【思唯网络】华为以太网链路聚合原理及配置一、组网拓扑二、配置手工模式下Eth-Trunk的建立、成员接口的加入由手工配置，没有LACP（链路聚合控制协议）的参与。

当需要在两个直连设备间提供一个较大的链路带宽而设备又不支持LACP时，可以使用手工模式。

同时手工模式下，所有的活动链路都参与数据转发并分担流量。

1、手动模式配置<HUAWEI> system-view[HUAWEI] sysname SwitchA[SwitchA] interface eth-trunk 1 //创建ID为1的Eth-Trunk接口[SwitchA-Eth-Trunk1] trunkport gigabitethernet 0/0/1 to 0/0/3 //在Eth-Trunk1接口中加入GE0/0/1到GE0/0/3三个成员接口[SwitchA-Eth-Trunk1] port link-type trunk //设置接口链路类型为trunk，接口缺省链路类型不是trunk口[SwitchA-Eth-Trunk1] port trunk allow-pass vlan 5 10[SwitchA-Eth-Trunk1] load-balance src-dst-mac //配置Eth-Trunk1基于源MAC地址与目的MAC地址进行负载分担[SwitchA-Eth-Trunk1] quit2、手动模式配置验证在任意视图下执行display eth-trunk 1命令，检查Eth-Trunk是否创建成功，及成员接口是否正确加入。

[SwitchA] display eth-trunk 1Eth-Trunk1's state information is:WorkingMode: NORMAL Hash arithmetic: According to SA-XOR-DALeast Active-linknumber: 1 Max Bandwidth-affected-linknumber: 8Operate status: up Number Of Up Port In Trunk: 3--------------------------------------------------------------------------------PortName Status WeightGigabitEthernet0/0/1 Up 1GigabitEthernet0/0/2 Up 1GigabitEthernet0/0/3 Up 1从以上信息看出Eth-Trunk 1中包含3个成员接口GigabitEthernet0/0/1、GigabitEthernet0/0/2和GigabitEthernet0/0/3，成员接口的状态都为Up。
