有关铁路信号的英文翻译资料Railroad station interconnectionUsing the machinery，the electrical automatic control and remote control's technology and the equipment，cause in the station scope on the semaphore，the admission passage and the admission passage rail switch have the restriction relations mutually，this kind of relations are called the railroad station interconnection。
The outline railroad station interconnection is the railway signal important component。
in 1843 Britain first used the mechanical interlocking interconnection；in 1887 Japan developed successfully the interconnection box equipment；in 1904 the US started to use all-electric interlocking interconnection；in 1929 the US started to use following the electricity centralized interconnection。
Along with electronic accounting machine's development and the popularization，some countries started to use the computer interconnection at present。
铁路信号计算机联锁系统的毕业论文《铁路信号计算机联锁系统自动测试的构造探析》摘要：伴随着电子计算机技术的飞速发展，传统的6502电气集中联锁系统迅速地被计算机联锁系统取代，后者已然成为了未来车站联锁系统的主要发展方向。
自动测试作为这两年兴起的联锁软件测试方式，对比手动测试更有优势，本文将重点探析铁路信号计算机联锁系统自动测试的构造。
关键字：铁路信号；计算机联锁系统；自动测试；构造探析计算机联锁软件凭借其高效率、测试充分等特点成为了保证铁路列车和机车安全作业的重要软件，为了保障计算机联锁软件的高安全性我们必须对其进行安全测试。
目前我国使用的计算机联锁软件测试方法主要有手工测试和自动测试，两者相较，手工测试拥有测试效率低和测试不充分等缺点;而自动测试系统恰好能弥补手工测试的这些弊病，它测试效率高、所需人工少、测试时间短，并且能有效地消除联锁试验中产生的失误，减低了软件带来的风险性。
总的来说，自动测试具有简单化、需时少、效率高等优点。
一、铁路信号计算机联锁系统介绍作为指挥铁路列车作业和机车作业的信号命令，铁路信号必须保证列车的机车运行安全、提高运行效率。
铁路信号系统的发展可以追溯到蒸汽时代，随着科技的进步、时代的发展，铁路信号系统从最初的人工操作演变为机械运行、机电结合以及电气一体，再到如今的计算机联锁系统，可谓日新月异。
目前我国广泛使用的有两种铁路信号系统，一个是传统的6502电气集中联锁系统，一个便是计算机联锁系统。
以前由人工操作的铁路信号系统，其传递信息的方式便是通过信号员挥动各式各样的旗帜来显示机车运行情况。
这种信号传递方式不仅耗时耗力，传递的信息量还小，不能保证信号传递的准确性和实时性，早已经被时代的发展淘汰。
现代铁路信号系统是建立在网络通信技术、视频监控技术、计算机技术基础之上的，通过计算机控制实现的一种信号系统。
在这种系统中使用了信号连锁软件的控制规则，建立了包括火车轨道、道岔以及信号机组的室外基础设备，能够实现对铁路列车运行状况的全面掌控，有利于保证火车运行的安全。
