FLUKE 434三相电能质量分析仪 福禄克 FLUKE

Fluke 430系列电能质量分析仪技术数据输入数量4个电压和电流（3相+中性点）最大电压电压有效值1000 Vrms (电压峰值6 kV peak) 最高采样速度各个通道同步，200 kS/s电压/电流/频率电压有效值Vrms (AC + DC)测量范围 1 ... 1000 V精度0.1% of Vnom Vpeak测量范围 1 ... 1400 V精度5% of Vnom波形因数CF，电压测量范围 1.0 ... > 2.8精度±5%Arms (AC + DC)测量范围0 ... 20 kA精度±0.5% ± 5个字Apeak测量范围0 ... 5.5 kA精度5%波形因数CF，电流测量范围 1 (10)精度±5%Hz 50 Hz nominal测量范围42.50 ... 57.50 Hz 精度±0.01 Hz骤升骤降Vrms (AC+DC) 2测量范围0.0% … 100%标称电压精度±0.2% 标称电压Arms (AC+DC) 2测量范围0 ... 20 kA ?精度±1% ±5个字谐波谐波(间谐波) (n)测量范围DC, 1..50; (关, 1..49)，依据IEC 61000-4-8进行测量Vrms测量范围0.0 … 1000 V精度±0.05% 标称电压Arms测量范围0.0 … 4000 mV x 电流钳变比精度±5% ±5个字Watts精度±20 ms (Fnom = 50 Hz)自动趋势记录采样率 5 个/sec ，每个通道同步连续采样存储1800 每个读数的min, max和avg值记录时间长至450天缩放水平缩放高至13倍存储屏幕和数据50, 内存分为数据记录、屏存和数据设置注意1 取决于电流钳的变比2 电压基于1个周波进行测量，从零点开始，每半周刷新一次产品介绍● 彩色大屏幕LCD显示● 适用于5种配线系统：单相二线(4电路)/单相三线/三相三线(2电路)/三相四线/单相三线+三相三线(Scott wiring)● 提供各种电力测量包括电力质量分析● 能够显示真有效值● 能够直接用交流供电，或是用电池来供电，Ni-MH充电电池也可使用● 波形和载体的显示能够靠功能键来转换● 记录能从1秒到1小时：1/2/5/10/15/20/30秒，1/2/5/10/15/20/30分钟, 1小时● 用CF卡储存数据达到了1G● 数据可用USB传输到PC上● 设计符合EN61010-1 CAT III 600V，安全规格日本共立KYORITSU电力计(电能质量分析仪）6300-02技术参数接线方式单相二线(4电路)/单相三线/三相三线(2电路)/三相四线/Scott wiring测量功能电压, 电流, 频率,有功功率, 无功功率, 视在功率,有用功, 无用功, 视在功,功率因数分析器(谐波/失衡/瞬变/电压下降/电压增长/中断)电压范围150/300/600/1000V电流范围0.5/1/5/10/20/50/100/200/500/1000/3000A精确度(目标值)电压: ±0.2%rdg±0.1%f.s. , 电流: ±0.2%rdg±0.1%f.s. + 钳型传感器精确度有功功率: ±0.5%rdg±0.1%f.s. +钳型传感器精确度功率因数的效果 ±1.0%rdg cosθ=±0.5(PF=1) 频率范围40~70Hz间隔时间记录功能1/2/5/10/15/30 seconds, 1/2/5/10/15/30 minutes, 1 hour 内存容量 1MB显示 3.5-inch Color LCD (320 x 240 Dot) 语言显示中文/日语/英语储存温度和湿度范围-20～60℃, less than 85%RH (无凝聚下) 操作温度和湿度范围 0～50℃, less than 85%RH (无凝聚下) 其它 DC 输入终端 (50mV/500mV/5V 范围调整) PC 卡接口 CF 卡 32M~1GB安全标准(EMC 标准) EN61010-1:2001 CAT Ⅲ 600Ｖ Pollution degree2(EN61326 (2001) Class A) 电源供应 AC100V~240V, LR6 x 6尺寸 206(W) x 184(D) x 65(H) mm 重量 Approx. 0.8kg配件Test lead (4pcs), Mains cord, PC 软件, USB 线, 说明手册,便携箱,电池(6pcs)日置3197电能质量分析仪接线方式 单相2 线, 单相3 线, 三相3 线, 三相4线（2.5E 测量可） 电压量程 AC 600V电流量程(根据测量范围,需要选择不同的钳式传感器) [9657-10, 9675] AC 500mA/5A,[9694, 9695-02] AC 5/50A, [9660, 9695-03] AC 10/100A, [9661, 9667 (500A 档量程)] AC 50/500A,[9667 (5kA 档量程)] AC 500/5000A, [9669] AC 100A/1kA测量方法瞬态过电压: 比较式（检出10k ～100kHz ）,谐波/间谐波: 2048点（10周期/50Hz, 12周期/60Hz时）其他有效值: 10.24kHz/ch采样测量功能 1. 瞬态过电压2. 电压突升，电压突降，电压中断3. 频率，电压（电压有效值·电压1/2有效值）, 电流（电流有效值·电流1/2有效值）, 电压·电流峰值, 有功/无功·视在功率, 功率因素（有功·无功）, 累积电量（有功·无功）, 功率或位移功率因素4. 电压不平衡率5. 谐波电压/电流/功率, 谐波电压·电流相位角, K 因素, 总谐波畸变6. 电流突升内存4MB接口USB 2.0（高速, 连接PC）显示 4.7英寸STN彩色液晶显示电源AC转换器9418-15（AC 100 ～240V）, 电池组9459, 连续使用6小时（不用带背光5分）, 最大23VA 尺寸，重量128W × 246H × 63Dmm, 1.2kg （包括电池组9459）附件电压线9438-03× 1套（红·黄·蓝·黑色各1根, 线长3m）, AC转换器9418-15× 1, 电池组9459× 1, USB 电缆× 1, 输入接口用标签× 1, 输入电线用标签× 1, 应用软件CD× 1, 肩带× 1, 携带盒× 1TES-3600 三相电力分析仪/电能质量分析仪交流电压测量(V)檔位测量方式准确性输入阻抗600.0V 真有效值± 0.5% 读值± 10 位(>30V) 2M Ω交流电流测量(A)檔位测量方式准确性250A 、500A 、1000A 真有效值± 0.5% 读值± 10 位+ 夹式电流感应器规格有效功率瓦特测量(KW)檔位准确性功率因素影响600.0KW ± 0.5% 读值± 10 位+ 夹式电流感应器规格± 0.1% 读值无效功率乏尔测量(KVAR)檔位准确性功率因素600.0KVAR ± 0.5% 读值± 10 位+ 夹式电流感应器规格± 0.1% 读值视在功率伏安测量(KVA)功率累积分测量功率因子测量(PF)频率测量(Hz)深圳市泰立仪器仪表FT-2000L系列在线电能质量监测仪，集所有功能于一身：·记录电压/电流的真有效值·电能质量分析仪·谐波分析仪·功率分析仪·电力需要分析仪·电力闪变仪·暂态分析仪·电源干扰分析仪·频率计·故障记录仪·图形记录仪检测和分析：◆电压◆电流◆频率◆电能质量：浪涌，下陷，脉冲◆功率：有功功率，无功功率，视在功率，功率因数◆谐波◆闪变◆接地电流◆三相不平衡先进的测量技术：◇同时测量电能质量、功率和谐波。

