ESAComp详细2009

(13) SCHEDULE(14) to EC-Type Examination Certificate KEMA 09ATEX0048 Issue No. 4(15) DescriptionDifferential Pressure Transmitters DELTABAR M Model PMD55 and Pressure transmittersCERABAR M Model PMC51, Model PMP51 and Model PMP55 and DELTAPILOT M Model FMB50, Model FMB51, Model FMB52 and Model FMB53 are used in potentially explosive atmospheres caused by the presence of flammable gases, liquids, vapours or dusts for the measurement of level, flow, differential pressure, over- and under pressure.The pressure signal at the ceramic or metal sensor is converted into an electrical signal.The output of the Pressure or Differential Pressure Transmitter is a 4 - 20 mA current output signal with or without a superimposed HART digital signal, or the transmitter is intended to be connected to a fieldbus system (Profibus PA or Foundation Fieldbus).The several versions of the Pressure and Differential Pressure Transmitters differ in type of sensor, type of enclosure, process connection etc.Optionally all versions of the Pressure and Differential Pressure Transmitters may be provided with an indicator.Optionally, the display connector can be used for temporary connection of a service tool (e.g.Endress+Hauser Commubox type FXA191 or type FXA195).Optionally the Pressure Transmitters that are intended for application in explosive gas atmospheres, may be provided with a sensor with extension cable.Ambient temperature range -50 ºC to +70 ºC.The relation between temperature class, ambient temperature and process temperature is given in the following table.temperatureclassambienttemperatureprocess temperatureFMB50 FMB51 FMB52,FMB53PMD55 PMP55 1),PMC51, PMP51T6 ≤ 40 °C ≤ 80 °C ≤ 80 °C ≤ 80 °C ≤ 80 °C ≤ 80 °CT4 ≤ 70 °C ≤ 100 °C ≤ 85 °C ≤ 80 °C ≤ 120 °C ≤ 100 °C 2)T3 ≤ 70 °C ≤ 150 °CNOTE 1: Depending on the diaphragm seal used in model PMP55, a higher process temperature is permitted. For details, refer to the relevant equipment manual.NOTE 2: Process temperature for Models PMC51 and PMP51 with hygienic process connection ≤ 130 °C.. The maximum surface temperature of the enclosure T75 °C, respectively T500 100 °C (transmitters with interface 4 - 20 mA) or T500 105 °C (transmitters with Fieldbus interface) is b ased on the maximum ambient temperature of 70 °C for a dust lay er with a maximum thickness of 5 mm respectively 500 mm.(13) SCHEDULE(14) to EC-Type Examination Certificate KEMA 09ATEX0048 Issue No. 4Electrical dataTransmitters in type of protection intrinsic safety Ex iaInterface 4 - 20 mA (with or without HART communication):Supply and output circuit (terminals + and - or connector):in type of protection intrinsic safety Ex ia IIC, only for connection to a certified intrinsically safe circuit, with the following maximum values:U i = 30 V; I i = 300 mA; P i = 1 W; L i = 0 mH; C i = 10 nF.Interface Profibus PA or Foundation Fieldbus:Supply and data circuit (terminals + and - or connector):in type of protection intrinsic safety Ex ia IIC, only for connection to a certified intrinsically safecircuit, with the following maximum values:U i = 24 V; I i = 250 mA; P i = 1,2 W; L i = 10 µH; C i = 5 nF;or to an intrinsically safe fieldbus in accordance with FISCO, with the following maximum values: U i = 17,5 V; I i = 500 mA; P i = 5,5 W; L i = 10 µH; C i = 5 nF.Display connector:in type of protection intrinsic safety Ex ia IIC, for connection to a certified intrinsically safe circuit, with following maximum values:U o = 8,6 V; I o = 39 mA; P o = 124 mW andU i = 8,5 V; I i = 7 mA; P i = 10 mW; C i = 0 nF; L o = 0 mH.Transmitters in type of protection Ex tU max = 45 V (interface 4 - 20 mA), respectively 32 V (fieldbus interface).Installation instructionsThe instructions provided with the equipment shall be followed in detail to assure safe operation. (16) Test ReportNo. NL/KEM/ExTR09.0017/**.(17) Special conditions for safe useNone.(18) Essential Health and Safety RequirementsCovered by the standards listed at (9).(19) Test documentationAs listed in Test Report No. NL/KEM/ExTR09.0017/**.。

