西门子S7-300全套接线图

3.9 Digital input module SM 321; DI 16 x DC 24 V; (6ES7321-1BH02-0AA0) Wiring and block diagrams of SM 321; DI 16 x DC 24 V① Channel number② Status display - green③ Backplane bus interfaceTechnical specifications of SM 321; DI 16 x DC 24 VTechnical specificationsDimensions and weightDimensions W x H x D (mm) 40 x 125 x 117 Weight ca. 200 g Module-specific dataSupports isochronous mode noNumber of inputs 16Cable length∙unshielded ∙shielded max. 600 m max. 1000 m3.7 Digital input module SM 321; DI 32 x DC 24 V; (6ES7321-1BL00-0AA0) Wiring and block diagrams of SM 321; DI 32 x DC 24 V① Channel number② Status display - green③ Backplane bus interfaceTerminal assignment of SM 321; DI 32 x DC 24 VThe figure below shows how channels are assigned to addresses (input byte x up to inputbyte x+3).[ [ [[3.37 Programmable digital IO module SM 327; DI 8/DO 8 x DC 24 V/0.5 A (6ES7327-1BH00-0AB0) Wiring and block diagram of SM 327; DI 8/DO 8 x DC 24 V/0.5 A, programmable① Channel number② Status display - green③ Backplane bus interfaceTechnical specifications of SM 327; DI 8/DO 8 x DC 24 V/0.5 A, programmableTechnical specificationsDimensions and weightDimensions W x H x D (mm) 40 x 125 x 120Weight ca. 200 gModule-specific dataSupports isochronous mode noNumber of inputs 8 digitalNumber of inputs/outputs 8, can be programmed separatelyCable length∙unshielded ∙shielded max. 600 m max. 1000 m3.26 Digital output module SM 322; DO 8 x DC 24 V/2 A; (6ES7322-1BF01-0AA0)Use of the module with high-speed countersPlease note when using the module in combination with high-speed counters:NoteWhen using a mechanical contact to switch on the 24-V power supply to SM 322; DO8 x DC 24 V/2 A, the module outputs will carry a "1" signal for the duration of ca. 50 µs dueto the circuit structure.Wiring and block diagram of SM 322; DO 8 x DC 24 V/2 A① Channel number② Status display - green③ Backplane bus interface3.22 Digital output module SM 322; DO 16 x DC 24 V/ 0,5 A; (6ES7322-1BH01-0AA0) Wiring and block diagram of SM 322; DO 16 x DC 24 V/ 0.5 A① Channel number② Status display - green③ Backplane bus interfaceSM 322; DO 16 x DC 24 V/0.5 A - Technical specificationsTechnical specificationsDimensions and weightDimensions W x H x D (mm) 40 x 125 x 117Weight ca. 190 gModule-specific dataSupports isochronous mode noNumber of outputs 16Cable length∙unshielded ∙shielded max. 600 m max. 1000 m3.32 Relay output module SM 322; DO 8 x Rel. AC 230 V; (6ES7322-1HF01-0AA0) Wiring and block diagrams of SM 322; DO 8 x Rel. AC 230 V① Channel number② Status display - green③ Backplane bus interfaceSM 322; DO 8 x Rel. AC 230 V - Technical specificationsTechnical specificationsDimensions and weightDimensions W x H x D (mm) 40 x 125 x 117 Weight ca. 190 gModule-specific dataSupports isochronous mode noNumber of outputs 8Cable length∙unshielded ∙shielded max. 600 m max. 1000 mVoltages, currents, electrical potentialsRated power supply L+ to the relays 24 VDC Total current of outputs (per group) max. 4 A3.31 Relay output module SM 322; DO 16 x Rel. AC 120/230 V; (6ES7322-1HH01-0AA0)Reaction to a shutdown of the power supplyNoteThe internal 200-ms buffer capacitance discharges sufficient power after power off to allowthe user program to set a defined relay state.Wiring and block diagrams of SM 322; DO 16 x Rel. AC 120/230 V① Channel number② Status display - green③ Backplane bus interface6.6 Analog input module SM 331; AI 8 x 13 Bit; (6ES7331-1KF02-0AB0)Wiring: Voltage measurement① Voltage measurement (± 5 V, ±10 V, 1 V to 5 V, 0 V to 10 V)② Voltage measurement (± 50 mV, ± 500 mV, ± 1 V) (note the input resistance defined in the technical data)③ Equipotential bonding④ Internal supply⑤ + 5 V from backplane bus⑥ Logic and backplane bus interface⑦ Electrical isolation⑧ Multiplexer⑨ Analog digital converter (ADC)⑩ Current sourceFigure 6-10 Block diagram and terminal diagramWiring: Voltage measurement and current output① Internal supply② Analog-to-Digital Converter (ADC)③ Inputs: Voltage measurement④ Outputs: Voltage output⑤ Digital-to-Analog Converter (DAC)⑥ Backplane bus interface⑦ Equipotential bonding⑧ Functional groundFigure 6-50 Wiring and block diagramsWiring: 2 and 4-wire connection for voltage output① 2-wire connection: no compensation for line impedance② 4-wire connection: with compensation for line impedance③ Equipotential bonding④ Functional ground⑤ Internal supply⑥ Electrical isolation⑦ Backplane bus interface⑧ Analog-to-Digital Converter (ADC)Figure 6-48 Wiring and block diagramsAnalog modules6.14 Analog output module SM 332; AO 4 x 12 Bit; (6ES7332-5HD01-0AB0)Wiring: 2 and 4-wire connection for voltage outputThe following Fig. represents the 2-wire connection with no compensation for line resistorsand the 4-wire connection with compensation for line resistors.① 2-wire connection, no compensation for line resistors② 4-wire connection, with compensation for line resistors③ Equipotential bonding④ Functional ground⑤ Internal supply⑥ Electrical isolation⑦ Backplane bus interface⑧ Analog-to-Digital Converter (ADC)Figure 6-46 Wiring and block diagramsS7-300 Module dataManual, 08/2009, A5E00105505-06 405。

