变压器常用中英对照

1、安全隔离变压器safety isolating transformer2、安全特低电压（SELV）safety extra-low voltageB1、棒式电流互感器bar primary type current transformer2、包封线圈的干式变压器encapsulated-winding dry-type transformer3、包封线圈干式电抗器encapsulated-winding dry-type reactor4、饱和电抗器saturable reactor5、保护用电流互感器protective current transformer6、保护用电压互感器protective voltage transformer7、保护装置（电容式电压互感器）protective device (of a capacitor voltage transformer)8、变磁通调压variable flux voltage variation (VFVV)9、变流变压器converter transformer10、变压器transformer11、变压器效率efficiency of transformer12、并联电抗器shunt reactor13、并联控制装置parallel control devices14、饼式线圈disc winding15、箔式线圈foil winding16、波纹式油箱corrugated type tank17、不接地电压互感器unearthed voltage transformerC1、操作计数器operation counter2、操作循环cycle of operation3、测量用电流互感器measuring current transformer4、测量用电压互感器measuring voltage transformer5、层式线圈layer winding6、叉花纠结式线圈sandwich-interleaved winding7、厂用变压器(发电厂用变压器) station service transformer8、插入电容式线圈capacitor shield winding9、充满油的密封系统sealed, completed filled system10、串级（电磁）式电流互感器cascade (inductive) current transformer11、串级（电磁）式电压互感器cascade (inductive) voltage transformer12、串级试验变压器cascade transformer13、串联电抗器series reactor14、串联绕组series winding15、船用变压器marine transformer16、触头组set of contacts17、储油柜oil conservator18、储油柜系统conservator system19、磁分路magnetic shunt20、磁箱式电流互感器porcelain-case type current transformer21、磁性调压器magnetic control voltage regulator22、粗调选择器coarse change-over selector1、带气垫的密封式油箱系统sealed-tank system with gas cushion2、带散热管的油箱tank with bend pipe3、单铁心式电流互感器single-core type current transformer4、单相单柱旁轭式铁心single-phase three-limb core5、单相二柱式铁心single-phase two-limb core6、倒立式电流互感器inverter-type current transformer7、电磁单元(电容式电压互感器) electromagnetic unit (of a capacitor voltage transformer)8、电动机构motor-drive mechanism9、电动机构的手动操作manual operation of motor-device mechanism10、电化学用整流变压器electro-chemistry rectifier transformer11、点火变压器ignition transformer12、电弧炉变压器arc furnace transformer13、电抗电压reactance voltage14、电抗器reactor15、电缆式电流互感器cable type current transformer16、电力变压器power transformer17、电铃变压器bell transformer18、电流互感器current transformer19、电流扩大值（测量用电流互感器的）extended rating current（of a measuring current transformer ）20、电流误差current error21、电炉变压器furnace transformer22、电容分压器（电容式电压互感器）capacitor voltage divider (of a capacitor voltage transformer)23、电容分压器的分压比voltage ratio of a capacitor divider24、电容式电压互感器capacitor voltage transformer25、电压互感器voltage transformer26、电压降或电压升（指定负载下的）voltage drop or rise for a specified load condition27、电压调整率（指定复式下的）voltage regulation for a specified load condition28、电压误差voltage error29、电阻电压resistance voltage30、电阻炉变压器resistance furnace transformer31、电阻式温度计resistance-type thermometer32、叠积式铁心laminated core33、低压端子（电容式电压互感器的）low voltage terminal (of a capacitor voltage transformer)34、低压绕组low-voltage winding35、端（部电容）环end ring36、短路匝short-circuited turn37、短路阻抗（一对绕组的）short-circuit impedance (of a pair of winding)38、端（部电容）屏end screen39、对应端子corresponding terminals40、独立绕组变压器separate winding transformer41、多框式铁心multi frame type core42、多绕组变压器multi-winding transformer43、多铁心式电流互感器multi-core type current transformer44、惰性气体压力系统inert gas pressure systemE1、额定参数rated quantities2、额定电流（变压器或并联电抗器绕组上的）rated current(of a winding of a transformer or shunt reactor)3、额定电流比（电流互感器的）rated transformer ratio (of a current transformer)4、额定电压比（电流互感器的）rated transformer ratio (of a voltage transformer)5、额定电压比（绕组的）rated voltage ratio (of a winding)6、额定电压比（电压互感器的）rated transformation ratio (of a voltage transformer)7、额定电压系数rated voltage factor8、额定动稳定电流rated dynamic current9、额定短时电流rated short-time current10、额定短时热电流（电流互感器的）rated short-time thermal current (of a current transformer)11、额定二次电流（电流互感器的）rated secondary current (of a current transformer)12、额定二次电压（电压互感器的）rated secondary voltage (of a voltage transformer)13、额定阀侧电流rated current on valve side14、额定阀侧电压rated current on line side15、额定阀侧视在功率rated apparent power on valve side16、额定负荷rated burden17、额定级电压rated through-current18、额定绝缘水平rated insulation level19、额定连续电流rated continuous current20、额定连续热电流（电流互感器）rated continuous thermal current (of a current transformer)21、额定频率rated frequency22、额定容量rated power23、额定输出（互感器的）rated output (of an instrument transformer)24、额定输出电压rated output voltage25、额定输入电压input voltage26、额定通过电流rated through current27、额定网侧电流rated current on line side28、额定网侧电压rated voltage on line side29、额定网侧视在功率rated apparent power on valve line30、额定仪表限值一次电流（电流互感器的）rated instrument limit primary current31、额定一次电流（电流互感器的）rated primary current (of a current transformer)32、额定一次电压（电压互感器的）rated primary voltage (of a voltage transformer)33、额定值rating34、额定准确限值一次电流（保护用电流互感器的）rated instrument limit primary current35、二次电流secondary current36、二次电路secondary circuit37、二次电压secondary voltage38、二次极限感应电势secondary limiting e.m.f39、二次绕组（变压器的）secondary winding (of a current transformer)40、二次绕组（电压互感器的）secondary winding (of a voltage transformer)II（防止点击）变压器class II transformerF1、阀侧绕组valve side winding2、发电厂自用变压器(简称：厂用变压器) station service transformer3、发电机变压器generator transformer4、放电线圈discharge coil5、反角环angle ring （cap-ring）6、非包封线圈干式变压器non-encapsulated-winding dry-type transformer7、非包封线圈干式电抗器non-encapsulated-winding dry-type reactor8、非封闭干式变压器non-enclosed dry transformer9、非耐短路变压器non-short-circuit proof transformer10、封闭干式变压器enclosed dry transformer11、风冷（AF）force-air cooling12、分接tapping (tap)13、分接参数tapping quantities14、分接变换操作tap-change operation15、分接变换指示器tap-change in progress indicator16、分接电压比（一对绕组的）tapping voltage ratio (of a pair of windings)17、分接范围tapping range18、分接工况tapping