华为RH2288H-V3服务器产品介绍

产品规格一览表项目名称：中牟县司法局社区矫正远程视频督察系统项目（社区矫正管理指挥平台及远程视频督察系统）序号货物名称品牌型号规格参数原产地制造商单位数量1高速扫描仪富士通FI-7125-SFADF高速扫描仪；纸张大小：最小A8，最大A4；图像传感器：彩色CCD×2（(正面x1，背面x1)；光源：白色LED×2；光学分辨率：50—600dpi（以1dpi增量进行变化）；扫描速度：ADF：彩色25ppm/50ipm黑白灰度30ppm/60ipm；卡片扫描：一次可扫描3张塑料卡片或者二代身份证。

ADF容量：80张上海富士通电子元器件（上海）有限公司台12二代身份证阅读器新中新F200A-SF调制方式：ASK或BPSK；与卡片的通讯速率：不低于106Kbit/s；最大读卡距离：不小于30mm；供电电源：USB供电；接口：USB2.0兼容USB1.1或以上；使用平台：WIN98/2000/XP/WIN7或以上；开发工具：支持SDK/DELPHI/VB/PB等；哈尔滨哈尔滨新中新电子股份有限公司台13人证对比科密DF-8000-SF4.0寸以上触摸屏；指纹容量2000张以上；面部容量2000张以上；记录容量12万以上；读取矫正人员人脸、指纹特征，将其到次数、报到时间、人员信息写入矫正管理系广州广州科密股份有限公司台10-52016督察平台对接软件海康威视iVMS-8700/SF支持多系统一体化管理，包含视频、报警、门禁、可视对讲、停车场、访客、巡查、考勤、梯控、消费、动环、运维等多个子系统；支持HTTPS安全加密访问认证；支持角色功能访问权限、角色资源访问权限、角色组织划分，角色类型设置。

支持设备登录密码强度提醒，加强设备安全管理；支持监控点在离线状态检测、设备掉线报警；支持防暴力破解认证，支持验证码、连续登录尝试次数限制、用户IP地址验证；支持对实时和历史报警信息进行排序、过滤显示，并对查看的联动录像、报警详情；可导出查询结果；支持BS客户端、CS客户端、移动客户端（Android、iPhone）视频预览；支持自动在1/4/6/7/9/16/24画面分割模式间进行监控点轮巡预览，轮巡时间可设置，支持全屏显示；支持录像标签功能：可以在录像回放界面搜索录像标签，对搜索录像标签结果进行修改、删除；打开录像标签进行录像回放；该功能包括车牌标签功能；支持流媒体集群，负载均衡；支持人脸、卡片（身份证）、密码、指纹、指静脉等组合认证方式的配置；支持移动端电子地图应用，视频、门禁、报警防区信息展示与管控；杭州杭州海康威视数字技术股份有限公司套117矫正平台对接数据分发软件榕基RCSJ2.1实现将社区服刑人员入矫登记的人脸、身份证、指纹信息自动分发至对应的司法所，并通过人证对比设备对社区服刑人员进行智能点名、智能报到、智能学习；实现对社区服刑人员日常人证比对业务场景的动态数据展示，并可将比对结果直接上传至河南省社区矫正信息管理系统；实时从社区矫正信息管理系统自动同步服刑人员的基础数据。

设备清单：
附表：
应用服务器RH2288H V3
华为虚拟化软件：
备注：提供原厂商三年全免现场质保（7*24*4 小时响应），要求所有硬件设备保修信息均为用户单位，必须从原厂公布的原厂服务电话得到查询验证，投标时必须提供原厂商针对用户的项目授权函和原厂免费质保承诺函
机房平面图
三、其他要求
1、投标供应商的资质要求：独立法人资格，注册资金300万元
人民币及以上，能独立承担民事责任。

