柴油共轨主要零部件通用性表

YC6J245-30(J61LA)柴油机零件图册Parts Catalogue of YC6J245-30(J61LA) Diesel Engine广西玉柴机器股份有限公司Guangxi Yuchai Machinery Co., Ltd.前言Foreword感谢您选用广西玉柴机器股份有限公司的产品，并感谢您阅读《YC6J-30(J61LA)柴油机零件图册》！Thanks for using Yuchai engine and reading the “Parts Catalogue of YC6J-30(J61LA)Diesel Engine”!玉柴的服务宗旨是：“倾我所有、尽我所能、竭诚用户、诚信天下”,为了更好地履行玉柴的服务宗旨，我们编印了《YC6J-30(J61LA)柴油机零件图册》，希望本图册可以让用户更好地认识了解玉柴产品的结构与配置，方便用户使用、维修和购置零配件。

With the aim to fulfill our company service tenet, i.e. “striving all out to serve the customers, spending full sincerity to confidence the world”, we compiled and printed th is “Parts Catalogue of YC6J-30(J61LA) Diesel Engine”. We hope this “Parts Catalogue of YC6J-30(J61LA) Diesel Engine” will help you to understand the structure and configuration of Yuchai’s YC6J-30(J61LA) diesel engines, so to operate and maintain them easily.本零件图册是根据相关生产图样、资料编制而成的。

上海日野服务科P11C发动机共轨原理介绍上海日野服务科共轨系统原理1、什么是共轨系统 2、共轨系统的组成 3、共轨系统与传统供油系统的比较 4、共轨系统的优点 5、共轨系统各主要组成部件介绍上海日野服务科发动机共轨系统电子控制单元 高压燃油 喷 油 泵 共轨 保持连续的压力 喷油器 电 磁 阀该系统摈弃了传统的泵－管－喷嘴的脉动供油方式，代之用一个 高压油泵在柴油机的驱动下，连续将高压燃油输送到共轨管内， 高压燃油再由共轨送入各缸喷油器。

上海日野服务科共轨系统主要生产厂家Ø德国 ROBERT BOSCH 公司的 CR 系统 Ø日本电装公司的 ECD-U2 系统 Ø美国的 DELPHI 公司的 LDCR 系统等 Ø意大利的 FIAT 集团的 unijet 系统上海日野服务科ECD-U2高压共轨电控喷油系统P11C发动机采用的是日本电装公司的ECD-U2高压共轨电控喷油系统上海日野服务科共轨系统与传统供油系统的比较上海日野服务科共轨系统主要特性Ø自由控制每循环喷油量以发动机转速,加速踏板开度等信息为基础,控制电磁阀的开启, 从而控制最佳喷油量Ø自由控制喷油压力根据发动机转速等参数计算出来,通过控制供油泵,使之向共轨 供出适量的燃油,从而控制共轨压力Ø自由控制喷油时间由ECU根据工况计算控制喷油时间，取代了机械式燃油系统中的提前器Ø自由控制喷油率可以实现引导喷射和多次喷射上海日野服务科高压共轨喷油系统的优点nnnn可以实现高压燃油，喷射燃油喷射压力完全独立于发动机 转速，在低速低负荷工况下同样可以实现高压喷射，改善 了发动机低速低负荷时的性能。

可独立地柔性控制喷油正时，配合高的喷射压力 （ 120MPa~200MPa ），可同时控制 NOx 和微粒（ PM ） 在较小的数值内，以满足排放要求。

可以实现预喷射或多次预喷射，调节喷油速率形状，实现 理想的喷油规律，可以优化燃烧过程，使发动机油耗、噪 声、烟度和排放等性能指标得到明显改善，同时有利于改 进发动机的扭矩特性，实现低速时的大扭矩。

