Diffusion and Separation of CO2and CH4in Silicalite,C168Schwarzite, and IRMOF-1:A Comparative Study from Molecular DynamicsSimulationRavichandar Babarao and Jianwen Jiang*Department of Chemical&Biomolecular Engineering,National Uni V ersity of Singapore,Singapore117576Recei V ed No V ember3,2007.Re V ised Manuscript Recei V ed February28,2008Recently we have investigated the storage and adsorption selectivity of CO2and CH4in three different classes of nanoporous materials s silicalite,IRMOF-1,and C168schwarzite through Monte Carlo simulation(Babarao,R.;Hu, Z.;Jiang,ngmuir,2007,23,659).In this work,the self-,corrected,and transport diffusivities of CO2and CH4 in these materials are examined using molecular dynamics simulation.The activation energies at infinite dilution are evaluated from the Arrheniusfits to the diffusivities at various temperatures.As loading increases,the self-diffusivities in the three frameworks decrease as a result of the steric hindrance;the corrected diffusivities remain nearly constant or decrease approximately linearly depending on the adsorbate and framework;and the transport diffusivities generally increase except for CO2in IRMOF-1.The correlation effects are identified to reduce from MFI,C168to IRMOF-1, in accordance with the porosity increasing in the three frameworks.Predictions of self-,corrected,and transport diffusivities for pure CO2and CH4from the Maxwell-Stefan formulation match the simulation results well.In a CO2/CH4mixture,the self-diffusivities decreases with loading,and good agreement is found between simulated and predicted results.On the basis of the adsorption and self-diffusivity in the mixture,the permselectivity is found to be marginal in IRMOF-1,slightly enhanced in MFI,and greatest in C168schwarzite.Although IRMOF-1has the largest storage capacity for CH4and CO2,its selectivity is not satisfactory.I.IntroductionNanoporous materials have been widely utilized in catalysis, ion exchange,gas storage,and purification.1In the nanodomain,fluids diffuse significantly differently from bulkfluids because of spatial confinement and surface interaction.2Understanding such diffusion behavior is not only of fundamental interest but also of central importance for industrial applications.There have been a large number of experimental studies on the determination of diffusivities in zeolites,carbons,and other materials.3,4 Nevertheless,with ever-growing computational power,com-putationally based molecular simulation has played an increas-ingly important role in nanoscience and nanotechnology.5 Simulation on the nanoscale can provide microscopic pictures that are experimentally inaccessible or difficult,if not impossible, to obtain.As a consequence,deeper insight can be gained from molecular simulation,thus assisting the rational design of new materials of increasing complexity.We will give a brief review of simulation studies on diffusion in various nanomaterials,among which zeolites are the most commonly investigated.In the early1990s,Theodorou and co-workers examined the self-diffusion of CH4in silicalite using equilibrium molecular dynamics(MD)6and transport diffusion using both equilibrium and nonequilibrium MD.7Recently,they simulated the self-and transport diffusion of CO2and N2in silicalite over a wide range of occupancies by using various forcefields and made a comparison with experimental data.8,9 Sholl and co-workers computed the transport diffusion of CH4 and CF4in silicalite and found that the Darken approximation is valid only for CH4and deviates strongly for CF4at all temperatures.10From the self-and transport diffusion of seven light gases separately in silicalite at room temperature,they observed that the self-diffusivity decreases with increased loading as a result of steric hindrance;however,the reverse is true for transport diffusivity.11They compared the simulation and experimental results for the permeation of the CH4/CF4mixture through silicalite