welding, cutting and more...High-vacuum extraction . KEMPER Dusty (27). Mini-Weldmaster (28). High-vacuum cartridge filter (29)· Accessories ............................... 30 - 31· High-vacuum extractionand filter unit (32)26Ultra light, flexible and powerful.These are only some properties of this small power pack.Two strong turbines provide an excellent extraction efficiencyand high static pressing. The minimum weight makes it veryflexible and universal for many different applications.A Kem Tex® ePTFE membrane filter cartridge provides thefiltration of superfine dust below 0.1 μm. Thereby this unitis suitable for the separation of alveole exchangeable dusts.The advantage of surface filtration is that the filtercartridge can be cleaned.In case of the Dusty, this happens manually in that minutewhen an essential cleaning will be indicated by theinstrument itself. The collected dust can be removed easilyfrom the lower part of the unit.Different nozzles, welding torches with integrated extraction ormini exhaust arms of the extensive accessory programme canbe connected to the two lugs of this extraction and filter unit.The extraction performance can be controlled steplessly andelectronically.For further accessories see pages 30/31. KEMPER DustyPart No.Description63 100KEMPER Dusty1.6 kW · 1 x 230 V / 50 HzVoltage: 1 x 230 V / 50 HzExtraction performance:340 m³/hMotor power: 1.6 kWNoise level:74 dB (A)Filter efficiency:> 99.9 %Weight:21 kgDimensions (w x d x h):300 x 300 x 690 mmTechnical dataPart No.Description10 902 44Spare filter for KEMPER DustySpare filter69mm300m m300mm₤1,197.00₤309.7027Mini-WeldmasterThis easy to transport high vacuum extraction and filterunit is ideal for the extraction of welding fumes at frequently changing work places.Extraction hoses with a diameter of 45 mm guarantee application at locations difficult to access.Various extraction nozzles with a magnetic foot are available.It is also possible to connect one or two welding torches with integrated extraction.The Mini-Weldmaster is equipped with a two stage filter and has a filter efficiency of 99.9 %. It is also possible to retrofit the unit with an activated charcoal filter. Cleaning of the filter inserts is not necessary.Depending on the actual operating time and the substances to be captured the filter has to be changed once or twice a year.A filter monitor indicates a necessary filter change.For more convenient handling a trolley with castor wheels and an automatic start-stop is available.For further accessories see pages 30/31.Part No.Description10 900 34Pre-filter mats, (10 per set)10 900 09Main filter10 900 08Activated charcoal filterSpare filtersVoltage:1 x 230 V / 50 Hz 3 x 400 V / 50 Hz Extraction performance:340 m³/h 270 m³/h Motor power: 1.6 kW 1.1 kW Noise level:71 dB (A)71 dB (A)Filter efficiency:> 99,9 % according to BGIA classification M Weight:24 kg 28 kgDimensions (w x d x h):340 x 450 x 660 mm 340 x 450 x 660 mmTechnical dataPart No.Description 91 730Mini-Weldmaster1.6 kW · 1 x 230 V / 50 Hz 91 730 100Mini-Weldmaster1.1 kW · 3 x 400 V / 50 Hz91 731Mini-Weldmaster with activated charcoal 1.6 kW · 1 x 230 V / 50 Hz91 731 100Mini-Weldmaster with activated charcoal 1.1 kW · 3 x 400 V / 50 HzUnits₤37.30116.40233.60₤1,330.002,659.001,563.002,893.0028With its four air intakes this mobile extraction and filter unit offers a flexible unit for the extraction of polluted air directly at source.It can be used on multiple operations in the metal working industry.The unit can be connected to exhaust nozzles, mini exhaust arms or shields with integrated extraction. The use of torches with integrated extraction makes it even more flexible.The robust extraction unit is supplied with two Kem Tex ® ePTFE membrane filter cartridges, which are monitored by the electrical control and – according to the saturation rate –cleaned automatically during operation.The extraction capacity can be controlled by a stepless adjustable speed control.For further accessories see pages 30/31.High-vacuum cartridge filter unit, mobilePart No.Description82 600High-vacuum cartridge filter unit, mobile 3.3 kW · 3 x 400 V / 50 Hz 94 102 600 02Sensor clamp for the automatic start-stopFan performance:max. 600 m³/h Motor power: 3.3 kW Amperage:7 APressure:20,000 PaVoltage:3 x 400 V / 50 Hz Filter efficiency:> 99,9 %(BGIA classification M)for info on filter cartridges see page 33Compressed air supply: 3.0 - 5.0 bar Weight:178 kg Dimensions (w x d x h):655 x 825 x 1,315 mm Noise level:70 dB (A)Technical dataPart No.Description 10 902 44Spare filter forhigh-vacuum cartridge filter unit, mobileSpare filter₤6,683.00495.60₤309.7029AccessoriesTrolleyPart No.Description91 750 200Trolley for Mini-Weldmaster incl. 4 guide rollers, with brakesExtraction hosePart No.Description93 070 004Extraction hose Ø 45 mm, length: 2.5 m 93 070 005Extraction hose Ø 45 mm, length: 5.0 m 93 070 006Extraction hose Ø 45 mm, length: 10.0 mSlit nozzle 300 mmPart No.Description23 200 08Slit nozzle, 300 mm, with magnetic footSlit nozzle 600 mmPart No.Description23 200 09Slit nozzle, 600 mm, with magnetic footFunnel nozzlePart No.Description23 200 10Funnel nozzle flexible, with magnetic footWelding shieldPart No.Description280 010 030Welding shield with integrated extraction₤49.9098.70191.10₤119.50₤128.80₤126.80₤101.80₤89.8030AccessoriesAdaptor for welding torchesFor connection with a hose, Ø 45 mm.Part No.Description10 