duty19、分接级tapping step20、分接位置指示器tap position indicator21、分接选择器tap-selector22、分接因数tapping factor23、分裂式变压器dual-low-voltage transformer24、分相封闭母线isolated phase bus25、负分接minus tapping26、负荷（互感器的）burden (of an instrument transformer)27、复合误差（电流互感器的）composite error (of a current transformer)28、附加绝缘supplementary insulation29、附加绕组auxiliary winding30、附加损耗supplementary load loss31、复绕式电流互感器compound-wound current transformer32、负载损耗load lossG1、干式变压器dry-type transformer2、干式电抗器dry-type transformer3、感应调压器induction-voltage regulator4、感应自动调压器automatic induction-voltage regulator5、高压电容器（电容式电压互感器的）high voltage capacitor (of a capacitor voltage transformer)6、高压端子（电容式电压互感器的）high voltage terminal (of a capacitor voltage transformer)7、高压绕组high-voltage winding8、隔爆变压器flame-proof transformer9、隔离变压器isolating transformer10、隔膜式油保护系统diaphragm-type oil preservation system11、公共绕组common winding12、工频感应炉变压器power frequency induction furnace transformer13、共箱隔相封闭母线segregated phase bus14、工作分接位置数number of service tapping positions15、拐点电压knee point voltage16、贯穿式电流互感器through-type current transformer17、管式散热器pipe-type radiator18、滚动接触电刷rolling type current collector19、过电流闭锁装置over current blocking device20、过渡触头transition contacts21、过渡阻抗transition impedance22、固有分接位置数number of service tapping positionsH1、恒磁通调压constant flux voltage variation（CFVV）2、虹吸净油器（净油器）oil（siphon）filter3、滑动接触电刷sliding type current collector4、互感器instrument transformer5、恢复电压recovery voltage6、户内式indoor type7、混合调压combined voltage variation8、户外式outdoor typeJ1、降低容量的分接reduced-power tapping2、降压变压器step-down transformer3、夹件clamps4、交叠式线圈sandwich winding5、角环angle ring6、加强绝缘reinforced insulation7、基本绝缘basic insulation8、接触调压器variable transformer9、接触自动调压器automatic variable regulator10、接地变压器earthing transformer（neutral coupler）11、接地电压互感器earthed voltage transformer12、介质损耗因数dielectric dissipation factor13、静电环electrostatic ring14、静电屏electrostatic shielding15、净油器oil(siphon) filter16、紧急脱扣装置emergency tripping device17、纠结-连续式线圈inter leaved and continuous winding18、纠结式线圈inter leaved winding19、极限开关limit switch20、机械端位止动装置mechanical end stop21、极性选择器reversing change-over selector22、局部放电partial discharge23、绝缘热稳定性（电流互感器的）dielectric thermal stability(of a current transformer) K1、开断电流switched current2、开口三角形联结open delta connection3、开路绕组open winding4、开路中间电压（电容式电压互感器的）open-circuit intermediate voltage（of a capacitorvoltage transformer）5、壳式变压器shell-type transformer6、矿热炉变压器ore furnace transformer7、矿用变压器mining transformer(general type)8、矿用隔爆移动变电站mining flame proof movable substation9、空心电抗器reactor with air core10、空载电流no-load current11、空载损耗no-load loss12、控制用变压器control transformer13、扩大额定值的电流互感器extend rating type current transformerL1、累加用电力互感器summation current transformer2、冷却器cooler3、联结组标号connection symbol4、联络变压器system-interconnection transformer5、连续式线圈continuous winding6、励磁电流（电流互感器的）exciting current （of a current transformer）7、励磁绕组energizing winding8、零序电流互感器（剩余电流互感器）residual current transformer9、零序电压互感器（剩余电压互感器）residual voltage transformer10、零序阻抗zero-sequence impedance11、例行试验routine test12、滤波电抗器tuning（filter）reactor13、螺旋式线圈helical windingM1、满容量分接full-power of a winding2、密封式变压器sealed transformer3、密封式电抗器sealed reactor4、母线式电流互感器bus-type current transformerN1、耐短路变压器short-circuit proof transformer2、内部负荷（电流互感器的）internal burden（of a current transformer）3、内屏蔽式线圈capacitor shield windingO1、耦合绕组coupling windingP1、旁轭magnetic return path2、配电变压器distribution transformer3、膨胀器expander4、片式散热器panel-type radiator5、平波电抗器smoothing reactor6、平衡电抗器interphase reactor7、平衡绕组balancing winding8、平面式邮箱plane type tank9、匹配用电流互感器current matching transformer10、匹配用电压互感器voltage matching transformer11、P 级performance Class AQ1、强迫油循环导向冷却forced-directed oil cooling2、强迫油循环风冷（OFAF）forced-oil and forced-air cooling3、强迫油循环水冷（OFWF）forced-oil and water cooling4、钳式电流互感器split core type current transformer5、牵引变压器traction transformer6、牵引整流变压器traction rectifier transformer7、起动电抗器starting reactor8、起动自耦变压器starting auto-transformer9、切换开关diverter switch10、器身active part11、气体继电器gas relay；buchholz relay12、全封闭干式变压器totally enclosed dry-type transformer13、全绝缘电流互感器fully insulated current transformer14、全自保护变压器completely self-protected distribution transformer15、驱动机构driving mechanism16、曲折形联结zigzag connectionR1、绕线式电流互感器wound primary type current transformer2、绕组winding3、绕组的分接电流tapping power of a winding4、绕组的分接电压tapping voltage of a winding5、绕组的分接容量tapping power of a winding6、绕组的分级绝缘non-uniform insulation of a winding7、绕组的全绝缘uniform insulation of a winding8、绕组联结图connection diagram of windings.S1、三角形联结delta connection2、Ⅲ类（防止电击）变压器class Ⅲtransformer3、Ⅲ类照明设备用变压器transformer for class Ⅲluminaires4、散热器radiator5、三相三柱旁轭式铁心three-phase three-limb core6、三相三柱式铁心three-phase three-limb core7、三相中性点电抗器three-phase neutral reactor8、设备最高电压Um highest voltage for equipment Um9、声功率级(Lw) sound power level10、升压变压器step-up transformer11、声压级(Lp) sound pressure level12、剩余电流residual current13、剩余电流互感器residual current transformer14、剩余电压residual voltage15、剩余电压互感器residual voltage transformer16、剩余电压绕组residual voltage winding17、实际电流比（电流互感器的）actual transformation ratio (of a current transformer)18、实际电压比（电压互感器的）actual transformation ratio(of a voltage transformer)19、试验变压器testing transformer20、双重绝缘double insulation21、双功能电压互感器dual purpose voltage transformer22、双绕组变压器two-winding transformer23、输出电压范围output voltage range24、输入电压范围input voltage range25、树脂浇注式电流互感器cast-resin type current transformer26、树脂浇注式电压互感器cast resin type voltage transformer27、速饱和电流互感器rapid-saturable current transformer28、损耗比loss