and found that atomistic modeling correctly predicted silicalite to be more selective for CF4.12From simulation, they investigated the effects of pore shape and connectivity on the diffusion of gases in silica zeolites13and also the effects of the sweep gas and porous support on zeolite membranes using atomic and continuum models.14Recently,Sholl published a comprehensive review on understanding diffusion in crystalline nanoporous materials using simulations.15Snurr and co-workers made thefirst comparison for the self-diffusivities of the CH4/ CF4mixture in silicate between simulation and NMR experiments, and good agreement was observed.16They inspected the structural and transport properties of CF4and n-alkane mixtures in faujasite from MD simulation and found that whereas the main-term transport diffusivities are greater than their self-diffusivity counterparts the cross-term diffusivities are1order of magnitude*Author to whom correspondence should be addressed.Tel:(65)6516 5083.Fax:(65)67791936.E-mail:chejj@.sg.(1)Macilwain,C.Nature2000,405,730.(2)Martin,C.R.;Siwy,Z.Nat.Mater.2004,3,284.(3)Karger,J.;Ruthven,D.Diffusion in Zeolites and Other Microporous Solids; Wiley:New York,1992.(4)Demontis,P.;Suffritti,G.B.Chem.Re V.1997,97,2845.(5)Drexler,put.Theor.Nanosci.2006,3,1.(6)June,R.L.;Bell,A.T.;Theodorou,D.N.J.Phys.Chem.1990,94,8232.(7)Maginn,E.J.;Bell,A.T.;Theodorou,D.N.J.Phys.Chem.1993,97,(8)Makrodimitris,K.;Papadopoulos,G.K.;Theodorou,D.N.J.Phys.Chem. B2001,105,777.(9)Papadopoulos,G.K.;Jobic,H.;Theodorou,D.N.J.Phys.Chem.B2004, 108,12748.(10)Skoulidas,A.I.;Sholl,D.S.J.Phys.Chem.B2001,105,3151.(11)Skoulidas,A.I.;Sholl,D.S.J.Phys.Chem.B2002,106,5058.(12)Skoulidas,A.I.;Bowen,T.C.;Doelling,C.M.;Falconer,J.L.;Noble, R.D.;Sholl,D.S.J.Membr.Sci.2003,227,123.(13)Skoulidas,A.I.;Sholl,D.S.J.Phys.Chem.A2003,107,10132.(14)Skoulidas,A.I.;Sholl,D.S.AIChE J.2005,51,867.(15)Sholl,D.S.Acc.Chem.Res.2006,39,403.5474Langmuir2008,24,5474-5484smaller than the main-term diffusivities.17In addition,they examined the permeances of CH4and CF4through faujasite18 and evaluated the diffusivities for a binary mixture of CH4/CF4, C3H8/CF4,n-C4H10/CF4,and C2H6/n-C4H10in faujasite at300 K.19Krishna and co-workers reported a kinetic Monte Carlo (MC)simulation for the self-diffusion of the CH4/CF4mixture in silicalite,20simulated the self-diffusion of pure CH4and CO2 and an equimolar mixture at a wide range of loading in MFI, CHA,and DDR zeolites,21and screened12different zeolites to determine the best one for separation of CO2and CH4.22 Furthermore,they investigated the correlation effects in the diffusion of CH4and CF4in the MFI zeolite from MD simulation and the Maxwell-Stefan(MS)formulation,respectively.23Jost et al.simulated the diffusion of the CH4/Xe mixture in silicalite and compared it with the pulsedfield gradient nuclear magnetic resonance and found that the simulation and experimental results were in accordance with each other.24Moulijn and co-workers investigated the separation of CH4/C2H6and CH4/C3H8mixtures in silicalite as a function of temperature,pressure,and composi-tion.25The role of adsorption in single and binary permeation of CH4and CO2through a silicalite membrane was further examined by them,in which the generalized MS formulation was adapted in combination with the ideal adsorbed solution theory(IAST)to model binary permeation.26Since its discovery in1991,carbon nanotubes(CNTs)27have stimulated considerable interest,including their potential use for membrane separation as a result of their well-defined nanoscale structures.28Sholl,Johnson,and co-workers simulated the self-and transport diffusivities of light gases such as H2,CH4,Ar,and Ne in CNTs and in two zeolites with comparable pore sizes and found that the diffusion is1-3orders of magnitude faster in CNTs than in silicalite depending on loading.29,30Similar behavior was observed by them for CO2and N2in CNTs at room temperature,in which the linear