BIM技术在给水排水工程中的应用作者：范海庆来源：《中国房地产业》 2019年第14期文/ 范海庆山东源达建设发展有限公司山东济南 250014【摘要】给水排水工程的质量直接影响建筑工程的总体质量。
因此，必须要加强对给水排水工程的质量控制，特别是在设计环节，要选择先进的设计软件进行工程设计，以确保给水排水工程的顺利施工。
近年来，BIM技术被广泛运用于给水排水工程设计中，而且优势较为明显，大大提高了给水排水工程设计水平，对建筑工程总体质量的提高具有十分积极的意义。
【关键词】BIM 技术；给水排水工程；应用1、BIM 技术概述BIM 新技术的应用基础是将每一个构件都看作是单一的元素，是将元素中的几何数据、物理特性、施工要求、价格等进行有效的整合，进而实现对建筑模型的整体数据化，并将此数据化的建筑模型进行整理，形成有效的数据资料库。
对建筑物构件进行数据的整合，能够有效的实现对各个建筑元素几何特征的及物理特性的反映，每个元素还同时能够保留自身与建筑整体的相互联系，实现了建筑系统的完整性及层次性。
建筑工程中给水排水设计具有一定的流程，即方案阶段、设计阶段、施工阶段以及运营阶段。
在此整个流程中，其与建筑自身的寿命周期相一致，当前，BIM 技术在建筑给水排水设计中的应用主要在方案设计阶段及施工阶段。
在设计阶段中，所应用到的BIM 技术主要是BIM 设计软件以及辅助设计软件，而在施工阶段中对BIM 技术的应用主要是施工方案组织及工程量计算。
2、BIM 技术的特点和应用优势2.1 技术特点第一，可视化。
随着建筑行业的快速发展，建筑工程的设计方案更加复杂，会影响施工技术人员的想象和理解。
基于BIM 技术下，促使线条式的构件转变为三维立体实物，一方面方便施工人员读图识图，另一方面加强了构件之间的互动性和反馈性。
如此一来，不仅有利于生成报表和效果图，而且项目设计、施工、运营等均处于可视化状态下。
第二，协调性。
建筑施工是一个多方参与的过程，主要包括业主方、设计方、施工方、监理方，如何协调各方利益和关系，成为施工管理的一个重要问题[1]。
