彩色涂层钢板(彩涂)技术与发展(一)随着社会经济的发展,人们追求高品质的生活理念已渗透进钢铁产业,以往黑色、粗犷的钢板已不能满足人们的要求,色彩艳丽、功能实用的彩涂钢板应运而生。
彩色涂层钢板是将一种有机涂层涂敷于钢材表面,它具有外表美观、色彩艳丽、强度高、耐蚀性好、加工成型方便等优点,而且还可以使用户降低成本、减少污染。
彩涂板也叫有机涂层板或预涂钢板,它是以金属卷材(冷轧板、热镀锌板、镀铝板、高铝合金板、不锈钢板等)为基材,在表面涂敷或层压各种有机涂料或塑料薄膜而成。
由于它是在冶金工厂完成表面涂层的卷材,可供用户直接加工成产品,所以也称预涂卷材。
彩涂行业的发展情况1 国外彩涂钢板的发展1935年美国建立了第一条连续涂层钢板线,近20年来彩涂板生产业以建筑工业为突破口得到了迅速发展,产量不断增加,生产能力超过1800万t,尤其是欧美和日本发展较快,在全世界400多条生产线中,美国约占50%,生产能力超过400万t,而且品种齐全。
日本自1958年建成了第一条喷淋式涂层生产线后,至今已有50余条生产线,生产能力近300万t。
美国、日本、欧洲三个地区合计年生产量占世界总产量的84%。
20世纪60年代以后,特别是近二十多年来比利时、瑞典、挪威、芬兰、巴西和东欧一些国家也相继兴建了一批生产线。
2 国内彩涂钢板的发展20世纪60年代,鞍山钢铁公司钢铁研究所就开始着手研究有机涂层卷材,但由于种种原因没有进一步深入研究,直至1987年武汉钢铁公司引进我国第一条正规预涂卷材生产线正式运转,宣告中国终于有了自己的预涂金属卷材工业。
紧接着广州彩色带钢厂(1986年、5万t)、北京钢门窗厂(1988年、3万t)、上海宝山钢铁公司(1989年,22.7万t)以及西南铝业公司(1993年,2万t)等引进的预涂金属卷材相继投产,形成第一次预涂金属卷材工业发展高潮。
20世纪90年代中后期出现了预涂金属卷材业的第二次大发展,这次业主绝大多数是私营企业,他们采用国产的年产量2万t左右的中型生产线建厂,分布在广东,江苏,山东等沿海地区,此阶段新建生产线数量超过50条。
彩涂板知识介绍在连续机组上以冷轧带钢、镀锌带钢(电镀锌和热镀锌)为基板,经过表面预处理(脱脂和学处理),用辊涂的方法,涂上一层或多层液态涂料,化经过烘烤和冷却所得的板材即为涂层钢板。
由于涂层可以有各种不同的颜色,习惯上把涂层钢板叫做彩色涂层钢板。
又由于涂层是在钢板成型加工之前进行的,在国外这叫做预涂层钢板。
一、彩涂板简介1、彩涂板的历史彩涂板生产技术于1927年首创于美国,1936年建成第1套彩图钢板生产机组,1955年建成世界第一套带钢列徐彩图生产机组。
20世界60年代彩涂板生产迅速发展,在北美、欧洲、日本发展尤为迅速。
上世纪80年代末我国才陆续建设彩钢板机组,这些机组多建在钢铁厂及合资企业,彩钢板工艺设备基本从国外引进。
到2000年国产彩钢板达到173万吨,出现了产能过剩。
国有特大钢铁企业宝钢、鞍钢、本钢、首钢、唐钢、济钢、昆钢、邯钢、武钢、攀钢等企业的机组产能、装备水平较高,都相继建成了采用国外技术、年生产能力12万~17万吨的彩钢板机组。
同时,许多民营企业投资的彩钢板生产大多采用国产设备,产能较小,但上马快、投资低,产品主要面向建材、装饰行业。
另外,外资、台资也纷纷登陆兴建彩涂机组,但大部分集中在沿海地区。
1999年以来,随着彩涂板市场兴旺,彩涂板的生产及消费进入了快速增长期。
从2000~2004年,生产量以平均39.0%的速度递增。
到2005年止,全国彩涂板产能大于800万吨/年,还有一批彩涂机组正在建设之中,全国总产能超过900万吨/年。
2、彩涂板特点涂层钢板具有轻质、美观和良好的防腐蚀性能,又可直接加工,它给建筑业、造船业、车辆制造业、家具行业、电气行业等提供了一种新型原材料,起到了以钢代木、高效施工、节约能源、防止污染等良好效果。
使用镀锌钢板为基板的彩色涂层钢板,除有锌保护外,锌层上的有机涂层起了覆盖隔离作用,可防止钢板生锈,使用寿命比镀锌钢板更长,据介绍涂层钢板的使用寿命比镀锌钢板长50%。
普通彩涂基板的生产1 前言彩色涂层板在现代生产生活中应用比较广泛, 其生产过程主要是在冷轧薄板表面涂敷上彩色涂料以改善其表面质量和抗腐蚀能力。
彩色涂层钢板的质量主要反映在涂层性能上, 涂层的性能又分为力学性能、物理性能和抗腐蚀性能。
对于普通彩基板, 在保证涂层性能条件下, 可适当降低锌层重量以节约成本。
本文介绍了鄂钢冷轧薄板厂彩色涂层钢板基板用镀锌钢板的生产工艺与质量控制。
2 基板产品技术要求2.1基板表面质量要求影响彩涂工艺的镀锌板的表面缺陷主要有漏镀和锌花结构, 其他缺陷还有锌粒、锌疤、折叠、裂纹、水印等。
2.2.1漏镀镀锌板出现漏镀的地方, 涂层以后该位置同样会出现漏涂现象。
另一种漏镀的现象是漏钢, 起因是热镀锌的基材由于某种原因生了很厚的黄锈, 这种氧化皮在还原炉种又得不到充分还原, 也会出现漏镀情况, 漏镀的地方呈粗糙的针孔黑点。
由于漏镀会使彩涂过程也出现漏涂情况, 所以作为彩涂基板的镀锌板不允许有漏镀缺陷。
2.1.2锌花结构锌花结构是指镀锌板表面锌花的大小、锌花的波动程度和锌层的厚度。
锌花结构好的镀锌板彩涂后的产品表面质量更高, 更适合特殊用途。
有些后加工产品对镀锌板的表面质量要求更高, 需要在小锌花的基础上再进行光整处理, 经光整后完全消除了锌花, 这种称为光整锌花的基材, 平整度非常高, 涂层后的产品用途范围更加广阔。
鄂钢公司冷轧薄板厂在镀锌机组配置了光整装置, 生产的经光整后的无锌花镀锌板, 更加适合彩涂工艺。
各型号的镀锌板锌层重量应符合表1的规定。
表1 锌层重量2.2基板外形尺寸要求生产彩色涂层板的基材板型对涂敷质量至关重要, 影响涂层表面质量的板型缺陷主要有: 浪边、瓢曲和镰刀弯。
2.2.1浪边和瓢曲浪边是指金属带材沿长度方向出现高低起伏的波浪形弯曲, 使表面失去平直性。
瓢曲是指在钢板或钢带长度及宽度方向同时出现高低起伏波浪, 称为“瓢形”的现象。
有浪边和瓢曲缺陷的基材在彩涂生产线上会出现边部漏涂现象, 漏涂的形式因浪边和瓢曲的峰值和谷值呈间断性或连续性, 大大影响涂层的表面质量。
