第一步、打印机组装FIRST STEP. PRINTER ASSEMBLY1、耗材托架的安装of Consumable Bracket 3D打印机操作手册3D PRINTERMANUAL NSTRUCTION上组图中，左图为耗材托架，右图为耗材托架的安装位置，安装位置在打印机后侧机盖上。
As shown above,left picture is consumable bracket,and the right picture is Installation location of the consumable bracket which is on the back of printer machine cover.2、送料管的安装of Transfer Material Pipeline上图所示位置在打印机后侧机盖上，白色的就是送料管，主要作用是为耗材提供输送通道。
快接头主要是用来固定送料管，防止送料管上下移动。
The installation which is shown above is on the back of printer machine cover,the white tube is the transfer material pipeline,it is designed for transfer the consumable. Quick connector is designed for fixed the transfer tube and prevent vertical movement.注：安装时送料管时，将送料管捅到底即可，插入长度约在一公分左右。
送料管的另外一端在安装好耗材之后进行安装，(后期如遇更换耗材或其他操作，需要将送料管拔出的情况时，需先将快接头上的塑料圈按下，之后才能将送料管拔出)。
Note:Please install the transfer material pipeline to the bottom of quick connector and it is about other end of the transfer material pipeline installed after the consumable installation.(If change the consumable or other operation,please press the plastic ring down before pull out the transfer material pipeline .)第二步、打印机平台调平SECOND PRINTER OPTICAL FLATNESS说明：打印机平台调平一次之后，一般情况下不用重复调平。
不过在运输过程中因为颠簸抖动，可能会导致平台的平整度发生变化，所以在使用之前建议先进行检查调平操作。
Instruction:Usually you do not need to adjust the optical flatness after first recommend to check the status caused by transportation.1、调平前准备1.Adjustment Ready.首先检查喷嘴，保证喷嘴外表面洁净，没有赘余的耗材等物。
如下图(左)所示，喷嘴处的赘余物可以用剪钳等工具剔除掉。
达到如下图(右)所示即可。
First checking the nozzle and make sure it’s clean on the shown below(Left),Use pliers and other tools to weed out the shown below(Right).2、控制打印机辅助调平Assist Adjust Level Control首先需要为3D打印机通电，3D打印机所使用的是普通220V家用电，直接接入即可。
该款3D打印机屏幕为触控屏幕，下图(左)为主界面，点击“工具”，选择“调平”如下图(右)。
Power ups the 3D printer first,3D printer use home voltage 220V.This 3D printer is touch screen model,The main menu as shown below(Left),Click the “TOOLS”,selecte“ADJUST MENT”as shown below (Right).随后会出现如下图(左)所示界面，点击“NEXT”，当喷头每次移动到一个微调螺母上方时，进行平台的微调，微调螺母如下图(右)所示。
Then click “NEXT”as shown below (Left),Adjust the platform when the nozzlemove to the location above the fine adjustment shown below(Right).平台上共分布着三个微调螺母，随着“NEXT”的点击，喷头会依次移动到微调螺母上方，每个点调节到如下图所示距离即可，或者可以将一张A4纸对折后，放在喷头和平台之间，调节时，适当抽拉纸张，纸张刚好可以轻松的抽出来的时候，说明喷头和平台的距离基本合适了。
也可以以玻璃平台上喷头的倒影和喷头实体之间的距离作为参照进行调节。
There distribute 3 fine adjust nuts,the nozzle will move above the nuts in turns,Adjust each of the regulatory point as shown below,Or fold a piece of A4 paper and place it between nozzle and you can draw out the paper gently,itproves the nozzle fit the basic platform.You can also Adjust it by the reflection on the glass platform sprinklers and nozzles entities as a reference.注：微调螺母的原理：微调机构由螺丝、蝶形螺母、弹簧三部分组成。
当螺母拧[紧]的时候,平台便会向[下]方移动，从而拉[远]喷头和平台的间距；当螺母拧[松]的时候，由于弹簧的弹性作用，便会将平台向[上]方顶起，从而拉[近]喷头和平台的间距；Note:Theory of fine adjustment nuts:Fine adjustment mechanism by screws, wing nuts, springs.Screwing the nuts,the platform will move down,it will pull away the distance between nozzle and platform.Loosening the nuts,the platform will move up,caused by spring action,it will shrink nearly the distance between nozzle and platform,第三步、耗材的安装及岀丝测试THIRD INSTALLATION AND TESTING EXTRUDER1、喷头加热NOZZLE通过打印机显示屏控制喷头加热，如下图(左)所示点击“预热”，随后出现如下图(右)所示界面。
Control heating nozzle by printer screen,Click the “Pre-Heating”as shownbelow(Left),it will display the follow interface,as shown below(Right).如上图(右)所示。
第一行为平台的温度控制选项，数字表示平台的“当前实际温度/设置温度”；第二行为喷头的温度控制选项，数字表示喷头的“当前实际温度/设置温度”；其中向上(向下)的箭头，分别表示提升(降低)温度。
现在需要将平台的“设置温度”设置到64度，将喷头的“设置温度”设置到205度。
如下图所示。
As shown above(Right).The first line are the platform temperature control options,the numbers shown on the screen are“TEMP/TEMP SETTING”;The second line are the platform temperature control options,the numbers shown on the screen are “TEMP/TEMP SETTING”;The UP and DOWN arrows stands for lifting and lowering the the platform temperature to 64℃,then set the nozzle temperature to 205 ℃。
As shown below.2、耗材的处理with Consumables将耗材从包装盒内取出后，将耗材的端部用剪钳剪出一个斜口，以便于耗材的送入。
另外耗材的端部约五公分的长度需略微的握直，也是便于耗材的送入。
如下图所示。
Taking the consumables out of the packaging box,and For insert easily ,cut out an incline on one side and straight grip around 5cm from the end of the other side.as shown below,将耗材挂在耗材托架上，然后将耗材从打印机后侧机盖的快接头下方送入如下图(左)所示。
耗材从送料卡下方送入，然后用手将送料卡捏住，如下图(右)所示。
之后将耗材继续向内穿入，直至从送料管的另外一端穿出。
Hang up the consumables on the bracket,then insert it to quick connector on the back of the printer. Insert the consumables across the back of transportation card,Pinch the transportation card,as shown below(Right).Insert the consumable until itpenetrate from the other side of the transportation pipeline.耗材从从送料管另外一端穿出后，将耗材从喷头上方的快接头处穿入，如下图（左）所示。
