紧固件的新德标、欧盟标准、国际标准、旧德标、国标、美标、日标对照表
新德标、欧盟标准、国际标准与旧德标对照表（节选）DIN EN
Standards classified by subject
DIN EN Standard
Title
Withdrawn
DIN ISO Standard DIN Standard Hexagon head bolts and
screws，hexagon nuts
DIN EN 1661 Hexagon nuts with flange (ISO/DIS
4161:1996,modified)
DIN
6923
DIN EN 1662 Hexagon bolts with flange - Small
series (ISO/DIS 15071:1996,modified)
DIN EN 1665 Hexagon bolts with flange - Heavy
series
DIN 6921
DIN 6922
DIN EN 24014 Hexagon head bolts-Product grade A
and B(ISO 4014:1988)
DIN ISO 4014 DIN 931-1
DIN EN 24015
Hexagon head bolts-Product grade B-Reduced shank(shank
diameter≈pitch diameter)
(ISO 4015:1979)
DIN EN 24016 Hexagon head bolts-Product grade
C(ISO 4016:1988)
DIN ISO 4016 DIN 601 DIN EN 24017
Hexagon head screws-Product
grades A and B(ISO 4017:1988)
DIN ISO 4017 DIN 933
DIN EN 24018 Hexagon head screws-Product grade
C(ISO 4018:1988)
DIN ISO 4018 DIN 558
DIN EN 24032
Hexagon nuts，style 1-Product
grades A and B(ISO 4032:1986) DIN ISO 4032 DIN 934
DIN EN 24033 Hexagon nuts,style 2-Product grades
A and B(ISO 4033:1979)
DIN EN 24034 Hexagon nuts-Product grade C
(ISO 4034:1986)
DIN ISO 4034 DIN 555
DIN EN 24035 Hexagon thin nuts(chamfered)-
Product grades A and B (ISO
4035:1986)
DIN ISO 4035 DIN 439-2
DIN EN 24036
Hexagon thin nuts-Product grade
B(unchamfered)(ISO 4036:1979) DIN ISO 4036
DIN 439-1
DIN EN 28673 Hexagon nuts,style 1,with metric fine
pitch thread-Product grades A and
B(ISO 8673:1988)
DIN ISO 8673
DIN 934
DIN 971-1
DIN EN 28674 Hexagon nuts,style 2,with metric fine pitch thread-Product grades A and
B(ISO 8674:1988)
DIN ISO 8674 DIN 971-2
DIN EN 28675
Hexagon thin nuts with metric fine
tch thread-Product grade A and B(ISO
8675:1988)
DIN ISO 8675 DIN 439-2
DIN EN 28676 Hexagon head screws with metric fine
pitch thread-Product grades A and
B(ISO 8676:1988)
DIN ISO 8676 DIN 961
DIN EN 28765
Hexagon head bolts with metric
fine pitch thread-Product grades A
and B(ISO 8765:1988)
DIN ISO 8765 DIN 960 Prevailing torque type hexagon nuts
DIN EN 1663
Prevailing torque type hexagon nuts
with flange(with non-metallic insert)
(ISO 7043:1997,modified)
DIN
6926
DIN EN 1664
Prevailing torque type all-metal
hexagon nuts with flange (ISO
7044:1997, modified)
DIN
6927
DIN EN 1666 Prevailing torque type hexagon nuts with flange (with non-metallic insert) with metric fine pitch
thread
(ISO 12125:1997, modified) DIN
6926
DIN EN 1667
Prevailing torque type
all-metal hexagon nuts with flange
with metric fine pitch thread
(ISO 12126:1997, modified)
DIN
6927
DIN EN ISO
7040
Prevailing torque type hexagon
nuts (with non-metallic insert), style
1-Property classes 5, 8 and 10 (ISO
7040:1997)
DIN 982
DIN 6924
DIN EN ISO
7042 Prevailing torque type all-metal
exagon nuts, style 2- Property classes 5, 8, 10 and 12 (ISO
7042:1997)
DIN 980 DIN 6925
DIN EN ISO
7719
Prevailing torque type all-metal hexagon nuts, style 1-Property classes 5, 8, and10 (ISO 7719:1997)
DIN EN ISO 10511 Prevailing torque type hexagon thin
nuts (with non-metallic insert) (ISO 10511:1997 )
DIN
985
DIN EN ISO 10512 Prevailing torque type hexagon
nuts (with non-metallic insert),style 1,
with metric fine pitch
thread-Property classes 6, 8 and 10
(ISO 10512:1997)
DIN 982
DIN 6924
DIN EN ISO 10513 Prevailing torque type all-metal
hexagon nuts, style 2,with metric fine pitch thread - Property
classes 8, 10 and 12 (ISO 10513:1997)
DIN 980 DIN 6925
Small screws with metric thread
DIN EN ISO
1207 Slotted cheese head screws-Product
grade A（ISO 1207：1992） DIN
84
DIN EIN ISO
1580 Slotted pan head screws-Product
grade A(ISO 1580:1994) DIN ISO 1580 DIN 85
DIN EN ISO
2009
Slotted countersunk flat head
screws(common head style)-Product
grade A(ISO 2009:1994)
DIN ISO 2009 DIN 963
DIN EN ISO
2010 Countersunk slotted raised head
crews (common head style) - Product
grade A (ISO 2010:1994)
DIN ISO 2010 DIN 964
DIN EN ISO
7045
Pan head screws with type H
or type Z cross recess-Product grade
A (ISO 7045:1994)
DIN ISO 7045 DIN 7985
DIN EN ISO 7046-1
Countersunk flat head screws
(common head style) with type H
or type Z cross recess, product grade
A - Part 1:Steel of property class
4.8(ISO 7046-1:1994)
DIN ISO 7046 DIN 965
DIN EN ISO 7046-2
Cross recessed countersunk flat head screws (common head
style),( grade A) - Part 2:Steel of
property class 8.8,stainless steel and nonferrous metals (ISO
7046-2:1990) DIN
965
DIN EN ISO
7047
Countersunk raised head screws
(common head style) with type H
or type Z cross recess - Product
grade A (ISO 7047:1994)
DIN ISO 7047 DIN 966