西门子S7300;S7400模拟量接线规范问题: 什么是2线和4线的测量传感器,以及连接时的注意事项? 解答: 2线传感器是一个被动的测量传感器,它的电源是由SM331来提供的;4线传感器是一个主动测量传感器,它的电源由外部电源提供而不是SM331提供,2根测量线被连接到SM上,所以SM331(－7KF)最大有8个通道。

? 2线测量传感器连接Mana与M(短接11和20端,11端和10端); 3.3KW的电阻。

? 4线测量传感器短接10和11端,短接所有的Mx-到Mana问题: 怎样接一个没有用的模拟量模块的输入? 解答: 没有用的模拟量输入接线应依靠这个输入的参先化,首先必须明确它是电压输入还是电流输入,以及设定了怎样的测量范围,被设定的测量量是电阻值还是温度值。

根据参数设定,可以按照以下方式连接没有用的模拟量输入。

这种连接对于SM331来说是非常必要的。

因为它每个通道组有两个物理输入点,那么没有用的通道可能会影响或破坏一个通道组另一个通道的诊断,特别是的1-5V、4 -20mA的信号。

问题: 如何设置和修改以下模块的分辨率?6ES7331-7KB01-0AB0 ?6ES7331-7KB00-0AB0??6ES7331-7KF01-0AB0 ?6ES7331-7KF00-0AB0 解答: 这些分辨率不可以直接在硬件组态中选择,它只能被间接的通过干扰频率抑制来设置。

下列表格提供了相关数据: 分辨率积分时间干扰频率抑制9bits2.5ms400Hz12bits16.7ms60Hz12bits20ms50Hz14bits100ms10Hz问题: SM322连接S＋和S－的目的? 解答: 对于电压输出,S＋和S－连接起来是为了检测负载侧实际压降,并把它传回到SM332,这将模块对外部的波动和偏差进行补偿,以提高负载侧的精度例如,温度的改变。

