LED DISPLAY BACK-UP INVENTORY KIT COMPONENTSSTEP 1. DETERMINE ORIENTATION OF DISPLAY AND INSTALL LIGHTING INSERTSThe Truck-Lite LED displays can be oriented to be used as a countertop piece/mounted low on wall or to be oriented to mount high on a wall. If your display will be used as a countertop display or mounted low on a wall, assemble the lighting insert into the black display base (96130 or 96131)so that the wide portion of the display base is located on the bottom. If your display will be mounted high on a wall, assemble the lighting insert into the black display base (96130 or 96131)so that the narrow portion of the display base is located on the bottom.A. Install assembled lighting insert into display base using 12 - 1/4 20 bolts and 12 wing nutsSTEP 2. INSTALL TOP MOUNT LAMPS (required for Signal-Stat & White Lighting diplays) Signal-Stat Display and White LightingDisplay include lamps that requiremounting on top of large base.Signal-Stat Display 96118-4A. Remove ring terminal and strip 1/2” of coating from whiteground wire on 2750 and 2751 pedestal lamps.B. Mount 2750 and 2751 pedestal lamps on top of display using mounting hardware provided with lamp (see below).C. Crimp white wire from 2750 and 2751 pedestal lamps to white wire with open crimp connector from LED display harnessD. Choose if you want to have the major or minor function for 2750 and 2751 lit.Major: Crimp black wire from 2750 and 2751 pedestal lamps to red wire with open crimp connector from LED display harness Minor: Crimp red wire from 2750 and 2751 pedestal lamps to red wire with open crimp connector from LED display harness White Lighting Display 96119-4A. Strip 1” of black insulation from 81360 LED Worklamp to reveal white and black wireB. Strip 1/2” of coating from white ground wire and black positive wire on 81360 LED WorklampC. Mount 81360 LED Worklamp on top of display using mounting hardware provided with lamp (see below).D. Crimp white wire from 81360 LED Worklamp to white wire with open crimp connector from LED display harnessE. Crimp black wire from 81360 LED Worklamp to red wire with open crimp connector from LED display harnessWHITE(ground)RED (major function)BLACK (minor function)RED (from display harness)WHITE(from display harness)(from display harness)2750 & 2751on Signal-Stat Display81360on White Lighting DisplayMounting Lamps to Display Base81360 wires routethrough rear hole2750 & 2751 wires route through same holeas mounting studSTEP 3. INSTALL WALL MOUNTING HARDWARESTEP 4. ASSEMBLE POWER SUPPLY UNIT AND ASSEMBLED LIGHTING UNITS(S) TOGETHERFor low wall mount use assemble hanging brackets on narrow side of base.A. Install 3 wall mounting brackets using 6 - 1/4 20 hex head bolts and 6 - wingnuts on narrow or wide side of display base depending on chosen orientation of displayTruck-Lite LED Lighting displays are designed so that the power supply unit connects to the left hand side of the assembled lighting unit regardless of orientation chosen.B. 96112 display requires connecting multiple (4) lighting displays chained together. Connect units together through side holes with 2 - 1/4 20 bolts and 2 - wingnuts * In case of over-voltage, each harness is equipped with a replaceable fuseB.A.B.STEP 6. INSTALL DRYWALL HANGERS AND HANG DISPLAYA. Drill 1/4” holes in wall (see required dimesions below)B. Install drywall hangers into 1/4“ hole in wall.C. Insert screws into drywall hanger leaving 1/4” extending fromwall to hang display.D. Insert screw heads into oversized hole and lower display, guidingscrews into slot.8-3/8”4-5/8”。