YN33CR电控高压共轨柴油机YN33CR Electronic-controlled, High Pressure and Common Rail Diesel Engine零件图册Parts Catalogue文件编号(File Number)：J15-YN33CR-2008.001昆明云内动力股份有限公司KUNMING YUNNEI POWER CO., LTD.目录contents1. 机体部件Cylinder Block Assy. (1)2. 正时齿轮室部件Timing gear chamber components. (7)3. 缸盖部件Cylinderhead Assy. (10)4. 活塞连杆总成Piston conrod Assy. (13)5. 曲轴飞轮离合器总成Crankshaft flywheel clutch Assy. (15)6. 润滑系统Lubricative System. (17)7. 油底壳部件Oil sump Assembly. (19)8. 共轨系统CRS. System. (21)9. 进气系统Intake System (24)10. 排气系统Exhaust System. (26)11. 冷却系统Cooling System. (29)12. 配气机构Valve train. (36)13. 起动系统Start system. (39)14. 空压机部件Compressor System. (42)1. 机体部件Cylinder Block Assy.242757、56、5558 596061机体部件Cylinder Block Assy.2.正时齿轮室部件Timing gear chamber components.13 14 15、16、17 18 19、20、21 22 23 24、25、26、27 28正时齿轮室部件Timing gear chamber components.3. 缸盖部件Cylinderhead Assy.15缸盖部件Cylinderhead Assy.4.活塞连杆总成Piston conrod Assy.活塞连杆总成Piston conrod Assy.5. 曲轴飞轮离合器总成 Crankshaft flywheel clutch Assy.1415 16 17 18 19曲轴飞轮离合器总成Crankshaft flywheel clutch Assy.6.润滑系统Lubricative System.润滑系统Lubricative System.7. 油底壳部件 Oil sump Assembly.油底壳部件Oil sump Assembly.8.共轨系统CRS. System.15 16 17 18 19 20 21 22 23 24共轨系统CRS. System.9. 进气系统 Intake System ．进气系统 Intake System．13171615144 3 612 8 7 119201830 2425 2627 28 112 5 11 10 9 29 4 31 3435 32 33 4 38 3637 22232110. 排气系统 Exhaust System.排气系统 Exhaust System.11.冷却系统Cooling System.11.1缸盖前盖板和节温器盖部件Cylinder head front cover and thermostat cover Assembly.1011.2风扇、水泵部件 Fan and water pump Assembly.11.3机油冷却器及放水开关部件 Oil cooler and water drain cock Assembly.3564冷却系统 Cooling System.12.配气机构Valve train.15 16 17 18 19 20 21 22 23配气机构 Valve train.13.8 9 10起动系统Start system.14. 空压机部件Compressor System.1012空压机部件Start system.。

WD12系列柴油机，是潍柴动力欧洲研发中心采用世界顶尖技术和全新设计理念研发的新一代柴油机，刷新国内重型柴油机中多项性能指标，具有更省油、更强劲、更可靠、更安全的优点，主要经济指标达到世界领先水平。

WD12柴油机是潍柴动力针对重型汽车市场开发研制的先进动力产品，是目前国内唯一成熟的最大排量柴油机。

其功率覆盖336马力——480马力，与现有同类同功率发动机相比，综合运行油耗降低10-15%，动力性提高30%，可以保证整车高效、高速运行，是目前国内重型汽车理想的升级动力。

WD12系列柴油机技术优势：更省油——相同载重，油耗降低15%，节省使用成本排量大，进气量大；配套专用P12高压油泵，燃油喷射雾化更好；配套专用高效增压器，进气效率较高；使用WD12发动机燃烧更充分，油耗更低。

更强劲——12升大排量，扭矩提高30%，动力更强劲WD12发动机排量大，低速（1000r/min）扭矩提高30%；使整车加速性能更好；最大扭矩大，使整车载重能力更强；大扭矩范围宽，在1200——1650转范围内均能输出大扭矩，使整车在各种工况下均能高效运行，可大大提高运营效率，实现“多拉快跑”的目的。

