J Sign Process SystDOI 10.1007/s11265-011-0650-6Instruction Cache Locking for Embedded Systems using Probability ProfileTiantian Liu· Minming Li · Chun Jason XueReceived: 27 August 2010 / Revised: 31 August 2011 / Accepted: 21 November 2011© Springer Science+Business Media, LLC 2011Abstract Cache is effective in bridging the gap between processor and memory speed. It is also a source of unpredictability because of its dynamic and adaptive behavior. A lot of modern processors provide cache locking capability which locks instructions or data of a program into cache so that a more precise estimationof execution time can be obtained. The selection of instructions or data to be locked in cache has dramatic influence on the system performance. For real-time systems, cache locking is mostly utilized to improve the Worst-Case Execution Time (WCET). However, Average-Case Execution Time (ACET) is also an im-portant criterion for some embedded systems, espe-cially for soft real-time embedded systems, such as image processing systems. This paper aims to utilize instruction cache (I-Cache) locking technique to guar-antee a minimized estimable ACET for embedded sys-tems by exploring the probability profile information.A Probability Execution Flow Tree (PEFT) is intro-duced to model an embedded application with runtime profile information. The static I-Cache locking problem is proved to be NP-Hard and two kinds of locking, fully locking and partially locking, are proposed to find the instructions to be locked. Dynamic I-Cache locking can further improve the ACET. For dynamic I-Cache locking, an algorithm that leverages the application’s branching information is proposed. All the algorithms are executed during the compilation time and the re-sults are applied during the runtime. ExperimentalT. Liu (B) · M. Li · C. J. XueDepartment of Computer Science, City University ofHong Kong, Kowloon, Hong Konge-mail: tiantianster@ results show that the proposed algorithms reduce the ACET of embedded applications further compared to state-of-the-art techniques.Keywords Cache locking· Probability Profile · ACET1 IntroductionCaches are known for their effectiveness in bridging the gap between processor and memory speed, but noto-rious for their unpredictability. With the utilization of cache, the Average-Case Execution Time (ACET) ofan application is improved dramatically. However, the unpredictable dynamic behavior of cache also makesthe estimation of an application’s ACET difficult and imprecise. ACET is an important metric for the designof some embedded systems[1, 2 ], especially for soft real-time embedded systems, such as image processing systems. With the use of cache, the ACET of an ap-plication is most likely to be overestimated, which in turn leads to an unnecessary increased hardware costof embedded systems.To remedy the unpredictability of cache, cache lock-ing technique is provided by a wide selection of modern processors, such as ARM9 series[3 ], MIPS32 series [4] and MCF5249[5]. Cache locking is to select andlock specific content of a program or data in a cache.For an application-specific embedded system, cache locking can effectively guarantee the precision of some cache hit/miss behaviors, thus a tighter ACET bound could be obtained. Embedded systems are mostly application-specific, which means that the applicationto be executed on a specific system is known before-hand. This characteristic enables researchers to utilizeJ Sign Process Syst the application’s properties to make some informed 2 Related Workdecisions before the execution. Therefore, in this paper,we utilize instruction cache (I-Cache) locking technique Several previous work has been done regarding theto find an estimable minimized ACET for an embedded cache locking problem in embedded systems. The most system based on the probability profiling information related works to this paper are [6, 7]. Both of theof the specific application running on the system. two works target to eliminate conflict miss rate within In this paper, a Probability Execution Flow Tree a cache set to reduce the ACET. Anand et al. [6 ] (PEFT) is introduced to model an embedded applica- devise a cost-benefit model to discover the memory ad- tion’s program with its probability profile information dresses to be locked in the I-Cache. Their experiments and application-specific information. Two schemes of confirm that cache locking is beneficial in improving cache locking are considered: static