rc951配置指导200511v1.02

面板LED 燈號 PCB 接點及Jumper跳線LED 燈號 顯示說明Jumper 跳線說明出廠設定 PWR 正常情況持續閃爍表CPU 有在正常運作 JP5 DI 外部或控制器內部供電切換 控制器內部供電 COM 未接卡機約每秒閃爍一次，接卡機閃爍速度變快JP6 設定繼電器(RELAY)是否由控制器供電控制器不供電 10M 當網路(LAN)通訊速率為10Mbps 時會亮燈 閉路(Close)表示由控制器供12VDC 電源100M 當網路(LAN)通訊速率為100Mbps 時會亮燈 JP7~JP12 繼電器(RELAY) NC 或NO 切換Normal Open DI1~DI8 當燈亮時表示該輸入接點導通JP15 韌體AP 是否啟用，開路(Open)表示啟用 韌體AP 啟用 RY1~RY6當燈亮時表示其對應之輸出接點繼電器作動後側板接點 接線說明接點及按鈕 接線說明C+ DI 外部電源輸入 (注意事項8) RESET 長按10秒控制器重置回出廠設定 DI1~DI4 出門按鈕接點對應1~4門點 預設IP 位址：10.0.50.100 DI5~DI8 火災發報接點對應1~4門點 COM RS485(2線/4線)串接讀卡機使用 G控制器共地接點 (注意事項8) LAN RJ45網路接線RY1+~RY4+ 外部電源輸入接點對應1~4門的電鎖使用DC JACK 控制器電源輸入(12VDC) RY1-~RY4-電源輸出至1~4門的電鎖使用PWR控制器電源輸入(12VDC)注意事項1. 控制器請使用12VDC 供電，允許的輸入電壓為9VDC~13VDC；控制器輸入電源，DC JACK 與端子接點(PWR)兩者擇一2. 控制器若斷電超過24小時，系統時鐘需重新設定3. 控制器韌體版本必須與讀卡機相符方可正常使用；版本ATOP 4Door ATT 是Atop 讀卡機使用，ATOP 4Door SOYAL 是Soyal 讀卡機使用4. 讀卡機RS-485 ID1~ID4為進入卡機，ID5~ID8為出門卡機5. 讀卡機的通訊線路建議使用22AWG 具Shielding 防護之雙絞線材；以一進一出方式串接卡機6. 電鎖的電源與控制器的電源分開供電，避免電鎖作動瞬間影響控制器7. 訊號傳輸線與電源線建議分開配管，避免訊號干擾8.當JP5切換使用"C+"外部電源時，勿使用"G"接點作為共地接點，應使用DI 外部電源之地電壓當迴路地控制器與HID卡機、AR1200韋根轉換器、電鎖建議接線圖控制器與卡機、電鎖建議接線圖電鎖由卡機控制接線圖控制器進出管制接線圖注意事項1. 電鎖及出門按鈕由控制器直接控制，安全性較高2. 若為節省佈線，可將電鎖及出門按鈕由轉換器控制3. 電鎖繼電器的NC/NO依電鎖型式決定，一般的陽極鎖或磁力鎖為NC4. 電鎖的電源建議獨立供電5. 電鎖建議外加一個反向二級體(1N4001)保護電路注意事項1. 進讀卡機的RS-485 ID為1~4，出讀卡機的RS-485 ID為5~82. 電鎖及出門按鈕由控制器直接控制，安全性較高3. 若為節省佈線，可將電鎖及出門按鈕由進讀卡機控制4. 電鎖繼電器的NC/NO依電鎖型式決定，一般的陽極鎖或磁力鎖為NC5. NC/NO使用控制器PCB之JUMPER JP7~JP10跳線6. 電鎖的電源建議獨立供電7. 電鎖建議外加一個反向二級體(1N4001)保護電路RS485 D+RS485 D-出門按鈕V+DI1DI COMVIN+NC1COM1To Vout+To Vout-控制器Wiegand注意事項1. 電鎖及出門按鈕由卡機控制，可節省佈線，但安全性較低2. 電鎖繼電器的NC/NO依電鎖型式決定，一般的陽極鎖或磁力鎖為NC3. 電鎖的電源建議獨立供電4. 電鎖建議外加一個反向二級體(1N4001)保護電路注意事項1. 電鎖及出門按鈕由控制器直接控制，安全性較高2. 電鎖繼電器的NC/NO依電鎖型式決定，一般的陽極鎖或磁力鎖為NC3. NC/NO使用控制器PCB之JUMPER JP7~JP10跳線4. 電鎖的電源建議獨立供電5. 電鎖建議外加一個反向二級體(1N4001)保護電路磁簧DI_GDIPCB跳線控制器出門按鈕警報器V+外部電源V-Pin6PCB跳線參見注意事項Pin7Pin8Pin1Pin2GND控制器電源供應器(For 控制器&卡機)出門按鈕V-RS485 D+DI_GDIGND V+(12V)電源供應器(For 電鎖)GNDID=1控制器警報器磁簧外部電源V+V+Pin5Pin6Pin9Pin7。

Protect IT保护继电器REX 521操作手册ABB的Industrial IT产品是用于提高生产率的标准件，并具备所有必要的工具，可在产品的寿命周期内以电子形式提供支持。

目录1.安全信息 (5)2.引言 (6)2.1.REX 521保护继电器 (6)3.说明 (7)3.1.HMI的特点 (7)3.1.1.按钮功能 (9)3.1.2.选择语言 (11)3.1.3.密码 (12)3.1.4.显示背光 (12)3.1.5.显示器对比度 (12)3.1.6.显示器测试 (13)3.1.7.选择一次侧值 (13)3.1.8.带光隔离的串行通讯端口 (13)3.2.菜单图 (14)3.2.1.测量菜单 (15)3.2.2.事件菜单 (16)3.2.3.手动控制 (17)3.2.3.1.本地/远方位置选择 (17)3.2.3.2.控制断路器 (17)3.2.4.整定参数 (20)3.2.5.整定位掩码 (20)3.3.指示信息 (21)3.3.1.保护指示 (21)3.3.2.自检 (22)3.3.3.状态监视指示 (23)3.4.LED指示灯 (24)3.4.1.绿色指示LED（READY） (24)3.4.2.黄色指示LED（START） (24)3.4.3.红色指示LED（TRIP） (24)3.5.告警LED (25)3.5.1.告警LED1-8 (25)4.测试模式 (26)4.1.I/O测试 (26)4.2.IRF测试 (26)4.3.功能块测试 (27)5.参考书目 (28)6.索引 (29)7.附录A缩略语： (32)修订历史版本D/17.11.2003：–更改第3.1节., 第3.2.3.1.和第5节。

–更改第10页表3.1.1-1，“按钮功能”，第15页表3.2.1-1，“测量视图”。

–更改图3.2.-1中的内容。

版本D/25.03.2004：–更改文档版面1. 安全信息2. 引言本手册旨在给用户提供关于保护继电器REX 521 版本C的基本信息，着重阐述人机界面（HMI）的使用。

NS 951系列综合测控装置说明书V1.10南京电力自动化设备总厂南京南自科技发展有限公司2005年6月本说明书可能会被修改，请注意最新版本资料南自科技电网事业部监制目录1 概述 (1)2 装置特点 (1)3 主要功能 (2)3.1 NS 951 (2)3.2 NS 951B (2)4技术条件 (3)4.1 额定参数 (3)4.2 测量精度 (3)4.3 绝缘性能 (3)4.4 机械性能 (4)4.5 气候条件 (4)4.6 电磁兼容 (4)5 硬件说明 (6)5.1 机箱结构 (6)5.2 交流模件 (6)5.3 CPU模件 (6)5.4 信号出口模件 (6)5.5 电源模件 (6)5.6 显示面板 (7)6 测量、控制以及事件记录功能 (8)6.1 测量功能 (8)6.2 控制功能 (8)6.3 事件记录功能 (8)6.4 打印设置 (8)7 装置面板说明 (10)7.1 指示灯 (10)7.2 键盘 (10)8菜单操作说明 (11)8.1 菜单使用说明 (11)8.2 测量信息 (12)8.3 历史记录 (12)8.4 系统设置 (13)9 遥测、遥信信息一览表 (15)9.1 遥测量信息一览表 (15)9.2 遥信量信息一览表 (16)9.3 数值型定值一览表 (16)9.4 控制型定值一览表 (17)10 接线说明 (18)10.1 电源插件 X1、X2—适用于NS951、NS951B (18)10.2 交流插件 X3—适用于NS951、NS951B (18)10.3 CPU插件 X4—适用于NS951、NS951B (19)10.4 出口插件 X5、X6—适用于NS951 (19)10.5 出口插件 X5、X6—适用于NS951B (20)11 附图 (22)11.1 面板示意图 (22)11.2 安装尺寸图 (23)11.3 背板示意图 (24)21 概述NS 951系列综合测控装置是在消化吸收国内外同类产品先进经验的基础上研制的基于DSP 技术的新一代测控产品。

