1Gbps LAN Card
Plate
6PIN Cable
Lens
Adaptor [12V 2A]
Required System Spec.
OS
•Windows XP, Windows 7
S/W Installation
1. S/W download 1) Visit , Moving to Support -> Download -> Industrial Cameras -> S/W 2) Download Neptune S/W along with OS. [32Bit / 64Bit]
시스템 최소사양
OS
•Windows XP, Windows 7
S/W 설치
1. S/W 다운로드 1) 자사 홈페이지 “”에 접속하여 SUPPORT DownloadIndustrial CamerasS/W항목으로 이동합니다. 2) Neptune S/W를 다운로드 합니다. [32Bit, 64Bit구분]
Driver, S/W CD
악세서리
한국어버전 Ver 1.1
CAT.6 LAN 케이블
1Gbps LAN 카드
Plate
IMI TECHNOLOGY CO., LTD. 경기도 안양시 동안구 관양동 799번지 안양메가밸리 616호 Tel : 031-423-9801 Fax : 031-423-9802 for inquiry : sale@ 6PIN 케이블 렌즈 아답터 [12V 2A]
CPU
• Core2quad or better spec.
RAM
• 2GB, even more
2. S/W Configuration Neptune : 1394A, 1394B, GigE / ActiveX API / 32, 64Bit Prontocam : 1394A, 1394B / ActiveX API / 32Bit **DEMO Viewer, Driver, Sample Source, API, Application Manual 3. S/W Insatllation 1) Move to the downloaded folder and run setup file. 2) Click “Next” on the installation window. 3) Click “Complete” on Customer information window and Click “Next” button. 4) Click “Install” on Neptune-Install Wizard window and run setup. 4-1) On Hardware installation window, click “Continue” button. [In Window XP] 4-2) Click “Yes” 4 times times in the window of file change confirmation [In Window XP] 5) Click “Finish” after setup. * Using after system rebooting is recommended 6) In using Win7, Click “Always trust software from IMI Tech” and click to “Install”
IP configuration
1. Network Structure 1) Connect PC 1ea, NETWORK CARD 1ea and camera 1ea directly. 2) Remove all firewall which is included in Windows and Vaccine Program.
IP setting 3) If you can’t find same IP address as above, change protocol and IP setting within Change Setting item. 2. Neptune Start 1) Click Neptune icon on Window wallpaper.
LAN Cable
Mainboard
3, PC System connection 1) Insult 1Gbps network card into PC and install the driver. [Network card installation method is from Card manufacturer] 2) Connect the LAN cable to network card.
Quick Start Install Guide
Basic contents

GigE Camera
User Manual(Website)
Driver, S/W CD(Website)
Accessaries
English Version Ver 1.1
CAT.6 LAN Cable IMI TECHNOLOGY CO., LTD. #616, Mega Valley, Gwanyang 2-dong, Dongan-gu, Anyang-si, Gyeonggi-do, 431-767, Korea Tel : 031-423-9801 Fax : 031-423-9802 for inquiry : world@
Start
1. CAMERA IP confirmation & Change 1) “Start””All program””IMI TECH” “Neptune””Tools””GigE Manager”. 2) Confirm IP address: 169.254.xxx.xxx // Subnet mask:255.255.0.0.
LAN CABLE
IP information check GigE CAMERA
PC SYSTEM 2. PC IP Confirmation 1) PC booting Approx. 2 minutes later, click “Window”+“R” Key. 2) Input “CMD” on open article and push “Enter” key. 3) Input “ipconfig” and push “Enter” key. 4) Confirm IP address: 169.254.xxx.xxx and subnet mask:255.255.0.0. 5) Confirm the article no 4), or IP configuration must be changed. 3, PC IP Changing 1) XP: Control panelNetwork connectionDouble click “Network adaptor” Select “Attributes”Double click “Internet protocol (TCP/IP) and check registration information window popup. 2) WIN7: Control panelNetwork and sharing centreAdaptor configuration changing Double click “Network adaptor” Select “Attributes” Double click “Internet Protocol Version 4 (TCP/IPv4)” and check attributes window popup. 3) Select “Automatic IP address receipt” and select “OK”, then close all setup windows popup. [Because of no DHCP Server, LLA area is setup. 4) For manual IP configuration, input “IP address: 169.254.xxx.xxx // subnet mask:255.255.0.0” and select “OK”, then close all setup windows popup ** Double check the IP information using PC IP confirmation list.
VIDEO
• AGP 128MB, even moreFra bibliotekPORT
• GigE [Intel Series]
Program language
• Visual Basic Visual C++
H/W Installation
1. Plate connection 2. Camera connection

Adaptor [12V 2A]
④ ④

Lens Plate
③ ② ③ ④
Camera 6PIN Cable
3. PC System connector

LAN Cable
LAN CARD
1. Plate connection 1) When you install the camera to the external equipments, attach the plate using 4 screws. 2. Camera connection 1) Turn the C or CS mount lens clockwise . [Article ① reference] 2) Connect LAN cable. [Article ② reference] ** Tighten Locking screw port after camera connection. 3) Connect 6PIN cable for power, Trigger input and Strobe output etc. [Article ③ reference] 4) Input power using 12V DC[Adopter] [Article ④ reference] ** Using PoE(802.3af) support Hub or NIC, it doesn’t need additional power connection.