and spherical models for CO2 were found to give roughly identical diffusivity.31They examined the transport diffusivity in rigid,defect-free CNTs in which an efficient thermostat was employed to account for the influence of nanotubeflexibility.The inclusion offlexibility reduces transport diffusion by roughly1order of magnitude at a pressure close to zero;in contrast,at high pressures the transport diffusion inflexible and rigid nanotubes is very similar,differing by a factor of2on average.32Furthermore,they predicted the binary permeance of the CH4/H2mixture through defect-free CNTs acting as a membrane at room temperature and showed that the mixture diffusion is also rapid as compared to single-component diffusion.33Arora and Sandler studied the mass transport of O2, N2,and their mixture in a CNT and demonstrated that good kinetic selectivity could be achieved for air separation by carefully adjusting the upstream and downstream pressures.34They further investigated the separation of O2and N2in a CNT with a constriction,which leads to high transport resistance to N2while allowing O2to pass at a much higher rate even though these gases have very similar sizes and energetics.35Combining the configurational-bias MC method with the dual control-volume grand canonical MD simulation,Firouzi et al.examined the transport and separation of binary n-alkane mixtures as well as CO2and n-alkane mixtures in CNTs under an external potential gradient.36Jakobtorweihen et al.proposed a novel algorithm for modeling the influence of host latticeflexibility and applied it to the investigation of the diffusion of chain molecules and mixtures in CNTs.37,38Within the past few years,a new family of naonporous materials,namely,metal organic frameworks(MOFs),have been developed.39–41With the well-located metal oxide clusters and organic linkers,MOFs allow the formation of porous frameworks with a wide variety of architecture,topology,and pore size and provide almost unlimited opportunities to develop,control,and tune structures for specific pared to zeolites and CNTs,the simulation studies for diffusion in MOFs are relatively few.Skoulidas found from MD simulation that the transport diffusivity of Ar in Cu-BTC at room temperature differs from the self-diffusivity by2orders of magnitude at high loadings.42Sarkisov et al.simulated the self-diffusivities of CH4, n-C5H12,n-C6H14,n-C7H6,and cyclo-C6H14in MOF-5,which are of the same order of magnitude as in silicalite.43Skoulidas and Sholl examined the self-and transport diffusion of light gases in MOF-2,MOF-3,MOF-5,and Cu-BTC.44Yang and Zhong performed simulations for the adsorption and diffusion of H2in IRMOFs.45Stallmach et al.reported thefirst experimental data on diffusion in MOF-5and demonstrated that organic gas molecules diffuse quite rapidly in MOFs.46Amirjalayer et al. conducted MD simulations of C6H6in IRMOF-1and found that the diffusion and activation energy of C6H6are considerably smaller in theflexible framework compared to those in the rigid one.47To the best of our knowledge,however,there is no simulation work to date for mixture diffusion in MOFs.The above-mentioned studies were primarily from numerical simulations on diffusion in zeolites,CNTs,and MOFs.Analytical predictions of mixture diffusion solely from single components have been a major challenge in the past few decades.Nevertheless, the Maxwell-Stefan(MS)formulation developed by Krishna and co-workers is an advance toward this end,as recently(17)Sanborn,M.J.;Snurr,R.Q.Sep.Purif.Technol.2000,20,1.(18)Sanborn,M.J.;Snurr,R.Q.AIChE J.2001,47,2032.(19)Chempath,S.;Krishna,R.;Snurr,R.Q.J.Phys.Chem.B2004,108, 13481.(20)Paschek,D.;Krishna,ngmuir2001,17,247.(21)Krishna,R.;van Baten,J.M.;Garcia-Perez,E.;Calero,S.Chem.Phys. Lett.2006,429,219.(22)Krishna,R.;van Baten,J.M.Chem.Eng.J.2007,133,121.(23)Skoulidas,A.I.;Sholl,D.S.;Krishna,ngmuir2003,19,7977.(24)Jost,S.;Bar,N.K.;Fritzsche,S.;Haberlandt,R.;Karger,J.J.Phys. Chem.B1998,102,6375.