© Semiconductor Components Industries, LLC, 2006July, 2006 − Rev. 61Publication Order Number:CS5160/D CS5160
CPU 5−Bit Synchronous
Buck Controller
The CS5160 is a 5−bit synchronous dual N−Channel buckcontrollers designed to provide unprecedented transient response fortoday’s demanding high−density, high−speed logic. It operates using aproprietary control method which allows a 100 ns response time toload transients. The CS5160 is designed to operate over a 9
−16 Vrange (VCC) using 12 V to power the IC and 5.0 V as the main supplyfor conversion.The CS5160 is specifically designed to power Pentium® IIIprocessors and other high performance core logic. They include thefollowing features: on board 5−bit DAC, short circuit protection, 1.0%output tolerance, VCC monitor, and programmable Soft Startcapability. The CS5160 is available in a 16 pin surface mount package.
Features•Dual N−Channel Design•Excess of 1.0 MHz Operation•100 ns Transient Response•5−Bit DAC•Backward Compatible with CS515X Family•30 ns Gate Rise/Fall Times•0.8% DAC Accuracy for the 01111 DAC Code•5.0 V & 12 V Operation•Remote Sense•Programmable Soft Start•Lossless Short Circuit Protection•VCC Monitor•V2™ Control Topology•Overvoltage Protection
CS5160GDR16http://onsemi.com
MARKINGDIAGRAMS
A= Assembly LocationWL, L= Wafer LotYY, Y= YearWW, W= Work Week
DevicePackageShippingORDERING INFORMATION
CS5160GD16SO−1648 Units/Rail
SO−162500 Tape & Reel1COMP
VFFBVFB
COFFSSVID0
VCC2VCC1VGATE(L)
VGATE(H)PGndPIN CONNECTIONS
LGndVID1VID2VID3
VID4SOIC−16D SUFFIXCASE 751B116
CS5160AWLYWW元器件交易网www.cecb2b.comCS5160
http://onsemi.com2
COMPVFFBVFBVGATE(H)
VGATE(L)VCC2VCC1
VID0VID1VID2VID3VID4
PGnd
SSCOFFCS5160
MBRS140T3SILICONIXSanyo GX12 V
680 pF
0.1 μF
LGnd1200 μF/10 V × 6.00.1 μF
VOUTVID0VID1VID2VID3VID4SILICONIXSUD50NO3−07
Sanyo GX1200 μF/10 V × 8.01.8 μHSUD50NO3−10P0.33 μF
1.3 k1.0 μH5 V
Figure 1. Application Diagram, 5.0 V to 1.5 V/15 A Core Logic Converter with 12 V Bias
MAXIMUM RATINGS*
RatingValueUnit
Operating Junction Temperature, TJ0 to 150°C
Lead Temperature Soldering: Reflow: (SMD styles only) (Note 1)230 peak°C
Storage Temperature Range, TS−65 to +150°C
ESD Susceptibility (Human Body Model)2.0kV1.60 second maximum above 183°C.*The maximum package power dissipation must be observed.
MAXIMUM RATINGS
Pin NameMax Operating VoltageMax Current
VCC116 V/−0.3 V100 mA DC/1.5 A peak
VCC218 V/−0.3 V100 mA DC/1.5 A peak
SS6.0 V/−0.3 V−100 μA
COMP6.0 V/−0.3 V200 μA元器件交易网www.cecb2b.comCS5160
http://onsemi.com3MAXIMUM RATINGS (continued)Pin NameMax CurrentMax Operating Voltage
VFB6.0 V/−0.3 V−0.2 μA
COFF6.0 V/−0.3 V−0.2 μA
VFFB6.0 V/−0.3 V−0.2 μA
VID0 − VID46.0 V/−0.3 V−50 μA
VGATE(H)18 V/−0.3 V100 mA DC/1.5 A peak
VGATE(L)16 V/−0.3 V100 mA DC/1.5 A peak
LGnd0 V25 mA
PGnd0 V100 mA DC/1.5 A peak
ELECTRICAL CHARACTERISTICS (0°C < TA < +70°C; 0°C < TJ < +85°C; 9.5 V < VCC1 < 14 V; 5.0 V < VCC2 < 16 V; DACCode: VID4 = VID2 = VID1 = VID0 =1; VID3 = 0; CVGATE(L) and CVGATE(H) = 1.0 nF; COFF = 330 pF; CSS = 0.1 μF, unless otherwise specified.)
CharacteristicTest ConditionsMinTypMaxUnit
Error Amplifier
VFB Bias CurrentVFB = 0 V−0.31.0μA
Open Loop Gain1.25 V < VCOMP , 4.0 V; CCOMP = 0.1 μF;Note 2−80−dB
Unity Gain BandwidthCCOMP = 0.1 μF; Note 2−50−kHz
COMP SINK CurrentVCOMP = 1.5 V; VFB = 3.0 V; VSS > 2.0 V3060120μA
COMP SOURCE CurrentVCOMP = 1.2 V; VFB = 2.7 V; VSS = 5.0 V153060μA
COMP CLAMP CurrentVCOMP = 0 V; VFB = 2.7 V0.41.01.6mA
COMP High VoltageVFB = 2.7 V; VSS = 5.0 V4.04.35.0V
COMP Low VoltageVFB = 3.0 V−1.001.15V
PSRR8.0 V < VCC1 < 14 V @ 1.0 kHz; CCOMP = 0.1 μF; Note 2−70−dB
Transconductance−−33−mmho
VCC1 MonitorStart ThresholdOutput switching8.608.959.30V
Stop ThresholdOutput not switching8.458.809.15V
HysteresisStart−Stop−150−mV
Soft Start (SS)
Charge Time−1.63.35.0ms
Pulse Period−25100200ms
Duty Cycle(Charge Time /Pulse Period) × 1001.03.36.0%
COMP Clamp VoltageVFB = 0 V; VSS = 00.500.951.10V
VFFB SS Fault DisableVGATE(H) = Low; VGATE(L) = Low0.91.01.1V
High Threshold−−2.53.0V
2.Guaranteed by design, not 100% tested in production.元器件交易网www.cecb2b.comCS5160
http://onsemi.com4ELECTRICAL CHARACTERISTICS (continued) (0°C < TA < +70°C; 0°C < TJ < +85°C; 9.5 V < VCC1 < 14 V; 5.0 V < VCC2 < 16 V; DACCode: VID4 = VID2 = VID1 = VID0 =1; VID3 = 0; CVGATE(L) and CVGATE(H) = 1.0 nF; COFF = 330 pF; CSS = 0.1 μF, unless otherwise specified.)
CharacteristicUnitMaxTypMinTest Conditions
PWM Comparator
Transient ResponseVFFB = 0 to 5.0 V to VGATE(H) = 9.0 V to 1.0 V;VCC1 = VCC2 = 12 V−100125ns
VFFB Bias CurrentVFFB = 0 V−0.3−μADAC
Input ThresholdVID0, VID1, VID2, VID3, VID41.001.252.40V
Input Pull Up ResistanceVID0, VID1, VID2, VID3, VID42550110kΩ
Pull Up Voltage−4.855.005.15V