and dynamic. In average case performance. However, their cost/benefitthe static locking scheme, cache contents are loaded formulation contains some profile information whichat application start-up and remain unchanged until is hard to be obtained or not accurate. Additionally,the end. In the dynamic locking scheme, locked cache they focus on finding the beneficial blocks which are contents can be changed at specific reloading points mapped to the same cache set. This will lead to anbased on the runtime information. The cache can be unbalance between different sets, because some setsfully locked or partially locked. The I-Cache locking may contain more valuable blocks while others may problem in this paper aims to analyze the application not. Liang et al. in [7 ] introduce temporal reuse profile during its compilation time, and select a set of nodes to model the cost and benefit of locking memory blocksto be locked in the I-Cache statically or sets of nodes to in the cache. They propose an optimal algorithm and abe reloaded and locked in the I-Cache dynamically. The heuristic approach that use the temporal reuse profilegoal is to optimize the ACET of an embedded system. to determine the most beneficial memory blocks. How- The contributions of this paper are as follows: ever, each cache set is also analyzed individually intheir work. When implementing their methods, both1. Propose I-Cache locking techniques to minimizeof the two works use the trampolines [8] approach to the average execution time of embedded applica-introduce the locking instruction to the binary code so tions by exploring applications’ statistical profilethat the mapping addresses of the blocks will not be information and application-specific foreknowingchanged.information.Most other researchers utilize I-Cache locking in2. Prove that the static I-Cache locking problem forreal-time applications to guarantee a tighter estimation ACET reduction is an NP-Hard problem, and pro-of Worst-Case Execution Time (WCET). Puaut et al.pose a fully locking algorithm and a partially lock-propose some heuristic methods about I-Cache locking ing algorithm.on minimization of WCET and Worst-Case Utilization 3. Propose an off-line algorithm for the dynamic I-(WCU) [9, 10 ].Campoy et al. use genetic algorithms Cache locking by exploring runtime branching in-for both static locking [11] and dynamic locking [12]i n formation. The outputs of the algorithm are usedmultitask, preemptive real-time systems. Falk et al. [13 ] during runtime.take the changing of worse-case execution path into The remainder of this paper is organized as fol- consideration and adopt a greedy strategy to choose lows. Section 2 presents related work. Section 3 an- instructions into cache. Liu et al. [14] study the static alyzes the cache architecture and presents the PEFT I-Cache locking problem to minimize WCET for real- model of an application. In Section 4, the static I- time embedded systems. The problem is proved to Cache locking problem is formulated using the in- be NP-Hard and optimal algorithms are proposed for teger linear programming model and proved to be subsets of the general problem with special propertiesNP-Hard. Fully locking and partially locking algo- and patterns.rithms are proposed respectively. For the dynamic Scratchpad memory is an alternative to cache. TheI-Cache locking problem, an off-line algorithm us- allocation of code/data to the scratchpad memory ising the static locking results and branching informa- under software control. Significant effort has beention to obtain the dynamic locking decisions is pro- invested in developing efficient allocation techniques posed in Section 5. Cache conflict problem caused for scratchpad memories. [15 , 16 ] aim at reducing theby cache locking is discussed in Section 6.S ection7 ACET of programs through memory access profiles. shows the experimental results compared with previ- Puaut et al. [17] propose an algorithm for off-line con- ous work. Finally, concluding remarks are presented in tents selection of on-chip memory, supporting both the Section 8.locked cache and scratchpad memory. They find thatJ Sign Process Systthe performance of applications using the two types of memory are very close to each other in most cases.Little previous work has explored the statistical in-formation and the foreknowing information of em-bedded applications for the I-Cache locking problem.Liang et al.