福禄克F430系列三相电能质量分析仪更快、更安全、更详细地定位和诊断的电能质量故障一、技术参数福禄克公司的F434 和F433三相电能质量分析仪可以帮助用户定位、预测、防止和诊断配电系统的故障。

对于那些维护或排障三相配电系统的工作人员来说，这些简便易用的手持工具是“必不可少”的。

新的IEC和GB国标关于闪变和电能质量方面的标准使得在对系统进行电能质量分析监测时有了判断的依据。

z记录三相系统中所有电能质量的参数。

z直观的菜单，最大程度上减少所需的设置。

z工业现场使用最高的安全等级。

z四个电压通道和四个电流通道。

z同时在所有相线上捕获波形数据。

z系统监测：在一个仪表板上现实全部电能质量参数。

z自动显示瞬态尖峰脉冲信号：不会漏掉任何一个事件。

z自动趋势绘图（AutoTrend）功能：无需对记录进行设置！z坚固的手持式设计。

z使用镍氢（NiMH）电池组时，一次充电可使用7个小时。

z将数据文件传输到PC，用于编写报告和利用FlukeView® 软件进行分析。

CAT IV 600 V 和 CAT III 1000 V的安全等级在设计时就考虑了保护用户和设备免受高压电击，福禄克F430系列电能质量分析仪、附件和充电器都经过验证，满足CAT IV 600 V和CAT III 1000 V环境下使用的严格的安全标准。

它们是同类别中第一款符合CAT IV安全等级的工具，所以可以被用于低压配电系统中所有的电气连接和插座。

快捷地观察趋势图利用AutoTrend （自动趋势绘图）功能，可以快速地深入浏览电能质量参数随时间的变化。

所显示的每一读数都被自动并且连续的进行记录，而不必设置触发限值或间隔时间，也无需手动启动记录过程。

可以快速地观察所有相线和零线上电压、电流、频率、功率、谐波或闪变的趋势图；还可以使用光标和缩放功能分析趋势－而不会中断记录。

AutoTrend 功能在后台自动记录显示的所有参数。

在数据和趋势图之间切换，以及使用光标和缩放功能分析测量结果，都不会中断记录过程。

•FLUKE分析仪属贵重设备，使用及搬运时请爱护设备，保持设备整洁。

二、谐波测试规程1、现场勘查及信息收集①对现场配电室的配电线路进行勘查，确定测试地点。

要求测试地点能够全面、真实的反映出被测变压器或负载的用电情况。

图1标出了3个常用的测试点，高压侧的测试应选在二次侧进行测量（在高压二次侧的PT、CT上侧）。

图1②记录被测配电系统的变压器、负载及无功补偿柜的基本情况，填写到《谐波测试记录单》中。

简单画出被测配电系统一次线路图。

2、数据测试在测试时先将测试仪器打开的主界面保存下来，下图是在0.4KV系统测试的主界面，使仪器满足以下要求：1 接线图是三相接地系统，在常规的工业现场一般都是三相负载，所以测试时将测试仪器设在三相星型接法。

在测试单相负载时可以将表接成两相接地系统，一般情况下不要更改。

2 检查测试仪器的时间是否为与实际时间相同，电压等级是否一致，电流量程是否正确，如打开设备主界面正确，自己不要随意更改。

4）图表上显示的L1、L2、L3所对应的颜色为黑、红、蓝，若不一致按SETUP键，然后按Enter键进行更改，将三相的颜色设为黑、红、蓝。

3 在0.69KV系统测试时将Vnom：230V改为400V,电压等级是其它的就将该数值改为所对应系统的相电压等级。

开机主界面若待测配电系统配有无功补偿柜或者其它电能质量治理设备，则应在无功补偿柜（其它电能质量治理设备）开、停两种状态下分别测试，并将测试数据分别命名区分保存。

①基波电流最大时测谐波频谱图和各次谐波柱状图、表格。

将测试图表打到电流谐波柱状表，按导航键将光标移动到基波电流上，在屏幕的左上角有电流值，由于负载是不断变化的，经过观察一段时间，在电流最大值的时候抓下谐波频谱图，此时基波图表会处在HOLD状态，依次将光标移动到THD、3、5、7、11、等特征性次数上抓下图表；然后按F2屏幕将切换到单相上，用电脑抓下电流图表，按F1切换到电压状态下，抓下电压的柱状图，同理按F2屏幕将切换到单相上，抓下电压图表；然后按F3切换到谐波表格上，再按F1将电压、电流谐波表格抓下来，下面是各种负载的典型图表。

Three Phase Power Quality AnalyzerFluke435使用手册2010年8月12日Fluke整体介绍1测量范围：1.1电压输入：a)最大输入电压：1000Vrmsb)标称电压范围：50至500V，内部分为三个范围：500V、250V、125Vc)最大峰值电压：6KVd)输入阻抗：4MΩ//5PF1.2 电流输入：a)输入范围：用仪表附带的电流夹i5s，1至5Arms;用可选电流夹i430flex-4pk，0.1至3000 Armsb)输入阻抗：50KΩ1.1.2标称频率：40…70Hz1.2菜单功能介绍：Fluke435菜单主要有SETUP、SCOPE、MENU、MONITOR、MEMORY、SAVE SCREEN1.2.1对测试仪进行设置：使用设置（SETUP）功能1.2.2检查电压导线和电流线夹是否正确连接：使用示波器波形(ScopeWaveform)和示波相量（Scope Phasor）功能1.2.3查看电力系统的各项数据：使用菜单（MENU）功能1.2.4对测试仪数据集进行内存管理：使用内存（MEMORY0）功能1.2.5对电力系统电能质量有一个总体了解：使用检测（MONITOR）功能。

1.2.6 制作屏幕画面：使用制作屏幕画面（SAVE SCREEN）功能2具体使用介绍：打开测试仪，会出现一个开机欢迎屏幕：按F1键可查看测试仪设置的系统接线方式2.1设置测试仪：点击SETUP键，进入设置菜单界面我们按照设置菜单界面选项按从上到下的界面进行设置。

2.1.1 User用户参数选择：按F4键进入测用户参数选择菜单。

a)相位标记（Phase Identification）：使用下/下箭头键来选择A、B、C 或 L1、L2、L3。

按功能键 F5 –确定（OK）来确认。

b)相位颜色（Phase Colors）使用功能键F1 至F4 来依照在美国、欧盟、英国使用或依照IEC 选择颜色。

【最新试题及答案】电工基础知识问答题以下问答题是电工基础知识学习中的最基础知识，掌握好电工基础知识对进行电工工作具有非常重要的作用。

1.什么是功率因数？如何计算功率因数？答：在交流电路中，电压与电流之间的相位差（∮）角的余弦称为功率因数，用COS∮表示，在数值上等于有功功率和视在功率之比，或电阻与阻抗之比。

即 COS∮＝P/S=P/U×I=I2R/U×I=R/Z平均功率因数＝有功功率/（有功功率2＋无功功率2 ）↑1/2＝有功功率/视在功率2.利用率、负荷率是怎样计算的？利用率＝日平均有功负荷/运行变压器容量×COS∮×100％负荷率＝日平均有功负荷/日最高有功负荷×100％3.有功功率、无功功率、视在功率的计算公式？答：有功功率：在交流电路中，电阻所消耗的功率为有功功率。

单位瓦（W）或千瓦（KW）。

计算式：P=√3 U×I ×COS∮无功功率：在交流电路中电感或电容实际上不消耗电能，它只和电源之间能量转换，只是电场能转换为磁场能或磁场能转换为电场能，能量并没有真正的消耗，使能量转换的功率，称为无功功率。

单位乏war 或千乏kvar。

计算式：Q＝√3U×I×sin∮视在功率：在交流电路中，电压和电流的乘积，或者说有功功率和无功功率的矢量和。

单位伏安（VA）或千伏安（KVA）。

计算式：S=√（P2+Q2 ）=√3 U＊I4.什么是相电压、相电流、线电压、线电流？答：相电压：三相电源中星型负载两端的电压称相电压。

用UA、UB、UC 表示。

相电流：三相电源中流过每相负载的电流为相电流，用IAB、IBC、ICA 表示。

线电压：三相电源中，任意两根导线之间的电压为线电压，用UAB、UBC、UCA表示。

线电流：从电源引出的三根导线中的电流为线电流，用IA、IB、IC 表示。

5.三相对称负载接成星型和三角形时，线电压与相电压，线电流与相电流有什么关系？答：三相对称负载接成星型时：（1）线电压等于相电压的√3 倍，线电压超前相电压30°。

福禄克F430系列三相电能质量分析仪更快、更安全、更详细地定位和诊断的电能质量故障一、技术参数福禄克公司的F434 和F433三相电能质量分析仪可以帮助用户定位、预测、防止和诊断配电系统的故障。

对于那些维护或排障三相配电系统的工作人员来说，这些简便易用的手持工具是“必不可少”的。

新的IEC和GB国标关于闪变和电能质量方面的标准使得在对系统进行电能质量分析监测时有了判断的依据。

z记录三相系统中所有电能质量的参数。

z直观的菜单，最大程度上减少所需的设置。

z工业现场使用最高的安全等级。

z四个电压通道和四个电流通道。

z同时在所有相线上捕获波形数据。

z系统监测：在一个仪表板上现实全部电能质量参数。

z自动显示瞬态尖峰脉冲信号：不会漏掉任何一个事件。

z自动趋势绘图（AutoTrend）功能：无需对记录进行设置！z坚固的手持式设计。

z使用镍氢（NiMH）电池组时，一次充电可使用7个小时。

z将数据文件传输到PC，用于编写报告和利用FlukeView® 软件进行分析。

CAT IV 600 V 和 CAT III 1000 V的安全等级在设计时就考虑了保护用户和设备免受高压电击，福禄克F430系列电能质量分析仪、附件和充电器都经过验证，满足CAT IV 600 V和CAT III 1000 V环境下使用的严格的安全标准。

