散装锅炉 field-assembled boiler常压热水锅炉 atmospheric pressure hot water boiler 低压锅炉 low pressure boiler中压锅炉 medium pressure boiler高压锅炉 high pressure boiler超高压锅炉 superhigh pressure boiler亚临界压力锅炉 subcritical pressure boiler超临界压力锅炉 supercritical pressure boiler超超临界锅炉 ultra supercritical boiler自然循环锅炉 natural circulation boiler强制循环锅炉 forced circulation boiler直流锅炉 once-through boiler复合循环锅炉 combined circulation boiler低循环倍率锅炉 low circulation boiler火管锅炉 fire tube boiler水管锅炉 water tube boiler固体燃料锅炉 solid-fuel fired boiler液体燃料锅炉 liquid-fuel fired boiler气体燃料锅炉 gas-fuel fired boiler余热锅炉 exhaust heat boiler 余热锅炉（HRSG）电热锅炉 electric boiler锅壳式锅炉 shell boiler水火管锅壳式锅炉 water-fire tube shell boiler卧式内燃锅炉 horizontal internal-combustion boiler 角管式锅炉 corner tube boiler立式锅炉 vertical boiler小型锅炉 low-capacity boiler铸铁锅炉 cast-iron boiler固态排渣锅炉 boiler with dry-ash furnace液态排渣锅炉 boiler with slag-tap furnace火床燃烧锅炉 grate firing boiler链条炉排锅炉 traveling grate boiler抛煤机链条炉排锅炉 spreader-stoker-fired boiler火室燃烧锅炉 suspension firing boiler煤粉燃烧锅炉 pulverized coal fired boiler水煤浆燃烧锅炉 coal-water slurrty fired boiler流化床燃烧锅炉 fluidized bed boiler循环流化床锅炉 circulating fluidized bed boiler增压循环流化床锅炉 pressurized fluidized bed boiler微正压锅炉 pressure fired boiler增压锅炉 supercharged boiler辐射式锅炉 radiant boiler通用压力锅炉 universal-pressure boiler汽水两用锅炉 multifunctional boiler (steam and hot water) 盘管式锅炉 coil tube boiler真空相变热水锅炉 vacuum phase-change hot water boiler有机热载体炉 organic heat transfer material heater锅炉本体 boiler proper受热面 heating surface辐射受热面 radiant heating surface对流受热面 convection heating surface附加受热面 auxiliary heating surface受压部件 pressure part受压元件 pressure part管屏 tube panel垂直上升管屏 up flow riser tube panel回带式管屏 ribbon panel水平围绕管屏 spirally-wound tube panel 管束 tube bank错列布置管束 staggered bank顺列布置管束 in-line bank对流烟道 convection pass并联烟道 parallel gas passes风道 air duct炉膛（燃烧室） furnace水冷炉膛 water cooled furnace绝热炉膛 insulating furnace炉胆 furnace波形炉胆 corrugated furnace回燃室 reversal chamber冷灰斗 water-cooled hopper bottom卫燃带 refractory belt折焰角 furnace arch炉拱 arch前拱 front arch后拱 rear arch燃烧器 burner煤粉燃烧器 powdered coal burner旋流式煤粉燃烧器 cyclone type burner直流式煤粉燃烧器 impellerless burner低氮氧化物燃烧器 low nitrogen oxide burner点火装置 flame ignitor油燃烧器 oil burner油雾化器 oil atomizer机械雾化油燃烧器（压力雾化油燃烧器） mechanical atomizing burner 气流雾化油燃烧器 gas atomizing burner气体燃烧器 gas burner调风器 register炉排 grate链条炉排 travelling grate stoker链带式炉排 chain belt type grate stoker横梁式炉排 crossgirder grate stoker鳞片式炉排 flake type grate stoker往复炉排 reciprocating grate倾斜式往复炉排 inclined reciprocating grate振动炉排 vibrating stoker抛煤机 spreader stoker锅筒 drum上锅筒 steam drum下锅筒 water drum锅壳 shell筒体 cylindrical shell封头 head凸形封头 convex head椭圆形封头 ellipsoidal head半球形封头 hemispherical head平封头 flat head管板 tube plate孔桥（管孔带） ligament人孔 manhole手孔 handhole集箱（联箱） header端盖 head锅筒内部装置 drum internals清洗装置 steam washer旋风分离器 cyclone separator轴流式分离器 turbo separator百叶窗分离器 corrugated scrubber钢丝网分离器 screen separator多孔板 perforated distribution plate 集汽管 dry pipe排污管 blowoff pipe下降管 downcomer加药管 chemical feed pipe蒸发受热面 evaporating heating surface水冷壁 water-cooled wall膜式水冷壁 membrane wall双面水冷壁 division wall防渣管（凝渣管） boiler slag screen锅炉管束 boiler convection tube bank烟管（火管） fire tube螺纹烟管 spirally corrugated tube内螺纹管 ribbed tube旗式受热面 flag pattern surface过热器 superheater辐射式过热器 radiant superheater墙式过热器 wall superheater屏式过热器 platen superheater对流式过热器 convection superheater包墙管过热器 steam-cooled wall顶棚管过热器（炉顶过热器） steam-cooled roof 悬吊式过热器 pendant superheater水平式过热器 horizontal superheater再热器 reheater辐射式再热器 radiant reheater对流式再热器 convection reheater减温器 desuperheater、 attemperator表面式减温器 drum type surface attemperator喷水减温器 spray type attemperator烟气挡板（旁路档板） smoke damper烟气再循环装置 gas recirculation equipment汽——汽热交换器 steam-steam heat exchanger省煤器 economizer沸腾式省煤器 steaming economizer非沸腾式省煤器 nonsteaming economizer钢管式省煤器 steel tube economizer鳍片管式省煤器 finned tube economizer铸铁肋片管式省煤器 cast-iron gilled tube economizer可分式省煤器（独立式省煤器） separated economizer悬吊管 pendant tube空气预热器 air heater钢管式空气预热器 tubular air heater再生式回转空气预热器 rotary regenerative air heater受热面转动型再生式空气预热器 rotating-plate type regenerative air heater风罩转动型再生式空气预热器 stationary-plate type regenerative air heater板式空气预热器 plate type recuperative air heater铸铁肋片管式空气预热器 cast-iron gilled tube air heater 暖风机 steam air heater锅炉构架 boiler structure支承式锅炉构架 bottom-supported structure悬吊式锅炉构架 top-supported structure by hangers框架式锅炉构架 frame type boiler structure桁架式锅炉构架 trussed type boiler structure刚性架 buckstay锅炉炉墙 boiler setting重型炉墙 bottom supported heavy wall轻型炉墙 sectional supporting water cooled wall敷管炉墙 top supported water cooled wall炉墙护板 boiler casing锅炉汽水系统 boiler steam and water circuit锅炉范围内管道 boiler external piping安全阀 safety valve静重式安全阀 direct-loaded safety valve弹簧式安全阀 spring-loaded safety valve杠杆式安全阀 deadweight safety valve脉冲式安全阀 pulsed safety valve电磁控制式安全阀 electric relief valve水封式安全装置 water-sealed safety equipment 水位表 water gauge玻璃水位计 glass water gauge双色水位计 double-colour water gauge高低水位报警器 high-low water level alarm低置水位计 remote water level indicator防爆门 explosion door排污阀 blowdown valve疏水阀（疏水器） bleeder点火程序控制装置 ignition control program熄火保护装置 flame failure protection额定蒸发量 nominal capacity最大连续蒸发量 maximum continuous rating额定供热量 rated heating capacity额定蒸汽参数 nominal steam parameter额定蒸汽压力 nominal steam pressure额定蒸汽温度 nominal steam temperature额定热水温度 nominal hot water temperature 给水温度 feed watr temperature3.2.2.1.9回水温度 return water temperature排污率 rate of blowdown锅炉热力计算 thermal calculation for boilers锅炉水动力计算 hydrodynamic calculation for boilers锅炉烟风阻力计算 flue-gas and air resistance calulation for boilers锅炉受压元件强度计算 strength calculation of pressure parts for boilers锅炉水循环 boiler circulation循环回路 circulation circuit蒸汽品质 steam quality蒸汽污染 steam contamination机械携带 mechanical carry-over溶解携带 vaporous carry-over蒸汽净化 steam purification蒸汽湿度 moisture in steam分段蒸发 stage evaporation气温调节 steam temperature control给水 feed water补给水 make-up water锅水 boiler water给水品质 feedwater condition锅水浓度 boiler water concentration总硬度 total hardness总碱度 total alkalinity悬浮固形物 suspended solid matter溶解固形物 dissolved solid matter相对碱度 relative alkalinity负压燃烧 negative-pressure firing压力燃烧 pressurized firing自然通风 natural draft机械通风 mechanical draft平衡通风 balanced draft分段送风 zone control draft燃料消耗量 fuel consumption计算燃料消耗量 calculated fuel consumption理论空气量 theoretical air过量空气系数 excess air ratio理论燃烧温度 theoretical combustion temperature 炉膛出口烟气温度 furnace outlet gas temperature 排烟温度 exhaust gas temperature锅炉热效率 boiler efficiency保证效率 guarantee efficiency燃烧效率 combustion efficiency锅炉热损失 boiler heat loss排烟热损失 heat loss due to exhaust gas气体不完全燃烧热损失 heat loss due to unburned gases固体不完全燃烧热损失 heat loss due to unburned carbon in refuse 散热损失 heat loss due to radiation灰渣物理热损失 heat loss due to sensible heat in slag飞灰可燃物含量（飞灰含碳量） unburned combustible in flue dust 炉渣可燃物含量（炉渣含碳量） unburned combustible in slag漏风系数 air leakage factor热风温度 hot air temperature一次风（一次空气） primary air二次风（二次空气） secondary air三次风（三次空气） tertiary air炉膛容积热负荷 furnace volume heat release rate炉膛截面热强度 furnace cross-section heat release rate辐射受热面热流密度（炉壁热流密度） furnace wall heat flux density 炉排面积热负荷 grate heat release rate炉排通风截面比 percentage of air space水动力特性 hydrodynamics循环倍率 circulation ratio循环水速 circulation velocity运动压头 available static head有效压头 available head质量流速 mass velocity质量含汽率 steam quality by mass临界含汽率 critical steam quality沸腾换热恶化 boiling crisis过冷沸腾 subcooled boiling计算压力 calculated pressure计算壁温 calculated metal temperature最高允许工作压力 maximum allowable working pressure 安全系数 safety factor许用应力 allowable stress理论计算壁厚 theoretical calculated thickness最小需要壁厚 minimum required thickness公称壁厚（名义壁厚） nominal thickness有效壁厚 effective thickness应力集中系数 stress concentration factor孔桥减弱系数 ligament efficiency焊缝减弱系数 weld efficiency开孔补强 reinforcement of openings表面清理 surface cleaning喷丸（砂）处理 shot-rain cleaning封头成型 head forming冲压成型 press forming旋压成型 spin forming爆炸成型 explosion forming边缘加工 edge processing去毛刺 deburring卷板 plate rolling冷态卷板 cold rolling热态卷板 hot rolling矫形 shape righting矫圆 round set板边预弯 preliminary rolling弯管 tube bending冷态弯管 cold bending胀管 tube expansion胀管率 expansion efficiency成排焊接 panel welding成排弯管 panel bending不圆度 out-of-roundness直线度 straightness/alinement 偏心度 eccentricity管端倾斜度 gradient of tube-end 通球试验 ball passing test锅筒起吊 drum lifting砌墙 walling烘炉 furnace drying煮炉 boiling out补炉 fetting挖补修理 remedy除垢 descaling机械除垢 mechanical descaling化学清洗 chemical cleaning碱煮除垢 alkali descaling酸洗除垢 acid descaling钝化处理 passivating冲管 flushing吹管 steam-line blowing锅炉改造 boiler reforming炉拱改造 arch reforming循环系统改造 circulation circuit reforming 锅炉启动 start-up上水 filling水位 water level炉内清扫 purge点火 fire升压 raising pressure疏水 drain并汽 bring a boiler onto the line启动压力 start-up pressure启动流量 start-up flow rate滑参数启动 variable parameter start-up 排污 blowdown定期排污 periodic blowdown连续排污 continuous blowdown吹灰 soot blowing压缩空气吹灰 compressed air blowing蒸汽吹灰 steam blowing药物清灰 chemical deashing压火 banking fire停炉 shutdown定压运行 constant pressure operation 变压运行 variable pressure operation 经济运行 economical operation停炉保养 preservation湿法保养 wet preservation干法保养 dry preservation充气保养 gas-filled preservation外部检查 visual inspection内部检查 internal inspection锅炉专业术语大全(中英文) 宏观检验 macroscopic examination漏风试验 air leakage test堵灰 clogging布风板grid plate41 / 41。

锅炉专业日常用词中英对照表锅炉Boiler手拉葫芦Chain block 钢架Steel structure 千斤顶Jack汽包Drum 石笔Slate pencil 顶板梁Girder 氧气Oxygen 吊杆Hanger 乙炔Acetylene 水冷壁Water wall 氩气Argon 省煤器Economizer 角磨机Grinder燃烧器Burner 弹簧秤Spring scale 刚性梁Buckstay 卡环Snap ring 过热器Superheater 导向滑车Guide pulley 再热器Reheater 水准仪Level gauge 密封Seal履带吊Crawler crane 安全阀Safety valve 卷扬机Winch 下降管Downcomer 经纬仪Theodolite 集箱Header吊线锤Plumb bob 减温器Attemperator 吹灰器Soot blower切圆Tangential减温减压站保温、油漆Heat insulation & Painting 邻炉加热adjacent boiler heating 点火杆、油枪Spark rod & Oil gun 检查孔inspection eye通球试验Ball-passing test 膨胀指示器expansion indicator 旋风分离器Cyclone separator 对空排汽系统Air exhausting system 百叶窗分离器Louver separator 压力表Pressure gauge人孔门Manhole 双色水位计Double-color water gauge 吊挂管Suspension pipe 平衡容器Balance cell 雾化片（雾化门）Atomizing disk取样器SamplerPressure-reducing and desuperheating station。