2、签定合同日期：自采购中心中标（成交）通知书发出之日起5个工作日内按时签约。

3、交货期（服务时间）：自合同签定之日起20天内。

4、交货（服务）地点：用户指定地点
5、质保期限（自交货并验收合格之日起计）：所有设备三年免费保修。

6、验收要求：在接到供应商以书面形式提出验收申请后，在5个工作日内及时组织相关专业技术人员，必要时邀请采购中心、质检等部门共同参与验收，并出具验收报告，作为支付货款的依据。

7、售后服务及其他（含安装、调试、培训、维护等）
设备到货后需完成后续的安装调试及师资培训工作，不收取其他任何费用。

8、付款方式
签订合同时供方预付合同总额5%的质量保证金，质量保证金待验收合格满一年后无质量问题一次性无息退还。

项目实施完成并经验收合格后，货款一次性付清。

特别提醒：
须根据询价文件要求上传附件，网上附件上传后再行报价（否则有可能无法上传附件），特别提醒，否则有可能作为无效投标。

华为Tecal RH2288H V2是华为新一代2U双路机架服务器，支持2个Intel® Xeon® E5-2600/E5-2600V2系列处理器，凭借高效的设计，最大可配置768GB内存和大容量本地存储，提供最优的计算性能和扩展能力，是关键型应用和云计算的理想选择。

强大的性能轻松应对各种应用要求和横向扩展的需求RH2288H V2采用最新的Intel® Xeon® E5-2600/E5-2600V2系列处理器，单颗处理器最大达到12个核心、30M L3缓存、8GT/sec的QPI(QuickPath Interconnect)，智能功耗调节功能，达到性能、功耗的完美结合，支持超线程、Turbo加速技术；支持24条RDIMM内存，内存容量最大768GB，可满足各种内存密集型应用需求；可选配华为ES系列PCIe SSD高性能存储卡，提供远超传统硬盘的I/O性能，解决磁盘性能瓶颈。

能耗智能控制提高能源效率采用80PLUS®白金高能效电源模块，满足能源之星标准，并通过中国节能环保产品认证；可按需选择460W、800W等多种电源模块，提高能源利用率；内部关键部位设置温度感应器，实时监控不同区域的温度状况，结合风扇智能调速技术进行精确散热，提升系统散热效率；动态功率封顶技术可管控预定配置的服务器功耗，防止功耗超标，且不影响业务运行。

简单方便的管理维护提供类似飞机“黑匣子”的故障信息记录，可快速定位意外宕机原因，迅速恢复业务运行；独立的BMC管理模块提供SOL、远程KVM、远程开关机等丰富管理功能，实现便捷安全的系统管理。

灵活可靠的存储配置选择提供3种存储配置选择，选择更灵活更贴近需求，分别支持8个2.5英寸SAS/SATA/SSD硬盘、12个3.5英寸SAS/SATA+2个2.5英寸SAS/SATA/SSD 硬盘或“24+2”个2.5英寸SAS/SATA/SSD硬盘3种方案可选；支持行业领先RAID技术，支持RAID0、1、10、5、50、6、60等，提供512M/1GB Cache，支持Cache电池保护和超级电容保护，支持RAID状态迁移、RAID配置记忆等功能，支持自诊断、WEB远程设置等功能，保障数据可靠性。