600 71Adaptor for welding torches with integrated extraction 42 - 44 mm 10 601 04Adaptor for welding torches with integrated extraction 39 - 42 mm 10 600 84Adaptor for welding torches with integrated extraction 30 - 38 mmMini-Exhaust armPart No.Description91 350Exhaust arm, Ø 50 mm, length: 740 mm, without exhaust nozzle, swivelling to all directions, tubes made of aluminium,joints made of molded plastic incl. standard fixing device.Other exhaust arm diameters on request.Mounting bracketsPart No.Description93 008 001Table mounting bracket incl. two screw clamps 93 008 002Wall mounting bracket incl. screws and rawlplugsNozzlesPart No.Description232 0002Slit nozzle, width 200 mm 232 0004Tube nozzle, Ø 50 mm232 0005Plexiglass nozzle, 245 x 220 mm232 0006Funnel nozzle, round, extraction hole Ø 210 mm₤7.307.307.30₤220.20₤44.5032.50₤54.9019.1068.4064.2031High-vacuum extraction and filter unitPart No.:91 0100 20091 0200 20091 0300 200Filter cartridges:Kem Tex ®ePTFE-membrane filter for surface filtration Filter efficiency:> 99.99 % according to BGIA classification L, M Filter efficiency:For alveole exchangeable dusts see page 33Extraction performance:3,300 m³/h 4,000 m³/h 4,500 m³/h Pressure:18,000 Pa 18,000 Pa 20,000 Pa Motor power:22.0 kW 30.0 kW 37.0 kW Voltage:3 x 400 V / 50 Hz 3 x 400 V / 50 Hz 3 x 400 V / 50 Hz Compressed air supply: 5.0 to 6.0 bar 5.0 to 6.0 bar 5.0 to 6.0 bar Weight:1,050 kg 1,150 kg 1,350 kg Dimensions (w x d x h):2,375 x 1,413 x 2,015 mm 2,826 x 1,413 x 2,015 mm 3,277 x 1,413 x 2,015 mmTechnical dataHigh-vacuum extraction and filter units of the system 9000are very suitable for the connection of several extraction elements and for the construction of central extraction systems for welding workshops, grinding shops or the like.The extracted harmful substances will be separated at the surface of the Kem Tex ® ePTFE membrane filter. The control,based on a Siemens Simatec S7, monitors the collected dust on the surface of the cartridges. On reaching a certain limit it automatically activates the cleaning process during operation of the unit.The robust filter unit, contructed of reinforced steel panels,consists of two parts being connected on site.The following table gives an overview of the standard units.Units with higher outputs are available.For further information on extraction and filtration unitssystem 9000 see pages 70 to 82.32Due to the Kem Tex ® ePTFE membrane filter the KEMPER extraction and filtration systems act as reference for all extraction units.KEMPER extraction and filtration systems are yet efficient where other filtration units are no longer able to filter even the smallest particles. Especially the range of particle sizes smaller than 0.4 μm is very important for the filtration of dusts generated during welding and cutting processes. Because the particles below 0.4 μm are alveole exchangeable.Pulmonary alveoli are the smallest units in the human lung where oxygen is exchanged between the inhaled air and the human blood. Particles reaching the pulmonary alveoli can also diffuse into the bloodstream, form deposits all over the body and, depending on the chemical structure of the particles, can cause cancer.It is absolutely essential for extraction and filtration systems to filter even those finest particles since it is the only possibility to protect your employees and yourself against serious diseases.The BGIA (German government safety organisation) tests on the particle size distribution of welding smoke has shown the following results (E308-16).The Kem Tex ® ePTFE membrane filters can filter particles smaller than 0.4 μm, which represent 98.9 % of the total dust particles, according to BGIA tests.The effective pore size of the Kem Tex ® ePTFE membrane filter is that small, that even particles with 0.1 μm already will be filtered up to 92 %. The equal zero-emission of the Kem Tex ®ePTFE membrane surpasses all current regulations even for superfine particles. Especially with superfine dusts theKem Tex ® ePTFE membrane filters prevent a penetration of the particles.Kem Tex ® ePTFE membrane filters are therefore the ultimate technology concerning all applications. They are yet efficient where conventional filters of the filter class “M” reach their limit. About 90 % less particles reach the air in comparison with conventional filters.Trust in the experience of KEMPER and keep your air clean with Kem Tex ® ePTFE membrane filters!KemTex ® ePTFE membrane filterParticles Ø in μm <0.2<0.4<0.6<0.8<1.0>1.0Quantity 8002519012% of the quantity 75.323.60.900.10.2% of the mass15.938.77.58.229.733Your distributor:P a r t N o . 