[18 ] utilize the probability information ofan application for cache configuration design whichis orthogonal to this paper’s work. In[19], an ap-proach for early branch resolution and subsequent fold-ing is presented. The application-specific informationis captured by the micro-architecture through a low-cost reprogrammable hardware, thus attaining the twin benefits of processor standardization and application-specific customization. Several work has used the fore-knowing information to provide scheduling methodsto improve timing performance for embedded systems [20– 22 ].Although there were a number of previous efforts on the cache locking problem, most of them focus on re-ducing the WCET[9–14 ]. The most related work to this paper primarily targets to eliminate conflict miss ratewithin one cache set to improve the ACET[6][7 ]. The unbalanced and random distribution of the beneficialblocks in different sets may weaken their methods. Inthis paper, we consider the problem from a differentangle. We first target to find the most efficient blockswithin the whole block sets to minimize ACET, then we use compilation techniques, such as padding and codepositioning[26] to avoid conflicts among these selected blocks. As concluded in[17 ] that using locked cacheand scratchpad memory are very close to each other in most cases, the algorithms proposed in this paper canalso be applied to scratchpad memory allocation.3 Cache Architecture and Task ModelThis section introduces the notations used in this paper concerning the cache architecture and task model.3.1 Cache ArchitectureCache locking technique is supported by several com-mercial processors[3 ,4], with different implementation methods. Some processors, for example Intel XScale[23] and MPC603E[5 ], allow developers to lock theentire cache. While others, for example RC64574[24], allow developers to lock only part of the cache. Somep rocessors[4 ,23] insert specific cache locking opera-tions into the application’s code to perform locking,while others[5, 24] use specific lock/freeze bits intheir cache control registers to lock each single cacheline content. In this paper, we assume the processor is equipped with an I-Cache with a total size of S.The proposed work is applied to a general architecture based on the above processors, resulting in a cache architecture with the following characteristics:1)I-Cache locking can be applied to each line of theI-Cache, which implies that the I-Cache can betotally locked or partially locked. This capability isprovided by several commercial processors[5, 24]. 2)The I-Cache can be loaded using a cache-fillinginstruction, which is provided by lots of processors[4 ,23 ]. During system start-up, a small routine isexecuted to pre-load the cache using the cache-filling instruction. After pre-loading the blocks, thecache is locked. Under the static locking scheme,the locked cache content will never change. Whileunder the dynamic locking scheme, the cache con-tent could be changed at specific reloading pointsby invoking these cache-filling instructions.3)The I-Cache can be either direct-mapped or set-associative. The mapping from memory space tothe I-Cache, as well as the possibility of cacheconflict within the locking selection are solved byprevious compilation techniques, such as proce-dure re-ordering[25 ], padding and code position-ing[26 ], as discussed in Section6.4)If the processor addresses an instruction that islocked in the I-Cache, this instruction will beserved from the I-Cache, resulting in fast accesstime (hit). If the processor addresses an instructionthat is not locked in the I-Cache, this instructionwill be served from the main memory, resulting inlonger access time (miss).5)This paper focuses on I-Cache locking. Data cacheis assumed to work in a normal fashion.3.2 PEFTIn this paper, a Probability Execution Flow Tree (PEFT) is used to model an embedded application.PEFT embodies the control flow of the application’scode and the profiling information of the applicationso that we can analyze it to find which part of the code should be selected into the I-Cache.Definition 1 A PEFT= (V, E, B) is a weighted tree, where V represents the set of nodes and E representsthe set of edges. B is the set of basic blocks in a program. Each b∈ B is a context-specific code block associated with three attributes: block_miss(b) is the single processing time when basic block b is not in the cache, block_hit(b) is the single processing time when basic block b is in the cache and block_s(b) is theJ Sign Process Systsize of basic block b . Node v ∈ V represents the real execution of a code block b∈ B under a certain context and therefore has two attributes: name(v) = b where b∈ B representing that basic block b is executed in this node and count(v) representing the average number of times b is executed in the current context. Edge evu ∈ E denotes a program control flow from node v to node u. Each edge has one attribute: edge_ prob(evu) which represents the execution probability of this flow. Forevery node v,u|evu∈E edge_ prob (evu) = 1.To generate a PEFT, an algorithm PEFT_CON isused, as shown in Algorithm 1. An application is firstrun in a profile tool, and the probabilities of edges are obtained and recorded in a probability matrix P[v][u]. Then, algorithm EFT_CON in[14]isusedtocon-struct an Execution Flow Tree (EFT)[14 ] (line 1). Fi-nally, we attach the statistical probability to each edge(line 2–4).A PEFT example is shown in Fig.1. Figure1( a)isa segment of the benchmark “Audio beam former”[28]and Fig.1(b) is the corresponding PEFT.Some important features about PEFT are as follows:1)The framework of PEFT is similar to the frame-work of CFG (Control Flow Graph) used in pre-vious research[10 ]. In Algorithm EFT_CON[14],each code line is scanned and different controlflows are processed accordingly. The sequentialcodes are the simplest and are treated as one ba-sic block. For branches, loops and routine calls,we process their bodies recursively and attach theEFTsub obtained to the main EFT. The differencebetween PEFT and CFG is that PEFT is explic-itly defined as a tree with probability informationand other attributes related to cache behavior. Abasic block can be one or more statements in theprogram depending on the context. For example,statement “exit(1)” in this example forms node 3in Fig.1(b).For simplicity, some of the call proce-if (!data_file) {print_usage();exit(1);}if (search_far_field == 1) {max_energy = search_far_field_angles(max_result, data_file, output_file, hamming);} else if (hill_climb == 1) {search_grid(source_location, data_file, output_file, hamming);max_result = (float*) malloc(ANGLE_ENERGY_WINDOW_SIZE*sizeof(float));} else {calc_single_pos(source_location, mic_locations, hamming, data_file, output_file);}exit(0);exit( )3print_usage( )21if (!data_file)6max_result = return of node 57search_far_field_angles( )8max_energy = return of node 75malloc( )exit( ) 12if (search_far_field == 1)49 if (hill_climb == 1)11 calc_single_pos( )14 exit( )10search_grid( )13exit( )95%5%31%69%73%27%(a) A segment of a benchmark [25].(b) Its PEFT.Figure 1 A segment of a benchmark and its PEFT.dures of the PEFT in Fig.1(b) are not presentedrecursively. For example, node 7 is an abstract pre-sentation of routine “search_far_field_angles()” .Algorithm EFT_CON does recursively process thesubroutines.2)In practical systems, the value of block_miss(b)orblock_hit(b) of a basic block b is not an accu-rate value if we consider timing anomalies, cacheand pipeline effects. It can be a range of values.In this paper, we use the average-case value ofblock_miss(b) orblock_hit(b) to form a modelfor solving the locking problem and comparingwith previous works. We run the benchmark sev-eral times using SimpleScalar[29 ] and obtain theprofiling information. From the cache miss/hit in-formation, we can obtain the estimation value ofblock_miss(b) orblock_hit(b).3)Node v has three additional attributesnode_miss(v), node_hit(v) and node_prob(v).node_miss(v) ornode_hit(v) is the real executiontime of node v and can be calculated asnode_miss(v) = block_miss(name(v)) × count (v)or node_hit(v)= block_hit(name(v)) × count(v),depending on whether name(v) is put inthe cache.node_ prob(v) is the executionJ Sign Process Systprobability of node v and can be calculatedas node_ prob(v)=node_prob(u)×edge_prob(euv),where u is the parent of v. It is easy todeduce that node_ prob(v) = node_prob(v0) ×edge_ prob(ev0 u1 )× edge_prob(eu 1 u2 )× ··· ×edge_ prob(euv) for node v along the path fromroot v0 to node v,wherenode_prob(v0) = 1.4)Algorithm EFT_CON gives the main flow of aloop. For a node v in a loop, the execution timeof its basic block could be different between itsfirst execution and each successive repetitionbecause of cache reusing[30]. The value ofnode_miss(v) can be calculated as node_miss(v) =block_miss(name(v)) + block_hit (name(v)) ×(count(v) − 1) which is its execution time underthe uncontrolled cache. The node_hit(v) is