Product PictureUnité bébé supplémentaire pourSCD610SCD609Caméra supplémentaire pour une famille qui s'agrandit Vision de jour comme de nuit, partout dans la maisonNotre technologie d'écoute-bébé vidéo numérique vous permet de maintenir une connexion sûre et privée avec votre bébé.Vision de jour comme de nuitSurveillez votre bébé nuit et jourPortée de 150 mDéplacement et zoomAjoutez plus de caméras lorsque votre famille s'agranditCompatible avec jusqu'à 4 camérasVision optimaleCaméra à fixation muraleCompatibleCompatible avec l'écoute-bébé SCD610Installation et utilisation facilesÉcoute-bébé vidéo numérique SCD609/00Points forts CaractéristiquesPortée de 150 mRestez en contact avec votre bébé chez vousgrâce à une portée allant jusqu'à 150 m environ.Fixation murale possiblePour une excellente vision. Installez votreécoute-bébé au mur avec le support mural facile à fixer.Déplacement et zoomVoyez tout ce que fait votre bébé grâce aux fonctions de déplacement et zoom optique x 2. Surveillez votre bébé nuit et jourVoyez votre bébé de nuit comme de jour.Affichage couleur dans la journée, noir et blanc infrarouge la patible avec jusqu'à 4 camérasMaîtrise totale. Avec plusieurs caméras, vouspouvez suivre votre bébé de pièce en pièce.Installation et utilisation facilesAssociez une caméra supplémentaire à votreécoute-bébé SCD610 en quelques étapessimples à réaliser grâce à l'écran interactif.Compatible avec l'écoute-bébé SCD610Parcourez automatiquement les camérassupplémentaires pour surveiller différentespièces ou différents enfants.Étapes de développementÉtape: Grossesse, 0 à 6 mois, 6-12 moisTuner/réception/transmissionSélection automatique du canalAlimentationAlimentation: 220-240 VPratiqueVoyant d'alimentationFixation murale possibleAlimentationAlimentation: 120 V (É.-U.)AccessoiresGuide de démarrage rapideTuner/réception/transmissionBande de fréquence: 2,4 GHzAccessoiresAdaptateur secteur© 2022 Koninklijke Philips N.V. Tous droits réservés.Les caractéristiques sont sujettes àmodification sans préavis. Les marques commerciales sont la propriété de Koninklijke Philips N.V. ou de leurs détenteurs respectifs.Date de publication 2022‑03‑30Version: 6.1.1EAN: 08 71010 35585 38 。
LMC078+LXM28S多圈位置溢出后的处理1.背景6月初在华东某包装客户现场，使用了LMC078+8台28S（带多圈电机）的解决方案来实现电机位置的保持。
在调试时，发现其中需要一直往一个方向运行的三个皮带机A1、A2，A3，在长时间运行后（当28S的位置发生溢出后），再对078和28S断电上电，LMC078中这几个轴的位置会发生改变，如图1和图2所示。
图中的A1装盒主轴、A2输送轴位置和A3放瓶输送轴的位置显示，采用的是轴名称.factposition 变量，对比系统断电前后的图1和图2的位置可以清楚的看出A1，A2，A3轴的位置断电再上电都发生了改变。
而其余五台伺服的运动方式是往复运动，没有出现过078中轴位置丢失的情况。
图1 断电后再上电A1~3轴的位置图2 A1~A3轴断电前，后位置对比这个客户现场发现的问题我在16号的张江实验室进行了复现和确认，如图3所示。
图3 张江实验复现上电前后位置变化2.LMC078和28S的固件版本LMC078 1.5.1.5，28S的固件测试2.75.25和2.78.3两个版本。
3.SoMove调试软件和DTM版本使用SoMove软件2.8.4+V1.6.12版本的DTM文件进行产品的调试。
4.Lexiumstudio 调试软件版本使用lexium studio V1.15.0，主要用于检查伺服驱动器和电机。
5.SoMove检查A1~A3轴断电前后的位置使用SoMove检查驱动器断电前后A1~A3的位置的改变动量非常小，A1轴断电前后的位置如图4所示。
图4 A1断开前后28S编码器位置的对比A2和A3轴的位置变化量也很小，位置的变化都在合理的范围内，说明28S 的位置信息在断电后并没有丢失。
6.LMC078轴位置丢失的原因和解决方案1）原因在客户现场发现只有A1~A3轴一直往一个方向运行的轴会发生溢出的现象，而A4~A7往复运行轴并没有问题，可以确定此问题是因为28S的位置发生溢出但LMC078没有对LXM28S的轴位置进行补偿导致的。
Heinemann®GJ1P Series Circuit BreakersDESCRIPTIONOptional Low-Voltage Shunt for Current MeteringEaton Corporation’s Cutler-Hammer series of Heinemann GJ1P breakers offer high quality circuit protection for DC applications from 100 to 1200 Amperes.Their precisely tailored time delays and ability to interrupt high currents makes them ideally suited for critical applications. On overloads exceeding 1000 – 1400% of rating, there is no intentional time delay and the breaker interrupts currents of as much as 25,000 A at 65V DC.An optional shunt (25 or 50millivolt full scale) permits