691 2440-3 · P r i n t e d o n e c o l o g i c a l l y b e n e fi c i a l p a p e r .All prices are exclusive of the current VAT.Priced catalogue items will be delivered carriage paid, within the EU (mainland),incl. packaging. For orders below a net price of £400.00, a standard carriage charge of £15.00ex. VAT, for packaging, insurance and carriage will be raised.All orders are subject to our conditions of sale.Price and technical specifi cations are subject to change without notice. We do not accept any liability for misprints. With the publication of this price list, all former price list loose there validity.The technical specifi cations stated in our catalogue are subject to change withoutnotice. This catalogue is protected by copyright and remains our property.This catalogue can be reclaimed at anytime.Reprints, or partial reprints can only beaccepted with written authorisation by KEMPER .KEMPER (U.K.) Ltd. · Venture Court · 2 Debdale Road · Wellingborough · Northamptonshire NN85AA·Tel.01327872909·Fax01327872181·**************.uk·。

百科特奥品牌除湿机机型归类总结百科特奥品牌中心，环境湿度控制技术专家，专业从事干燥通风空气处理，除湿、加湿、消毒、防潮等开发、生产，从业10余年的专业技术团队，专业设计生产除湿机，家用除湿机，工业除湿机，防爆除湿机，防爆空调，特种除湿机，百科特奥品牌中心，引进来自日本的先进的室内环境湿度控制技术和生产工艺，为你提供打造干燥舒适的室内空间环境的优质除湿机，百科特奥除湿机，具有外形高雅大方，设计新颖和具有安装维修方便等特点，百科特奥除湿机采用丹甫斯、松下、日立、大金、三菱等名牌压缩机、微电脑控制、噪声低、湿度显示、直观了然、性能优越、操作简便等众多优点。

家用、实验室、库房、车间、档案室等场所防潮除湿，抽湿袪霉，袪霉杀菌，袪霉净化最佳的选择！百科特奥除湿机执行标准：国家GB4706.32-2012、GB4706.1-2005，GB4343.1-2009，GB17625.1-2012标准，2013年10月起开始执行！百科特奥家用除湿机系列特点及参数：1.全塑设计，美观大方 2.移动万向轮，轻便放置 3.无触点水位开关，水满自动报警 4.3公斤的水箱，水满自动停机 5.自动除霜 6.环保家用型，名牌往压缩机（丹甫斯）型号除湿面积除湿量规格DH-820B 机械型20-35M2 20升/天310*280*580(mm) DH-818E 液晶型20-35M2 18升/天613×345×245(mm DH-826E 液晶型20-40M2 26升/天613×345×245(mm DH-826D 液晶型20-40M226升/天310*280*580(mm) DH-838E数码型40-65m2 38升/天440×330×640(mm) DH-858E数码型60-90m2 58升/天440×330×640(mm)百科特奥商用除湿机系列特点及参数：往复式压缩机，旋转式压缩机，脚底装有四角万向轮，可以移动自如、上前吹式出风口，下前进风口、数字显示，湿度自由控制、自动化霜功能、在环境温度低于18度一下自动化霜（合资品牌：蓝海压缩机，日立压缩机）型及号除湿面积除湿量规格DH-838D 液晶型40-65m2 38升/天440*330*640(mm)DH-858D 液晶型60-90m2 58升/天440*330*640(mm)DH-890C 数码型90-130m2 90升/天420*480*960(mm)DH-890D 液晶型90-130m2 90升/天420*480*960(mm)DH-8138C 数码型100-160M2138升/天420*480*1030(mm)DH-8138D 液晶型100-160M2138升/天420*480*1030(mm)百科特奥工业除湿机系列特点及参数：采用国际名牌大金压缩机、三菱压缩机，脚底装有四角万向轮，可以移动自如、上前吹式出风口、正前出风口，下前进风口、数码显示，湿度自由控制、自动化霜功能、在环境温度低于18度以下自动化霜北京除湿机专卖，顺义除湿机，海淀除湿机，大兴除湿机，百科特奥朝阳除湿机专卖型号除湿面积除湿量规格DH-8150C 数码型150-230m2 150升/天500*600*1020(mm) DH-8150D 液晶型150-230M2 150升/天600*600*1020(mm) DH-8168C 数码型200-280M2 168升/天405*605*1620(mm) DH-8168D 液晶型200-280M2 168升/天650*600*1950(mm) DH-8192C 数码型260-320M2 192升/天405*605*1620(mm) DH-8240C 数码型300-400M2 240升/天470*770*1700(mm) DH-8360C 数码型400-600M2360升/天520*1200*1745mm DH-8480C 数码型600-800M2480升/天520*1200*1745mm百科特奥除湿机产品型号详解：DH是除湿机英文单词：Dehumidifevs的缩写，8是我公司所有除湿机的序列编号的通用字（8喻意谐音发财），8后面的数字代表除湿机的24小时标准工况（温度30°，湿度RH80%）的除湿量，B、C、D、E只是做了产品的开发先后顺序的区分。

TERMS USED IN THE TABLESON PAGES 26 TO 31GENERAL SPECIFICATIONSUSED PRICESAirplane and some helicopter selling prices are based on the latest available edition of the Aircraft Bluebook Price Digest. Additional helicopter pricing data isfrom HeliValues.TYPICAL CREW/PASSENGER SEATINGThis is the typical crew and passenger seating on the aircraft, not the maximum certified seats. These numbers mayvary for different operations (corporate, commercial, EMS, etc.). Maximum number of passengers are as certified.CABIN DIMENSIONSCabin height, width and length are based on a completed interior. On “cabin-class”aircraft, the length is measured from the cockpit divider to the aft pressure bulkhead (or aft cabin bulkhead, if unpressurized). For small-cabin aircraft, the distance is from the cockpit firewall to the aft bulkhead. Height and width are the maximum within that cabin space.Cabin volume is the interior volume,with headliner in place, without chairsor other furnishings.WEIGHTSMaximum takeoff weight is specified during aircraft certification.Fuel capacity is in gallons based on6.7 pounds per gallon (jet fuel). Maximum payload with full fuel is the useful load minus the usable fuel. The useful load is based on the maximum ramp weight minus the basic operating weight.PRODUCTION STARTED/ENDEDYear of the first delivery to the yearof the last serial number delivery.NUMBER BUILTTotal number produced, which may include converted aircraft.PERFORMANCE SPECIFICATIONS JET and TURBOPROP RANGEThe maximum IFR range with all passenger seats occupied. This uses the NBAA IFR alternate fuel reserve calculation for a 200-nm alternate. HELICOPTER RANGEThe maximum VFR range of the aircraft with all passenger seats occupied. This is used for all helicopters.CRUISE SPEEDMax (ktas) is the maximum cruise speed at maximum continuous power. This is also commonly referred to as high-speed cruise.Normal cruise speed is the recommended cruise speed established by themanufacturer. This speed may be the same as maximum cruise