SALES OFFICE(301) 975-1000TECHNICAL SUPPORT(301) 975-1007An ISO-90011.0 WARRANTY INFORMATIONPatton Electronics warrants all Model 1205RC components to be free from defects, and will—at our option—repair or replace the product should it fail within one year from the first date of shipment.This warranty is limited to defects in workmanship or materials, and does not cover customer damage, abuse or unauthorized modifi-cation. If this product fails or does not perform as warranted, your sole recourse shall be repair or replacement as described above. Under no condition shall Patton Electronics be liable for any damages incurred by the use of this product. These damages include, but are not limited to, the following: lost profits, lost savings and incidental or consequen-tial damages arising from the use of or inability to use this product. Patton Electronics specifically disclaims all other warranties, expressed or implied, and the installation or use of this product shall be deemed an acceptance of these terms by the user.1.1 RADIO AND TV INTERFERENCEThe Model 1205RC generates and uses radio frequency energy, and if not installed and used properly—that is, in strict accordance with the manufacturer’s instructions—may cause interference to radio and television reception. The Model 1205RC has been tested and found to comply with the limits for a Class A computing device in accordance with the specifications in Subpart J of Part 15 of FCC rules, which are designed to provide reasonable protection from such interference in a commercial installation. However, there is no guarantee that interfer-ence will not occur in a particular installation. If the Model 1205RC does cause interference to radio or television reception, which can be determined by turning the power off or removing the card, the user is encouraged to try to correct the interference by one or more of the fol-lowing measures: moving the computing equipment away from the receiver, re-orienting the receiving antenna and/or plugging the receiv-ing equipment into a different AC outlet (such that the computing equip-ment and receiver are on different branches).In the event the user detects intermittent or continuous product malfunction due to nearby high power transmitting radio frequency equipment, the user is strongly advised to take the following steps: use only data cables with an exter-nal outer shield bonded to a metal or metalized connector; and, config-ure the rear card as shown in section 3.4 of this manual.1.2 CE NOTICEThe CE symbol on your Patton Electronics equipment indicates that it is in compliance with the Electromagnetic Compatibility (EMC) directive and the Low Voltage Directive (LVD) of the Union European (EU). A Certificate of Compliance is available by contacting Technical Support.1All warranty and nonwarranty repairs must be returned freight pre-paid and insured to Patton Electronics. All returns must have a Return Materials Authorization number on the outside of the shipping contain-er. This number may be obtained from Patton Electronics Technical Support: (301) 975-1007; ; or, support@. Packages received without an RMA number will not be accepted.Patton Electronics' technical staff is also available to answer any questions that might arise concerning the installation or use of your Model 1205RC. Technical Service hours: 8AM to 5PM EST, Monday through Friday.22.0 GENERAL INFORMATIONThank you for your purchase of this Patton Electronics product. This product has been thoroughly inspected and tested and is warrant-ed for One Year parts and labor. If any questions during installation or use of the 1205RC, contact Patton Electronics Technical Support: (301) 975-1007; ; or, ******************.2.1 FEATURES• V.35 (EIA-530) operation• Synchronous data rates from 32 to 144 Kbps• Host-to-host distances up to 300 feet• Internal or external clocking• All necessary data, clocking and control signals supported• Constant or RTS controlled carrier selections• RTS-CTS delay options of 0mS, 7mS or 53mS• Front panel LEDs show TD, DTR and CD activity for each port • Two UD-26 connectors on rear interface card• Switchable 120V or 240V power supply• Mounts in Patton’s 16-slot