metering of current. Since the shunt output is low voltage,light-gauge wiring can be used from shunt to meter.Indication may be displayed inpercent, watts, safe/danger or other dial calibrations. In addition, the busbar is available in two versions:Standard Size and Reduced Size. Contact your Eaton Sales Representative for more information.Precision Current Equalization (PCE) Circuit BreakersGJ1P breakers rated 250 to1200 A are built in parallel construction. Conventional parallel pole breakers can experience uneven current distribution because of variations in internalresistances. This condition can result in nuisance tripping since the higher current in one parallel branch has the same effect as an overload on the sensing element in that branch. Proprietary Precision Current Equalization (PCE)circuit breakers, on the other hand, allow for differences in internal resistances byautomatically distributing the current equally through the parallel current sensing elements, minimizing the danger of nuisance tripping.The UL listed series GJ1P (UL489) models are available in a choice of fast, medium or slow response times to accurately match load conditions. They can be ordered in “series trip ”, “mid-trip ” and “switch only ”constructions and are available front- or back-mounted, front- or back-connected, with optional auxiliary switches for signaling.HYDRAULIC-MAGNETIC BENEFITSThe magnetic/hydraulic load-sensing and time delaymechanisms used in GJ1P breakers are insensitive to changes in ambient or enclosure temperature.Therefore, GJ1P circuitbreakers are suited for service conditions encountered in telecommunications,transportation, air conditioning and other outdoor or “heat-loaded ” equipment.SPECIFICATIONSStandard Current Ratings:100, 125, 150, 175, 200, 225,250, 300, 350, 400, 450, 500,600, 700, 800, 900, 1000,1100, 1200 A.Standard Maximum Voltages:160V DC up to 700A65V DC from 701 to 1200A Breakers will be labeled with standard maximum (UL) voltage unless otherwise specified.Special Current Ratings:Any integral rating between 100and 1200 A DC. Consult factory for ordering information and metering shunt restrictions.Interrupting Capacities:UL Listed:10,000 A @ 160V DC 25,000 A @ 65V DC Non-UL:14,000 A @ 160V DC.Operating Temperature Range:-40°C to +85°C.Approximate Weight:1-pole (100-225A) 1.13kg (2.5lbs)2-pole (250-400A) 2.27kg (5lbs)3-pole (450-700A) 3.40kg (7.5lbs)4-pole (701-800A) 4.54kg (10lbs)5-pole (801-1000A) 5.67kg (12.5lbs)6-pole (1001-1200A) 6.80kg (15lbs)Weight may vary based on shunt and busbar.APPROVALSUL Listing:GJ1P breakers are UL listed per UL489. For CSA certification,consult application engineering.Description . . . . . . . . . . . . . .2Specifications . . . . . . . . . . . .2Approvals . . . . . . . . . . . . . . .2Time Delay Characteristics . . .3Dimensions . . . . . . . . . . . .4-5How to Order . . . . . . . . . . .6-7Additional Products. . . . . . . . .8TABLE OF CONTENTS PageHEINEMANN ®CIRCUIT BREAKERSGJ1P Series Circuit Breakers(100-1200 Amperes DC)2Heinemann is a registered trademark of the Eaton Corporation, Commercial Controls Business Unit.100150.01.001.1110100100010,000200300400500600700800900100011001200125C u rv e 1C u rv e 2C u rv e 3Current – Percent of Ampere RatingT r i p T i m e – S e c o n d sDC CURVES100150.01.001.1110100100010,000200300400500600700800900100011001200125Current – Percent of Ampere RatingT r i p T i m e – S e c o n d sINSTANT DELAY DC CURVE PPERCENT OF RATED CURRENT VS. TRIP DELAY AT 25ºCTIME DELAYCHARACTERISTICSTime delay, in all models,is inversely proportional to the magnitude of the overload, adjusting