SSMS错误代码⼤全0 操作成功完成。
1 功能错误。
2 系统找不到指定的⽂件。
3 系统找不到指定的路径。
4 系统⽆法打开⽂件。
5 拒绝访问。
6 句柄⽆效。
7 存储控制块被损坏。
8 存储空间不⾜,⽆法处理此命令。
9 存储控制块地址⽆效。
10 环境错误。
11 试图加载格式错误的程序。
12 访问码⽆效。
13 数据⽆效。
14 存储器不⾜,⽆法完成此操作。
15 系统找不到指定的驱动器。
16 ⽆法删除⽬录。
17 系统⽆法将⽂件移到不同的驱动器。
18 没有更多⽂件。
19 介质受写⼊保护。
20 系统找不到指定的设备。
21 设备未就绪。
22 设备不识别此命令。
23 数据错误 (循环冗余检查)。
24 程序发出命令,但命令长度不正确。
25 驱动器⽆法找出磁盘上特定区域或磁道的位置。
26 ⽆法访问指定的磁盘或软盘。
27 驱动器找不到请求的扇区。
28 打印机缺纸。
29 系统⽆法写⼊指定的设备。
30 系统⽆法从指定的设备上读取。
31 连到系统上的设备没有发挥作⽤。
32 进程⽆法访问⽂件,因为另⼀个程序正在使⽤此⽂件。
33 进程⽆法访问⽂件,因为另⼀个程序已锁定⽂件的⼀部分。
36 ⽤来共享的打开⽂件过多。
38 到达⽂件结尾。
39 磁盘已满。
50 不⽀持⽹络请求。
51 远程计算机不可⽤。
52 在⽹络上已有重复的名称。
53 找不到⽹络路径。
54 ⽹络忙。
55 指定的⽹络资源或设备不再可⽤。
56 已到达⽹络 BIOS 命令限制。
57 ⽹络适配器硬件出错。
58 指定的服务器⽆法运⾏请求的操作。
59 发⽣意外的⽹络错误。
60 远程适配器不兼容。
61 打印机队列已满。
62 ⽆法在服务器上获得⽤于保存待打印⽂件的空间。
63 删除等候打印的⽂件。
64 指定的⽹络名不再可⽤。
65 拒绝⽹络访问。
66 ⽹络资源类型错误。
67 找不到⽹络名。
68 超过本地计算机⽹卡的名称限制。
69 超出⽹络 BIOS 会话限制。
70 远程服务器已暂停,或正在启动过程中。
夏普复印机特殊故障代码的复位方法夏普复印机特殊故障代码的复位方法夏普700/800系列复印机特殊故障代码主要有HX(H1 —H8,热辊定影器故障)、Lx(L1-L6 ,微动开关/光电开关故障)、Ux(U1U2,电池电压低或数据传输故障)及PI(曝光灯温度保险丝异常)•其中,U1用指令“13复位,其它特殊故障代码用指令“14”复位。
夏普1000 /2000系列复印机特殊故障代码主要有HX(H2-H4,热辊定影器故障)与U2(存储器读写故障)•其中,U2用指令“16复位,其它特殊故障代码用指令“14”复位。
夏普7000 /8000系列复印机特殊故障代码主要有HX(H3、H4,热辊定影器故障)与U1(电池电压低)。
其中U1用指令“13”复位,H3 H4用指令“14复位•复位操作的顺序如附图所示.此外,夏普z60型复印机特殊故障代码用U(主板电池电压低)、L(微动开关故障)、H (热辊定影器故障)、F(定影灯或温度保险丝问题)表示,均用指令“1复位。
复位时,依序按下清除键、重复键、(加数键)、(减数键)数字键“1和复印键即可.注:(1)应在 5 秒钟内按下该键:(2)夏普750、770、771 、780、781 、825 等复印机按重复键,其它复印机按暂停键;(3)此时操作板上所有显示消失,主电机停止转动,复印机准备接受指令(主电机转动时复印机不接受指令);(4)夏普1000/2000 系列复印机包括夏普1016、1020、1025、1116、2014、2020、2022、2027、2040、2114、2214 等型复印机;夏普7000/8000 系列复印机包括夏普7320、7370、7700、7750、7800、7850、8570、8870 等型复印机.夏普工厂代码2[公告]夏普的工厂代码24: 进入ar-206 的维修代码是c-*_0_* 主代码+ 附代码5: 夏普的工厂代码的补充代码!!!!!按C键T CA键T 0键T C键T XXT复印键以下是我转帖的80 01 显影器单元不检测模式设定80 02 显示或修改[25-2]TD 传感器目标电压80 06 AE 传感器增益设定80 0880 09缺省(^'7才儿卜;default)值自动设定81 ** 显示或修改总计数器[22-05]82 ** 显示或修改当前保养计数器[22-01] (小人指示灯点亮)84 01 清除总复印张数计数器[22-05]85 ** 显示或修改当前载体印张计数器[22-06],[22-01](小太阳灯点亮)88 01 清除全部内存储器89 01 清除全部计数器键入"1"按复印键89 02 清除键操作码.记忆数据键入"2"按复印键90 1 显示[47]AE 传感器增益数据80V *** 60V ***75V *** 55V ***70V *** 50V ***65V *** 45V ***90 10 过程控制数据显示STD ID:75 MARK:98 MAK BA 164BASE1:0 BASE2:0 BASE3:0BASE4:0 BASE5:0 BASE6:0BASE7:0 IDPAT1 :0 IDPAT2 :0IDPAT3:0 IDPAT4:0 IDPAT5:0IDPAT6:0 IDPAT7 :092 1 SARM -- EEPROM 数据传送2 EEPROM -- SARM 数据传送80-19 载体参数调整83-1 SPF 计数器设置83-2 双面计数器设置83-5 装订计数器设置83-6 告警计数器设置83-8 传真计数器夏普工厂代码3[公告]夏普的工厂代码383-10 打印计数器设置83-11 打印计数器设置83-12 其它计数器设置83-13 扫描方式计数器设置83-14 IMC 计数器设置88-2 ZLO 清除88-3 传真清除88-4 打印清除88-7 描扫清除89-3 传真密码清除我补充的是26-96 查机身号码这在于无换主板时有效6: 夏普数码复印机用户程序模式夏普数码复印机用户程序模式注:* 号为缺省值AR158/AL12401. 进入方式.持续按左右浓度调整键5 秒钟;.对于AR158,载体,墨粉,保养,卡纸灯同时闪烁,显示窗口显示--;.对于AL1240, 鼓,卡纸,墨粉灯同时闪烁,显示窗口显示--;.用十位数选择功能代码,按复印键;用个位数键选择设定代号,按复印键;•选错功能代码时按"C"键,按浓键或淡键退出;2. 用户代码.AR1581 自动复位时间设定0:取消1:10 秒2:30 秒*3:60 秒4:90 秒5:120 秒2 自动进入预热状态时间设定*0:30 秒1:60 秒2:90 秒3 电源自动关闭时间设定0:2 分钟*1:5 分钟2:15 分钟3:30 分钟4:60 分钟5:120 分钟4 SPF 原稿连续进纸设定0: 取消*1: 设定5 是否使用电源自动关闭功能0:取消*1: 设定6 分辨率设定*0:300DPI 1:600DPI .AL1240(仅列出与158 不同点)1 自动复位时间设定0:取消1:30 秒*2:60 秒3:90 秒4:120 秒2 自动进入预热状态时间设定0:30 秒1:60 秒*2:90 秒9 16K 复印纸*0:取消1:设定夏普代码46 说明:46 是暴光强度调整用于在各暴光方式下,设定复印浓度(复印机灯输出电压)执行模式时,开始预热并在复印数量显示器上显示当前手动设定上限值(ME)预热完毕后,准备就绪灯点亮.按START键时,在当前设定的暴光方式下进行复印由于有若干显示项目,复印数量显示屏的第3 位表示光接收电平与原稿判断电平差异,下两位表示数据要选择显示,按放大倍率显示键复印数量显示屏第3位第2第1位暴光部显示显示数据A 1 --- 99 ME exp.1 手动(ME)上限值b 1一99 ME exp.5 手动(ME)下限值c 1----99 ME+PE exp.1 手动(ME)色粉节省上限值d 1---99 ME+PE exp.5 手动(ME)色粉节省下限值E 1---99 PE exp.1 照片(PE)上限值F 1---99 PE exp.5 照片(PE)下限值G 1---99 AE exp.1 自动(AE)倾斜H 1---99 AE exp.5 自动(AE)下限值I 1---99 AE+PE exp.1 自动(AE)色粉节省倾斜J 1---99 AE+PE exp.5 自动(AE)色粉节省下限值设定范围为1---99,增加设定值将增加复印浓度。
10004—WSAEINTR函数调用中断。
该错误表明由于对WSACancelBlockingCall的调用,造成了一次调用被强行中断。
10009—WSAEBADF文件句柄错误。
该错误表明提供的文件句柄无效。
在MicrosoftWindowsCE下,socket函数可能返回这个错误,表明共享串口处于“忙”状态。
10013—WSAEACCES权限被拒。
尝试对套接字进行操作,但被禁止。
若试图在sendto或WSASendTo中使用一个广播地址,但是尚未用setsockopt和SO_BROADCAST这两个选项设置广播权限,便会产生这类错误。
10014—WSAEFAULT地址无效。
传给Winsock函数的指针地址无效。
若指定的缓冲区太小,也会产生这个错误。
10022—WSAEINVAL参数无效。
指定了一个无效参数。
例如,假如为WSAIoctl调用指定了一个无效控制代码,便会产生这个错误。
另外,它也可能表明套接字当前的状态有错,例如在一个目前没有监听的套接字上调用accept或WSAAccept。
10024—WSAEMFILE打开文件过多。
提示打开的套接字太多了。
通常,Microsoft提供者只受到系统内可用资源数量的限制。
10035—WSAEWOULDBLOCK资源暂时不可用。
对非锁定套接字来说,如果请求操作不能立即执行的话,通常会返回这个错误。
比如说,在一个非暂停套接字上调用connect,就会返回这个错误。
因为连接请求不能立即执行。
10036—WSAEINPROGRESS操作正在进行中。
当前正在执行非锁定操作。
一般来说不会出现这个错误,除非正在开发16位Winsock应用程序。
10037—WSAEALREADY操作已完成。
一般来说,在非锁定套接字上尝试已处于进程中的操作时,会产生这个错误。
比如,在一个已处于连接进程的非锁定套接字上,再一次调用connect或WSAConnect。
另外,服务提供者处于执行回调函数(针对支持回调例程的Winsock函数)的进程中时,也会?出现这个错误。