(25)van de Graaf,J.M.;Kapteijn,F.;Moulijn,J.A.AIChE J.1999,45,497.(26)Zhu,W.D.;Hrabanek,P.;Gora,L.;Kapteijn,F.;Moulijn,J.A.Ind.Eng. Chem.Res.2006,45,767.(27)Iijima,S.Nature1991,354,56.(28)Ajayan,P.M.;Zhou,O.Z.Applications of Carbon Nanotubes.In Carbon Nanotubes;Springer-Verlag Berlin:Berlin,2001;Vol.80;p391.(29)Skoulidas,A.I.;Ackerman,D.M.;Johnson,J.K.;Sholl,D.S.Phys.Re V. Lett.2002,89.(30)Ackerman,D.M.;Skoulidas,A.I.;Sholl,D.S.;Johnson,J.K.Mol.(33)Chen,H.B.;Sholl,D.S.J.Membr.Sci.2006,269,152.(34)Arora,G.;Sandler,S.I.J.Chem.Phys.2006,124.(35)Arora,G.;Sandler,S.I.Nano Letters2007,7,565.(36)Firouzi,M.;Nezhad,K.M.;Tsotsis,T.T.;Sahimi,M.J.Chem.Phys. 2004,120,8172.(37)Jakobtorweihen,S.;Verbeek,M.G.;Lowe,C.P.;Keil,F.J.;Smit,B. Phys.Re V.Lett.2005,95,044501.(38)Jakobtorweihen,S.;Lowe,C.P.;Keil,F.J.;Smit,B.J.Chem.Phys. 2007,127,024904.(39)Yaghi,O.M.;O’Keeffe,M.;Ockwig,N.W.;Chae,H.K.;Eddaoudi,M.; Kim,J.Nature2003,423,705.(40)Eddaoudi,M.;Kim,J.;Rosi,N.;Vodak,D.;Wachter,J.;O’Keefe,M.; Yaghi,O.M.Science2002,295,469.(41)Rosi,N.L.;Eckert,J.;Eddaoudi,M.;Vodak,D.T.;Kim,J.;O’Keeffe, M.;Yaghi,O.M.Science2003,300,1127.(42)Skoulidas,A.I.J.Am.Chem.Soc.2004,126,1356.(43)Sarkisov,L.;Duren,T.;Snurr,R.Q.Mol.Phys.2004,102,211.(44)Skoulidas,A.I.;Sholl,D.S.J.Phys.Chem.B2005,109,15760.(45)Yang,Q.Y.;Zhong,C.L.J.Phys.Chem.B2005,109,11862.Diffusion and Separation of CO2and CH4Langmuir,Vol.24,No.10,20085475reviewed.48They used a generalized MS model to predict the permeationfluxes of hydrocarbon mixtures through a silicalite membrane.49,50A general analytical expression for self-diffusivity in a multicomponent mixture was proposed by them.51It has been found that the MS diffusivity in zeolites shows a variety of dependencies on occupancy.As a consequence,they further modeled the occupancy dependence of diffusivity in zeolites by taking into account various factors such as zeolite topology, connectivity,and molecular interactions.52Sholl tested this by predicting binary diffusivity in a lattice model with site heterogeneity.He found that the model is quite accurate in situations where the binding sites are relatively homogeneous but is less accurate for strongly heterogeneous energy distribu-tions.53In addition,Krishna and van Baten carried out MD simulations for pure components and binary,ternary,and quaternary mixtures in FAU at300K over a wide range of loading and found that MS diffusivity for a particular species is nearly identical whether this species is present on its own or in a mixture with other species.54Having tested the MS formulation extensively in zeolite structures for predicting mixture diffusion, they further tested the MS formulation in CNTs for various binary mixtures and found good agreement with simulations.55Whereas the MS formulation to predict mixture diffusion from single components has been tested relatively well in zeolites and CNTs, only recently has such a prediction been attempted in MOF-5 by Keskin and Sholl.56Through MC simulation,we have recently investigated the adsorption of pure CO2and CH4and the separation of their binary mixture in three different families of nanostructured materials s silicalite,C168schwarzite,and IRMOF-1.57The separation of CO2 from CH4,a major component in natural gas,is considered to be an important practical problem.Our simulated adsorption isotherms and isosteric heats closely match the available experimental data. Compared with the adsorption capacities of silicalite and C168 schwarzite,those of CH4and CO2in IRMOF-1are substantially larger.As a typical MOF,IRMOF-1could be a good candidate for gas storage,but its adsorption selectivity does not differ much from silicalite and C168particularly at high pressure.57Nevertheless,the efficacy of membrane-based separation for a gas mixture depends notonlyonthesolubilitydifference,whichisanequilibriumproperty, but also on the diffusivity difference,which is a transport property.58 As a consequence,in this work