rack chassis and 2/4/8-slot ClusterBoxes• Made in the U.S.A.2.2 DESCRIPTIONThe Patton Model 1205RC synchronous modem eliminator rack card lets two synchronous hosts communicate with each other in the same room for a fraction of the cost of a pair of high speed modems. Supporting synchronous data rates of 32, 48, 56, 64, 72, 112, 128 and 144 Kbps, the Model 1205RC can be configured to emu-late dial-up or leased line service. Maximum distance between the connected hosts is 300 feet. Timing can be set for internal or external clock, and all necessary data, clocking and control signals are support-ed.The Model 1205RC is designed to mount in Patton’s 2U high, 16-slot rack chassis, as well as Patton’s 2/4/8-slot desktop Cluster Boxes. This rack chassis and cluster boxes feature a switchable 120/240 VAC power supply (optional 48 VDC) and hot swappable function/interface cards mounted in a mid-plane architecture. Front panel LEDs show TD, DTR and CD activity for both ports, as well as power. The rear interface card has two UD-26 connectors for patching to the host devices.3The power supply on/off switch is located on the front panel. When plugged in and switched on, a red front panel LED will glow. Since the Model 1000R16 is a “hot swappable” rack, it is not necessary for any cards to be installed before switching on the power supply.The power supply may be switched off at any time without harming the installed cards.NOTE: Please refer to the Model 1000RP Series User Manual AC and DC Rack Mount Power Supplie s for fuse and power cardreplacement information.4.2 INSTALLING THE MODEL1205RC INTO THE CHASSISThe Model 1205RC is comprised of a front card and a rear card. The two cards meet inside the rack chassis and plug into each other by way of mating 50 pin card edge connectors. Use the following steps as a guideline for installing each Model 1205RC into the rack chassis:1.Slide the rear card into the back of the chassis along themetal rails provided.2.Secure the rear card using the metal screws provided.3.Slide the card into the front of the chassis. It should meet therear card when it’s almost all the way into the chassis.4.Push the front card gently into the card-edge receptacle of therear card. It should “click” into place.5.Secure the front card using the thumb screws.NOTE:Since the Model 1000R16 chassis allows “hot swapping”of cards, it is not necessary to power down the rack when youinstall or remove a Model 1205RC.10There is no power switch on the Model 1205RC: Power is auto-matically applied to the 1205RC when its card-edge connector makes contact with the chassis’mid-plane socket, or when the chassis’power supply is turned on. Note: The 1205RC is a “hot swappable” card—it will not be damaged by plugging it in or removing it while the rack is powered up.When the Model 1205RC is powered up, and both ports are pass-ing data normally, the following LED conditions will exist:• PWR = green• TD = blinking red and green• CD = green• DTR = green13APPENDIX AMODEL1205RC SPECIFICATIONSTransmission Format: Synchronous, CCITT V.35Internal Interface:Connection to Model 1000R16 rackchassis via male card edge External Interface:UD-26 female, ports A1 and B1Data Rates:32, 48, 56, 64, 72, 112, 128 and 144 Kbps Clocking:Internal, external or receive loopback Distance:300 feet (DTE to DTE)RTS/CTS Delay:Strap selectable, 0, 7, 53 mS (+/- 15%) Indicators: Independent Bi-color LED indicators foreach port: TD, CD and DTR; common“Power” indicatorTemperature:0-50°C / 32-122°FHumidity: 5 to 95%, noncondensingDimensions: 0.95”w x 3.1”h x 5.4”l14Dear Valued Customer,Thank you for purchasing Patton Electronics products! We doappreciate your business. I trust that you find this user manual helpful.We manufacture one of the widest selections of data communica-tions products in the world including CSU/DSU's, network termination units, powered and self-powered short range modems, fiber optic