ratio29、损耗变动量power loss variationT1、套管bushing2、套管式电流互感器bushing type current transformer3、特殊试验special test4、调谐电抗器tuning（filter）reactor5、调压器voltage regulator6、铁轭yoke7、铁心core8、铁心接地端子earthed terminal for core9、铁心柱core limb10、通断触头main switch contacts11、桶式邮箱barrel type tank12、同心式线圈concentric windingW1、网侧绕组line side winding2、玩具用变压器transformer for toys3、稳定绕组stabilizing winding4、温升temperature rise5、稳压精度accuracy of a voltage stabilizing6、误差补偿error compensation7、无励磁分接开关off-circuit tap-changer8、无励磁调压变压器off-circuit-tap-changing transformer9、无危害式变压器（保安式变压器）fail-safe transformerX1、线段section2、相绕组phase winding3、箱式变电站integral unit4、相位差phase displacement5、相位移（变压器的）phase displacement（for a transformer）6、限流电抗器current-limiting reactor7、线路端子line terminal8、线圈coil9、线匝turn10、消弧电抗器arc-suppression reactor11、消弧线圈arc-suppression reactor12、消弧电抗器（消弧线圈）的额定电流rated current of an arc suppression reactor13、型式试验type test14、星形联结star connection15、信号温度计pressure-type thermometer16、心式变压器core-type transformer17、吸湿器radiator18、吸收比dielectric absorption ratio19、选择开关selector switch20、循环电流switched currentY1、压力释放装置pressure relief device2、压力式温度计pressure-type thermometer3、盐浴炉变压器salt bath furnace transformer4、仪表保安系数（FS）instrument security factor5、一次电流primary current6、一次电压primary voltage7、一次绕组（变压器的）primary winding（of a voltage transformer）8、一次绕组（电流互感器的）primary winding （of a current transformer）9、一次绕组（电压互感器的）primary winding（of a voltage transformer）10、I 类（防止电击）变压器class I transformer11、移圈调压器moving-coil voltage regulator12、油保护系统oil preservation system13、油流继电器oil-flow relay14、油浸式变压器oil-immersed type transformer15、油浸式电抗器oil-immersed type reactor16、油位计oil level indicator17、有载分接开关on-load tap-changer18、有载调压变压器on-load-tap-changing transformer19、油中溶解气体分析dissolved gas（in oil）analysisZ1、(线)匝turn2、再起动装置restarting device3、增压变压器booster transformer4、正分接plus tapping5、整流变压器rectifier transformer6、直流互感器direct current instrument transformer7、支柱式电流互感器support type current transformer8、中间式电流互感器current matching transformer9、中频变压器intermediate-frequency transformer10、中性点端子neutral terminal11、中性点接地电抗器neutral-earthing reactor12、中性点耦合器（中性点耦合器）earthing transformer（neutral coupler）13、中压电容器（电容式电压互感器的）intermediate voltage capacitor（of a capacitor voltage transformer）14、电压端子（电容式电压互感器的）intermediate voltage terminal（of a capacitor voltage transformer）15、中压绕组intermediate-voltage winding16、钟罩式油箱bell type tank17、转换选择器change-over selector18、主触头main contacts19、主分接（额定分接）principal tapping20、逐级控制step-by-step control21、准确级accuracy class22、准确限值系数（保护用电流互感器的）accuracy limit factor（of a protective current transformer）23、主（电容）屏main capacitor plate24、柱上式pole-type25、自动调压器automatic voltage regulator26、自动调压速度response speed27、自冷(AN) natural air cooling; self-cooling28、自耦变压器auto-transformer29、自耦复绕式电流互感器auto-compound current transformer30、自耦式互感器instrument auto-transformer31、总损耗total loss32、组合式变电站integral unit substation33、组合式互感器combined transformer34、最大额定级电压maximum rated step voltage35、最大额定通过电流maximum rated through-current36、阻抗电压（对于主分接）impedance voltage at rated current(for the principal tapping)37、阻尼电抗器damping reactor。

变压器中英文术语-3D Shock3D 冲击载荷记录器recorderAcc.class准确级Acid value（KOH mg/g)酸值Acid-base reaction (PH)酸碱反应Across the isolating distance通过隔离开关of isolating switchesair gap空气间隙Alarm circuit（Upper limit报警回路（上限输出）output）Alarms and tripping 警报和跳闸along with CT outlet box出线匣Altitude海拔高度Anti earth-quake grade 耐地震强度Antivibration pad 防震垫Assembly drawing装配图Auxiliary power supply辅助电源供电Base Materials母材Basic parameter基本参数Bellows pipe波纹管below the lower低于下转变温度transformation temperatureBolt螺栓Break,Open断,通Breakdown voltage of the oil油击穿电压Burden(VA)负荷bus母线Butterfly valve蝶阀butterfly valve seals蝶阀密封by Infrared 红外线法by resistance电阻法by thermometer温度计法cabinet for cableconnections, auxiliary relays and风控箱cooling system control,Fancontrol boxcabinets 控制柜Cable Tray Assembly电缆槽装置cabling布线capacity on valve side阀侧容量capacity online side网侧容量Capacity ratio容量比Center line of tank油箱中心线Center of gauge轨距中心Center of rail轨道中心Center of supporting plate支架板中心Center of tank油箱中心Clamp earthing接地线夹Clamp earthing assembly接地线夹装配conatant flux voltage恒磁通调压variation (C.F.V.V)connecting lead from windingto tap changer从绕组到分接开关的引线connection pipe,measure联管，升高座devide,ascending flanged baseConservator，membrane油枕，储油柜expansion tankConservator Air Bag胶囊（储油柜用）Conservator and connection储油柜及联管装配图pipe assembly drawingConservator of OLTC小油枕conservator with rubber胶囊式储油柜diaphragm，rubber bladerconservatorconstruction surface结构表面Contact thermometer指针式温度计contract life寿命Control cabinet of N2 FIRE充氮灭火装置控制柜FIGHTING SYSTEMControling & Measuring控制及测量回路接线原理图Circuit Drawingcooling冷却方式Copper Screw 铜螺杆Copper Valve 铜阀门Core earthing铁芯接地Core earthing assembly铁心接地装配Core earthing bushing核心接地套管接头terminalcore type芯式Cover plate盖板Current matcher电流匹配器Current transformer（CT）电流互感器Curve plate of oil temperature储油柜油温油位曲线牌and oil level for conservatorDC output直流输出Detailed Scope of Supply供货范围Dielectric levels (winding) 绝缘水平（绕组）：Dielectric loss angle tangent介电损耗角正切Dielectric loss of bushing套管介损Dismounted parts拆件零件，拆卸件draining valve放油阀门Eight-holes Butterfly valve 八孔蝶阀Eight-holes flange for装配的八孔法兰assemblingEqualpotential device between上下节油箱等电位设备upper and lower tankExternal cooling medium外部冷却介质Extreme minus tap极限负分接Extreme plus tap极限正分接Fan control box installation风控箱安装基本绘图base drawingFans风机Filling nitrogen connection排油注氮联管装配pipe assembly drawingFire prevention cabinet of N2充氮灭火装置消防柜FIRE FIGHTING SYSTEMFittings of N2 FIRE FIGHTING充氮灭火装置附件SYSTEMFixing device for connection联管固定装置pipeFixing pole固定杆Flange法兰for earthing bushing接地套管for handhole of h.v.ascending高压升高座的手孔flange basefor relief plug of conservator 放气塞Gas relay气体继电器Gas relay contact power继电器接点容量Gate Valve Flange法兰闸阀Grid parameter 电网参数：h.v.bushing高压套管H.V.Line terminal H.V.