软件安装步骤：1、在英文操作系统下，通过安装光盘进行SIL worx安装，版本为8.3，注意授权狗的版本和软件版本一致，安装结束打开程序。

2、NEW 一个项目，3、将Resource下的属性中的ID号改为：100；在下面的minmumconfiguration version,修改为：SIL worX V4，否则load出错；4、建立变量，可以右键导出后缀为csv的elcel文档，建立后导入；5、导入Lib,(注意授权狗和系统版本对应，否则导不进去)；6、编写logic，注意数据类型；7、硬件配置，CPU IP地址为99; CM: IP地址为100；对于多CPU修改。

8、将变量拖拽至上面对应卡件的对应通道中，（和接线图一致）；9、点击保存，关对应窗口。

10、建立OPCA、在工程师站上安装X-OPC server,注意安装结束后打钩：运行x-opc server,此程序要求一直运行。

B、配置OPC的ID,输入购买的ID号，C、在configure/new/opc-server set, 起一个名字；D、在新建opc-server set名字\ new\opc-server\properties 输入ID号点击OK;E、在License Management \new\Licenes key , 右键属性，输入激活码，F、在OPC-host \ 建立IP connection \输入本机的IP。

G、点击safeethernet ,弹出窗口，将下面的Resources 拖拽至上面设置一个名字即可。

H、至此OPC通讯设置完成。

11、在Resource\new\Alarm＆Envent，点击：Alarm＆Envent，将弹出窗口中下面的变量全部选中，拖拽至上面的：Event Definition BOOL 窗口下，进行关联报警。

12、至此系统的SOE配置完成，进行保持、编译，进行下装。

13、下装时顺序为：Resource , Opc server, configure; 下装结束后点击：Opc server和Resource设置为online ,可以查看程序运行情况，14、如果要在线force, 须进行：forcing \force editor\start globalforcing .15、如果需要在线diagnosis, 需要将Hardware 设置为online ，硬件块上出现绿色打钩。