种类水管锅炉 water tube boiler自然循环锅炉 natural circulation boiler强制循环锅炉 forced circulation boiler直流锅炉 once-through boiler废热锅炉 waster heat boiler乏气锅炉 exhaust gas boiler正压锅炉 supercharged boiler燃煤锅炉 coal fired boiler重油锅炉 heavy oil boiler燃气锅炉 gas fired boiler混烧锅炉 multi-fuel fired boiler超临界压力锅炉 supercritical pressure boiler亚临界压力锅炉 subcritical pressure boiler汽包锅炉 drum boiler辐射式锅炉 radiant boiler室内锅炉 indoor boiler露天锅炉 outdoor boiler辅助锅炉 auxiliary boiler常压流化床Atmospheric fluidized bed combustion （AFBC）循环流化床circulating fluidized bed combustion (CFBC)四角燃烧锅炉 corner fired boilerFURNACE 炉膛BURNNER 燃烧器SH ；SUPERHEATER 过热器RH ；REHEATER 再热器PLATEN SUPERHEATER 屏过PENDANT 悬吊管WATERWALL 水冷壁DOWM COMER 下降管HEADER 联箱、母管STEAM DRUM 汽包ATTEMPERATOR 减温器SPRAY 喷水ECONIMIZER 省煤器AIR PREHEATER 空预器ELECTROSTATIC PRECIPITATOR 静电除尘器INDUCED DRAFT FAN 引风机FORCED DRAFT FAN 送风机PRIMARY AIR FAN 一次风机SECONDARY AIR 二次风SEAL AIR FAN 密封风机PULVERIZER 磨煤机COAL FEEDER 给煤机IGNITOR 点火器，油枪INITIATE 启动、引燃、激发、触发CLEAN 清扫ISOLATION 隔离绝缘LIGHT OIL 轻油CHIMINEY STACK 烟囱COMBUSTION 燃烧FLUE GAS 烟气WATER 水STEAM 蒸汽SOOT BLOWER 吹灰器CRUSHER 破碎机SAFETY VALVE 安全阀PURGE 吹扫BOILER EFFLUENT STORAGE POOL 锅炉废水池SPARK 火花，点火花DRAIN & VENT 疏水和排气ASH—HOPPER 灰斗COAL BANKER 煤仓STONE COAL 无烟煤GAS COAL 烟煤UNLOADER 卸煤机STACKER RECLAIMER 堆取料机CONVEYOR 皮带机MMMC＝MILLIMETER MERCURY ；MMH2O 毫米汞柱；毫米水柱ALARM LIMITS 报警限制PRESSURE DIFFERENCE 压差LFO .DISCH .PRESS 轻油出口压力AUX .ST SPLY FOR ATOMIZ辅助蒸汽供雾化蒸汽AIR SVCE SUPPLY 服务空气SEAL AIR FAN PRESS 密封风机压力MAINTAINED IGNITORS PULVERIZER A 磨煤机A油枪操作LIGHT OIL SEL GRP 1 第一组轻油枪选择STOP IGNITORS GRP 1 第一组油枪停止PULVERIZER SELECTION A 磨煤机A选择FEEDER LOCAL SELECT 给煤机就地控制选择FEEDER REMOTE SELECT 给煤机遥控选择PULVERIZER M/A SELECT磨煤机手/自动选择PULVERIZER INERT MODE SELECT 磨煤机惰性方式选择PULVERIZER NORMAL MODE SELECT 磨煤机正常方式选择LUB OIL PUMP 润滑油泵START IGNITOR GRP 1 第一组油枪点火STOP/START SEQUENCE PULVERIZER A 磨煤机A程序停止/启动STOP/START PULVERIZER 磨煤机停止/启动STOP/START IGNITORS 油枪停止/启动STOP/START FEEDER 给煤机停止/启动STOP/START MILL 磨组停止/启动STOP/START PA FLOW 一次风停止/启动OPEN/CLOSE SWING VLVS 摆阀开/关PULVERIZER EMERGENCE TRIP 磨煤机紧急跳闸BOILER TRIP RESET 锅炉跳闸复位ALL AIR HTRS RUNNING 各空预器运行EITHER ID FAN RUNNING 任一吸风机运行EITHER FAN RUNNING 任一风机运行BOILER AIR REQUIRED 锅炉风量需求（>30%）ALL PULV GRP SHUTDOWN 所有磨组停运OPERATE MODE SELECT 运行方式选择MANUAL MODE 手动方式TURBINE FOLLOW MODE 机跟随方式BOILER FOLLOW MODE 炉跟随方式COORDINATE MODE 协调方式SLIDING PRESS MODE 滑压运行方式DECR/INCR PRESS AT FIX LOAD 固定负荷方式增减压力SECONDARY SH INLET TEMP 二级过热器进口温度SEC SH OUT STEAM TEM二级过热器出口蒸汽温度MAIN STEAM TEMP/PRESSURE/FLOW 主汽温度/压力/流量FEED WATER FLOW 给水流量ACTUAL MEGAWATT 有功THROTTLE PRESS 节流压力TURB FIRST STAGE PRESS汽机第一级(调节级)压力PRI AIR DUCT PRESS 一次风管压力SEC AIR DUCT PRESS 二次风管压力PRI/SEC AIR FLOW MILL A A磨组一次/二次风流量FURNACE PRESS 炉膛压力SH/RH SPRAY CONTROL VLVS SELECT 过热器/再热器减温水控制阀选择PLATEN SPARY CONTROL VLVS SIDE A 屏过减温水A侧控制阀SEC SH SPARY CONT VLVS SIDE A 二级过热器减温水A侧控制阀SH/RH SPARY WATER STOP VLVS 过热器/再热器减温水截止阀MAIN STEAM STOP VLV 主蒸汽截止阀SH STEAM ELECTR VLV 过热器电磁阀AIR DRAFT SEQUENCE 风机程序控制（顺控）TRANSPORT AIR SEQUENCE 风量程序控制（顺控）PRIMARY AIR SEQUENCE 一次风控制AIR HEATER A MOTER 空预器马达AAIR HEATER MOTOR LEAD 空预器马达选择AIR HEATER LOC/REM SELECT 空预器就地/遥控选择SCANNER BLOWERS 火检吹扫器INDUCED&FORCED DRAFTS 吸送风机SPEED CHANGE (NOT) PERMISSIVE 速度切换（不）允许MILL A GROUP MASTER A 磨组主控器PRI AIR FLOW MILL A CONT DAMPER 磨组一次风控制挡板MILL A OUT TEMP CONT DAMPER A磨组出口温度控制挡板BOIL MILL A GR1 WDBOX PR炉A磨组第一组风箱压力BOIL MILL A BNR MET TEMP炉A磨组喷燃器金属温度MILL A LOAD A磨组负荷SEC AIR FLOW MILL A CONT DAMPER A磨组二次风流量控制挡板TWIN FLOW AIR HTR A CONT VLV 双流式空预器控制阀PRI AIR FAN A CONT DAMPER A侧一次风机控制挡板FD FAN/ID FAN A CONT DAMPER A送/吸风机控制挡板FD FAN A FLOW A送风机流量O2 IN THE FUEL GAS 烟气含氧量FUEL GAS ID FAN A OUTLET PRESS A吸风机出口压力PRI AIR FAN A OUTLET PRESS A一次风机出口压力AIR HTR A SEC AIR OUT TEM空预器A二次风出口温度MANUAL LOAD SET/RATE 手动负荷设定/负荷率MIN MAX LOAD（LIMITS）最大最小负荷（限制）MANUAL THROTTEL PRESS SET POINT 手动节流压力设定值BOILER MASTER 锅炉主控器TURBINE MASTER 汽机主控器SH STEAM TEMP SET POINT 过热温度设定点SH STEAM FINAL TEMP 过热汽出口温度收到基 as-received basis , ar空气干燥基 air-dried basis , ad 干燥基 dry basis ,d干燥无灰基 dry and ash-free basis ,daf 水分 moisture灰分 ash 挥发分 volatile matter 固定碳 fixed carbon弹筒发热量 bomb calorific value高位发热量 gross calorific value低位发热量 net calorific value 灰变形温度 ash deformation temperature灰软化温度 ash softening temperature 灰流动温度 ash fluid temperature贫煤 Meagre coal贫瘦煤 Meager-lean coal 瘦煤 Lean coal焦煤 Coking coal肥煤 Fat coal气肥煤 Gas-fat coal气煤 gas coal中粘煤 Medium caking coal弱粘煤 Poor caking coal不粘煤 Noncaking coal长焰煤 Long flame coal燃料消耗量 fuel consumption rate火道锅炉Flame tube boiler疏水器、疏水阀steam trap饱和蒸汽saturated steam过热蒸汽superheated steam震动炉篦Oscillating bar grate链条炉蓖Chain grate, travelling grate省煤器economizer减速器speed reducer螺旋除渣机screw slag remover除尘器dust collector引风机combustion air fan鼓风机exhausting fan上煤机coal conveyor尖端的、高科技的Hi-tech节能的energy-saving高效的high-efficiency低噪声的low noise耐用的、持久的durable蒸发evaporation额定的rated热效率thermal efficiency碳化物carbide碳化硅silicon carbide一氧化物monoxide一氧化碳carbon monoxide二氧化碳dioxide二氧化碳亚临界压力锅炉carbon dioxide subcritical pressure boiler 燃煤锅炉 coal-fired boiler启动锅炉 start-up boiler炉墙 furnace wall管束（排） tube bundle管屏 tube platen下降管 downcomer上升管 riser省煤器管 economizer tube再热器管 reheater tube过热器管 superheated tube蛇形管 coil吊挂管 supporting tube水冷壁管 water wall tube饱和蒸汽管saturated steam pipe水冷壁 water wall鳍片管finned tube, fin tube, gilled tube联箱 header锅炉本体 boiler proper锅炉机组 boiler unit炉膛 boiler framework燃烧器 furnace燃烧室 combustion chamber油枪 oil gun torch风门 damper管板 tube plate煤粉管道pulverized coal piping过热器superheater沸点boiling temperature吹灰器soot blower包墙过热器wall enclosure superheater再热器 reheater炉膛容积furnace volume再热器冷段 primary reheater汽水分离器steam separator, moisture separator 再热器热段final reheater省煤器economizer空气预热器air preheater安全门 safety valve防暴门 explosion vent检查孔 inspection hole三通阀 three-way valve事故喷水阀emergency water spray valve 锅炉排污 blowdown大板梁plate girder, upper beam灰斗 ash hopper空气压缩机 air compressor混合器 mixer磨煤机coal pulverizer, coal mill一次风机 primary air fan送风机forced draft fan, force fan人孔门 man hole引风机induced draft fan, induced fan 膨胀补偿节 expansion joint原煤斗raw coal bunker, raw coal silo 结渣 lagging煤粉仓pulverized coal bunker看火孔 observation hole水循环 water circulation风道 air duct除尘器dust collector, precipitator 灰渣泵 ash pump, slag pump风道 air duct轴封泵 shaft sealing pump伸缩节 expansion joint灰浆泵 ash slurry pump风管道 air piping保温材料heat-insulating material除灰管道 ash piping稳定燃烧 stable combustion烟囱 chimney, stack支吊架 supports and hangers燃烧 combustion水压试验 hydraulic test负压 negative pressure点火 ignition正压 positive pressure着火点firing point, ignition temperature冷风 cold air锅炉上水 boiler water filling热风 hot air点火用油 fuel oil for ignition停炉 boiler shutdown熄火 fire-offALL AIR HTRS RUNNING 各空预器运行EITHER ID FAN RUNNING 任一吸风机运行EITHER FAN RUNNING 任一风机运行BOILER AIR REQUIRED 锅炉风量需求（>30%）ALL PULV GRP SHUTDOWN 所有磨组停运OPERATE MODE SELECT 运行方式选择MANUAL MODE 手动方式TURBINE FOLLOW MODE 机跟随方式BOILER FOLLOW MODE 炉跟随方式COORDINATE MODE 协调方式SLIDING PRESS MODE 滑压运行方式DECR/INCR PRESS AT FIX LOAD 固定负荷方式增减压力SECONDARY SH INLET TEMP 二级过热器进口温度SEC SH OUT STEAM TEM二级过热器出口蒸汽温度MAIN STEAM TEMP/PRESSURE/FLOW 主汽温度/压力/流量FEED WATER FLOW 给水流量ACTUAL MEGAWATT 有功THROTTLE PRESS 节流压力TURB FIRST STAGE PRESS汽机第一级(调节级)压力PRI AIR DUCT PRESS 一次风管压力SEC AIR DUCT PRESS 二次风管压力PRI/SEC AIR FLOW MILL A A磨组一次/二次风流量FURNACE PRESS 炉膛压力SH/RH SPRAY CONTROL VLVS SELECT 过热器/再热器减温水控制阀选择PLATEN SPARY CONTROL VLVS SIDE A 屏过减温水A侧控制阀SEC SH SPARY CONT VLVS SIDE A 二级过热器减温水A侧控制阀SH/RH SPARY WATER STOP VLVS 过热器/再热器减温水截止阀MAIN STEAM STOP VLV 主蒸汽截止阀SH STEAM ELECTR VLV 过热器电磁阀AIR DRAFT SEQUENCE 风机程序控制（顺控）TRANSPORT AIR SEQUENCE 风量程序控制（顺控）PRIMARY AIR SEQUENCE 一次风控制AIR HEATER A MOTER 空预器马达AAIR HEATER MOTOR LEAD 空预器马达选择AIR HEATER LOC/REM SELECT 空预器就地/遥控选择SCANNER BLOWERS 火检吹扫器INDUCED&FORCED DRAFTS 吸送风机SPEED CHANGE (NOT) PERMISSIVE 速度切换（不）允许MILL A GROUP MASTER A 磨组主控器PRI AIR FLOW MILL A CONT DAMPER 磨组一次风控制挡板MILL A OUT TEMP CONT DAMPER A磨组出口温度控制挡板BOIL MILL A GR1 WDBOX PR炉A磨组第一组风箱压力BOIL MILL A BNR MET TEMP炉A磨组喷燃器金属温度MILL A LOAD A磨组负荷SEC AIR FLOW MILL A CONT DAMPER A磨组二次风流量控制挡板TWIN FLOW AIR HTR A CONT VLV 双流式空预器控制阀PRI AIR FAN A CONT DAMPER A侧一次风机控制挡板FD FAN/ID FAN A CONT DAMPER A送/吸风机控制挡板FD FAN A FLOW A送风机流量O2 IN THE FUEL GAS 烟气含氧量FUEL GAS ID FAN A OUTLET PRESS A吸风机出口压力PRI AIR FAN A OUTLET PRESS A一次风机出口压力AIR HTR A SEC AIR OUT TEM空预器A二次风出口温度MANUAL LOAD SET/RATE 手动负荷设定/负荷率MIN MAX LOAD（LIMITS）最大最小负荷（限制）MANUAL THROTTEL PRESS SET POINT 手动节流压力设定值BOILER MASTER 锅炉主控器TURBINE MASTER 汽机主控器SH STEAM TEMP SET POINT 过热温度设定点SH STEAM FINAL TEMP 过热汽出口温度锅炉 boiler锅炉机组 boiler unit固定式锅炉 stationary boiler蒸汽锅炉 steam boiler电站锅炉 power station boiler工业锅炉 industrial boiler生活锅炉 domestic boiler热水锅炉 hot water boiler船用锅炉 marine boiler快装锅炉 package boiler组装锅炉 shop-assembled boiler散装锅炉 field-assembled boiler常压热水锅炉 atmospheric pressure hot water boiler低压锅炉 low pressure boiler中压锅炉 medium pressure boiler高压锅炉 high pressure boiler超高压锅炉 superhigh pressure boiler亚临界压力锅炉 subcritical pressure boiler超临界压力锅炉 supercritical pressure boiler超超临界锅炉 ultra supercritical boiler自然循环锅炉 natural circulation boiler强制循环锅炉 forced circulation boiler直流锅炉 once-through boiler复合循环锅炉 combined circulation boiler低循环倍率锅炉 low circulation boiler火管锅炉 fire tube boiler水管锅炉 water tube boiler固体燃料锅炉 solid-fuel fired boiler液体燃料锅炉 liquid-fuel fired boiler气体燃料锅炉 gas-fuel fired boiler余热锅炉 exhaust heat boiler 余热锅炉（HRSG）电热锅炉 electric boiler锅壳式锅炉 shell boiler水火管锅壳式锅炉 water-fire tube shell boiler卧式内燃锅炉 horizontal internal-combustion boiler角管式锅炉 corner tube boiler立式锅炉 vertical boiler小型锅炉 low-capacity boiler铸铁锅炉 cast-iron boiler固态排渣锅炉 boiler with dry-ash furnace液态排渣锅炉 boiler with slag-tap furnace火床燃烧锅炉 grate firing boiler链条炉排锅炉 traveling grate boiler抛煤机链条炉排锅炉 spreader-stoker-fired boiler火室燃烧锅炉 suspension firing boiler煤粉燃烧锅炉 pulverized coal fired boiler水煤浆燃烧锅炉 coal-water slurrty fired boiler流化床燃烧锅炉 fluidized bed boiler循环流化床锅炉 circulating fluidized bed boiler增压循环流化床锅炉 pressurized fluidized bed boiler微正压锅炉 pressure fired boiler增压锅炉 supercharged boiler辐射式锅炉 radiant boiler通用压力锅炉 universal-pressure boiler汽水两用锅炉 multifunctional boiler (steam and hot water) 盘管式锅炉 coil tube boiler真空相变热水锅炉 vacuum phase-change hot water boiler有机热载体炉 organic heat transfer material heater锅炉本体 boiler proper受热面 heating surface辐射受热面 radiant heating surface对流受热面 convection heating surface附加受热面 auxiliary heating surface受压部件 pressure part受压元件 pressure part管屏 tube panel垂直上升管屏 up flow riser tube panel回带式管屏 ribbon panel水平围绕管屏 spirally-wound tube panel管束 tube bank错列布置管束 staggered bank顺列布置管束 in-line bank对流烟道 convection pass并联烟道 parallel gas passes风道 air duct炉膛（燃烧室） furnace水冷炉膛 water cooled furnace绝热炉膛 insulating furnace炉胆 furnace波形炉胆 corrugated furnace回燃室 reversal chamber冷灰斗 water-cooled hopper bottom卫燃带 refractory belt折焰角 furnace arch炉拱 arch前拱 front arch后拱 rear arch燃烧器 burner煤粉燃烧器 powdered coal burner旋流式煤粉燃烧器 cyclone type burner直流式煤粉燃烧器 impellerless burner低氮氧化物燃烧器 low nitrogen oxide burner点火装置 flame ignitor油燃烧器 oil burner油雾化器 oil atomizer机械雾化油燃烧器（压力雾化油燃烧器） mechanical atomizing burner 气流雾化油燃烧器 gas atomizing burner气体燃烧器 gas burner调风器 register炉排 grate链条炉排 travelling grate stoker链带式炉排 chain belt type grate stoker横梁式炉排 crossgirder grate stoker鳞片式炉排 flake type grate stoker往复炉排 reciprocating grate倾斜式往复炉排 inclined reciprocating grate振动炉排 vibrating stoker抛煤机 spreader stoker锅筒 drum上锅筒 steam drum下锅筒 water drum锅壳 shell筒体 cylindrical shell封头 head凸形封头 convex head椭圆形封头 ellipsoidal head半球形封头 hemispherical head平封头 flat head管板 tube plate孔桥（管孔带） ligament人孔 manhole手孔 handhole集箱（联箱） header端盖 head锅筒内部装置 drum internals清洗装置 steam washer旋风分离器 cyclone separator轴流式分离器 turbo separator百叶窗分离器 corrugated scrubber钢丝网分离器 screen separator多孔板 perforated distribution plate集汽管 dry pipe排污管 blowoff pipe下降管 downcomer加药管 chemical feed pipe蒸发受热面 evaporating heating surface水冷壁 water-cooled wall膜式水冷壁 membrane wall双面水冷壁 division wall防渣管（凝渣管） boiler slag screen锅炉管束 boiler convection tube bank烟管（火管） fire tube螺纹烟管 spirally corrugated tube内螺纹管 ribbed tube旗式受热面 flag pattern surface过热器 superheater辐射式过热器 radiant superheater墙式过热器 wall superheater屏式过热器 platen superheater对流式过热器 convection superheater包墙管过热器 steam-cooled wall顶棚管过热器（炉顶过热器） steam-cooled roof 悬吊式过热器 pendant superheater水平式过热器 horizontal superheater再热器 reheater辐射式再热器 radiant reheater对流式再热器 convection reheater减温器 desuperheater、 attemperator表面式减温器 drum type surface attemperator 喷水减温器 spray type attemperator烟气挡板（旁路档板） smoke damper烟气再循环装置 gas recirculation equipment 汽——汽热交换器 steam-steam heat exchanger省煤器 economizer沸腾式省煤器 steaming economizer非沸腾式省煤器 nonsteaming economizer钢管式省煤器 steel tube economizer鳍片管式省煤器 finned tube economizer铸铁肋片管式省煤器 cast-iron gilled tube economizer可分式省煤器（独立式省煤器） separated economizer悬吊管 pendant tube空气预热器 air heater钢管式空气预热器 tubular air heater再生式回转空气预热器 rotary regenerative air heater受热面转动型再生式空气预热器 rotating-plate type regenerative air heater 风罩转动型再生式空气预热器 stationary-plate type regenerative air heater 板式空气预热器 plate type recuperative air heater铸铁肋片管式空气预热器 cast-iron gilled tube air heater暖风机 steam air heater锅炉构架 boiler structure支承式锅炉构架 bottom-supported structure悬吊式锅炉构架 top-supported structure by hangers框架式锅炉构架 frame type boiler structure桁架式锅炉构架 trussed type boiler structure刚性架 buckstay锅炉炉墙 boiler setting重型炉墙 bottom supported heavy wall轻型炉墙 sectional supporting water cooled wall敷管炉墙 top supported water cooled wall炉墙护板 boiler casing锅炉汽水系统 boiler steam and water circuit锅炉范围内管道 boiler external piping安全阀 safety valve静重式安全阀 direct-loaded safety valve弹簧式安全阀 spring-loaded safety valve杠杆式安全阀 deadweight safety valve脉冲式安全阀 pulsed safety valve电磁控制式安全阀 electric relief valve水封式安全装置 water-sealed safety equipment水位表 water gauge玻璃水位计 glass water gauge双色水位计 double-colour water gauge高低水位报警器 high-low water level alarm低置水位计 remote water level indicator防爆门 explosion door排污阀 blowdown valve疏水阀（疏水器） bleeder点火程序控制装置 ignition control program熄火保护装置 flame failure protection额定蒸发量 nominal capacity最大连续蒸发量 maximum continuous rating额定供热量 rated heating capacity额定蒸汽参数 nominal steam parameter额定蒸汽压力 nominal steam pressure额定蒸汽温度 nominal steam temperature额定热水温度 nominal hot water temperature给水温度 feed watr temperature3.2.2.1.9回水温度 return water temperature排污率 rate of blowdown锅炉热力计算 thermal calculation for boilers锅炉水动力计算 hydrodynamic calculation for boilers锅炉烟风阻力计算 flue-gas and air resistance calulation for boilers锅炉受压元件强度计算 strength calculation of pressure parts for boilers 锅炉水循环 boiler circulation循环回路 circulation circuit蒸汽品质 steam quality蒸汽污染 steam contamination机械携带 mechanical carry-over溶解携带 vaporous carry-over蒸汽净化 steam purification蒸汽湿度 moisture in steam分段蒸发 stage evaporation气温调节 steam temperature control给水 feed water补给水 make-up water锅水 boiler water给水品质 feedwater condition锅水浓度 boiler water concentration总硬度 total hardness总碱度 total alkalinity悬浮固形物 suspended solid matter溶解固形物 dissolved solid matter相对碱度 relative alkalinity负压燃烧 negative-pressure firing压力燃烧 pressurized firing自然通风 natural draft机械通风 mechanical draft平衡通风 balanced draft分段送风 zone control draft燃料消耗量 fuel consumption计算燃料消耗量 calculated fuel consumption理论空气量 theoretical air过量空气系数 excess air ratio理论燃烧温度 theoretical combustion temperature炉膛出口烟气温度 furnace outlet gas temperature排烟温度 exhaust gas temperature锅炉热效率 boiler efficiency保证效率 guarantee efficiency燃烧效率 combustion efficiency锅炉热损失 boiler heat loss排烟热损失 heat loss due to exhaust gas气体不完全燃烧热损失 heat loss due to unburned gases固体不完全燃烧热损失 heat loss due to unburned carbon in refuse 散热损失 heat loss due to radiation灰渣物理热损失 heat loss due to sensible heat in slag飞灰可燃物含量（飞灰含碳量） unburned combustible in flue dust炉渣可燃物含量（炉渣含碳量） unburned combustible in slag漏风系数 air leakage factor热风温度 hot air temperature一次风（一次空气） primary air二次风（二次空气） secondary air三次风（三次空气） tertiary air炉膛容积热负荷 furnace volume heat release rate炉膛截面热强度 furnace cross-section heat release rate辐射受热面热流密度（炉壁热流密度） furnace wall heat flux density 炉排面积热负荷 grate heat release rate炉排通风截面比 percentage of air space水动力特性 hydrodynamics循环倍率 circulation ratio循环水速 circulation velocity运动压头 available static head有效压头 available head质量流速 mass velocity质量含汽率 steam quality by mass临界含汽率 critical steam quality沸腾换热恶化 boiling crisis过冷沸腾 subcooled boiling计算压力 calculated pressure计算壁温 calculated metal temperature最高允许工作压力 maximum allowable working pressure安全系数 safety factor许用应力 allowable stress理论计算壁厚 theoretical calculated thickness最小需要壁厚 minimum required thickness公称壁厚（名义壁厚） nominal thickness 有效壁厚 effective thickness应力集中系数 stress concentration factor 孔桥减弱系数 ligament efficiency焊缝减弱系数 weld efficiency开孔补强 reinforcement of openings表面清理 surface cleaning喷丸（砂）处理 shot-rain cleaning封头成型 head forming冲压成型 press forming旋压成型 spin forming爆炸成型 explosion forming边缘加工 edge processing去毛刺 deburring卷板 plate rolling冷态卷板 cold rolling热态卷板 hot rolling矫形 shape righting矫圆 round set板边预弯 preliminary rolling弯管 tube bending冷态弯管 cold bending胀管 tube expansion胀管率 expansion efficiency成排焊接 panel welding成排弯管 panel bending不圆度 out-of-roundness直线度 straightness/alinement偏心度 eccentricity管端倾斜度 gradient of tube-end通球试验 ball passing test锅筒起吊 drum lifting砌墙 walling烘炉 furnace drying煮炉 boiling out补炉 fetting挖补修理 remedy除垢 descaling机械除垢 mechanical descaling化学清洗 chemical cleaning碱煮除垢 alkali descaling酸洗除垢 acid descaling钝化处理 passivating冲管 flushing吹管 steam-line blowing锅炉改造 boiler reforming炉拱改造 arch reforming循环系统改造 circulation circuit reforming 锅炉启动 start-up上水 filling水位 water level炉内清扫 purge点火 fire升压 raising pressure疏水 drain并汽 bring a boiler onto the line启动压力 start-up pressure启动流量 start-up flow rate滑参数启动 variable parameter start-up排污 blowdown定期排污 periodic blowdown连续排污 continuous blowdown吹灰 soot blowing压缩空气吹灰 compressed air blowing蒸汽吹灰 steam blowing药物清灰 chemical deashing压火 banking fire停炉 shutdown定压运行 constant pressure operation变压运行 variable pressure operation经济运行 economical operation停炉保养 preservation湿法保养 wet preservation干法保养 dry preservation充气保养 gas-filled preservation外部检查 visual inspection内部检查 internal inspection宏观检验 macroscopic examination漏风试验 air leakage test堵灰 clogging布风板grid plate。

