DescriptionThe3500/22M Transient Data Interface(TDI)is the interfacebetween the3500monitoring system and compatiblesoftware(System1*Condition Monitoring and Diagnosticsoftware and3500System Configuration software).The TDIcombines the function of a3500/20Rack Interface Module(RIM)with the data collection capability of a communicationprocessor such as TDXnet.The TDI resides in the slot adjacent to the power supplies of a3500rack.It interfaces with M series monitors(3500/40M,3500/42M,etc.)to continuously collect steady state andtransient dynamic(waveform)data and pass this data throughan Ethernet link to the host software.Refer to theCompatibility section at the end of this document for moreinformation.Static data capture capability is standard with the TDI.However,using an optional Channel Enabling Disk will allowthe TDI to capture dynamic and high-resolution transient dataas well.The TDI incorporates the communication processorfunction within the3500rack.Although the TDI provides certain functions common to theentire rack,it is not part of the critical monitoring path andhas no effect on the proper,normal operation of the overallmonitor system for automatic machinery protection.Every3500rack requires one TDI or RIM,which always occupies Slot1(next to the powersupplies).3500/22M Transient Data Interface Module Product DatasheetBently Nevada*Asset Condition MonitoringSpecificationsInputsPower Consumption10.5WattsData Front Panel USB-B10Base-T/100Base-TX I/O 10Base-T or100Base-TX Ethernet,autosensing100Base-FX I/O100Base-FX Fiber-Optic Ethernet OutputsFront Panel LEDsOK LED Indicates when the3500/22M is operating properlyTX/RX LED Indicates when the3500/22M is communicating with the other modules in the rackTM LED Indicates when the3500rack is in Trip Multiply modeCONFIG OK LED Indicates that the3500rack has a valid configurationI/O Module OK RelayFunction Indicates when the3500rack is operating normally or when a fault has been detected within the er can select either an“OPEN”or“CLOSED”contact to annunciate a NOT OK condition.This relay always operates as “Normally Energized”.Ratings Standard OK Relay is rated to5A@24 Vdc/120Vac,120Watts/600VA Switched Power(maximum)OK Relay with gold-plated contacts is rated down to1mA@1Vdc(minimum)Arc Protection Arc suppressors are provided.ControlsFront PanelRack reset button Clears latched alarms and Timed OKChannel Defeat in the rack.Performssame function as“Rack Reset”contacton I/O moduleAddressswitchUsed to set the rack address:127possible addressesConfigurationKeylockUsed to place3500rack in either“RUN”mode or“PROGRAM”mode.RUN modeallows for normal operation of the rackand locks out configuration changes.PROGRAM mode allows for normaloperation of the rack and also allows forlocal or remote rack configuration.Thekey can be removed from the rack ineither position,allowing the switch toremain in either the RUN or PROGRAMposition.Locking the switch in the RUNposition allows you to restrictunauthorized rack reconfiguration.Locking the switch in PROGRAMposition allows remote reconfiguration ofa rack at any time.Part Number:161581-01I/O Module System ContactsTrip MultiplyDescription Used to place3500rack in Trip Multiply MaximumCurrent<1mAdc,Dry Contact to CommonAlarm InhibitDescription Used to inhibit all alarms in the3500rack MaximumCurrent<1mAdc,Dry Contact to CommonRack ResetDescription Used to clear latched alarms and Timed OK Channel DefeatMaximumCurrent<1mAdc,Dry Contact to CommonI/O Module Signal Common TerminalBoth versions of the TDI I/O Module now include a2-pin connector for connecting Signal Common to a single point Instrument Ground for the rack. When this is done,the selector switch on the side of the Power Input Module(PIM)must be slid in the direction of the arrow marked"HP"to isolate Signal Common from chassis(safety) ground.Data CollectionKeyphasor*Inputsl Supports the four3500system Keyphasor signals.The speed range support is based on the number ofdynamic channels enabled:Number of Channels MinimumSpeedMaximumSpeed1to161rpm100,000rpm 17to241rpm60,000rpm 25to481rpm30,000rpml Supports multiple events per revolution speed inputs up to20kHz Startup/Coastdown Datal Data collected at selected increments of speed and timel Increasing and decreasing speed intervals are independently programmablel Initiation