A Cheap Ultrasonic Range Finder

  • 格式:doc
  • 大小:486.00 KB
  • 文档页数:12

Do you need to add a
distance sensor to your
embedded project ? Build
this simple ultrasonic
range finder !
This quick & dirty PIC
ultrasonic range
finder will find a place
in numerous projects :
presence detector,
robotics, car parking,
distance measurement...
With a few cheap
components and less than
200 bytes of code, this
sensor will work from 30 to
200 cm, around 1 cm
accuracy, with underflow
and overflow indication.
How does it work & Circuit schematic
Everybody knows the speed of the sound in the dry air is around 340 m/s. Send a short ultrasonic pulse at 40 Khz in the air, and try to listen to the echo. Of course you won't hear anything, but with an ultrasonic sensor the back pulse can be detected. If you know the time of the forth & back travel of the ultrasonic wave, you know the distance, divide the distance by two and you know the range from the ultrasonic sensor to the first obstacle in front of it.
Here we use an ultrasonic piezzo transmitter with its receiver, they are very efficient, easy to find and quite cheap.
First, we have to send the pulse : it is easy to get a 40 Khz pulse from a PIC PWM output. You can drive an ultrasonic transmitter directly from the PIC output, but the sense range will not exceed 50 cm. Using a transistor and a resonator circuit, the ultrasonic transmitter will get around 20 volts and the sense range will be extended up to 200 cm.
Second we have to sense the echo : the piezzo receiver can provide a few dozens of millivolt, this will be enough for a PIC ADC with 4 mV resolution
without extra hardware.
Click on schematic to enlarge C1 is a decoupling capacitor The PWM pulse from the RC2 pin of the PIC drives the T1
transistor base
through R1 resistor A 330 µH inductor is added in parallel to the piezzo ultrasonic transceiver , to form a LC
resonnator, the D1 diode protects T1 from reverse voltage. The
ultrasonic receiver is directly connected
to the RA1 pin of the PIC (ADC channel number 1), with R3 in parallel as impedance adaptator.
The
proto
type
board
<-
Compo
nent
side
Solde
r side
->
Take
care
to
align
as
best
as
possi
be the
trans
mitte
r with
the
recei
ver Source code
Here is the mikroC source code :
INSTRUCTIONS FOR USE
I tested it
with an
EasyPic4
developmen
t board :
Of course,
this
ranger is
very basic
and have a
few drawba
cks :
A little
shock to
the piezzo
receiver
cell could
lead to a
wrong
measuremen
t,
Since
ultrasonic
pulse is
not coded,
any other
ultrasonic
source
will put
the mess : => Unwanted underflow or overflow conditions may happen
This is the price of the very simple design of the ranger.
This is what you should see on your scope, if you probe to the ultrasonic receiver pins :
Horizontal : 1 ms/div
Vertical : 5 mV/div
The mechanical echo is removed by a software delay.
The reflected wave is around 40 mV peak to peak, it comes around 9.5 ms after the ultrasonic burst, if we say that sound velocity is 340 m/s it means that the object distance was around 0.0095 / 2 * 340 = 1.615 meters.
Actually, it was the ceiling, it was 172 cm above the circuit, the LCD wrote 170 cm.
I hope this basic project will make a good start for yours !
Please report bugs & comments in my forums。