WOSA3.0错误码1.公共错误码(-2) WOSA版本不对(-3) WOSA版本不对(-4) 操作取消(-5) 注册表配置不对(-6) 注册表配置不对(-7) 注册表配置不对(-8) 注册表配置不对(-9) 注册表配置不对(-10) 注册表配置不对(-11) 注册表配置不对(-12) 注册表配置不对(-13) 设备没有准备好,设备故障(-14) 设备故障(-15) 内部错误(-16) 无效地址(-17) 无效的APP句柄(-18) 无效的缓冲区(-19) 无效的命令种类(-20) 无效的操作命令(-21) 无效的事件类别(-22) 无效的服务句柄(-23) 无效的服务句柄WFS_ERR_INVALID_HWND (-24) 无效的窗口句柄WFS_ERR_INVALID_HWNDREG (-25) 无效的参数WFS_ERR_INVALID_POINTER (-26) 无效的指针WFS_ERR_INVALID_REQ_ID (-27) 无效的请求IDWFS_ERR_INVALID_RESULT (-28) 无效的返回结果WFS_ERR_INVALID_SERVPROV (-29) 无效的SP,可能sp服务没有启动WFS_ERR_INVALID_TIMER (-30) 无效的参数WFS_ERR_INVALID_TRACELEVEL (-31) 无效的日志级别WFS_ERR_LOCKED (-32) 服务已经被加锁WFS_ERR_NO_BLOCKING_CALL (-33) 不能调用BLOCKING CALLWFS_ERR_NO_SERVPROV (-34) sp不存在,可能sp服务没有启动WFS_ERR_NO_SUCH_THREAD (-35) 线程不存在WFS_ERR_NO_TIMER (-36) 计时器创建失败WFS_ERR_NOT_LOCKED (-37) 加锁不成功WFS_ERR_NOT_OK_TO_UNLOAD (-38) 不能加载sp的dllWFS_ERR_NOT_STARTED (-39) StartUp失败WFS_ERR_NOT_REGISTERED (-40) 没有注册事件WFS_ERR_OP_IN_PROGRESS (-41) 操作正在执行中WFS_ERR_OUT_OF_MEMORY (-42) 内存溢出WFS_ERR_SERVICE_NOT_FOUND (-43) WOSA版本不对WFS_ERR_SPI_VER_TOO_HIGH (-44) WOSA版本不对WFS_ERR_SPI_VER_TOO_LOW (-45) WOSA版本不对WFS_ERR_SRVC_VER_TOO_HIGH (-46) WOSA版本不对WFS_ERR_SRVC_VER_TOO_LOW (-47) WOSA版本不对WFS_ERR_TIMEOUT (-48) 操作超时WFS_ERR_UNSUPP_CATEGORY (-49) 不支持的查询类别WFS_ERR_UNSUPP_COMMAND (-50) 不支持的操作命令WFS_ERR_VERSION_ERROR_IN_SRVC (-51) WOSA版本错误WFS_ERR_INVALID_DATA (-52) 无效的数据WFS_ERR_SOFTWARE_ERROR (-53) 软件错误WFS_ERR_CONNECTION_LOST (-54) 连接断开WFS_ERR_USER_ERROR (-55) 用户使用错误WFS_ERR_UNSUPP_DATA (-56) 不支持的数据2.PrinterWFS_ERR_PTR_FORMNOTFOUND (-100) FORM未找到WFS_ERR_PTR_FIELDNOTFOUND (-101) FIELD未找到WFS_ERR_PTR_NOMEDIAPRESENT (-102) 缺纸WFS_ERR_PTR_READNOTSUPPORTED (-103) 设备不支持读操作WFS_ERR_PTR_FLUSHFAIL (-104) 不支持FLUSHWFS_ERR_PTR_MEDIAOVERFLOW (-105) Media超域WFS_ERR_PTR_FIELDSPECFAILURE (-106) Field语法错误WFS_ERR_PTR_FIELDERROR (-107) 处理Field时发生错误WFS_ERR_PTR_MEDIANOTFOUND (-108) Media未找到WFS_ERR_PTR_EXTENTNOTSUPPORTED (-109) 设备无法获得范围WFS_ERR_PTR_MEDIAINV ALID (-110) 无效的MediaWFS_ERR_PTR_FORMINV ALID (-111) 无效的FormWFS_ERR_PTR_FIELDINV ALID (-112) 无效的FieldWFS_ERR_PTR_MEDIASKEWED (-113) Media错误WFS_ERR_PTR_RETRACTBINFULL (-114) 回收箱满WFS_ERR_PTR_STACKERFULL (-115) STACKE满WFS_ERR_PTR_PAGETURNFAIL (-116) 设备不能翻页WFS_ERR_PTR_MEDIATURNFAIL (-117) 设备不能翻转介质WFS_ERR_PTR_SHUTTERFAIL (-118) Shutter执行命令失败WFS_ERR_PTR_MEDIAJAMMED (-119) 卡纸WFS_ERR_PTR_FILE_IO_ERROR (-120) 文件读取失败WFS_ERR_PTR_CHARSETDATA (-121) 字符集不一致WFS_ERR_PTR_PAPERJAMMED (-122) 卡纸WFS_ERR_PTR_PAPEROUT (-123) 缺纸WFS_ERR_PTR_INKOUT (-124) 墨水用玩WFS_ERR_PTR_TONEROUT (-125) 色带用玩WFS_ERR_PTR_LAMPINOP (-126) 成象灯不可操作WFS_ERR_PTR_SOURCEINVALID (-127) 资源无效WFS_ERR_PTR_SEQUENCEINVALID (-128) 命令序列不对WFS_ERR_PTR_MEDIASIZE (-129) 介质的长度不对3.CardReaderWFS_ERR_IDC_MEDIAJAM (-200) 卡堵塞WFS_ERR_IDC_NOMEDIA (-201) 没有卡WFS_ERR_IDC_MEDIARETAINED (-202) 吞卡WFS_ERR_IDC_RETAINBINFULL (-203) 吞卡箱满WFS_ERR_IDC_INV ALIDDATA (-204) 无效的数据WFS_ERR_IDC_INV ALIDMEDIA (-205) 无效的MediaWFS_ERR_IDC_FORMNOTFOUND (-206) Form未找到WFS_ERR_IDC_FORMINV ALID (-207) Form无效WFS_ERR_IDC_DATASYNTAX (-208) 数据语法错误WFS_ERR_IDC_SHUTTERFAIL (-209) 打开Shutter失败WFS_ERR_IDC_SECURITYFAIL (-210) 安全检测失败WFS_ERR_IDC_PROTOCOLNOTSUPP (-211) 协议不支持WFS_ERR_IDC_ATRNOTOBTAINED (-212) ATR未获得WFS_ERR_IDC_INVALIDKEY (-213) Key无效WFS_ERR_IDC_WRITE_METHOD (-214) 不支持写的操作WFS_ERR_IDC_CHIPPOWERNOTSUPP (-215) 不支持IC读写WFS_ERR_IDC_CARDTOOSHORT (-216) 卡长度过短WFS_ERR_IDC_CARDTOOLONG (-217) 卡长度过长4.CashDispenserWFS_ERR_CDM_INVALIDCURRENCY (-300) 无效的币种WFS_ERR_CDM_INVALIDTELLERID (-301) 无效的TellerIDWFS_ERR_CDM_CASHUNITERROR (-302) 钞箱故障WFS_ERR_CDM_INVALIDDENOMINATION (-303) 无效的配钞WFS_ERR_CDM_INVALIDMIXNUMBER (-304) 参数错误WFS_ERR_CDM_NOCURRENCYMIX (-305) 参数错误WFS_ERR_CDM_NOTDISPENSABLE (-306) 无法挖出指定的钞票WFS_ERR_CDM_TOOMANYBILLS (-307) 要求挖的钞票过多,无法挖出WFS_ERR_CDM_INVALIDPOSITION (-308) 无效的位置WFS_ERR_CDM_POSITIONLOCKED (-309) 出口位置被锁住WFS_ERR_CDM_SAFEDOOROPEN (-310) 挖钞时安全门是打开的,无法挖钞WFS_ERR_CDM_INVALIDRETRACT (-311) Retract命令无效WFS_ERR_CDM_SHUTTERNOTOPEN (-312) Shutter打开失败WFS_ERR_CDM_SHUTTEROPEN (-313) Shutter已经打开WFS_ERR_CDM_SHUTTERCLOSED (-314) Shutter已经关闭WFS_ERR_CDM_INVALIDCASHUNIT (-315) 无效的钞箱编号WFS_ERR_CDM_NOBILLS (-316) 没有钞票WFS_ERR_CDM_EXCHANGEACTIVE (-317) 设备处于维护状态中WFS_ERR_CDM_NOEXCHANGEACTIVE (-318) 设备未处于维护状态中WFS_ERR_CDM_SHUTTERNOTCLOSED (-319) Shutter关闭失败WFS_ERR_CDM_PRERRORNOBILLS (-320) 送钞时没有钞票WFS_ERR_CDM_PRERRORBILLS (-321) 送钞时发生错误,并且部分钞票已送出WFS_ERR_CDM_PRERRORUNKNOWN (-322) 送钞时发生错误,钞票位置未知WFS_ERR_CDM_BILLSTAKEN (-323) 收钞时部分或全部钞票被取走WFS_ERR_CDM_TOOMANYCOINS (-324) 要求挖的硬币过多WFS_ERR_CDM_CASHINACTIVE (-325) 设备处于存款过程中WFS_ERR_CDM_NOCASHINSTARTED (-326) 没有开始存款过程WFS_ERR_CDM_INVALIDMIXTABLE (-327) 无效的配钞表WFS_ERR_CDM_OUTPUTPOS_NOT_EMPTY (-328) 出钞口有钞票WFS_ERR_CDM_INVALIDRETRACTPOSITION (-329) 回收钞票位置无效WFS_ERR_CDM_NOTRETRACTAREA (-330) 指定的回收位置不支持WFS_ERR_CDM_NOCASHBOXPRESENT (-333) 没有Cash boxWFS_ERR_CDM_AMOUNTNOTINMIXTABLE (-334) 指定的配钞没有在配钞表中WFS_ERR_CDM_ITEMSNOTTAKEN (-335) 钞票未拿走WFS_ERR_CDM_ITEMSLEFT (-336)) 钞票遗留在钞道或出钞口上5.PinpadWFS_ERR_PIN_KEYNOTFOUND (-400) 按键未找到WFS_ERR_PIN_MODENOTSUPPORTED (-401) 不支持的模式WFS_ERR_PIN_ACCESSDENIED (-402) 访问拒绝WFS_ERR_PIN_INVALIDID (-403) ID无效WFS_ERR_PIN_DUPLICATEKEY (-404) Key已存在WFS_ERR_PIN_KEYNOVALUE (-406) Key没有加载WFS_ERR_PIN_USEVIOLATION (-407) Key使用不对WFS_ERR_PIN_NOPIN (-408) 键盘中没有密码WFS_ERR_PIN_INVALIDKEYLENGTH (-409) 无效的Key长度WFS_ERR_PIN_KEYINVALID (-410) 无效的按键WFS_ERR_PIN_KEYNOTSUPPORTED (-411) 存在不支持的按键WFS_ERR_PIN_NOACTIVEKEYS (-412) 没有激活任何按键WFS_ERR_PIN_INVALIDKEY (-413) 无效的keyWFS_ERR_PIN_NOTERMINATEKEYS (-414) 没有终止键WFS_ERR_PIN_MINIMUMLENGTH (-415) 最小密码长度无效WFS_ERR_PIN_PROTOCOLNOTSUPP (-416) 协议不支持WFS_ERR_PIN_INVALIDDATA (-417) 无效的数据WFS_ERR_PIN_NOTALLOWED (-418) 不允许进行操作WFS_ERR_PIN_NOKEYRAM (-419) Key RAM空间不够WFS_ERR_PIN_NOCHIPTRANSACTIVE (-420) 还没开始ChipTransactionWFS_ERR_PIN_ALGORITHMNOTSUPP (-421) 算法不支持WFS_ERR_PIN_FORMATNOTSUPP (-422) 格式不支持WFS_ERR_PIN_HSMSTATEINVALID (-423) HSMSTATE无效WFS_ERR_PIN_MACINVALID (-424) MAC无效WFS_ERR_PIN_PROTINVALID (-425) 协议无效WFS_ERR_PIN_FORMATINVALID (-426) 格式无效WFS_ERR_PIN_CONTENTINVALID (-427) 内容无效6.TTUWFS_ERR_TTU_FIELDERROR (-701) Field错误WFS_ERR_TTU_FIELDINVALID (-702) Field无效WFS_ERR_TTU_FIELDNOTFOUND (-703) Field未找到WFS_ERR_TTU_FIELDSPECFAILURE (-704) Field语法错误WFS_ERR_TTU_FORMINV ALID (-705) 无效的FormWFS_ERR_TTU_FORMNOTFOUND (-706) Form未找到WFS_ERR_TTU_INV ALIDLED (-707) LED无效WFS_ERR_TTU_KEYCANCELED (-708) 按键取消WFS_ERR_TTU_MEDIAOVERFLOW (-709) Media超域WFS_ERR_TTU_RESNOTSUPP (-710) 分辨率不支持WFS_ERR_TTU_CHARSETDATA (-711) 字符集不对WFS_ERR_TTU_KEYINVALID (-712) 按键无效WFS_ERR_TTU_KEYNOTSUPPORTED (-713) 按键不支持WFS_ERR_TTU_NOACTIVEKEYS (-714) 没有激活任何按键7.SIUWFS_ERR_SIU_INVALID_PORT (-801) 端口无效WFS_ERR_SIU_SYNTAX (-802) 参数错误WFS_ERR_SIU_PORT_ERROR (-803) 执行命令时硬件故障8.CashAcceptorWFS_ERR_CIM_INVALIDCURRENCY (-1300) 无效币种WFS_ERR_CIM_INVALIDTELLERID (-1301) 无效的TellerIDWFS_ERR_CIM_CASHUNITERROR (-1302) 钞箱故障WFS_ERR_CIM_TOOMANYITEMS (-1307) 存款放入的钞票过多WFS_ERR_CIM_UNSUPPOSITION (-1308) 指定的位置不支持WFS_ERR_CIM_SAFEDOOROPEN (-1310) 存款时安全门是打开的WFS_ERR_CIM_SHUTTERNOTOPEN (-1312) Shutter打开失败WFS_ERR_CIM_SHUTTEROPEN (-1313) Shutter已经打开WFS_ERR_CIM_SHUTTERCLOSED (-1314) Shutter已经关闭WFS_ERR_CIM_INVALIDCASHUNIT (-1315) 无效的钞箱编号WFS_ERR_CIM_NOITEMS (-1316) 没有钞票WFS_ERR_CIM_EXCHANGEACTIVE (-1317) 设备处于维护状态WFS_ERR_CIM_NOEXCHANGEACTIVE (-1318) 设备没有处于维护状态WFS_ERR_CIM_SHUTTERNOTCLOSED (-1319) Shutter关闭失败WFS_ERR_CIM_ITEMSTAKEN (-1323) 回收钞票时部分钞票被拿走WFS_ERR_CIM_CASHINACTIVE (-1325) 设备处于存款过程中WFS_ERR_CIM_NOCASHINACTIVE (-1326) 设备没有处于存款过程中WFS_ERR_CIM_POSITION_NOT_EMPTY (-1328) 入钞或出钞口有钞票WFS_ERR_CIM_INVALIDRETRACTPOSITION (-1334) 回收位置无效WFS_ERR_CIM_NOTRETRACTAREA (-1335) 指定的回收位置不可用。
VC中GetLastErro返回的错误码〖0〗-操作成功完成。
〖1〗-功能错误。
〖2〗-系统找不到指定的⽂件。
〖3〗-系统找不到指定的路径。
〖4〗-系统⽆法打开⽂件。
〖5〗-拒绝访问。
〖6〗-句柄⽆效。
〖7〗-存储控制块被损坏。
〖8〗-存储空间不⾜,⽆法处理此命令。
〖9〗-存储控制块地址⽆效。
〖10〗-环境错误。
〖11〗-试图加载格式错误的程序。
〖12〗-访问码⽆效。
〖13〗-数据⽆效。
〖14〗-存储器不⾜,⽆法完成此操作。
〖15〗-系统找不到指定的驱动器。
〖16〗-⽆法删除⽬录。
〖17〗-系统⽆法将⽂件移到不同的驱动器。
〖18〗-没有更多⽂件。
〖19〗-介质受写⼊保护。
〖20〗-系统找不到指定的设备。
〖21〗-设备未就绪。
〖22〗-设备不识别此命令。
〖23〗-数据错误 (循环冗余检查)。
〖24〗-程序发出命令,但命令长度不正确。
〖25〗-驱动器⽆法找出磁盘上特定区域或磁道的位置。
〖26〗-⽆法访问指定的磁盘或软盘。
〖27〗-驱动器找不到请求的扇区。
〖28〗-打印机缺纸。
〖29〗-系统⽆法写⼊指定的设备。
〖30〗-系统⽆法从指定的设备上读取。
〖31〗-连到系统上的设备没有发挥作⽤。
〖32〗-进程⽆法访问⽂件,因为另⼀个程序正在使⽤此⽂件。
〖33〗-进程⽆法访问⽂件,因为另⼀个程序已锁定⽂件的⼀部分。
〖36〗-⽤来共享的打开⽂件过多。
〖38〗-到达⽂件结尾。
〖39〗-磁盘已满。
〖50〗-不⽀持⽹络请求。
〖51〗-远程计算机不可⽤。
〖52〗-在⽹络上已有重复的名称。
〖53〗-找不到⽹络路径。
〖54〗-⽹络忙。
〖55〗-指定的⽹络资源或设备不再可⽤。
〖56〗-已到达⽹络 BIOS 命令限制。
〖57〗-⽹络适配器硬件出错。
〖58〗-指定的服务器⽆法运⾏请求的操作。
〖59〗-发⽣意外的⽹络错误。
〖60〗-远程适配器不兼容。
〖61〗-打印机队列已满。
〖62〗-⽆法在服务器上获得⽤于保存待打印⽂件的空间。
〖63〗-删除等候打印的⽂件。
佳能复印机错误代码细节维修模式:IR2320j/3300开机后按*键,再按2.8(同时按),再按*(几秒内完成)。
iR C2220 按左右键三秒,然后按菜单键[E602-XXYY][补救措施]当执行HD-CLEAR 时,所涉及的分区的所有内容(文件、子目录)将损失。
当机器在执行HD-CLEAN时关闭后实际格式化在机器启动时进行。
这时,启动屏幕显示进程条,其边缘在大约5min内达到终点。
确定不要在进程条移动时关闭电源。
此功能(即模式项)无法用于BOOTDEV 和DOSDEV4 ;要重新格式化这2个分区的任何一个,必须使用SST。
记住在维修模式中格式化硬盘驱动器必须为完全格式化。
- HD-CHECK如果当数据写入到硬盘驱动器时切断电源,有可能发生扇区写入中止。
当在这样的扇区上运行HD-CHECK 时,将进行维修,但扇区中的所有数据将丢失。
写入中止的扇区可仅通过HDD-CHECK (0)进行维修;如果类型- 类型不为0,任务将限于FS水平的检查。
如果含有控制区的一个重要扇区出现写入中止的扇区,则无法修复;您必须执行硬盘驱动器格式化。
- 更换硬盘驱动器1. 关闭主开关。
2. 连接新的硬盘驱动器。
3. 在安全模式中启动机器。
4. 连接SST,并执行完全格式化。
5. 使用SST,下l 载系统软件(系统、语言、RUI)。
6. 关闭然后再打开电源。
(机器启动可能需要花费大约5min)清E000000-000代码:开机后按*键,再按2.8(同时按),再按*(几秒内完成)。
按COPIER-FUNCTION-CLEAR-ERR-OK。
关机再打开。
所有错误可以用finderr+错误代码查到,英文的,这里中文注释便于理解。
-100 错误的描述:C—ISAM错误;向具有唯一索引的字段加入一个重复值。
系统的操作:该语句不被处理。
更正的方法:检查是否用iswrite,isrewrite,isrewcurr或isaddindex的方法,向一个具有唯一索引的字段加入一重复值。
-101 错误的描述:C-ISAM错误;文件没有打开。
系统的操作:该语句不被处理。
更正的方法:检查C-ISAM错误:C-ISAM文件是否已用isopen调用打开,或者是否向一个以只读打开的C-ISAM文件中执行写操作。
-102 错误的描述:C—ISAM错误:C—ISAM函数含有非法参数系统的操作:该语句不被处理更正的方法:检查C—ISAM调用的第一个参数,是否超出相应的值域-103 错误的描述:C—ISAM错误;非法的关键字说明(太多的分量或太长)系统的操作:该语句不被处理。
更正的方法:检查组成该关键字说明的一个或多个元素,是否超出相应的值域。
(每个关键字的说明最多允许8个分量和120个字符)-104 错误的描述:C—ISAM错误:打开文件太多系统的操作:该语句不被处理。
更正的方法:在UNIX系统中(以及多数DOS系统中),每个进程打开文件夹的最大个数为20。
-105 错误的描述:C—ISAM错误:C—ISAM文件格式有误。
系统的操作:该语句不被处理。
更正的方法:C—ISAM文件的格式已被破坏,对该文件运行bcheck程序,修复被破坏了的索引。
如果bcheck不能修复该文件,须从后援存储介质上重新装入数据。
-106 错误的描述:C—ISAM错误;非互斥访问。
系统的操作:该语句不被处理。
更正的方法:当要增加或删除一个索引时,必须以互斥访问打开文件。
-107 错误的描述:C—ISAM错误:记录被锁住。
系统的操作:该语句不被处理。
更正的方法:由该调用请求的文件或记录不能被访问,这是因为该文件被其它用户锁住。