stillnode_hit(v) = block_hit(name(v)) × count(v).5)There is a procedure Duplicate() in AlgorithmEFT_CON. If a node v has an indegree(v) of atleast 2, Duplicate() instantiates the structure start-ing from v by indegree(v) times, which ensures thatthe output is a tree. For example, nodes 12, 13and 14 in Fig.1 (b) are duplicating nodes whichare introduced by the procedure Duplicate(). Eachduplicating substructure represents an invocationof the associated basic blocks (in this example,it is code line “exit(0)”), so they have the samename and count value, thus same node_miss(v) andnode_hit(v). With these duplicated nodes, thePEFT structure is still equivalent to EFG[13]or CFG[10] structure. From the definition andEFT_CON algorithm, we know that every path inan EFG or CFG is enumerated in a PEFT, whileevery path in a PEFT corresponds to one possiblepath in an EFG or CFG.3.3 ACET of a PEFTACET is the expected length of the root-leaf pathin a PEFT. Let Pi= (pi0 pi1 ... pil i )be a root-leaf path, where pi0, pi1,..., pili ∈ V and li is thenumber of edges on path Pi.Eachpath Pi has twoattributes length(Pi) and probability(Pi). length(Pi)is defined as the summation of the weights ofnodes on Pi, which represents the execution timeof this path.Let Wreal(v) = (1 − δ(name(v))) ×node_mi s s(v) + δ(name(v)) × node_hit(v),whereδ(name(v)) = 1 if name(v) is put in the cacheandδ(name(v)) = 0 otherwise. The length(Pi) is calculated as length(Pi) =li j=0 Wreal( pij). The other attributeprobability(Pi) represents the execution probability of this path and is calculated as probability(Pi) =li−1j=0 edge_ prob (epij pij+1 ).Table 1 Notations used in this paper.Notation Descriptionb A basic blockblock_s(b)Size of basic block bblock_miss(b)Execution time of basic block b when bis not in cacheblock_hit(b)Execution time of basic block b when bis in cacheblock_ prob(b)Execution weight of basic block beach_sa ving(b)ACET saving of basic block bv A nodename(v)Basic block in node vcount(v)Execution count of basic block in node v node_ prob(v)Execution probability of node vnode_miss(v)Execution time of node v when name(v)is not in cachenode_hit(v)Execution time of node v when name(v)is in cacheWreal(v)Real execution time of node v,is equal to node_miss(v) ornode_hit(v) evu An edgeedge_ prob(evu)Execution probability of edge evuPi A root-leaf pathlength(Pi)Execution time of path Piprobability(Pi)Execution probability of path PiDenote the total number of the root-leaf paths as|P|, then the ACET of a PEFT can be calculated as:|P|i=1length(Pi) × probability(Pi)(1) The notations are summarized in Table1.4 Static I-Cache LockingAs discussed in Section3.1, first we want to find a most efficient locking selection of memory blocks to mini-mize ACET of the application. In this section, we dis-cuss the static locking scheme, where cache contents are loaded at application start-up and remain unchangeduntil the end. We further consider two different locking strategies: fully locking and partially locking, depend-ing on whether or not the whole I-Cache is locked.4.1 Fully LockingThe fully locking means that the whole I-Cache is usedas the locked cache.J Sign Process Syst 4.1.1 Problem FormulationThe ACET minimization problem using static I-Cachelocking can be defined as follows. Given an I-Cache ofsize S and a PEFT representing a given program, theaim is to put a subset of basic blocks into the I-Cacheso that the total size of the chosen basic blocks doesnot exceed S and the ACET of the PEFT is minimized.With Formula1 discussed in Section3.3,w eformulatethe fully static I-Cache locking problem as an integerlinear programming (ILP) instance as follows:min|P|i=1length(Pi) × probability(Pi)s.t.⎧⎪⎪⎪⎪⎪⎪⎨⎪⎪⎪⎪⎪⎪⎩length(Pi) =li j=0(1 − δ(name(v))) × node_miss(v)+δ(name(v)) × node_hit(v)probability(Pi) =li−1j=0 edge_ prob (epij pij+1 )b∈Bblock_s(b) × δ(b) ≤ Sδ(b) ∈{0, 1}The variables in this ILP formulation areδ(b) foreach basic block which can only be equal to 0 or 1.The first two groups of equations give the calculationof length(Pi) and probability(Pi). The third inequalityis I-Cache size limitation. Because we use the lock-ing technique with the entire cache, every time weshould maintain this limitation no matter which kindof mapping is used. Otherwise, we will not be ableto put all the selected nodes to the cache. It is truethat some instructions may be mapped to the samecache line. This cache conflicts may happen with both direct-mapped cache and set-associative cache. We can