德马格塑料机械（宁波）有限公司
售后服务培训资料
Service training course of DPG
plastics injection moulding machine
德马格塑料机械（宁波）有限公司售后服务部编制
服务热线： 配件供应：
7 5
4 6
投诉电话：7 8 传真：8
技术资料 请勿转载
第一章 显示器的操作原理Egocontrol operating Philosophy
操作终端 “NC4 控制器”Operating Terminal “Ergocontrol NC4”
Fig. 1--1: Operating terminal “Ergocontrol (EC) NC4”
液晶屏幕
LCD Display
功能组键
Function group key
数字键盘
Numeric Keypad
手动动作功能键
Manaulfunction button
状态选择键
Mold selection button
-
紧急停止按钮
Emergency stop 开关按钮
ON/OFF button 启动按钮
Start button
软驱
Disk driver 软件
Soft key 光标移动键
Cursor move key
特殊功能键盘
Special function
key 光标快速移动滑轮
Cursor move shuttle wheel 软键
Soft key 1. 1. 1 功能组键/Function Group Keys
Ergocontrol (EC) 显示屏中的页面均可通过屏幕下的相关热键（功能组键）翻到
Ergocontrol (EC)screen pages are function relevant called up by pressing the hot keys (function group
keys).
按下这些按钮可直接翻到相关的主画面如：按 合模单元组键可直接翻到
“10模具设置”页
By pressing these buttons is displayed the main page of the selected function group,
screen page “10 MOULD” in function group “clamping unit”.
功能组键/Function group 合模单元/CLAMPING UNIT
功能组键/Function group
注射单元/INJECTION UNIT
功能组键/Function group
温度控制/TEMPERATURES
功能组键/Function group
程序选择/PROGRAMS
功能组键/Function group
加工控制/PROCESS CONTRO
Fig. 1--2: Meaning of the function group keys
其它的一些功能键均可通过按屏幕下的软键来选取
Further function group relevant screen pages can be selected by pressing the appropriate
softkeys (see also chapter 2. 3 and 2. 4. 1).
按软件中的“返回”可退回至原有的画面中
By pressing the softkey ”return” can be returned to the previously displayed screen page.
软键图标：
Softkey “return:
1. 2 随机软盘的用法/Handling of the Machine Diskettes
机器由于种种原因出现程序丢失时可通过重装随机软盘来恢复（详细的操作方法在后面的第七项有详细讲解）The machine programs have to be reloaded only when the program is crashed
for any reason.
注意： 这些软盘“Boot CPU(机器控制程序)”，”Boot firmware(固化程序)”,”Boot picture(画面程
序)”，”Boot Diagnostic—disk(清除程序)” 均能在将软盘插入软驱后重开电源时自动将程序载入机器
Note: The diskettes “Boot CPU” (machine control), “Boot Ergocontrol” (firmware and
screen layout) and “Diagnostic--DISK” (diagnosis of faults) are automatically loaded into
machine control, when such a disk is in the disk drive unit while the machine is switched on.
. 1 安装CPU盘/Diskette “BOOT CPU” 功能组键/Function group
自动化/AUTOMATIZATION
功能组键/Function group
德马格机械手/HANDLING
功能组键/Function group
页面列表/PAGE LAYOUT
功能组键/Function group
服务页面/SERVICE
功能组键/Function group
警服页面/ALARMS P
。将CPU盘插入软驱
Put the disk into the drive unit;
。关闭油泵电机
Switch off the pump;
。关开机器总电源
Switch (off and) on the machine power
。开始读程序后显示屏里会出现以下画面
；Auto exeo SIGMATEK GMBH
；Demag Ergotech Wiehe Gmbh
；NC4 ERGOCONTROL
；machine program
；Disk done by ETP on XXX XX:XX
；SPS
RESET CAN/ 00
CPU BOOTADR CAN/ 00
LCM40 CAN/ 00 B:PRG__SGM\NDM303SPR
STATUS: READ FILE: B:\****\.***
ERRO: NO
Fig. 1--3: CPU booting page
。待软驱灯灭后, 画面中会出现如下画面
Following picture will be displayed in the ergocontrol unit after the indicate light
off of the disk driver.
SIGMATEK GmbH HADWRERESET
CAN – STATION 25
CAN – BAUDRATE: [ 615 KB ] 00
PROGSEG: [ Mb ]
PICSEG: [ Mb ]
KONTRAST: xxx
Fig. 1--4: CPU booting page
。待以下主画面出现时取出磁盘
Take the disk out of the unit after the “main menu” lay out in ergocontrol.
: machine main page
1. 2. 2 安装“SPS数据源”盘/Diskette “Sources SPS--DISC”
只有当需要安装外加程序或升程序级时才要求更换此程序盘，，若出现这种情况只有德马格海天公司的售后服务人员才可操作。（或在德马格海天售后服务人员的指导下）
This Diskette is required only in case of CPU program changes, updates and/or
program additions by DET--Service.
1. 2. 3 安装固化程序盘/Diskette “BOOT firmware”
。将固化程序盘插入软盘驱动器
Put the disk into the drive unit;
。关开机器总电源
Switch (off and) on the machine;
。待软驱灯灭后取出磁盘
Take the disk out of the unit after the indicate light off.
. 4 安装画面启动盘/Diskette “BOOT PICTURE”
。将画面程序盘插入软盘驱动器
Put the picture disk in the disk drive unit
。关闭油泵电机
Switch (off) the pump motor
。关闭机器总电源
Switch (off and on) the machine power