[技巧]用友T3最常见的问题——解决方法【易学易懂】1. 安装用友T3标准版时提示,运行时错误429解决方案:开始——运行——regsvr32 scrrun.dll2.在系统管理中无法备份,提示路径不存在解决方案:修改我的电脑属性中的高级-环境变量,将上面和下面的两个TEMP的值设为一致3.在用友T3 记账时或者预览凭证时出现“运行错误91”解决方案:1.更改系统环境变量中用户变量的Tmp变量值.具体方法:首先在C盘下建立一个空文件夹,更名为temp,然后在‘我的电脑处’单击鼠标右键,属性里点高级,然后点‘环境变量’,将temp和tmp 的值都修改为才c:\temp(通过点‘编辑’按钮进行修改)2.删除操作系统路径\Documents and Settings\XXX\Local Settings\Temp 下的ZWSQLTemp.mdb文件,其中XXX表示系统登陆帐户3.如果以上方法都不行,请检查登陆操作系统的用户是否具有超级用户以上的权限,若没有,请添加。
4.进入软件报运行时错误429,ActiveX 部件不能创建对象。
解决方案:先在开始——运行输入regsvr32 "C:\windows\system32\scrrun.dllregsvr32 "C:\Program Files\Common Files\Microsoft Shared\DAO\dao360.dll提示注册成功后即可。
5.SQL server 在SQL没有设定SA密码的时候打开T3系统管理出现超级用户口令错误,无法连接用友财务通。
解决方案:1.首先退出SQL server服务管理器2.打开任务管理器,把相关的SQL进程都关闭3.菜单——运行输入osql -E -Q "exec sp_password NULL,NULL,'sa'";即可解决6.填制凭证摘要的时候点击放大镜出现DLL加载错误。
ContentsNoCONTENTSRECORD OF REVISIONS1 GENERAL DESCRIPTION2 ABSOLUTE MAXIMUM RATINGS3 ELECTRICAL SPECIFICATION3-1 ELECTRIACL CHARACTERISTICS3-2 INTERFACE CONNECTIONS3-3 SIGNAL TIMING SPECIFICATION3-4 SIGNAL TIMING WAVEFORMS3-5 COLOR INPUT DATA REFERENCE3-6 POWER SEQUENCE3-7 BACKLIGHT SPECIFICATION4 OPTICAL SPECIFICATION5 MECHANICAL CHARACTERISTICS6 RELIABILITY TEST ITEMS7 INTERNATIONAL STANDARD7-1 SAFETY7-2 EMC8 PACKING8-1 DEFINITION OF LABEL8-2 PACKING METHODS8-3 PALLET AND SHIPMENT INFORMATION9 PRECAUTIONS9-1 MOUNTING PRECAUTIONS9-2 OPERATING PRECAUTIONS9-3 ELECTROSTATIC DISCHARGE CONTROL9-4 PRECAUTIONS FOR STRONG LIGHT EXPOSURE9-5 STORAGE9-6 HANDLING PRECAUTIONS FOR PROTECT FILMRecord of RevisionVersion Date Page Description0.1 2010/03/19 First release0.2 2010/04/01 7 Delete Note 67 Modify “ Note 7 Note 6 “ & modify “ the brightness of CCFL will drop and the life time of CCFL will be reduced the brig htness of LED will drop and the life time of LED will be reduce d “7 Modify “Note 8 Note 7“ & delete “ Specified values are for a single lamp only which is aligned horizontally”28 Modify “ Brightness of CCFL Brightness of module “ 0.3 2010/04/14 21 Update front view 2D drawing22 Update back view 2D drawing1.0 2010/05/28 13 Update power sequence t3 Max 45013 Add power sequence t8 & t917 Update Contrast Ratio typical 4,00021 Update front view 2D drawing22 Update back view 2D drawing27 Update Pallet and Shipment Information1. General DescriptionThis specification applies to the 31.5 inch Color TFT-LCD Module T315XW06 V0. This LCD module has a TFT active matrix type liquid crystal panel 1,366 x 768 pixels, and diagonal size of 31.5 inch. This module supports 1,366 x 768 mode. Each pixel is divided into Red, Green and Blue sub-pixels or dots which are arranged in vertical stripes. Gray scale or the brightness of the sub-pixel color is determined with a 8-bit gray scale signal for each dot.The T315XW06 V0 has been designed to apply the 8-bit 1 channel LVDS interface method. It is intended to support displays where high brightness, wide viewing angle, high color saturation, and high color depth are very important.General InformationItems Specification Unit Note Active Screen Size 31.5 inchDisplay Area 697.685 (H) x 392.256(V) mmOutline Dimension 741.4 (H) x 435.8 (V) x 16.8 (D) mm Front Bezel to T-con ShieldingDriver Element a-Si TFT active matrixDisplay Colors 8 bit, 16.7M colorNumber of Pixels 1,366 x 768 pixelPixel Pitch 0.51075 mmPixel Arrangement RGB vertical stripeDisplay Operation Mode Normally BlackSurface Treatment Anti-Glare, 3H Haze=11%2. Absolute Maximum RatingsThe followings are maximum values which, if exceeded, may cause faulty operation or damage to the unitItem Symbol Min Max Unit Conditions Logic/LCD Drive Voltage Vcc -0.3 14 [Volt] Note 1Input Voltage of Signal Vin -0.3 4 [Volt] Note 1Operating Temperature TOP 0 +50 [o C] Note 2Operating Humidity HOP 10 90 [%RH] Note 2Storage Temperature TST -20 +60 [o C] Note 2Storage Humidity HST 10 90 [%RH] Note 2Panel Surface Temperature PST -- 65 [o C] Note 3Note 1: Duration:50 msec.Note 2 : Maximum Wet-Bulb should be 39 and No condensation.℃The relative humidity must not exceed 90% non-condensing at temperatures of 40or less. At temperatures℃greater than 40, the wet bulb temperature must not exceed 39.℃℃Note 3: Surface temperature is measured at 50℃ Dry condition3. Electrical SpecificationThe T315XW06 V0 requires two power inputs. One is employed to power the LCD electronics and to drive the TFT array and liquid crystal. The second input for BLU is to power inverter.3-1 Electrical CharacteristicsValueParameterSymbolMin. Typ. Max Unit Note LCDPower Supply Input Voltage V DD 10.8 12 13.2 V DC 1 Power Supply Input Current I DD -- 0.3 -- A 2 Power Consumption P C -- 3.6 -- Watt 2 Inrush CurrentI RUSH -- 2 3 A 3 Differential Input High Threshold VoltageV TH -- -- +100 mV 4 Differential Input Low Threshold Voltage V TL -100 -- -- mV 4 LVDS InterfaceInput Common Mode Voltage V ICM 1.1 1.25 1.4 V DC 4 Input High