蓝光盘库技术方向对比【概况】Panasonic采用模式：单光驱单光头(单面刻录1光头，双面2光头)，由多个光驱构成光驱组的模式他社：但光驱内集成多组光头(单面4光头，双面8光头)的模式【比较】1，读/写速度比较P社模式下读/写速度一致，均为360MB/s(=30MB/s*2*6)他社模式下，由于散热会影响误码率，使用寿命等一系列问题，在数据刻写时集成在同一光驱内的8个光头无法同时工作，部分光头必须处于待机状态，导致刻写速度仅为140MB/s。

数据读取时功耗较低，8个光头同时工作，读取速度280MB/s。

目前MAM系统最多可支持6组光驱，在满配光驱情况下，双方的系他社模式通过占用盘匣空间提高系统速度，以牺牲盘柜容量密度换取系统速度的提升2，未来发展性比较随着光盘容量提升，单光头速度随之提升。

单光头速度为N[MB/s]时，两种模式下的刻写速度分别为P模式：N*12[MB/s]它社模式：N*4[MB/s]随着N的增长，量模式下的系统速度逐渐拉大。

他社模式存在扩容性，可发展性，系统速度的提升的一系列无法解决的问题。

P社模式不存在上述问题并，且可确保读写速度一致，并均有良好的扩展性。

3，可对应最大单个文件容量P社模式以盘匣为单位，可对应的最大单个文件大小为1.8TB。

他社模式以光盘为单位，可对应最大文件大小仅为300GB，超过300GB需对文件进行分割，影响读/写效率4，数据安全性P社模式多张光盘同时读/写，可采用与HDD类似的RAID5,6提高存储安全级别。

他社无法对应RAID模式，与LTO类似，只能采取多倍备份的模式，消耗空间过大5，读写效率P社模式读取同一盘匣内数据均无需更换盘片，效率高他社模式下需更换盘片，导致读取时间增加6，P社盘库中所采用的所有硬件部分（机械手臂，光驱，光盘）均为P社自主研发及生产的产品，在产品兼容性，持续性，将来性方面拥有决定权。

他社盘库中关键硬件部分为指定工厂进行代工的产品，在研发，生产，兼容性等方面存在风险。
