Note:
– If the material type is changed in CAD, this will be reflected in an update. – if the property values of the material change in CAD, this will not update.
ANSYS, Inc. Proprietary 2009 ANSYS, Inc. All rights reserved.
9-5
February 23, 2009 Inventory #002593
CAD and Parameters
… Parameter Import
Parametric CAD dimensions can be imported into Mechanical:
Tra Inc. Proprietary 2009 ANSYS, Inc. All rights reserved.
9-6
February 23, 2009 Inventory #002593
CAD and Parameters
… Named Selections Import
CAD and Parameters
Updating Modified Geometry
Updating geometry:
– After modifying the source geometry the project schematic will show a refresh/update state for the model (RMB to complete).
– When “Yes” (default), dimension names containing the parameter key (default is “DS”) will be imported into Mechanical. – To import all parameters leave the parameter key field blank. – CAD parameters will appear in the Details view for the Geometry.
Training Manual
ANSYS, Inc. Proprietary 2009 ANSYS, Inc. All rights reserved.
9-7
February 23, 2009 Inventory #002593
CAD and Parameters
… Material Property Import
Please note, not all import capabilities described here are available with all CAD systems. Features depend on CAD capabilities and the support provided through the CAD vendor’s API.
– IGES Geometry Interface reader is provided for all installations.
DesignModeler is the Workbench geometry application and supports all the functions and capabilities listed for commercial CAD systems.
– Not all CAD software have the same features, so there are some differences in CAD-related functionality which is supported in Mechanical.
ANSYS, Inc. Proprietary 2009 ANSYS, Inc. All rights reserved.
The capabilities described in this section are generally applicable to all ANSYS licenses. However, some CAD functionality are specific to certain CAD software, so these will be designated accordingly.
ANSYS, Inc. Proprietary 2009 ANSYS, Inc. All rights reserved.
9-3
February 23, 2009 Inventory #002593
CAD and Parameters
… CAD Interoperability
There are various items that can be imported from supported CAD systems:
Refresh needed
Refresh complete, update needed RMB for option
ANSYS, Inc. Proprietary 2009 ANSYS, Inc. All rights reserved.
Update complete
9-9
February 23, 2009 Inventory #002593
Training Manual
Refreshing: reads the new geometry into the analysis application but does not update the finite element mesh. Updating: combines refreshing geometry and remeshing the FE model.
CAD and Parameters
Updating Modified Geometry Parameters
Updating new parameter values:
CAD and Parameters
Chapter Overview
Training Manual
In this chapter, interoperability with CAD software as well as parameters will be discussed.
A. CAD Interoperability B. DesignXplorer Parameter Manager C. Workshop 9-1
– Assemblies with mixed solids and surfaces are OK. – Select desired geometry type to filter import. – Cannot import a part with mixed solids and surfaces.
Material Properties: allow material property import from supported CAD systems (see the current documentation for properties supported by various CAD vendors. Materials imported from CAD will appear in the “Engineering Data” branch and will be assigned to individual parts.
– Geometry, Spot welds, Parameters, Material properties, etc.
Training Manual
To access these import preferences use the Geometry properties in the Project schematic.
9-2
February 23, 2009 Inventory #002593
CAD and Parameters
A. CAD Interoperability
Training Manual
Numerous Geometry Interfaces are available for commercial CAD systems:
– For the latest information on CAD geometry interfaces and supported platforms see the ANSYS Workbench Mechanical documentation:
Mechanical Help > CAD Systems
ANSYS, Inc. Proprietary 2009 ANSYS, Inc. All rights reserved.
9-4
February 23, 2009 Inventory #002593
CAD and Parameters
… Geometry Import
Import solid, surface, or line bodies:
If “groups” are defined in the CAD package they can be imported as Named Selections:
– “Groups” containing the specified prefix in their name are imported in the Named Selection branch (default is “NS”). – To import all groups leave the named selection key field blank.