线路端子h.v.neutral phase bushing高压零相套管终端terminalh.v.Neutral phase CT高压零相电流互感器H.V.neutral terminal H.V.中性点端子Heating resistance加热电阻Height of center of gravity重心高度Height of parts to be lifted吊高Higher than upper limit value高于上限设定值Horizontal acceleration and横向加速度,垂直加速度vertical accelerationImpressed Voltage Resistance 外施耐压Inlet and drain valves 注油阀和排油阀Installation and operation安装和操作指令instructionInstallation Panel Hole安装面板开孔尺寸DimensionsInsulation for active parts主体绝缘Insulation levels绝缘水平Insulation oil变压器油，绝缘油Insulation paper cup绝缘纸杯Insulation paper Cylinder绝缘纸桶Insulation paperboard绝缘纸板Jack千斤顶l.v.bushing terminal低压套管接头l.v.line bank低压接线排L.V.Line terminal L.V.线路终端l.v.outlet method低压出线方式laboratory test report for绝缘油测试报告insulation oilLighting照明灯List of delivery documents出厂文件一览表List of Factory Technical出厂技术文件一览表DocumentsLower than limit value低于极限值Lower than upper limit value低于上限设定值M type OLTC M型OLTCMAE motor drive mechanism MAE电动机构Maker原产地manhole sealing人孔密封条Max unbalanced ratio最大不平衡率Measurement deviation测量误差Measurement for winding绕组电阻测量resistanceMinimum Preheat Temp最小预热温度Motor drive mechanism of OLTC电动机构Motor voltage 马达电压MV & LV Turret中低压升高座N - nude packing 裸装SC- steel case 铁皮箱neutral solidly earthed中性点直接接地Nitrogen cylinder of N2 FIRE充氮灭火装置氮气瓶FIGHTING SYSTEMNo load current空载电流No load losses空载损耗Noise Level噪声水平No-load voltage adjustment空载调压Nominal Voltage of Networks 电网额定电压no-return单向Normal operation 额定运行Normal setting condition正常使用条件Number of phase相数Nut 螺母Nylon tie尼龙扎带off-circuit tap-changer无励磁调压分接开关oil bushing 油式套管Oil draining valve assembly放油阀装置Oil for fittings加添油重Oil impregnated capacitive油浸电容套管bushingoil level gauges油位计Oil level indicator油位指示器Oil level indicator for变压器储油柜油位表transformer conservatorOil sampling valve油样活门Oil thermometer油温计,油面温度计oil-proof rubber耐油橡胶oil-proof,antiflaming,shield耐油、阻燃、屏蔽ingOLTC connection开关接线On-load losses负载损耗open air 露天in warehouse 仓库open winding开口线圈operation instruction使用说明书Operation test:操作试验Original Certification Check原材料合格证Over load capability过负荷能力Overall dimension外形尺寸overall height安装高度overe-xcited过励磁Partial discharge局放Performance data(guarantee性能数据（保证值）及允许偏差value) and permissible tolerancePermissible tolerance容许公差Plate for Clamping earthing接地线夹板Plate for Conservator储油柜板Plate for Core earthing铁心接地板Plate radiator片式散热器Plate(h.v.A.B.C.O)字牌Plate（Manhole)字牌（人孔）Pollution污秽等级Position(s) of Fillet 角焊缝位置Position(s) of Groove坡口焊缝power supply at terminal终端供电Pressure Relief Valve(PRD)安全阀Pressure relief valve/device压力释放阀Product Code产品代号Product test qualified产品测试合格证书certificateProduct Type产品型号Proposed foundation location建议地基位置示意图diagramRail foundation轨道基础Rated Capacity额定容量Rated Current额定电流Rated Frequency额定频率Rated nominal voltages in kV空载额定电压比of each winding on principaltapping at no-load:rated output power额定负荷Rated tap额定档Rated Voltage额定电压Rating Plate，铭牌Nameplate,Rating and diagramplatesRatio电流（压）比Reactor电抗器reference data参考数据Requirements of construction 结构方面要求Resistance overvoltage电阻过压冲击impulseScrew and seals assembly for真空蝶阀的螺杆和密封装配vacuum butterflySealing gasket密封垫片Sealing Rubber Along Tank密封橡胶沿着油箱Sealing washer密封垫圈Sealing，seals密封件Seals for assembly in factory 工厂组装密封Seals for assembly in site 现场组装密封Seamless steel tube无缝钢管See Drawing见图样Separate windings 独立绕组shell type壳式Short circuit impedance (%)短路阻抗Signal temperature indicator信号温度计Silical gel breather吸湿器Site temperature环境温度Size of unit组件尺寸solid直接Spare oil备用油Spare parts list备品备件specific loss单位损耗Spring Gasket 弹簧垫Standard code标准代号Steel plate钢板Tank and construction surface油箱和结构表面tank rim箱沿Tap Changer location 调压开关位置Tap pos.开关位置tapping分接Tapping range额定电压及分接范围Technical documents技术文件Technical Requirements技术要求Temperature rise limit温升限值Temperature value of each温度计各接点温度整定值contactTerminal box端子箱Test report of CT CT测试报告Thermometer socket温度计座This specifications provide外形尺寸图,外形图type,performance data,technicalrequirements and structure.Throttle valve断流阀节流阀Time Range保温时间范围:To central control room中央控制室To earth and between phases 对地和相间Top oil顶油Total losses总损耗Transformer foundation 变压器底座Transformer legs变压器芯柱Transportation dimension运输尺寸外形图DrawingTransportation drawing运输图Transportation(filling运输重（充氮）nitrogen)under-excited 欠励磁Upper positioning assembly 上部定位装配Vacuum butterfly valve真空蝶阀Vector Group Symbol联结组别Voltage vector relationship电压矢量关系Welding Procedure焊接工艺规程 (WPS) SpecificationWelding Progression焊接方向wheels小车Winding temperature indicator绕组温度计Wiring diagram线路图in conditioned warehouse空调房间。

1、分接开关（Tap-Changer)across coarse tap winding粗级调压线圈两端actual through-current实际通过电流additional contact range附加触点盘adjustment position校准位置application of test voltage施加试验电压的一般要求arrangement of winding线圈排列asymmetric pennant cycle非对称旗循环automatic passage through position自动通过位置auxiliary transformer辅助变压器auxiliary arcing contact过弧触头auxiliary circuit insulation test辅助线路试验axle销轴ball bearing球轴承basic connection diagram基本接线图bearing sleeve轴套,轴支撑套bell-type tank钟罩式油箱bevel gear伞齿輪盒bleeder放气裝置bleeder screw放气塞bleeding facility放气，放气裝置bracket compl弓型件braid编织线braided contact lead编织线brake contactor制动接触器break-down voltage击穿电压breaking capacity开断容量breaking capacity test切换容量试验breech cap护板，护帽bridge桥接bushing轴套，套筒cabinet hinge门折页cam凸轮cam operated contact凸轮驱动触点cam switch凸轮开关cardan shaft方向轴centering sliced spacer定位间距垫圈change-over selector转換选擇器chopped