Threshold VoltageV IH (High) 2.7--3.3V DC--CMOS InterfaceInput Low Threshold Voltage V IL (Low) 0 -- 0.6 V DC -- Backlight Power Consumption P BL -- 37.2 -- Watt -- Life Time30,000----Hours7Note :1. The ripple voltage should be controlled under 10% of V CC2. Test Condition:(1) V DD = 12.0V (2) Fv = 60Hz(3) F CLK = 80 Mhz (typ.), 86Mhz (max) (4) Temperature = 25 ℃ (5) Test Pattern : White Pattern3. Measurement condition : Rising time = 400usDD4. V ICM = 1.25VV0V5. Input Channel Pair Skew Margin6. The relative humidity must not exceed 80% non-condensing at temperatures of 40℃or less. Attemperatures greater than 40℃, the wet bulb temperature must not exceed 39℃. When operate at low temperatures, the brightness of LED will drop and the life time of LED will be reduced.7. The lifetime is defined as the time which luminance of LED is 50% compared to its original value.[Operating condition: Continuous operating at Ta = 25±2℃]T315XW06 V0 Product SpecificationRev. 1.0 3-2 Interface ConnectionsLCD Connector - LVDS connector on transfer board : Starconn 093G30-B0001A-1PIN Symbol Description1 V DD Power Supply, +12V DC Regulated2 V DD Power Supply, +12V DC Regulated3 V DD Power Supply, +12V DC Regulated4 V DD Power Supply, +12V DC Regulated5 GND Ground6 GND Ground7 GND Ground8 GND Ground9 LVDS_SEL Open/High(3.3V) for NS, Low(GND) for JEIDA10 Reserved AUO Internal Use Only11 GND Ground12 CH1_0- LVDS Channel 1, Signal 0-13 CH1_0+ LVDS Channel 1, Signal 0+14 GND Ground15 CH1_1- LVDS Channel 1, Signal 1-16 CH1_1+ LVDS Channel 1, Signal 1+17 GND Ground18 CH1_2- LVDS Channel 1, Signal 2-19 CH1_2+ LVDS Channel 1, Signal 2+20 GND Ground21 CH1_CLK- LVDS Channel 1, Clock -22 CH1_CLK+ LVDS Channel 1, Clock +23 GND Ground24 CH1_3- LVDS Channel 1, Signal 3-25 CH1_3+ LVDS Channel 1, Signal 3+26 GND Ground27 Reserved AUO Internal Use Only28 Reserved AUO Internal Use Only29 GND Ground30 GND GroundT315XW06 V0 Product SpecificationRev. 1.0LVDS Option = High/Open NSC lockC H x _C H x _C H x _C H x _C H x _C H x _C H x _C H x _Note: x = 1, 2, 3, 4…LVDS Option = Low JEIDAC lockC H x _C H x _C H x _C H x _C H x _C H x _C H x _C H x _Note: x = 1, 2, 3, 4…T315XW06 V0 Product SpecificationRev. 1.0 3-3 Signal Timing SpecificationThis is the signal timing required at the input of the user connector. All of the interface signal timing should be satisfied with the following specifications for its proper operation.Signal Item Symbol Min. Typ. Max UnitPeriod Tv 784 810 1015 ThVertical SectionActive Tdisp (v) 768 ThBlanking Tblk (v) 16 42 247 ThPeriod Th 1460 1648 2000 Tclk Horizontal SectionActive Tdisp (h) 1366 TclkBlanking Tblk (h) 94 282 634 TclkClock Frequency Fclk=1/Tclk 50 80 86 MHzVertical Frequency Frequency Fv 47 60 63 Hz Horizontal Frequency Frequency Fh 43 48 53 KHz Notes:(1) Display position is specific by the rise of DE signal only.Horizontal display position is specified by the rising edge of 1st DCLK after the rise of 1st DE, is displayed on the left edge of the screen.(2) Vertical display position is specified by the rise of DE after a “Low” level period equivalent to eight times ofhorizontal period. The 1st data corresponding to one horizontal line after the rise of 1st DE is displayed at the top line of screen.(3) If a period of DE “High” is less than 1,366 DCLK or less than 768 lines, the rest of the screen displays black.(4) The display position does not fit to the screen if a period of DE “High” and the effective data period do notsynchronize with each other.T315XW06 V0 Product Specification Rev. 1.0Tv Tblk(v) Th DE Tdisp(v)M pixel M pixel M pixelRGB DataInvalid DataLine NLine 1Line 2Line 3Line 4Line NInvalid DataN L in eCLK Tclk Th Tdisp(h) DETblk(h)3-4 Signal Timing WaveformsCH1Pixel M-3Pixel M-2Pixel M-1Pixel MInvalid DataPixel 1Pixel 2Pixel 3Pixel 4Pixel 5Pixel 6Pixel M-2Pixel M-1Pixel MInvalid DataPixel 1Pixel 2© Copyright AUO Optronics Corp. 2009 All Rights Reserved.Page 11 / 29T315XW06 V0 Product Specification Rev. 1.03-5 Color Input Data ReferenceThe brightness of each primary color (red, green and blue) is based on the 8 bit gray scale data input for the color; the higher the binary input, the brighter the color. The table below provides a reference for color versus data input. Color Data Reference Input Color Data Color RED MSB LSB MSB GREEN LSB MSB BLUE LSBR7 R6 R5 R4 R3 R2 R1 R0 G7 G6 G5 G4 G3 G2 G1 G0 B7 B6 B5 B4 B3 B2 B1 B0 Black Red(255) Green(255) Basic Color Blue(255) Cyan Magenta Yellow White RED(000) RED(001) R ---RED(254) RED(255) GREEN(000) GREEN(001) G ---GREEN(254) GREEN(255) BLUE(000) BLUE(001) B ---BLUE(254) BLUE(255) 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1 1 1 1 1 1 1 0 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1 0 0 1 1 0 0 1 1 0 0 1 1 0 0 1 1 0 0 1 1 0 0 1 1 0 0 0 