它们是同类别中第一款符合CAT IV安全等级的工具，所以可以被用于低压配电系统中所有的电气连接和插座。

快捷地观察趋势图利用AutoTrend （自动趋势绘图）功能，可以快速地深入浏览电能质量参数随时间的变化。

所显示的每一读数都被自动并且连续的进行记录，而不必设置触发限值或间隔时间，也无需手动启动记录过程。

可以快速地观察所有相线和零线上电压、电流、频率、功率、谐波或闪变的趋势图；还可以使用光标和缩放功能分析趋势－而不会中断记录。

AutoTrend 功能在后台自动记录显示的所有参数。

在数据和趋势图之间切换，以及使用光标和缩放功能分析测量结果，都不会中断记录过程。

TECHNICAL DATA1770 Series Three-Phase Power Quality AnalyzersAutomatic measurements. More flexibility. Better power quality troubleshooting.Fluke 1770 Series Three-Phase Power Quality Analyzers eliminate the complexities of power quality logging, troubleshooting, and analysis. Engineered to be the faster, easier way to perform power quality studies, the 1770 Series offers automatic measurements, a straightforward user interface and setup, best-in-class specifica-tions, and a simplified reporting platform. The instrument can also be powered directly from the measurement circuit, eliminating the need to find a power outlet or use a lengthy extension cord.With the 1770 Series you’ll never miss a critical power qualityevent—from fast transients up to 8 kV, harmonics up to 30 kHz, dips and swells, as well as the voltage, current, and power measure-ments that enable you to characterize your electrical system.Automatic measurement captureWhether you’re performing a quick system check or a detailed power quality study, consistent data is key. The Fluke 1770 Series offers a unique automatic measurement capture system that helps ensure you’re collecting the right data every time, while still giving you the flexibility to select and adjust specific parameters as needed. More than 500 power quality parameters are cap-tured by default and the guided setup makes it easy to select the right parameters for the system you’re working on. Logged data is instantly viewable, downloadable, and shareable with Fluke Energy Analyze Plus software so you never need to wait to finish a session before reviewing results or analyzing data.Ultimate measurement confidenceThe Fluke 1770 Series are 2-in-1 devices that combine the trouble-shooting functionality of a power quality meter with the robust analysis and logging capabilities of a standalone power quality analyzer—in a single, easy-to-use, handheld device.The ‘PQ Meter’ function gives you immediate access to live on-screen data in the field so you can quickly identify potential problems while troubleshooting. The detailed ‘PQ Logging and Analysis’ function eliminates the complexity of performing power quality studies by guiding you through the setup process ensuring you’re capturing the right data every time. Couple these measure-ment modes with a unique measurement connection autocorrect function and you can be confident that you never need to worry about going back for a second measurement—even if you were unsure about what to look for when you started.AUTOMATICALLY MEASURE POWER AND POWER QUALITY PARAMETERSCritical power quality data is captured as soon as you begin a session, without extensive setup or selectionsINTUITIVE USER INTERFACEThe streamlined user interface makes it easy to navigate between measurement parameters like V/A/Hz, power, dips and swells, harmonics, or power quality health at the push of a buttonHIGH-SPEED VOLTAGE TRANSIENT CAPTURECapture damaging high-speed transients so you can mitigate their effects before equipment failsANALYSIS AND REPORTINGComes standard with Fluke Energy Analyze Plus software giving you the ability to create custom-ized reports, or leverage built-in one-click report-ing to industry standards like EN 50160, IEEE 519and GOST 33073Fluke Energy Analyze Plus: Power quality health summaryFluke Energy Analyze Plus: Energy study tabPowerful analysis software with easy-to-create reportsFluke 1770 Series Power Quality Analyzers come standard with the powerful Fluke Energy Analyze Plus software, designed to eliminate the hassles found with other multi-purpose application software. Energy Analyze Plus helps you evalu-ate power quality data right out of the box and without extensive training.Download, analyze, track, and report powerquality and energy data easier than ever. Quickly compare results to historical values, benchmark against industry norms, compare measured data to local conditions, and create a more complete picture of what’s occurring across your facility, even as the data is still being collected. Energy Analyze Plus offers unified support for the Fluke 1730 Series Energy and Power Loggers, 1740 Series Power Quality Loggers, and 1770 Series Power Quality Analyzers.•“In-workshop” and “in-the-field” download through PC application software•Simple data downloads using USB memory stick, WiFi, LTE, wired Ethernet, or USB cable •Analyze every measured detail of energyconsumption and power quality state-of-health with automated reporting•One-touch reporting creates standardizedreports conforming to standards like EN 50160, IEEE 519, GOST 33073 IEC 61000-2-2, or export data in PQDIF or NeQual compatible format or CSV for use with third-party software•Advanced analysis allows the user to choose any available logged parameter and create a highly customized view of measurements foradvanced data correlationHigh-speed voltage transient captureTransients negatively impact otherwise healthy systems every day and their potential to damage your equipment can’t be underestimated. Whether your system is experiencing impulsive or oscil-latory transients, the results can be devastating and cause problems ranging from insulation fail-ures to total equipment failures. The Fluke 1775 and Fluke 1777 incorporate advanced transient capture technology to help you clearly identify high-speed voltage transients, so you have the data you need to stop them in their tracks. The Fluke 1775 Power Quality Analyzer has 1MHz sampling capability to capture fast transients, while the Fluke 1777 Power Quality Analyzer has 20MHz sampling capability to capture the fastesttransients in high detail.Compliant to international standardsThe Fluke 1770 Series offers the best-in-class accuracy you’ve come to expect from a Fluke Power Quality Analyzer in a IEC 61000-4-30 Class A edition 3 compliant package. On top of that, the 1770 Series has been engineered to meet the future requirements of Class A edition 4, for conformance to EN 50160 and IEEE 519, so you’ll be prepared to tackle tomorrow’s measurement requirements, today.From traditional industrial systems to renewable energy systems to electric vehicles, we’ve got you coveredThe Fluke 1770 Series was designed to be safe and easy to use in any measurement environ-ment. The 1770 Series allows you to capture a full range of power quality variables as well as high-speed waveforms, high-speed transients, and higher frequency harmonics, all of which are instantly viewable on the large, high-resolution screen. With a best-in-class CAT IV 600 V / CAT III 1000 V overvoltage rating, these analyzers can be used at the service entrance or downstream, measuring AC and DC inputs, and harmonics measuring up to 30 kHz. With the 1770 Series you can be confident that you’ll capture the data you need to make better maintenance decisions no matter the task.View real-time voltage transitory events while logging for faster troubleshootingA full range of harmonics are available from the fi rst 50 integer harmonics and from 2 kHz to 30 kHzWork where, when, and how you wantNo two days in the field are the same. You need a power qual-ity analyzer that can go where you go and do what you need it to when you get there. With a full range of accessories and built-in features the Fluke 1770 Series makes it easier to get your job done. The slim ergonomic design and integrated hand strap make it easy to hold and the included hanging kit makes it easy to secure your analyzer inside a cabinet. The integrated internal power supply allows the unit to be powered directly from the measured circuit, while a 90-minute battery helps ensure you can still access and review data even when you aren’t connected to a live system.Quickly and easily transfer data to your PC using the USB C, USB A, Ethernet, WiFi, cellular network support options, depending on your requirements. With an internal GPS module and an optional double insulated external antenna, you can time sync your data for more accurate troubleshooting and analysis.Calculate current harmonics limitsWhen downloading data from the Fluke 1770 Series Power Quality Analyzers the included Energy Analyze Plus software package can compare measured voltage and current harmonic statistical data to different standards, like EN 50160 or IEEE 519, to determine if they exceed compliance limits. This powerful predictive maintenance feature enables current harmonics to be observed before distortion appears in the voltage allowing you to prevent unexpected failures or non-compliance situations and increase system uptime. With the proliferation of inverter-based loads and power generation, keep-ing current harmonics in check is becoming increasingly critical toensure reliable power quality and avoid system downtime.Individual harmonics can be easily selected to view trend data as loads change Easily navigate using the large color touchscreenSpecificationsElectrical measurement accuracy1 Not in 177X/BASIC versions2 Requires 5 m i17XX-FLEX5M-EXT extension cable3 Availability and supported providers vary by country. Check with your local Fluke representative.Electrical measurement accuracy continuedPower/Energy1 Nominal voltage in the range of 100 V to 690 V. Also known as Udin.Reference ConditionsEnvironmental: 23 °C ±5 °C, instrument operating for at least 30 minutes, no external electrical/magnetic field, RH <65 %Input conditions: Cos Φ/PF=1, Sinusoidal signal f=50/60 Hz, power supply 120 V/230 V ±10 %.Current and power specifications: Input voltage >100V Input current > 10 % of current rangePrimary conductor of clamps or Rogowski coil in center positionTemperature coefficient: Add 0.1 x specified accuracy for each degree C above 28 °C or below 18 °C1 Nominal voltage in the range of 100 V to 690 V. Also known as Udin.2 0 °C to 45 °C: Intrinsic Accuracy x2. Outside of 0 °C to 45 °C: Intrinsic Accuracy x33 Only for calibration laboratories4 With iFlex 1500A, I17XX-FLEX1500 24General specificationsOrdering information1Fluke 1777 Power Quality Analyzer. Note: Included items vary by model and are listed in the “Ordering information” table.1 Standard units include i17XX-FLEX1500 24" current probes and a WiFi/BLE adapter. /BASIC models do not include current probes or WiFi/BLE adapters.11 Fluke Corporation 1770 Series Three-Phase Power Quality Analyzers Fluke Corporation PO Box 9090, Everett, WA 98206 U.S.A.For more information call:In the U.S.A. (800) 443-5853 In Canada (800) 36-FLUKE From other countries +1 (425) 446-5500 ©2021 Fluke Corporation. Specifications subject to change without notice.06/2021 210548-enModification of this document is not permitted without written permission from Fluke Corporation.Fluke. Keeping your world up and running.®。