wave截波circlip lock ring开口锁环circulating current循环电流classification分类coarse tap selector粗级选擇器coarse change-over selector粗级转換选擇器cocking sledge释放滑板，枪机滑板combined filter insert释放滑板compression spring压力弹簧connecting lead連接线conservator储油柜constant induction恒磁通contact holder触头座contact life触头寿命contact life expectancy触头预期寿命contact range, continuous连续触点盘contact range, decadic十进制触点盘contact tip接点，触点coupling接头，聯轴器cup spring碟形弹簧current splitting电流私分流current strip导电片cycle of operation操作循环delay time延时dielectric strength绝缘强度dielectric test绝缘试验disc盘，垫块diverter switch切换开关diverter switch unit切換開关芯子double-bridging off-load tap changer双桥接無励磁分接开关double-ended open-jaw wrench双头开口扳手double-ended socket wrench双头套筒扳手drag hand拖针drag ring拖环drive crank回动件drive shaft驱动轴，传动轴drive shaft传动轴drive shaft arrangement传动轴布置drive star回动轴dust and vermin proof housing防尘防虫机箱duty on main and transition condition主触头和过渡触头的任务eccentric cam偏心轮effect of power-factor on circuit-breaking duty功率因数对开关任务electrolysis transformer整流变压器emergency tripping device紧急跳阐装置emergency-off紧急跳阐epoxy guid plate（环氧浇注）导板epoxy segment环氧浇注弓型件feather键filter滤油机filter cartridge滤芯filter insert滤芯fixed contact定触头flag cycle旗循环flat head screw平头螺丝flexible current strip软导電片for neutral application用于中性点full wave全波furnace transformer电弧炉变压器geneva gear槽轮机，行星机构geneva wheel槽轮，行星轮grading block均压环guide block导板挡块guide bolt导杆guide roller导滾head variant头型helical spring, compression type螺旋压簧hexagon socket screw內六角螺丝hexagon socket screw key內六角螺丝扳手highest amplitude最大振幅highest voltage for equipment设备最高电压hub基座impact recorder冲击记录仪information required with enquiries and orders询价和订货要求的数据inherent drawing基本图纸，固有图纸insulating bar绝缘立柱，绝缘条insulating clingers绝缘筒insulating tube绝缘管insulation level绝缘水平insulation level to ground對地绝缘水平intermediate bearing中间齿轮intermediate terminal中間端子intermediate plate中間板internal tap changer insulation分接开关内绝缘laminated tube层压胶纸管lamp panel灯板，灯屏level transverse橫吊具lifting lug吊攀lightning impulse voltage test雷电冲击電压试验limit switch限位开关linear off-circuit tap changer线性调无励磁分接开关linear tap winding线性调压线段load shedding甩负载lock tab锁片main arcing contact主弧触头main contact主触头main switching contacts主通断触头maximum number of effective turns最大有效匝数maximum rated step voltage最大额定级电压maximum rated through-current最大额定通过電流measurement of partial discharge局部放電测量mechanical end stop机械的极限止动装置mechanical endurance test机械寿命试验mid-position中間位置minimum number of effective turns最小有效匝数mode switch工作方式开关molded insulation模压绝缘motor drive mechanism电动机构motor drive unit电动机构motor driver电动机构motor protective switch电机保护开关mounting flange安装法兰movable contact动触头nameplate铭牌nature of tests试验的性质no-load tap-changer无载分接开关number of contact range触点盘数目number of inherent tapping position固有分接位置数number of operating position分接位置数目number of service tapping position工作分接位置数o-ring O形密封垫，O形封环off-circuit tap changer无励磁分接开关oil compartment油室oil displacement volume油中占据容积oil-level gauges油位计on load tap changer有载分接开关operating key（V型有载分接开关）专用吊具operating position分接位置operation counter计数器overcurrent blocking device过電流闭锁装置overload condition过载条件overpressure relay过压力継电器overrun test超试验overunning超paper filter纸滤芯parallel bridge关联桥接parallel control devices关联控制装置parallel control unit关联控制器pawl棘爪peak value峰值pipe connection管接头plate spring平板弹簧pointer instrument指针式指示器position transmitter位置传送器potential switch電位开关potentiometer contact range分压式触点盘power supply unit電源装置power-frequency voltage test工频电压试验pressure and vacuum tests压力和真空试验pressure gauge压力表pressure monitor压力监视器pressure plate压板pressure relief device压力释放装置pressure relief diaphragm压力释放板pressure relief value压力释放阀process transformer工业变压器protection class保护等级protective relay保护断电器rms有效值ratchet棘轮rated frequency额定频率rated lightning impulse withstand voltage额定雷電冲击耐压rated power frequency withstand voltage额定工频耐压rated step voltage额定级电压rated through-current额定通过电流rated torque on drive shaft传动轴额定转矩rated withstand voltage to ground额定对地耐压recovery voltage恢愎电压regulating range调压范围relay converter中継转換器relevant step voltage相关级电压remote indicator远方显示resistance position transmitter电阻式位置传送器response time动作時间restarting device重启动装置reversing change-over selector极性转換送选择器reversing switch反向开关，极性选择器rivet铆钉rivet plate垫板rivet, counter sunk埋头铆钉，沉头铆钉rivet, round head圆头铆钉rocker摇杆roller滾筒，滾轴，辊子routine test出厂试验screen cap均压环，屏蔽环screening cap屏蔽帽screening device屏蔽装置sartorial connection导电环，弧形导电片selector switch选择开关selsyn transmitter伺服传送器sequence test须序试验series-parallel off-circuit tap changer串开联无励磁分接开关service condition使用条件service duty test工作负载切换试验service position工作位置（＝分接位置）set of contacts触头组short-circuit strength短路强度shunt contact主触头simulated test circuits模拟试验线路single-bridging of-load tap changer单桥接无励磁分接开关sliced spacer滑动间距垫圈，间距垫圈sliced spacing ring间距垫圈环slider滑块slotted socket screw,recess head沉头开槽内六角螺丝special design特殊型式，特殊设计spring holder弹簧架，弹簧挂板standard-tank标准油箱，箱盖式油箱star-delta off-circuit changer星角接無励磁分接开关stationary oil filter固定式滤油机step voltage级电压step-by-step control逐级控制step-by-step operation逐级操作step-by-step principle逐级控制原理suction pipe吸油管supporting flange支撑法兰surface constant面接触switched current开断电流switching开断，变换，切换，转换switching capacity切换容量switching column开關柱switching element触头元件switching impulse test操作冲击试验switching operation变换操作switching process转换（开关）过程switching segment触头扇形板switching signal转换（切换，触发）过程switching system触头系统switching test切换试验switching time开关（转换）时间switching transient开关瞬态swivelling range of gear unit上齿轮盒回转范围symmetric pennant cycle對称尖旗循环synchronous speed同步转速synthetic insulating liquid合成绝缘液体take-off bar引出导杆take-off contact case引出触头座take-off leads引出线take-off