CCNA认证基础-习题分析讲义第一部分第一章1. Convert the binary number 10111010 into its hexadecimal equivalent. Select thecorrect answer from the list below. （3）1) 852) 903) BA4) A15) B36) 1C2. Convert the Hexadecimal number A2 into its Base 10 equivalent. Select thecorrect answer from the list below. （4）1) 1562) 1583) 1604) 1625) 1646) 1663. Which binary number is a representation of the decimal number 248? （3）1) 111010002) 111101003) 111110004) 111110104. Which of the following will test the internal loopback of a node? （3）1) ping 10.10.10.12) ping 192.168.1.13) ping 127.0.0.14) ping 223.223.223.2235) ping 255.255.255.2555. What can be verified by successfully pinging the reserved loopback address ona host? （2）1) Connectivity exists between two hosts on the LAN.2) The TCP/IP stack of the local host is configured correctly.3) A connection exists between a host and the default gateway.4) The route a packet takes from the local host to a remote host is valid.6. Which of the following commands could be used on a Windows-basedcomputer to view the current IP configuration of the system? (Choose two.) （3，4）1) configip2) ifconfig3) ipconfig4) winipcfg5) Winipconfig7.Refer to the exhibit. What must be configured on Host B to allow it to communicate withthe Host C? (Choose three.) （2，4，6）1)the MAC address of RTA router interface connected to Switch 12) a unique host IP address3)the IP address of Switch 14)the default gateway address5)the MAC address of Host C6)the subnet mask for the LAN8. What are important characteristics to consider when purchasing a networkinterface card? (Choose two.) （2，3）1) security used on the network2) media used on the network3) system bus used on the computer4) software installed on the network5) diagnostic tools installed on the network第二章1. Select the necessary information that is required to compute the estimated timeit would take to transfer data from one location to another. (Choose two.) （1，5）1) file size2) data format3) network in use4) type of medium5) bandwidth of the link2. Using the data transfer calculation T=S/BW, how long would it take a 4MB file tobe sent over a 1.5Mbps connection? （2）1) 52.2 seconds2) 21.3 seconds3) 6.4 seconds4) 2 seconds5) 0.075 seconds6) 0.0375 seconds3. What are features of the TCP/IP Transport layer? (Choose two.) （3，5）1) path determination2) handles representation, encoding and dialog control3) uses TCP and UDP protocols4) packet switching5) reliability, flow control and error correction4. Which of the following is the Layer 4 PDU? （4）1) bit2) frame3) packet4) Segment5. What is important to remember about the data link layer of the OSI model whenconsidering Peer to Peer communication? (Choose three.) （3，4，5）1) It links data to the transport layer.2) It encapsulates frames into packets.3) It provides a service to the network layer.4) It encapsulates the network layer information into a frame.5) Its header contains a physical address which is required to complete the datalink functions.6) It encodes the data link frame into a pattern of 1s and 0s (bits) for transmissionon the medium.6. Which statement describes a star topology? （2）1) Each host in the network is connected to a backbone cable that is terminated atboth ends.2) Each host is connected to a hub or switch, either of which acts as a central pointfor all network connections.3) Each host is directly connected to two other hosts to form a long chain of hosts.4) Each host has a connection to all other hosts in the network.7. Which statements describe the logical token-passing topology? (Choose two.)（2）1) Network usage is on a first come, first serve basis.2) Computers are allowed to transmit data only when they possess a token.3) Data from a host is received by all other hosts. Electronic tokens are passedsequentially to each other.4) Token passing networks have problems with high collision rates.8. Which technologies are considered to be LAN technologies? (Choose two.) （2，5）1) DSL2) Token Ring3) Frame Relay4) ISDN5) Ethernet9.Refer to the exhibit. Host A wants to send a message to host B. Place the following stepsin the correct order so that the message can be sent. （4）A - add network layer addressesB - transmit bitsC - create application dataD - add data link layer addresses1) B, A, D, C2) D, A, C, B3) A, D, A, B4) C, A, D, B5) C, D, A, B6) C, B, A, D10.After an uns u ccessful ping to the local router, the technician decides to investigate therouter. The technician observes that the lights and fan on the router are not operational.In which layer of the OSI model is the problem most likely occurring? （4）1) transport2) network3) data link4) physical11. Refer t o the exhibit. What is the order of the TCP/IP Protocol Data Units as datais moved as indicated through the OSI model? （3）1) data, segments, frames, packets, bits2) data, packets, segments, frames, bits3) data, segments, packets, frames, bits4) data, packets, frames, segments, bits第三章1. Which combinations of charges will be repelled by electric force? (Choose two.)