automatically to limit transient power to the load. On overloads exceeding 1,000 –1,400%, the circuit breaker trips without any deliberately imposed delay.Curve 1.Standard time delayis furnished unlessanother optional delay is specified. It is thepreferred characteristic for use where the load is composed of both resistive and inductive components.Curve 2.Medium time delayis for general usein mixed (inductive and resistive) circuits where the breaker rating is matched to the current carrying capacity of the mains.Curve 3.Short time delaypermits a very brief delay period before tripping.Curve P .Non-time delay breakersare available forapplications which cannot tolerate even brief transient overloads.These breakers have no time delay mechanism other than that imposed by the coil self-inductance and the inertia of the mechanism.Tripping specificationsThe time delay curves depict breaker response time vs. percent of rated load with no preloading.The function is plotted at an ambient temperature of 77°F (25°C) with the breaker in a vertical or wall-mounted position.Series GJ1P circuitbreakers will carry 100%of rated load continuously.Both time delay and non-time delay breakers may trip between 101%and 125% of rated load,and must trip at 125%and above.3% (sec)Delay 100%125%200%400%600%800%1000%Delay Max.1no trip 1100150206 1.7.065Delay Min.1no trip 110224 1.1.01.008Delay Max.2no trip 110153.8.28.055Delay Min.2no trip 12 2.5.5.18.01.008Delay Max.3no trip 10.8.19.08.047.038Delay Min.3no trip.44.13.03.015.01.008STANDARD FRONT-CONNECTED CONSTRUCTIONWire Range #6 to 250 MCM74.59(2.938)76.20(3.000)Aux. Terminals, Male Type Molex 02-09-2101, Model 1190-T(See Illustrations for Combinations)Shunt Terminals, Female TypeMolex 02-09-1101, Model 1189-T37.69(1.484)42.84(1.687)0.99 (0.390)71.42(2.812)#10-32 Inserts (4 Places)38.10(1.500)19.05(0.750)19.05(0.750)6.35 ± 0.38(0.250 ± 0.156)6.35 ± 0.38(0.250 ± 0.156)Panel Mounting Hole Distance for #10-32LINELOAD 75.38(2.968)5.53(0.218)59.91(2.359)32.13(1.266)5.53(0.219)“D ” Type Terminals as Shown180.97(7.125)41.27(1.625)4.74(0.188)58.67(2.313)41.27(1.625)41.27(1.625)263.52(10.375)29.36(1.156)7.14(0.281)78.56(3.094)59.13(2.328)28°±5°32°±5°ONOFFSee Optional Terminal ConfigurationWire Range #6to 250 MCM41.27(1.625)36.49(1.437)38.10(1.500)100 – 22 A250 – 400Width dimensions are as follows:100 – 225 38.1 (1.5)250 – 400 A 76.2 (3.0)450 – 700 A 114.3 (4.5)701 – 800A 142.4 (6.0)801 – 1000A 190.5 (7.5)1001 – 1200A228.6 (9.0)28.95(1.141)46.40(1.828)22.22(0.875)Fastener Mounted ThisSide of Bus Plate,Terminals are Front-Connected and Unit is Rear-Mounted.Fastener Mounted This Side of Bus Plate, Terminalsare Back-Connected and Unit is Panel-Mounted.60.32(2.375)7.92(0.312)3/8-16UNC -2B (4 per Unit)38.10(1.500)225.43 (8.875)Center to CenterOptional Terminal ConfigurationsHEINEMANN ®CIRCUIT BREAKERSGJ1P Series Circuit BreakersDIMENSIONSDimensions are given here only as a preliminary guide to specifying. Final engineeringdrawings should be made from the latest Heinemann drawings. Contact Customer Service Center.Tolerance:±0.79 (0.031) except where noted. For metric threads, contact Customer Service Center.DIMENSIONS APPROXIMATE IN MM (INCHES)431.75(1.250) Min.41.65(1.641) Max.19.05(0.750)7.51(0.297)7.51(0.297)7.51(0.297)16.66(0.656)Typ.29.36(1.156)29.36(1.156)48.41(1.906)48.41(1.906)67.46(2.656)67.46(2.656)38.10(1.500)38.10(1.500)38.10(1.500)38.10(1.500)19.05(0.750)19.05(0.750)19.05(0.750)22.23(0.875) Min.321.31(12.65) Max.78.96(3.109)Min. Typ.5.15(0.203)Dia. Typ.C100 – 225 A Ratings 226 – 400 A Ratings401 – 700 150A RatingsBA106.75(4.203)Typ.C