3000C产品配置指导手册版权所有©杭州海康威视数字技术股份有限公司2019。
保留一切权利。
本手册的任何部分，包括文字、图片、图形等均归属于杭州海康威视数字技术股份有限公司或其子公司（以下简称“本公司”或“海康威视”）。
未经书面许可，任何单位和个人不得以任何方式摘录、复制、翻译、修改本手册的全部或部分。
除非另有约定，本公司不对本手册提供任何明示或默示的声明或保证。
关于本手册本手册描述的产品仅供中国大陆地区销售和使用。
本手册作为指导使用。
手册中所提供照片、图形、图表和插图等，仅用于解释和说明目的，与具体产品可能存在差异，请以实物为准。
因产品版本升级或其他需要，本公司可能对本手册进行更新，如您需要最新版手册，请您登录公司官网查阅（）。
海康威视建议您在专业人员的指导下使用本手册。
商标声明为海康威视的注册商标。
本手册涉及的其他商标由其所有人各自拥有。
责任声明●在法律允许的最大范围内，本手册所描述的产品（含其硬件、软件、固件等）均“按照现状”提供，可能存在瑕疵、错误或故障，本公司不提供任何形式的明示或默示保证，包括但不限于适销性、质量满意度、适合特定目的、不侵犯第三方权利等保证；亦不对使用本手册或使用本公司产品导致的任何特殊、附带、偶然或间接的损害进行赔偿，包括但不限于商业利润损失、数据或文档丢失产生的损失。
●若您将产品接入互联网需自担风险，包括但不限于产品可能遭受网络攻击、黑客攻击、病毒感染等，本公司不对因此造成的产品工作异常、信息泄露等问题承担责任，但本公司将及时为您提供产品相关技术支持。
●使用本产品时，请您严格遵循适用的法律。
若本产品被用于侵犯第三方权利或其他不当用途，本公司概不承担任何责任。
●如本手册内容与适用的法律相冲突，则以法律规定为准。
前言本节内容的目的是确保用户通过本手册能够正确使用产品，以避免操作中的危险或财产损失。
在使用此产品之前，请认真阅读产品手册并妥善保存以备日后参考。
符号约定对于文档中出现的符号，说明如下所示。
网络硬盘录像机海康威视的网络硬盘录像机是结合IT领域多项最新技术（如视音频压缩/解压缩、大容量硬盘记录/检索、TCP/IP网络等技术），专为安全技术防范领域设计的数字监控产品。
它同时具备数字视音频录像机（DVR）和数字视音频服务器（DVS）的特性，既可本地独立工作，也可联网组成一个强大的安全监控网，广泛用于银行、电力、公安、司法、交通、电信、小区、工矿、企业、水利设施等各领域、各部门的安全防范。
DS-8000系列命名规则主要性能与功能压缩处理●压缩代码具有自主知识产权，压缩比高，清晰度好，编码性能稳定可靠；●独立硬件压缩，DSP功耗低，更适合长时间稳定运行；●每路视频参数独立可调；●可动态调整编码参数；●支持定码率、变码率、变帧率；●帧结构可选；●可设定视频图像质量，也可设定视频图像的压缩码流，以获得满意的回放的图像质量和码流大小；●视频和音频信号压缩后生成复合码流，也可生成单一H.264视频流；●复合码流回放时视频和音频保持同步；●支持双码流技术；●支持JPEG标准的D1或CIF格式图片压缩、存储、网络传输；●支持水印（WaterMark）技术，防止图像被修改，保证录像资料真实有效。
本地录像●一台设备最多可支持八个硬盘的连接，每个硬盘的容量可达2000GB；●录像模式：定时录像、手动录像、移动侦测录像、报警录像、命令触发录像、移动侦测录像&报警录像、移动侦测录像| 报警录像；●文件切换时不丢帧；●硬盘文件系统为FAT32，与Windows文件系统一致；●硬盘上文件可以选择循环记录和非循环记录；●文件记录无碎片，系统可长时间保持稳定运行；●硬盘内录像资料不可被删除；●本地硬盘SMART支持；●非工作硬盘休眠机制；●通过USB设备、IDE CDRW、SATA设备进行文件备份或本地码流剪辑；●可外接盘库等第三方存储设备。
本地监控●音视频实时预览、画面分割、手动切换与自动轮巡；●OSD叠加，时间、位置及格式可调，通道名叠加，叠加位置可调；●本地监视器通道录像状态、报警状态显示；●多区域遮盖处理，遮盖区域的大小及位置可设置；●镜头遮挡报警处理，遮挡报警区域的大小、位置可调，灵敏度可选；●多级别、多区域的移动侦测处理；●视频丢失报警；●非法访问、IP冲突、网线断等异常事件报警；●报警输入/输出的布防与撤防、报警联动；●本地监视器上的多路回放，支持快放、慢放、暂停、单帧等回放模式，按时间回放时定位准确；●PTZ控制，支持众多解码器类型，支持预置点、巡航、轨迹的设置与调用；●多种操作方式：前面板按键操作、遥控器操作、RS-485键盘操作（设备级联）、网络键盘操作；●本地日志（支持操作、报警、异常类型）记录、查询及上传；●用户权限定制。
