General Purpose PowerWirewound Resistors

PW Series

•2 watts to 25 watts

•0.10 ohms to 30K ohms

•±10% or ±5% tolerance

•TC’s from 300 ppm/°C to +5500 ppm/°C

General NoteWelwyn Components reserves the right to make changes in product specification without notice or liability. All information is subject to Welwyn’s own data and is considered accurate at time of going to print.

© Welwyn Components Limited· Bedlington, Northumberland NE22 7AA, UKTelephone: +44 (0)1670 822181 · Facsimile: +44 (0)1670 829465 · Email: info@welwyn-tt.com · Website: www.welwyn-tt.com

111PW-2PW-3PW-5PW-7PW-10PW-15PW-18PW-22PW-25

Power rating at 25°Cwatts23571015182225

Resistance rangeohms0R15 to 2K40R1 to 7K50R1 to 8K50R1 to 18K0R18 to 30K0R18 to 30K0R18 to 22K0R27 to 18K0R27 to 18K

Temperature coefficient0.06%/°C0.15 to 0.990.1 to 0.990.1 to 0.990.1 to 0.990.18 to 0.990.18 to 0.990.18 to 0.990.27 to 1.30.27 to 1.3

over R range0.03%/°C1.0 to 2.4K1.0 to 7.5K1.0 to 8.5K1.0 to 18K1.0 to 30K1.0 to 30K1.0 to 22K1.5 to 12K1.5 to 10K

+0.55%/°C0.1 to 300.1 to 860.1 to 680.1 to 1500.1 to 2400.1 to 2400.1 to 2000.15 to 3600.15 to 300

+0.45%/°C0.24 to 1300.1 to 2700.1 to 3000.15 to 6800.24 to 11000.24 to 11000.24 to 11000.36 to 18000.36 to 1200

+0.25%/°C1.0 to 100.24 to 200.27 to 221.0 to 511.0 to 821.0 to 821.0 to 701.0 to 1201.5 to 100Electrical Data

Physical Data

Issue B · 03.02A subsidiary of TTelectronics plcWelwyn Components

Please note: When ordering the alternative configuration please add an ‘A’ after the part number. (i.e., PW-2A)

Dimensions (mm)

L ±0.8W ±0.8H ±0.8d dia.E ±0.8LL min.F (ref.)

PW-217.56.356.350.87.8736.61.60

PW-322.47.877.870.919.6536.61.60

PW-522.49.658.640.9110.438.11.60

PW-735.39.658.640.9111.938.13.18

PW-1047.89.658.640.9111.938.13.18

PW-1547.812.712.70.9116.038.13.18

PW-1847.812.712.70.9116.038.13.18

PW-2263.512.712.71.0*16.038.13.18

PW-2563.512.712.71.0*16.038.13.18

* Copper Clad Steel

L0.125 max.dW

H

LLE

FStandard ConfigurationAlternate Configuration元器件交易网www.cecb2b.com

General Purpose Power

Wirewound ResistorsPW Series

© Welwyn Components LimitedBedlington, Northumberland NE22 7AA, UKTelephone: +44 (0)1670 822181 · Facsimile: +44 (0)1670 829465 · Email: info@welwyn-tt.com · Website: www.welwyn-tt.com

112

Issue B · 03.02Welwyn Components

100

80

60

40

20

0050100150200250Ambient Temperature (°C)Percent of Rated Load254085

PW-2

PW-3, 5, 7, 10

PW-15, 18, 22, 25300

250

200

150

100

50

0020406080100120Temperature Rise (°C)

Percent of Rated LoadPW-22, 25

PW-15, 18PW-10PW-7PW-5PW-3Power DeratingTemperature Rise

Packaging

Resistors are supplied bulk packed. Quantity 500.元器件交易网www.cecb2b.com

General Purpose PowerWirewound Resistors

PW Series

•20 watts to 50 watts

•0.10 ohms to 2.0K ohms

•±10% or ±5% tolerance

•Customs

General NoteWelwyn Components reserves the right to make changes in product specification without notice or liability. All information is subject to Welwyn’s own data and is considered accurate at time of going to print.

© Welwyn Components Limited· Bedlington, Northumberland NE22 7AA, UKTelephone: +44 (0)1670 822181 · Facsimile: +44 (0)1670 829465 · Email: info@welwyn-tt.com · Website: www.welwyn-tt.com

113PW-20EPW-30PW-40PW-50EPower rating at 25°Cwatts20304050Resistance rangeohms0R1 to 2K0R5 to 1K20R65 to 1K50R08 to 1K8Electrical Data

Issue B · 03.02A subsidiary of TTelectronics plcWelwyn Components

Please note: When ordering the alternative configuration please add an ‘A’ after the part number. (i.e., PW-2A)

0.032±0.0025

0.205 or 0.187±0.0050.157±0.0200.250 (Typ.)

0.5±0.030

0.5±0.0305/32 Dia. Thru (2)A

0.069±0.005

0.25±0.0310.032±0.0025

0.375

0.200 (Typ.)

0.135±0.0150.25

0.750.282±0.020

0.75±0.030

0.75±0.0300.8755/32 Dia. Thru (2)

A

B

0.125±0.015PW-20E WirewoundPW-30, 40 and 50E Wirewound

PW-20E Alternate Terminal ConfigurationPrinted Circuit TerminalDimensions (Inches)A ±0.030B ±0.060 PW-20E1.8752.50PW-302.002.55PW-402.453.00PW-50E3.0753.625

2.000±0.040

0.187±0.0101.410±0.040

1.050 Min.0.060 Dia. (2)0.500±0.030

0.500±0.0300.840±0.0400.250 min.0.020PW-15E100

80

60

40

20

0050100150200250Ambient Temperature (°C)Percent of Rated LoadPW-20E, PW-30, PW-40PW-50E without bracket

300

250

200

150

100

50

00255075100125Temperature Rise (°C)

Percent of Rated LoadPW-30PW-40PW-50E

PW-20EWith Bracket:PW-30 Increased to 40 wattsPW-40 Increased to 50 wattsPW-50 Increased to 60 wattsPower Derating

Temperature Rise元器件交易网www.cecb2b.com