更可靠——热负荷更低，零部件寿命更长，减少维护费用大排量，同功率热负荷更低WD12柴油机排量达到12升，与现有同类同功率发动机相比升功率最低，柴油机整机的可靠性得到极大提高，曲轴、连杆、轴瓦等零部件使用寿命更长；同时延缓了机油老化速度，延长了更换机油的周期，给用户带来可观的直接收益。

高强度机体WD12柴油机的机体经过全面结构计算、可靠实验，综合性能指标高出同类产品20%高压油泵采用法兰士齿轮传动法兰连接使得喷油提前角精度更高，避免了提前角发生变化导致柴油机性能和排放指标恶化情况的出现，减少了震动，全面提高了整机可靠性。

水泵侧置不与风扇连接，降低了零部件故障率，维修方便更安全——标配潍柴独有的WEVB技术，制动效率提高50%采用WEVB发动机制动系统后，整车制动效率可以提高50%，大大增加了整车运行的安全性。

100个柴油机各零部件介绍1、飞轮飞轮的主要功用是储存作功冲程的能量，克服辅助冲程的阻力以保持曲轴旋转的均匀性，使内燃机工作平稳。

为此，它要能储存一定的能量，并在需要时放出。

2、飞轮壳飞轮壳安装于发动机与变速箱之间，外接曲轴箱、起动机、油底壳，内置飞轮总成，起到连接机体、防护和载体的作用。

3、飞轮齿圈飞轮外缘上压有一个齿圈，可与起动机的驱动齿轮啮合，把起动机的动力传递到曲轴的连接件，主要作用是实现起动机与曲轴之间动力传递，为发动机提供惯性。

4、飞轮螺栓飞轮螺栓的作用就是装配时产生足够的预紧力,使发动机在工作时飞轮与曲轴结合面间产生的摩擦力矩能够传递扭矩。

5、起动机内燃机借助于外力由静止状态过渡到能独立运转的过程，称为内燃机起动过程，简称为内燃机起动。

完成起动过程所需的装置，称为起动装置。

发动机的起动装置主要有：电力起动机、电磁啮合式起动机、减速起动机和永磁起动机、空气起动机等6、机油泵总成机油泵是润滑系中机油压力和流量的动力源。

它保证发动机润滑所需要的机油压力和流量。

机油泵的结构形式有齿轮式、转子式、叶片式和柱塞式。

常用的有齿轮式和转子式。

7、机油滤清器是用来滤清机油中的金属磨屑、机械杂质及机油本身氧化的产物，如各种有机酸、沥青质以及碳化物等，防止它们进入零件的摩擦表面而将零件拉毛、刮伤，使磨损加剧，以及防止润滑系通道堵塞而烧坏轴瓦等严重事故。

