1. 上一曲/音量减/频道减2. 下一曲/音量加/频道加3. TF 卡槽4. 支架开启/闭合5. 播放/暂停/接挂电话/FM6. 麦克风7. Type-C 充电插口8. 数码显示屏
9. LED 指示灯
无线充电参数：输入功率：5V/2A或9V/1.67A输出功率：10W/7.5W/5W无线充电距离3-6mm（max）转换效率：慢充≥70%，快充≥75%工作频率：110-205KHz蓝牙参数：蓝牙版本：5.0工作频率：2.4G声道：立体声FM频道：85-110MHz蓝牙距离：≤10mTF卡：最大支持32G包装清单：1*BC-011*汽车出风口夹子1*延长支架1*USB数据线1*使用说明书产品参数 产品名称：BC-01材料：防火 PC+ABS颜色：黑色使用方法1.将夹子通过螺帽固定住本产品，确保支架可以灵活旋转2.接通电源：将产品通过电源线连接汽车内USB充电口（快充模式需要使用高通快充适配器）3.按压出风口夹子固定至出风口，然后调整好位置并固定螺帽4.蓝牙使用： * BC01两边双灯闪烁为蓝牙模式，打开手机蓝牙，找到蓝牙设备BC01;进行连接配对 * BC01显示屏闪烁为FM调频模式，将频率调至与汽车收音机同一频率（FM调频时，将汽车收音机 的频率调整到当地无电台频点，然后再将BC01的频率和汽车收音机频率调节一致） *配对成功，播放音乐 *当放音乐时如果有杂音请上/下调整频率0.1MHZ5.无线充电： *将带无线充电功能的手机放置在支架上与产品贴近即可充电（建议先将蓝牙设置好再放置手机进行充电）6.取出手机 触摸开合按键会自动打开支架，然后取出手机 说明书
按键 功能
上一曲/音量减/频率减
下一曲/音量加/频率加 蓝牙/TF卡模式: 短按-上一曲 长按—音量减 FM调频模式 短按—频率减 长按—频率快速减 蓝牙/TF卡模式: 短按-下一曲 长按—音量加 FM调频模式: 短按-频率加 长按—频率快速加 播放/暂停通话状态: 接听来电—短按 拒接来电—长按 结束通话—短按 重播上一个电话—双击音乐播放状态: 播放—短按 暂停—短按 进入FM调频模式: 进入—长按直到显示屏闪烁 退出—短按 开启/闭合:开启支架—短按 关闭支架—短按 特点1. Qi认证无线充电标准2.快充支持10W/7.5W/5W，适用于安卓和苹果系统。3. 无线支架感应：当手机摆放在无线蓝牙支架时，两边的夹臂会自动将手机夹住。4. 异常感应：当支架上没有手机时，两边的夹臂会自动合拢。5. 延伸支架可以灵活伸缩调节，可以很好的把手机调整到合适的位置，便于放置和取出。6. 全新升级静音设计：使用静音马达，夹臂活动时没有马达噪音。7. 360°旋转：支持360°角度旋转，便于找到最合适的位置对手机操作和放置取出8. 带有过流保护、过热保护、短路保护功能，使用更安全9. 认证：FCC/CE/ROHS
保修服务本产品自购买之日起十二个月内在正常使用情况下无材料和工艺缺陷。 保修服务需要购买证明。消费者不应试图打开或拆卸设备，否则可能会造成损坏而导致保修失效。1. 空调出风口夹子安装方式
2.延长支架安装方式安装步骤1.将螺帽调整到最佳活动状态2.输入：将无线充电器和车载适配器与充电线连接。3.按下夹子按钮进行固定，然后调整角度并拧紧固定螺母。4.放上手机：充电器可以在接近时感应您的手机，并且将自动锁紧您的手机和无线充电。5.取下智能手机 触摸开关按钮，支架自动打开，然后将手机拿出。
1. Perv/V-/CH-2. Next/V+/CH+3. TF Card4. Open/Close5. Play/Pause/Answer/Hang up/FM6. Microphone7. Type-c Charge port8. Channel Display Screen9. LED Indicate Instructions1.Adjust the screw cap to the best active status2.Power supply:Connect the BC-01 Type-C port and car USB port (or charge adabtor)with the Type-C cable. Note:For fast wireless charging mode must use Qualcomm quick charge adaptor. 3.Press the button of clip to fix, then adjust the angle and tighten the fixed nut.4.Bluetooth function： *It's bluetooth mode when the two indictor flicker, then turn on smartphone bluetooth function and fund bluetooth device“BC01”to connect. *It's FM mode when the display screen flicker, then set the BC01 channel as same as car radio channel(NOTE: car radio has no local radio program) *connected successful and enjoy music *If there is any noise, please set car radio frequency up/down 0.1MHZ5.Wireless charge： *Smartphone must has wireless charge function *Put your smartphone on the Bracket. (It's better after BC-01 bluetooth has connected your smartphone)6.Take off smartphone Touch the open/close button ,the clips automatically open,then take your phone out.
Buttons Functions
Perv/V-/CH-
Next/V+/CH+Bluetooth/TF Card Mode: Short Touch—PreviousLong Touch—Volume DownFM ModeShort Touch—Channel DownLong Touch—Channel Down FastBluetooth/TF Card Mode:Short Touch—Next SongLong Touch—Volume UpFM Mode:Short Touch—Channel UpLong Touch—Channel Up Fast Play/Pause
Open/CloseCall Mode:Answer—Short TouchRefuse—Long TouchHang up—Short TouchReplay Call—Double Music Mode:Play—Short TouchPause—Short TouchEnter FM Mode:Enter—Long Touch untill Display Screen FlickerExit—Short TouchOpen Bracket—Short TouchClose Bracket—Short Touch
Wireless charging specification：input：5V-2A or 9V-1.67Aoutput: 10W/7.5W/5WWireless charging Distance: 3-6mm(max)Conversion Efficiency：70%-75%Operating Frequency: 110-205KHzBluetooth specification:Bluetooth Version: 5.0Operating Frequency: 2.4GSound Channel: StereoFM Channel: 85-110MHzBluetooth Distance：≤10mTF card: Maximum support 32GPackage：1*BC-011*Clip1*Extended bracket1*Type-C cable1*User manuelProduct Specification Product model：BC-01Material：Fireproof PC+ABSColor：BlackFeatures: 1. Wireless changing for devices with Qi standard2. Charging fast at 10W,7.5W and ordinary at 5W,compatible with Apple and Android devices.3. Wireless charging sensing:when the phone with wireless charge receiver approaches the charger, the two clips will automatically clip the phone and charge wirelessly. 4. Foreign body detection sensing:when the phone with none of the receiver approaches the charger,the two clips will also automatically clip the phone,then use it for a phone holder.5. The clips can extend and reteact flexibly,so easily fix phone to charge or release to use.6. New upgrade mute design:Using the mute motor,the clips stretch and shrink with no noise.7. 360°rotation: The handle supports 360°rotation,which enables you to find suitable directions to place your phone on or get you phone off.8. Over-current protection,over-heat protection and short-circuit protection.9. Certification:FCC,CE,ROHS
WarrantyThis device is free from defects in material and workmanship under normal use for twelve(12)months commencing upon the date of purchase. Proof of purchase is required for warranty service.The consumer should never attempt to open or disassemble the device,and doing so may cause damage that voids your warranty. USER MANUEL