speed.SERVICE CEILINGFor airplanes, this is the highest altitude at which a 100-fpm rate of climb is possible at maximum takeoff weight with all engines running. For helicopters, this is the maximum certified altitude for operation.BALANCED FIELD LENGTH (BFL) – AIRPLANES ONLYBFL is the distance obtainedby–determining the decision speed (V 1) at which the takeoff distance and the accelerate-stop distance are equal(multi-engine aircraft only). This is based on four passengers and maximum fuel on board (turbine aircraft). BFL is based on a dry level runway, no wind, NBAA IFR reserves and 86 degrees NDING DISTANCE–AIRPLANES ONLY This is computed using the landing distance from 50 or 35 feet above the ground (depends on certification criteria) multiplied by 1.667. No credit is given for thrust reversers. Configuration is with four passengers and NBAA IFR fuel reserve on board.*Notes:1. All personal very light jets have one engine. All other jets listed have two engines.2. All personal very light jets, compact very light jets and other jets marked with an asterisk (*) are approved or planned to be approved for operation by one pilot. The maximum passenger seating of these aircraft there-fore includes one passenger in the right seat in the cockpit. Seating for all other aircraft assumes a two-pilot crew and maximum “typical” executive seating. In corporate shuttle configurations, the Airbus and Boeing bizliners may be configured with many more seats than indicated in the table.3. The cabin volumes of the personal and compact very light jets include the cockpit, because their small sizes preclude having a fixed divider between cockpit and cabin.4.Aircraft are listed in order of cabin volume first, followed by maximum takeoff weight, if cabin volumes are equal.5. By convention only, very light jets have maximum takeoff weights under 10,000 pounds.6. By FAA certification rules, all airplanes with maximum takeoff weights above 12,500 pounds are considered “heavy airplanes” and must be certified to stricter FAR Part 25 air transport category rules. Airplanes weigh-ing less than 12,500 pounds are considered “light airplanes” and may be certified under less-stringent FAR Part 23 rules, though by manufacturer choice some are certified to Part 25. With FAA approval, a company may apply to certify a multi-engine airplane weighing up to 19,000 pounds using Part 23 commuter catego-ry rules. The Emivest SJ30 and Hawker Beechcraft Premier II fall into this group.THE CESSNA MUSTANG, WHICH HAS A 210-CUBIC-FOOT CABIN, IS ASSIGNED TO THE “COMPACT VERY LIGHT JETS” CATEGORY.。

Table of Contents!WARNING - USER RESPONSIBILITYFAILURE OR IMPROPER SELECTION OR IMPROPER USE OF THE PRODUCTS DESCRIBED HEREIN OR RELATED ITEMS CAN CAUSE DEATH, PERSONAL INJURY AND PROPERTY DAMAGE.This document and other information from Parker Hannifin Corporation, its subsidiaries and authorized distributors provide product or system options for further investigation by users having technical expertise.The user, through its own analysis and testing, is solely responsible for making the final selection of the system and components and assuring that all performance, endurance, maintenance, safety and warning requirements of the application are met. The user must analyze all aspects of the application, follow applicable industry standards, and follow the information concerning the product in the current product catalog and in any other materials provided from Parker or its subsidiaries or authorized distributors.To the extent that Parker or its subsidiaries or authorized distributors provide component or system options based upon data or specifications provided by the user, the user is responsible for determining that such data and specifications are suitable and sufficient for all applications and reasonably foreseeable uses of the components or systems.OFFER OF SALEThe items described in this document are hereby offered for sale by Parker Hannifin Corporation, its subsidiaries or its authorized distributors. This offer and its acceptance by the provisions stated in the detailed ‘Offer of Sale’ which is available upon request.Global PartnershipsGlobal SupportParker is committed to helping make our customers more productiveand more profitable through our global offering of motion and control products and systems. Inan increasingly competitive global economy, we seek to develop customer relationships as technology partnerships. Working closely with our customers, we can ensure the best selection of technologies to suit the needs of our customers’ applications.Electromechanical Technologies for High Dynamic Performance and Precision MotionParker electromechanical technologies form an important part of Parker’s