modems, interface converters, baluns, electronic data switches, data-line surge protectors, multi-plexers, transceivers, hubs, print servers and much more. We produce these products at our Gaithersburg, MD, USA, facility, and can custom manufacture products for your unique needs.We would like to hear from you. Please contact us in any of the fol-lowing ways to tell us how you like this product and how we can meet your product needs today and in the future.Web: Sales E-mail: ****************Support E-mail: ******************Phone - Sales (301) 975-1000Phone - Support (301) 975-1007Fax: (301) 869-9293Mail: Patton Electronics Company7622 Rickenbacker DriveGaithersburg, MD 20879 USAWe are committed to a quality product at a quality price. Patton Electronics is ISO 9001 certified. We meet and exceed the highest standards in the industry (CE, UL, etc.).It is our business to serve you. If you are not satisfied with any aspect of this product or the service provided from Patton Electronics or its distributors, please let us know.Thank you.Burton A.PattonExecutive Vice PresidentP.S. Please tell us where you purchased this product._________________________________________________________ _________________________________________________________ _________________________________________________________ __________________________________________________________________________________________________________________。

DIRECT DRIVE COMPRESSORS MCFRC100,102A,103,108,109,107,113 MCFRC100,108MCFRC102A,109MCFRC103MCFRC107MCFRC113--------------------------------------------------------------------------------------------------------------Operation Instruction of Direct Drive Oil-Lubricated Piston Compressor MCFRC100,102A,103,108,109,107and113 Protect yourself and others by observing all safety information,warnings,and cautions.Failure to comply with instructions could result in personal injury and/or damage to product or property.Please retain instructions for future reference.WARRANTYThe Supplier warrants to the original purchaser only;this power tool to be free from defects in material and workmanship.Subject to certain exceptions,the Supplier will repair or replace any part on an electric power tool which,after examination,is determined to be defective in material or workmanship for a period of one(1)year after the date of purchase unless otherwise noted.Return of the power tool to the Retailer,is required together with the proof of purchase should be included with the returned product.This warranty does not apply to damage that is determined to be from repairs made or attempted by anyone other than authorized agents,misuse,alterations,abuse,normal wear and tear,lack of maintenance,or accidents.This warranty does not include items considered as consumables.Statutory RightsThis warranty is in addition to and in no way affects your statutory rights. SPECIFICA TIONSPart No.MCFRC100MCFRC108MCFRC102AMCFRC109MCFRC103MCFRC107MCFRC113Voltage230V/50HZ230V/50HZ230V/50HZ230V/50HZ230V/50HZ Tank capacity24Litre50Litre100Litre6Litre100Litre Rated Speed2850RPM2850RPM2850RPM2850RPM2850RPM Current 5.5A 6.5A 6.5A 5.5A 6.5A Pumpdisplacement150L/MIN206L/MIN206L/MIN130L/MIN315L/MINMax Pressure 800kPa/8Bar800kPa/8Bar800kPa/8Bar800kPa/8Bar800kPa/8BarOutlet1x1/4"1x1/4"1x1/4"1x1/4"1x1/4"--------------------------------------------------------------------------------------------------------------GENERAL SAFETY INSTRUCTIONSBefore attempting to operate this compressor the following basic safety precautions should always be taken to reduce the risk of fire,electric shock and personal injury.It is important to read the instruction manual to understand the application,limitations and potential hazards associated with any tool.They are designed for the safety of yourself and others,ensuring a long and trouble free service life from your machine.Work AreaWorkbenches should be kept tidy because cluttered