如果不需要,那么将S＋和QV、S－和Mana相连,或让S＋、S－开路。

3.9 Digital input module SM 321; DI 16 x DC 24 V; (6ES7321-1BH02-0AA0) Wiring and block diagrams of SM 321; DI 16 x DC 24 V① Channel number② Status display - green③ Backplane bus interfaceTechnical specifications of SM 321; DI 16 x DC 24 VTechnical specificationsDimensions and weightDimensions W x H x D (mm) 40 x 125 x 117 Weight ca. 200 g Module-specific dataSupports isochronous mode noNumber of inputs 16Cable length∙unshielded ∙shielded max. 600 m max. 1000 m3.7 Digital input module SM 321; DI 32 x DC 24 V; (6ES7321-1BL00-0AA0) Wiring and block diagrams of SM 321; DI 32 x DC 24 V① Channel number② Status display - green③ Backplane bus interfaceTerminal assignment of SM 321; DI 32 x DC 24 VThe figure below shows how channels are assigned to addresses (input byte x up to inputbyte x+3).[ [ [[3.37 Programmable digital IO module SM 327; DI 8/DO 8 x DC 24 V/0.5 A (6ES7327-1BH00-0AB0) Wiring and block diagram of SM 327; DI 8/DO 8 x DC 24 V/0.5 A, programmable① Channel number② Status display - green③ Backplane bus interfaceTechnical specifications of SM 327; DI 8/DO 8 x DC 24 V/0.5 A, programmableTechnical specificationsDimensions and weightDimensions W x H x D (mm) 40 x 125 x 120Weight ca. 200 gModule-specific dataSupports isochronous mode noNumber of inputs 8 digitalNumber of inputs/outputs 8, can be programmed separatelyCable length∙unshielded ∙shielded max. 600 m max. 1000 m3.26 Digital output module SM 322; DO 8 x DC 24 V/2 A; (6ES7322-1BF01-0AA0)Use of the module with high-speed countersPlease note when using the module in combination with high-speed counters:NoteWhen using a mechanical contact to switch on the 24-V power supply to SM 322; DO8 x DC 24 V/2 A, the module outputs will carry a "1" signal for the duration of ca. 50 µs dueto the circuit structure.Wiring and block diagram of SM 322; DO 8 x DC 24 V/2 A① Channel number② Status display - green③ Backplane bus interface3.22 Digital output module SM 322; DO 16 x DC 24 V/ 0,5 A; (6ES7322-1BH01-0AA0) Wiring and block diagram of SM 322; DO 16 x DC 24 V/ 0.5 A① Channel number② Status display - green③ Backplane bus interfaceSM 322; DO 16 x DC 24 V/0.5 A - Technical specificationsTechnical specificationsDimensions and weightDimensions W x H x D (mm) 40 x 125 x 117Weight ca. 190 gModule-specific dataSupports isochronous mode noNumber of outputs 16Cable length∙unshielded ∙shielded max. 600 m max. 1000 m3.32 Relay output module SM 322; DO 8 x Rel. AC 230 V; (6ES7322-1HF01-0AA0) Wiring and block diagrams of SM 322; DO 8 x Rel. AC 230 V① Channel number② Status display - green③ Backplane bus interfaceSM 322; DO 8 x Rel. AC 230 V - Technical specificationsTechnical specificationsDimensions and weightDimensions W x H x D (mm) 40 x 125 x 117 Weight ca. 190 gModule-specific dataSupports isochronous mode noNumber of outputs 8Cable length∙unshielded ∙shielded max. 600 m max. 1000 mVoltages, currents, electrical potentialsRated power supply L+ to the relays 24 VDC Total current of outputs (per group) max. 4 A3.31 Relay output module SM 322; DO 16 x Rel. AC 120/230 V; (6ES7322-1HH01-0AA0)Reaction to a shutdown of the power supplyNoteThe internal 200-ms buffer capacitance discharges sufficient power after power off to allowthe user program to set a defined relay state.Wiring and block diagrams of SM 322; DO 16 x Rel. AC 120/230 V① Channel number② Status display - green③ Backplane bus interface6.6 Analog input module SM 331; AI 8 x 13 Bit; (6ES7331-1KF02-0AB0)Wiring: Voltage measurement① Voltage measurement (± 5 V, ±10 V, 1 V to 5 V, 0 V to 10 V)② Voltage measurement (± 50 mV, ± 500 mV, ± 1 V) (note the input resistance defined in the technical data)③ Equipotential bonding④ Internal supply⑤ + 5 V from backplane bus⑥ Logic and backplane bus interface⑦ Electrical isolation⑧ Multiplexer⑨ Analog digital converter (ADC)⑩ Current sourceFigure 6-10 Block diagram and terminal diagramWiring: Voltage measurement and current output① Internal supply② Analog-to-Digital Converter (ADC)③ Inputs: Voltage measurement④ Outputs: Voltage output⑤ Digital-to-Analog Converter (DAC)⑥ Backplane bus interface⑦ Equipotential bonding⑧ Functional groundFigure 6-50 Wiring and block diagramsWiring: 2 and 4-wire connection for voltage output① 2-wire connection: no compensation for line impedance② 4-wire connection: with compensation for line impedance③ Equipotential bonding④ Functional ground⑤ Internal supply⑥ Electrical isolation⑦ Backplane bus interface⑧ Analog-to-Digital Converter (ADC)Figure 6-48 Wiring and block diagramsAnalog modules6.14 Analog output module SM 332; AO 4 x 12 Bit; (6ES7332-5HD01-0AB0)Wiring: 2 and 4-wire connection for voltage outputThe following Fig. represents the 2-wire connection with no compensation for line resistorsand the 4-wire connection with compensation for line resistors.① 2-wire connection, no compensation for line resistors② 4-wire connection, with compensation for line resistors③ Equipotential bonding④ Functional ground⑤ Internal supply⑥ Electrical isolation⑦ Backplane bus interface⑧ Analog-to-Digital Converter (ADC)Figure 6-46 Wiring and block diagramsS7-300 Module dataManual, 08/2009, A5E00105505-06 405。

