二、调速器的类型
1．按调速范围分类 （1）极限调速器（限速器） 只用于限制柴油机的最高 转速不超过某规定值，在转速低于此规定值时不起调节作 用。此种调速器仅用于船舶主机，目前已很少单独使用。 （2）定速（单制）调速器 在负荷变化时能使柴油机转速 保持在规定范围内。此种调速器应用于发电柴油机。 （3）双制式调速器 能维持柴油机的最低运转转速并可限 制其最高转速。其中间转速由人工手动调节。此种调速器 用于对低速性能要求较高或带有离合器的中小型船用主机。 （4）全制式调速器 在从最低稳定转速到最高转速的全部 运转范围内，均能自动调节喷油量以保持任一设定转速。 此种调速器广泛用于船舶主机及柴油机发电机组。
三、超速保护装置 1．作用：防止在调速器损坏时造成柴油机超速而损 坏。
超速保护装置是一种运转安全装置，与调速器不一
样，它只限制柴油机转速，本身无调速特性。在柴油 机正常运转范围内不起作用，只在转速达到规定值时 才发生动作使柴油机立即停车或降速。
我国有关规定：Nb≥220KW的主机和柴油发电机应 装超速保护装置，以防主机n＞120%nb，柴油发电机 n＞115%nb。
我国有关规范要求发电柴油机的≯10％；（突加50％
后再加50％全负荷）≯10％。
2）稳定时间ts 指从突加（或突减）全负荷后转速刚偏离最高空载 转速的波动范围（或标定转速的波动范围）到转速 恢复到标定转速的波动范围（或最高空载转速的波 动范围）为止所需时间（s）。我国有关规范规定， 交流发电机ts≯5s。
nm=(ncmax+ncmin)/2。 一般，在标定工况时Φ≤(0.25~0.5)%；φ≤(0.5~1)%。
3）不灵敏度ε
n2 n1 100%
令：
nm
式中：n1——柴油机转速减少时，调速器开始起作用