A List of Abbreviations and Symbols in English-ChineseA Ash Handling System 除灰系统AH Air Heater 空气预热器AAh Analyzer, Alarm High 分析器，高值报警AIV Air Intake Valve 进气阀ALIGN Alignment 校正ALKF Airlock Feeder 锁气器AP Ash Slurry Pump 灰浆泵ATM Atmosphere 大气AC Air Conditioner 空气调节器AFT Atmosphere Flash Tank 大气扩容器AC Alternating Current 交流电ALM Alarm 报警AMP Ampere 安培AX THR BRG Axis Thrust Bearing 轴向推力，轴承ATMZ Atomizing 雾化AUTO Automation 自动AUX Auxiliary 辅助的BA Bottom Ash 底灰BAH Bottom Ash Hopper 底灰斗BLR Boiler 锅炉BSD Boiler Shut Down 停炉BUSH Bushing 衬套BYPS Bypass 旁路BCP Boiler Circulating Pump 锅炉循环泵BVD Boiler Vents and Drains 锅炉疏水放气BFP Boiler Feed-water Pump 锅炉给水泵BFPTBoiler Feed-water Pump Turbine锅炉给水泵汽机BFW Boiler Feed-water 锅炉给水BM Boiler Master 锅炉主控BMCR Boiler Maximum Continuous Rating 锅炉最大连续出力BFBP Boiler Feed Booster Pump 锅炉给水增压泵BNR Burner 燃烧器BOP Balance Of Plant 电厂辅机设备BPC Blade Pitch Control 叶片带距控制BT Boiler Tube 炉管CH Crusher House 碎煤房COMB Combustion 燃烧COMP Compressed Air 压缩空气CONV Conveyer 输送机CPL Control Panel Local 就地控制盘CPM Control Panel Main 主控盘CRT Cathode Ray Tube 屏幕显示CT Current Transformer 变流器CYCL Cyclone 旋风分离器CAS Casing 缸CB Cut Breaker 开关COMP Complete 完成CCCW Closed Circulating Cooling Water 闭式循环冷却水CCW Closed Cooling Water 闭式冷却水CCWHF Closed Cooling Water Heater 闭式冷却水冷却器CCWP Closed Cooling Water-pump 闭式冷却水泵CS Closed Cooling Water System 闭式冷却水系统CH Coal Handling 煤的装卸CHK VLV Check Valve 逆止阀CIRC Circulation 循环CLR Cooler 冷却器CLSD Closed 闭式CLOW Cooling Water 冷却水CMPR Compressor 压缩机CNDNR Conditioner 调节器CNTL Control 控制CNTLE Controller 控制器COND Condensate 凝结水CONDTY Conductivity 导电率CP Condensate Pump 凝结泵CIR Circuit 回路COUPI Coupling 藕合，连接CP Condensate Polisher 除盐装置CS Control Switch 控制开关CRSV Cold Reheat Safety Valve 再热器冷段安全阀CV Control Valve 控制阀CWP Circulation Water Pump 循环水泵DMPR Damper 挡板DP Difference Pressure 差压DPIC Differential Pressure Indicating Controller 压差指示控制器DPT Differential Pressure Transmitter 压差变速器DRN Drain 疏水DV Drain Valve 疏水阀DC Direct Current 直流电DSH De-super-heater 减温器DCA Drain Cooler Approach 疏水冷却器通道DEAER De-aerator 除氧器DEV Deviation 偏差DIFFRLY Differential Relay 差动继电器DISCH VLV Discharge Valve 排放阀DIST Disturbance 故障DSCH Discharge 排出ECON Economizer 省煤器EP Electrical Static Precipitator 电除尘ECC Eccentric 偏心EFF Efficiency 效率EHC Electric Hydraulic Control 电液控制EO Electric Operate 电气操作EQ Equipment 设备ER Error 误差ES Extraction System 抽气ESC Escape 逃逸ESS Engineering Safety System 保安系统EU Engineering Unit 工程单位EXH Exhaust 排汽EXT Extract 抽出F Fly Ash System 飞灰系统FA Fine Ash 细灰FDR Feeder 给料机FE Flow Element 流量元件FI Flow Indicator 流量指示件FDBK Feedback 反馈FITG Fitting 连接件FLW Flow 流量FO Fail Open 故障时自动开关FT Flow Totalize 流量累加器FT Flow transmitter 流量变送器FV Flow Control Valve 流量控制阀FY Flow Relay or Valve 流量传送器FA Failure Alarm 故障报警FD Forced Draft 强制通风FDF Forced Draft Fan 送风机FDR Feeder 给煤机FIC Flow Indicate Controller 流量指示控制器FLT Flash Tank 扩容箱FLD Field 磁场FLG Flange 法兰FLM Flame 火焰FWH Feed Water Heater 给水加热器FO Fuel Oil 燃油FREQ Frequency 频率FURN Furnace 炉膛FV Flow Control Valve 流量控制阀GLD Gland 密封GRDR Grinder 碎渣机GND Ground 接地GC Generator Cooling 发电机冷却GEN Generator 发电机GESE Gland Steam Condenser Exhauster 轴封抽汽机GMT Generator Main Transformer 发电机变压器GRAD Grandient 梯度GS Gland Steam 轴封蒸汽GSC Gland Steam Condenser 轴封加热器GV Governor Valve 压调门H Heat Conservation 保温HO Heavy Oil 重油HP High Pressure Horse Power 高压马力HS Hand Switch 手动开关HTR Heater 加热器HV Hand Control Valve 手动控制器HY Hand Relay or Transducer 手动继电器（转换器）H Hand 手动的HB Heat Balance 热平衡HD Heater Drain 加热器疏水HD der 联箱HL Heat Loss 热损失HMDY Humidity 湿度HPH High Pressure Heater 压加热器HPR Hooper 漏斗HPT High Pressure Turbine 高压缸HR Hot Reheat 再热器，热段HR Heat Rate 热耗率HSV Hot Reheat Safety Valve 再热器热段安全阀HT Heat 加热HTG Heating 加热HTR Heater 加热器HVAC Heating Ventilation & Air Conditioner 加热通风与空气调节HW Hot-well 热井HV Hand Control Valve 手动控制器HYD Hydraulic 液力的INTLK Interlock 联锁IC Instrument and Control 仪表与控制（热工）ICV Intermediate Control Valve 中压控制阀ID Induced Draft 抽风，引风IDF Induced Draft Fan 引风机IGN Ignition 点火装置INLT Inlet 入口IPR Initial Pressure 初压INST Instrument 仪表INVR Inverter 倒相器，转换开关I /O Input/Output 输入/输出IP Intermediate Pressure 中压IPT Intermediate Pressure Turbine 中压缸ISV Intermediate Pressure Turbine Steam Valve中压缸，进汽阀JP Jet Pump 喷射器LG Level Gauge 料位计LUB Lubricate 润滑油LVL Level 水位，液位LA Level Alarm 液体报警LIM(LMIR) Limiter 限制器LKG Leakage 泄漏LP Low Pressure 低压L.P Low Point 低位LPH Low Pressure Heater 低压加热器LS Live Steam 主蒸汽LSH Local Switch Hand 就地开关LUB OIL Lube Oil 润滑油M Mechanical 机械Motor 马达MAG Magnetic 磁性MOD Mode 方式M/A Manual/Automatic 手动/自动MAN Manual 手动MARG Margin 极限MAX Maximum 最大的，最大值的MCR Maximum Continuous Rating最大连续出力MCV Main Control Valve 主控制阀MD Modulation Damper 调节挡板MDBFP Motor Driven Boiler Feed-water Pump 电动给水泵MEAS Measure 测量MFT Master Fuel Trip 主燃料切断MIN Minimal 最小的MKUP (MU) Make-up 补充ML Mill 磨煤机MN Main 主要的M.O. Manual Operate 手操MPT Main Power Transformer 主变压器MS Main Steam 主蒸汽MSV Main Steam Valve 主汽阀NOZ Nozzle 喷嘴NPSH Net Pump Suction Heat 泵的静吸压头OL Overload 过载OLR Overload Relay 过载继电器OPER Operation 运行OSC Oscillograph 示波器OTLT Outlet 出口PA Primary Air 一次风PAF Primary Air Fan 一次风机PAH Pressure Alarm High 高压报警PAL Pressure Alarm低压报警PAS TDBFP A Status 汽动给水泵A状态PB Push Button 按钮PBS TDBFP B Status 汽动给水泵B状态PC Power Center 动力中心PC Pressure Controller 压力控制器P.C. Pressure Control 压力控制PCP Precipitator 除尘器PCV Pressure Control Valve 压力控制阀PDI Pressure Differential Indication 差压指示计PDT Pressure Differential Transmitter 差压变送器PED Pdestal 轴承座PERF CALC Performance Calculation 性能计算PF Power Factor 功率因数PHTR Pre-heater 预热器PMP Pump 泵PNEU Pneumatic 气动的PR Pressure Recorder 压力记录计PRG Purge 吹扫PRV Pressure Relief Valve 泄压阀PRO Protection 保护PROGR Program 程序PT Pressure Transmitter 压力变送器PULV pulverizer 磨煤机PVSV Pressure Vacuum Safety Valve压力真空安全阀PW Plant Water 厂用水PY Pressure Relay 压力继电器QA Quality 质量，性能RB Run Back 快速降负荷RCV Recovering 回收RCV Reverse Current Valve 逆止阀RECIRC Re-circulation 再循环RECT Rectifier 整流器RED Reducer 减压器RET Return 返回RH Re-heater 再热器RO Restriction Orifice 节流孔板ROT Rotor 转子RTU Remote Telemetry Unit 遥测装置SA Secondary Air 二次风SAT Saturate 饱和的SC Steam Coil Air Heater 暖风器SCAV Scavenge 吹扫SCN Scanner 控制器SD Shut-off Damper 关断挡板Shut-Down 停止运行SEP Separator 分离器SG Switchgear 开关装置SH-DN Shut-Down 切除SH Super-heater 过热器SLS Seals 密封SO Shut Off 关闭SPD Speed 转速SPRA Spray 喷水SPT Support 支持，支架ST Start 启动，开始STD-BY Stand By 备用ST System 系统STM Steam 蒸汽STR Stator 定子STRNR Strainer 滤器SU Start Up 启动SV Solenoid Valve 电磁阀Shut Off Valve 关断阀SUCT Suction 吸入SW Switch 开关Steam Water 汽水SBLWR Soot Blower 吹灰器TBFP Turbine Drive Boiler Feed-water Pump 汽动给水泵TCV Temperature Control Valve 温度控制T.B. Transfer Damper 转换挡板TE Temperature Element 测量元件TG Turbine-generator 汽轮发电机Turbine-gear 汽机盘车THERM Thermal 热力的TMS Turbine Master System 汽机主控TRANS Transfer 转换TRBL Trouble 故障TRKG Tracking 跟踪TRX TURBOMAX 汽机最大热应力控制TT Temperature Transmitter 温度传感器TTD Terminal Temperature Difference 温度端差TURB Turbine 汽机TW Thermo-well 热电偶套管UAM Unit Automatic Master 机组自动系统VAC Vacuum 真空VAL Value 数值VB Vibration 振动VLV Valve 阀门WH Watt-hour 瓦小时WP Work Point 工作点WW Water Wall 水冷壁WX Watt Transducer 功率转换器COVER Crossover 切换管CV Control Valve 控制阀PS Position Switch 状态开关，位置开关PT Position Transmitter 状态变送器BOOSTER PUMP FREE SIDE BEARING TEMP前置泵自由端径向轴承温度BOOSTER PUMP DRIVEN SIDE BEARING TEMP前置泵驱动端径向轴承温度BOOSTER PUMP THRUST BEARING OUTSIDE TEMP前置泵推力轴承外侧温度BOOSTER PUMP THRUST BEARING INSIDE TEMP前置泵推力轴承内侧温度comment 注释，评论module 模块standby 备用proximity 相近，接近，亲近detector 探测器bracket 支架interlocks 互锁，连锁axial 轴向的surge conditions 喘振loss of speed 飞车accessory 附件pulsation 有节奏的跳动，跳动fossil fired 燃煤intent 意图，目的，意向intend 意指，想要，打算consistent 一致的，调和的practice 惯例，实习，实践intrinsic 固有的，内在的procurement 获得，获取fabrication 制作，构成，伪造物vent 通风孔，出烟孔，出口，放出，排出，发泄noncondensible gas 不凝结气体intermittent 间歇的，断断续续的blowdown 排污tank 桶，箱，罐diagram 图表deaerator 除氧器corrosion 侵蚀，腐蚀状态concentration 集中，集合，浓缩，浓度recommend 推荐，介绍，托付，劝告abnormal and normal conditions 变工况和额定工况warm up 暖机acid wash 酸洗scale 范围，水垢，水锈，比例，刻度sludge 污泥，淤泥foreign matter 不相关的物质facilitate 推动，促进，使简化multistage 多级的remote control 遥控safety relief valve 安全卸压阀gauge 量规，量表，测量manhole 人孔，检修孔equivalent 等价物，相等的forging 锻造seat 部位，座socket welding 管座焊接enthalpy 焓estimate 评价，评估，估价parameters 参数，参量nominal 名义上的，额定的，标称的MS—Main Steam 主蒸汽Cycle循环Intercept截止Fetting附件Gage规，表，压力计Taps接头test wells测点插孔stress-relieved 应力消除thermometer温度计steam purge system蒸汽吹扫系统centrifugal type pumps离心式泵margin余量friction losses磨擦损失solenoid螺线管modulat调整，调节criteria标准wrenches扳手pipe taps管接头Assemble 集合，集结，组装Group 聚合，成群Vibration 振动audio 声频的，音频的integral 部分，完整，积分，完整的boiler house 锅炉房coal conveyor 输煤装置coal bunker 煤仓coal mill 磨煤机steam boiler water boiler tube蒸汽锅炉，管式锅炉furnace(combustion chamber) 炉膛(燃烧室) water tube 水管ash pit 灰坑super-heater 过热器water pre-heater 水预热器air pre-heater 空气预热器gas duct(flue) 烟气管,烟道dust collecting plant 集尘室electrical precipitation plant 电气除尘室induced draught fan 引风机chimney 烟囱de-aerator 除氧器feed water tank 供水箱boiler feed pump 给水泵switchgear 开关设备cable tunnel 电缆通道cable cellar 电缆槽turbine room 汽轮机室steam turbine with alternator蒸汽汽轮发电机组economizer 省煤器steam drum 汽包surface condenser 表面凝汽low-pressure pre-heater 低压预热器circulating water pipe(pump) 循环水管control room 控制室electrostatic dust remover(precipitator)静电除尘器pulverizer 磨煤机slag pump 灰渣泵thermal cycle 热力循环(net)heat rate （净）热耗率STEAM POWER STATION 火力发电站。

锅炉名词术语1.1-锅炉类型1.2-常用名词1.3-炉膛和燃烧设备1.4-锅筒、锅内装置及集箱1.5-锅炉蒸发受热面1.6-过热器和再热器1.7-省煤器和空气预热器1.8-锅炉构架和炉墙1.9-锅炉管道和安全附件2.1-基本参数2.2-常用术语2.3设计参数和指标I-锅炉设备及主要零部件II-锅炉设计Ⅲ-锅炉制造Ⅳ-锅炉安装维修改造Ⅳ-锅炉定期检验Ⅴ-锅炉使用（运行）Aacid descaling 酸洗除垢：在一定浓度的盐酸和氢氟酸的水溶液中再配以一定浓度的缓蚀剂作为缓蚀盐酸清洗剂注入锅水中，采用浸泡或循环清洗或浸泡结合循环清洗的方法进行酸洗的除垢方法。

Additive 添加剂：为了不同目的（例如燃用高硫燃料时减轻低温受热面的腐蚀、沸腾燃料时减少大气污染和液态排渣中降低熔点等）在燃料中所加处的化学物质。

Adiabatic Temperature /Theoretical Combustion Temperature 理论燃烧温度：燃料在绝热条件下燃烧时烟气所能达到的温度。

Air Compartment 风室：炉排下部的进风室。

air duct 风道: 输送锅炉燃料燃烧所需空气的通道。

air heater 空气预热器: 利用低温烟气加热空气的对流受热面部件。

air leakage factor 漏风系数: 外界漏入锅炉某一烟道中的空气量与锅炉理论空气量的比值。

即为锅炉某一烟道进出口处烟气中过量空气系数的差值。

air leakage test 漏风试验: 检查锅炉炉墙及烟风道严密性的试验。

alkali descaling 碱煮除垢：在锅水中加入一定量的纯碱（32CONa）、烧碱（NaOH）和磷酸三钠（43PONa）作为清洗剂，在一定压力下进行较长时间煮炉，碱煮结束后放尽碱液，并用清水冲洗的除垢方法。

碱煮法对硫酸盐和硅酸盐水垢能起较好的松软作用，但总的效果不如酸洗法。

Alkalinity 碱度：水中所含能接爱氢离子的物质的含量。

boiler锅炉boiler unit锅炉机组stationary boiler固定式锅炉steam boiler/generator蒸汽锅炉utility boiler电站锅炉industrial boiler工业锅炉hot water boiler热水锅炉indoor boiler室内锅炉ourdoor boiler露天锅炉package boiler快装锅炉shop-assembled boiler组装锅炉field-assembled boilerfield-erected boilersupercritical pressure boiler超临界压力锅炉subcritical pressure boiler亚临界压力锅炉superhigh pressure boiler超高压锅炉high pressure boiler高压锅炉medium pressure boiler中压锅炉low pressure boiler低压锅炉natural circulation boiler自然循环锅炉forced circulation boiler强制循环锅炉assisted circulation boiler辅助循环锅炉controlled circulation boiler控制循环锅炉once-through boiler直流锅炉combined circulation boiler复合循环锅炉low circulation-ratio boiler低循环倍率锅炉solid-fuel fired boiler固体燃料锅炉liquid-fuel fired boiler液体燃料锅炉coal fired boiler燃煤锅炉oil fired boiler燃油锅炉gas fired boiler燃气锅炉multi-fuel fired boiler混烧锅炉boiler with dry-ash furnaceboiler with dry-bottom furnaceboiler with slag-tap furnaceboiler with wet-bottom furnacesupercharged boiler增压锅炉water tube boiler水管锅炉cross drum boiler横锅筒（汽包）锅炉longitudinal drum boiler纵锅筒（汽包）锅炉shell boiler锅壳锅炉horizontal boiler卧式锅壳锅炉vertical boiler立式锅炉stationary boiler of locomotive type固定式机车锅炉π-type boiler （two-pass boiler)π型锅炉box-type boiler箱型锅炉tower boiler 塔型锅炉散装锅炉固态排渣锅炉液态排渣锅炉D-type boilerD 型锅炉rated capacitynominal capacitymaximum continuous rating最大连续蒸发量rated heating capacity额定供热量nominal steam conditionnominal steam parameternominal steam pressure额定蒸汽压力nominal steam temperature额定蒸汽温度(nominal) hot water temperature热水温度feed water temperature给水温度return water temperature回水温度circulation circuitsteam generating circuitsteam purification蒸汽净化steam temperature control汽温调节feed water给水condensate凝结水make-up water补给水boiler water锅水；炉水boiling crisis沸腾换热恶化as-fired fuel炉前燃料fire bedfuel bedfire line最高火界additive添加剂flue gas dew point烟气露点boiler circulation水循环mechanical carry-overmoisture carry-overvaporous carry-over溶解携带water separation汽水分离steam washing蒸汽清洗stage evaporation分段蒸发pressurized firing压力燃烧negative-pressure firing负压燃烧grate firing火床燃烧suspension firing火室燃烧；悬浮燃烧tangential firing切向燃烧opposed firing对冲燃烧cyclone-furnace firing旋风燃烧fluidized-bed combustion沸腾燃烧gas recirculation烟气再循环natural draft自然通风mechanical draft机械通风balanced draft平衡通风forced draft 正压通风火床机械携带额定蒸发量额定蒸汽参数循环回路induced draft负压通风zone control分段送风pressure atomizationmechanical atomizationtwin-fluid atomization双流体雾化rotary-cup atomization旋杯雾化；转杯雾化direct leakageinfiltration leakagebypass leakageentrained leakageboiler proper锅炉本体heating surface受热面radiant heating surface辐射受热面convection heating surface对流受热面pressure part受压部件；受压元件cylindrical shell筒体head封头；端盖header集箱；联箱tube panel管屏up flow riser tube panel垂直上升管屏ribbon panel回带管屏spirally-wound tubes水平围绕管圈tube bundle管束gas passgas ductconvection pass对流烟道parallel gas passes并联烟道air duct风道arch拱furnace arch折焰角water-cooled hopper bottom冷灰斗wall with refractory liningrefractory beltsupporting tube悬吊管design pressure设计压力maximum allowable working pressure最高允许工作压力maximum allowable metal temperature最高许用壁温furnace enclosure design pressure炉膛设计压力heat input输入热量heat output锅炉有效利用热量fuel consumption燃料消耗量calculated fuel consumption计算燃料消耗量ash-retention efficiency排渣率load range at constant temperature（保持）额定汽温的负荷范围injection flow(rate)喷水量blowdown flow(rate)排污量theoretical air 理论空气量卫燃带压力雾化；机械雾化直接泄漏间接泄漏烟道excess air ratio过量空气系数hot air temperature热风温度exhaust gas temperature排烟温度theoretical combustion temperatureadiabatic temperaturefurnace outlet gas temperaturefurnace exit gas temperaturepressure drop汽水阻力draft losspressure dropstack draft自生通风压头available static head运动压头circulation ratio循环倍率circulation velocity循环水速steam quality by mass质量含汽率；干度mass velocity质量流速critical steam quality临界含汽率steam quality at minimum heat transfercoefficient最高壁温处含汽率furnace volume炉膛容积furnace volume heat release rateheat liberation rate in furnacefurnace cross-section heat release ratefurnace plan heat release rateburner zone wall heat release rate燃烧器区域炉壁热负荷furnace wall heat release rate炉壁热负荷furnace wall heat flux density炉壁热流密度critical heat flux density临界热流密度grate heat release rate炉排（面积）热负荷burner heat input燃烧器热功率ignition energy点火能量evaporation rate受热面蒸发率percentage of economizer evaporation省煤器沸腾率primary air一次风secondary air二次风tertiary air三次风imaginary circle假想切圆percentage of air space通风截面比fineness煤粉细度explosion mixture limits爆炸界限furnace炉膛；炉胆fire box火箱smoke box烟箱burner燃烧器tilting burner摆动式燃烧器igniter点火器oil atomizer 油雾化器理论燃烧温度炉膛出口烟气温度通风阻力炉膛容积热负荷炉膛截面积热负荷register调风器stabilizer稳燃器wind box风箱burner portburner quarlgrate炉排hand-fired grate手烧炉排stoker-fired gratemechanical stokertravelling grate stoker链条炉排chain grate stoker链带式炉排bar grate stoker横梁式炉排louvre stoker鳞片式炉排vibrating stoker振动炉排inclined reciprocating grate往复炉排spreader stoker抛煤机air compartment风室reinjection system飞灰复燃装置drum锅筒；汽包steam drum上锅筒water drum下锅筒shell锅壳drum internals锅筒内部装置；汽包内部装置steam washer清洗装置cyclone separator旋风分离器turbo separator轴流式分离器baffle plate缝隙挡板corrugated scrubber百叶窗分离器screen separator钢丝网分离器perforated distribution plate多孔板dry pipe集汽管evaporating heating surface蒸发受热面water-cooled wall水冷壁membrane wall膜式水冷壁division wall双面水冷壁anti-clinker box防焦箱gererating tube bankboiler convection tube bankboiler (slag) screen防渣管fire tube ；smoke tube烟管；火管mixer混合器superheater过热器radiant superheater辐射过热器wall superheater墙式过热器platen superheater屏式过热器convection surperheater对流过热器steam-cooled wall 包墙过热器燃烧器喷口机械炉排锅炉管束steam-cooled roof顶棚管过热器reheater再热器attemperatordesuperheatersurface type attemperatorsurface type desuperheaterspray type attemperatorspray type desuperheaterbifluxreheater superheater attemperatorbypass damper旁路挡板economizer省煤器steaming economizer沸腾式省煤器steel tube economizer钢管省煤器finned tube economizer鳍片管省煤器cast-iron gilled tube economizer铸铁省煤器air heater空气预热器tubular air heater管式空气预热器rotary air heaterregenerative air heater rotating-plate type regenerativeair heaterLjungstrom type air heaterstationary-plate type regenerativeair heaterrothemuhle type air heatersteam air heater暖风器boiler structure锅炉构架top-supported structure by beams支承式锅炉构架top-supported structure by hangers悬吊式锅炉构架buckstay刚性梁inner casing内护板outer casing外护板boiler steam and water circuit锅炉汽水系统boiler external piping锅炉范围内管道start-up system启动系统start-up flash tank启动分离器safety valve安全阀safety relief valve安全泄放阀water level indicator水位表injector注水器boiler setting炉墙soot blower吹灰器slag removal equipment除渣设备boiler efficiency锅炉效率；锅炉热效率boiler operating availability锅炉可用率boiler forced outage rate锅炉事故率feed water condition 给水品质汽-汽热交换器回转式空气预热器受热面回转式预热器风罩回转式预热器减温器面式减温器喷水减温器steam purity 蒸汽品质moisture in steam 蒸汽湿度boiler water concentration 锅水浓度；炉水浓度total dissolved salt 总含盐量total solid (matter)全固形物dissolved solid (matter)溶解固形物suspended solid (matter)悬浮物total hardness （总）硬度alkalinity 碱度heat loss 热损失heat loss due to exhaust gas 排烟热损失heat loss due to unburned gases 气体（化学）未完全燃烧热损失heat loss due to unburned carbon inrefuse 固体（机械）未完全燃烧热损失heat loss due to radiation 散热损失heat loss due to sensible heat in slag 灰渣物理热损失unburned combustible in flue dustunburned carbon in flue dust unburned combustible in slagunburned carbon in slag unburned combustible in sifting 漏煤可燃物含量dust loadingdust density load range of boiler 锅炉负荷调节范围turndown ratio 燃烧器调节比air leakage factor 漏风系数set pressure 整定压力start-to-discharge pressure 前泄压力popping pressure 起座压力reseating pressure 回座压力blowdown 回座压差discharge capacity 排放量；排汽能力boiler efficiency test 锅炉效率试验；锅炉热效率试验hydrostatic test 水压试验hydrostatic deformation test 验证性水压试验air leakage test 漏风试验pressure decay test 风压试验load test 负荷试验circulation test 水循环试验thermal chemical test 热化学试验sounding of tube by balls 通球试验safety valve operating test 安全阀校验flue gas analysis 烟气分析Orsat (gas analyser)奥氏（烟气）分析器suction pyrometer 抽气式热电偶（高温计）venturi pneumatic pyrometer 气力式高温计heat flux meter 热流计飞灰可燃物含量；飞灰含碳量炉渣可燃物含量；炉渣含碳量烟气含尘量start-up启动filling上水water level水位initial water level点火水位purge吹扫blowoff放水drain疏水blowdown排污raising pressure升压bringing a boiler onto the line 并汽start-up pressure启动压力start-up flow rate启动流量shutdownoutageout of service停用banking fire压火storage停炉保护chemical cleaning化学清洗boiling-out（碱）煮炉flushing冲管steam-line blowing 吹管passivating钝化drying-out烘炉flow stagnation停滞flow reversal倒流separation of two-phase fluid 汽水分层steam bindingsteam blanketingpriming汽水共腾foaming泡沫共腾external deposit烟气侧沉积物internal deposit汽水侧沉积物slagging结渣fouling积灰clogging堵灰pitting attack点状腐蚀ductile gouging延性腐蚀hydrogen damage 氢脆caustic embrittlement苛性脆化high temperature corrosion 高温腐蚀low temperature corrosion 低温腐蚀overheating超温；过热flashback回火blow off脱火loss of ignition熄火；灭火furnace explosion炉膛爆炸furnace implosion 炉膛内爆汽塞停炉furnace puff炉膛爆燃blow hole火口secondary combustion二次燃烧。