机油滤清器性能的好坏直接影响到内燃机的大修期限和使用寿命。

8、发电机功用：向用电设备供电，并向蓄电池充电，为了满足蓄电池充电的需求，车用发电机的输出电压必须是直流电。

内燃机上装有的发电机通常有并激直流发电机、硅整流发电机和永磁式交流发电机。

目前国内、外汽车上使用的发电机几乎都是硅整流交流发电机。

硅整流交流发电机是由转子、定子、整流器、端盖、风扇叶轮组成。

发电机产生的二相交流电通过整流器进行三相桥式全波整流后，转为直流电。

输出电压一般为28V。

9、水泵总成水泵的功用是对冷却水加压，保证其在冷却系中循环流动。

）系列柴油机零件图册认证）常柴4L35B/4LD40B（通过EPA IV认证PARTS CATALOG OF CHANGCHAI BRAND4L35B/4LD40B(AUTHORIZED BY EPA IV CERTIFICATE) DIESEL ENGINE常柴股份有限公司CHANGCHAI CO.，LTD.CHINANo.Part No.名 称Name of part Quantity 1GB/T3452.1-92O 型密封圈 33.5×2.65O Seal ring 33.5×2.6512N85-01002加油口盖Oil filling cover 13GB/T65-2000螺钉M4×6Bolt M4×644ZN390TE-01018(I)EPA 排放标签 EPA emission label 15N85-01004抽气管Breather tube 164L68-010003B 气缸盖罩Cylinder head cover 17N485-01001气缸盖罩密封圈Cylinder head cover seal 18N85-01005挡架Retainer 19N85-01008铁丝滤网Steel wool screen 110N85-01007多孔挡板Multi-hole retaining plate 111N85-01006挡油板Oil retainer 112GB/T895-87垫圈 Washer 6213GB/T65-2000螺钉M6×12Screw M6×12214ZN390TE-09007回气管Breather pipe 115QC/T619-1999夹箍Q676B25Pipe clip Q676B252No.Part No.名 称Name of part Quantity 1N85-02101A 套管 Sleeve 42GB/T5782-2000螺栓M8×20Bolt M8×2043N85-02004吊耳Lifting eye 144L68-020006排气管垫片Exhaust manifo 45N85-02109碗形塞φ26Expansion plugφ2646N85-02105气门导管Intake manifold 47GB/T923-88盖形螺母 M8Nut M858GB/T5783-2000螺栓M10×30Bolt M10×3049GB/T93-87垫圈10Washer 10610N85T-20001垫片Gasket 111GB/T899-88螺柱M8×75Stud M8×75812GB/T6170-2000螺母M8Nut M8813N485T-10001A 排气管Exhaust manifold 1144B26-021008气缸盖Cylinder head 1154L68-020009喷油器压板Injector plate 416GB/T899-88螺柱M10×50Bolt M10×50417GB/T6170-2000螺母 M10Nut M10418N85-02104碗形塞φ55Expansion plugφ55119N85-02102碗形塞φ20Expansion plugφ20420N485T-09001进气管Intake manifold 121GB/T5783-2000螺栓M8×45Bolt M8×45422GB/T97.1-2002垫圈8Washer 8423N485-09006垫片Gasket 324N485-09005盖板Cover 225ZN490QA-02005进气管垫片Intake manifold gasket 1264L68-021007进气门座Intake vlvae seat 4274L68-021006排气门座Exhaust valve seat 428GB/T5783-2000螺栓M8×16Bolt M8×16829QJ/MD05.01组合垫圈8Washer 8530GB/T899-88螺柱M10×50Bolt M10×50831GB/T859-87垫圈8Washer 82932GB/T5782-2000螺栓M8×28Bolt M8×28533N85Q-17004节温器壳垫片Thermostat shell gasket 1344B26-023000A 电热塞Heater plug 4Cylinder Head Cover Assembly （Fig.1）气缸盖总成气缸盖总成（（图2）Cylind Head Assembly (Fig.2)气缸盖罩总成气缸盖罩总成（（图1）354B26-020010电热塞接线板Heater plug patch board 136N85-02004A 吊耳吊耳 Lifting eye 137N390T-09002G 进气接管Intake joint pipe 1384L88-350005EGR 法兰垫片EGR flange gasket 139N390T-09005支架Support 1No.Part No.