彩涂钢板Pre-Painted Hot Dipped Galvanized Steel Coils(已签阅)Our Products / Pre-PaintedName: Pre-PaintedType: Pre-PaintedDescribe:Pre-Painted Hot Dipped Galvanized Steel ProductHot Dipped Galvanizing:PPGI is prepainted galvanised steel, also known as precoated steel, coil coated steel, color coated steel etc. A galvanized steel sheet in coil form is cleaned, pretreated, applied with various layers of organic coatings which can be paints, vinyl dispersions, orlaminates.These coatings are applied in a continuous process known as Coil Coating.The steel thus produced in this process is a prepainted, prefinished ready to use material. PPGI is the material which uses galvanised steel as the basic substrate metal. There could be other substrates such as aluminum, Galvalume, stainless steel, etc.Characteristics:∙Corrosion protection∙Long life-time for coated colorProduct Specification:Basic Substrate: cold rolled HDG / GalvalmueQuality: CQ DQColor Standard: Acc to Ral Color Standard or customer's color sample21 ℃.Should temperature of environment becomes too low, warming the steel sheet could be a better choice.e. In order to keep the formation roller and surface of steel sheet from damaging and scratch, formation roller (such as quenched steel and mold die) made of hard material should be adopted. Chrome should be galvanized to the surface of roller.f. It is advisable to add protective appliqué onto the surface of color coated steel sheet. When the construction finished, protective appliqué could be removed.Requirement for transporting the color coated steel sheeta. Keep the color coated steel sheet far from water and sunshine .It is advisable to store them indoors.b. Should the color coated steel sheet be rained or dewing, please dry them as soon as possible so as to remove humidity.c. Keep the inventory as the same as it shipped from factory, do not stock as piles so as to protect the coating layer.d. It is strongly recommended to consume the steel sheet that comes into the inventory earlier. Otherwise, pollution, scratch and color aberration may arise as steel sheet produced at different date mixed together.e. Transport the steel sheet as it shipped out of factory. Releasing the cushion and reversing the package is highly harmful.f. When unloading the steel sheet or steel coil, rubber cushion and lift must be adopted for the sake of avoiding scratch.g. Clean the carriage of transporting the color coated steel sheet and add rubber cushion or adopt protective instrument .h. Vertical packaging is advised for transporting color coated steel sheet. Coil down ending machine should be used to put the coils horizontally.i. Steel sheet and coils should be fixed well prior to transportation ,otherwise they will move and cause scratch.j. When take out color coated steel sheets, do not pull. Otherwise, flash of cutting section and edge will cause dent and scratches. Notes for curving:a. Minimize the area of flash of cutting edge, otherwise color coated steel sheet would be scratched in stock.b. Remove the flash and powder generated from cutting as soon as possible, or they will harm the surface of steel sheet and form the source of scratch and roasting.c. When cutting the color coated steel sheet, plastic roller should be adopted. Adding a rubber cushion to the surface of steel sheet could be a better choice for avoiding damage to surface. Notes for cutting: Outdoor: roof, roof structure, surface sheet of balcony, frame of window, door, door of garage, roller shutter door, booth,。