锅炉专业术语涉及锅炉的设计、制造、安装、运行和维护等方面的专业术语。

以下是一些常见的锅炉专业术语及其英文对照：1. 水管锅炉 (Water Tube Boiler)- 锅炉中水流动的管道，用于产生蒸汽。

2. 自然循环锅炉 (Natural Circulation Boiler)- 利用密度差产生的自然循环来驱动水流动的锅炉。

3. 强制循环锅炉 (Forced Circulation Boiler)- 通过泵强制循环水流的锅炉。

4. 直流锅炉 (Once-Through Boiler)- 水在一次通过锅炉后就被加热并转化为蒸汽的锅炉。

5. 废热锅炉 (Waste Heat Boiler)- 利用工业过程中产生的废热来加热水的锅炉。

6. 乏气锅炉 (Exhaust Gas Boiler)- 利用发动机排放的废气来加热水的锅炉。

7. 正压锅炉 (Supercharged Boiler)- 通过增加压力来提高锅炉效率的锅炉。

8. 燃煤锅炉 (Coal Fired Boiler)- 使用煤作为燃料的锅炉。

9. 重油锅炉 (Heavy Oil Boiler)- 使用重油作为燃料的锅炉。

10. 燃气锅炉 (Gas Fired Boiler)- 使用天然气或其他燃气作为燃料的锅炉。

11. 混烧锅炉 (Multi-Fuel Fired Boiler)- 能够燃烧多种燃料的锅炉。

12. 超临界压力锅炉 (Supercritical Pressure Boiler)- 工作压力超过临界点的锅炉。

13. 亚临界压力锅炉 (Subcritical Pressure Boiler)- 工作压力低于临界点的锅炉。

14. 汽包锅炉 (Drum Boiler)- 锅炉内有一个或多个汽包来存储蒸汽。

15. 辐射式锅炉 (Radiant Boiler)- 主要通过辐射热传递来加热水的锅炉。

16. 室内锅炉 (Indoor Boiler)- 设计用于安装在室内的锅炉。

1/15
* 主要施工工艺 锅炉本体与配件 锅炉本体与配件 锅炉本体与配件 ** 锅炉本体与配件 * 锅炉本体与配件 * * * * 砌பைடு நூலகம்材料 机械与工具 * * * 锅炉一般用语 锅炉一般用语 ** * 主要施工工艺 * * * * * 砌筑材料 * 锅炉一般用语 锅炉一般用语 主要施工工艺 砌筑材料 * * * * * 主要施工工艺 砌筑材料 主要施工工艺 主要施工工艺 机械与工具 ** 锅炉分类 锅炉分类 * ** *
锅炉词汇
锅炉本体 锅炉范围内管道 锅炉防爆门 锅炉给水泵 锅炉工作压力 锅炉构架组焊 锅炉管束 锅炉机组 锅炉框架(钢架) 锅炉汽水系统 锅水（炉水） 锅水浓度 锅筒（汽包） 锅筒工作压力 锅筒内部装置 过热器 夯实锤 合门处（锁口） 合门砖（锁砖） 烘炉 虹吸拴 呼吸阀 护板 滑动风门 划线 环砌 换管 回水温度 回转式空气预热器 火焰烘炉 机（底）座 基准管 集汽管 集箱(联箱) 挤浆 监察段 减温器 碱度 胶带输煤机 搅拌机 窖炉砌筑 空气压缩机 空气预热器 矿渣棉 窥视器 拉线（挂线） 拉砖（拉固砖) 冷灰斗 离心式风机 犁式卸煤器 立砌 Boiler hourmenon Boiler External piping Burst prevent gate of boiler Water feed pump of boiler Boiler operating pressure Boiler structure pack and welding Tube bundle of boiler Boiler unit Boiler structure Boiler steam and water circuit Boiler water Boiler water concentration Drum Drum operating pressure Drum internals Super heater Rammer hammer Lock door Lock door brick Drying-out Siphon tie Breath vavle Casing Glide wind gate Laying-out Ring lay Repipe return water temperature Turning air preheater Flame drying-out Machine base Reference pipe Steam pipe Header Compact grout Supervise sect Attemperator Alkalinity Adhesive tape coal transporter Mixer Boiler brick setting Air compressor Air perheater Mineral wool Peek device Lining Guy brick Water -cooled hopper bottom Centrifugal Fans Furrow coal discharger Riser lay

电力术语一、锅炉部分1．临界压力锅炉supercritical pressure boiler2. 亚临界压力锅炉subcritical pressure boiler3. 超高压锅炉super-high pressure boiler4. 蒸汽锅炉steam boiler5. 蒸汽发生器steam generator6. 液态排渣锅炉wet bottom boiler7. 固态排渣锅炉dry bottom boiler8. 燃煤锅炉coal-fired boiler9. 燃气锅炉Gas-fired boiler10.燃油锅炉oil-fired boiler11.自然循环锅炉natural circulation boiler12.汽包（锅筒）锅炉drum boiler13.强制循环锅炉controlled circulation boiler14.直流锅炉once-through boiler15.复合循环锅炉combined circulation boiler16.旋风炉cyclone furnace boiler17.沸腾炉fluidized bed combustion(FBC)boiler18.循环硫化床circulating fluidized bed combustion(FBC)boiler19.增压循环硫化床锅炉pressurized circulating fluidized bed combustion(PCFBC)boiler20.链条锅炉chain-grate boiler21.热水锅炉hot-water boiler22.废热（余热）锅炉water-heat boiler, heat recover steam generator(HRSG)23.启动锅炉start-up boiler24.厂用锅炉auxiliary boiler25.垃圾焚烧锅炉refuse-fired boiler, refuse incinerator27.露天锅炉outdoor boiler28.单炉膛锅炉single furnace boiler29.双炉膛锅炉twin furnace boiler30.W火焰锅炉W-flame boiler, vertical-fired boiler31.L火焰锅炉L-shape furnace boiler32.塔式锅炉tower boiler33.箱式锅炉box-type boiler34．炉墙furnace wall35. 汽包（锅筒）drum36.封头head37.汽包封头drum end plate, drum head38.下降管downcomer 39.集中下降管centralized downcomer40.分散下降管distributed downcomer41.上升管riser42.管束（排）tube bundle43.管屏tube platen44.省煤器管economizer tube45.过热器管superheated tube46.再热器管reheater tube47.蛇形管coil48.吊挂管supporting tube49.引入管inlet pipe50.引出管outlet pipe51.饱和蒸汽管saturated steam pipe52.水冷壁管water wall tube53.鳍片管finned tube, fin tube, gilled tube54.内螺纹管rifled tube, grooved tube55.吸潮管moisture absorption piping56.水冷壁water wall57.膜式水冷壁membrane wall58.内螺纹水冷壁rifled tube water wall59.联箱header60.集汽联箱steam header61.卫燃带bailey wall, refractory belt62包墙管（包覆管）wall enclosure tube63.防渣管（弗斯顿管）slag screen, feston tube64.锅炉本体boiler proper65.锅炉机组boiler unit66.锅炉构架boiler structure67.炉膛boiler framework68.燃烧器furnace69.直流式燃烧器direct-flow burner70.旋流式燃烧器turbulent burner71.低NOX燃烧器low NOX burner72.摇摆式燃烧器tilting burner73.缝隙式燃烧器split burner74.燃烧室combustion chamber75.油枪oil gun torch76.风门damper77.一次风primary air78.二次风secondary air79.三次风tertiary air80.煤粉管道pulverized coal piping81.管板tube plate82.沸点boiling temperature83.过热器superheater84.前屏过热器front platen superheater85.后屏过热器rear plate superheater86.对流过热器convection superheater87.辐射过热器radiant superheater88.屏式过热器plate superheater89.顶棚过热器ceiling superheater90.包墙过热器wall enclosure superheater91.前包墙过热器front wall enclosure superheater92.后包墙过热器rear wall enclosure superheater93.侧包墙过热器side wall enclosure superheater94.吹灰器soot blower95.转动式吹灰器rotary soot bolwer96.伸缩式吹灰器retractable soot blower97.受热面积heating surface area, heat absorption area98.炉膛容积furnace volume99.炉膛热负荷furnace heat release rate, furnace heating absorption rate100.汽水分离器steam separator, moisture separator 101.起动分离器starting separator102.再循环管recirculating piping103.暖风器steam air heater104.再热器reheater105.再热器冷段primary reheater106.再热器热段final reheater107.顶棚ceiling108.省煤器economizer109.管式省煤器tube economizer110.管式空气预热器tubular air preheater111.回转式（再生式）空气预热器regenerative air preheater, rotary air preheater112.板式空气预热器plate air preheater113.空气预热器air preheater114.三分仓空气预热器trisector regenerative air preheater115.漏风系数air leakage coefficient116.漏风率air leakage ratio117.漏风系统air leakage system118.漏风试验air leakage test119.安全门safety valve120.安全门开启压力opening pressure of safety valve 121.安全门回座压力safety valve reseating pressure 122.安全门压力整定试验pressure setting test of safety valve123.安全门动作压力safety valve operating pressure 124.饱和蒸汽安全门saturated steam safety valve 125. 过热蒸汽安全门superheated steam safety valve126.再热蒸汽安全门reheated steam safety valve 127.防暴门explosion vent128.检查孔inspection hole129.事故喷水阀emergency water spray valve 130.汽包事故放水阀emergency drum drain valve 131.三通阀three-way valve132.反冲洗阀back wash valve133.取样阀sampling valve134.插板gate135.给水大旁路门feedwater overall bypass valve 136.给水小旁路门feedwater individual bypass valve 137.大板梁plate girder, upper beam138.外护板outer casing139.锅炉排污blowdown140.定期排污扩容器intermittent blowdown flash tank141.连续排污扩容器continuous blowdown flash tank 142.灰斗ash hopper143.冷灰斗bottom ash hopper, furnace hopper 144.混合器mixer145.齿圈（大牙轮）ring gear, geared ring146.空调器air conditioner147.空气压缩机air compressor148.给煤机coal feeder149.皮带式给煤机belt coal feeder150.刮板式给煤机scraper coal feeder151.叶轮式给煤机paddle coal feeder152.给粉机pulverizer coal feeder153.磨煤机coal pulverizer, coal mill154.钢球磨煤机tube mill155.中速辊式磨煤机roller mill, bowl mill, disk roll mill156.双进双出钢求磨煤机double inlet and outlet tube mill157.中速磨煤机medium speed mill158.风扇磨煤机beater wheel mill, beater mill 159.排粉风机pulverized coal exhauster160.一次风机primary air fan161. 烟气再循环风机gas recirculation fan162.送风机forced draft fan, force fan163.引风机induced draft fan, induced fan164.离心风机centrifugal fan165.轴流风机axial-flow fan166.双速风机double speed fan167.轴流静叶可调风机adjustable static-blade axial-flow fanfixed pitch axial-flow fan168.轴流动叶可调风机adjustable moving-blade axial-flow fanvariable pitch axial-flow fan169.原煤斗raw coal bunker, raw coal silo170.煤粉仓pulverized coal bunker171.输粉机pulverized coal conveyer172.刮板输粉机scraper pulverized coal conveyer 173.螺旋输粉机pulverized coal screw conveyer 174.粗粉分离器classifier175.细粉分离器（旋风分离器）cyclone separator 176.锁气器air lock, flap177.减速机speed reduce178.看火孔observation hole179.人孔门man hole180.重油泵heavy oil pump181.重油加热器heavy oil heater182.汽-汽热交换器biflux183.煤气罐gas tank184.膨胀补偿节expansion joint185.直吹式制粉系统direct firing pulverizing system 186.中贮式制粉系统bin storage type pulverizing system187.锅炉效率boiler efficiency188.锅炉热力计算boiler thermodynamic calculation 189.锅炉空气动力计算boiler aerodynamic calculation 190.锅炉水循环计算boiler water circulation calculation191.锅炉水力计算boiler hydrodynamic calculation 192.锅炉强度计算boiler strength calculation193.锅炉热平衡boiler heat balance calculation 194.正平衡法direct balance method195.反平衡法indirect balance method196.过剩空气系数excess air coefficient197.排烟温度flue gas temperature198.单位蒸量specific evaporation199.低温腐蚀low temperature corrosion 200.高温腐蚀high temperature corrosion201.结渣lagging202.结垢腐蚀deposit corrosion203.飞灰磨损fly ash erosion204炉膛负压furnace draft205.最高允许温度maximum permissible temperature206.炉膛正压furnace pressure207.水循环water circulation208.循环倍率circulation ratio209.除尘器dust collector, precipitator210.静电除尘器electrostatic precipitator211.整流装置rectifying device212.锤打装置rapping gear213.含尘浓度dust loading concentration214.煤灰细度dust fineness215.除尘效率dust collection efficiency216.干式除尘器dry dust collector217.湿式除尘器wet dust collector, scrubber218.文丘里除尘器venture scrubber219.布袋除尘器fabric filter, bag house220.钢珠除尘装置shot-cleaning device221.水膜式除尘器centrifugal scrubber222.灰渣泵ash pump, slag pump223.轴封泵shaft sealing pump224.灰浆泵ash slurry pump225.除尘水泵dedusting pump226.回收水池water recovery pond227.清水池clean water pond228.灰浆池ash slurry pond229.油泵坑oil pump pit230.灰库ash silo231.灰场ash yard232.灰坝ash yard dam233.耐火砖firebrick234.保温材料heat-insulating material235.干式除灰（气力除灰）pneumatic pressure ash handling236.水力除灰hydraulic ash handling237.正压气力除灰pneumatic pressure ash handling 238.负压气力除灰pneumatic pressure ash handling 239.仓式泵fluidizing transporter240.空气斜槽airslide, air gravity conveyor241.灰渣分除bottom and fly ash separate handling242.灰渣混除bottom and fly ash mixed handling 243.灰渣利用bottom and fly ash recovery244.排渣槽bottom ash hopper245.埋刮板捞渣机submerged slag conveyor246.螺旋式捞渣机screw slag conveyor247.碎渣机clinker grinder, slag crusher248.振动筛vibrating screen249.稳燃器flame stabiliaer250.燃烧器蜗壳burner spiral case251.雾化器atomization252.机械雾化mechanical atomization253.蒸汽雾化steam atomization254.空气雾化air atomization255.气固两相流动gas-solid two-phase flow256.闭路循环closed cycle257.蒸汽带水carryoery258.炉膛灭火boiler flame failure, boiler flame blackout259.稳定燃烧stable combustion260.压力容器pressure vessel261.支吊架supports and hangers262.原煤管道raw coal piping263.风道air duct264.热风道hot air duct265.冷风道cold air duct266.穿墙套管wall-through bushing, wall-bushing 267.伸缩节expansion joint268.送粉管道pulverized coal feed piping269.燃油管道fuel oil piping270.风管道air piping271.一次风管道primary air piping272.二次风管道secondary air piping273.落粉管pulverized coal chute274.除灰管道ash piping275.烟道gas dust, gas pass276.尾部烟道convection flue gas pass277.煤气管gas piping278.连续排污管continuous blowdown piping279.烟囱chimney, stack280.多管式烟囱multi-flue chimney281.燃烧combustion282.四角喷射燃烧corner firing283.燃烧速度combustion rate284.机械未完全燃烧热损失heat loss due to mechanical incomplete combustion285化学未完全燃烧热损失heat loss due to chemical incomplete combustion286.灰渣热损失heat loss due to sensible heat in refuse287.排烟热损失heat loss due to flue gas288.散热损失heat loss due to radiation289.热损失heat loss290.火焰flame291.不稳定燃烧instable combustion292.负压燃烧balance draft combustion293.微负压燃烧pressurized combustion294.炉膛容积热负荷furnace volume heat release rate295.炉膛温度furnace temperature296.锅炉水循环boiler water circulation297.偏离泡核沸腾departure from nucleate boiling(DNB)298.水压试验hydraulic test299.汽水共沸priming300.点火ignition301.点火准备ignition preparation302.着火点firing point, ignition temperature303.折焰角nose304.飞灰fly ash305.煤粉细度fineness of pulverized coal306.灰ash307.灰的熔化点ash fushion temperature, ash fushion point, ash melting point308.可磨系数grindability index309.最大蒸发量maximum evaporation310.锅炉热平衡boiler heat balance311.超负荷运行overload operation312.正压positive pressure313.负压negative pressure314.理论空气量theoretical air quantity315.过剩空气量excess air quantity316.冷风cold air317.热风hot air318.除渣slag removal319.烟气flue gas320.锅炉上水boiler water filling321.蠕胀爆管tube burst due to creep322.汽包满水overfeed of water into drum323.锅炉灭火boiler fire extinction324.爆燃puff325.爆炸（外爆）explosion326.内爆implosion327.防爆anti-explosion328.煤粉自燃pulverized coal self-ignition, pulverized coalspontaneous combustion329.堵灰ash fouling330.堵煤coal jamming, coal plugging331.燃烧切圆firing tangential circle332.火焰中心flame center333.积粉pulverized coal deposits334.粉灰ash deposits335.飞灰可燃物combustibles in fly ash336.点火用油fuel oil for ignition337.飞灰腐蚀fly ash corrosion338.受热面heating surface339.辐射受热面radiation heating surface340.对流受热面convection heating surface341.尾部受热面rear heat recovery surface342.含氧量oxygen content343.蒸发量evaporation, evaporative capacity 344.切换风air switch-over345.煤耗率coal consumption rate346.入炉煤发热量heating value of the as fired coal 347.停炉boiler shutdown348.熄火fire-off349.灰水回收recovery of ash slurry water350.细灰fine ash351.粗灰coarse ash352.干灰dry ash353.湿灰wet ash354.燃烧系数combustion system, firing system 355.制粉系统coal pulverizing system356.除灰系统ash handling system二、汽轮机357.汽轮机steam turbine358.凝汽式汽轮机condensing steam turbine359.背压式汽轮机back pressure turbine360.抽汽式汽轮机steam extraction turbine361.中间再热式汽轮机reheating type steam turbine 362.供热式汽轮机steam supply turbine, heat supply turbine, cogeneration turbine363.冲动式汽轮机impulse turbine364.反动式汽轮机reaction turbine365.轴流式汽轮机axial flow turbine366.辐流式汽轮机radial flow turbine367.单轴汽轮机tandem compound turbine, single-shaft turbine368.双轴汽轮机double-shaft turbine, cross compound turbine369.前置式汽轮机topping turbine370.燃气轮机gas turbine371.高压汽轮机high pressure turbine372.中压汽轮机medium pressure turbine373.低压汽轮机low pressure turbine374.超高压汽轮机ultra pressure turbine375.亚临界压力汽轮机subcritical pressure turbine 376.超临界压力汽轮机supercritical pressure turbine 377.空冷式汽轮机组air cooled turbine unit378.燃气轮机组（装置）gas turbine unit379.高压汽缸high-pressure(HP) cylinder380.中压汽缸intermediate-pressure(IP) cylinder 381.低压汽缸low-pressure(LP) cylinder382.内汽缸inner casing383.外汽缸outer casing384.上汽缸upper casing385.下汽缸lower casing386.汽缸法兰螺栓加热装置cylinder flange heating appliance387.汽缸台板（底板）cylinder sole pin388.汽缸猫爪cylinder claw389.滑销sliding pin390.横销traverse pin391.纵销longitudinal pin392.立销vertical pin393.定位销aligning pin, locating pin394.汽轮机转子turbine rotor395.叶轮blade disc396.叶片blade, bucket397.动叶片moving blade398.静叶片stationary blade399.叶根型式type of blade root400.末级叶片长度length of last stage blade401.喷嘴室nozzle box402.末级叶片强度last stage blade stress403.排汽室steam exhaust hood404.喷嘴nozzle405.围带shroud ring406.拉筋（拉金）lacing wire407.平衡块balance weight408.固定螺钉dowel409.隔板diaphragm410.隔板套diaphragm sleeve411.隔板汽封diaphragm seal, diaphragm sealing 412.汽封steam seal gland, steam sealing413.迷宫式汽封labyrinth seal414.梳齿式汽封serrate-type steam seal415.汽封套seal bushing416.汽封块seal block417.汽封齿seal tooth418.轴承支架bearing stoll, bearing bracket419.主轴承箱main bearing box420.滚珠轴承ball bearing421.滚柱轴承roller bearing422.滑动轴承sliding bearing423.推力轴承thrust bearing424.止推环thrust collar425.瓦枕bearing pillow426.锁饼lock427.推力瓦块thrust bearing pad428.主油泵main oil pump429.备用油泵emergency bearing oil pump430.调速油泵regulation oil pump, speed governing oil pump431.交流润滑油泵AC lube oil pump432.直流润滑油泵DC lube oil pump433.注油器oil injector434.同步器synchronizer435.同步器手轮synchronizer hand wheel436.控制滑阀pilot valve437.随动滑阀servo-valve438.分配滑阀distributing pilot valve, distributor valve439.中间滑阀intermediate valve440.微分器differentiator441.功率限制器load limiter442.动态校正器dynamic corrector443.滑阀套valve sleeve444.喷油嘴oil nozzle 445.弹性调速器flexible governor446.调速器挡块governor stop447.危急遮断器滑阀emergency trip pilot valve 448.撞击子ram449.防火滑阀fire protection pilot valve450.延滞滑阀delay pilot valve451.跟踪滑阀follow-up pilot valve452.电-液转换器electro-hydraulic converter, electro-hydraulic transducer453.切换滑阀change-over pilot valve454.危急保安器emergency governor455.危急保安器滑阀emergency governor pilot valve 456.超速试验滑阀overspeed test pilot valve457.喷油试验滑阀nozzle test pilot valve458.反馈滑阀feedback pilot valve459.起动排油阀oil drain valve at star-up460.紧急放油阀emergency oil relieve valve461.排油口oil diacharge outlet462.节流滑阀throttle pilot valve463.滑动油阀movable pilot valve464.高压自动关闭器high-pressure automatic closing gear465.中压自动关闭器medium pressure automatic closing gear466.高压油动机（高压伺服马达）high-pressure hydraulic actuator, high-pressure servo-motor 467.中压油动机medium-pressure hydraulic actuator, medium-pressure servo-motor468.杠杆lever469.轴shaft470.主轴main shaft471.传动轴(主动轴) driven shaft472.被动轴（从动轴）driven shaft473.小轴axle474.联轴器coupling475.刚性联轴器rigid coupling476.半挠性联轴器semi-flexible coupling477.齿型联轴器serrated coupling478.冷油器oil cooler479.溢油器oil overflow valve480.排油烟机oil-fume extractor, oil fume exhaust 481.油烟分离器oil-fume separator482.油净化器oil purifier, oil conditioner483.过滤罐filtering tank484.布袋式过滤器bag filter, fabric filter485.齿轮油泵gear oil pump486.顶轴油泵jacking oil pump487.柱塞式油泵piston type oil pump488.螺杆式油泵worm type oil pump489.盘车装置turning gear490.盘车手轮turning gear hand wheel491.化桩板lagging enclosure492.齿轮gear493.直齿式齿轮spur gear494.斜齿式齿轮helical gear495.伞型齿轮bevel gear496.蜗轮worm wheel497.蜗杆worm stem498.弹簧spring499.密封油箱sealing oil tank500.空气侧交流密封油泵air side AC sealing oil pump 501.空气侧支流密封油泵air side DC sealing oil pump 502.压差阀differential pressure valve503.平衡阀balancing valve504.密封瓦sealing pad505.缓冲油箱buffer oil tank506.高位油箱head oil tank, elevated oil tank 507.事故油箱emergency oil tank508.磁性过滤器magnetic filter509.发电机内冷水箱generator inner cooling water tank510.发电机内冷水泵generator inner cooling water pump511.离子交换器ion exchanger512.干燥器dryer, drier513.冷凝式干燥器condensing type drier514.凝汽器condenser515.多压式凝汽器multi-pressure condenser516.单流程凝汽器single-pass condenser517.双流程凝汽器double-pass condenser518.黄铜管brass tube519.管板tube plate520.凝汽器喉部condenser throat521.热水井hot well522.凝结水泵condensate pump523.泵壳pump casing524.盘根gland packing525.盘根压盖gland top cover 526.盘根端盖gland end cover527.填料packing528.轴封抽汽风机shaft seal extraction fan529.轴封抽汽冷却器shaft seal extraction cooler, gland cooler530.轴封漏汽加热器shaft seal leakage heater 531.低压加热器low-pressure feed water heater 532.中压加热器media-pressure feed water heater 533.高压加热器high-pressure feed water heater 534.蒸汽冷却器steam cooler535.疏水冷却器drain water cooler536.汽侧steam side537.水侧water side538.U型管U-tube539.除氧器deaerator540.储水池water storage pond541.卧式除氧器horizontal type deaerator542.立式除氧器vertical type deaerator543.喷雾式除氧器atomizing type deaerator544.淋水盘water spraying tray, sprinkling tray 545.除氧水箱deaerated water tank546.稳压水箱surge water tank, stabilizing water tank547.除盐水箱demineralized water tank548.除盐水泵demineralized water pump549.汽动给水泵steam-driven feed water pump 550.电动调速给水泵motor-driven variable speed feed water pump551.前置水泵booster pump552.给水泵feed water pump553.机械密封mechanical seal554.碳精密封环carbon seal ring, carbon packing ring555.动环moving ring556.静环static ring557.平衡盘balancing disc558.液力偶合器hydraulic coupler559.泵轮（主动轮）pump impeller, driving impeller 560.涡轮（从动轮）whirling impeller, driven impeller 561.勺管scoop tube562.辅助油泵auxiliary oil pump563.疏水泵drain pump564.疏水扩容器drain flash tank565.疏水箱drain tank566.热网加热器heater for heating network, heating network hot water heater567.生水加热器raw water heater568.热网水泵pump for heating network, heating network hot water pump569.生水泵raw water pump570.除尘水泵pump for scrubber, scrubber water pump571.壳体case, shell572.水室water chamber573.封头end cover574.挡板baffle plate575.导流板guide plate576.射水泵water jet pump577.真空泵vaccum pump578.射水抽气器water jet air ejector579.射汽抽气器steam jet air ejector580.射水池water jet pond581.排水池drain water pond582.工业水泵industrial water pump, service water pump583.排污泵blowdown pump584.轴流泵axial flow pump585.清水泵clean water pump586.污水泵sewage pump587.排水泵water discharge pump588.立式深井泵vertical deep-well pump589.深井泵deep-well pump590.潜水泵submerged pump591.循环水泵circulating water pump592.清污机trash remover593.混流泵mixed flow pump594.离心泵centrifugal pump595.旋转滤网rotating type screen, screw type strainer596.胶球泵rubber ball recirculating pump597.收球网ball screen598.装球网ball collector599.管式冷却器tubular cooler, tube type cooler599/1.支撑斜钢supporting wedge600.板式冷却器plate type cooler601.冷却水池cooling water pond602.喷水池spraying water pond603.冷却水塔cooling tower 604.自然通风冷却塔natural draft cooling tower 605.逆流式冷却塔reverse flow cooling tower606.横流式塔transverse flow cooling tower607.机力通风冷却塔mechanical draft cooling tower 608.空气冷却塔air cooling tower609.干式冷却塔dry cooling tower610.分水槽water diversion channel611.竖井shaft, well612.闸板井gate well613.闸门室gate chamber, gate house614.挡风板air baffle plate615.新（主）蒸汽管道main steam piping, live steam piping616.主蒸汽系统main steam system617.再热蒸汽系统reheat steam syetem618.抽汽系统extraction steam system619.轴封供汽系统shaft seal steam supply system 620.轴封shaft seal621.门杆漏汽系统valve lever leakage steam system 622.汽缸法兰螺栓加热系统casing flange and bolt heating system623.真空系统vaccum system624.凝结水系统condensate system625.再热蒸汽管道reheat steam system626.给水系统feed water system627.循环水系统circulating water system628.工业水系统industrial water system, service water system629.供油系统oil supply system630.密封油系统seal oil system631.厂用蒸汽系统auxiliary steam system632.调速系统speed governing system633.电液调速系统electro-hydraulic speed governing system634.发电机内冷水系统generator inner cooling water system635.热网系统heating network system636.导汽管steam lead pipe637.连通管inter-connecting pipe638.抽汽管道steam extraction pipe639.抽汽母管steam extraction header640.厂用蒸汽管道plant service steam piping641.厂用蒸汽母管plant service steam header 642.蒸汽旁路系统steam bypass system643.蒸汽大旁路single stage steam bypass644.一级蒸汽旁路first stage steam bypass645.二级蒸汽旁路second stage steam bypass646.辅助蒸汽母管auxiliary steam header647.供汽联箱steam header648.回汽联箱return steam header649.供水联箱water supply header650.回水联箱return water header651.门杆漏汽管道valve lever steam leakage piping 652.轴封漏汽管道shaft seal leakage steam piping 653.抽空气管道air extraction piping654.压缩空气管道compressed air piping655.氢气管道hydrogen piping656.疏水管道drain water piping657.凝结水管道condensate piping658.循环水管道circulating water piping659.工业水管道industrial water piping, service water piping660.冷却水管道cooling water piping661.给水管道feed water piping662.除盐水管道demineralized water piping663.减温水管道attemperating water piping664.再循环水管道recirculating water piping665.排水管道water discharge piping666.润滑油供油管道lube oil supply piping667.润滑油管lube oil piping668.调速油管governing oil piping669.回油管道return oil piping670.压力油管道pressure oil piping671.密封油管道seal oil piping672.脉动油管pulsating oil piping673.热网水管道heating network water piping 674.平衡管balance pipe675.电动主闸门motor-operated main gate valve 676.高压主汽门high-pressure main stop valve 677.中压主汽门intermediate pressure main stop valve678.旁路门bypass valve679.防腐汽门corrosion-proof valve680.高压调速汽门high-pressure governor valve 681.中压调速汽门medium pressure governor valve 682.对空排汽门atmospheric relief valve683.疏水门drain valve684.调整门adjusting valve 685.电动门motor-operated valve686.手动门hand-operated valve687.减温器attemperator, desuperheater688.减压器（阀）pressure reducer(valve)689.减温减压器temperature and pressure reducer 690.抽汽电动门motor-operated steam extraction valve691.抽汽逆止门extraction check valve692.高压排汽逆止门high-pressure exhaust check valve693.逆止门check valve, non-return valve694.入口门inlet valve695.出口门outlet valve696.球型阀globe valve697.闸板阀gate valve698.针型阀needle valve699.翻板阀tripper valve700.液压阀hydraulic valve701.控制阀control valve702.换向阀reverse flow valve703.疏水阀drain valve704.蝶阀butterfly valve705.衬胶门rubber lined valve706.高压加热器入口联成阀composite valve at high pressure heater inlet707.高压加热器出口联成阀composite valve at high pressure heater outlet708.高压加热器旁路门high pressure heater bypass valve709.水封阀门water seal valve710.排污门blow down valve711.排气门exhaust steam valve712.排汽门exhaust steam valve713.补水门water supply valve, make-up water valve714.补油门oil valve, oil supply valve715.补氢门hydrogen supply valve716.空气门air valve717.真空破坏阀vacuum breaking valve, vacuum breaker718.排汽安全门exhaust steam safety valve719.弹簧安全门spring relief valve720.排汽缸喷水门exhaust cylinder water-spraying valve721.电磁阀solenoid valve, magnet valve722.前截门front intercept valve723.后截门rear intercept valve724.排氢门hydrogen vent valve725.中间抽头门intermediate stage bleed-off valve 726.最小流量阀minimum flow valve727.暖泵门pump warming valve728.泵体放水门pump-body water drain valve 729.放水门water discharge valve730.减温水门attemperating water valve731.切换门change-over valve, diverting valve 732.联络门interconnection valve733.液压逆止门hydraulic check valve734.再沸腾加热门reboiled heating valve735.放空气门air vent valve736.再循环门recirculation valve737.冷却水门cooling water valve738.热效率thermal efficiency, heat efficiency 739.内效率internal efficiency740.额定工况rated operation condition741.最大工况maximum operation condition742.汽耗量steam consumption743.汽耗率steam consumption rate744.热耗率specific heat consumption, heat rate 745.新蒸汽压力initial steam pressure, live steam pressure746.再热蒸汽冷段压力cold reheated steam pressure 747.再热蒸汽热段压力hot reheated steam pressure 748.再热蒸汽热段温度hot reheated steam temperature749.再热蒸汽冷段温度cold reheated steam temperature750.主蒸汽流量steam flow751.再热蒸汽流量reheated steam flow752.低压缸排汽流量low-pressure cylinder exhaust steam flow753.转速rotating speed, revolution754.真空度vaccum755.旋转方向rotation direction756.给水温度feedwater temperature757.调节级压力pressure at velocity stage758.临界转速critical speed759.吊装重量lifting weight760.速度变化率speed variation rate 761.迟缓率delay rate762.凸轮转角cam torque angle763.过热度superheat degree764.温差temperature difference765.端差terminal temperature difference766.过冷度supercooling degree767.高压加热器投入率high pressure heater availability rate768.轴向位移axial shift, axial displacement769.大轴晃动值shaft swinging value, shaft eccentricity770. 高压缸膨胀high-pressure cylinder expansion 771.中压缸膨胀intermediate pressure cylinder expansion772.低压缸膨胀low pressure cylinder expansion 773.市政速油压governing oil pressure774.润滑油压lubricating oil pressure775.脉动油压impulse oil pressure776.附加保安油压additional safeguard oil pressure 777.滑阀上油压oil pressure above pilot valve 778.滑阀下油压oil pressure under pilot valve 779.润滑油温lubricating oil temperature780.轴承加油温度bearing return oil temperature 781.轴承钨金温度babbit metal temperature, bearing metal temperature782.推力瓦块温度thrust pad temperature783.密封油压seal oil pressure784.油位oil level785.水中含氧量oxygen content of water786.凝结水硬度condensate hardness787.轴承振动值shaft(bearing) vibration amplitude 788.垂直振动值vertical vibration amplitude789.水平振动值horizontal vibration amplitude 790.轴向振动值axial vibration amplitude791.油膜振荡oil film oscillation, oil whipping792.冲转impulse starting793.冷态启动cold start794.热态启动hot start795.滑参数启动starting at sliding parameters, sliding pressure starting796.滑参数停机shut-down at sliding parameters, sliding pressure shut-down797.升速speed up798.升速率percentage of maximum momentaryspeed variation,speed-up rate799.负荷上升率loading rate800.基本负荷base load801.调峰运行peak load regulating operation, cyclic operation802.空转idling, idle running803.手动打闸停机hand trip, turbine hand trip 804.暖机turbine warming up805.最短盘车时间minimum turning time806.低速暖机low speed warming807.中速暖机medium speed warming808.滑参数起动曲线starting curve at sliding parameters,sliding pressure starting-up curve809.滑参数停机曲线shut-down curve at sliding parameters,sliding pressure shut-down curve810.全周进汽full admission811.部分进汽partial admission, partial-arc admission812.喷嘴调节nozzle governing813.节流调节throttle governing814.破坏真空vaccum breaking815.汽缸金属温度cylinder metal temperature 816.听音检查sound detection817.惰走时间idling time818.超速试验overspeed test819.真空严密性试验vaccum leakage test820.主汽门严密性试验main steam stop valve leakage test821.危急遮断器充油试验emergency governor oil filling test822.低油压保护试验low oil pressure protection test 823.调速系统静止试验governing system pre-operation test824.调速系统动态特性试验governing system dynamic performance test825.调速系统静态特性试验governing system static performance test826.甩负荷试验load-dump test, load-rejection test 827.空负荷试验no-load test828.满负荷试验full-load test829.超负荷试验overload test 830.转子平衡试验rotor balancing test 831.动平衡dynamic balancing832.静平衡static balancing833.热力试验thermodynamic test834.叶片频率试验blade frequency test 835.投入运行to be put into operation 836.开启opening837.关闭closing838.启动starting-up839.停止shutting down840.充氢hydrogen charging841.排氢hydrogen discharging842.补水water make-up843.补油oil make-up844.水位调整water level regulation845.暖管warming846.手摇同步器hand synchronizer847.检查inspection, examination848.巡检routing inspection849.蒸汽带水carry-over850.水击hydraulic shock, water hammer 851.超速overspeed852.轴承损坏（烧瓦）bearing burnt-out 853.断叶片broken blade854.断轴broken shaft855.气蚀cavitation856.反转（倒转）reversal rotation857.调节级regulation stage858.压力级pressure stage859.抽真空vaccum extraction860.盘车turning861.法兰加热flange heating862.螺栓加热bolt heating863.漏汽steam leakage864.漏水water leakage865.炭精轴封carbon packing866.冒烟smoking, smoke belching867.着火fire catching, fire868.强烈振动strong vibration869.管道破裂piping breaking870.无蒸汽运行no-steam operation871.堵塞choking, plugging, blocking 872.异音abnormal sound873.轴封供汽steam supply for shaft sealing。