we investigate the diffusion of CO2,CH4,and their mixture in the three nanostructured adsorbents using MD simulation and examine the permselectivity based on diffusion and adsorption selectivity.This is thefirst simulation study on mixture diffusion in a MOF.In section II, the models used for adsorbents and adsorbates are briefly described and followed in section III by the simulation methodology.In section IV,we present the diffusivities and activation energies at infinite dilution for CO2and CH4.Then the self-,corrected,and transport diffusivities for single component from simulation are presented as a function of loading at300K.The correlation effects are examined from the self-and corrected diffusivities and subsequentlyfitted by an empirical equation.With thefitted correlation effects,the simulated self-, corrected,and transport diffusivities are compared with the theoretical predictions from the MS formulation.Finally,the self-diffusivities in the binary mixture at300K are presented from both simulation and the MS bining the differences in adsorption and diffusion between the two components in a binary mixture,permselectivity is evaluated.In section V,the concluding remarks are summarized.II.ModelsThe atomistic models for three adsorbents(silicalite,C168 schwarzite,and IRMOF-1)and two adsorbates(CH4and CO2) are the same as in our previous study;57therefore,a brief description is given here.Silicalite(MFI)is an Al-free zeolite typically used in membrane processes because of its pore size and ease of preparation.MFI consists of two types of channels with10-membered rings s one is straight,and the other is sinusoidal.These intersecting channels have a diameter of about 5.4Å.The Lennard-Jones potential parameters and partial charges of the Si and O atoms were adapted from the work of Hirotani et al.59Experimentally synthesized nanoporous carbon is amorphous and does not have a well-defined structure;conse-quently,C168schwarzite is used to represent a nanoporous carbon.60Two types of channels exist in C168schwarzite with average diameters of approximately7and9Å.The channels in the same layer are isolated from each other,but they are connected to those in the neighboring layers by channel intersections.Carbon atoms in C168schwarzite were assumed to be neutral,and the Steele potential was used to model the disperse interactions.61 IRMOF-1is an isoreticular MOF that has one type of straight channel with sizes of15and12Åseparately along the channel.62 A universal forcefield(UFF)was used to model the Zn,C,O, and H atoms in IRMOF-1.63On the basis of a fragmented cluster, the atom-centered partial charges were estimated with B3LYP/ 6-31G(d)density-functional theory computation and subsequently fitted using the restrained electrostatic potential(RESP)method.64 CH4was mimicked by the united-atom model with the interaction potential parameters from the TraPPE forcefield developed to reproduce the critical parameters and saturated liquid densities of alkanes.65The interactions between CH4and the adsorbent were modeled using the Lennard-Jones potential,and the Lorentz–Ber-thelot mixing rules were used to calculate the cross interaction parameters.CO2was represented by a three-site moleculefitted to the experimental data of bulk CO2.59The partial charge was0.576e on the C atom and–0.288e on the O atom.The C-O bond length was assumed to be rigid,and the bond length was1.18Å.The OCO bond angle wasflexible and governed by a harmonic potential of 1/2kθ(θ-θ0)2with force constant kθ)1275kJ/mol/rad2and equilibrium angleθ0)180°.CO2-CO2and CO2-adsorbent interactions were modeled by a combination of Lennard-Jones and Coulombic potentials except for C168schwarzite,where only the Lennard-Jones potential was considered.III.MethodologyDiffusion can be characterized into self-,corrected and transport diffusion at different length scales.Self-diffusivity describes the(48)Krishna,R.;Baur,R.Sep.Purif.Technol.2003,33,213.