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 0 0 1 1 0 0 1 1 0 0 1 1 0 0 1 1 0 0 1 1 0 0 1 1 0 0 0 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 0 0 0 1 1 1 0 0 0 1 0 0 0 1 1 1 0 0 0 1 0 0 0 1 1 1 0 0 0 1 0 0 0 1 1 1 0 0 0 1 0 0 0 1 1 1 0 0 0 1 0 0 0 1 1 1 0 0 0 1 0 0 0 1 1 1 0 0 0 1 0 0 0 1 1 1 0 1 0 0 1 0 1 0 1 1 0 0 0 0 1 0 1 0 1 1 0 0 0 0 1 0 1 0 1 1 0 0 0 0 1 0 1 0 1 1 0 0 0 0 1 0 1 0 1 1 0 0 0 0 1 0 1 0 1 1 0 0 0 0 1 0 1 0 1 1 0 0 0 0 1 0 1 0 1 1 0 0 0 0 0 1 1 1 0 1 0 0 0 0 0 1 1 1 0 1 0 0 0 0 0 1 1 1 0 1 0 0 0 0 0 1 1 1 0 1 0 0 0 0 0 1 1 1 0 1 0 0 0 0 0 1 1 1 0 1 0 0 0 0 0 1 1 1 0 1 0 0 0 0 0 1 1 1 0 1 0 0© Copyright AUO Optronics Corp. 2009 All Rights Reserved.Page 12 / 29T315XW06 V0 Product Specification Rev. 1.03-6 Power Sequence for LCDValues Parameter Min. t1 t2 t3 t4 t5 t6 t7 t8 t9 0.4 0.1 450 0*1Unit Type. ------------------Max. 30 50 --------*2ms ms ms ms ms ms ms ms ms0 --500 10 0--50 ---Note: (1) T4=0 : concern for residual pattern before BLU turn off. (2) T6 : voltage of VDD must decay smoothly after power-off. (customer system decide this value)© Copyright AUO Optronics Corp. 2009 All Rights Reserved.Page 13 / 29T315XW06 V0 Product Specification Rev. 1.03-7Backlight SpecificationThe backlight unit contains 1-side lightbar.3-7-1 Electrical SpecificationSpec Item 1 2 3 4 Input Voltage Input Current Input Power Inrush Current Symbol VDDB IDDB PDDB IRUSH ON 5 On/Off Control Voltage VBLON OFF IBLON MAX V_EPWM MIN I_EPWM D_EPWM F_EPWM VDDB=24V VDDB=24V VDDB=24V VDDB=24V 0 10 140 180 0.8 2 100 240 mADC % Hz VDDB=24V 0 VDDB=24V VDDB=24V 2 0.8 1.5 5.5 VDC 3 mA Condition Min VDDB=24V VDDB=24V VDDB=24V 22.8 --2 Typ 24 1.55 37.2 Max 25.2 1.71 41.1 7 5.5 VDC VDC ADC W ADC 1 1 2 Unit Note67On/Off Control Current External PWM Control Voltage External PWM Control Current89 External PWM Duty Ratio 10 External PWM FrequencyNote 1 : Dimming ratio= 100% (MAX) Ta=25±5 , Turn on for 45minutes Note 2: Measurement condition Rising time = 20ms (VDDB : 10%~90%); Note 3: Less than10% dimming control is functional well and no backlight shutdown happened© Copyright AUO Optronics Corp. 2009 All Rights Reserved.)℃(Page 14 / 29T315XW06 V0 Product Specification Rev. 1.03-7-2 Interface ConnectionLED Driver Connector: CI1114M1HR0-NH (Cvilux) Pin No 1 2 3 4 5 6 7 8 9 10 11 Symbol VDDB VDDB VDDB VDDB VDDB BLGND BLGND BLGND BLGND BLGND DET Description Operating Voltage Supply, +24V DC regulated Operating Voltage Supply, +24V DC regulated Operating Voltage Supply, +24V DC regulated Operating Voltage Supply, +24V DC regulated Operating Voltage Supply, +24V DC regulated Ground and Current Return Ground and Current Return Ground and Current Return Ground and Current Return Ground and Current Return BLU status detection Normal : 0~0.8V ; Abnormal : Open collector BL On-Off control : 12 VBLON BL On : High/Open (2.0V~5.5V); BL off : Low (0~0.8V/GND) 13 14 NC PDIM NC External PWM (10%~100% Duty, open for 100%) < NC ; at Internal PWM mode>(Note*) IF External PWM function includes 10% dimming ratio. Judge condition as below: (1) Backlight module must be lighted ON normally. (2) All protection function must work normally. (3) Uniformity and flicker could NOT be guaranteed© Copyright AUO Optronics Corp. 2009 All Rights Reserved.Page 15 / 29T315XW06 V0 Product Specification Rev. 1.03-7-3 Power Sequence for LED Driver90%24V(typ.)90%Power Input for BLU (VDDB)10%T1T2T5Dimming Control Signal (VDIM)T3T4BLU On/Off Enable (VBLON)Dip condition for LED DriverPower Input for BLU (VDDB)T6VDDB(typ.)*0.8Parameter Min T1 T2 T3 T4 T5 T6 20 500 250 0 1 -Value Typ Max 10Units ms ms ms ms ms msNote 1: There is no problem for LED Driver operation if I2T spec of fuse is satisfied even though T1 is out of spec© Copyright AUO Optronics Corp. 2009 All Rights Reserved.Page 16 / 29T315XW06 V0 Product Specification Rev. 1.04. Optical SpecificationOptical characteristics are determined after the unit has been ‘ON’ and stable for approximately 45 minutes in a dark environment at 25° The values specified are at an approximate distance 50cm from the LCD surface at a C. viewing angle of φ and θ equal to 0° .Fig 1 presents additional information concerning the measurement equipment and method.SR3 or equivalentParameter Contrast Ratio Surface Luminance (White) Luminance Variation Response Time (G to G) Color Gamut RedSymbol Min. CR LWH δWHITE(9P) Tγ NTSC RX RY 3,200 350 ----Values Typ. 4,000 400 -6.5 72 0.64 0.33 0.31 Typ.-0.03 0.62 0.15 0.06 0.280 0.290 ----89 89 89 89 ----Typ.