CA2201固定翼无人机技术使用说明书(版本：V1.00)航天科工深圳（集团）有限公司Aerospace Science & Industry Shenzhen (Group) Co.,Ltd目录1 机体布局 (1)2 结构安装说明 (2)2.1机体各部分安装 (2)2.1.1 机翼对接安装（见图2-1） (2)2.1.2 尾翼对接安装（见图3-1） (2)2.1.3 整机对接安装（见图4-1） (3)2.2机体的使用与维护 (4)2.2.1 使用要求 (4)2.2.2 维护要求 (5)3 发动机的使用说明 (6)3.1启动前准备 (6)3.2发动机启动 (6)3.3发动机的关闭 (6)3.4发动机的维护 (6)4 稳压电源使用说明 (8)4.1通电前的准备工作 (8)4.2充电器使用说明 (8)4.3稳压电源维护说明 (8)4.4主电源维护说明 (8)4.5充电器维护说明 (8)5 机载相机使用说明 (9)5.1相机参数 (9)5.2航拍设置 (9)5.2.1航线设置 (9)5.2.2对焦设置 (9)6 全系统飞行使用说明 (10)6.1飞行现场工作流程图 (10)6.2工作流程 (10)6.2.1 进入飞行场地前的准备工作 (10)6.2.2 外场飞行 (11)6.3无人机飞行四不飞 (14)1 机体布局图1-1 机体布局2 结构安装说明CA2201的机体采用快装快卸对接方式进行安装。
机体四大组件分别进行对接安装后，再进行整机的对接安装。
2.1 机体各部分安装2.1.1 机翼对接安装（见图2-1）将连接杆插入到左右两侧机翼的圆形插孔中，保证左右两侧机翼的根弦面贴合。
图2-1 机翼对接安装2.1.2 尾翼对接安装（见图3-1）将尾杆插入机翼两侧，使用配套的螺纹紧固件（包括：M3×16内六角圆柱头螺钉2个，φ3平垫圈2个）锁紧。
图3-1 尾翼对接安装2.1.3 整机对接安装（见图4-1）（1）、将机翼放到机身安装位置，使用配套的螺纹紧固件锁紧（包括：M5×40内六角圆柱头螺钉2个）。