(49)Kapteijn,F.;Moulijn,J.A.;Krishna,R.Chem.Eng.Sci.2000,55,2923.(50)Krishna,R.;Paschek,D.Sep.Purif.Technol.2000,21,111.(51)Krishna,R.;Paschek,D.Phys.Chem.Chem.Phys.2002,4,1891.(52)Krishna,R.;Paschek,D.;Baur,R.Microporous Mesoporous Mater.2004, 76,233.(53)Sholl,ngmuir2006,22,3707.(54)Krishna,R.;van Baten,J.M.J.Phys.Chem.B2005,109,6386.(55)Krishna,R.;van Baten,J.M.Ind.Eng.Chem.Res.2006,45,2084.(56)Keskin,S.;Sholl,D.S.J.Phys.Chem.C2007,111,14055.(59)Hirotani,A.;Mizukami,K.;Miura,R.;Takaba,H.;Miya,T.;Fahmi,A.; Stirling,A.;Kubo,M.;Miyamoto,A.Appl.Surf.Sci.1997,120,81.(60)Jiang,J.W.;Sandler,S.I.J.Am.Chem.Soc.2005,127,11989.(61)Steele,W.Chem.Re V.1993,93,2355.(62)Millward,A.R.;Yaghi,O.M.J.Am.Chem.Soc.2005,127,11989.(63)Rappe,A.K.;Casewit,C.J.;Colwell,K.S.;Goddard,W.A.;Skiff,5476Langmuir,Vol.24,No.10,2008Babarao and Jiangmobility of individual molecules,also called tracer diffusivity,can be estimated from the mean-squared displacement based on the Einstein relation 66D s (c ))lim t f ∞16t 〈1N ∑k )1N|r k (t )-r k (0)|2〉(1)where c is concentration,r k (t )is the position of the k th moleculeat time t ,and N is the number of molecules.This definition applies to both single and multicomponent systems.On a macroscopic scale,Fick’s law of diffusion gives the phenomenological relation between flux J and concentration gradient ∇c ,J )-D t (c )∇c(2)The transport or Fickian diffusivity D t can be evaluated from the corrected diffusivity D c (c )and thermodynamic correction factor Γ(c ),D t (c ))D c (c )Γ(c )(3)withΓ(c ))(∂ln f ⁄∂ln c )T(4)where f is the fugacity of the fluid in equilibrium with the adsorbed phase at a concentration c .Γ(c )at a given temperature T can be evaluated from the equilibrium adsorption isotherm.The corrected diffusivity D c (c ),which is also called the jump diffusivity,can be written asD c (c ))Lk B T ⁄c(5)where L is the phenomenological coefficient and k B is Boltzmann’s constant.Note that the corrected diffusivity is equal to the Maxwell -Stefan diffusivity for a system with only one species.From the linear response theory,L is related to the flux autocorrelation function by 67L )13Vk B T∫0∞〈j (0)·j (t )〉d t(6)where V is the system volume and j (t )is the microscopic current defined as the sum of molecular velocitiesj (t ))∑k )1Nv k (t )(7)The microscopic current is an equilibrium property and can be directly obtained from MD simulation.Equation 6is the Green -Kubo form,and the equivalent Einstein form can be found elsewhere.67The above expression can be extended to multicomponent systems.Self-,corrected,and transport diffu-sivities are concentration-dependent and generally not equal to each other unless at infinite dilution,D s (0))D t (0))D c (0))D (0)(8)In this work,we simulate the diffusion of pure and mixed CH 4and CO 2in MFI,IRMOF-1,and C 168using the MUSIC program.68The simulations were carried out in a canonical ensemble (NVT )with a Nose-Hoover thermostat,and the equations of motion were integrated using a sixth-order Gearpredictor-corrector algorithm.69A time step of 1fs was used for CH 4,and 0.3fs was used for CO 2and the mixture to achieve better energy conservation.A spherical cutoff length of 19.0Åwas used to evaluate the intermolecular Lennard-Jones interactions without the long-range corrections.Cou-lombic interactions between CO 2and adsorbent were calculated using the Ewald summation technique.70For CO 2molecules,Coulombic interactions were calculated directly on the basis of the center-of-mass cutoff of 19.0Åbecause the CO 2molecule is neutral with a quadrupole interaction that converges rapidly with the cutoff distance.To accelerate the simulation,the Lennard-Jones and Coulombic interactions between adsorbate and adsorbent were calculated via a pretabulated energy map that was constructed throughout a unit cell of adsorbent with a grid of 0.2×0.2×0.2Åcubic mesh.The simulation box for MFI contained 12(2×2×3)unit cells,whereas for C 168schwarzite and IRMOF-1,8(2×2×2)unit cells