Document Number: 40054 Revision 20-Oct-03
For technical questions, contact eurowettant@
63
元器件交易网
738D, CT9 (CECC 30202-004)
Vishay TansiБайду номын сангаасor
Wet Tantalum Capacitors with Glass to Tantalum Hermetic Seal, Sintered Anode TANTALEX® Capacitors
This is expressed in volts. See Ratings and Case To complete the three-digit block, zeros precede the Codes Table. voltage rating. A decimal point is indicated by an "R" (6R3 = 6.3 volts).
CAPACITANCE (µF) 68 270 560 1000 1200
CASE CODE
PART NUMBER*
6.3 VDC at + 85°C, 4 VDC at + 125°C, 3 VDC at + 175°C A B C D D 738D686X06R3A2 738D277X06R3B2 738D567X06R3C2 738D108X06R3D2 738D128X06R3D2 17.1 67.8 151.9 100.5 120.6 10 10 10 10 10 1.0 1.0 1.0 1.0 1.0 1 1 2 3 3 2 7 13 14 14 -40 -44 -64 -80 -80 +10.5 +17.5 +17.5 +25 +25 +17.5 +20 +20 +25 +25
62
For technical questions, contact eurowettant@
Document Number: 40054 Revision 20-Oct-03
元器件交易网
738D, CT9 (CECC 30202-004)
0 = Bare case. 2 = Outer plastic film insulation. 6 = High temperature film insulation (above + 125°C).
Packaging: The use of formed plastic trays for packaging these axial lead components is standard. Tape and reel is not recommended due to the unit weight.
WITH OUTER PLASTIC - FILM INSULATION D (Max.) 0.219 [5.56] 0.312 [7.92] 0.406 [10.31] 0.406 [10.31] L (Max.) 0.515 [13.08] 0.704 [17.88] 0.828 [21.03] 1.126 [28.60] LEAD LENGTH 1.500 ± 0.250 [38.10 ± 6.35] 2.250 ± 0.250 [57.15 ± 6.35] 2.250 ± 0.250 [57.15 ± 6.35] 2.250 ± 0.250 [57.15 ± 6.35] Max. WEIGHT (Ounces/Grams) 0.07 [2.0] 0.18 [5.1] 0.36 [10.2] 0.49 [13.9]
10 VDC at + 85°C, 6.3 VDC at + 125°C, 5 VDC at + 175°C 39 47 150 180 330 390 680 A A B B C C D 738D396X0010A2 738D476X0010A2 738D157X0010B2 738D187X0010B2 738D337X0010C2 738D397X0010C2 738D687X0010D2 15.1 15.1 28.2 45.2 51.9 73.5 42.7 10 10 10 10 10 10 10 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1 1 1 1 2 2 4 2 2 6 7 16 16 16 -36 -36 -36 -36 -60 -64 -80 +12 +14 +14 +14 +17.5 +17.5 +25 +16 +16 +16 +16 +20 +20 +25
APPROVALS
• CECC 30202-004 CT9 style
ORDERING INFORMATION
CT9 738D MODEL
226 CAPACITANCE
X0 CAPACITANCE TOLERANCE X0 = ± 20% X9 = ± 10% X5 = ± 5% Special Order.
8 VDC at + 85°C, 5 VDC at + 125°C, 4 VDC at + 175°C 56 220 470 820 A B C D 738D566X0008A2 738D227X0008B2 738D477X0008C2 738D827X0008D2 14.1 55.2 82.6 51.5 10 10 10 10 1.0 1.0 1.0 1.0 1 1 2 4 2 7 14 16 -40 -44 -64 -80 +10.5 +17.5 +17.5 +25 +16 +20 +20 +25
Wet Tantalum Capacitors with Glass to Tantalum Hermetic Seal, Sintered Anode TANTALEX® Capacitors
DIMENSIONS in inches [millimeters]
L D
Vishay Tansitor
0.180 [4.57] Max.
100 DC VOLTAGE RATING AT + 85°C
B CASE CODE
2 STYLE NUMBER
This is expressed in picofarads. The first two digits are the significant figures. The third is the number of zeros to follow.
16 VDC at + 85°C, 10 VDC at + 125°C, 8 VDC at + 175°C 27 33 120 220 270 470 560 A A B C C D D 738D276X0016A2 738D336X0016A2 738D127X0016B2 738D227X0016C2 738D277X0016C2 738D477X0016D2 738D567X0016D2 10.3 10.3 30.2 34.5 50.8 35.4 42.2 10 10 10 10 10 10 10 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1 1 1 2 2 6 6 2 2 7 16 16 24 24 -28 -28 -28 -50 -56 -80 -80 +10.5 +14 +17.5 +17.5 +17.5 +25 +25 +16 +16 +20 +18 +20 +25 +25
738D STANDARD RATINGS
Max. DF at + 20°C (%) Max. IMP. at - 55°C 100 KHz (Ohms) Max. IMP. at + 20°C 100 KHz (Ohms) Max. DCL (µA) at + 20°C + 85°C + 125°C Max. CAPACITANCE CHANGE (%) at - 55°C + 85°C + 125°C
FEATURES
• Hermetic glass to tantalum seal • High CV per unit volume • Extremely low leakage current • Wide temperature range: - 55 to + 175°C • Improved reliability through the use of a glass-to- tantalum true hermetic anode seal is the prime feature of the 738D and CT9 sintered anode TANTALEX® capacitor. This construction eliminates all internal lead welds while retaining the strength of internal lead-welded parts. • The construction offers outstanding resistance to thermal shock.
PERFORMANCE CHARACTERISTICS
Operating Temperature: - 55°C to + 85°C and with voltage derating to two-thirds the + 85°C rating at + 125°C. Capable of + 175°C operation at reduced voltage. Use of Type 135D capacitors for high temperature applications is recommended. Capacitance Tolerance: At 120 Hz, + 25°C. ± 20% standard. ± 10%, ± 5% available as special. DC Leakage Current (DCL Max.): At + 25°C, + 85°C and + 125°C: Leakage current shall not exceed the values listed in the Standard Ratings Tables. Life Test: Capacitors are capable of withstanding a 2000 hour life test at a temperature of + 85°C or + 125°C at the applicable rated DC working voltage.