global motion and control offering. Electromechanical systems combine high performance speed and position control with the flexibility to adapt the systems to the rapidly changing needs of the industries we serve.Parker HannifinThe global leader in motion and control technologies and systemsParker Hannifin is a Fortune 250 global leader in motion and controltechnologies. For more than a century the company has been enablingengineering breakthroughs that lead to a better tomorrow. Learn more at or @parkerhannifinAbout Parker Hannifin CorporationRange Overview 1 HP - 2000 HPWith more than 30 years of worldwide application experience, Parker assists its customers in improving productivity and reducing energy consumption with a comprehensive, robust range of DC drives and drive systems. Parker DC drive products are sold, supported and serviced worldwide, with solutions from simple speed control to complex multi-motor coordinated process control. Parker DC drive products are easy to configure and commission, with simple but flexible function block-based configuration tools and connectivity with all major industrial fieldbus networks.Digital DC Drives Maximize Flexibility and Functionality Using the same 32-bit control architecture as our current range of AC drive products, Parker’s range of digital DC drives provides the same high level of functionality - and with it flexibility and performance - as comparable AC drive systems, while simultaneously allowing the user to integrate both AC and DC drive systems in a single machine with the same interface and software.Retrofit Existing Applications with the Latest TechnologyBy retrofitting existing DC motor applications with Parker digital DC drives, the user can avoid the cost of replacing an existing functioning, DC motor with a similar AC drive system, while still enjoying the benefits of a flexible control platform and high performance drive.DC590+ Integrator Series 2 Digital DC DriveThe DC590+ uses an advanced control platform to provide high levels of flexibility and performance for a wide range of applications. Designed for machine integrators, the DC590+ features function block programming, multiple communications and feedback options and support worldwide. Available as non-regenerative or full fourquadrant regenerative. Available from 1-2400A maximum. Fieldbus options include Profibus-DP, CANopen, Modbus RTU, Ethernet and DeviceNet.Typical applications include •Converting machinery •Hoists and cranes•Plastics processing machinery •Wire and cable manufacturing •Automotive test standsProcessSimple2400A35A15ADC Drives Product Range OverviewGlobal DC Drive Solutions to Maximize Flexibility and Increase performanceDRV Package - “Ready to Install” DC DrivesSave design time, panel space and the time and cost of component sourcing and installation with Parker’s unique DRV drive format. DRV drives include all peripheral power components typically required in a DC drive system, integrated in a self-contained package. This packagecontains the additional components within the footprint of the standard drive module and saves significant panel space while reducing complexity and improving the appearance.01010010002000HPSystems•Conveyors, basic speed control•Packaging machinerySingle Phase Two Quadrant Analog Isolated Converter: 512CThe 512C provides effective torque and speed control of permanent magnet or wound field DC motors. Extremely linear speed and current loops in an isolated package, ideal for single or multiple motor applications up to 32A (10 HP at highest input voltage).Typical applications include:•Centrifugal fans and pumps•Extruders and mixers•Small paper converting machinesSingle Phase Four Quadrant Analog Isolated Converter: 514CThe 514C offers full four quadrant regenerative control of permanent magnet or wound field DC motors. Ideal for applications requiring accurate or rapid deceleration of high inertia loads. Effective for single or multiple motor applications to 32A (10 HP at highest input voltage). Typical applications include:•Machine tool spindles•Wire drawing machines•Winders/Reelers 010*******2000 HP 010*******2000 HP 010*******2000 HPAnalog DC Drives RangeSingle Phase Analog Non-Isolated Converter:506/507/508Economical, compact torque and speed control of permanent magnet or shunt wound DC motors. Selectable between110VAC or 230VAC single phase supply. Tachometer or armature voltage feedback, 3, 6, or 12A armature options.Typical applications include:DescriptionThe 506, 507 and 508 series drives break new ground in cost-effective DC motor control. Available in 3, 6 or 12A armature ratings, the feature packed minimum footprint design is ideal for speed or torque control of permanent magnet