– If the material type is changed in CAD, this will be reflected in an update. – if the property values of the material change in CAD, this will not update.
ANSYS, Inc. Proprietary 2009 ANSYS, Inc. All rights reserved.
9-5
February 23, 2009 Inventory #002593
CAD and Parameters
… Parameter Import
Parametric CAD dimensions can be imported into Mechanical:
Tra Inc. Proprietary 2009 ANSYS, Inc. All rights reserved.
9-6
February 23, 2009 Inventory #002593
CAD and Parameters
… Named Selections Import
CAD and Parameters
Updating Modified Geometry
Updating geometry:
– After modifying the source geometry the project schematic will show a refresh/update state for the model (RMB to complete).
– When “Yes” (default), dimension names containing the parameter key (default is “DS”) will be imported into Mechanical. – To import all parameters leave the parameter key field blank. – CAD parameters will appear in the Details view for the Geometry.
Training Manual
ANSYS, Inc. Proprietary 2009 ANSYS, Inc. All rights reserved.
9-7
February 23, 2009 Inventory #002593
CAD and Parameters
… Material Property Import
Please note, not all import capabilities described here are available with all CAD systems. Features depend on CAD capabilities and the support provided through the CAD vendor’s API.
– IGES Geometry Interface reader is provided for all installations.
DesignModeler is the Workbench geometry application and supports all the functions and capabilities listed for commercial CAD systems.
– Not all CAD software have the same features, so there are some differences in CAD-related functionality which is supported in Mechanical.
ANSYS, Inc. Proprietary 2009 ANSYS, Inc. All rights reserved.
The capabilities described in this section are generally applicable to all ANSYS licenses. However, some CAD functionality are specific to certain CAD software, so these will be designated accordingly.
ANSYS, Inc. Proprietary 2009 ANSYS, Inc. All rights reserved.
9-3
February 23, 2009 Inventory #002593
CAD and Parameters
… CAD Interoperability
There are various items that can be imported from supported CAD systems:
Refresh needed
Refresh complete, update needed RMB for option
ANSYS, Inc. Proprietary 2009 ANSYS, Inc. All rights reserved.
Update complete
9-9
February 23, 2009 Inventory #002593
Training Manual
Refreshing: reads the new geometry into the analysis application but does not update the finite element mesh. Updating: combines refreshing geometry and remeshing the FE model.
CAD and Parameters
Updating Modified Geometry Parameters
Updating new parameter values:
CAD and Parameters
Chapter Overview
Training Manual
In this chapter, interoperability with CAD software as well as parameters will be discussed.
A. CAD Interoperability B. DesignXplorer Parameter Manager C. Workshop 9-1
– Assemblies with mixed solids and surfaces are OK. – Select desired geometry type to filter import. – Cannot import a part with mixed solids and surfaces.
Material Properties: allow material property import from supported CAD systems (see the current documentation for properties supported by various CAD vendors. Materials imported from CAD will appear in the “Engineering Data” branch and will be assigned to individual parts.
– Geometry, Spot welds, Parameters, Material properties, etc.
Training Manual
To access these import preferences use the Geometry properties in the Project schematic.
9-2
February 23, 2009 Inventory #002593
CAD and Parameters
A. CAD Interoperability
Training Manual
Numerous Geometry Interfaces are available for commercial CAD systems:
– For the latest information on CAD geometry interfaces and supported platforms see the ANSYS Workbench Mechanical documentation:
Mechanical Help > CAD Systems
ANSYS, Inc. Proprietary 2009 ANSYS, Inc. All rights reserved.
9-4
February 23, 2009 Inventory #002593
CAD and Parameters
… Geometry Import
Import solid, surface, or line bodies:
If “groups” are defined in the CAD package they can be imported as Named Selections:
– “Groups” containing the specified prefix in their name are imported in the Named Selection branch (default is “NS”). – To import all groups leave the named selection key field blank.