名 称Name of part Quantity 1GB/T5782-2000螺栓M10×35Bolt M10×35102GB/T5782-2000螺栓M12×40Bolt M12×4043GB/T859-87垫圈12Washer 1224GB/T859-87垫圈10Washer 10125ZN485T-03012C 飞轮壳Flywheel housing 16HG4-692-67油封DL85×110×12Oil seal DL85×110×1217GB/T5783-2000螺栓M8×25Bolt M8×2578GB/T859-87垫圈8Washer 8489GB/T848-85垫圈8Washer 84210N85-03108塞片Expansion plug 111N85-03109凸轮轴后衬套Camshaft rear bushing 112N85-03102碗形塞φ30 Expansion plug φ30 413N85-03112凸轮轴中间衬套Camshaft middle bushing 114ZN490QA-03104主轴承盖Main shaft cover 4154L40-03022加强板Reinforce plate 116GB/T93-87垫圈12Washer 12517GB/T5782-2000螺栓M12×30Bolt M12×30518ZN490QA-03107后主轴承盖Rear main shaft cover 119N90-03002封水圈Water seal ring 820N85-03111堵塞φ14Blocking plug φ144214L40-03101机体Cylinder block 122N85-03103凸轮轴衬套Camshaft bushing 123N85-12001齿轮室垫片Gear case gasket 124GB/T6170-86螺母M8Nut M8325GB/T899-88螺栓M8×35Bolt M8×35326ZN485T-12002(A)齿轮室Gear case 127GB/T6170-86螺母Nut M10128GB/T93-87垫圈10Washer 10129N390T-12007发电机支架Generator bracket 130GB/T5782-2000螺栓M8×20Bolt M8×20831GB/T5782-2000螺栓M10×90Bolt M10×90132GB/T276-82轴承107Bearing 107233N85-12003（A ）齿轮室盖垫片Gear case cover gasket 134ZN485T-12004(A)齿轮室盖Gear case cover 135GB/T5782-2000螺栓M8×65Bolt M8×65336GB/T5782-2000螺栓M8×40Bolt M8×40137GB/T5782-2000螺栓M8×30Bolt M8×30238N85T-12010液压泵盖垫片Hydraulic pump cover gasket 239N85T-12009B 液压泵盖Hydraulic pump cover 240GB/T5782-2000螺栓M8×25Bolt M8×251141HG4-692-67油封DR52×72×12Oil seal DR52×72×12142N485T-12005B 齿轮室前盖Gear case front cover 143N485T-12006齿轮室前盖垫片 Gear case front cover gasket 144N85-03014气缸盖螺栓垫圈Cylinder head bolt washer 1445N85-03016气缸盖短螺栓Cylinder head shot bolt 446N85-03015气缸盖长螺栓Cylinder head long bolt 14474B26-030013气缸盖垫片Cylinder head gasket 148N85-03017气缸盖定位套Cylinder head locating sleeve 2机体机体、、齿轮室总成齿轮室总成（（图3）Cylinder Block and Gear Case Assembly(Fig.3)49N90-03003气缸套Cylinder liner 450GB/T5782-2000螺栓M8×75Bolt M8×75151GB/T70.1-2000内六角圆柱头螺钉M8×20 Inner hexagon cylindrical bolt M8×20 352N85-03001齿轮室定位套Gear case locating sleeve 353N85T-03110定位销Dowel pin 254N85-03105主轴承盖螺栓垫圈Main shaft cover bolt washer 1055N90-03106主轴承盖螺栓Main shaft cover bolt 1056N85-03007曲轴止推片(下)Crankshaft thrust plate (lower)257N85-03009曲轴止推片(上) Crankshaft thrust plate (upper)258N85-03006主轴瓦(下) Main bearing shell (lower)459N85-03008主轴瓦(上) Main bearing shell (upper)460N85-03020机油滤清器垫片Lubricating oil filter gasket 261N85-03004机油压力传感器Oil pressure sensor 162ZN390TE-03200放水阀部件 Water draining cock 163N85-03005后油封盖垫片Rear oil seal cover gasket 164N85-03010后油封盖Rear oil