+0.03 Max --1.33 ---Unit -cd/m -Ms % --------degree degree degree degree2Notes 1 2 3 4 ---------5 5 5 5Green Color Coordinates BlueGX GY BX BYWhiteWX WYx axis, right(φ=0° ) Viewing Angle x axis, left(φ=180° ) y axis, up(φ=90° ) y axis, down (φ=270° )θr θl θu θd© Copyright AUO Optronics Corp. 2009 All Rights Reserved.Page 17 / 29T315XW06 V0 Product Specification Rev. 1.0Note: 1. Contrast Ratio (CR) is defined mathematically as: Contrast Ratio= Surface Luminance of Lon5 Surface Luminance of Loff52. Surface luminance is luminance value at point 5 across the LCD surface 50cm from the surface with all pixels displaying white. From more information see FIG 2. When lamp current IH = 11mA. the luminance with all pixels displaying white at center 5 location. 3. The variation in surface luminance, δWHITE is defined (center of Screen) as: δWHITE(9P)= Maximum(Lon1, Lon2,…,Lon9)/ Minimum(Lon1, Lon2,…Lon9) LWH=Lon5 where Lon5 isluminance ratio (0%,25%,50%,75%,100% brightness matrix) and is based on Fv=60Hz to optimize.Measured Response Time 0% 25% Start 50% 75% 100%25% to 0% 50% to 0% 75% to 0% 100% to 0% 50% to 25% 75% to 25% 100% to 25%5. Viewing angle is the angle at which the contrast ratio is greater than 10. The angles are determined for the horizontal or x axis and the vertical or y axis with respect to the z axis which is normal to the LCD surface. For more information see FIG4.FIG. 2 Luminance© Copyright AUO Optronics Corp. 2009 All Rights Reserved.γ4. Response time Tis the average time required for display transition by switching the input signal for fiveTarget 0% 25%0% to 25%50%0% to 50% 25% to 50%75%0% to 75% 25% to 75% 50% to 75%100%0% to 100% 25% to 100% 50% to 100% 75% to 100%75% to 50% 100% to 50% 100% to 75%VH/2123456H78H/6 V/6 V/2Page 18 / 29T315XW06 V0 Product Specification Rev. 1.0FIG.3 Response Time The response time is defined as the following figure and shall be measured by switching the input signal for “any level of grey(bright) “ and “any level of gray(dark)”. Any level of gray (Bright) Any level of gray (Dark) Any level of gray (Bright)0%, 25%, 50%, 75%, 100%0%, 25%, 50%, 75%, 100%0%, 25%, 50%, 75%, 100%TimeFIG.4 Viewing Angle© Copyright AUO Optronics Corp. 2009 All Rights Reserved.γ γ γ γγ γ γ γT( F)T( R)Page 19 / 29%01%09Photodetector OutputT315XW06 V0 Product Specification Rev. 1.05. Mechanical CharacteristicsThe contents provide general mechanical characteristics for the model T315XW06 V0. In addition the figures in the next page are detailed mechanical drawing of the LCD.Horizontal Vertical Outline Dimension Depth Horizontal Bezel Opening Vertical Horizontal Active Display Area Vertical Weight Surface Treatment741.4mm 435.8mm 16.8mm (Front Bezel to T-con Shielding) 705.4mm 399.8mm 697.685mm 392.256mm 6,000 g (Typ.) AG, Haze=11%, 3H© Copyright AUO Optronics Corp. 2009 All Rights Reserved.Page 20 / 296. Reliability Test ItemsNo. Test Item Q’ty Condition1 High temperature storage test 3 60℃, 300hrs2 Low temperature storage test3 -20℃, 300hrs3 High temperature operation test 3 50℃, 300hrs4 Low temperature operation test 3 -5℃, 300hrs5 Vibration test (non-operation) 3 Wave form : random Vibration level : 1.0G RMS Bandwidth: 10-300Hz Duration: X, Y, Z 10min One time for each direction6 Shock test (non-operation) 3 Shock level: 50GWaveform: half sine wave, 11ms Direction: ±X, ±Y, ±Z, One time each direction7 Vibration test (With carton) 5 Random wave (1.0G RMS, 10-200Hz) 10mins/ each X,Y,Z axes8 Drop test (With carton) 5 Height: 38.1 cm1 corner, 3 edges, 6 surfaces (ASTM-D5276)7. International Standard7-1 Safety(1) UL 60950-1, UL 60065; Standard for Safety of Information Technology Equipment Including electricalBusiness Equipment.(2) IEC 60950-1 : 2001, IEC 60065:2001 ; Standard for Safety of International Electrotechnical Commission(3) EN 60950 : 2001+A11, EN 60065:2002+A1:2006; European Committee for Electrotechnical Standardization(CENELEC), EUROPEAN STANDARD for Safety of Information Technology Equipment Including Electrical Business Equipment.7-2 EMC(4) ANSI C63.4 “Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and ElectricalEquipment in the Range of 9kHz to 40GHz. “American National standards Institute(ANSI), 1992(5) C.I.S.P.R “Limits and Methods of Measurement of Radio Interface Characteristics of Information TechnologyEquipment.” International Special committee on Radio Interference.(6) EN 55022 “Limits and Methods of Measurement of Radio Interface Characteristics of InformationTechnology Equipment.” European Committee for Electrotechnical Standardization. (CENELEC), 19988. Packing8-1 Definition of LabelPanel Label*xxxxxxxxxxxx-xxxxxx*Green mark description(1) For Pb Free Product, AUO will add for identification.