ring引出环take-off terminal引出端子tap change indication wheel分接变换指示轮tap changer head开关头tap changer head cover开关头盖tap changer incomplete indication分接变换未完成显示tap changer model分接开关规格tap changer type分接开关型号tap position indication分接位置指示tap selector分接选择器tap selector pitch分接选择器触头数tap selector size分接选择器触等级tap winding调压线圈，调压线段tap-change in progress indication分接变换在进行的指示tap-change operation分接变换（操作）taper pin斜形销，锥销tapping current分接电流temperature of tap-changer environment分接开关的环境溫度temperature rise of contact触头温升temporary over-load短时过负载tension spring张力弹簧，拉簧terminal range端子排thermal stability热稳定thermostat恒温器threaded clamping stud夹紧螺杆tie-in resistor连接电阻，束缚电阻transition contacts过渡触头transition impendence过渡阻抗transition resistance过渡电阻triangular switching lever拨盘，转换三角杆tripping pressure动作压力tubular drive shaft传动轴套two-position slide switch双投动开关type test型式试验type-test certificate型式试验证书upper contact plane上层触头upper gear unit上齿轮盒variable induction变磁通variants of the tap changer head开关头类型voltage stress电压梯度wind up上紧wind-up sledge上紧滑板wind-up sledge上紧滑板withstand voltage耐受电压（＝能承受住的電压）2、温度指示器类(Temperature Indicator)ambient temperature环境温度bulb温包cable gland电缆护套capillary tubing毛细管capillary with SS-cover毛细管带有不锈钢护套contact thermometer触点式温度计（接触式温度计－误译）heating element发热元件hot spot temperature最热点温度inductive load感性负载making and breaking capacity通断容量matching resistance匹配电阻matching unit匹配器maximum indicating pointer最大连续输入（电流）maximum pointer拖针（最大值指针）measuring accuracy测量精度mercury switch银开关micro switch微动开关oil temperature indicator油温指示器potentiometer分压器power supply电源（装置）protective tube保护管resetable可重整定switching accuracy通断精度switching differential通断回程差，通断间距temperature sensor温度传感器（温包）temperature gradient温度梯度，温差temperature of the hottest part of wdg..线圈最热分部温度terminal block端子排thermal image热模拟（热像）thermal time constant热时间常数thermometer溫度计thermometer pocket溫度计座thermometer well溫度计座top oil temperature油面溫度（顶层油溫）top oil temperature rise油面溫升（顶层油升）two way switch双向开关ventilated case通气型外壳winding temperature indicator线圈溫度指示器winding temperature transmitter线圈溫度传送器3、套管类(Bushing)air draining plug放气塞arcing horns保护间隙bushing in resin bonded paper胶纸套管C.T. space电流互感器空间cantilever load悬臂负荷capacitance graded bushing电容式套管cemented porcelain水泥浇铸瓷件condenser bushing电容式套管creep age distance爬距discharge distance放电距离dissipation factor介损因数draw leasd type穿缆式draw rod type穿杆式drew lead bushing穿缆套管dry power frequency withstand voltage工频干耐压dynamic current动稳定电流fix rod type固定导杆式fix tube type固定导管式flexible connection软连接high polluted atmosphere高污秽大气layer conductance污层电导mechanical failing load机械破环负荷normal tail正常尾oil condenser充油电容器oil impregnated paper bushing油浸纸套管oil reservoir储油柜oil side deflector油侧屏蔽pair of sheds(small-large)（大小）伞對partial discharge局放（局部放电）pollution layer污层porcelain瓷件power factor功率因数rated phase to earth voltage额定相對地电压shed伞，伞裙small-large sheds大小伞temperature cycle test溫度循环试验thermal shotr time current热短时电流thermal stability test热稳定试验throughway bushing穿墙套管voltage tap电压抽头wet power frequency withstand voltage工频湿耐压4、变压器和滤油机类(Transformer)acidity酸度coalescer聚结器contaminat污秽continuous duty连续负载dielectric dissipation介质损耗duty of pump泵效率fire hazard易燃（性）heavy duty重型，重负载interface tension界面张力mobile transformer oil purifier拖车式变压器油净油机neutralization value中和值oil discharge pump放油泵，排油泵oxidation stability氧化稳定性portable 2 stage purifier移动式两级净油机portable industrial oil purifier移动式工業油净油机purification净化（处理）purifier净油机regeneration再生（处理）sludge沉淀，油泥solid particles固体颗粒stationary purifier固定式净油机water content含水量5、其它组件类(Spare Parts)A/D converter交直流变换器alarm accuracy报警精度armored cable铠装电缆bandwidth带宽BCD encoded signal BCD编码信号BCD = binary codedf decimal二－十进制编码Buchhoiz relay气体继电器climatic version六气条件corrosion resistance耐腐蚀degree of protection保护等级digital indication unit数码显示器digital switch数字式开关diode-matrix二级管矩阵double-float Buchholz relay双浮子气体继电器flap value aperture挡板开孔float浮子LED = light emitting diode发光二极管line drop compensator线路压降补偿magnet contact tube干簧继电器multi contact plug多针插头multi-contact jack多针插座N/C contact动开（常闭）触点N/O contact动开（常开）触点reed contact干簧触点response time of damper挡板响应时间semaphore扬旗（压力释放阀用）shock proof耐震动shock resistance抗震能力single-float Buchholz relay单浮子气体继电器switching system触点系統temperature comp. Range溫度补偿范围TTL = transistor-transistor logic晶体管－晶体管逻辑电路voltage limit supervisory control电压限值监控voltage limit supervisory control unit电压限值监控器voltage regulating relay电压调整器（电压调整继电器）weather-proof耐大气作用screw螺钉，螺丝，虎钳anchor地脚螺丝attachment装配螺丝，紧固螺丝backing-up上动螺丝ball-jointed方向球铰螺杆bench台式虎钳binding接线螺丝bleed带孔螺丝，放气螺丝calibration校准螺丝check止动螺丝clamp夹紧螺丝closing螺纹规coarse thread粗纹螺丝endless蜗杆expansion可调螺丝fastening紧固螺丝flat平头螺丝half-round半圆头螺丝holding紧固螺丝hollow空心螺丝hook带钩螺丝lock锁紧螺丝plug螺塞perpetual蜗杆round head圆头螺丝self tapping自攻螺丝setting定位螺丝setting-up固定螺丝，锁紧螺丝sheet metal金属板螺丝slotted有槽螺丝slotted head槽头螺丝socket凹头螺丝tapping自攻螺丝thumb蝶形螺丝worm蜗杆nut螺母，螺帽adjusting调整螺母attaching配合螺母back支撑螺母，限动螺母blinding扣紧螺帽blind盲孔螺母，螺盖blocking防松螺母，锁紧螺母butterfly蝶形螺母cap螺帽clamp花螺母，压紧螺母fixing固定螺帽flange凸缘螺母flush平顶螺母fly蝶形螺母hex(=hexagonal)六角螺母locking锁紧螺母pinch锁紧螺母screw螺母sealing密封螺母self-locking自锁螺母slotted有槽螺母slit开缝螺母stamped模压螺母stop防松螺母terminal接线柱螺母wing蝶形（元宝）螺帽packing垫（压紧，密封）螺帽union联管螺帽，连接螺套。