华为RH2288v3安装系统
一、配置局域网环境
因为我是通过网络安装的，所以要配置局域网
首先用一根网线把服务器和电脑连接起来
要和我插得端口一样，不然可能不成功
下面是电脑的
然后配电脑的IP就好打开控制面板
到这里局域网就配置好了
二、登录服务器控制页面
在浏览器中输入https://192.68.2.100，打不开页面说明局域网没有配置成功
默认用户名是root，密码是Huawei12#$
点远程控制
点下载
如果没有下载成功，也可以从下面的百度云链接下载、链接：
https:///s/1dX5tjeoEj9nt9NLd63P7VA 提取码：cmac
三、磁盘阵列
下载解压后是这样的
点击启动，用户名密码和刚才一样
强制重启
到了下面页面点Ctrl+R
光标移至左上方，点击F2键，再点“create virtual drive”回车
然后进入下面的页面
点回车选择RAID-5
用Tab键移动光标到红色区域
用空格键选择，把所有硬盘都选上
用Tab键移动光标到红色区域，回车
用Tab键移动光标到红色区域，回车
用Tab键移动光标到红色区域，回车
用Tab键移动光标到红色区域，回车
用Tab键移动光标到红色区域，回车
用Tab键移动光标到红色区域，回车
四、安装系统
选择本地的ISO镜像文件
没有的去下面下载，一定要下载后缀名是ISO的
点击连接
然后重启
接下来就和正常安装系统一样了，每步都有系统提示，我这里就不演示了。