(2) For RoHs compatible products, AUO will add RoHS for identification.Note: The green Mark will be present only when the green documents have been ready by AUO internal green team. (definition of green design follows the AUO green design checklist.)Carton Label*xxxxxxxxxxxx-xxxxxx*Panel Unique IDAUO Internal Use8-2 Packing Method5pcs ModulesCushion set” H ” Tape8-3 Pallet and Shipment InformationSpecificationItemQuantityDimensionWeight (kg) PackingRemark1 Packing BOX 5pcs/box 828(L)mm*283W)mm*536(H)mm 36.52 Pallet11150(L)mm*840(W)mm*132(H)mm133 Boxes per Pallet8 boxes/Pallet4 Panels per Pallet 40 pcs/pallet1150(L)mm*840(W)mm*1204(H)mm3055Pallet after packingN/A1150(L)mm*840(W)mm*2408(H)mm Double Pallet6108. PrecautionsPlease pay attention to the followings when you use this TFT LCD module.9-1 Mounting Precautions(1) You must mount a module using holes arranged in four corners or four sides.(2) You should consider the mounting structure so that uneven force (ex. twisted stress) is not applied to module.And the case on which a module is mounted should have sufficient strength so that external force is not transmitted directly to the module.(3) Please attach the surface transparent protective plate to the surface in order to protect the polarizer.Transparent protective plate should have sufficient strength in order to the resist external force.(4) You should adopt radiation structure to satisfy the temperature specification.(5) Acetic acid type and chlorine type materials for the cover case are not desirable because the formergenerates corrosive gas of attacking the polarizer at high temperature and the latter cause circuit broken by electro-chemical reaction.(6) Do not touch, push or rub the exposed polarizer with glass, tweezers or anything harder than HB pencil lead.And please do not rub with dust clothes with chemical treatment. Do not touch the surface of polarizer for bare hand or greasy cloth. (Some cosmetics are detrimental to the polarizer.)(7) When the surface becomes dusty, please wipe gently with absorbent cotton or other soft materials likechamois soaks with petroleum benzene. Normal-hexane is recommended for cleaning the adhesives used to attach front/ rear polarizer. Do not use acetone, toluene and alcohol because they cause chemical damage to the polarizer.(8) Wipe off saliva or water drops as soon as possible. Their long time contact with polarizer causesdeformations and color fading.(9) Do not open the case because inside circuits do not have sufficient strength.9-2 Operation Precautions(1) The device listed in the product specification sheets was designed and manufactured for TV application(2) The spike noise causes the mis-operation of circuits. It should be lower than following voltage:V=±200mV(Over and under shoot voltage)(3) Response time depends on the temperature. (In lower temperature, it becomes longer..)(4) Brightness of module depends on the temperature. (In lower temperature, it becomes lower.) And in lowertemperature, response time (required time that brightness is stable after turned on) becomes longer.(5) Be careful for condensation at sudden temperature change. Condensation makes damage to polarizer orelectrical contacted parts. And after fading condensation, smear or spot will occur.(6) When fixed patterns are displayed for a long time, remnant image is likely to occur.(7) Module has high frequency circuits. Sufficient suppression to the electromagnetic interference shall be doneby system manufacturers. Grounding and shielding methods may be important to minimize the interface.9-3 Electrostatic Discharge ControlSince a module is composed of electronic circuits, it is not strong to electrostatic discharge. Make certain that treatment persons are connected to ground through wristband etc. And don’t touch interface pin directly.9-4 Precautions for Strong Light ExposureStrong light exposure causes degradation of polarizer and color filter.9-5 StorageWhen storing modules as spares for a long time, the following precautions are necessary.(1) Store them in a dark place. Do not expose the module to sunlight or fluorescent light. Keep the temperaturebetween 5 and 35 at normal humidity.℃℃(2) The polarizer surface should not come in contact with any other object. It is recommended that they bestored in the container in which they were shipped.9-6 Handling Precautions for Protection Film(1) The protection film is attached to the bezel with a small masking tape. When the protection film is peeled off,static electricity is generated between the film and polarizer. This should be peeled off slowly and carefully by people who are electrically grounded and with well ion-blown equipment or in such a condition, etc.(2) When the module with protection film attached is stored for a long time, sometimes there remains a verysmall amount of glue still on the bezel after the protection film is peeled off.(3) You can remove the glue easily. When the glue remains on the bezel or its vestige is recognized, please wipethem off with absorbent cotton waste or other soft material like chamois soaked with normal-hexane.。