were used.All three adsorbents were assumed to be rigid,and the framework atoms were fixed during simulation.It is important to note,however,that diffusion can be substantially influenced by the framework flexibility.In zeolites,diffusion is usually accelerated in the flexible model by the increased possible number of pathways for the molecular jump.71Nevertheless,a reduction in diffusion is observed in flexible carbon nanotubes by taking into account the energy exchange between diffusing molecules and the nanotube.32The diffusion and activation energy of benzene in IRMOF-1are considerably smaller in the flexible framework compared to those in the rigid one.This is attributed to the correlation motion of benzene with the organic linker phenylene rings,which leads to an increases in the population of benzene in the A-cell pockets.47The final configurations of MC simula-tions for the adsorption of pure CH 4,CO 2,and the equimolar CH 4/CO 2mixture from our previous work 57were taken as the initial configurations for the MD simulations in this work.For pure CH 4and CO 2at 300K,simulations were performed for a total period of 2.5-5.0ns with an equilibration period of 1.0-3.5ns.Ten independent runs were performed at each loading to obtain the desired level of statistical accuracy.During the production run,the atomic coordinates were written to a disk every 1ps and then used to calculate the averaged D s from the Einstein relation.The molecular velocities were written to a disk every 0.1ps and then used to calculate the flux autocorrelation function and phenomenological coefficient using eq 6with an upper limit of 30ps.As demonstrated previously,17,72with an even short limit of 10ps,the flux autocorrelation function decays to zero,and the integral converges to a constant.In addition,we calculated the diffusivities at infinite dilution of CH 4and CO 2in all three adsorbents at various temperatures.To do this,we performed the MD simulation as described above with at least 40molecules in the box by turning off the adsorbate–adsorbate interactions.For the CH 4/CO 2mixture,MD simulations were performed at 300K for a total period of 8ns,with the first half left out for equilibration and the second half left out for the ensemble average.IV.Results and DiscussionFirst we present the simulation results for pure CH 4and CO 2in the three nanostructures at infinite dilution.From the(66)McQuarrie,D.A.Statistical Mechanics;University Science Books:Sausalito,CA,2000.(67)Theodorou,D.N.;Snurr,R.Q.;Bell,A.T.Molecular Dynamics and (69)Allen,M.P.;Tildesley,D.J.Oxford University Press:Oxford,U.K.,1987.Diffusion and Separation of CO 2and CH 4Langmuir,Vol.24,No.10,20085477temperature-dependent diffusivities,the activation energies for diffusion are obtained.Then as a function of loading,the simulated self-,corrected,and transport diffusivities of pure CH4and CO2 at300K are shown.The correlation effects of diffusion are examined and used in the MS formulation for predictions,which in turn are compared with the simulation results.Finally,the simulated and predicted self-diffusivities of the CH4/CO2binary mixture are presented at300K,and the permselectivity for the mixture is evaluated.Diffusivities and Activation Energies at Infinite Dilution. Figure1shows the diffusivities at infinite dilution D(0)for CH4and CO2separately in MFI,C168,and IRMOF-1as a function of the inverse temperature.The results are the average of10independent runs with a standard deviation of within 5%.As estimated in our previous study57and also given in Table1,for the three adsorbents under consideration,the porosity increases in the order of MFI<C168<IRMOF-1.In accordance with the increasing trend in porosity,D(0)generally increases in the same order for both CH4and CO2because of the increased free space for molecules to move.At temperatures lower than 300K,however,D(0)in MFI becomes slightly greater than in C168.Therefore,porosity is not the only factor