LC L C L FRONT MOUNTING PANEL AND SUPPORT BRACKET115.08(4.531)76.98(3.031)38.1(1.500)38.1(1.500)71.42(2.912)5.94(0.234)Ref.5.15(0.203)Typ. Dia.65.02(2.562)59.13(2.328)(3-Pole)3PoleC L C L C L Holes Required When Breaker Is Front-Mounted2Pole1PoleAB C (2-Pole)(1-Pole)38.88(1.531)19.43(0.765)Mounting kits containing clips, brackets and necessary hardware and instructions are available (consult factory).009-18234 100 – 225 A 1.5 (1-pole wide)009-18235 250 – 400 A 3 (2-pole wide)009-18232 450 – 700 A 4.5 (3-pole wide)For 701-1200A devices, contact your Eaton Sales Representative for mounting kit part numbers.See Step (2)See Step (5)BACK MOUNTING CIRCUIT BREAKERBack mounting circuit breaker mounting instructions 1. Position circuit breaker to support brackets.2. Place mounting bracket in recess on front top portion of circuit breaker.3. Install four (4) #10-32 by 3-1/4" long screws through holes in mounting bracket and support structure.4. Install lock washer and nut on each of the screws and tighten.5. Place mounting bracket on front lower portion of circuit breaker.6. Install two (2) #10-32 by 5/8" screws through holes in mounting bracket and support structure.7. Repeat step 4.5DIMENSIONS APPROXIMATE IN MM (INCHES)NOTE: Standard size busbar is shown above. For the reduced size busbar, contact your Eaton Sales Representative for mounting dimensions.Series PrefixGJ1PSwitch (No Coil)Series Trip w/SPDT Aux. SwitchSeries Trip Series Trip and Mid-Trip Series Trip, Mid-Trip and SPST Alarm SwitchTerminal Location Back FrontInternal Circuit Metering ShuntNo Shunts Metering Shunt Metering ShuntB HCodeLocationInternal CircuitCodeDescriptionShuntCode—25mV 50mVP M N0-2-3-98-99-Series Prefix GJ1PTerminal LocationBInternal Circuit3-Metering ShuntPAdd each appropriate Number or Letter …HEINEMANN ®CIRCUIT BREAKERSGJ1P Series Circuit BreakersHOW TO ORDER — Series GJ1PTo determine your Complete Catalog Number , you must start with appropriate Series Prefix and add the appropriate Code Letters and/or Numbers as in the example below:SELECTION TABLE61Multi-pole construction – Consult factory.An auxiliary switch, if supplied, will be located in the right pole space. If the auxiliary switch is supplied in a breaker which has a metering shunt, it will be single-pole single throw (SPST). The single-pole double throw (SPDT) auxiliary switch can be supplied only in a breaker without a metering shunt.2Cannot be used on breaker containing metering shunt.3Only for breakers rated in excess of 250 A. Breakers up to 250 A without meteringshunt are available as standard GJ1 type breakers. Please consult Series GJ catalog.MarketUL-489TerminalsSolderless Connector Bus Bar ConnectionStandard Current Ratings 1AmpereTrip Curve 1123P0 – 1200(Add 0 before amp rating if less than 1000A.Example: 0700)-01-02-03-0PDescriptionCodeDEDUStandardCodeCurveCodeComplete Catalog Number: GJ1PB3-PEDU0700-02Terminal ConfigurationEUS/European ApprovalDUStandard Current Ratings 10700Trip Curves 1-024Add 0 before amp rating if less than 1000. For example: a 700A rating would bedesignated as 0700.The width of the breaker is determined by the current rating:100 – 225 A 1.5” (1-pole wide)250 – 400 A 3” (2-pole wide)450 – 700 A 4.5” (3-pole wide)701 – 800A 6” (4-pole wide)801 – 1000A 7.5” (5-pole wide)1001 – 1200A 9” (6-pole wide)5See page 3 for time delay characteristics and trip curve information.7© 2001 Eaton Corporation All Rights Reserved Printed in USAForm No. BR5401SE0002A / CSS 65322June 2001Commercial ControlsFor the Widest Selection of Circuit Protection, from 0.01 to 1200 Amperes, Look to Eaton.。