or shunt wound DC motors fed from single phase supplies.Typical applications include:•Fans and pumps •Conveyors•Packaging machineryLow cost high featured design IP20 protected coversCompact footprint and DIN rail mounting Selectable 110V or 230V supplySelectable tach or armature voltage feedbackStandardsMarkedEN61800-3 (EMC) with external filterEN50178 (safety, low voltage directive)andTechnical SpecificationAnalog DC Drives506/507/508 SeriesUp to 2 HP/12ADimensions (in/mm)Note: Color of enclosure may vary from illustration(UL applies to 506 and 507 only)DescriptionIsolated control circuitry, a host of features, and extremely linear control loop make the 512C ideal for single motor or multi-drive applications. The 512C is suitable for controlling permanent magnet or field wound DC motors in speed or torque control, and can be used “open loop” with armature voltage feedback, or with DC tach feedback for enhanced regulation and speed range. Chassis mount, IP00 rating. Typical applications include:•Centrifugal fans and pumps •Extruders and mixers •ConveyorsTechnical SpecificationsAnalog DC Drives512C SeriesUp to 32AStandards:MarkedEN61800-3 (EMC) with external filterEN50178 (safety, low voltage directive)Common Specifications: 512C and 514CVoltage Ratings:Dimensions (in/mm):DescriptionThe regenerative 514C DC drive offers full four quadrant control of DC motors from single phase supplies. As such it is ideal for applications involving overhauling loads or where rapid and accurate deceleration is required. 514C can be used “open loop” with armature voltage feedback, or with DC tach feedback for enhanced regulation and speed range. Chassis mount, IP00 rating. Typical applications include:•Machine tool spindles •Wire drawing machines •Winders/ReelersTechnical SpecificationAnalog DC Drives514C SeriesUp to 32ANote: Color of front panel may vary from illustrationDrive mounted on a “footprint” filterEMC Filtersfor AC and DC DrivesDescriptionA range of pre-selected EMC (Electromagnetic Compatibil-ity)/RFI (Radio Frequency Interference) Filters are avail-able, suitable for all drives. These filters are a cost effective and easily implemented solution for the abatement of EMC in order to meet certain directives. Installation of the drive must be in accordance with the installation guidelines in the product manual.Filters described as “footprint” type are designed to save panel space by mounting behind the drive.Ordering© 2021 Parker Hannifin Corporation. All rights reserved.Parker Hanni f in CorporationElectronic Motion and Controls DivisionTel: (800) 358-9070emn.service @ AE – UAE, Dubai Tel: +971 4 8127100 ********************AR – Argentina, Buenos Aires Tel: +54 3327 44 4129AT – Austria, Wiener Neustadt Tel: +43 (0)2622 23501-0 *************************AT – Eastern Europe, Wiener NeustadtTel: +43 (0)2622 23501 900 ****************************AU – Australia, Castle Hill Tel: +61 (0)2-9634 7777AZ – Azerbaijan, Baku Tel: +994 50 2233 458****************************BE/LU – Belgium, Nivelles Tel: +32 (0)67 280 900*************************BR – Brazil, Cachoeirinha RS Tel: +55 51 3470 9144BY – Belarus, Minsk Tel: +375 17 209 9399*************************CA – Canada, Milton, Ontario Tel: +1 905 693 3000CH – Switzerland, Etoy Tel: +41 (0)21 821 87 00*****************************CL – Chile, Santiago Tel: +56 2 623 1216CN – China, Shanghai Tel: +86 21 2899 5000CZ – Czech Republic, Klecany Tel: +420 284 083 111*******************************DE – Germany, Kaarst Tel: +49 (0)2131 4016 0*************************DK – Denmark, Ballerup Tel: +45 43 56 04 00*************************ES – Spain, Madrid Tel: +34 902 330 001 ***********************FI – Finland, Vantaa Tel: +358 (0)20 753 2500 *************************FR – France, Contamine s/Arve Tel: +33 (0)4 50 25 80 25 ************************GR – Greece, Athens Tel: +30 210 933 6450 ************************HK – Hong Kong Tel: +852 2428 8008HU – Hungary, Budapest Tel: +36 1 220 4155*************************IE – Ireland, Dublin Tel: +353 (0)1 466 6370 *************************IN – India, MumbaiTel: +91 22 6513 7081-85IT – Italy, Corsico (MI) Tel: +39 02 45 19 21 ***********************JP – Japan, Tokyo Tel: +81 (0)3 6408 3901KR – South Korea, Seoul Tel: +82 2 559 0400KZ – Kazakhstan, Almaty Tel: +7 7272 505 800****************************LV – Latvia, Riga Tel: +371 6 745 2601 ************************MX – Mexico, Apodaca Tel: +52 81 8156 6000MY – Malaysia, Shah Alam Tel: +60 3 7849 0800NL – The Netherlands, OldenzaalTel: +31 (0)541 585 000 ********************NO – Norway, Ski Tel: +47 64 91 10 00************************NZ – New Zealand, Mt Wellington Tel: +64 9 574 1744PL – Poland, Warsaw Tel: +48 (0)22 573 24 00 ************************PT – Portugal, Leca da Palmeira Tel: +351 22 999 7360**************************Parker WorldwideRO – Romania, Bucharest Tel: +40 21 252 1382*************************RU – Russia, Moscow Tel: +7 495 645-2156************************SE – Sweden, Spånga Tel: +46 (0)8 59 79 50 00 ************************SG – Singapore Tel: +65 6887 6300SK – Slovakia, Banská Bystrica Tel: +421 484 162 252**************************SL – Slovenia, Novo Mesto Tel: +386 7 337 6650**************************TH – Thailand, Bangkok Tel: +662 717 8140TR – Turkey, Istanbul Tel: +90 216 4997081 ************************TW – Taiwan, Taipei Tel: +886 2 2298 8987UA – Ukraine, Kiev Tel +380 44 494 2731*************************UK – United Kingdom, WarwickTel: +44 (0)1926 317 878 ********************US – USA, Cleveland Tel: +1 216 896 3000VE – Venezuela, Caracas Tel: +58 212 238 5422ZA – South Africa, Kempton ParkTel: +27 (0)11 961 0700*****************************。

1455KleppeLane|Sparks,NV89431|[p]775.359.4712|[f]775.359.7424|[e]***************||4March,2009 DISCLAIMER: Continued product improvements make specifications subject to change without notice. Check for the latest product information and updates.09/08Model 3202/3202G Page 1 of 4 No. 2077328(20)1455 Kleppe Lane HAWS AG Bachweg 3 CH-3401 Burgdorf SwitzerlandHaws Mfg. Pte Lt. 2A Sungei Kadet Drive Singapore 729554Avlis-Avenido Senador, Testonio Vilela 505 Jardim Aeroporto Itu, S.P. 13304-550 BrasilE-mail: *************** website: Model 3202/3202G Drinking Fountain LIMITED WARRANTYHAWS ® warrants that all of its products are guaranteed against defective material or poor workmanship for a period of one year from date of shipment. HAWS liability under this warranty shall be discharged by furnishing without charge F.O.B. HAWS Factory any goods, or part thereof, which shall appear to the Company upon inspection to be of defective material or not of first class workmanship, provided that claim is made in writing to company within a reasonable period after receipt of the product. Where claims for defects are made, the defective part or parts shall be delivered to the Company, prepaid, for inspection. HAWS will not be liable for the cost of repairs, alterations or replacements, or for any expense connected therewith made by the owner or his agents, except upon writtenauthority from HAWS, Sparks, Nevada. HAWS will not be liable for any damages caused by defective materials or poor workmanship, except for replacements, as provided above. Buyer agrees that Haws has made no other warranties either expressed or implied in addition to those above stated, except that of title with respect to any of the products or equipment sold hereunder and that HAWS shall not be liable for general, special, or consequential damages claimed to arise under the contract of sale. The drinking fountain manufactured by HAWS is warranted to function if installation and maintenance instructions provided are adhered to. The units also must be used for the purpose for which they were intended. NO OTHER WARRANTIES EXPRESSED OR IMPLIED ARE AUTHORIZED, PROVIDED OR GIVEN BY HAWS.NOTE TO INSTALLER: Please leave this information with the Maintenance Department. SHOULD YOU EXPERIENCE DIFFICULTY WITH THE INSTALLATION OF THIS MODEL, PLEASE CALL: 1-800-766-5612 FOR PARTS CALL: 1-800-758-9378(U.S.A. AND CANADA ONLY) MONDAY-THURSDAY: 6:00 A.M. – 4:00 P.M. PSTFRIDAY: 6:00 A.M – 1:00 P.M. PSTRECOMMENDED TOOLS: Hack saw, pipe joint sealant, screwdriver, level, 12" adjustable wrench, 10" pipe wrench, 5/64“ hex key wrench, 9/16”, 1/2", 7/16” socket wrench or open end wrench.LOCATION OF UNIT: The Model 3202/3202G Drinking Fountain is a wheelchair accessible drinking water facility. The height dimensions shown, meet current ADA requirements. When installing this unit, local, state or federal codes should be adhered to. If height other than shown is required, then dimensions must be adjusted accordingly.SUPPLY LINE: The minimum recommended line size is 1/2“IPS with 30-90 psi (2-6 ATM) pressure. Where sediment or mineral content is a problem, an inlet filter is recommended. PLUMBING CONNECTIONS: Inlet is 1/4" IPS male fitting.MAINTENANCE: Periodically clean the strainer. Refer to 5874 Valve Manual for more information.TROUBLESHOOTINGPROBLEM REPAIR CHECKLIST1. Insufficient bubbler flow. 1a. Check that inlet screwdriver stop valve is inwide-open position.b. Verify minimum 30 psi flowing supplypressure.c. Clean strainer. See 5874 Valve Manual.d. Adjust valve to increase flow. Use frontadjust screw or see 5874 Valve Manual.© 2006 Haws® Corporation – All Rights ReservedHAWS® and other trademarks used in these materials are the exclusive property of Haws Corporation. 09/08 Model 3202/3202G Page 2 of 4。