（4，6）1) neutral and neutral2) neutral and positive3) neutral and negative4) positive and positive5) positive and negative6) negative and negative2. Which of the following are considered the best media for use in data networkcommunications? (Choose three.) （2，3，6）1) glass2) fibers3) copper4) gold5) plastic6) silicon7) Silver3. Which of the following wireless standards increased transmission capabilitiesto 11 Mbps? （2）1) 802.11a2) 802.11b3) 802.11c4) 802.11d4. What is attenuation? （3）1) opposition to the flow of current2) measurement of electrical signals relative to time3) degradation of a signal as it travels along the medium4) amount or volume of traffic that is flowing on the medium5. Which cable specifications are indicated by 10BASE-T? （3）1) 10 Mbps transmission speed, baseband signal, 500 meter cable length, coaxialcable2) 10 Mbps transmission speed, broadband signal, 100 meter cable length, coaxialcable3) 10 Mbps transmission speed, baseband signal, 100 meter cable length,twisted-pair cable4) 10 Gbps transmission speed, broadband signal, 500 meter cable length,twisted-pair cable6. For which Ethernet installations would fiber optic rather than Cat5 UTP be abetter media choice? (Choose two.) （2，4）1) a 3 meter connection between two 10BASE-T hubs2) an environment with many potential sources of EMI and RFI3) a peer to peer connection between two NICs with RJ45 connectors4) an installation between two buildings that are located 500 meters apart5) a single building installation where installation costs are the major concern7. Refer to the exhibit. Which type of UTP cable should be used to connect Host Ato Switch1? （4）1) rollover2) console3) crossover4) straight-through8. Refer to the exhibit. Which type of Category 5 cable is used to make an Ethernetconnection between Host A and Host B? （3）1) coax cable2) rollover cable3) crossover cable4) straight-through cable第四章1. During cable testing, which of the following are used to calculate theinformation carrying capacity of a data cable? (Choose two.) （2，5）1) bit speed2) attenuation3) wire map4) saturation limit5) analog bandwidth2. What type of wiring problem is depicted in this sample of a cable tester? （3）1) a fault2) a short3) an open4) a split a good map3. In a new network installation, the network administrator has decided to use amedium that is not affected by electrical noise. Which cable type will best meet this standard? （5）1) coaxial2) screened twisted pair3) shielded twisted pair4) unshielded twisted pair5) fiber optic4. How does network cable length affect attenuation? （3）1) Category 5 cable that is run in metal conduit has the highest attenuation in theshortest distance.2) Shorter cable lengths have greater signal attenuation.3) Longer cable lengths have greater signal attenuation.4) The length of the cable has no effect on signal attenuation.第五章1. The highest capacity Ethernet technologies should be implemented in whichareas of a network? (Choose three.) （3，4，5）1) between workstation and backbone switch2) between individual workstations3) between backbone switches4) between enterprise server and switch5) on aggregate access links2. What device must be used between an AUI port of a networking device and themedia to which it is being connected? （3）1) a transducer2) a transmitter3) a transceiver4) a transponder5) a port replicator3. An ISDN Basic Rate Interface (BRI) is composed of how many signalingchannels? （1）1) 12) 23) 34) 44. Which layer of the OSI model covers physical media? （1）1) Layer 12) Layer 23) Layer 34) Layer 45) Layer 56) Layer 65. What type of network cable is used between a terminal and a console port? （3）1) cross-over2) straight-through3) rollover4) patch cable6. What is the recommended maximum number of workstations configured on apeer-to-peer network? （3）1) 252) 153) 104) 55) 27. Which of the