seal cover 165CC490Q-030021机油滤清器垫块Lubricating oil filter end cover 166GB/T119-2000销B8×16Pin B8×16267GB/T119-2000销B10×22Pin B10×22268GB/T5782-2000螺栓M8×60Bolt M8×60169GB/T5782-2000螺栓M8×45Bolt M8×45370GB/T70.1-2000内六角圆柱头螺钉M8×55Inner hexagon cylindrical bolt M8×55171GB/T5782-2000螺栓M8×50Bolt M8×50172N85-19005推杆室盖垫片Push-rod chamber cover gasket 173ZN390TE-03025B 推杆室盖板Push-rod chamber cover 174QJ/MD05.01-1990组合垫圈10Combined Washer10275GB/T6013-2000铰接螺栓M10×1Link Bolt M10×1176QJ/MD05.01-1990组合垫圈16Combined Washer16277N485Q-29001铰接螺栓Link Bolt 1No.Part No.名 称Name of part Quantity 1GB/T5782-2000螺栓M12×30Bolt M12×3012GB/T859-87垫圈12Washer 1213N85-04009凸轮轴正时齿轮压板Camshaft timing gear retainer 14N85T-04011A-1液压泵齿轮Hydraulic pump gear 154L68-040007凸轮轴正时齿轮Camshaft timing gear 16GB/T5782-2000螺栓M8×16Bolt M8×1627GB/T859-87垫圈8Washer 848GB/T97.1-2002垫圈8Washer 829N85-04008凸轮轴压板Camshaft retainer 1104L88-040002正时惰齿轮衬套Timing idle gear bushing 111N85T-04004A 正时惰齿轮轴Timing idle gear shaft 112N85T-04012空心螺栓Hollow bolt 113GB/T6013-2000垫圈8Washer 8214N485T-04100吸油管部件Oil pipe 115GB/T5782-2000螺栓M8×50Bolt M8×50216N85T-04003正时惰齿轮压板 Timing idle gear retainer 117GB/T5783-2000螺栓M6×25Bolt M6×25518GB/T859-87垫圈6Washer 6619N485T-32001(D)联接盘 Adapter 1204L88-040010机油泵主动齿轮Lubricating oil pump driving gear 121N85-04006曲轴正时齿轮Crankshaft timing gear 1224L88-040005正时惰齿轮Timing idle gear 123N485T-04001(A)燃油泵正时齿轮Injection pump timing gear 1正时齿轮系总成正时齿轮系总成（（图4）Timing Gear Train (Fig.4)No.Part No.名 称Name of part Quantity 14B26-050002第一道活塞环1st piston ring 424B26-050003-1第二道活塞环2nd piston ring 434B26-051000油环部件Oil ring 44GB/T893.2-86孔用挡圈28Circlip 28854B26-050001活塞Piston 46N85-05201连杆Connecting rod 47N85-05203连杆螺栓Connecting rod bolt 884L68-050005连杆轴瓦Connecting rod bearing shell 89N85-05204连杆盖 Connecting rod cap 410N85-05205连杆螺母Connecting rod nut 811N85-05202连杆衬套Connecting rod bushing 412N85-05004活塞销Piston pin 4No.Part No.名 称Name of part Quantity 1N85Q-06007曲轴皮带轮螺栓Crankshaft pulley bolt 12N85-06002起动爪垫圈Starting jaw washer 13ZN485T-06001A 曲轴皮带轮Crankshaft pulley 14N485-04010（A ）机油泵主动齿轮Lubricating oil pump driving gear 154L68-040006曲轴正时齿轮Crankshaft fiming gear 16GB/T1096-2003键C10x63Key C10x6317ZN490B-06004-1曲轴Crankshaft 18GB/T119.1-2000销B10x25h8Cylindrical pin B10x25h819N85-06102飞轮齿圈Flywheel ring gear 110ZN485T-06101G 飞轮Flywheel 111GB/T276-94轴承 6004Bearing 6004112N85-06005（A ）飞轮螺栓垫片Flywheel blot washer 113N85-06006飞轮螺栓Flywheel bolt 6No.Part No.