常用原理图元件符号、PCB封装及所在库
序
号
元件名称封装名称原理图符号及库PCB封装形式及库
1
Battery
直流电源
BAT-2 Battery
BT?
Miscellaneous
Devices.IntLib
Miscellaneous Devices PCB.PcbLib
2 Bell
铃
PIN2
Bell
LS?
Miscellaneous
Devices.IntLib
Miscellaneous Connector PCB.PcbLib
3
Bridge1
二极管整流
桥
E-BIP-P4/D Bridge1
D?
Miscellaneous
Devices.IntLib
Bridge Rectifier.PcbLib
4
Bridge2
集成块整流
桥
E-BIP-P4/x
AC
2
V+
1
AC
4
V-
3
Bridge2
D?
Miscellaneous
Devices.IntLib
Bridge Rectifier.PcbLib
5 Buzzer
蜂鸣器
PIN2
Buzzer
LS?
Miscellaneous
Devices.IntLib
Miscellaneous Connector PCB.PcbLib
6
Cap
无极性电容
RAD-0.3
Cap
C?
Miscellaneous
Devices.IntLib
Miscellaneous Devices PCB.PcbLib
7
Cap
极性电容100pF
Cap Pol1
C?
号
8 Electro 1
电解电容
RB-.2/.4
(99) Miscellaneous
Devices.Lib(99)Miscellaneous.ddb
9 Cap Semi
贴片电容
C3216-1206
Cap
C?
Miscellaneous
Devices.IntLib
Miscellaneous Devices PCB.PcbLib
10
D Zener
稳压二极管
DIODE-0.7
D Zener
D?
Miscellaneous Devices PCB.PcbLib
11
Diode
二极管
DSO0C2/X Diode
D?
Miscellaneous
Devices.IntLib
Small Outline Diode - 2 C-Bend
Leads.PcbLib
12
Dpy
RED-CA
数码管
DIP10
a
b
f
c
g
d
e
VCC
1
2
3
4
5
6
7
a
b
c
d
e
f
g
8dp
dp
9
10
NC
Dpy Red-CA
DS?
Miscellaneous
Devices.IntLib
Miscellaneous Devices PCB.PcbLib
13 Fuse 2
熔断器
PIN-W2/E Fuse 2
F?
Miscellaneous
Devices.IntLib
Miscellaneous Devices PCB.PcbLib
14 Inductor
电感
C1005-0402 10mH
Inductor
L?
Miscellaneous
Devices.IntLib
Miscellaneous Devices PCB.PcbLib
15
JFET-P
场效应管
CAN-3/D
3
2
1
JFET-P
Q?
号
Miscellaneous Devices.IntLib Vertical, Single-Row, Flange Mount
with Tab.PcbLib
16 Jumper
跳线
RAD-0.2 Jumper
W?
Miscellaneous
Devices.IntLib
Miscellaneous Devices PCB.PcbLib
17
Header5
单排插针
HDR1X5
1
2
3
4
5
Header 5
JP?
Miscellaneous
Connectors.IntLib
Miscellaneous Connector PCB.PcbLib
18 Lamp
灯
PIN2 Lamp
DS?
Miscellaneous
Devices.IntLib
Miscellaneous Connector PCB.PcbLib
19
LED1
发光二极管
LED-1
12
LED1
DS?
Miscellaneous
Devices.IntLib
Miscellaneous Devices PCB.PcbLib
20 MHDR2×4
双排插针
MHDR2×4
12
34
56
78
MHDR2X4
JP?
Miscellaneous
Connectors.IntLib
Miscellaneous Connector PCB.PcbLib
21
Mic2
麦克风
DIP2 Mic2
MK?
Miscellaneous
Devices.IntLib
Miscellaneous Connector PCB.PcbLib
22 Motor Serxo
伺服电机
RAD-0.4
Motor Servo
B?
Miscellaneous
Miscellaneous Devices PCB.PcbLib