Huawei FusionServer RH2288H V3 White PaperIssue06Date2016-10-31Copyright © Huawei Technologies Co., Ltd. 2016. All rights reserved.No part of this document may be reproduced or transmitted in any form or by any means without prior written consent of Huawei Technologies Co., Ltd.Trademarks and Permissionsand other Huawei trademarks are trademarks of Huawei Technologies Co., Ltd.All other trademarks and trade names mentioned in this document are the property of their respective holders.NoticeThe purchased products, services and features are stipulated by the contract made between Huawei and the customer. All or part of the products, services and features described in this document may not be within the purchase scope or the usage scope. Unless otherwise specified in the contract, all statements, information, and recommendations in this document are provided "AS IS" without warranties, guarantees or representations of any kind, either express or implied.The information in this document is subject to change without notice. Every effort has been made in the preparation of this document to ensure accuracy of the contents, but all statements, information, and recommendations in this document do not constitute a warranty of any kind, express or implied.Huawei Technologies Co., Ltd.Address:Huawei Industrial BaseBantian, LonggangShenzhen 518129People's Republic of ChinaWebsite:White Paper ContentsContents1 Overview (1)2 Features (3)3 Logical Architecture (6)4 Hardware Description (7)4.1 Appearance (7)4.2 Ports (15)4.3 Indicators and Buttons (16)4.4 Physical Structure (19)5 Technical Specifications (26)6 Component Compatibility (34)6.1 Processor (34)6.2 Memory (37)6.3 Storage (44)6.4 I/O Expansion (51)6.5 PSU (69)6.6 OS and Software (70)7 System Management (76)8 Warranty (78)9 Physical Specifications (79)10 Certifications (82)1 Overview The Huawei RH2288H V3 is a2 U dual-socket rack server. This multipurpose server is designed in response to customer requirements for Internet, Internet data center, cloud computing, enterprise, and telecom service applications.The RH2288H V3 features high-performance computing, large storage capacity, low power consumption and high scalability and reliability. It supports virtualization and is easy to deploy and manage. It is ideal for basic enterprise applications, telecom services, and storage services, such as distributed storage, data mining, electronic albums, and videos.The RH2288H V3 supports the following hard disk configurations:l Eight front 2.5-inch hard disksEight front 2.5-inch SAS HDDs, SATA HDDs, or SSDs, with one SAS card or SASRAID controller cardl Eight front 3.5-inch hard disksEight front 3.5-inch SAS HDDs, SATA HDDs, or SSDs, with one SAS card or SASRAID controller cardThe hard disks can also be connected through the Intel chipset (PCH).If SATA HDDs are used, the SATA HDDs can be connected to the platform controller hub (PCH) instead of being connected to a RAID controller card. The RH2288H V3server supports an optional SoftRAID license and SoftRAID 0, 1, and 5. The server with SoftRAID configuration does not support installation of a virtualization OS.If you have any questions about the hard disk configuration, contact your local Huawei salesrepresentatives.l Twelve front 3.5-inch hard disksTwelve front 3.5-inch SAS HDDs, SATA HDDs, or SSDs, with one SAS card or SAS RAID controller card, and four optional rear 3.5-inch SAS or SATA HDDs or 2.5-inch SAS HDDs, SATA HDDs, or SSDsl Twelve front hard disksTwelve front hard disks, including a maximum of four front NVMe PCIe SSDs. Tosupport SAS HDDs, SATA HDDs, and SSDs, the server must be configured with a SAS card or SAS RAID controller card. A server without NVMe PCIe SSDs supports amaximum of twelve front 3.5-inch SAS HDDs, SATA HDDs, and SSDs.l Twelve front 3.5-inch hard disksA server without NVMe PCIe SSDs supports a maximum of twelve front 3.5-inch SASHDDs, SATA HDDs, and SSDsEight to twleve front NVMe PCIe SSDs. The server can be configured with a SAS card or SAS RAID controller card.The hard disks can also be connected through the Intel chipset (PCH).2.5-inch SAS HDDs, SATA HDDs, or SSDs can be installed in NVMe PCIe SSD slots.l Twenty-four front 2.5-inch hard disksTwenty-four front 2.5-inch SAS HDDs, SATA HDDs, or SSDs, with one SAS card or SAS RAID controller card for every eight hard disks and a maximum of three SAS cards or SAS RAID controller cards for the serverl Twenty-five front 2.5-inch hard disksTwenty-five front 2.5-inch SAS HDDs, SATA HDDs, or SSDs, with one SAS card or SAS RAID controller card, and three