名 称Name of part Quantity 1N485-07001凸轮轴Camshaft 12GB/T1096-2003平键C10×25 Falt key C10×25 13N485-07003气门挺拄Valve tappet 84N485-07002气门推杆Valve push rod 85N85-02208堵塞Blocking plug 26N85-022001前摇臂座Front rocker arm support 17GB/T859-87垫圈8Washer 8108GB/T5782-2000螺栓M8×60Bolt M8×6059GB/T5782-2000螺栓M8×45Bolt M8×45510N85-02212气门摇臂衬套Valve rocker arm bushing 811N85-02203气门间隙调整螺母Valve clearance adjusting nut 812N85-02202气门间隙调整螺钉Valve clearance adjusting screw 813N85-02205气门摇臂弹簧Valve rocker arm spring 414N85-02211气门摇臂Valve rocker arm 815GB/T79-2000螺钉M8×45Screw M8×45516GB/T6170-2000螺母M8Nut M8517N85-022004摇臂座Rocker arm support 418N85-02206轴套Rocker arm shaft bushing 3曲轴飞轮总成曲轴飞轮总成（（图6）Crankshaft and Flywheel Assembly (Fig.6)配气机构配气机构（（图7）Valve Timing Mechanism(Fig.7)活塞活塞、、连杆总成连杆总成（（图5）Piston and Connecting Rod Assembly (Fig.5)19N485-02207摇臂轴Rocker arm shaft 120GB/T308-77 气门杆密封圈Valve rod seal ring 821N85-02001-1气门弹簧上座 Valve spring seat(upper)822N85-02002气门锁夹Valve collet 1623N85-02003-1气门外弹簧Valve outer spring 824N85-02003-2气门内弹簧Valve inner spring 8254B26-020007排气门Exhaust valve 4264B26-020008进气门Intake valve 4No.Part No.名 称Name of part Quantity 1GB/T5783-2000螺栓M8×60Bolt M8×6042GB/T859-87垫圈8Washer 8153CC490Q-080012冷却风扇Cooling fan 14N390T-08020B 风扇垫块组件Fan pad 15GB/T6170-2000螺母M10Nut M1016GB/T859-87垫圈10Washer 1017GB/T97.1-2002垫圈10Washer 1018N390T-08011(A)水泵皮带轮Water pump pulley 19N485T-08012水泵皮带轮壳Water pump pulley housing 110GB/T5783-2000螺栓M8×25Bolt M8×25111GB/T97.1-2002垫圈8Washer 8112GB/T1099.1-2003键4×36Key 4×36113GB/T6170-2000螺母M8Nut M8414N390T-08018A 撑杆Bracing 115N85T-08004D 水泵壳体Water pump housing 116GB/T898-88螺柱M8×50Stud M8×50117N485Q-17008水温传感器306Water temperature sensor model 306118N85Q-17003节温器(155B)Thermostat (Model 155B)119GB/T1152-79油杯M8×1Oil cup M8×1120N85T-08008节温器壳垫片Thermostat housing gasket 121N85T-08007节温器壳Thermostat housing 122GB/T5783-2000螺栓M8×30Bolt M8×30223N85T-08003水封IF-12Water seal ring IF-12124N85T-08005水泵叶轮Water pump impeller 125N85T-08009水泵垫片Water pump gasket 126N85T-08010水泵连接板Water pump adapter 127N85T-08017水泵连接板垫片Water pump adapter gasket 128GB/T68-2000螺钉M8×16Screw M8×16229GB/T3452.1-2005O 型密封圈34.5×3.55O-ring seal 34.5×3.55130GB/T5783-2000螺栓M8×20Bolt M8×20231N85T-08013出水接头Water drain connector 132N85T-08014出水接头垫片Water drain connector gasket 133N85T-08016螺塞Plug 134GB/T3541-83垫圈12Washer 12135N85T-08015放水螺栓Water drain screw 136GB/T5780-2000螺栓M8×45Bolt M8×45237GB/T898-88螺柱M8×45Stud M8×45338N85T-08006水泵轴Water pump shaft 139GB/T276-94滚动轴承602020Ball bearing 602020240N85T-08002轴承隔套Bearing spacing sleeve 141GB/T893.2-86挡圈35Circlip 35142HG4-401-66风扇皮带AV15×900Fan belt AV15×900143HG4-401-66风扇皮带AV15×600Fan belt AV15×600144N390T-08020(C)风扇垫块组件Fan pad 1水泵水泵、、风扇总成(图8)Water Pump and Fan Assembly(Fig.8)No.Part No.