influencing the diffusivity.Our simulated D(0)at300K given in Table1generally matches the reported simulation and experimental values well. For CH4in MFI,D(0)agrees well with the simulation results from a number of groups.6,7,11,21For CH4in IRMOF-1,D(0)is also in good agreement with the simulation result,44but both are almost an order of magnitude less than the measured value by Stallmach et al.46For CO2in MFI,D(0)is comparable to the measured value from QENS[(0.6-0.7)×10-8m2/s],9though a bit higher than the value simulated by Krishna et al.21For CO2 in IRMOF-1,D(0)is slightly higher than the simulated value of Skoulidas et al.44The discrepancy for CO2might be due to the different potential parameters used.C168schwarzite is a hypothetical structure for nanoporous carbons,and no experi-mental data are available for comparison with our results.In nanoporous materials,the steric effect and surface interaction play a dominant role.Diffusion is normally interpreted as an activated process and can be described by the Arrhenius relationD(0))Dfexp(-E a RT)(9) where D f is the prefactor,E a is the activation energy,and R is the gas constant.Byfitting the simulated D(0)at various temperatures using eq9,D f and E a can be correlated.The lines with CO2.As a result of the high porosity,in IRMOF-1D f for both CH4and CO2is found to be almost1order of magnitude greater than in MFI and C168.Our simulated E a for CH4in MFI(4.45kJ/mol)is in good agreement with the experimental value(5.69kJ/mol).73Stallmach et al.found E a for CH4in IRMOF-1 to be around8.5kJ/mol,46which is almost twice the simulated value(4.88kJ/mol).However,the discrepancy in both D(0)and E a in IRMOF-1may be due to the defects present in the porous structure used in experiments,which was not taken into account in simulations.Our simulated E a for CO2in MFI(3.35kJ/mol) is smaller than one available experimental value(5.8kJ/mol). However,note that the experimental condition was not at infinite dilute;instead,the loading was approximately two molecules/ unit cell.9A molecule must overcome the free-energy barrier to move from one site to another.The barrier as reflected in the activation energy is lower for either CH4or CO2in C168schwarzite compared with that in MFI and IRMOF-1.In particularly,the estimated E a for CO2in C168(1.75kJ/mol)is considerably lower. As further discussed below,this is because CO2is a slender molecule and readily mobile particularly in C168channels. Self-Diffusivities.Figure2shows the loading dependence of the self-diffusivities D s for CH4and CO2in the three adsorbents. The loadings considered here for IRMOF-1are substantially lower than the saturation loading.The error bars indicate the uncertainties in our simulation.As seen,D s for both CH4and CO2in each adsorbent decreases monotonically as loading increases.This is type I behavior as characterized by Karger and Pfeifer in whichfive types of diffusion behavior were demon-strated with increased loading.74The observed type I behavior is very common in nanoporous materials as a result of enhanced steric hindrance of the motion of a tagged particle by neighboring particles as the loading increases.At a loading of around3mmol/g for either CH4or CO2,D s in IRMOF-1is about twice of that in C168and almost1order of magnitude greater than that in MFI. The decreased rate in D s(the slope)is closely related to theFigure1.Diffusivities D(0)at infinite dilution as a function of inverse temperature for pure CH4and CO2in MFI,IRMOF-1,and C168.Symbols are from simulation,and lines are the Arrheniusfits to the symbols.Table1.Diffusivities D(0)at300K(10-8m2/s),Prefactors D f(10-8m2/s),and Activation Energies E a(kJ/mol)at InfiniteDilution for CH4and CO2in MFI,C168,and IRMOF-1adsorbent adsorbate porosity D(0)D f E aMFI CH40.37 1.569.28 4.45CO2 1.31 5.18 3.35C168CH40.67 1.51 6.24 3.50CO2 1.35 2.81 1.75IRMOF-1CH40.82 3.3722.6 4.88CO2 3.0115.4 4.05 5478Langmuir,Vol.24,No.10,2008Babarao and Jiang。