optional rear 3.5-inch SAS or SATA HDDs or 2.5-inch SAS HDDs, SATA HDDs, or SSD.SAS HDDs, SATA HDDs, or SSDs can be installed in some of the NVMe PCIe SSD slots.Figure 1-1 shows an RH2288H V3 server.Figure 1-1 RH2288H V32 FeaturesPerformance and ScalabilityAn RH2288H V3 supports up to two Intel® Xeon® E5-2600 v3 processors, 36 cores, and 72threads, or two Intel® Xeon® E5-2600 v4 processors, 44 cores, and 72 threads, whichmaximizes the concurrent execution of multithreaded applications.l Each Intel® Xeon® E5-2600 v3 processor has up to 18 cores, 3.5 GHz frequency, one L3 cache of 45 MB, and two 9.6 GT/s QuickPath Interconnect (QPI) link pairs betweenprocessors.l Each Intel® Xeon® E5-2600 v4 processor has up to 22 cores, 3.5 GHz frequency, one L3 cache of 55 MB, and two 9.6 GT/s QuickPath Interconnect (QPI) link pairs betweenprocessors.l Intel Hyper-Threading technology enables each processor core to run up to two threads, improving parallel computing performance.l Intel Turbo Boost Technology 2.0 allows processor cores to run faster than the frequency specified in the Thermal Design Power (TDP) configuration if they are operating belowpower, current, and temperature specification limits.l The RH2288H V3 supports Peripheral Component Interconnect Express (PCIe) 3.0 toprovide 60% higher I/O bandwidth (8 Gbit/s) than PCIe 2.0 (5 Gbit/s).l Intel integrated I/O enables the PCIe 3.0 controller to be integrated into the Intel® Xeon®E5 series processors. This shortens I/O latency and improves overall systemperformance.The RH2288H V3 provides flexible memory and hard disk configurations to meet storage andupgrade requirements.l The RH2288H V3 supports double data rate 4 (DDR4) registered DIMMs (RDIMMs)and load-reduced DIMMs (LRDIMMs). An RH2288H V3 fully configured with twenty-four 2400MT/s RDIMMs or LRDIMMs provides 1536 GB of memory space. Themaximum theoretical memory bandwidth is 136.5 GB/s. In addition, error checking andcorrecting (ECC) technology ensures high DIMM availability.l The RH2288H V3 supports hard disk drive (HDD) and solid state drive (SSD) disks. An SSD supports up to 100 times more I/O operations per second (IOPS) than a typicalHDD. The use of all SSDs provides higher I/O performance than the use of all HDDs ora combination of HDDs and SSDs.The RH2288H V3 supports a built-in or plug-in NIC, which provides a variety of networkports.Hardware-assisted Intel® Virtualization Technology (Intel® VT) allows operating system (OS)vendors to better use hardware to address virtualization workloads.Intel Advanced Vector Extensions 2.0 (A VX 2.0) improves floating-point computingperformance for computing-intensive applications.Availability and ServiceabilityThe following features make the RH2288H V3 more available and serviceable:l Manufactured using carrier-class components.l Hot-swappable SATA HDDs, SAS HDDs, or SSDs. The SSDs are more reliable thanHDDs, ensuring uninterrupted system performance.l Support for RAID 0, 1, 1E, 10, 5, 50, 6, and 60, and a RAID cache. A supercapacitorprotects cache data from power failures.l Huawei proprietary intelligent baseboard management system (iBMC) monitors system parameters in real time, triggers alarms, and performs failure recovery, minimizingsystem downtime.l Simplified O&M and efficient troubleshooting through:–UID and HLY indicators on the front panel–Fault diagnosis LED–Touch LCD diagnosis panel–iBMC web user interface (WebUI)Manageability and SecurityThe following features make the RH2288H V3 more manageable and secure:l Built-in iBMC monitors server operating status and allows remote management.l Integrated Unified Extensible Firmware Interface (UEFI) improves setup, configuration, and update efficiency and simplifies fault handling.l Optional Trusted Platform Module (TPM) provides advanced encryption functions,including digital signatures and remote authentication.l Advanced Encryption Standard–New Instruction (AES NI) allows faster and strongerencryption.l Lockable server chassis panel ensures security of local data.l Chassis opening events are logged for security purposes.l Intel Execute Disable Bit function to prevent certain types of malicious buffer overflow attacks when working with a supported OS.l Intel Trusted Execution Technology enhances security using hardware-based defenseagainst malicious software attacks, allowing applications to run independently.l Network Controller Sideband Interface (NC-SI) gives a network port both management and service port functions for maximized customer return on investment (ROI).The NC-SI feature is disabled by default and can