外置闪光灯⽩玩了，原来E-TTL模式还可以这样玩如何玩转E-TTL，其实不能算是闪光灯的基础知识，应该算是⼊门对闪光灯的使⽤多少有所了解以后的知识了。
所谓的E-TTL，也就是闪光灯通过镜头测光由相机决定闪光灯的输出量。
那么，这个输出量是多少呢？你不知道，我也不知道，只有⼀个最后的曝光结果给我们看。
曝光不⾜或者曝光过量的原因是什么，我们都不知道，因为闪光灯没有给我们⼀个确切的输出值。
这⼀点也就是为什么建议初学闪光灯的使⽤者，⼀定要从⼿动曝光开始，⼿动控制闪光灯的输出值，1/1、1/2、1/4、1/8、1/16、1/32、1/64、1/128，⼀共7档的输出量供您选择，每档之间还可以调整1/3的步长。
曝光不⾜了，您可以提⾼闪光灯的输出值⼀档，曝光过了，您可以减⼀档。
总之，您可以慢慢的调整，直到找到合适的输出值为⾄。
但是，凡事都有⼀个但是。
⼿动曝光这么好，⼚家为什么花费巨资研究出E-TTL来呢？原因就在于，很多时候，不允许您慢条斯理的寻找您的合适的输出功率。
⽽且，很多时候，被摄主体在不断的移动之中，场景在不断的转换之中，⼿动控制闪光灯？除⾮您是疯⼦或者您就是传说中的“灯神”！E-TTL就是要的⾃动要的快速要的准确，我们⼀定要相信⼚家的能⼒，这个玩意绝对不是⽩给的！这也是为什么原⼚灯价格这么贵的原因，贵总是有理由的！那么，是不是把闪光灯插在相机热靴上打开，就⼀切OK了呢？很不幸，事实总是⾮常残酷的，您还需要了解⼀些东西，掌握⼀些东西，才能⼀切OK。
现在，让⽼格给你揭开E-TTL的神秘⾯纱，给您揭⽰⼀些⼚家说明书中没有的东西。
⽼格尽量⽤通俗易懂的语⾔结合图⽚来说明，如果您说还是没有看懂，请您拿起您的相机，把您的闪光灯插上，实验⼀下。
演⽰相机：佳能5D2 演⽰闪光灯：佳能580 2代使⽤镜头：蔡司50/1.4 ZE 闪光灯裸灯演⽰图⽚快门速度1/200秒，感光度100，排除现场环境光的影响，只测量闪光灯的数据。