1.CPU（1）cpu 312c集成DI-DO引出线（连接器X1）全球独家推出　全覆盖型省配线解决方案（2）313c集成AI-AO和DI的引出线（连接器X1）集成DI-DO引出线（连接器X2）数字I-O接线图313c-2dp313c-2 ptp（5）314c-dp集成AI-AO和DI的引出线（连接器X1）集成DI-DO引出线（连接器X2）数字I-O接线图数字与模拟I-O的接线图（6）314c-2ptp集成AI-AO和DI的引出线（连接器X1）集成DI-DO引出线（连接器X2）数字I-O接线图数字与模拟I-O的接线图2.功能模块POS 输入模块,用于带StartStop接口的超声波编码器位置检测 338-4BC01-0AB04输入，2输出 334-0CE01-0AA08 点输入，9-12-14 位分辨率 331-7KF02-0AB0,8点输入，用于热电偶 331-7PF11-0AB08点输入，增强型16位分辨率，4通道模式 331-7NF10-0AB02点输入，9-12-14位分辨率8点输入，13位分辨率 331-1KF01-0AB08点输入，用于热电阻 331-7PF01-0AB08点输入，增强型16位分辨率 331-7NF00-0AB05模拟量输出模块4点输出，16位 332-7ND02-0AB04点输出，11-12位 332-5HD01-0AB0 8点输出，11-12位 332-5HF00-0AB06数字量输入模块8 点输入，120-230V AC 321-1FF01-0AA08 点输入，120-230V AC, single root 321-1FF10-0AA016 点输入，24-48V DC 321-1CH00-0AA016 点输入，24V DC，低态有效 321-1BH50-0AA016 点输入，48-125V DC 321-1CH20-0AA0 16 点输入，120-230V AC 321-1FH00-0AA016点输入，24V DC 321-1BH02-0AA016点输入，24V DC，用于等时线模式下运行 321-1BH10-0AA016点输入，24V DC，用于等时线模式下运行 321-1BH10-0AA0 有诊断能力32 点输入，120V AC 321-1EL00-0AA032点输入，24V DC 321-1BL00-0AA07数字量输出模块8点输出，11-12位 332-5HF00-0AB08点输出，24V DC，0.5A，322-8BF00-0AB08点输出，24V DC，2A 322-1BF01-0AA08点输出，48-125V DC，1.5A 322-1CF00-0AA08点输出，120-230V AC，1A 322-1FF01-0AA08点输出，继电器，2A 322-1HF01-0AA08点输出，继电器，5A 322-1HF10-0AA08点输出，继电器，5A，带过压RC滤波器保护 322-5HF00-0AB016点输出，24-48V DC，0.5A 322-5GH00-0AB0 16点输出，24V DC，0.5A 322-1BH01-0AA016点输出，24V DC，0.5A，高速 322-1BH10-0AA0 16点输出，120-230V AC，1A 322-1FH00-0AA016点输出，继电器，8A 322-1HH01-0AA0 32点输出，24V DC，0.5A 322-1BL00-0AA032点输出，120V AC，1A 322-1FL00-0AA0 （8）数字量输入输出模块SM323 16输入， 16输出 323-1BL00-0AA0。