be enabled through the iBMC WebUI or basic input/output system (BIOS). The service network port with NC-SI enabled supports the followingconfigurations:l Bound to a network port on the onboard NIC or on any network port of the subboard installed on the server. By default, the service network port is bound to host network port 1.l Enabling, disabling, and configuring a virtual local area network (VLAN) ID. The VLAN ID is 0and disabled by default.l IPv4 and IPv6 addresses are supported. You can set an IPv4 address, subnet mask, and gateway IPaddress, or IPv6 address prefix length for the service network port.Energy EfficiencyThe following features make the RH2288H V3 conserve more energy:l80 Plus Platinum power supply units (PSUs) of multiple power ratings provide 94%power efficiency at 50% load.l V oltage regulator-down (VRD) power supplies for boards minimize energy loss fromDC/DC power conversion.l Improved thermal design, area-based and Proportional-Integral-Derivative (PID)intelligent fan speed adjustment, and intelligent CPU frequency adjustment optimize heatdissipation and reduce overall system power consumption.l Intel® Intelligent Power Capability allows a processor to be powered on or off based on service requirements.l Power capping and power control functions.l Use of innovative components:–Intel® Xeon® E5-2600 v3 processors and Intel® Xeon® E5-2600 v4 processorsperform better than the previous-generation Intel® Xeon® processors while fittinginto the same TDP. Low-voltage Intel® Xeon processors consume less energy,ideally suited for data centers and telecommunications environments constrained bypower and thermal limitations.–SSDs consume 80% less power than HDDs. In addition, hard disks can be poweredon at different times to reduce startup power consumption.– 1.2 V DDR4 RDIMMs consume 20% less energy than 1.5 V DDR3 RDIMMs. Customization SupportThe Huawei proprietary RH2288H V3 supports customization timed to customer needs.3 Logical ArchitectureFigure 3-1 shows the components of the RH2288H V3 that provide the software services necessary for its rich functionality.At the heart of the server are two Intel® Xeon® E5-2600 v3 (Haswell-EP) or E5-2600 v4(Broadwell-EP) series processors and 24 DDR4 DIMMs. The processors are connected by QPI links at 9.6 GT/s.Each processor connects to two PCIe riser cards to provide ease of expandability and connection.The RAID controller card and hard disk backplane form a hard disk interface module, which connects to the processors through PCIe connectors.Figure 3-1RH2288H V3 logical architectureWhite Paper 3 Logical Architecture4 Hardware Description4.1 AppearanceFront PaneFigure 4-1 shows the front panel of an RH2288H V3 with eight 3.5" hard disks.Figure 4-1Front panel of an RH2288H V3 with eight 3.5" front hard disks1Fault diagnosis LED2Health status indicator3UID button/indicator4Power button/indicator5VGA port6NMI button7Customizable label8Built-in DVD-ROM drive ortouch LCD diagnosis panel9Hard disks (slots numbered 0 to 7from top to bottom and from leftto right)10Hard disk fault indicator11Hard disk active indicator12USB 2.0 port13Network port link status indicators 414Network port link statusindicators 315Network port link status indicators 216Network port link statusindicators 1White Paper 4 Hardware DescriptionFigure 4-2 shows the front panel of an RH2288H V3 with twelve 3.5" hard disks.Figure 4-2 Front panel of an RH2288H V3 with twelve 3.5" front hard disks1Fault diagnosis LED2Health status indicator3UID button/indicator4Power button/indicator5Customizable label6Hard disks (numbered 0 to 11 fromtop down and from left to right)7Hard disk fault indicator8Hard disk active indicator9USB 2.0 port10Network port link status indicators411Network port link status indicators 312Network port link status indicators 213Network port link status indicators1––Figure 4-3 shows the front panel of the RH2288H V3 with twelve 3.5-inch hard disks, including four NVMe PCIe SSDs.Figure 4-3 Front panel of the RH2288H V3 with twelve 3.5-inch hard disks, including four NVMe PCIe SSDs1Fault diagnosis LED2Health indicator3UID button/indicator4Power button/indicator5NVMe PCIe SSD yellowindicator6NVMe PCIe SSD green indicator7Label (including ESN label)8NVMe PCIe SSDs (numbered 8 to 11from left to right and from top tobottom)9Hard disks (numbered 0 to 7 from top to bottom and from left to right)10Hard disk fault indicator11Hard disk active indicator 12USB 2.0 port13Network port link status indicators 414Network port link status indicators 315Network port link status indicators 216Network