19 ARRANGEMENT OF MISCELLANEOUS PIPING
杂项管路布置图
20 PIPING AND INSTRUMENTATION DIAGRAM
(P&I流程图)介质流程图
21 BOILER CIRCULATION PUMPS DIAGRAM
锅炉循环泵系统图
22 STRENGTH CALCULATION OF BOILER STEAM DRUM
第 3 页，共 17 页
121 SCOPE OF SUPPLY AND TECHNICAL REQUIREMENTS
供货范围和技术要求
第 4 页，共 17 页
ቤተ መጻሕፍቲ ባይዱ
序号
英文
122 CONTRACT NO.
123 A TECHNOLOGY TRANSFER CONTRACT
124 BUYER
125 SELLER
第 2 页，共 17 页
序号
英文
80 CHEMICAL COMPOSITION
81 MATERIAL PROPERTIES
82 MINIMUM TENSILE STRENGTH
83 MINIMUM YIELD STRENGTH
84 MAXIMUM TEMPERATURE LIMITS(OXIDATION LIMIT)
74 STRUCTURAL STEEL DESIGN SECTION
75 STRESS ANALYSIS SECTION
76 SECRETARY OFFICE
77 FIRING SYSTEM DESIGN SECTION
78 COMPUTER PROGRAM DESIGN SECTION
79 POSTWELD HEAT TREATMENT

锅炉专业英语中英文对照表火道锅炉Flame tube boiler疏水器、疏水阀steam trap饱和蒸汽saturated steam过热蒸汽superheated steam震动炉篦Oscillating bar grate链条炉蓖Chain grate, travelling grate省煤器economizer减速器speed reducer螺旋除渣机screw slag remover除尘器dust collectorcombustion air fan鼓风机exhausting fan上煤机coal conveyor尖端的、高科技的Hi-tech节能的energy-saving高效的high-efficiency低噪声的low noise耐用的、持久的durable蒸发evaporation额定的rated热效率thermal efficiency碳化物carbide碳化硅silicon carbidemonoxide一氧化碳carbon monoxide二氧化碳dioxide二氧化碳亚临界压力锅炉carbon dioxide subcritical pressure boiler燃煤锅炉coal-fired boiler启动锅炉 start-up boiler炉墙 furnace wall管束（排） tube bundle管屏tube platen下降管 downcomer上升管 riser省煤器管 economizer tube再热器管 reheater tube过热器管 superheated tube蛇形管 coil吊挂管 supporting tube水冷壁管 water wall tubesaturated steam pipe水冷壁 water wall鳍片管finned tube, fin tube, gilled tube 联箱 header锅炉本体 boiler proper锅炉机组 boiler unit炉膛 boiler framework燃烧器 furnace燃烧室 combustion chamber油枪 oil gun torch风门 damper管板 tube plate。

油雾化器 稳燃器 风箱
调风器 风室 烟箱 炉排 抛煤机 飞灰复燃装置 锅筒（汽包） 锅筒内部装置 汽水分离器 集汽管 蒸发受热面 水冷壁 防焦箱
பைடு நூலகம்
锅炉管束 Tube bundle of boiler 锅炉本体与配件 防渣管 Anti-slag tube 锅炉本体与配件 Fire tube 锅炉本体与配件 烟管（火管） 过热器 Super heater 锅炉本体与配件 Reheater 锅炉本体与配件 再热器 减温器 Attemperator 锅炉本体与配件 汽－汽热交换器 Reheating attemperator 锅炉本体与配件 旁路挡板 Bypass damper 锅炉本体与配件 Economizer 锅炉本体与配件 省煤器 Air perheater 锅炉本体与配件 空气预热器 安全阀 Safety valve 锅炉本体与配件 安全泄放阀 Safety relief valve 锅炉本体与配件 水位表 Water level indicator 锅炉本体与配件 压力表 Pressure inolicator 锅炉本体与配件 Water injector 锅炉本体与配件 注水器 吹灰器 Soot Blower 锅炉本体与配件 除渣设备 Slag removal equipment 锅炉本体与配件 除尘设备 Dust removal equipment 锅炉本体与配件 输煤设备 Coal feeder 锅炉本体与配件 （锅炉）给水设备 Water feeder 锅炉本体与配件 （锅炉）通风设备 Ventilation Equipment 锅炉本体与配件 （锅炉）水处理设备 Water treated 锅炉本体与配件 Refractory 砌筑材料 耐火材料 定形耐火材料 Certain sized refractory 砌筑材料 不定形耐火材料 Uncertain sized refractory 砌筑材料 耐火砖 Refractory brick 砌筑材料 耐火泥（粉） Refractory clay 砌筑材料 泥浆（灰浆） Silp 砌筑材料 砂浆 Mortar 砌筑材料 耐火浇注料（耐火混凝土Refractory casting material (Refractory concrete) 砌筑材料 耐火可塑料 Refractory material 砌筑材料 耐火捣打料 Refractory tamping material 砌筑材料 耐火喷涂料 Refractory spray coating material 砌筑材料 投射料 Spray material 砌筑材料 涂抹料 Daub material 砌筑材料 耐火粘土砖（烧粘土、耐火砖 Refractory clay brick 砌筑材料 高铝砖 Aluminum fire brick 砌筑材料 硅砖 Silica brick 砌筑材料 镁铬砖 Magnesite chrome brick 砌筑材料 镁铝砖 magnetite aluminum brick 砌筑材料 白云石砖 Cinguefoil brick 砌筑材料 砌筑材料 普通粘土砖（红砖、青砖Common clay brick Straight shape brick 砌筑材料 直形砖（标形砖）