of transient data collection based on detecting the machine speed within one of twoprogrammable windowsl The number of transient events that can becollected is only limited by the available memory inthe moduleAlarm Data Collectionl Pre-and post-alarm datal Static values collected at one second intervals for 10minutes before the event and1minute after theeventl Static values collected at100ms intervals for20 seconds before the event and10seconds after theeventl 2.5minutes of waveform data collected at10-second intervals before the alarm and1minute ofwaveform data collected at10-second intervalsafter the alarmStatic Values Datal TDI will collect the static values including the values measured by the monitors.l TDI provides four nX static values for each point.Amplitude and phase are returned for each of thevalues.Waveform Samplingl Collection of waveforms for48channels.l DC-coupled waveformsl Simultaneous Synchronous and Asynchronous data sampled during all operational modesl User-configurable Synchronous waveform sampling rates:o1024samples/rev for2revolutionso720samples/rev for2revolutionso512samples/rev for4revolutionso360samples/rev for4revolutionso256samples/rev for8revolutionso128samples/rev for16revolutionso64samples/rev for32revolutionsPart Number:161581-01o32samples/rev for64revolutionso16samples/rev for128revolutionsl Asynchronous data sampled to support an800-line spectrum at the following frequency spans:o10Hzo20Hzo50Hzo100Hzo200Hzo500Hzo1000Hzo2000Hzo5000Hzo10kHzo20kHzo30kHzl Asynchronous data is anti-alias filteredl Channel Pairs for providing Orbit or synchronous full spectrum presentations can be split among multiplemonitors.For asynchronous full spectrums thechannels must be within a monitor channel pair(30kHz frequency span data will not be phasecorrelated between channel pairs) CommunicationsProtocolsBN Host Protocol Communication with3500 Configuration Software,3500Data Acquisition Software,and3500Display SoftwareBN TDI Protocol Communication with System1* Condition Monitoring and Diagnostic SoftwareFront PanelCommunications USB-BProtocolSupportedBN Host ProtocolBaud Rate 115.2kbaud maximum (auto-baud capable)Cable Length USB Cable Length:5meters(16.4ft) maximum.A3meter(9.8ft)cable is included with the3500rackConnector USB-B10Base-T/100Base-TX Ethernet I/OCommunications Ethernet,10Base-T and100Base TX. Conforms to IEEE802.3Protocol Supported BN Host Protocol and BN TDI Protocolusing Ethernet TCP/IPConnectionRJ-45(telephone jack style)for10Base-T/100Base-TX EthernetcablingCable Length100metres(328feet)maximum100Base-FX Ethernet I/OCommunicationsEthernet,100Base-FX Fiber Optic,fullduplex multimode.Conforms toIEEE802.3uProtocolSupportedBN Host Protocol and BN TDI Protocolusing Ethernet TCP/IPConnectionMT-RJ Male Fiber Optic connector for100Base-FX cablingCable Length2000metres(6560feet)maximum,multimode fiber optic cableThe3500/22M has a MT-RJ Male connector on the unit forFiber Optic100Base-FX cabling therefore you MUST use aMT-RJ Female connector on the fiber optic cable to ensureproper connectivity.Environmental LimitsTDI Module,10Base-T/100Base-TX I/O,and100Base-FX I/OOperatingTemperature-30°C to+65°C(-22°F to+149°F)StorageTemperature-40°C to+85°C(-40°F to+185°F)Humidity95%,non-condensingBattery LifePowered TDI38years@50°C(122°F)Unpowered TDI12years@50°C(122°F)Part Number:161581-01Compliance and CertificationsNote:This device complies with part 15of the FCC Rules.Operation is subject to the following two conditions:(1)This device may not cause harmful interference,and (2)This device must accept any interference received,including interference that may cause undesired operation.EMCStandardsEN 61000-6-2Immunity for Industrial EnvironmentsEN 61000-6-4Emissions for Industrial EnvironmentsEuropean Community DirectivesEMC Directive 2014/30/EU Electrical SafetyStandards EN 61010-1European Community DirectivesLV Directive 2014/35/EUHazardous Area ApprovalsFor the detailed listing of country and product specificapprovals,refer to the Approvals Quick Reference Guide ,document 108M1756,at .CSA/NRTL/C (Approval Option -01Ex nC [L]IIC T4Gc Class I,Division 2,Groups A,B,C and D Class I,Zone 2AEx nC IIC T4Gc ClassI,Division 2Groups A,B,C and DT4@Ta =-20°C ≤Ta ≤+65°C (-4°F ≤Ta ≤+149°F)per drawing 149243ATEX/IECEx (Approval Option -02II 3GEx