1580IEEETRANSACTIONSONMULTIMEDIA,VOL.9,NO.8,DECEMBER2007OnMaximizingTreeBandwidthforTopology-AwarePeer-to-PeerStreamingXingJin,StudentMember,IEEE,W.-P.KenYiu,StudentMember,IEEE,S.-H.GaryChan,SeniorMember,IEEE,andYajunWang

Abstract—Inrecentyears,therehasbeenanincreasinginterestinpeer-to-peer(P2P)multimediastreaming.Inthispaper,wecon-siderconstructingahigh-bandwidthoverlaytreeforstreamingser-vices.Weobservethatunderlayinformationsuchaslinkconnec-tivityandlinkbandwidthisimportantintreeconstruction,becausetwoseeminglydisjointoverlaypathsmaysharecommonlinksontheunderlay.Wehencestudyhowtoconstructahigh-bandwidthoverlaytreegiventheunderlaytopology.WeformulatetheproblemasbuildingaMaximumBandwidthMulticastTree(MBMT)oraMinimumStressMulticastTree(MSMT),dependingonwhetherlinkbandwidthisavailableornot.WeprovethatbothproblemsareNP-hardandarenotap-proximablewithinafactorof(23+),forany0,unless=NP.Wethenpresentapproximationalgorithmstoaddressthemandanalyzethealgorithmperformance.Furthermore,wediscusssomepracticalissues(e.g.,groupdynamics,resilienceandscalability)insystemimplementation.WeevaluateouralgorithmsonInternet-liketopologies.Theresultsshowthatouralgorithmscanachievehightreebandwidthandlowlinkstresswithlowpenaltyinend-to-enddelay.MeasurementstudybasedonPlan-etLabfurtherconﬁrmsthis.Ourstudyshowsthattheknowledgeofunderlayisimportantforconstructingefﬁcientoverlaytrees.

IndexTerms—Overlaytree,peer-to-peerstreaming,topology-aware,treebandwidth.

I.INTRODUCTION

WITHthepopularityofbroadbandInternetaccess,there

hasbeenanincreasinginterestinmediastreamingservices.Recently,P2Pstreaminghasbeenproposedanddevelopedtoovercomelimitationsintraditionalserver-basedstreaming.InaP2Pstreamingsystem,cooperativepeersself-organizethemselvesintoanoverlaynetworkviaunicastconnections.Theycacheandrelaydataforeachother,therebyeliminatingtheneedforpowerfulserversfromthesystem.Inthispaper,weconsiderbuildingahigh-bandwidthoverlaytreeforsteaming.Astreamingvideousuallyhasacertainbi-trate.Toensuregoodstreamingqualityatahost,theincomingbandwidthofthehostshouldbehigherthanorequaltothestreamingbitrate.Wehenceneedtobuildatreewithenoughtreebandwidthtosupportthestreaming.Heretreebandwidth

ManuscriptreceivedOctober31,2006;revisedJuly29,2007.ThisworkwassupportedinpartbytheResearchGrantCounciloftheHongKongSpecialAdministrativeRegion(HKUST611107)andHongKongInnovationandTechnologyCommission(GHP/045/05).TheassociateeditorcoordinatingthereviewofthismanuscriptandapprovingitforpublicationwasProf.KlaraNahrstedt.TheauthorsarewiththeDepartmentofComputerScienceandEngineering,HongKongUniversityofScienceandTechnology,Kowloon,HongKong,China(e-mail:csvenus@cse.ust.hk;kenyiu@cse.ust.hk;gchan@cse.ust.hk;yalding@cse.ust.hk).DigitalObjectIdentiﬁer10.1109/TMM.2007.907459

Fig.1.Theimpactofunderlayinformationtooverlaytreeconstruction.(a)Naiveconstructionofanoverlaytree(thelabelalongahostisitsdegreebound).(b)Treebandwidth=0:5

(thelabelalongalinkistheresidual

bandwidthofthelink).(c)Atreewithhighertreebandwidthof1.0.

isdeﬁnedastheminimumpath-bandwidthofanoverlaytree[1].Notethataverageincomingbandwidthofhostsmayalsobeusedtoevaluateatree.However,whentheincomingbandwidthofahostislowerthanthestreamingbitrate,thehostwillen-counterpacketlossandthereceivedstreamingqualitywillbereduced.Averageincomingbandwidthcannotindicatethepor-tionofhostswithgood(orbad)streamingqualities.Wehencefocusontreebandwidthinsteadofaverageincomingbandwidthinthispaper.Somepreviousworkimposesdegreeboundsonhosts.Thatis,thedegreeofahostinanoverlaytreecannotexceedacertainbound[2],[3].Thisapproachcaneffectivelyreducecongestionnearhosts.However,itcannotimprovetreebandwidthifthebandwidthbottlenecksoccuratintermediatelinksinpathsin-steadofedgelinksnearhosts.Furthermore,twoseeminglydis-jointoverlaypathsmaysharecommonunderlaylinks;thereforetheselectionofoverlaypathswithouttheknowledgeofunderlaymayleadtoseriouslinkcongestion.Notethatinthispaper,alinkreferstoaphysicalunderlayconnectionbetweentworoutersorbetweenarouterandahost;whileapathreferstoanend-to-endconnectionbetweentwohosts,whichmaycontainmultipleun-derlaylinks.Furthermore,thebandwidthoflinksorpathsreferstotheresidualbandwidthalonglinksorpaths.WeshowatreeconstructionexampleinFig.1.,andarefourhosts,whosedegreeboundsare2,2,2and1,respectively.Rectangleswithlabels1to5arerouters.Withoutanyknowledgeoftheun-derlay,atreemaybeconstructedasFig.1(a)shows.SupposethatthelinkconnectivityandlinkbandwidthontheunderlayisasshowninFig.1(b).Wecanseethatthistreeisofbandwidth0.5(thebottlenecklinkisbetweenrouters3and4).Giventheunderlayinformation,wecaninfactbuildatreewithhighertreebandwidthof1asshowninFig.1(c).Therefore,underlayinfor-mationisimportantforbuildingahigh-bandwidthoverlaytree.
