冷藏车设计毕业论文[管理资料]

摘 要

随着社会经济的发展，应用制冷技术和专用设备以满足特殊温度要求的货物进行冷藏与日俱增，随着我国高速路的延伸，公路冷藏运输也发展起来，绝大部分冷藏车对货物采用隔热保温的方法。本设计以CA1046汽车三类底盘为基础，改装设计为小型冷藏汽车，该车冷藏箱可通过安装在副车架上的四个支撑从车架上方便移下，这样可以满足特殊条件的使用要求。利用制冷理论设计冷藏车既有隔热车厢隔热保温，又安装有制冷机组制冷，满足冷藏车的冷藏温度5℃～10℃的设计要求。运输中压缩机采用汽车发电机的电源驱动，在停车时可采用外接电源驱动压缩机。

关键词 制冷技术；冷藏运输车；专用车设计

Abstract

As social and economic development, application of refrigeration

technology and special equipment to meet the special requirements of the

temperature of frozen goods growing, as China's high-speed Road, the extension

of Highway Refrigerated Transport has also developed, the vast majority of the

goods refrigerated trucks used Insulation approach. The three designed to CA1046

car chassis as the foundation, the design modifications for small refrigerated

vehicles, the vehicle can be refrigerated containers installed in the frame of the

four support from the convenience of the frame shift, so to meet the special

conditions of use requirements . Refrigeration theoretical design using refrigerated

trucks both inside insulation insulation, refrigeration units equipped with

refrigeration, refrigerated trucks to meet the refrigeration temperature 5 ℃ to

10 ℃ design requirements. Compressors used in the transport vehicle driven

power generators in the parking available in an external power supply-driven

compressor.

Keywords：Refrigeration Technology, Refrigerated Transporter, Special Vehicle

Design

目 录

摘 要 ........................................................... I

Abstract ........................................................ II

第1章 绪论 ...................................................... 1

课题背景 ............................................................................................................ 1

冷藏运输中的制冷技术发展与应用 ................................................................ 1

蒸气压缩式制冷原理 ........................................................................................ 2

第2章 冷藏车的布置 .............................................. 4

制冷车的分类和特点 ...................................................................................... 4

冷藏汽车整车布置 .......................................................................................... 4

本章小结 .......................................................................................................... 5

第3章 冷藏箱的设计 .............................................. 6

冷藏箱的类型与定义 ...................................................................................... 6

冷藏箱的结构设计 .......................................................................................... 7

冷藏箱隔热层材料及其厚度 .......................................................................... 8

机械式冷藏箱的工作原理 .............................................................................. 9

热平衡计算 ...................................................................................................... 9

本章小结 ........................................................................................................ 12

第4章 制冷剂的选择与要求 ....................................... 13

制冷剂的种类 ................................................................................................ 13

制冷剂的热力学性质及使用要求 ................................................................ 13

制冷剂的选择 ................................................................................................ 14

本章小结 ........................................................................................................ 14

第5章 制冷机组的设计 ........................................... 15

制冷机组的结构 ............................................................................................ 15

蒸气压缩式制冷循环的热力计算 ................................................................ 15

制冷压缩机的结构性能要求 ........................................................................ 17

制冷压缩机的选配与特点 ............................................................................ 18

冷凝器的结构与设计 .................................................................................... 19

蒸发器的结构与设计 .................................................................................... 19

储液器的结构与设计 .................................................................................... 20 膨胀阀的选配与要求 .................................................................................... 20

本章小结 ........................................................................................................ 21

第6章 制冷管路的设计与隔热措施 ................................. 22

制冷管路 ........................................................................................................ 22

制冷管路的隔热 ............................................................................................ 22

本章小结 ........................................................................................................ 23

结论 ............................................................ 24