1、分接开关（Tap-Changer)across coarse tap winding粗级调压线圈两端actual through-current实际通过电流additional contact range附加触点盘adjustment position校准位置application of test voltage施加试验电压的一般要求arrangement of winding线圈排列asymmetric pennant cycle非对称旗循环automatic passage through position自动通过位置auxiliary transformer辅助变压器auxiliary arcing contact过弧触头auxiliary circuit insulation test辅助线路试验axle销轴ball bearing球轴承basic connection diagram基本接线图bearing sleeve轴套,轴支撑套bell-type tank钟罩式油箱bevel gear伞齿輪盒bleeder放气裝置bleeder screw放气塞bleeding facility放气，放气裝置bracket compl弓型件braid编织线braided contact lead编织线brake contactor制动接触器break-down voltage击穿电压breaking capacity开断容量breaking capacity test切换容量试验breech cap护板，护帽bridge桥接bushing轴套，套筒cabinet hinge门折页cam凸轮cam operated contact凸轮驱动触点cam switch凸轮开关cardan shaft方向轴centering sliced spacer定位间距垫圈change-over selector转換选擇器chopped wave截波circlip lock ring开口锁环circulating current循环电流classification分类coarse tap selector粗级选擇器coarse change-over selector粗级转換选擇器cocking sledge释放滑板，枪机滑板combined filter insert释放滑板compression spring压力弹簧connecting lead連接线conservator储油柜constant induction恒磁通contact holder触头座contact life触头寿命contact life expectancy触头预期寿命contact range, continuous连续触点盘contact range, decadic十进制触点盘contact tip接点，触点coupling接头，聯轴器cup spring碟形弹簧current splitting电流私分流current strip导电片cycle of operation操作循环delay time延时dielectric strength绝缘强度dielectric test绝缘试验disc盘，垫块diverter switch切换开关diverter switch unit切換開关芯子double-bridging off-load tap changer双桥接無励磁分接开关double-ended open-jaw wrench双头开口扳手double-ended socket wrench双头套筒扳手drag hand拖针drag ring拖环drive crank回动件drive shaft驱动轴，传动轴drive shaft传动轴drive shaft arrangement传动轴布置drive star回动轴dust and vermin proof housing防尘防虫机箱duty on main and transition condition主触头和过渡触头的任务eccentric cam偏心轮effect of power-factor on circuit-breaking duty功率因数对开关任务electrolysis transformer整流变压器emergency tripping device紧急跳阐装置emergency-off紧急跳阐epoxy guid plate（环氧浇注）导板epoxy segment环氧浇注弓型件feather键filter滤油机filter cartridge滤芯filter insert滤芯fixed contact定触头flag cycle旗循环flat head screw平头螺丝flexible current strip软导電片for neutral application用于中性点full wave全波furnace transformer电弧炉变压器geneva gear槽轮机，行星机构geneva wheel槽轮，行星轮grading block均压环guide block导板挡块guide bolt导杆guide roller导滾head variant头型helical spring, compression type螺旋压簧hexagon socket screw內六角螺丝hexagon socket screw key內六角螺丝扳手highest amplitude最大振幅highest voltage for equipment设备最高电压hub基座impact recorder冲击记录仪information required with enquiries and orders询价和订货要求的数据inherent drawing基本图纸，固有图纸insulating bar绝缘立柱，绝缘条insulating clingers绝缘筒insulating tube绝缘管insulation level绝缘水平insulation level to ground對地绝缘水平intermediate bearing中间齿轮intermediate terminal中間端子intermediate plate中間板internal tap changer insulation分接开关内绝缘laminated tube层压胶纸管lamp panel灯板，灯屏level transverse橫吊具lifting lug吊攀lightning impulse voltage test雷电冲击電压试验limit switch限位开关linear off-circuit tap changer线性调无励磁分接开关linear tap winding线性调压线段load shedding甩负载lock tab锁片main arcing contact主弧触头main contact主触头main switching contacts主通断触头maximum number of effective turns最大有效匝数maximum rated step voltage最大额定级电压maximum rated through-current最大额定通过電流measurement of partial discharge局部放電测量mechanical end stop机械的极限止动装置mechanical endurance test机械寿命试验mid-position中間位置minimum number of effective turns最小有效匝数mode switch工作方式开关molded insulation模压绝缘motor drive mechanism电动机构motor drive unit电动机构motor driver电动机构motor protective switch电机保护开关mounting flange安装法兰movable contact动触头nameplate铭牌nature of tests试验的性质no-load tap-changer无载分接开关number of contact range触点盘数目number of inherent tapping position固有分接位置数number of operating position分接位置数目number of service tapping position工作分接位置数o-ring O形密封垫，O形封环off-circuit tap changer无励磁分接开关oil compartment油室oil displacement volume油中占据容积oil-level gauges油位计on load tap changer有载分接开关operating key（V型有载分接开关）专用吊具operating position分接位置operation counter计数器overcurrent blocking device过電流闭锁装置overload condition过载条件overpressure relay过压力継电器overrun test超试验overunning超paper filter纸滤芯parallel bridge关联桥接parallel control devices关联控制装置parallel control unit关联控制器pawl棘爪peak value峰值pipe connection管接头plate spring平板弹簧pointer instrument指针式指示器position transmitter位置传送器potential switch電位开关potentiometer contact range分压式触点盘power supply unit電源装置power-frequency voltage test工频电压试验pressure and vacuum tests压力和真空试验pressure gauge压力表pressure monitor压力监视器pressure plate压板pressure relief device压力释放装置pressure relief diaphragm压力释放板pressure relief value压力释放阀process transformer工业变压器protection class保护等级protective relay保护断电器rms有效值ratchet棘轮rated frequency额定频率rated lightning impulse withstand voltage额定雷電冲击耐压rated power frequency withstand voltage额定工频耐压rated step voltage额定级电压rated through-current额定通过电流rated torque on drive shaft传动轴额定转矩rated withstand voltage to ground额定对地耐压recovery voltage恢愎电压regulating range调压范围relay converter中継转換器relevant step voltage相关级电压remote indicator远方显示resistance position transmitter电阻式位置传送器response time动作時间restarting device重启动装置reversing change-over selector极性转換送选择器reversing switch反向开关，极性选择器rivet铆钉rivet plate垫板rivet, counter sunk埋头铆钉，沉头铆钉rivet, round head圆头铆钉rocker摇杆roller滾筒，滾轴，辊子routine test出厂试验screen cap均压环，屏蔽环screening cap屏蔽帽screening device屏蔽装置sartorial connection导电环，弧形导电片selector switch选择开关selsyn transmitter伺服传送器sequence test须序试验series-parallel off-circuit tap changer串开联无励磁分接开关service condition使用条件service duty test工作负载切换试验service position工作位置（＝分接位置）set of contacts触头组short-circuit strength短路强度shunt contact主触头simulated test circuits模拟试验线路single-bridging of-load tap changer单桥接无励磁分接开关sliced spacer滑动间距垫圈，间距垫圈sliced spacing ring间距垫圈环slider滑块slotted socket screw,recess head沉头开槽内六角螺丝special design特殊型式，特殊设计spring holder弹簧架，弹簧挂板standard-tank标准油箱，箱盖式油箱star-delta off-circuit changer星角接無励磁分接开关stationary oil filter固定式滤油机step voltage级电压step-by-step control逐级控制step-by-step operation逐级操作step-by-step principle逐级控制原理suction pipe吸油管supporting flange支撑法兰surface constant面接触switched current开断电流switching开断，变换，切换，转换switching capacity切换容量switching column开關柱switching