电能质量记录仪：高级电能质量记录仪用于捕获全面的电能干扰细节，包括波形、趋势分析和跨时较长的 A 类“供电质量”合规性测试，以捕获最难跟踪的问题。

电能质量和电能量记录器：电能质量记录器用于清晰描述电能质量、电能量和负载研究以及在用户指定的时间段内捕获难以发现的电压事件。

电能质量故障排除工具和分析仪：专用的电能和电能质量仪表用于执行单相和三相电能质量故障排除和负载研究、能耗分析和供电质量合规性测试。

此外还提供适用于高级电能质量和电机分析仪的型号，旨在进行预防性维护。

Fluke 电能质量和能源工具Fluke 提供的电能质量测试工具种类多样，适用于工业、公共设施和商业建筑应用领域的故障排除、预防性维护以及长期记录和分析具体应用单相三相VR17103451732/173411736/17382174217461748434-II435-II437-II438-II175041760能源研究测量 V 、I 、kW 、Cos/DPF 、kWhr 在能源审计期间获取详细的电能和能耗图并精确地找到节能机会••••••••••••测量最小值/最大值和平均值••••••••••••记录 10 天••••••••••••将浪费的能源换算成金钱••••基本谐波研究总谐波失真测量（电压和电流）发现系统中造成失真的根源，以便能够过滤这些负载或者将它们转移到单独的电路中•••••••••••••电压和电流的谐波分量 1 到 25•（仅电压）••••••••••高级谐波研究完整谐波谱如果失真的负载正导致您的系统出现问题，您就需要获得全面的数据以发现问题根源并找到解决办法••••••••••电能谐波•••••••基本工业电能质量故障排除示波器功能在现场排除故障时，您可以利用图形化数据来追查当前问题的根源••••••••电压骤降和骤升•••••••••••高级电能质量故障排除全面的记录功能复杂的系统通常需要更深入地挖掘测量数据。