nA nC ic IIC T4Gc T4@-20°C ≤Ta ≤65°C (-4°F to 149°F)PhysicalTDI ModuleDimensions (Height x Width x Depth)241.3mm x 24.4mm x 241.8mm (9.50in x 0.96in x 9.52in)Weight 0.91kg (2.0lbs)I/O ModulesDimensions (Height x Width x Depth)241.3mm x 24.4mm x 99.1mm (9.50in x 0.96in x 3.90in)Weight 0.20kg (0.44lbs)Rack Space RequirementsTDI Module 1full-height front slot I/O Modules1full-height rear slotPart Number:161581-01Ordering InformationFor the detailed listing of country and product specificapprovals,refer to the Approvals Quick Reference Guide, document108M1756,at . Product Options and Part Numbers3500/22M TDI Module and I/O3500/22-AXX-BXX-CXXA:Transient Data Interface Type01Standard(use forstandard monitoringapplications)B:I/O Module Type0110Base-T/100Base-TXEthernet02100Base-FX(Fiber Optic)Ethernet0310Base-T/100Base-TXEthernet with gold-plated OK Relaycontacts04100Base-FX(fiber optic)Ethernet with gold-plated OK RelaycontactsC:Agency Approval Option00None01CSA/NRTL/C(Class1Div2)02Multi(CSA,ATEX,IECEx)350022M Dynamic Data Enabling Disk This disk enables the number of channels of dynamic data(i.e.,the ability to collect waveforms)that the TDI will support.There are two levels of dynamic data.Steady-State points are channels that collect waveform data due either to a software command or to an alarm event,and therefore support current values, scheduled waveform capture,and alarm data capture.Transient points provide all the function of a Steady-State point with the additional capability of waveform collection due to parameter variations such as machine speed. 3500/09-AXXX-BXXXA:Steady-State Points:0to672B:Transient Points:2to 672The sum of the two fields must be equal to or less than672.One disk can support multiple TDIs.Ethernet CablesStandard10Base-T/100Base-TX Shielded Category5Cable with RJ-45connectors(solid conductor)138131-AXXXA:Cable Length:006-6feet(1.8m)010-10feet(3.0m)025-25feet(12.2m)040-40feet(12.2m)050-50feet(15.2m)075-75feet(22.9m)085-85feet(25.9m)100-100feet(30.5m)120-120feet(36.6m)150-150feet(45.7m)200-200feet(61.0m)250-250feet(76.2m)320-320feet(97.m)Standard lengths for10Base-T/100Base-TX cabling are shown above.Part Number:161581-01Fiber Optic Cable100Base-FX fiber optic cable with MT-RJ female connectors.161756-AXXXA:Cable Length(in feet)up to1300ft(400m)010to500(10ft.to500ft.in 10ft.increments only)500to1300(500ft.to1300ft.in100ft.increments only)Spares288055-01Standard Transient Data InterfaceModule with USB cable100M283310foot A to B USB cable146031-0110Base-T/100Base-TX I/O Module 146031-02100Base-FX(Fiber Optic)I/O Module 161580-013500/22M TDI Operation andMaintenance Manual164466-01Network Accessories Datasheet 00580441Connector header,internaltermination,3-position,green00580436Connector header,internaltermination,6-position,green111M5777Connector header,internaltermination,2-position,green CompatibilityWhen upgrading your3500rack from a3500/20 RIM to a3500/22TDI,there may be3500M modules(e.g.3500/40M)that are not compatible with the3500/22.Please check with********************for additional details.Network RequirementsFor complete information on network requirements,refer to the3500Hardening Guide [106M9733].This document can be requested at .Part Number:161581-01Part Number:161581-01Graphs andFigures1:Main Module2:10Base-T/100Base TX (copper)Ethernet I/O Module 3:100Base-FX (fiber optic)Ethernet I/O Module 4:LEDs indicate operating status of the module 5:Hardware Switches6:USB Configuration Port for configuring or retrieving machinery data 7:OK Relay indicates the OK status of the overall rack 8:Signal Common external grounding terminal9:RJ-45Ethernet Port for configuration and data collection 10:System Contacts11:Fiber Optic Ethernet Port for configuration and data collectionFigure 1:Front and rear view of the Transient Data InterfaceCopyright2002-2018Baker Hughes,a GE company,LLC("BHGE")All rights reserved.*Denotes a trademark of Bently Nevada,LLC,a wholly owned subsidiary of Baker Hughes,a GEcompany.All product and company names are trademarks of their respective holders.Use of the trademarks does not imply any affiliation with or endorsement by the respective holders.The information contained in this document is subject to change without prior notice.1631Bently Parkway South,Minden,Nevada USA89423Phone:Part Number:161581-01。