benches and work areas invite accidents. Floors should be kept clean and free from rubbish.Special care should be taken if the floor is slippery due to sawdust or wax.Work EnvironmentKeep the work area well lit.Do not use compressor in areas where there is a risk of explosion or fire from combustible materials,flammable liquids,e.g.,paint,varnish,petrol etc or flammable gases and dust of an explosive nature.Guard Against Electric ShockDo not expose your compressor to rain,or use in damp or wet locations.Beware Children and PetsChildren and pets should be kept out of the work area.Use the right toolSelect the right tool for the job.Do not use a tool for a job for which it was not designed.Do not force a small tool to do the job of a heavy-duty tool.Personal safety ClothingDo not wear loose clothing,jewellery or anything that could get caught in moving machinery. HairLong hair should be tied back or contained in a protective covering.Eye ProtectionAlways use protective safety goggles or safety glasses.Ear ProtectionEar protection is advised during periods of extended operation.FootwearWhere there is a risk of heavy objects damaging feet or if there is a risk of slipping on wet or slippery floors suitable non-slip safety footwear should be worn.--------------------------------------------------------------------------------------------------------------Secure the Work PieceWherever possible secure the work piece using clamps or a vice.It is safer than using your hand and leaves both hands free to control the air tool.Do Not Over-reachDo not over-reach,keep proper footing and maintain your balance at all times.Maintain Tools with CareKeep cutting tools sharp and clean for better and safer performance.Follow the instructionsfor lubricating and changing accessories.Check the tool power cord periodically and if damaged have it replaced by an authorized service facility.Keep handles dry,clean and free from oil and grease.Ensure that ventilation slots are kept clean and free from dust at all times. Blocked ventilation slots can cause overheating and damage to the motor.Stay AlertWatch what you are doing,use common sense,and do not operate the air tool when youare tired or have taken medication that causes drowsiness,consumed alcohol or drugs. General Warnings for compressors•Do not attempt to modify the compressor in any way.•The use of any tools or accessory other than those designed for use with compressed air could result in injury to the operator.•The output pressure of the compressor should be adjusted to the design pressure of the air tool or accessory being used.•Always check that the output of the compressor does not exceed the maximum pressure for any attached tool or accessory.•Repairs should only be carried out by qualified persons using original spare parts.Failure to do so may result in considerable danger to the user.Breathable Air WarningThis compressor/pump is not equipped for,and should not be used to supply breathing quality air for any application of air for human consumption.Overload protection.This compressor is fitted with an overload protection device.In the event that the motor becomes too hot,a thermal protection device will cut the mains supplyto the motor.When the motor temperature returns to normal the mains supply will berestored automatically.Extension Cords and ReelsIn general,it is not recommended to use an extension lead.A longer air line is recommended as voltage drop on extension leads may lead to motor damage and will void warranty.If an extension cord must be used,for lengths up to5metres,an approved15amp rated cord must be used.