电力术语一、锅炉部分1．临界压力锅炉supercritical pressure boiler2. 亚临界压力锅炉subcritical pressure boiler3. 超高压锅炉super-high pressure boiler4. 蒸汽锅炉steam boiler5. 蒸汽发生器steam generator6. 液态排渣锅炉wet bottom boiler7. 固态排渣锅炉dry bottom boiler8. 燃煤锅炉coal-fired boiler9. 燃气锅炉Gas-fired boiler10.燃油锅炉oil-fired boiler11.自然循环锅炉natural circulation boiler12.汽包（锅筒）锅炉drum boiler13.强制循环锅炉controlled circulation boiler14.直流锅炉once-through boiler15.复合循环锅炉combined circulation boiler16.旋风炉cyclone furnace boiler17.沸腾炉fluidized bed combustion(FBC)boiler18.循环硫化床circulating fluidized bed combustion(FBC)boiler19.增压循环硫化床锅炉pressurized circulating fluidized bed combustion(PCFBC) boiler20.链条锅炉chain-grate boiler21.热水锅炉hot-water boiler22.废热（余热）锅炉water-heat boiler, heat recover steam generator(HRSG)23.启动锅炉start-up boiler24.厂用锅炉auxiliary boiler25.垃圾焚烧锅炉refuse-fired boiler, refuse incinerator27.露天锅炉outdoor boiler28.单炉膛锅炉single furnace boiler29.双炉膛锅炉twin furnace boiler30.W火焰锅炉W-flame boiler, vertical-fired boiler31.L火焰锅炉L-shape furnace boiler32.塔式锅炉tower boiler33.箱式锅炉box-type boiler34．炉墙furnace wall35. 汽包（锅筒）drum36.封头head37.汽包封头drum end plate, drum head38.下降管downcomer39.集中下降管centralized downcomer40.分散下降管distributed downcomer41.上升管riser42.管束（排）tube bundle43.管屏tube platen44.省煤器管economizer tube45.过热器管superheated tube46.再热器管reheater tube47.蛇形管coil48.吊挂管supporting tube49.引入管inlet pipe50.引出管outlet pipe51.饱和蒸汽管saturated steam pipe52.水冷壁管water wall tube53.鳍片管finned tube, fin tube, gilled tube54.内螺纹管rifled tube, grooved tube55.吸潮管moisture absorption piping56.水冷壁water wall57.膜式水冷壁membrane wall58.内螺纹水冷壁rifled tube water wall59.联箱header60.集汽联箱steam header61.卫燃带bailey wall, refractory belt62包墙管（包覆管）wall enclosure tube63.防渣管（弗斯顿管）slag screen, feston tube64.锅炉本体boiler proper65.锅炉机组boiler unit66.锅炉构架boiler structure67.炉膛boiler framework68.燃烧器furnace69.直流式燃烧器direct-flow burner70.旋流式燃烧器turbulent burner71.低NOX燃烧器low NOX burner72.摇摆式燃烧器tilting burner73.缝隙式燃烧器split burner74.燃烧室combustion chamber75.油枪oil gun torch76.风门damper77.一次风primary air78.二次风secondary air79.三次风tertiary air80.煤粉管道pulverized coal piping81.管板tube plate82.沸点boiling temperature83.过热器superheater84.前屏过热器front platen superheater85.后屏过热器rear plate superheater86.对流过热器convection superheater87.辐射过热器radiant superheater88.屏式过热器plate superheater89.顶棚过热器ceiling superheater90.包墙过热器wall enclosure superheater91.前包墙过热器front wall enclosure superheater92.后包墙过热器rear wall enclosure superheater93.侧包墙过热器side wall enclosure superheater94.吹灰器soot blower95.转动式吹灰器rotary soot bolwer96.伸缩式吹灰器retractable soot blower97.受热面积heating surface area, heat absorption area98.炉膛容积furnace volume99.炉膛热负荷furnace heat release rate, furnace heating absorption rate100.汽水分离器steam separator, moisture separator101.起动分离器starting separator102.再循环管recirculating piping103.暖风器steam air heater104.再热器reheater105.再热器冷段primary reheater106.再热器热段final reheater107.顶棚ceiling108.省煤器 economizer109.管式省煤器tube economizer110.管式空气预热器tubular air preheater111.回转式（再生式）空气预热器regenerative air preheater, rotary air preheater 112.板式空气预热器plate air preheater113.空气预热器air preheater114.三分仓空气预热器trisector regenerative air preheater115.漏风系数air leakage coefficient116.漏风率 air leakage ratio117.漏风系统air leakage system118.漏风试验air leakage test119.安全门safety valve120.安全门开启压力opening pressure of safety valve121.安全门回座压力safety valve reseating pressure122.安全门压力整定试验pressure setting test of safety valve123.安全门动作压力safety valve operating pressure124.饱和蒸汽安全门saturated steam safety valve125. 过热蒸汽安全门superheated steam safety valve126.再热蒸汽安全门reheated steam safety valve127.防暴门 explosion vent128.检查孔inspection hole129.事故喷水阀 emergency water spray valve130.汽包事故放水阀 emergency drum drain valve131.三通阀three-way valve132.反冲洗阀back wash valve133.取样阀sampling valve134.插板gate135.给水大旁路门feedwater overall bypass valve136.给水小旁路门feedwater individual bypass valve137.大板梁plate girder, upper beam138.外护板outer casing139.锅炉排污blowdown140.定期排污扩容器intermittent blowdown flash tank141.连续排污扩容器continuous blowdown flash tank142.灰斗 ash hopper143.冷灰斗bottom ash hopper, furnace hopper144.混合器mixer145.齿圈（大牙轮）ring gear, geared ring146.空调器 air conditioner147.空气压缩机air compressor148.给煤机coal feeder149.皮带式给煤机belt coal feeder150.刮板式给煤机scraper coal feeder151.叶轮式给煤机paddle coal feeder152.给粉机pulverizer coal feeder153.磨煤机coal pulverizer, coal mill154.钢球磨煤机tube mill155.中速辊式磨煤机roller mill, bowl mill, disk roll mill156.双进双出钢求磨煤机double inlet and outlet tube mill 157.中速磨煤机medium speed mill158.风扇磨煤机beater wheel mill, beater mill159.排粉风机pulverized coal exhauster160.一次风机primary air fan161. 烟气再循环风机gas recirculation fan162.送风机forced draft fan, force fan163.引风机induced draft fan, induced fan164.离心风机centrifugal fan165.轴流风机axial-flow fan166.双速风机double speed fan167.轴流静叶可调风机adjustable static-blade axial-flow fan fixed pitch axial-flow fan168.轴流动叶可调风机adjustable moving-blade axial-flow fan variable pitch axial-flow fan169.原煤斗raw coal bunker, raw coal silo170.煤粉仓pulverized coal bunker171.输粉机pulverized coal conveyer172.刮板输粉机scraper pulverized coal conveyer173.螺旋输粉机pulverized coal screw conveyer174.粗粉分离器classifier175.细粉分离器（旋风分离器）cyclone separator176.锁气器 air lock, flap177.减速机speed reduce178.看火孔observation hole179.人孔门man hole180.重油泵heavy oil pump181.重油加热器heavy oil heater182.汽-汽热交换器biflux183.煤气罐gas tank184.膨胀补偿节 expansion joint185.直吹式制粉系统direct firing pulverizing system 186.中贮式制粉系统bin storage type pulverizing system 187.锅炉效率boiler efficiency188.锅炉热力计算boiler thermodynamic calculation 189.锅炉空气动力计算boiler aerodynamic calculation 190.锅炉水循环计算boiler water circulation calculation 191.锅炉水力计算boiler hydrodynamic calculation 192.锅炉强度计算boiler strength calculation193.锅炉热平衡boiler heat balance calculation194.正平衡法direct balance method195.反平衡法indirect balance method196.过剩空气系数 excess air coefficient197.排烟温度flue gas temperature198.单位蒸量specific evaporation199.低温腐蚀low temperature corrosion200.高温腐蚀high temperature corrosion201.结渣lagging202.结垢腐蚀deposit corrosion203.飞灰磨损fly ash erosion204炉膛负压furnace draft205.最高允许温度maximum permissible temperature 206.炉膛正压furnace pressure207.水循环 water circulation208.循环倍率circulation ratio209.除尘器dust collector, precipitator210.静电除尘器 electrostatic precipitator211.整流装置rectifying device212.锤打装置rapping gear213.含尘浓度dust loading concentration214.煤灰细度dust fineness215.除尘效率dust collection efficiency216.干式除尘器dry dust collector217.湿式除尘器 wet dust collector, scrubber218.文丘里除尘器venture scrubber219.布袋除尘器fabric filter, bag house220.钢珠除尘装置shot-cleaning device221.水膜式除尘器centrifugal scrubber222.灰渣泵 ash pump, slag pump223.轴封泵shaft sealing pump224.灰浆泵 ash slurry pump225.除尘水泵dedusting pump226.回收水池 water recovery pond227.清水池clean water pond228.灰浆池 ash slurry pond229.油泵坑oil pump pit230.灰库 ash silo231.灰场 ash yard232.灰坝 ash yard dam233.耐火砖firebrick234.保温材料heat-insulating material235.干式除灰（气力除灰）pneumatic pressure ash handling 236.水力除灰hydraulic ash handling237.正压气力除灰pneumatic pressure ash handling238.负压气力除灰pneumatic pressure ash handling239.仓式泵fluidizing transporter240.空气斜槽airslide, air gravity conveyor241.灰渣分除bottom and fly ash separate handling242.灰渣混除bottom and fly ash mixed handling243.灰渣利用bottom and fly ash recovery244.排渣槽bottom ash hopper245.埋刮板捞渣机subm erged slag conveyor246.螺旋式捞渣机screw slag conveyor247.碎渣机clinker grinder, slag crusher248.振动筛vibrating screen249.稳燃器flame stabiliaer250.燃烧器蜗壳burner spiral case251.雾化器 atomization252.机械雾化mechanical atomization253.蒸汽雾化steam atomization254.空气雾化air atomization255.气固两相流动gas-solid two-phase flow256.闭路循环closed cycle257.蒸汽带水carryoery258.炉膛灭火boiler flame failure, boiler flame blackout 259.稳定燃烧stable combustion260.压力容器pressure vessel261.支吊架supports and hangers262.原煤管道raw coal piping263.风道 air duct264.热风道hot air duct265.冷风道cold air duct266.穿墙套管 wall-through bushing, wall-bushing267.伸缩节 expansion joint268.送粉管道pulverized coal feed piping269.燃油管道fuel oil piping270.风管道 air piping271.一次风管道primary air piping272.二次风管道secondary air piping273.落粉管pulverized coal chute274.除灰管道ash piping275.烟道gas dust, gas pass276.尾部烟道convection flue gas pass277.煤气管gas piping278.连续排污管continuous blowdown piping279.烟囱chimney, stack280.多管式烟囱multi-flue chimney281.燃烧combustion282.四角喷射燃烧corner firing283.燃烧速度combustion rate284.机械未完全燃烧热损失heat loss due to mechanical incomplete combustion 285化学未完全燃烧热损失heat loss due to chemical incomplete combustion 286.灰渣热损失heat loss due to sensible heat in refuse287.排烟热损失heat loss due to flue gas288.散热损失heat loss due to radiation289.热损失heat loss290.火焰flame291.不稳定燃烧instable combustion292.负压燃烧balance draft combustion293.微负压燃烧pressurized combustion294.炉膛容积热负荷furnace volume heat release rate295.炉膛温度furnace temperature296.锅炉水循环boiler water circulation297.偏离泡核沸腾departure from nucleate boiling(DNB)298.水压试验hydraulic test299.汽水共沸priming300.点火ignition301.点火准备ignition preparation302.着火点firing point, ignition temperature303.折焰角nose304.飞灰fly ash305.煤粉细度fineness of pulverized coal306.灰 ash307.灰的熔化点ash fushion temperature, ash fushion point, ash melting point 308.可磨系数grindability index309.最大蒸发量maximum evaporation310.锅炉热平衡boiler heat balance311.超负荷运行 overload operation312.正压positive pressure313.负压negative pressure314.理论空气量theoretical air quantity315.过剩空气量 excess air quantity316.冷风cold air317.热风hot air318.除渣slag removal319.烟气flue gas320.锅炉上水boiler water filling321.蠕胀爆管tube burst due to creep322.汽包满水 overfeed of water into drum323.锅炉灭火boiler fire extinction324.爆燃puff325.爆炸（外爆） explosion326.内爆implosion327.防爆 anti-explosion328.煤粉自燃pulverized coal self-ignition, pulverized coalspontaneous combustion329.堵灰 ash fouling330.堵煤coal jamming, coal plugging331.燃烧切圆firing tangential circle332.火焰中心flame center333.积粉pulverized coal deposits334.粉灰 ash deposits335.飞灰可燃物combustibles in fly ash336.点火用油fuel oil for ignition337.飞灰腐蚀fly ash corrosion338.受热面heating surface339.辐射受热面radiation heating surface340.对流受热面convection heating surface341.尾部受热面rear heat recovery surface342.含氧量 oxygen content343.蒸发量 evaporation, evaporative capacity344.切换风 air switch-over345.煤耗率coal consumption rate346.入炉煤发热量heating value of the as fired coal347.停炉boiler shutdown348.熄火fire-off349.灰水回收recovery of ash slurry water350.细灰fine ash351.粗灰coarse ash352.干灰dry ash353.湿灰 wet ash354.燃烧系数combustion system, firing system355.制粉系统coal pulverizing system356.除灰系统ash handling system二、汽轮机357.汽轮机steam turbine358.凝汽式汽轮机condensing steam turbine359.背压式汽轮机back pressure turbine360.抽汽式汽轮机steam extraction turbine361.中间再热式汽轮机reheating type steam turbine362.供热式汽轮机steam supply turbine, heat supply turbine, cogeneration turbine 363.冲动式汽轮机impulse turbine364.反动式汽轮机reaction turbine365.轴流式汽轮机axial flow turbine366.辐流式汽轮机radial flow turbine367.单轴汽轮机tandem compound turbine, single-shaft turbine368.双轴汽轮机double-shaft turbine, cross compound turbine369.前置式汽轮机topping turbine370.燃气轮机gas turbine371.高压汽轮机high pressure turbine372.中压汽轮机medium pressure turbine373.低压汽轮机low pressure turbine374.超高压汽轮机ultra pressure turbine375.亚临界压力汽轮机subcritical pressure turbine376.超临界压力汽轮机supercritical pressure turbine377.空冷式汽轮机组air cooled turbine unit378.燃气轮机组（装置）gas turbine unit379.高压汽缸high-pressure(HP) cylinder380.中压汽缸intermediate-pressure(IP) cylinder381.低压汽缸low-pressure(LP) cylinder382.内汽缸inner casing383.外汽缸outer casing384.上汽缸upper casing385.下汽缸lower casing386.汽缸法兰螺栓加热装置cylinder flange heating appliance387.汽缸台板（底板）cylinder sole pin388.汽缸猫爪cylinder claw389.滑销sliding pin390.横销traverse pin391.纵销longitudinal pin392.立销vertical pin393.定位销 aligning pin, locating pin394.汽轮机转子turbine rotor395.叶轮blade disc396.叶片blade, bucket397.动叶片moving blade398.静叶片stationary blade399.叶根型式type of blade root400.末级叶片长度length of last stage blade401.喷嘴室nozzle box402.末级叶片强度last stage blade stress403.排汽室steam exhaust hood404.喷嘴nozzle405.围带shroud ring406.拉筋（拉金）lacing wire407.平衡块balance weight408.固定螺钉dowel409.隔板diaphragm410.隔板套diaphragm sleeve411.隔板汽封diaphragm seal, diaphragm sealing412.汽封steam seal gland, steam sealing413.迷宫式汽封labyrinth seal414.梳齿式汽封serrate-type steam seal415.汽封套seal bushing416.汽封块seal block417.汽封齿seal tooth418.轴承支架bearing stoll, bearing bracket419.主轴承箱main bearing box420.滚珠轴承ball bearing421.滚柱轴承roller bearing422.滑动轴承sliding bearing423.推力轴承thrust bearing424.止推环thrust collar425.瓦枕bearing pillow426.锁饼lock427.推力瓦块thrust bearing pad428.主油泵main oil pump429.备用油泵 emergency bearing oil pump430.调速油泵regulation oil pump, speed governing oil pump 431.交流润滑油泵AC lube oil pump432.直流润滑油泵DC lube oil pump433.注油器oil injector434.同步器synchronizer435.同步器手轮synchronizer hand wheel436.控制滑阀pilot valve437.随动滑阀servo-valve438.分配滑阀distributing pilot valve, distributor valve439.中间滑阀intermediate valve440.微分器differentiator441.功率限制器load limiter442.动态校正器dynamic corrector443.滑阀套valve sleeve444.喷油嘴oil nozzle445.弹性调速器flexible governor446.调速器挡块governor stop447.危急遮断器滑阀 emergency trip pilot valve448.撞击子ram449.防火滑阀fire protection pilot valve450.延滞滑阀delay pilot valve451.跟踪滑阀follow-up pilot valve452.电-液转换器electro-hydraulic converter, electro-hydraulic transducer453.切换滑阀change-over pilot valve454.危急保安器 emergency governor455.危急保安器滑阀 emergency governor pilot valve456.超速试验滑阀overspeed test pilot valve457.喷油试验滑阀nozzle test pilot valve458.反馈滑阀feedback pilot valve459.起动排油阀oil drain valve at star-up460.紧急放油阀 emergency oil relieve valve461.排油口oil diacharge outlet462.节流滑阀throttle pilot valve463.滑动油阀movable pilot valve464.高压自动关闭器high-pressure automatic closing gear465.中压自动关闭器medium pressure autom atic closing gear466.高压油动机（高压伺服马达）high-pressure hydraulic actuator, high-pressure servo-motor 467.中压油动机medium-pressure hydraulic actuator, medium-pressure servo-motor468.杠杆lever469.轴shaft470.主轴main shaft471.传动轴(主动轴) driven shaft472.被动轴（从动轴）driven shaft473.小轴 axle474.联轴器coupling475.刚性联轴器rigid coupling476.半挠性联轴器semi-flexible coupling477.齿型联轴器serrated coupling478.冷油器oil cooler479.溢油器oil overflow valve480.排油烟机oil-fume extractor, oil fume exhaust 481.油烟分离器oil-fume separator482.油净化器oil purifier, oil conditioner483.过滤罐filtering tank484.布袋式过滤器bag filter, fabric filter485.齿轮油泵gear oil pump486.顶轴油泵jacking oil pump487.柱塞式油泵piston type oil pump488.螺杆式油泵 worm type oil pump489.盘车装置turning gear490.盘车手轮turning gear hand wheel491.化桩板lagging enclosure492.齿轮gear493.直齿式齿轮spur gear494.斜齿式齿轮helical gear495.伞型齿轮bevel gear496.蜗轮 worm wheel497.蜗杆 worm stem498.弹簧spring499.密封油箱sealing oil tank500.空气侧交流密封油泵air side AC sealing oil pump 501.空气侧支流密封油泵air side DC sealing oil pump 502.压差阀differential pressure valve503.平衡阀balancing valve504.密封瓦sealing pad505.缓冲油箱buffer oil tank506.高位油箱head oil tank, elevated oil tank507.事故油箱 emergency oil tank508.磁性过滤器magnetic filter509.发电机内冷水箱generator inner cooling water tank 510.发电机内冷水泵generator inner cooling water pump 511.离子交换器ion exchanger512.干燥器dryer, drier513.冷凝式干燥器condensing type drier514.凝汽器condenser515.多压式凝汽器multi-pressure condenser516.单流程凝汽器single-pass condenser517.双流程凝汽器double-pass condenser518.黄铜管brass tube519.管板tube plate520.凝汽器喉部condenser throat521.热水井hot well522.凝结水泵condensate pump523.泵壳pump casing524.盘根gland packing525.盘根压盖gland top cover526.盘根端盖gland end cover527.填料packing528.轴封抽汽风机shaft seal extraction fan529.轴封抽汽冷却器shaft seal extraction cooler, gland cooler530.轴封漏汽加热器shaft seal leakage heater531.低压加热器low-pressure feed water heater532.中压加热器media-pressure feed water heater533.高压加热器high-pressure feed water heater534.蒸汽冷却器steam cooler535.疏水冷却器drain water cooler536.汽侧steam side537.水侧 water side538.U型管U-tube539.除氧器deaerator540.储水池 water storage pond541.卧式除氧器horizontal type deaerator542.立式除氧器vertical type deaerator543.喷雾式除氧器atomizing type deaerator544.淋水盘 water spraying tray, sprinkling tray545.除氧水箱deaerated water tank546.稳压水箱surge water tank, stabilizing water tank547.除盐水箱demineralized water tank548.除盐水泵demineralized water pump549.汽动给水泵steam-driven feed water pump550.电动调速给水泵motor-driven variable speed feed water pump551.前置水泵booster pump552.给水泵feed water pump553.机械密封mechanical seal554.碳精密封环carbon seal ring, carbon packing ring555.动环moving ring556.静环static ring557.平衡盘balancing disc558.液力偶合器hydraulic coupler559.泵轮（主动轮）pump impeller, driving impeller560.涡轮（从动轮） whirling impeller, driven impeller561.勺管scoop tube562.辅助油泵auxiliary oil pump563.疏水泵drain pump564.疏水扩容器drain flash tank565.疏水箱drain tank566.热网加热器heater for heating network, heating network hot water heater567.生水加热器raw water heater568.热网水泵pump for heating network, heating network hot water pump 569.生水泵raw water pump570.除尘水泵pump for scrubber, scrubber water pump571.壳体case, shell572.水室 water chamber573.封头 end cover574.挡板baffle plate575.导流板guide plate576.射水泵 water jet pump577.真空泵vaccum pump578.射水抽气器 water jet air ejector579.射汽抽气器steam jet air ejector580.射水池 water jet pond581.排水池drain water pond582.工业水泵industrial water pump, service water pump583.排污泵blowdown pump584.轴流泵 axial flow pump585.清水泵clean water pump586.污水泵sewage pump587.排水泵 water discharge pump588.立式深井泵vertical deep-well pump589.深井泵deep-well pump590.潜水泵subm erged pump591.循环水泵circulating water pump592.清污机trash remover593.混流泵mixed flow pump594.离心泵centrifugal pump595.旋转滤网rotating type screen, screw type strainer596.胶球泵rubber ball recirculating pump597.收球网ball screen598.装球网ball collector599.管式冷却器tubular cooler, tube type cooler599/1.支撑斜钢supporting wedge600.板式冷却器plate type cooler601.冷却水池cooling water pond602.喷水池spraying water pond603.冷却水塔cooling tower604.自然通风冷却塔natural draft cooling tower605.逆流式冷却塔reverse flow cooling tower606.横流式塔transverse flow cooling tower607.机力通风冷却塔mechanical draft cooling tower608.空气冷却塔air cooling tower609.干式冷却塔dry cooling tower610.分水槽 water diversion channel611.竖井shaft, well612.闸板井gate well613.闸门室gate chamber, gate house614.挡风板 air baffle plate615.新（主）蒸汽管道main steam piping, live steam piping 616.主蒸汽系统main steam system617.再热蒸汽系统reheat steam syetem618.抽汽系统 extraction steam system619.轴封供汽系统shaft seal steam supply system620.轴封shaft seal621.门杆漏汽系统valve lever leakage steam system622.汽缸法兰螺栓加热系统casing flange and bolt heating system 623.真空系统vaccum system624.凝结水系统condensate system625.再热蒸汽管道reheat steam system626.给水系统feed water system627.循环水系统circulating water system628.工业水系统industrial water system, service water system 629.供油系统oil supply system630.密封油系统seal oil system631.厂用蒸汽系统auxiliary steam system632.调速系统speed governing system633.电液调速系统 electro-hydraulic speed governing system 634.发电机内冷水系统generator inner cooling water system 635.热网系统heating network system636.导汽管steam lead pipe637.连通管inter-connecting pipe638.抽汽管道steam extraction pipe639.抽汽母管steam extraction header640.厂用蒸汽管道plant service steam piping641.厂用蒸汽母管plant service steam header642.蒸汽旁路系统steam bypass system643.蒸汽大旁路single stage steam bypass644.一级蒸汽旁路first stage steam bypass645.二级蒸汽旁路second stage steam bypass646.辅助蒸汽母管auxiliary steam header647.供汽联箱steam header648.回汽联箱return steam header649.供水联箱 water supply header650.回水联箱return water header651.门杆漏汽管道valve lever steam leakage piping652.轴封漏汽管道shaft seal leakage steam piping653.抽空气管道air extraction piping654.压缩空气管道compressed air piping655.氢气管道hydrogen piping656.疏水管道drain water piping657.凝结水管道condensate piping658.循环水管道circulating water piping659.工业水管道industrial water piping, service water piping 660.冷却水管道cooling water piping661.给水管道feed water piping662.除盐水管道demineralized water piping663.减温水管道attemperating water piping664.再循环水管道recirculating water piping665.排水管道 water discharge piping666.润滑油供油管道lube oil supply piping667.润滑油管lube oil piping668.调速油管governing oil piping669.回油管道return oil piping670.压力油管道pressure oil piping671.密封油管道seal oil piping672.脉动油管pulsating oil piping673.热网水管道heating network water piping674.平衡管balance pipe675.电动主闸门motor-operated main gate valve676.高压主汽门high-pressure main stop valve677.中压主汽门intermediate pressure main stop valve 678.旁路门bypass valve679.防腐汽门corrosion-proof valve680.高压调速汽门high-pressure governor valve681.中压调速汽门medium pressure governor valve682.对空排汽门atmospheric relief valve683.疏水门drain valve684.调整门 adjusting valve685.电动门motor-operated valve686.手动门hand-operated valve687.减温器 attemperator, desuperheater688.减压器（阀）pressure reducer(valve)689.减温减压器temperature and pressure reducer690.抽汽电动门motor-operated steam extraction valve 691.抽汽逆止门 extraction check valve692.高压排汽逆止门high-pressure exhaust check valve 693.逆止门check valve, non-return valve694.入口门inlet valve695.出口门outlet valve696.球型阀globe valve697.闸板阀gate valve698.针型阀needle valve699.翻板阀tripper valve700.液压阀hydraulic valve701.控制阀control valve702.换向阀reverse flow valve703.疏水阀drain valve704.蝶阀butterfly valve705.衬胶门rubber lined valve706.高压加热器入口联成阀composite valve at high pressure heater inlet 707.高压加热器出口联成阀composite valve at high pressure heater outlet 708.高压加热器旁路门high pressure heater bypass valve709.水封阀门 water seal valve710.排污门blow down valve711.排气门 exhaust steam valve712.排汽门 exhaust steam valve713.补水门 water supply valve, make-up water valve714.补油门oil valve, oil supply valve715.补氢门hydrogen supply valve716.空气门 air valve717.真空破坏阀vacuum breaking valve, vacuum breaker718.排汽安全门 exhaust steam safety valve719.弹簧安全门spring relief valve720.排汽缸喷水门 exhaust cylinder water-spraying valve721.电磁阀solenoid valve, magnet valve722.前截门front intercept valve723.后截门rear intercept valve724.排氢门hydrogen vent valve725.中间抽头门intermediate stage bleed-off valve726.最小流量阀minimum flow valve727.暖泵门pump warming valve728.泵体放水门pump-body water drain valve729.放水门 water discharge valve730.减温水门attemperating water valve731.切换门change-over valve, diverting valve732.联络门interconnection valve733.液压逆止门hydraulic check valve734.再沸腾加热门reboiled heating valve735.放空气门air vent valve736.再循环门recirculation valve737.冷却水门cooling water valve738.热效率thermal efficiency, heat efficiency739.内效率internal efficiency740.额定工况rated operation condition741.最大工况maximum operation condition742.汽耗量steam consumption743.汽耗率steam consumption rate744.热耗率specific heat consumption, heat rate745.新蒸汽压力initial steam pressure, live steam pressure746.再热蒸汽冷段压力cold reheated steam pressure747.再热蒸汽热段压力hot reheated steam pressure748.再热蒸汽热段温度hot reheated steam temperature749.再热蒸汽冷段温度cold reheated steam temperature750.主蒸汽流量steam flow751.再热蒸汽流量reheated steam flow752.低压缸排汽流量low-pressure cylinder exhaust steam flow753.转速rotating speed, revolution754.真空度vaccum755.旋转方向rotation direction756.给水温度feedwater temperature757.调节级压力pressure at velocity stage758.临界转速critical speed759.吊装重量lifting weight760.速度变化率speed variation rate761.迟缓率delay rate762.凸轮转角cam torque angle763.过热度superheat degree764.温差temperature difference765.端差terminal temperature difference766.过冷度supercooling degree767.高压加热器投入率high pressure heater availability rate768.轴向位移axial shift, axial displacement769.大轴晃动值shaft swinging value, shaft eccentricity770. 高压缸膨胀high-pressure cylinder expansion771.中压缸膨胀intermediate pressure cylinder expansion772.低压缸膨胀low pressure cylinder expansion773.市政速油压governing oil pressure774.润滑油压lubricating oil pressure775.脉动油压impulse oil pressure776.附加保安油压additional safeguard oil pressure777.滑阀上油压oil pressure above pilot valve778.滑阀下油压oil pressure under pilot valve779.润滑油温lubricating oil temperature780.轴承加油温度bearing return oil temperature781.轴承钨金温度babbit metal temperature, bearing metal temperature 782.推力瓦块温度thrust pad temperature783.密封油压seal oil pressure784.油位oil level785.水中含氧量 oxygen content of water786.凝结水硬度condensate hardness787.轴承振动值shaft(bearing) vibration amplitude788.垂直振动值vertical vibration amplitude789.水平振动值horizontal vibration amplitude790.轴向振动值axial vibration amplitude791.油膜振荡oil film oscillation, oil whipping792.冲转impulse starting793.冷态启动cold start794.热态启动hot start795.滑参数启动starting at sliding parameters, sliding pressure starting 796.滑参数停机shut-down at sliding parameters, sliding pressure shut-down 797.升速speed up798.升速率percentage of maximum momentary speed variation,speed-up rate799.负荷上升率loading rate800.基本负荷base load801.调峰运行peak load regulating operation, cyclic operation802.空转idling, idle running803.手动打闸停机hand trip, turbine hand trip804.暖机turbine warming up805.最短盘车时间minimum turning time806.低速暖机low speed warming807.中速暖机medium speed warming808.滑参数起动曲线starting curve at sliding parameters,sliding pressure starting-up curve809.滑参数停机曲线shut-down curve at sliding parameters,sliding pressure shut-down curve810.全周进汽full admission811.部分进汽partial admission, partial-arc admission812.喷嘴调节nozzle governing813.节流调节throttle governing814.破坏真空vaccum breaking815.汽缸金属温度cylinder metal temperature816.听音检查sound detection817.惰走时间idling time818.超速试验 overspeed test819.真空严密性试验vaccum leakage test820.主汽门严密性试验main steam stop valve leakage test821.危急遮断器充油试验 emergency governor oil filling test822.低油压保护试验low oil pressure protection test823.调速系统静止试验governing system pre-operation test824.调速系统动态特性试验governing system dynamic performance test 825.调速系统静态特性试验governing system static performance test826.甩负荷试验load-dump test, load-rejection test827.空负荷试验no-load test828.满负荷试验full-load test829.超负荷试验 overload test830.转子平衡试验rotor balancing test 831.动平衡dynamic balancing832.静平衡static balancing833.热力试验thermodynamic test834.叶片频率试验blade frequency test 835.投入运行to be put into operation 836.开启opening837.关闭closing838.启动starting-up839.停止shutting down840.充氢hydrogen charging841.排氢hydrogen discharging842.补水 water make-up843.补油oil make-up844.水位调整 water level regulation 845.暖管 warming846.手摇同步器hand synchronizer847.检查inspection, examination848.巡检routing inspection849.蒸汽带水carry-over850.水击hydraulic shock, water hammer 851.超速 overspeed852.轴承损坏（烧瓦）bearing burnt-out 853.断叶片broken blade854.断轴broken shaft855.气蚀cavitation856.反转（倒转）reversal rotation857.调节级regulation stage858.压力级pressure stage859.抽真空vaccum extraction860.盘车turning861.法兰加热flange heating862.螺栓加热bolt heating863.漏汽steam leakage864.漏水 water leakage865.炭精轴封carbon packing866.冒烟sm oking, smoke belching 867.着火fire catching, fire868.强烈振动strong vibration869.管道破裂piping breaking870.无蒸汽运行no-steam operation。