多个负载可能正在随机交互作用并引发同一个问题•••••••••••高级功能浪涌电流通过切换负载发现峰值电流。

Ｔhree Phase Ｐowｅr Quality Analyｚｅ
r
Fluke4３５
使
用
手
册
２01０年8月12日
Fｌuke整体介绍
１测量范围:
1.１电压输入：
a)最大输入电压：10００Vrmｓ
b)标称电压范围:50至５０0Ｖ，内部分为三个范围:5０0Ｖ、
250V、１25V
c)最大峰值电压：6ＫV
d)输入阻抗：４MΩ／/5PF
1.２电流输入:
a)输入范围：用仪表附带的电流夹ｉ5s，1至5Armｓ;用可选电
流夹i430fleｘ-4pk，0.1至30０0 Arms
b)输入阻抗:50KΩ
1.1.2标称频率:４0…70Hz
１.2菜单功能介绍：Fluｋｅ435菜单主要有SETＵP、SCＯＰE、MENU、ＭＯ
NITOR、MEMＯＲY、SＡＶE SCREＥN
１.2．１对测试仪进行设置:使用设置（SＥTUP)功能
1．2．2检查电压导线和电流线夹是否正确连接:使用示波器波形(ＳcopｅＷavｅform)和示波相量（Ｓcope Phａsor）功能１.2.3查看电力系统的各项数据：使用菜单（ＭENU）功能
1.2．4对测试仪数据集进行内存管理:使用内存（ＭEMORＹ0)功能
1.２.5对电力系统电能质量有一个总体了解：使用检测(MOＮITＯＲ)功
能。