port link status indicators 1Figure 4-4 shows the front panel of an RH2288H V3 with eight to twelve NVMe PCIe SSDs.Figure 4-4 Front panel of an RH2288H V3 with eight to twelve NVMe PCIe SSDs1Fault diagnosis LED 2Health indicator 3UID button/indicator 4Power button/indicator5NVMe PCIe SSD yellow indicator6NVMe PCIe SSD green indicator 7Label (including the ESN label)8NVMe PCIe SSDs (numbered 4 to 11from top to bottom and from left)9Hard disks (supporting SSDs,SAS HDDs, SATA HDDs, and NVMe PCIe SSDs; numbered 0to 3 from top to bottom and from left to right)10Hard disk fault indicator or NVMe PCIe SSD yellow indicator11Hard disk activity indicator or NVMe PCIe SSD green indicator 12USB 2.0 port13Network port link status indicators 414Network port link status indicators 315Network port link status indicators 216Network port link status indicators 1Figure 4-5 shows the front panel of an RH2288H V3 with eight 2.5" hard disks.Figure 4-5 Front panel of an RH2288H V3 with eight 2.5" front hard disks1Fault diagnosis LED2Health status indicator3UID button/indicator4Power button/indicator5VGA port6NMI button7Customizable label8Built-in DVD-ROM drive or touchLCD diagnosis panel9Hard disks (numbered 0 to 7 fromleft to right)10USB 2.0 port11Network port link status indicators 412Network port link status indicators 313Network port link status indicators 214Network port link status indicators 115Hard disk fault indicator16Hard disk activity indicatorFigure 4-6 shows the front panel of an RH2288H V3 with twenty-five 2.5" hard disks. Figure 4-6 Front panel of an RH2288H V3 with twenty-five 2.5" front hard disks1Fault diagnosis LED2Health status indicator3UID button/indicator4Power button/indicator5Customizable label6Hard disks (numbered 0 to 24from left to right)7USB 2.0 port8Network port link status indicators49Network port link statusindicators 310Network port link status indicators 211Network port link statusindicators 112Hard disk fault indicator13Hard disk activity indicator––Figure 4-7 shows the front panel of an RH2288H V3 with twenty-four 2.5" hard disks.Figure 4-7 Front panel of an RH2288H V3 with twenty-four 2.5" front hard disks1Fault diagnosis LED2Health indicator3UID button/indicator4Power button/indicator5NMI button6VGA port7Label (including the ESN label)8Hard disks (numbered 0 to 23 from left toright)9USB 2.0 port10Network port link status indicators 411Network port link statusindicators 312Network port link status indicators 213Network port link statusindicators 114Hard disk fault indicator15Hard disk activity indicator––Rear PanelFigure 4-8 shows the rear view of an RH2288H V3.Figure 4-8 Rear view of an RH2288H V31PSU2PSU indicator3Power socket of a PSU4I/O module 25Connection status indicator6Data transmission statusindicator7Onboard standard PCIe slot8I/O module 19NIC10UID indicator11USB 3.0 port12Management network port(Mgmt)13VGA port14Serial portThe slots labeled 4 and 8 can house either I/O modules or 2.5" or 3.5" hard disks.l An RH2288H V3 equipped with twelve front 3.5" hard disks can house up to four rear3.5" or 2.5" hard disks.l An RH2288H V3 equipped with twenty-five front 2.5" hard disks can house up to two rear 2.5" hard disks.l An RH2288H V3 not equipped with any rear hard disk can house up to two I/O modules.Each I/O module provides two or three PCIe slots.PCIe Slot LayoutFigure 4-9 shows the PCIe slot layout of the RH2288H V3.Figure 4-9 PCIe slot layoutPCIe slots on I/O module 1 and 2I/O module 1 provides slots 1 to 3, and PCIe riser module 2 provides slots 6 to 8.I/O module 1 and 2 supports 2-slot PCIe riser module or 3-slot PCIe riser module, but three PCIe slots are always displayed on the panel.l If I/O module 1 provides two PCIe slots, slot 3 is unavailable.l If I/O module 2 provides two PCIe slots, slot 8 is unavailable.Table 4-1 describes the mapping between PCIe slots and CPUs, and the PCIe specifications of the RH2288H V3.The PCIe slots mapping to a vacant CPU socket are unavailable.Table 4-1 PCIe slot descriptionPCIe GPU Configuration RulesA GPU must be installed on a PCIe riser module.l A 2-slot PCIe riser module supports a maximum of two single-slot PCIe x16 GPUs (bandwidth of one GPU: x8) or one dual-slot PCIe x16 GPU.l A 3-slot riser module does not support any GPU.4.2 PortsAll ports found on an RH2288H V3 are listed in Table 4-2 and Table 4-3.Table 4-2 Ports on the front panelTable 4-3 Ports on the server rear4.3 Indicators and ButtonsIndicators, described with buttons in Table 4-4 and Table 4-6, display the status of theRH2288H V3.Table 4-4 Indicators and buttons on the front panel。