A List of Abbreviations and Symbols inEnglish-ChineseA Ash Handling System 除灰系统AH Air Heater 空气预热器AAh Analyzer, Alarm High 分析器，高值报警AIV Air Intake V alve 进气阀ALIGN Alignment 校正ALKF Airlock Feeder 锁气器AP Ash Slurry Pump 灰浆泵A TM Atmosphere 大气AC Air Conditioner 空气调节器AFT Atmosphere Flash Tank 大气扩容器AC Alternating Current 交流电ALM Alarm 报警AMP Ampere 安培AX THR BRG Axis Thrust Bearing 轴向推力，轴承A TMZ Atomizing 雾化AUTO Automation 自动AUX Auxiliary 辅助的BA Bottom Ash 底灰BAH Bottom Ash Hopper 底灰斗BLR Boiler 锅炉BSD Boiler Shut Down 停炉BUSH Bushing 衬套BYPS Bypass 旁路BCP Boiler Circulating Pump 锅炉循环泵BVD Boiler V ents and Drains 锅炉疏水放气BFP Boiler Feed-water Pump 锅炉给水泵BFPTBoiler Feed-water Pump Turbine锅炉给水泵汽机BFW Boiler Feed-water 锅炉给水BM Boiler Master 锅炉主控BMCR Boiler Maximum Continuous Rating 锅炉最大连续出力BFBP Boiler Feed Booster Pump 锅炉给水增压泵BNR Burner 燃烧器BOP Balance Of Plant 电厂辅机设备BPC Blade Pitch Control 叶片带距控制BT Boiler Tube 炉管CH Crusher House 碎煤房COMB Combustion 燃烧COMP Compressed Air 压缩空气CONV Conveyer 输送机CPL Control Panel Local 就地控制盘CPM Control Panel Main 主控盘CRT Cathode Ray Tube 屏幕显示CT Current Transformer 变流器CYCL Cyclone 旋风分离器CAS Casing 缸CB Cut Breaker 开关COMP Complete 完成CCCW Closed Circulating Cooling Water 闭式循环冷却水CCW Closed Cooling Water 闭式冷却水CCWHF Closed Cooling Water Heater 闭式冷却水冷却器CCWP Closed Cooling Water-pump 闭式冷却水泵CS Closed Cooling Water System 闭式冷却水系统CH Coal Handling 煤的装卸CHK VLV Check V alve 逆止阀CIRC Circulation 循环CLR Cooler 冷却器CLSD Closed 闭式CLOW Cooling Water 冷却水CMPR Compressor 压缩机CNDNR Conditioner 调节器CNTL Control 控制CNTLE Controller 控制器COND Condensate 凝结水CONDTY Conductivity 导电率CP Condensate Pump 凝结泵CIR Circuit 回路COUPI Coupling 藕合，连接CP Condensate Polisher 除盐装置CS Control Switch 控制开关CRSV Cold Reheat Safety V alve 再热器冷段安全阀CV Control V alve 控制阀CWP Circulation Water Pump 循环水泵DMPR Damper 挡板DP Difference Pressure 差压DPIC Differential Pressure Indicating Controller 压差指示控制器DPT Differential Pressure Transmitter 压差变速器DRN Drain 疏水DV Drain V alve 疏水阀DC Direct Current 直流电DSH De-super-heater 减温器DCA Drain Cooler Approach 疏水冷却器通道DEAER De-aerator 除氧器DEV Deviation 偏差DIFFRLY Differential Relay 差动继电器DISCH VLV Discharge V alve 排放阀DIST Disturbance 故障DSCH Discharge 排出ECON Economizer 省煤器EP Electrical Static Precipitator 电除尘ECC Eccentric 偏心EFF Efficiency 效率EHC Electric Hydraulic Control 电液控制EO Electric Operate 电气操作EQ Equipment 设备ER Error 误差ES Extraction System 抽气ESC Escape 逃逸ESS Engineering Safety System 保安系统EU Engineering Unit 工程单位EXH Exhaust 排汽EXT Extract 抽出F Fly Ash System 飞灰系统FA Fine Ash 细灰FDR Feeder 给料机FE Flow Element 流量元件FI Flow Indicator 流量指示件FDBK Feedback 反馈FITG Fitting 连接件FLW Flow 流量FO Fail Open 故障时自动开关FT Flow Totalize 流量累加器FT Flow transmitter 流量变送器FV Flow Control V alve 流量控制阀FY Flow Relay or V alve 流量传送器FA Failure Alarm 故障报警FD Forced Draft 强制通风FDF Forced Draft Fan 送风机FDR Feeder 给煤机FIC Flow Indicate Controller 流量指示控制器FLT Flash Tank 扩容箱FLD Field 磁场FLG Flange 法兰FLM Flame 火焰FWH Feed Water Heater 给水加热器FO Fuel Oil 燃油FREQ Frequency 频率FURN Furnace 炉膛FV Flow Control V alve 流量控制阀GLD Gland 密封GRDR Grinder 碎渣机GND Ground 接地GC Generator Cooling 发电机冷却GEN Generator 发电机GESE Gland Steam Condenser Exhauster 轴封抽汽机GMT Generator Main Transformer 发电机变压器GRAD Grandient 梯度GS Gland Steam 轴封蒸汽GSC Gland Steam Condenser 轴封加热器GV Governor V alve 压调门H Heat Conservation 保温HO Heavy Oil 重油HP High Pressure Horse Power 高压马力HS Hand Switch 手动开关HTR Heater 加热器HV Hand Control V alve 手动控制器HY Hand Relay or Transducer 手动继电器（转换器）H Hand 手动的HB Heat Balance 热平衡HD Heater Drain 加热器疏水HD der 联箱HL Heat Loss 热损失HMDY Humidity 湿度HPH High Pressure Heater 压加热器HPR Hooper 漏斗HPT High Pressure Turbine 高压缸HR Hot Reheat 再热器，热段HR Heat Rate 热耗率HSV Hot Reheat Safety V alve 再热器热段安全阀HT Heat 加热HTG Heating 加热HTR Heater 加热器HV AC Heating V entilation & Air Conditioner 加热通风与空气调节HW Hot-well 热井HV Hand Control V alve 手动控制器HYD Hydraulic 液力的INTLK Interlock 联锁IC Instrument and Control 仪表与控制（热工）ICV Intermediate Control V alve 中压控制阀ID Induced Draft 抽风，引风IDF Induced Draft Fan 引风机IGN Ignition 点火装置INLT Inlet 入口IPR Initial Pressure 初压INST Instrument 仪表INVR Inverter 倒相器，转换开关I /O Input/Output 输入/输出IP Intermediate Pressure 中压IPT Intermediate Pressure Turbine 中压缸ISV Intermediate Pressure Turbine Steam V alve中压缸，进汽阀JP Jet Pump 喷射器LG Level Gauge 料位计LUB Lubricate 润滑油LVL Level 水位，液位LA Level Alarm 液体报警LIM(LMIR) Limiter 限制器LKG Leakage 泄漏LP Low Pressure 低压L.P Low Point 低位LPH Low Pressure Heater 低压加热器LS Live Steam 主蒸汽LSH Local Switch Hand 就地开关LUB OIL Lube Oil 润滑油M Mechanical 机械Motor 马达MAG Magnetic 磁性MOD Mode 方式M/A Manual/Automatic 手动/自动MAN Manual 手动MARG Margin 极限MAX Maximum 最大的，最大值的MCR Maximum Continuous Rating最大连续出力MCV Main Control V alve 主控制阀MD Modulation Damper 调节挡板MDBFP Motor Driven Boiler Feed-water Pump 电动给水泵MEAS Measure 测量MFT Master Fuel Trip 主燃料切断MIN Minimal 最小的MKUP (MU) Make-up 补充ML Mill 磨煤机MN Main 主要的M.O. Manual Operate 手操MPT Main Power Transformer 主变压器MS Main Steam 主蒸汽MSV Main Steam V alve 主汽阀NOZ Nozzle 喷嘴NPSH Net Pump Suction Heat 泵的静吸压头OL Overload 过载OLR Overload Relay 过载继电器OPER Operation 运行OSC Oscillograph 示波器OTLT Outlet 出口PA Primary Air 一次风PAF Primary Air Fan 一次风机PAH Pressure Alarm High 高压报警PAL Pressure Alarm低压报警PAS TDBFP A Status 汽动给水泵A 状态PB Push Button 按钮PBS TDBFP B Status 汽动给水泵B 状态PC Power Center 动力中心PC Pressure Controller 压力控制器P.C. Pressure Control 压力控制PCP Precipitator 除尘器PCV Pressure Control V alve 压力控制阀PDI Pressure Differential Indication 差压指示计PDT Pressure Differential Transmitter 差压变送器PED Pdestal 轴承座PERF CALC Performance Calculation 性能计算PF Power Factor 功率因数PHTR Pre-heater 预热器PMP Pump 泵PNEU Pneumatic 气动的PR Pressure Recorder 压力记录计PRG Purge 吹扫PRV Pressure Relief V alve 泄压阀PRO Protection 保护PROGR Program 程序PT Pressure Transmitter 压力变送器PULV pulverizer 磨煤机PVSV Pressure V acuum Safety V alve压力真空安全阀PW Plant Water 厂用水PY Pressure Relay 压力继电器QA Quality 质量，性能RB Run Back 快速降负荷RCV Recovering 回收RCV Reverse Current V alve 逆止阀RECIRC Re-circulation 再循环RECT Rectifier 整流器RED Reducer 减压器RET Return 返回RH Re-heater 再热器RO Restriction Orifice 节流孔板ROT Rotor 转子RTU Remote Telemetry Unit 遥测装置SA Secondary Air 二次风SA T Saturate 饱和的SC Steam Coil Air Heater 暖风器SCA V Scavenge 吹扫SCN Scanner 控制器SD Shut-off Damper 关断挡板Shut-Down 停止运行SEP Separator 分离器SG Switchgear 开关装置SH-DN Shut-Down 切除SH Super-heater 过热器SLS Seals 密封SO Shut Off 关闭SPD Speed 转速SPRA Spray 喷水SPT Support 支持，支架ST Start 启动，开始STD-BY Stand By 备用ST System 系统STM Steam 蒸汽STR Stator 定子STRNR Strainer 滤器SU Start Up 启动SV Solenoid V alve 电磁阀Shut Off V alve 关断阀SUCT Suction 吸入SW Switch 开关Steam Water 汽水SBLWR Soot Blower 吹灰器TBFP Turbine Drive Boiler Feed-water Pump 汽动给水泵TCV Temperature Control V alve 温度控制T.B. Transfer Damper 转换挡板TE Temperature Element 测量元件TG Turbine-generator 汽轮发电机Turbine-gear 汽机盘车THERM Thermal 热力的TMS Turbine Master System 汽机主控TRANS Transfer 转换TRBL Trouble 故障TRKG Tracking 跟踪TRX TURBOMAX 汽机最大热应力控制TT Temperature Transmitter 温度传感器TTD Terminal Temperature Difference 温度端差TURB Turbine 汽机TW Thermo-well 热电偶套管UAM Unit Automatic Master 机组自动系统V AC V acuum 真空V AL V alue 数值VB Vibration 振动VLV V alve 阀门WH Watt-hour 瓦小时WP Work Point 工作点WW Water Wall 水冷壁WX Watt Transducer 功率转换器COVER Crossover 切换管CV Control V alve 控制阀PS Position Switch 状态开关，位置开关PT Position Transmitter 状态变送器BOOSTER PUMP FREE SIDE BEARING TEMP前置泵自由端径向轴承温度BOOSTER PUMP DRIVEN SIDE BEARING TEMP前置泵驱动端径向轴承温度BOOSTER PUMP THRUST BEARING OUTSIDE TEMP前置泵推力轴承外侧温度BOOSTER PUMP THRUST BEARING INSIDE TEMP前置泵推力轴承内侧温度comment 注释，评论module 模块standby 备用proximity 相近，接近，亲近detector 探测器bracket 支架interlocks 互锁，连锁axial 轴向的surge conditions 喘振loss of speed 飞车accessory 附件pulsation 有节奏的跳动，跳动fossil fired 燃煤intent 意图，目的，意向intend 意指，想要，打算consistent 一致的，调和的practice 惯例，实习，实践intrinsic 固有的，内在的procurement 获得，获取fabrication 制作，构成，伪造物vent 通风孔，出烟孔，出口，放出，排出，发泄noncondensible gas 不凝结气体intermittent 间歇的，断断续续的blowdown 排污tank 桶，箱，罐diagram 图表deaerator 除氧器corrosion 侵蚀，腐蚀状态concentration 集中，集合，浓缩，浓度recommend 推荐，介绍，托付，劝告abnormal and normal conditions 变工况和额定工况warm up 暖机acid wash 酸洗scale 范围，水垢，水锈，比例，刻度sludge 污泥，淤泥foreign matter 不相关的物质facilitate 推动，促进，使简化multistage 多级的remote control 遥控safety relief valve 安全卸压阀gauge 量规，量表，测量manhole 人孔，检修孔equivalent 等价物，相等的forging 锻造seat 部位，座socket welding 管座焊接enthalpy 焓estimate 评价，评估，估价parameters 参数，参量correction factor修正系数nominal 名义上的，额定的，标称的MS—Main Steam 主蒸汽Cycle循环Intercept截止Fetting附件Gage规，表，压力计Form factor 形状系数Taps接头test wells测点插孔stress-relieved 应力消除thermometer温度计steam purge system蒸汽吹扫系统centrifugal type pumps离心式泵margin余量friction losses磨擦损失solenoid螺线管modulat调整，调节criteria标准wrenches扳手pipe taps管接头Assemble 集合，集结，组装Group 聚合，成群Vibration 振动audio 声频的，音频的integral 部分，完整，积分，完整的boiler house 锅炉房coal conveyor 输煤装置coal bunker 煤仓coal mill 磨煤机steam boiler water boiler tube蒸汽锅炉，管式锅炉furnace(combustion chamber) 炉膛(燃烧室) water tube 水管ash pit 灰坑super-heater 过热器water pre-heater 水预热器air pre-heater 空气预热器gas duct(flue) 烟气管,烟道dust collecting plant 集尘室electrical precipitation plant 电气除尘室induced draught fan 引风机chimney 烟囱de-aerator 除氧器feed water tank 供水箱boiler feed pump 给水泵switchgear 开关设备cable tunnel 电缆通道cable cellar 电缆槽turbine room 汽轮机室steam turbine with alternator蒸汽汽轮发电机组economizer 省煤器steam drum 汽包surface condenser 表面凝汽low-pressure pre-heater 低压预热器circulating water pipe(pump) 循环水管control room 控制室electrostatic dust remover(precipitator)静电除尘器pulverizer 磨煤机slag pump 灰渣泵thermal cycle 热力循环(net)heat rate （净）热耗率STEAM POWER STA TION 火力发电站锅炉boiler锅炉机组boiler unit固定式锅炉stationary boiler蒸汽锅炉steam boiler电站锅炉power station boiler工业锅炉industrial boiler生活锅炉domestic boiler热水锅炉hot water boiler船用锅炉marine boiler快装锅炉package boiler组装锅炉shop-assembled boiler散装锅炉field-assembled boiler常压热水锅炉atmospheric pressure hot water boiler低压锅炉low pressure boiler中压锅炉medium pressure boiler高压锅炉high pressure boiler超高压锅炉superhigh pressure boiler亚临界压力锅炉subcritical pressure boiler超临界压力锅炉supercritical pressure boiler 超超临界锅炉ultra supercritical boiler自然循环锅炉natural circulation boiler强制循环锅炉forced circulation boiler直流锅炉once-through boiler复合循环锅炉combined circulation boiler低循环倍率锅炉low circulation boiler火管锅炉fire tube boiler水管锅炉water tube boiler固体燃料锅炉solid-fuel fired boiler液体燃料锅炉liquid-fuel fired boiler气体燃料锅炉gas-fuel fired boiler余热锅炉exhaust heat boiler 余热锅炉（HRSG）电热锅炉electric boiler锅壳式锅炉shell boiler水火管锅壳式锅炉water-fire tube shell boiler 卧式内燃锅炉horizontal internal-combustion boiler角管式锅炉corner tube boiler立式锅炉vertical boiler小型锅炉low-capacity boiler铸铁锅炉cast-iron boiler固态排渣锅炉boiler with dry-ash furnace液态排渣锅炉boiler with slag-tap furnace火床燃烧锅炉grate firing boiler链条炉排锅炉traveling grate boiler抛煤机链条炉排锅炉spreader-stoker-fired boiler火室燃烧锅炉suspension firing boiler煤粉燃烧锅炉pulverized coal fired boiler水煤浆燃烧锅炉coal-water slurrty fired boiler流化床燃烧锅炉fluidized bed boiler循环流化床锅炉circulating fluidized bed boiler增压循环流化床锅炉pressurized fluidized bed boiler微正压锅炉pressure fired boiler增压锅炉supercharged boiler辐射式锅炉radiant boiler通用压力锅炉universal-pressure boiler汽水两用锅炉multifunctional boiler (steam and hot water)盘管式锅炉coil tube boiler真空相变热水锅炉vacuum phase-change hot water boiler有机热载体炉organic heat transfer material heater锅炉本体boiler proper受热面heating surface辐射受热面radiant heating surface对流受热面convection heating surface附加受热面auxiliary heating surface受压部件pressure part受压元件pressure part管屏tube panel垂直上升管屏up flow riser tube panel回带式管屏ribbon panel水平围绕管屏spirally-wound tube panel管束tube bank错列布置管束staggered bank顺列布置管束in-line bank对流烟道convection pass并联烟道parallel gas passes风道air duct炉膛（燃烧室）furnace水冷炉膛water cooled furnace绝热炉膛insulating furnace炉胆furnace波形炉胆corrugated furnace回燃室reversal chamber冷灰斗water-cooled hopper bottom卫燃带refractory belt折焰角furnace arch炉拱arch前拱front arch后拱rear arch燃烧器burner煤粉燃烧器powdered coal burner旋流式煤粉燃烧器cyclone type burner直流式煤粉燃烧器impellerless burner低氮氧化物燃烧器low nitrogen oxide burner 点火装置flame ignitor油燃烧器oil burner油雾化器oil atomizer机械雾化油燃烧器（压力雾化油燃烧器）mechanical atomizing burner气流雾化油燃烧器gas atomizing burner气体燃烧器gas burner调风器register炉排grate链条炉排traveling grate stoker 链带式炉排chain belt type grate stoker横梁式炉排crossgirder grate stoker鳞片式炉排flake type grate stoker往复炉排reciprocating grate倾斜式往复炉排inclined reciprocating grate 振动炉排vibrating stoker抛煤机spreader stoker锅筒drum上锅筒steam drum下锅筒water drum锅壳shell筒体cylindrical shell封头head凸形封头convex head椭圆形封头ellipsoidal head半球形封头hemispherical head平封头flat head管板tube plate孔桥（管孔带）ligament人孔manhole手孔handhole集箱（联箱）header端盖head锅筒内部装置drum internals清洗装置steam washer旋风分离器cyclone separator轴流式分离器turbo separator百叶窗分离器corrugated scrubber钢丝网分离器screen separator多孔板perforated distribution plate集汽管dry pipe排污管blowoff pipe下降管downcomer加药管chemical feed pipe蒸发受热面evaporating heating surface水冷壁water-cooled wall膜式水冷壁membrane wall双面水冷壁division wall防渣管（凝渣管）boiler slag screen锅炉管束boiler convection tube bank烟管（火管）fire tube螺纹烟管spirally corrugated tube内螺纹管ribbed tube旗式受热面flag pattern surface过热器superheater辐射式过热器radiant superheater墙式过热器wall superheater屏式过热器platen superheater对流式过热器convection superheater包墙管过热器steam-cooled wall顶棚管过热器（炉顶过热器）steam-cooled roof悬吊式过热器pendant superheater水平式过热器horizontal superheater再热器reheater辐射式再热器radiant reheater对流式再热器convection reheater减温器desuperheater、attemperator表面式减温器drum type surface