--------------------------------------------------------------------------------------------------------------Do Not Abuse the Power CordNever yank or pull on the power cord to disconnect it from the mains supply socket.Never carry or drag your compressor by its power cord.Keep the power cord away from heat,oil, solvents and sharp edges.If the power cord becomes damaged have it replaced by an authorized service facility.Check Damaged PartsBefore using the compressor it should be carefully checked to determine that it will operate properly and perform its intended function.Check for the correct alignment of moving parts ensuring they do not bind.Check for broken or missing parts and have them replaced or repaired at an authorized service centre.Check any other condition that may affect the operation of the compressor.A guard or any other part of the compressor that is damaged should be properly repaired or replaced by an authorized service centre.Disconnect CompressorEnsure that the compressor is disconnected from the mains supply and the tank is empty when not in use,before servicing,lubricating or making adjustments to air lines,and when changing accessories such as blades,bits,nails and cutters on air tools.Avoid Unintentional StartingEnsure that the switch is in the OFF position before plugging the compressor into themains supplyTurning the compressor ON and OFFUse the red knob on top of the pressure switch to turn the unit on and off.Pull the knob upto turn the compressor on and push the knob in to turn it off.Turning the unit on and off from the mains supply only will result in damage to the motor and void warranty as the pressure switch has an additional function to purge the air trapped in the delivery pipe when themotor is turned off.This minimises the load on the motor when it is next started.--------------------------------------------------------------------------------------------------------------GENERAL VIEW AND MAIN COMPONENTS1.Main Compressor2.Pressure Switch3.Outlet Valve4.Pressure Regulator5.Pressure Gauge6.Non-Return Valve7.Drain Cock8.Wheel9.Discharge Pipe10.Air Tank 11.Safety Valve12.Fan CoverNote:Fittings may differ from those shown above.112435678910121--------------------------------------------------------------------------------------------------------------ASSEMBLYThis air compressor requires some minor assemble before it can be used.Locate the accessory pack.It should contain:1.Wheels and axle set2.Rubber stopper3.Air Filter4.Oil Breather plug5.A bottle of oil•Fit the wheels to the unit using the axlekit provided and insert the rubber stopper into thespigot on the bottom of the tank.•Fit the air filter to cylinder head of the compressor.•Locate the plastic dust plug in the oil breather hole and remove it to expose the oil breather hole.Oil breather hole--------------------------------------------------------------------------------------------------------------Oil Warning:This unit is shipped with oil in the compressor pump.•Usually check the oil level in the pump.Please fill the oil from the oil breather hole until the oil reaches the red mark on the sight glass•Check that the small hole in the top of the breather pipe is clear and then insert it into the oil filler hole.NOTE:The oil must be changed after the first10hrs of operation then every20hrs thereafter.Recommend compressor oil:Use SAE30for temperatures over10℃and use SAE10below10℃.--------------------------------------------------------------------------------------------------------------INITIAL ST ARTUP•Ensure the unit is stable in a well-ventilated dry position.•Ensure that the drain valve is closed and all air outlets are closed.Connect the power lead to the mains.•Start the compressor by pulling on the red knob.