following increases the potential for a collision to occur? （4）1) the use of an active hub instead of an intelligent hub2) the use of an intelligent hub instead of an active hub3) a reduction in the number of devices attached to the hub4) an increase in the number of devices attached to the hub8. What is the maximum length of a media segment used for 100BASE-TX? （1）1) 100 meters2) 185 meters3) 400 meters4) 500 meters9. Which cable diagram displays the end to end pinout for a crossover cable usedwith Cisco devices? （3）1) Cable A2) Cable B3) Cable C4) Cable D第六章1. What does the "10" in 10Base2 indicate about this version of Ethernet? （2）1) The version uses Base10 numbering within the frames.2) The version operates at a transmission rate of 10 Mbps.3) Frames can travel 10 meters unrepeated.4) The maximum frame length is 10 octets.2. How is a MAC address represented? （4）1) four groups of eight binary digits separated by a decimal point2) four Base10 digits separated by a decimal point3) six hexadecimal digits4) twelve hexadecimal digits5) twenty-four Base10 digits3. Which of the following statements are correct about CSMA/CD? (Choose three.)（1，3，6）1) It is a media access method used in LANs.2) It is a media access method used in FDDI WANs.3) When a device needs to transmit, it checks to see if the media is available.4) A device sends data without checking media availability because all deviceshave equal access.5) Multiple devices can successfully transmit simultaneously.6) Only one device can successfully transmit at a time.4. Which devices shown in the graphic must have a MAC address? （5）1) only PC2) only router3) PC and router4) PC, hub, and router5) PC, printer, and router第七章1. Which of the following items are common to all 100BASE technologies?(Choose three.) （1，4，5）1) frame format2) media3) connectors4) timing5) multi-part encoding2. Which of the following does 1000BASE-T use to accomplish gigabit speeds onCat 5e cable? （4）1) the use of four conductors in full-duplex mode2) the use of two multiplexed pairs of wires, simultaneously3) the use of three pairs of wires for data and the fourth for stabilization andforward error correction4) the use of all four pairs of wires in full-duplex mode, simultaneously3. For which of the following is Ethernet considered the standard? (Choose three.)（1，4，5）1) inter-building connection2) mid-length voice3) video conferencing4) vertical wiring5) horizontal wiring6) diagonal wiring4. To make sure timing limitations are not violated when implementing a 10 MbpsEthernet network involving hubs or repeaters, a technician should adhere to which rule? （4）1) the 4-5-3 rule2) the 6-4-2 rule3) the 3-4-5 rule4) the 5-4-3 rule5. What is the maximum distance that 10BASE-T will transmit data before signalattenuation affects the data delivery? （1）1) 100 meters2) 185 meters3) 300 meters4) 500 meters6. When using Category 5 UTP cable, which RJ-45 pin pairs are used to exchangedata between hosts on an Ethernet network? （2）1) 1 and 2; 4 and 52) 1 and 2; 3 and 63) 3 and 6; 7 and 84) 4 and 5; 7 and 8第八章1. John has been hired as the network administrator of a local company and hasdecided to add more hubs to the company's existing network. Which of the following has been caused by John's inexperience? （1）1) collision domain extended2) an increased number of collision domains3) increased network performance4) increased bandwidth5) extended bandwidth2. "CompA" is trying to locate a new computer named "CompB" on the network.Which of the following does "CompA" broadcast to find the MAC address of "CompB"? （2）1) MAC request2) ARP request3) ping4) Telnet5) proxy ARP3. Which of the following is a term associated with replacing hubs with switchesto increase the number of collision domains? （3）1) encapsulation2) latency3) segmentation4) layered model5) broadcast domain6) Extended4. The accumulation of traffic from which of the following can cause a networkcondition called broadcast radiation? (Choose three.) （3，5，6）1) anonymous FTP servers2) telnet sessions3) video over IP applications4) NAS services5) ARP requests6) RIP updates5. Which of the following describes the use of Spanning Tree Protocol (STP)? （4）1) resolve routing loops2) eliminate Split Horizon errors3) limit collisions4) resolve switching loops6. Which term describes the delay in time that occurs when a frame leaves itssource device and reaches its destination? （4）1) collision2) backoff3) attenuation4) latency5) broadcast7. Based on the graphic above, which of the following occurs as each host systemcomes on line in the topology? （2）1) The switch sends its MAC address to each host.2) The switch adds MAC address to the bridge table as each host sends a frame.3) Each host exchanges MAC addresses with each other.4) The switch listens for data traffic to block since the switch lacks an IP address. 