1.２.６制作屏幕画面:使用制作屏幕画面（SＡVE SCREEN)功能。

SW43W®HOLD RUNPRINTENTERF1F2F3RECORDMENU SAVE • On screen graphics show you how to set up 3 phase power measurements• Watts, power factor, displacement power factor (Cos ␸), VA and VAR• Voltage and current waveforms• Voltage, current, and power harmonics • Up to 51st harmonic• Total harmonic distortion (THD)• Phase angel of individual harmonics• Voltage and current waveforms • True-rms voltage and current • FrequencyFluke 43BPower Quality AnalyzerMaintain power systems, troubleshoot powerproblems, diagnose equipment failuresTechnical DataInput Characteristics RangesAccuracyInput impedance 1 M Ω, 20 pFVoltage rating600 Vrms, CAT IIIVolt / Amps / HertzTrue-rms voltage (AC+DC) 5.000 V, 50.00 V, 500.0 V, 1250 V*±(1 % + 10 counts)True-rms current (AC+DC)50.00 A, 500.0 A, 5.000 kA, 50.00 kA, 1250 kA ±(1 % + 10 counts)Frequency 10.0 Hz to 15.0 kHz ±(0.5 % +2 counts)CF Crest Factor 1.0 to 10.0±(5% + 1 count)PowerW, VA, VAR Reactive Power 250 W 2.50 kW, 25.0 kW, 250 kW, 2.50±(2 % + 6 counts) Total Power 1-phase and 3-phase,3MW, 25 MW, 250 MW, 625 MW, 1.56 GW ±(4 % + 4 counts) Fundamental conductor balanced loads Power PF Power Factor0.00 to 1.00±0.04DPF Displacement Power Factor0.00 to 0.25not specified 0.25 to 0.90±0.040.90 to 1.00±0.03Hz Frequency Fundamental 40.0 to 70.0 Hz ±(0.5 % + 2 counts)HarmonicsVolts, Amps, WattsFundamental V,A ±(3 % + 2 counts), W ±(5 % + 2 counts)2 to 31st Harmonic V,A ±(5 % + 3 counts), W ±(10 % + 10 counts)32 to 51st HarmonicV,A ±(15 % + 5 counts), W ±(30 % + 5 counts)Frequency of fundamental 40 Hz to 70 Hz±0.25 HzPhaseVolt & Amps (between Fund. & Harmonic)2nd (±3°) … 51st (±15°)Watts (between Volt Fund. & Amps Harmonic )Fund (±5°) … 51st (±15°)K-Factor (Amps & Watts) 1.0 to 30.0±10 %THD0.00 to 99.99±(3% + 8 counts)Sags & SwellsRecording times (selectable) 4 min to 16 daysVrms Actual, Vrms max, 5.000 V, 50.00 V 500.0 V, 1250 V*Readings ±(2% +10 counts)min (AC + DC)Cursor readings ±(2% + 12 counts)Cursor Readings Average ±(2% +10 counts)Arms Actual, Arms max,50.00 A, 500.0 A, 5.000 kA, 50,00 kAmin (AC + DC)RecordingRecording times (selectable) 4 min to 16 daysParametersChoose one or two parameters from one of the groups below V/A/Hz Line Voltage, Current, Frequency Power Watts, VA, VAR, PF, DPF, FrequencyHarmonics THD, Volt(Fund. & Harmonic), Amps(F&H) Watts(F&H) Freq.(H), %(H) of total, Phase(H), KF OhmsOhms, Diode, Continuity, Capacitance Temperature °C or °FScope DC Voltage, DC Current, AC Voltage, AC Current, Frequency, Pulse Width + or -,Phase, Duty cycle + or -, Peak max, Peak min, Peak min-max, Crest Factor TransientsMinimum pulse width 40 nsUseful bandwidth input 1DC to 1 MHz (with test leads TL24)Number of transients40Voltage threshold settings 20%, 50%, 100%, 200% above or below reference signalReference signalAfter START, the Vrms and frequency of the signal are measured. From these data a pure sinewave is calculated as reference for threshold setting.Vpeak min, Vpeak max at cursor 10 V, 25 V, 50 V, 125 V, 250 V, 500 V, 1250 V ±5% of full scale*Rated 600V CAT IIISpecifications Fluke 43B Power Quality AnalyzerAccuracies are stated as ±(percentage of reading + counts) without probes unless otherwise noted.Specifications are valid for signals with a fundamental between 40 and 70 Hz.The Fluke 43B Power Quality Analyzer is optimized for industrial measurements on the 50 Hz fundamental frequency. Since its usable fundamental frequency range extends from 10 Hz to 400 Hz, the 43B is ideal for industrial, aviation, marine and railway applications.Note: Current harmonics measurements can be done via channel 1 with improved accuracy• Continuously measure volts and amps on a cycle-by-cycle basis for up to 16 days • Use cursors to read time and date of sags and swells• Catch voltage transients and waveform distortion• Catch and save up to 40 transients• Correlate the cause of transients with time and date stampsModeUsable bandwidth Harmonics on 400 Hz fundamentalTypical accuracy for 400 Hz fundamentalVolt Amp Hz 10 Hz … 3.5 kHz 9th harmonic 5%Power 20Hz … 2 kHz 5th harmonic 10%Harmonics10 Hz … 3.5 kHz9th harmonic10% Channel 150% Channel 2®Inrush Current Ranges Accuracy Current ranges (selectable) 1 A, 5 A, 10 A, 50 A, 100 A, 500 A, 1000 A Inrush times (selectable)l s, 5 s, 10 s, 50 s, 100 s, 5 min Cursor readings A peak max at cursor 1 and cursor 2±5% of full scale Time between cursors** 4 to 235 pixels ±(0.2% + 2 pixels)Scope, dual channel scope with measurement reading Input Impedance Input 1 1 M Ω//12 pF; with BB120: 20 pF ±2 pF; with BB120 ±3 pF Input 2 1 M Ω//10 pF; with BB120: 18 pF ±2 pF; with BB120 ±3 pF VerticalVoltage ranges 50 mV/div to 500V/div ±(1% + 2 pixels)Vertical sensitivity, resolution 5 mV/div to 500V/div, 8 bit (256 levels)Bandwidth channel [1] (voltage)DC to 20 MHz at inputs, or with BB120 and VPS40 (standard with Fluke 43B);1 MHz with TL24 LeadsBandwidth channel [2] (current)DC to 15 kHz at inputs10 kHz with supplied current clampsCoupling DC, AC (10 Hz -3 dB)HorizontalTimeBase modes Normal, roll, single TimeBase ranges 60 s/div to 20 ns/div ±(0.4% + 1 pixel)Sampling rate 25 MS/s Record length 512 per channel (min / max samples)Trigger source Input 1 or Input 2 or Automatic selection Trigger Mode Automatic Connect-and-View™, Free Run,Single Shot.Connect-and-View™Advanced automatic triggering that recognizes signal patterns and automaticallyadjusts triggering, timebase and amplitude. Automatically displays stable pictures of complex and dynamic signals like motor drive and control signals.Pre-trigger Up to 10 divisions Measurement readings,Volts & Amps (DC, AC, AC + DCrms, Peak max, Peak min, Peak min / max ),per channel selectable Frequency, Duty cycle + or - , Phase, Pulse Width + or -, Crest factor Ohms, Diode, Continuity, Capacitance Ohms 500.0 Ω 5.000 k Ω, 50.00 k Ω, 500.0 k Ω,±(0.6% +5 counts)5.000 M Ω, 30.00 M ΩDiode voltage 0 to 3.000 V ±(2% +5 counts)Continuity, shorts > 1 ms Beeper on at < 30Ω±5Ω,Capacitance 50.00 nF, 500.0 nF, 5.000 µF, 50.00 µF,±(2% +10 counts)500.0 µFTemperature***-100.0 °C to 400.0 °C,±(0.5% +5 counts)-200.0 °F to 800.0 °FMax current, max open circuit volt.0.5 mA, < 4 V (all functions above)MemoryNumber of screens 20Optical Isolated RS-232 Interface To printer Supports HP LaserJet, DeskJet, Epson FX/LQ and Postscript printers withoptional PAC91 Printer Adapter CableTo PC FlukeView Power Quality Analyzer software with PM9080 InterfaceAdapter included with 43B and 43KitFlukeView Power Quality Software Hardware requirements PC or 100% compatible with Windows 95, 98, Me, 2000, NT4.0.