•Check for air leaksNote:Output fittings may differ from those shownWarning :Use the red knob to turn the unit on and off,not the mains switch.Turning the unit on and off from the mains only will result in damage to themotorTurn off--------------------------------------------------------------------------------------------------------------OPERATIONThe pressure in the tank is controlled by the action of the pressure switch located under the pressure switch coverWhen the set maximum pressure is reached the pressure switch activates and the motor is turned off.The pressure will then decrease as the air is used until the set minimum is reached after which the pressure switch turns the motor on again.The operator of the compressor should be well aware that during use of the compressor the motor will cycle (start and stop)under the influence of the rising or falling pressure in the tank and the motor will start without any warning.The maximum and minimum pressures are factory set and should not be altered.You can utilize either the direct outlet and/or the regulated outlet.The pressure of the regulated outlet can be changed by turning the control knob.Rotate the knob clockwise to increase pressure and anti-clockwise to decreaseNote:Output fittings may differ from thoseshownTurn off--------------------------------------------------------------------------------------------------------------MAINTENANCEWarning:Before maintenance operation,stop the air compressor,disconnect the unit from the mains supply and discharge all air in the air tank.Daily1.Check oil level before each use.2.Drain the condensation from the air receiver.3.Check for air leaks.Weekly1.Remove air filter element and clean or replace as required.Monthly1.Inspect non-return valve(clean or replace as required)Caution:ensure that air the tank is empty for this operation.2.Manually test the safety valve by pulling the ring.Three Monthly1.Change Oil2.Tighten cylinder head bolts.3.Clean and check valve assembly,replace gaskets/valves if worn or damaged.Recommend compressor oil use SAE30for temperatures over10℃and use SAE10 below10℃.--------------------------------------------------------------------------------------------------------------TROUBLES AND REMEDIESTrouble Possible causesRemedies Motor unable to run or running slow ⑴Fault in line,or voltage insufficient⑵Power wire too thin or too long⑶Fault in pressure switch⑷Fault in motor⑸Sticking of main compressor⑹The inner thermal protector on motor cut off ⑴Check the line ⑵Replace the wire ⑶Repair or replace ⑷Repair or replace ⑸Check and repair ⑹Compressor works too hard,turn offthe power and wait for 10-15minutes tocool down motor and restart.Sticking of main compressor ⑴Moving parts burnt due to insufficient oil ⑵Moving parts damaged,or stuck by foreign body Check crankshaft,bearing,connectingrod,piston,piston ring,etc.and replaceif necessaryExcessive vibration or abnormal noise ⑴Connecting part loose ⑵Foreign body got into main compressor ⑶Piston knocking valve seat ⑷Moving parts seriously worn⑴Check and retighten⑵Check and clean away⑶Replace with thicker paper gasket⑷Repair or replace Pressure insufficientor dischargecapacity decreased ⑴Motor running too slow ⑵Air filter choked up ⑶Leakage of safety valve ⑷Leakage of discharge pipe ⑸Sealing gasket damaged⑹Valve plate damaged,carbon build up or stuck⑺Piston ring and cylinder worn or damaged ⑴Check and remedy ⑵Clean or replace the cartridge ⑶Check and adjust ⑷Check and repair ⑸Check and replace ⑹Replace and clean ⑺Repair or replaceExcessive oilconsumption ⑴Oil level too high ⑵Breath pipe choked up⑶Piston ring and cylinder worn or damaged ⑴Keep the level within set range ⑵Check and clean ⑶Repair or replacePART LIST OF DIRECT DRIVE COMPRESSOR24L: MCFRC100,108; 50L: MCFRC102A,109; 100L: MCFRC103OTS VERSION: 10TH,MARCH,2012 QTY QTY 1Bolt M8×105430Spring washer 54 2Cylinder head131Bolt M5×954 3O Ring132Circlip Φ141 4Valve plate133Motor Fan1 5Inlet valve134Screw M4×101 6Locating pin Φ3×6235Tooth washer 41 7Valve gasketδ0.8136Screw M3×62 8A CylinderΦ42 for MCFRC100,108137Spring washer 32 8B CylinderΦ48 for MCFRC102A,109,103138A Capacitor 15UF for MCFRC100,1081 9Cylinder gasket δ0.8138B Capacitor 30UF for MCFRC102A,109,1031 10Bolt M12×15139Tooth washer 81 11A Piston ringΦ42 for MCFRC100,108140Air filter1 11B Piston ringΦ48 for MCFRC102A,109,103141Right-angle