8. Which devices segment collision domains? (Choose two.) （2，3）1) transceiver2) router3) switch4) hub5) media9. Which protocol is used to eliminate switching loops? （3）1) Transmission Control Protocol2) Routing Information Protocol3) Spanning Tree Protocol4) Interior Gateway Routing Protocol5) Internetworking Protocol10. Refer to the exhibit. A network associate needs to establish an Ethernetconnection between Host A and Host B. However, the distance between the two hosts is further than the cabling standards allow. Which two devices that operate at the physical layer of the OSI can be used to allow Host A and Host B to communicate? （2，5）1) switch2) hub3) bridge4) router5) repeater第九章1. Which term describes an ARP response by a router on behalf of a requestinghost? （3）1) ARP2) RARP3) Proxy ARP4) Proxy RARP2. Which protocol functions at the internet layer of the TCP/IP protocol suite? （4）1) File Transfer Protocol (FTP)2) Trivial File Transfer Protocol (TFTP)3) Transmission Control Protocol (TCP)4) Internet Protocol (IP)5) User Datagram Protocol (UDP)6) Simple Mail Transport Protocol (SMTP)3. Which of these workstation installation and setup tasks are concerned withnetwork access layer functions? (Choose two.) （2，4）1) configuring the e-mail client2) installing NIC drivers3) configuring IP network settings4) connecting the network cable5) using FTP to download application software updates4. Which part of an IP address identifies a specific device on a network? （4）1) first two octets2) third and fourth octets3) network portion4) host portion5) only the fourth octet5. Which of the following are features of the Internet Protocol (IP)? (Choose two.)（1，3）1) It is the most widely implemented global addressing scheme.2) It allows two hosts to share a single address on a local area network.3) It is a hierarchical addressing scheme allowing addresses to be grouped.4) It is only locally significant, used primarily on local area networks.6. Which of the following are useable Class A IP addresses with a default subnetmask? (Choose three.) （2，3，5）1) 127.0.39.12) 111.9.28.303) 123.1.2.1324) 128.50.38.25) 105.1.34.16) 0.23.92.37. Which application layer protocols use UDP at the transport layer? (Choose two.)（2，4）1) FTP2) SNMP3) Telnet4) DHCP5) SMTP第十章1. Which OSI layer encapsulates data into packets? （3）1) session2) transport3) network4) data link2. Which OSI layer defines the functions of a router? （3）1) physical2) data link3) network4) transport5) session3. Which of the following are Cisco proprietary routing protocols? (Choose two.)（2，6）1) RIPv22) IGRP3) OSPF4) BGP5) RIPv16) EIGRP4. A company with a Class B license needs to have a minimum of 1,000 subnetswith each subnet capable of accommodating 50 hosts. Which mask below is the appropriate one? （4）1) 255.255.0.02) 255.255.240.03) 255.255.255.04) 255.255.255.1925) 255.255.255.2245. A small company has a class C network license and needs to create five usablesubnets, each subnet capable of accommodating at least 20 hosts. Which of the following is the appropriate subnet mask? （3）1) 255.255.255.02) 255.255.255.1923) 255.255.255.2244) 255.255.255.2406. When a network administrator applies the subnet mask 255.255.255.248 to aClass A address, for any given subnet, how many IP addresses are available to be assigned to devices? （6）1) 10222) 5103) 2544) 1265) 306) 67. Host A is assigned the IP address 10.18.97.55 /21. How many more networkdevices can be assigned to this subnetwork if Host A is the only one that has an IP address assigned so far? （4）1) 2542) 5093) 10214) 20455) 40946) 81908.Refe r to the exhibit. The network administrator wants to create a subnet for thepoint-to-point connection between the two routers. Which subnetwork mask would provide enough addresses for the point-to-point link with the least number of wasted addresses?1) 255.255.255.1922) 255.255.255.2243) 255.255.255.2404) 255.255.255.2485) 255.255.255.2529. What is the correct number of usable subnetworks and hosts for the