** 1 pixel = inrush time/250*** Requires optional temperature accessory• Inrush current up to 500 A with 80i500s and up to 200 A with i200s• Use cursors to measure inrush current timing• Connect-and-View™ scope for quick wavefrom display• View voltage and current channels simultaneously• Up to 20 MHz bandwidh with VPS4010:1 voltage probe (standard with Fluke 43B)• FlukeView ®Power Quality Analyzer software (included with 43B and 43Kit)• Capture measurement screens for professional-looking reports• Log readings to your computer disk drive • Works with Windows word processing,spreadsheet and analysis software• Windows 95 / 98 / Me / 2000 / NT 4.0Standard available in all models43Basic43B43Kit Fluke 43B Power Quality Analyzer●●●BP120 NiCd Battery Pack (installed)●●●PM 8907 Battery Charger/Line Voltage Adapter●●●TL24 Test Leads●●●AC20 Industrial Test Clips●●●TP4 Slim Reach Test Probe Set (4 mm)●●●BB120 Banana-to-BNC Adapter Plug●●●Model differencei200s AC Current Clamp (200 A)●80i500s AC Current Clamp (500 A)●●SW43W FlukeView Software for Windows●●PM 9080 Serial Interface/Adapter Cable●●C120 Hard Case●●TP1 Slim Reach Test Probe Set (flat blade)●●AC85 Large Jaw Alligator Clips●●Power Quality Video●●Users Manual / Application Guide●Manual CD 43B●●Promotional Model NumbersVPS40 Voltage Probe●Fluke 61 IR Thermometer●Fluke VR101S Voltage Event Recorder System●Optional AccessoriesC789 Soft Meter Case80i110s AC/DC Current Clamp (100 A) i1000s AC Current Clamp (1000 A)i2000sflex AC Current Clamp (2000 A) i3000s AC Current Clamp (3000 A)80TK Thermocouple Module (Type K) 80T-IR Infrared Temperature Probe80T-150U Universal Temperature Probe PAC91 Printer Adapter Cable TL76 All-in-one Test Lead SetTL910 Electronic Test Probe SetTL220 SureGrip Industrial Test Lead Kit TP220 SureGrip Test Probe SetAC220 SureGrip Alligator Clip SetAC280 SureGrip Hook Clip SetAC283 SureGrip Pincer Clip SetAC285 SureGrip Alligator Clip SetPowerLine voltage adapter/battery charger includedInstalled battery Rechargeable NiCd pack (4 to 6 Vdc)Operating time 4 hoursCharging time 4 hours (unit OFF) 12 hours (unit ON)Refresh Cycle8 to 14 hours (to keep NiCd battery capacity optimal) EnvironmentalTemperature0ºC to 50ºC (32ºF to 122ºF)Environmental MIL 28800E, Type 3, Class III, Style BEnclosure IP51 (dust, drip water proof)Mechanical DataSize (H x W x D)232 x 115 x 50 mm (9.1 x 4.5 x 2 inches)Weight 1.1 kg (2.5 lbs.) incl. battery packSafetyFor measurements on 600 Vrms Category III installations, Pollution Degree 2 in accordance withEN61010-1 (1993) (IEC1010-1)ANSI/ISA S82.01-1994CAN/CSA-C22.2 No. 1010.1-92UL3111-1Surge protection 6 kV on input 1 and 2Floating measurements600 Vrms from any terminal to groundWarranty 3 years parts and labor on Fluke 43B, 1 year on accessories Ordering InformationFluke 43Basic Power Quality AnalyzerFluke 43B Power Quality AnalyzerFluke 43Kit Power Quality Analyzer®Specifications Fluke VR101S Voltage Event Recorder SystemElectrical(voltage versions, plug style, and manual languages are determined by country)Voltage Version Operating range Nominal frequencies Power consumption120 V70 V to 140 V50 Hz or 60 Hz 2 W230 V 140 V to 270 V50 Hz or 60 Hz 3 WSags, Swells and Outage MeasurementsVoltage Version Range Accuracy Resolution120 V Hot-to-neutral0 to 200 V rms±2 V rms 1 V rmsNeutral-to-ground 3 to 200 V rms±2 V rms 1 V rms230 V Hot-to-neutral0 to 400 V rms±4 V rms 2 V rmsNeutral-to-ground 3 to 120 V rms±2 V rms 1 V rmsTransient MeasurementsRange Accuracy ResolutionHot-to-neutral100 to 2500 V peak±(10% reading +10 V)10 VNeutral-to-ground50 to 2500 V peak±(10% reading +10 V)10 VPhase angle20°to 180°±1°1°200°to 360°Minimum pulse width: 1 µsFrequency MeasurementsRange Accuracy Resolution45 to 65 Hz±0.1 Hz (3 cycles min)0.1 HzTime Measurements: Events < 1 secondAccuracy ResolutionHot-to-neutral±0.5 cycles0.5 cyclesNeutral-to-ground±1 cycle 1 cycleEvents ≥1 second (time stamp)Accuracy Resolution±(2 sec/day + 8 sec)8 secGeneral SpecificationsMemory size4000 eventsPowerBattery type 3.5V lithium (non-replaceable)Battery life7 yearsMechanicalPhysical size85 mm x 68 mm x 35 mmWeight120gEnvironmentalOperating temperature-40 to 70°CRelative Humidity0 to 95% (non-condensing)SafetyCSA Certification pending, CSA-NRTL (to UL 3111) certification pending,Complies with requirements of EN61010-1:1993Warranty 1 yearFluke CorporationP.O. Box 9090Everett, WA USA 98206Fluke Europe B.V.P.O. Box 11865602 BD EindhovenThe NetherlandsFluke (UK) LtdIndustrial SalesThe Metro CentreDwight Road, WatfordWD1 8HGUnited KingdomTel.:***********Fax:***********E-mail:*******************.nlVisit us on the world wide web at: For more information call:In the U.S.A. (800) 443-5853or Fax (425) 456-5116In Europe/M-East/Africa+31 (0)40 2 675 200or Fax +31 (0)40 2 675 222In Canada (905) 890-7600or Fax (905) 890-6866From other countries+1 (425) 456-5500or Fax +1 (425) 456-5116Visit us on the world wide web at: © Copyright 2001 Fluke Corporation.All rights reserved.Printed in the Netherlands 06/03.Data subject to alteration without notice. Pub_ID: 10630-engRev. 01Fluke.Keeping your worldup and running.SW43W。