attemperator 喷水减温器spray type attemperator烟气挡板（旁路档板）smoke damper烟气再循环装置gas recirculation equipment 汽——汽热交换器steam-steam heat exchanger省煤器economizer沸腾式省煤器steaming economizer非沸腾式省煤器nonsteaming economizer钢管式省煤器steel tube economizer鳍片管式省煤器finned tube economizer铸铁肋片管式省煤器cast-iron gilled tube economizer可分式省煤器（独立式省煤器）separated economizer悬吊管pendant tube空气预热器air heater钢管式空气预热器tubular air heater再生式回转空气预热器rotary regenerative air heater受热面转动型再生式空气预热器rotating-plate type regenerative air heater风罩转动型再生式空气预热器stationary-plate type regenerative air heater板式空气预热器plate type recuperative air heater铸铁肋片管式空气预热器cast-iron gilled tube air heater暖风机steam air heater锅炉构架boiler structure支承式锅炉构架bottom-supported structure 悬吊式锅炉构架top-supported structure by hangers框架式锅炉构架frame type boiler structure 桁架式锅炉构架trussed type boiler structure 刚性架buckstay锅炉炉墙boiler setting重型炉墙bottom supported heavy wall轻型炉墙sectional supporting water cooled wall敷管炉墙top supported water cooled wall炉墙护板boiler casing锅炉汽水系统boiler steam and water circuit 锅炉范围内管道boiler external piping安全阀safety valve静重式安全阀direct-loaded safety valve弹簧式安全阀spring-loaded safety valve杠杆式安全阀deadweight safety valve脉冲式安全阀pulsed safety valve电磁控制式安全阀electric relief valve水封式安全装置water-sealed safety equipment水位表water gauge玻璃水位计glass water gauge双色水位计double-colour water gauge高低水位报警器high-low water level alarm 低置水位计remote water level indicator防爆门explosion door排污阀blowdown valve疏水阀（疏水器）bleeder点火程序控制装置ignition control program 熄火保护装置flame failure protection额定蒸发量nominal capacity最大连续蒸发量maximum continuous rating 额定供热量rated heating capacity额定蒸汽参数nominal steam parameter额定蒸汽压力nominal steam pressure额定蒸汽温度nominal steam temperature额定热水温度nominal hot water temperature 给水温度feed watr temperature3.2.2.1.9回水温度return water temperature排污率rate of blowdown锅炉热力计算thermal calculation for boilers 锅炉水动力计算hydrodynamic calculation for boilers锅炉烟风阻力计算flue-gas and air resistance calulation for boilers锅炉受压元件强度计算strength calculation of pressure parts for boilers锅炉水循环boiler circulation循环回路circulation circuit蒸汽品质steam quality蒸汽污染steam contamination机械携带mechanical carry-over溶解携带vaporous carry-over蒸汽净化steam purification蒸汽湿度moisture in steam分段蒸发stage evaporation气温调节steam temperature control给水feed water补给水make-up water锅水boiler water给水品质feedwater condition锅水浓度boiler water concentration总硬度total hardness总碱度total alkalinity悬浮固形物suspended solid matter溶解固形物dissolved solid matter相对碱度relative alkalinity负压燃烧negative-pressure firing压力燃烧pressurized firing自然通风natural draft机械通风mechanical draft平衡通风balanced draft分段送风zone control draft燃料消耗量fuel consumption计算燃料消耗量calculated fuel consumption 理论空气量theoretical air过量空气系数excess air ratio理论燃烧温度theoretical combustion temperature炉膛出口烟气温度furnace outlet gas temperature排烟温度exhaust gas temperature锅炉热效率boiler efficiency保证效率guarantee efficiency燃烧效率combustion efficiency锅炉热损失boiler heat loss排烟热损失heat loss due to exhaust gas气体不完全燃烧热损失heat loss due to unburned gases固体不完全燃烧热损失heat loss due to unburned carbon in refuse散热损失heat loss due to radiation灰渣物理热损失heat loss due to sensible heat in slag飞灰可燃物含量（飞灰含碳量）unburned combustible in flue dust炉渣可燃物含量（炉渣含碳量）unburned combustible in slag漏风系数air leakage factor热风温度hot air temperature一次风（一次空气）primary air二次风（二次空气）secondary air三次风（三次空气）tertiary air炉膛容积热负荷furnace volume heat release rate炉膛截面热强度furnace cross-section heat release rate辐射受热面热流密度（炉壁热流密度）furnace wall heat flux density炉排面积热负荷grate heat release rate炉排通风截面比percentage of air space水动力特性hydrodynamics循环倍率circulation ratio循环水速circulation velocity运动压头available static head有效压头available head质量流速mass velocity质量含汽率steam quality by mass临界含汽率critical steam quality沸腾换热恶化boiling crisis过冷沸腾subcooled boiling计算压力calculated pressure计算壁温calculated metal temperature最高允许工作压力maximum allowable working pressure安全系数safety factor许用应力allowable stress理论计算壁厚theoretical calculated thickness 最小需要壁厚minimum required thickness公称壁厚（名义壁厚）nominal thickness有效壁厚effective thickness应力集中系数stress concentration factor孔桥减弱系数ligament efficiency焊缝减弱系数weld efficiency开孔补强reinforcement of openings表面清理surface cleaning喷丸（砂）处理shot-rain cleaning封头成型head forming冲压成型press forming旋压成型spin forming爆炸成型explosion forming边缘加工edge processing去毛刺deburring卷板plate rolling冷态卷板cold rolling热态卷板hot rolling矫形shape righting矫圆round set板边预弯preliminary rolling弯管tube bending冷态弯管cold bending胀管tube expansion胀管率expansion efficiency成排焊接panel welding成排弯管panel bending不圆度out-of-roundness直线度straightness/alinement偏心度eccentricity管端倾斜度gradient of tube-end通球试验ball passing test锅筒起吊drum lifting砌墙walling烘炉furnace drying煮炉boiling out补炉fetting挖补修理remedy除垢descaling机械除垢mechanical descaling化学清洗chemical cleaning碱煮除垢alkali descaling酸洗除垢acid descaling钝化处理passivating冲管flushing吹管steam-line blowing锅炉改造boiler reforming炉拱改造arch reforming循环系统改造circulation circuit reforming 锅炉启动start-up上水filling水位water level炉内清扫purge点火fire升压raising pressure疏水drain并汽bring a boiler onto the line 启动压力start-up pressure启动流量start-up flow rate滑参数启动variable parameter start-up 排污blowdown定期排污periodic blowdown连续排污continuous blowdown吹灰soot blowing压缩空气吹灰compressed air blowing 蒸汽吹灰steam blowing药物清灰chemical deashing压火banking fire停炉shutdown定压运行constant pressure operation 变压运行variable pressure operation 经济运行economical operation停炉保养preservation湿法保养wet preservation干法保养dry preservation充气保养gas-filled preservation外部检查visual inspection内部检查internal inspection宏观检验macroscopic examination漏风试验air leakage test堵灰clogging常用锅炉专业词汇中英对照序号英文中文1 GENERAL ARRANGEMENT SIDE ELEV A TION 锅炉总图纵剖视2 GENERAL ARRANGEMENT PLAN VIEWS 锅炉总图水平剖视3 GENERAL ARRANGEMENT FRONT ELEV A TION 锅炉总图前视图4 AIR & GAS FLOW SCHEMA TIC DIAGRAM 烟风流程图5 STEAM & WA TER FLOW DIAGRAM 汽水流程图6 AIR & GAS DUCT GENERAL ARRANGEMENT 烟风道布置总图7 WELDMENTS INTERFACE FOR STEAM AND WA TER PIPING 汽水接口尺寸图8 BOILER THERMAL EXPANSION DIAGRAM 锅炉热膨胀系统图9 SUPERHEA TER SYSTEM GENERAL ARRANGEMENT SIDE 过热器总图纵剖视ELEV A TION10 SUPERHEA TER SYSTEM GENERAL ARRANGEMENT PLAN VIEWS 过热器总图水平剖视11 GENERAL ARRANGEMENT OF WA TER WALL 水冷壁总图12 GENERAL ARRANGEMENT OF BACKPASS WALL 包墙布置总图13 GENERAL ARRANGEMENT OF ROOF TUBES 顶棚管总图14 GENERAL ARRANGEMENT OF ECONOMIZER 省煤器总图15 ARRANGEMENT OF STEAM & W A TER CONNECTIONS FOR W A TER COLUMN水位表管路布置图16 ARRANGEMENT OF TOP HEADERS & LINKS 顶部大管道布置图17 METAL TEMPERA TURE MEASUREMENTS LOCA TION DWG 壁温测点布置图18 INSTRUMENT INSERT & MEASUREMENT LOCA TION DWG 仪表测点布置图19 ARRANGEMENT OF MISCELLANEOUS PIPING 杂项管路布置图20 PIPING AND INSTRUMENTA TION DIAGRAM (P&I流程图)介质流程图21 BOILER CIRCULA TION PUMPS DIAGRAM 锅炉循环泵系统图22 STRENGTH CALCULA TION OF BOILER STEAM DRUM 锅筒强度计算书23 STRENGTH CALCULA TION OF BOILER HEADERS PIPING AND TUBING 管子及集箱强度计算书24 O.D : OUTSIDE DIAMETER 外直径25 I .D : INSIDE DIAMETER 内直径26 R : RADIUS 半径27 MINIMUM WALL THICKNESS(MWT) 最小壁厚28 A VERAGE WALL THICKNESS(A WT) 平均壁厚29 MAXIMUM PERMISSIBLE DIAMETER OF OPENING 最大允许开孔直径30 SIZE OF OPENING 开孔尺寸31 TEMPERA TURE COEFFICIENT 温度系数32 MAXIMUM ALLOWABLE STRESS 最大许用应力33 MINIMUM REQUIRED THICKNESS 最小需要壁厚34 ADDITIVE THICKNESS 附加壁厚35 ACTUAL THICKNESS OF SHELL 筒身取用壁厚36 ACTUAL THICKNESS OF PIPE 管子取用壁厚37 HEMISPHERICAL HEAD 球型封头序号英文中文38 FLA T HEAD 平端盖39 LONGITUDINAL PITCH 纵向节距40 CIRCUMFERENTIAL PITCH 环向节距41 DIAGONAL PITCH 斜向节距42 EFFICIENCY OF LIGAMENT 孔桥系数43 EFFICIENCY FOR LONGITUDINAL LIGAMENT 纵向孔桥系数44 EFFICIENCY FOR CIRCUMFERENTIAL LIGAMENT 环向孔桥系数45 EFFICIENCY FOR DIAGONAL LIGAMENT斜向孔桥系数46 EQUIV ALENT LONGITUDINAL EFFICIENCY 当量纵向孔桥系数47 LIMITS OF REINFORCEMENT FOR OPENING 开孔补强范围48 CORRECTION FACTOR FOR PRESSURE STRESS压应力修正系数49 AREA REQUIRED FOR REINFORCEMENT 需要补强面积50 AREA IN EXCESS THICKNESS IN THE SHELL 筒身起加强作用补强面积51 AREA IN EXCESS THICKNESS IN THE NOZZLE 管接头起加强作用补强面积52 ASME CODE SECTION ⅠASME法规第Ⅰ卷53 ASME CODE SECTION Ⅱ，PART D ASME法规第Ⅱ卷D篇54 RULES FOR CONSTRUCTION OF POWER BOILERS 动力锅炉建造规则55 ASME BOILER AND PRESSURE VESSEL CODE ASME锅炉与压力容器法规56 THE AMERICAN SOCIETY OF MECHANICAL ENGINEERS美国机械工程师学会57 COMBUSTION ENGINEERING INCORPORA TION 美国燃烧工程公司58 MITSUBISHI HEA VY INDUSTRIES LIMITED 日本三菱重工业集团59 HARBIN BOILER COMPANY LIMITED 哈尔滨锅炉厂有限责任公司60 MASONEILAN 阀门供货商美国梅索尼兰公司61 DRESSER 阀门供货商美国德莱赛公司62 ANDERSON GREENWOOD 阀门供货商美国安德森格林伍德公司63 CROSBY阀门供货商美国克罗斯比公司64 VELAN阀门供货商加拿大威兰公司65 FISHER阀门供货商美国费舍尔公司66 COPROSIDER 三通供货商意大利考坡罗西得公司67 ALSTOM POWER BOILER GMBH 阿尔斯通公司68 NORTHEAST ELECTRIC POWER DESIGN INSTITUTE 东北电力设计院69 BOILER DESIGN AND DEVELOPMENT DEPARTMENT锅炉设计开发处70 UTILITY BOILER PRESSURE PARTS DESIGN SECTION 电站锅炉受压元件设计室71 CFB BOILER PRESSURE PARTS DESIGN SECTION 流化床锅炉受压元件设计室72 PERFORMANCE DESIGN SECTION 性能设计室73 AIR HEA TER AND DUCT DESIGN SECTION 空气预热器设计室74 STRUCTURAL STEEL DESIGN SECTION 钢架设计室75 STRESS ANALYSIS SECTION 应力分析室76 SECRETARY OFFICE 计划室77 FIRING SYSTEM DESIGN SECTION 燃烧系统设计室78 COMPUTER PROGRAM DESIGN SECTION 计算机程序设计室79 POSTWELD HEA T TREA TMENT 焊后热处理序号英文中文80 CHEMICAL COMPOSITION 化学成分81 MA TERIAL PROPERTIES 材料性能82 MINIMUM TENSILE STRENGTH 最小抗拉强度83 MINIMUM YIELD STRENGTH 最小屈服强度84 MAXIMUM TEMPERA TURE LIMITS(OXIDA TION LIMIT) 最高使用温度（抗氧化温度）85 CREEP RA TE 蠕变数率86 STRESS RUPTURE 断裂应力值87 AUSTENITIC ALLOY STEEL (STAINLESS STEEL ) 奥氏体不锈钢88 FERROUS STEEL 铁素体钢89 COEFFICIENT OF THERMAL EXPANSION 热膨胀系数90 LINEAR THERMAL EXPANSION 线性热膨胀系数91 CONVERSION FACTOR 换算系数92 PERMANENT STRAIN 永久变形93 NP=NOT PERMITTED 不许采用94 FINITE ELEMENT ANALYSES 有限元分析95 ELASTIC DEFORMA TION 弹性变形96 PLASTIC DEFORMA TION 塑性变形97 FURNACE VOLUME 炉膛容积98 FURNACE WIDTH 炉膛宽度99 FURNACE DEPTH 炉膛深度100 MAN HOLE （锅筒）人孔101 TEMPERA TURE PROBE 温度探针102 THERMOCOUPLE 热电偶103 WALL BLOWER 墙式吹灰器104 RETRACTABLE BLOWER 伸缩式吹灰器105 SOOT BLOWING SYSTEM 吹灰系统106 HYDROSTA TIC TEST（HYDRAULIC TEST）水压试验107 HARDNESS TEST 硬度试验108 RADIOGRAPHIC TEST (RT) 射线检查109 MAGNETIC TEST (MT) 磁粉检查110 MA TERIAL PURCHASING REQUISITION 材料申请单111 ACCESS DOOR 检修人孔112 DYE PENETRANT TEST (PT) 着色检查113 ￠:OF BOILER 锅炉中心线114 FW :FIELD WELD工地焊接115 TUBE ENDS SCARFING PER HG04004-98 管端坡口按HG04004-98116 ULTRASONIC INSPECTION (UT) 超声波检查117 DETAIL OF GROOVE 坡口详图118 REDUCER 大小头119 TEE 三通120 ELBOW(锻造) BEND (弯制) 弯头121 SCOPE OF SUPPLY AND TECHNICAL REQUIREMENTS供货范围和技术要求序号英文中文122 CONTRACT NO. 合同号123 A TECHNOLOGY TRANSFER CONTRACT技术转让合同124 BUYER 买方125 SELLER 卖方126 VENDOR 卖主127 SHIPPING MARK 发货标记128 PACKAGE NO. 发货清单号129 CASE NO. 发货件号130 GROSS WEIGHT 毛重131 NET WEIGHT 净重132 KEEP AWAY FROM MOISTURE 防潮133 ETC. 等等134 N.A.=NOT APPLICABLE 不采用135 DITTO 同上136 PACKAGE PER DWG 按图包装137 BUNDLED WITH WIRE & BAR 铁丝捆扎扁钢笼扎138 TWO LABLES FOR ONE PACKAGE 每包两个小标牌139 SUPPLY PER TOTAL LENGTH 按总长供货140 DELIVERY A T A GIVEN LENGTH 分段出厂141 SCALLOPED BAR 梳形板142 HANGER PLA TE 吊挂板143 SUPPORT RACK 撑架144 WOODEN CASE 木箱包装145 HANDLE WITH CARE 小心轻放146 THIS SIDE UP 这侧朝上147 DIMENSIONS (LENGTH ,HEIGHT AND WIDTH ) 尺寸（长、高、宽）148 RECIPIENT 收件人149 CONSIGNEE / RECEIVER 收件人150 REPRESENTA TIVE OF HBC 哈锅代表151 VICE CHIEF ENGINEER 副总师152 DIRECTOR 处长153 SUPERVISOR 室主任/ 组长154 DESIGNED BY 设计155 CHECKED BY校对156 REVIEWED BY审核157 VERIFIED BY审定158 APPROVED BY 批准159 HEADER MANUFACTURING SHALL BE IN ACCORDANCE WITH SPECIFICA TION HG5.2.1.5 集箱制造按技术条件HG5.2.1.5160 TUBE ENDS SCARFING PER 94-0430(Ⅺ) & INNER SCARFING DIAMETER 37mm 管端坡口按94-0430(Ⅺ) 型加工,且内倒角D内=37mm161 CHAMFER 1.5×45°按1.5×45°倒角162 SHOWN 1 OPPOSITE HAND 1 正反各一163 PIECE NO: / MARK NO.件号序号英文中文164 HEA T TREA TMEN TO BE MADE AFTER ALL PARTS WELDED TO THE HEADER 集箱所有零件焊接完毕进行热处理165 RIGHT SIDE SHOWN,LEFT SIDE TO BE SYMMETRICAL 本图仅示出右侧，左侧与之对称166 DIMENSION IN BRACKETS IS THE MIN REQUIRED THICKNESS BY CALCULA TION,IT IS NOT PERMITTED IN ANY CASE THE WALL THICKNESS LESS THAN THIS V ALUE括号内尺寸为理论计算最小壁厚,任何情况下均不得小于该值167 FIN SPLIT TO BE SEAL WELDED AFTER COMPLETING BUTT WELD WITH ADJACENT PANEL A T SITE 管屏在工地对接完工以后,鳍片开缝应焊封168 BIFURCA TE TUBE 分叉管,三叉管169 TUBE ENDS TO BE COA TED WITH VINYL CAPS &COHESIVE TAPE 管子两端均盖以塑料管盖并用胶带密封170 WELDING MA TERIAL 熔焊金属171 QUANTITIES GIVEN ARE FOR ONE BOILER 给出的数量为单台锅炉172 DEVELOPMENT ON OUTSIDE OF SHELL PLA TES筒身按外表面展开图173 MA TCH DRILL 20mm φ HOLES WITH DWG 5541B.142 A T ASSEMBLYΦ20装配时与图5541B.142配钻174 SHARP EDGE IN THE OPENING AREA OF INSIDE SURFACE TO BE GROUND SMOOTHLY IN 2~3mm RADIUS 集箱内表面开孔部位均以R=2~3mm倒圆175 REMOVE ANY BURRS THA T EXIST ON HOLES & WELD SEAM 去除开孔及焊缝的毛刺176 TUBE BUTT WELDING IS NOT PERMITTED WITHIN 250mm FROM ￠OF BUCKSTAY 刚性梁中心线上下250mm以内不准有拼接焊缝177 SHOWN AND OPPOSITE HAND TO BE MADE PER DRA WING 按本图制造正反178 BENDING RADIUS 120mm 弯曲半径120mm179 CUTTING AND SEAL WELDING A T SITE 工地切割焊封180 CHROMIUM 元素Cr181 MOLYBDENUM 元素Mo182 V ANADIUM 元素V183 TITANIUM 元素Ti184 BORON 元素B185 MANGANESE 元素Mn186 CARBON 元素C187 TUNGSTEN 元素W188 NICKLE 元素Ni189 STEEL BILLET 钢坯190 COMPENSA TION CALCULA TION FOR MULTIPLE OPENINGS孔桥补强计算191 THE RADIUS ON OUTSIDE OF THE TEE A T THE JUNCTION OF BRANCH AND RUN SHALL BE EQUAL TO OR GREA TER THAN 120mm 三通外侧主管与支管交接处R应≥120mm 192 THE MIN THICKNESS OF AN UNPIERCED SHELL OF TEE 不开孔三通最小壁厚序号英文中文193 TUBE ENDS SCARFING FOR FIELD WELDING SEE DWG YT15-199，TYPE Ⅱ，D1=4940-0.5,tT=58，F=25 工地焊接坡口按YT15-199Ⅱ型，D1=4940-0.5,tT=58，F=25194 STRENGTH OF THE FILLET WELD IN TENSION 焊缝抗拉强度195 STRENGTH OF THE FILLET WELD IN SHEAR 焊缝抗剪强度196 THE WELD TO BE GROUND SMOOTHLY IN R120mm该焊缝以R120mm打磨光滑。
