吉他综合效果器使用常识——GT-8初学者调整设置2006-01-10 tedboy（转）吉他中国论坛点击: 22253吉他综合效果器使用常识——GT-8初学者调整设置GT-8初学者调整设置GT-8终于到手了，怎样才能得到好的音色呢？你可能会花上一两个小时玩遍所有预制音色，却很难找到几个还算满意的，绝大多数音色要么不喜欢，要么根本用不着。
你会觉得困惑，听上去不值得你花的银子，只有那么一点让你满意的，亏大了！因此，你开始自己动手调整音色，可是更糟糕了，简直不忍耳睹，或者只好了那么一点点。
于是你再次开始怀疑银子白花了。
希望这篇文章可以帮你打消疑虑，并且用一种快乐的、内行的方式进行调节，得到你需要的音色。
第一步，基础调节设定电平。
这是最重要的一步。
耐心点，花点时间以免返工。
无须多言，有几点必须牢记。
输入电平的调整。
关掉所有效果，打开电平表 [SYSTEM] [PARAMETER]—METER：INPUT，调整PATCH LEVEL在100（我的建议），然后用力弹琴在METER上得到峰值LEVEL。
接下来，[SYSTEM] [PARAMETER]—METER：OUTPUT，确定二者匹配。
我的值是-3。
这样说可能会有点误导，实际上INPUT LEVEL的调整不会影响INPUT METER。
INPUT METER得到的是吉他的直接输入信号（未经过任何处理），但是可以注意到OUTPUT METER是随着INPUT METER的调整而变化的。
INPUT LEVEL的调整是在效果之前吉他输入之后，而我们的目的是保证INPUT LEVEL和OUTPUT LEVEL之间不产生衰减（保持相同的LEVEL）。
如果你的吉他输入信号的确很弱的话，你可能希望通过提升INPUT LEVEL的电平调整来得到好的、强的信号，这是最重要的设置步骤。
预制INPUT LEVEL设定值为0db。
另外，必须注意的是INPUT LEVEL的调整会影响整体的电平，所以如果你调整了INPUT LEVEL的话，随时应该检查OUTPUT LEVEL，以确保没有衰减信号。
1、打开电源和使用在装好电池和使用交流电的时候打开开关！（位于电源接口旁边）主屏幕当前显示当前所用的效果，包括效果图像和虚拟旋钮，可以通过每一块显示屏下面对应的旋钮来控制。
编辑效果参数，屏幕显示参数名称，页选项卡，参数值，如果有可调节的参数多于3个将会有多个选项卡！可以通过对应的旋钮来更改参数！2、调整效果确认主屏幕所显示效果，使用踩钉可以打开或关闭效果，当打开效果时踩钉旁边的红灯会亮，否则会灭。
选择效果类型按上下选择键可以更换所选的效果，调整会自动保存，效果列表请参阅33页！若要调整参数，转动对应旋钮改变页面，按PAGE 键，下一个页面会打开！3、选择补丁（patch ）在这里补丁就是预设出厂音色确认首页显示内容要激活补丁选择，按下左起第一个踩钉一秒钟以激活补丁，屏幕将显示补丁库的编号和名称；若要更改补丁按左起第二个踩钉选择前一个补丁，按第三个踩钉选择下一个补丁，旋转中间效果的对应旋钮就能改变补丁编号和名称；如果要更改库同时按下一号踩钉和二号踩钉选择前一个库，同时按下三号四号踩钉选择下一个库，旋转中间效果的对应旋钮可以改变库的编号和名称。
同时按下两个踩钉时可能会感应较早按下的踩钉，要注意避免这种情况。
返回主页按下一号踩钉一秒！4、存储补丁G3自动保存设置时调整的参数要存储或换用不同的补丁，按STORE ／SWAP 键，屏幕显示如下，图见说明书P12第一个图。
通过转动左边效果的最左边旋钮来选择是否存储或交换补丁。
要设置存储或交换新的补丁的位置转动右边效果的二号旋钮给更改的补丁或存储的更换编号。
转动左边效果最左边旋钮更改该库的存储或更换（当前使用的补丁不能作为选择目标）要存储／换用完整补丁按STORE ／SWAP 键，屏幕显示”COMPLETE”后，打开STORE ／SWAP 交换补丁（如果要退出，按除了STORE ／SWAP 以外的任意键。
5、设置特定的补丁参数按TOTAL 键激活总菜单，转动左边效果的第一个旋钮来调整补丁级别，范围0~120。