apply some compiling techniques[26] to solve the cache conflict problem after we have decided which nodes to lock, which will be studied in Section6. The goal ofthe problem is to minimize the ACET for the PEFT by determiningδ(b) for each b ∈ B.4.1.2 Problem AnalysisFor each node v in a PEFT, define its set of outgo-ing edges as OutEdgesv ={evtm |e vtm ∈ E, 1 ≤ m ≤ Mv}, whereMv is the out-degree of node v.Let u representthe preceding node of v and ti represent the successive node of v for a path Pi which has v on it. The terms relating to Wreal(v) (node_miss(v) or node_hit(v))in Formula1 can be combined and further transformedas follows:Pi vWreal(v) × probability(Pi)= Wreal(v)×Pi v(edge_prob(epi0 pi1 )×···× edge_prob(euv)prob(evti )×··· × edge_prob(epili−1pili ))= Wreal(v) × (edge_prob(epi0 pi1 )×···×edge_ prob (eu v)×Pi v&ti=tm1≤m≤Mv(edge_prob(evtm )×···×edge_prob(epili−1pili )))= Wreal(v) × (edge_prob(epi0 pi1 )×··· × edge_prob(euv))= Wreal(v) × node_prob(v)As can be seen from the above, for every node v, the corresponding portion in Formula1 is Wreal(v) ×node_ prob(v).Formula1 can be expressed with regardto node v as:v∈VWreal(v) × node_prob(v)(2)In a PEFT, one basic block can be called by different nodes. In other words, name(u) could be equal toname(v) even when u = v. This scenario is denoted asreusing in this paper. Considering reusing, Formula2can be further transformed into:v∈VWreal(v) × node_prob(v)=v∈V((1 − δ(name(v))) × block_miss(name(v))+ δ(name(v))block_hit(name(v)))× count(v) × node_prob(v)=b∈B(((1 − δ(b)) × block_miss(b) + δ(b)× block_hit(b))v∈V& name(v)=b(count(v)× node_prob(v)))Let block_ prob(b) =v∈V& name(v)=b (count(v) ×node_ prob(v)). It is a constant when a PEFT is given.It represents the execution weight of basic block bappearing on different nodes in a PEFT. It may scaleJ Sign Process Systbigger than 1, so we do not say it is a probability.Finally, Formula1 is reduced to:b∈B((1 − δ(b)) × block_miss(b) + δ(b)× block_hit(b)) × block_prob(b)(3)Define each_sa ving(b) = (block_miss(b) − block_hit(b)) × block_prob(b) which is the ACET saving foran individual b∈ B. The static I-Cache locking prob-lem can be proved to be an NP-Hard problem.Theorem 1 The static I-Cache locking for ACET mini-mization is NP-Hard.Proof We prove that this problem is NP-Hard by areduction from the 0/1 knapsack problem. Given a0/1 knapsack instance, we have the finite set A withweight weight(a) and value value(a) for each a ∈ A,a value threshold K and a total weight limit W.Thestatic I-Cache locking problem is constructed as fol-lows. For each a∈ A,wecreateabasic block ba ∈B with each_sa ving(ba) = value(a) and block_s(ba) = weight(a). This instance can be constructed in polyno-mial time from the 0/1 knapsack instance.Define Total_time_unlock= b a∈B block_miss(b a)×block_ prob(ba).Formula3 can be transformed asTotal_time_unlock− b a∈B δ(b a) × each_saving(b a), whereδ(ba) = 1/0 means whether ba is put intocache or not. The deterministic version of staticI-Cache locking problem is to find whether there is aδ(ba) = 0/1 for every ba ∈ B whichcan achieve:Total_time_unlock− b a∈B δ(b a) ×each_sa ving(ba) ≤ Total_time_unlock − K and b a∈F block_s(b a) × δ(b a) ≤ S.This can be done if and only if there is aδ(a) = 0/1 for every a∈ A such that a∈A δ(a) × value(a) ≥ K and a∈A weight(a) × δ(a) ≤ W. Thus the desired δ(a)for every a∈ A exists for the instance of 0/1 knapsackif and only if aδ(ba) for every ba ∈ B exists for the cor-responding instance of static I-Cache locking problem.4.1.3 AlgorithmWhen we consider to lock all the I-Cache of size S,a dynamic programming method can be used to solvethe 0/1 knapsack problem optimally within pseudo-polynomial time[31]. In the static I-Cache locking problem, the transformed objective shown in Formula3 is not related to the PEFT’s structure. Therefore,we can treat basic blocks as items in the 0/1 knapsack problem and carry out dynamic programming similarly. The Algorithm SICL (Static I-Cache Locking for a PEFT) is shown in Algorithm 2.In Algorithm SICL,CalcFunProb(PEFT)isa procedure to calculate block_ prob(bi) and each_sa ving(bi) for each bi ∈ B (line1). Thechoice made under each circumstance is kept using anarray structure OPT[|B|][S + 1] (line 2). Each OPT[i][s] keeps the optimal solution for basicblock subset{b1, ··· bi} under cache size s withtwo variables: Sa ving and Cachable (lines 7–8, 11–12), which respectively represent the maximizedACET saving for this subset and whether or。
