ECopyright 1995 by Dallas Semiconductor Corporation.All Rights Reserved. For important information regardingpatents and other intellectual property rights, please refer toDallas Semiconductor data books.DS12B887

Real Time ClockDS12B887

080895 1/16FEATURES

•Drop-in replacement for IBM AT computer clock/cal-endar

•Pin compatible with the MC146818B and DS1287

•Totally nonvolatile with over 10 years of operation inthe absence of power

•Self-contained subsystem includes lithium, quartz,and support circuitry

•Counts seconds, minutes, hours, days, day of theweek, date, month, and year with leap year com-pensation

•Binary or BCD representation of time, calendar, andalarm

•12- or 24-hour clock with AM and PM in 12-hour mode

•Daylight Savings Time option

•Multiplex bus for pin efficiency

•Interfaced with software as 128 RAM locations

–14 bytes of clock and control registers

–114 bytes of general purpose RAM

•Programmable square wave output signal

•Bus-compatible interrupt signals (IRQ)

•Three interrupts are separately software-maskableand testable

–Time-of-day alarm once/second to once/day

–Periodic rates from 122 µs to 500 ms

–End of clock update cyclePIN ASSIGNMENT

24 PIN ENCAPSULATED PACKAGEVCCSQW

NC

RCLR

NC

IRQ

NC

DS

NC

R/W

AS

CSNC

NC

NC

AD0

AD1

AD2

AD3

AD4

AD5

AD6

AD7

GND1

2

3

4

5

6

7

8

9

10

11

1224

23

22

21

20

19

18

17

16

15

14

13

PIN DESCRIPTION

AD0-AD7–Multiplexed Address/Data Bus

NC–No Connection

CS–Chip Select

AS–Address Strobe

R/W–Read/Write Input

DS–Data Strobe

IRQ–Interrupt Request Output

SQW–Square Wave Output

VCC–+5 Volt Supply

GND–Ground

RCLR–RAM Clear

DESCRIPTION

The DS12B887 Real Time Clock plus RAM is designed

to be a direct replacement for the DS1287A or

DS12887A. The DS12B887 is identical in form, fit, and

function to the DS1287A or DS12887A, with the excep-

tion of RCLR, and has an additional 64 bytes of general

purpose RAM. Access to this additional RAM space is

determined by the logic level presented on AD6 during

the address portion of an access cycle. A lithium energy

source, quartz crystal, and write-protection circuitry arecontained within a 24-pin dual in-line package. As such,

the DS12B887 is a complete subsystem replacing 16

components in a typical application. The functions

include a nonvolatile time-of-day clock, an alarm, a one-

hundred-year calendar, programmable interrupt,

square wave generator, and 114 bytes of nonvolatile

static RAM. The real time clock is distinctive in that

time-of-day and memory are maintained even in the

absence of power.元器件交易网www.cecb2b.comDS12B887

080895 2/16OPERATION

The block diagram in Figure 1 shows the pin connec-

tions with the major internal functions of the DS12B887.The following paragraphs describe the function of each

pin.

BLOCK DIAGRAM DS12B887 Figure 1

USER RAM114 BYTESCLOCK, CALENDAR,AND ALARM RAMREGISTERS A,B,C,DSQUAREWAVE OUTPERIODIC INTERRUPT/SQUARE WAVESELECTOROSC.

POWERSWITCHANDWRITEPROTECT

BUSINTERFACECLOCK/CALENDARUPDATE

BCD/BINARYINCREMENTSQW

IRQ

DOUBLEBUFFERED

ADO–AD7ASDS

R/WCSCS

VCC

POKVCC

VBATB8B64B64

RAMCLEARLOGICRCLR

POWER-DOWN/POWER-UP

CONSIDERATIONS

The Real Time Clock function will continue to operate

and all of the RAM, time, calendar, and alarm memory

locations remain nonvolatile regardless of the level of

the VCC input. When VCC is applied to the DS12B887

and reaches a level of greater than 4.25 volts, the device

becomes accessible after 200 ms, provided that the

oscillator is running and the oscillator countdown chain

is not in reset (see Register A). This time period allows

the system to stabilize after power is applied. WhenVCC falls below 4.25 volts, the chip select input is inter-

nally forced to an inactive level regardless of the value of

CS at the input pin. The DS12B887 is, therefore, write-

protected. When the DS12B887 is in a write-protected

state, all inputs are ignored and all outputs are in a high

impedance state. When VCC falls below a level of

approximately 3 volts, the external VCC supply is

switched off and an internal lithium energy source sup-

plies power to the Real Time Clock and the RAM

memory.元器件交易网www.cecb2b.com