IP networkaddress 192.168.35.0 subnetted with a /28 mask?1) 6 networks / 64 hosts2) 14 networks / 32 hosts3) 14 networks / 14 hosts4) 30 networks / 64 hosts10. Which subnet masks would be valid for a subnetted Class B address? (Choosetwo.) （5，6）1) 255.0.0.02) 255.254.0.03) 255.224.0.04) 255.255.0.05) 255.255.252.06) 255.255.255.19211. Refer to the exhibit. How will the Fohi router dynamically learn routes to the192.168.16.16/28, 192.168.16.32/28, and 192.168.16.48/28 subnetworks? （3）1) with a static route2) with a routed protocol3) with a routing protocol4) with a directly connected route12. How many broadcast domains are shown in the diagram? （1）1) three2) four3) five4) six5) seven6) eight13. How many collision domains are shown in the diagram? （5）1) three2) four3) five4) six5) seven6) eight14. A router interface has been assigned an IP address of 172.16.192.166 with amask of 255.255.255.248. To which subnet does the IP address belong?1) 172.16.0.02) 172.16.192.03) 172.16.192.1284) 172.16.192.1605) 172.16.192.1686) 172.16.192.17615. Refer to the exhibit. Host A is sending data to Host B. Once R2 determines thatdata from Host A must be forwarded to R1 to reach Host B, which layer of the OSI model will R2 use to address and build the frames destined for R1?1) physical2) data link3) network4) transport5) session6) presentation16. Which type of address is 192.168.170.112/28?1) host address2) subnetwork address3) broadcast address4) multicast address17. Which type of address is 223.168.17.167/29?1) host address2) multicast address3) broadcast address4) subnetwork address18. Which combination of network id and subnet mask correctly identifies all IPaddresses from 172.16.128.0 through 172.16.159.255?1) 172.16.128.0 255.255.255.2242) 172.16.128.0 255.255.0.03) 172.16.128.0 255.255.192.04) 172.16.128.0 255.255.224.05) 172.16.128.0 255.255.255.19219. Refer to the exhibit. The internetwork in the exhibit has been assigned the IPaddress 172.20.0.0. What would be the appropriate subnet mask to maximize the number of networks available for future growth?1) 255.255.224.02) 255.255.240.03) 255.255.248.04) 255.255.252.05) 255.255.254.06) 255.255.255.0第十一章1. If a network administrator needed to download files from a remote server, whichprotocols could the administrator use to remotely access those files? (Choose two.) （3，5）1) NFS2) ASCII3) TFTP4) IMAP5) FTP6) UDP2. What is established during a connection-oriented file transfer betweencomputers? (Choose two.) （2，5）1) a temporary connection to establish authentication of hosts2) a connection used for ASCII or binary mode data transfer3) a connection used to provide the tunnel through which file headers aretransported4) a command connection which allows the transfer of multiple commands directlyto the remote server system5) a control connection between the client and server3. Which of the following protocols are used for e-mail transfer between clientsand servers? (Choose three.) （3，4，5）1) TFTP2) SNMP3) POP34) SMTP5) IMAP46) postoffice4. Which type of institution does the domain suffix .org represent? （4）1) government2) education3) network4) non-profit5. Which of the following services is used to translate a web address into an IPaddress? （1）1) DNS2) WINS3) DHCP4) Telnet6. Which part of the URL http://www.awsb.ca/teacher gives the name of thedomain? （4）1) www2) http://3) /teacher4) awsb.ca7. Which protocols are TCP/IP application layer protocols? (Choose two.) （2，4）1) UDP2) FTP3) IP4) SMTP5) TCP8. What are three characteristics of the TCP protocol? (Choose three.) （3，4，6）1) has less overhead than UDP2) is used for IP error messages3) forces the retransmission undelivered packets4) creates a virtual session between end-user applications5) carries the IP address of destination host in the TCP header6) is responsible for breaking messages into segments and reassembling9. Two peer hosts are exchanging data using TFTP. During the current session, adatagram fails to arrive at the destination. Which statement is true regarding the retransmission of the datagram? （2）1) Datagram retransmission requires user authentication.2) Datagram retransmission is controlled by the application.3) Datagram retransmission relies on the acknowledgements at transport layer.4) Datagram retransmission occurs when the retransmission timer expires in thesource host.案例学习1. 子网计算练习：Answer2. 子网号及广播地址计算练习Answer3. 子网规划练习：已知：给定一个C类地址201.16.5.0/24。