connecter Rp3/81 12A PistonΦ42 for MCFRC100,108142Fan cover1 12B PistonΦ48 for MCFRC102A,109,103143Screw M5×102 13A Piston Pin for MCFRC100,108144Screw ST3.4×162 13B Piston Pin for MCFRC102A,109,103145Handle Grip1 14CirclipΦ12246One-way valve1 15A Connecting rod for MCFRC100,108147Bolt M8×254 15B Connecting rod for MCFRC102A,109,103148Nut M84 16Breath pipe149Discharge Pipe1 17Screw M5×14650Discharge gasket2 18Oil leveler M27×1.5151Tank 36liter 1 19Crankcase cover152A 4.5" wheel kits for MCFRC100,1082 20Rubber gasket152B6" wheel kits for MCFRC102A,1092 21Screw M8×22-left152C8" wheel kits for MCFRC1032 22A Crank 17.5mm for MCFRC100,108153Drain Valve 1 22B Crank 20mm for MCFRC102A,109,103154Rubber foot kit2 23Crankcase155Release pipe1 24Sealing ring 20×40×7156south africa Power cord1 25Bearing 6204-2RZ1571/4" need valve with nut1 26A Rotor for MCFRC100,1081581/4"-1/4" mini regulator1 26B Rotor for MCFRC102A,109,10315940mm rear gauge2 27Bearing 6202-2RZ1601/4" -1/4"connector2 28A stator for MCFRC100,10816150mm rear gauge28B stator for MCFRC102A,109,1031628Bar 4 way 1/4" pressure switch1 29Motor bracket1631/4",8Bar safety valve1MCFRC107 PART LIST Unit QTY Unit QTY1 Bolt M6×35PC434 Spring Washer 4PC12 Spring Washer 6PC835 Screw M4×8PC13 Cylinder head PC136 Spring Washer 5PC44 Cylinder Head Sealing PC137 Bolt M5×80PC45 E-Bow Connector PC138 Clip Φ14PC16 Valve Plate SET139 Fan PC17 Inlet Valve PC142 Plastic Bottom cover PC18 Valve pin PC243 Fan cover PC19 Valve Gasket PC144 Screw M4×8PC410 Helx Bolt M6×20PC445 Bolt M5×16PC411 Cylinder PC146 Capacitor PC112 Cylinder Gasket PC148 Tooth Washer 8PC113 Piston Ring Set SET149 Nut M8PC115 Piston PC150 Air Filter PC116 Hole Clip Φ12PC251 Handel Grip PC117 Piston Pin PC152 Discharge Pipe SET118 Connect Rod PC153 Bolt M8×30PC419 Oil Breather PC154 Nut M8PC420 Oil Leveler PC155 Pressure Tank 6LT PC121 Bolt M5×16PC456 Pad SET422 Crankcase Cover PC157 Drain Valve PC123 Crankcase Sealing PC158 Check Valve SET124 Molt M10 for Crank PCS159 Release Pipe SET125 Crank PC160 Outlet Valve PC126 Crankcase PC161 Regulator PC127 Oil Sealing PC162 Pressure Guage 40PC128 Bearing 6003-2RS PC163 Connector R1/4PC129 Motor PC164 Power cord PC130 Stator SET165 Safty Valve PC131 Bearing 6202-2RS PC166 Pressure Switch PC132 Motor Bracket PC167 Pressure Guage 50PC133 Tooth Washer 4PC1MCFRC113 PART LISTNOPart Unit Qty NO Part Unit Qty 1Bolt M8x40PC 837fan PC 12cylinder head PC 238circlip Φ20PC 13O Ring PC 239Main cover PC 14valve plate subassembly SET 240Srew M5x14PC 45valve slice δ0.3PC 241Srew M3x6PC 46locating pin Φ3×6PC 442Spring washer 3PC 47valve gasket δ0.8PC 243Starting capacitance PC 18cylinder Φ42(Φ47)PC 244Running capacitance PC 19bolt M8x25PC 445Srew ST 3.9x15PC 310Spring Washer 8PC 446Head cover PC 111cylinder gasket δ0.8PC 247Cover support PC 112piston ring Φ42(Φ47)SET 248nut 8PC 213piston Φ42(Φ47)PC 249Air filter SET 214piston pin Φ12×35(38.5)PC 250Connect pipe SET 115circlip Φ14PC 451Tree-way connector A PC 116connecting rod PC 252Tree-way connector B PC 117breath pip SET 153Leak valve PC 118crankcase cover PC 154right-angle connector PC 119oil leveler SET 155Discharge Pipe PC 120bolt M5x16PC 556release pipe SET 121rubber gasket PC 157check valve PC 122screw M8×20PC 158Tank PC 123enlarge washer 8PC 159Bolt M8x40PC 424crank PC 160nut 8PC 425crankcase PC 161wheel assembly SET 226sealing ring 24×47×8PC 162handle grip PC 127brearing 6205PC 163drain valve SET 128rotor SET 164 foot pad assembly SET 229stator SET 165Outlet Valve SET 130screw M4×10PC 266Regulator PC 131Centrifugal switch L22SET 167Conector R1/4PC 132brearing 6204PC 168Power cord 3G1.5mm2PC 133motor bracket PC 169Pressure Guage 40mm PC 134Tooth Wahser 4PC 170Safety valve 1/4" 9Bar PC 135spring washer 6PC 471Pressure switch 8Bar PC 1Distributed by L&G Tool&Machinery Distributors Limited6Kyalami Rd,Westmead3610,P.O.Box15313,Westmead3608,Telephone:031-7176800,Fax:031-7176868。