element触头元件switching impulse test操作冲击试验switching operation变换操作switching process转换（开关）过程switching segment触头扇形板switching signal转换（切换，触发）过程switching system触头系统switching test切换试验switching time开关（转换）时间switching transient开关瞬态swivelling range of gear unit上齿轮盒回转范围symmetric pennant cycle對称尖旗循环synchronous speed同步转速synthetic insulating liquid合成绝缘液体take-off bar引出导杆take-off contact case引出触头座take-off leads引出线take-off ring引出环take-off terminal引出端子tap change indication wheel分接变换指示轮tap changer head开关头tap changer head cover开关头盖tap changer incomplete indication分接变换未完成显示tap changer model分接开关规格tap changer type分接开关型号tap position indication分接位置指示tap selector分接选择器tap selector pitch分接选择器触头数tap selector size分接选择器触等级tap winding调压线圈，调压线段tap-change in progress indication分接变换在进行的指示tap-change operation分接变换（操作）taper pin斜形销，锥销tapping current分接电流temperature of tap-changer environment分接开关的环境溫度temperature rise of contact触头温升temporary over-load短时过负载tension spring张力弹簧，拉簧terminal range端子排thermal stability热稳定thermostat恒温器threaded clamping stud夹紧螺杆tie-in resistor连接电阻，束缚电阻transition contacts过渡触头transition impendence过渡阻抗transition resistance过渡电阻triangular switching lever拨盘，转换三角杆tripping pressure动作压力tubular drive shaft传动轴套two-position slide switch双投动开关type test型式试验type-test certificate型式试验证书upper contact plane上层触头upper gear unit上齿轮盒variable induction变磁通variants of the tap changer head开关头类型voltage stress电压梯度wind up上紧wind-up sledge上紧滑板wind-up sledge上紧滑板withstand voltage耐受电压（＝能承受住的電压）2、温度指示器类(Temperature Indicator)ambient temperature环境温度bulb温包cable gland电缆护套capillary tubing毛细管capillary with SS-cover毛细管带有不锈钢护套contact thermometer触点式温度计（接触式温度计－误译）heating element发热元件hot spot temperature最热点温度inductive load感性负载making and breaking capacity通断容量matching resistance匹配电阻matching unit匹配器maximum indicating pointer最大连续输入（电流）maximum pointer拖针（最大值指针）measuring accuracy测量精度mercury switch银开关micro switch微动开关oil temperature indicator油温指示器potentiometer分压器power supply电源（装置）protective tube保护管resetable可重整定switching accuracy通断精度switching differential通断回程差，通断间距temperature sensor温度传感器（温包）temperature gradient温度梯度，温差temperature of the hottest part of wdg..线圈最热分部温度terminal block端子排thermal image热模拟（热像）thermal time constant热时间常数thermometer溫度计thermometer pocket溫度计座thermometer well溫度计座top oil temperature油面溫度（顶层油溫）top oil temperature rise油面溫升（顶层油升）two way switch双向开关ventilated case通气型外壳winding temperature indicator线圈溫度指示器winding temperature transmitter线圈溫度传送器3、套管类(Bushing)air draining plug放气塞arcing horns保护间隙bushing in resin bonded paper胶纸套管C.T. space电流互感器空间cantilever load悬臂负荷capacitance graded bushing电容式套管cemented porcelain水泥浇铸瓷件condenser bushing电容式套管creep age distance爬距discharge distance放电距离dissipation factor介损因数draw leasd type穿缆式draw rod type穿杆式drew lead bushing穿缆套管dry power frequency withstand voltage工频干耐压dynamic current动稳定电流fix rod type固定导杆式fix tube type固定导管式flexible connection软连接high polluted atmosphere高污秽大气layer conductance污层电导mechanical failing load机械破环负荷normal tail正常尾oil condenser充油电容器oil impregnated paper bushing油浸纸套管oil reservoir储油柜oil side deflector油侧屏蔽pair of sheds(small-large)（大小）伞對partial discharge局放（局部放电）pollution layer污层porcelain瓷件power factor功率因数rated phase to earth voltage额定相對地电压shed伞，伞裙small-large sheds大小伞temperature cycle test溫度循环试验thermal shotr time current热短时电流thermal stability test热稳定试验throughway bushing穿墙套管voltage tap电压抽头wet power frequency withstand voltage工频湿耐压4、变压器和滤油机类(Transformer)acidity酸度coalescer聚结器contaminat污秽continuous duty连续负载dielectric dissipation介质损耗duty of pump泵效率fire hazard易燃（性）heavy duty重型，重负载interface tension界面张力mobile transformer oil purifier拖车式变压器油净油机neutralization value中和值oil discharge pump放油泵，排油泵oxidation stability氧化稳定性portable 2 stage purifier移动式两级净油机portable industrial oil purifier移动式工業油净油机purification净化（处理）purifier净油机regeneration再生（处理）sludge沉淀，油泥solid particles固体颗粒stationary purifier固定式净油机water content含水量5、其它组件类(Spare Parts)A/D converter交直流变换器alarm accuracy报警精度armored cable铠装电缆bandwidth带宽BCD encoded signal BCD编码信号BCD = binary codedf decimal二－十进制编码Buchhoiz relay气体继电器climatic version六气条件corrosion resistance耐腐蚀degree of protection保护等级digital indication unit数码显示器digital switch数字式开关diode-matrix二级管矩阵double-float Buchholz relay双浮子气体继电器flap value aperture挡板开孔float浮子LED = light emitting diode发光二极管line drop compensator线路压降补偿magnet contact tube干簧继电器multi contact plug多针插头multi-contact jack多针插座N/C contact动开（常闭）触点N/O contact动开（常开）触点reed contact干簧触点response time of damper挡板响应时间semaphore扬旗（压力释放阀用）shock proof耐震动shock resistance抗震能力single-float Buchholz relay单浮子气体继电器switching system触点系統temperature comp. Range溫度补偿范围TTL = transistor-transistor logic晶体管－晶体管逻辑电路voltage limit supervisory control电压限值监控voltage limit supervisory control unit电压限值监控器voltage regulating relay电压调整器（电压调整继电器）weather-proof耐大气作用screw螺钉，螺丝，虎钳anchor地脚螺丝attachment装配螺丝，紧固螺丝backing-up上动螺丝ball-jointed方向球铰螺杆bench台式虎钳binding接线螺丝bleed带孔螺丝，放气螺丝calibration校准螺丝check止动螺丝clamp夹紧螺丝closing螺纹规coarse thread粗纹螺丝endless蜗杆expansion可调螺丝fastening紧固螺丝flat平头螺丝half-round半圆头螺丝holding紧固螺丝hollow空心螺丝hook带钩螺丝lock锁紧螺丝plug螺塞perpetual蜗杆round head圆头螺丝self tapping自攻螺丝setting定位螺丝setting-up固定螺丝，锁紧螺丝sheet metal金属板螺丝slotted有槽螺丝slotted head槽头螺丝socket凹头螺丝tapping自攻螺丝thumb蝶形螺丝worm蜗杆nut螺母，螺帽adjusting调整螺母attaching配合螺母back支撑螺母，限动螺母blinding扣紧螺帽blind盲孔螺母，螺盖blocking防松螺母，锁紧螺母butterfly蝶形螺母cap螺帽clamp花螺母，压紧螺母fixing固定螺帽flange凸缘螺母flush平顶螺母fly蝶形螺母hex(=hexagonal)六角螺母locking锁紧螺母pinch锁紧螺母screw螺母sealing密封螺母self-locking自锁螺母slotted有槽螺母slit开缝螺母stamped模压螺母stop防松螺母terminal接线柱螺母wing蝶形（元宝）螺帽packing垫（压紧，密封）螺帽union联管螺帽，连接螺套。