名 称Name of part Quantity 1N485T-03110定位销Dowel pin 22ZN485T-11001油底壳垫片Oil sump gasket 13ZN485T-11004油底壳Oil sump 14GB/T93-87垫圈 8Washer 8465GB/T5782-2000螺栓M8×55Bolt M8×5516GB/T3452.1-2005O 形密封圈11.2×2.65O-ring seal 11.2×2.6527195-01026闷头Plug 28ZN485T-11007机油尺Oil dipstick 19CZ475Q-032200机油尺管焊接件Oil dipstick pipe body 110QJ/MD05.01组合垫圈12Fit together Washer 12111GB/T5783-2000螺栓Bolt M8×302512GB/T93-87垫圈10Washer 10313GB/T95-2002垫圈10-100HV Washer 10-100HV 314GB/T5783-2000螺栓M10×30Bolt M10×30315ZN485T-11005副油底壳垫片Auxiliary oil sump gasket 116ZN485T-11006副油底壳Auxiliary oil sump 117GB/T5783-2000螺栓M8×45Bolt M8×45818GB/T5783-2000螺栓M8×25Bolt M8×2511No.Part No.名 称Name of part Quantity 1GB/T6173-2000螺母M10×1Nut M10×112GB/T859-87垫圈10Washer1013GB/T848-85垫圈10Washer10144L88-130007机油泵齿轮Lubricating Oil pump gear 15N85-13006限压阀塞Pressure-limiting plug 16GB/T5782-2000螺栓M6×50Bolt M6×5037GB/T5782-2000螺栓M6×55Bolt M6×5518GB/T97.1-2002垫圈4Washer 419N85-13005限压弹簧 Pressure-limiting spring 110GB/T859-87垫圈6Washer 6111GB/T308-89钢球φ10Steel ballφ10112N485-13001-A 机油泵体Oil pump body 113N485-13004-A 外转子Out rotor 114N85-13103-A 圆柱销Cylindrical pin 115N485-13102-A 内转子Inner rotor 116N85-13008-A 机油泵调整垫片δ0.08Lubricating oil pump Adjusting shimδ0.08117N485-13002-A 机油泵盖Lubricating Oil pump cover 1184L88-130003机油泵垫片δ0.5Lubricating Oil pump gasketδ0.5119GB/T1099.1-2003键3×5×13key 3×5×13120N485-13101-A 机油泵轴 Lubricating Oil pump shaft 1Part No.名 称Name of part Quantity 14L40-18001A 喷油泵 Injection pump 124L68-151000D-1喷油器回油管接头部件Injector fuel return pipe part 13GB/T1099-79半圆键3×16Woodruff 3×1614GB/T3452.1-1992O 型密封圈 77.6×2.65O-ring seal 77.6×2.65254L68-18003喷油泵垫块Inject pump end cover 1Oil Sump Assembly (Fig.9)机油泵总成机油泵总成（（图10）Lubricating Oil Pump Assembly(Fig.10)Fuel System (Fig.11)燃油系统总成燃油系统总成（（图11）油底壳总成(图9)64L40-25000喷油器总成Injector 474L68-150003回油总管Fuel return main pipe 18N85-15500（A ）输油泵进油管接头部件Fuel feed pump inlet pipe part 19N485-15300滤清器出油管部件Fuel filter outlet pipe 110N485-15400B 输油泵出油管部件Fuel feed pump outlet pipe 111N485-28000(B)燃油滤清器总成Fuel filter 112GB/T848-85垫圈8Washer 8213GB/T859-87垫圈8Washer 8214GB/T5782-2000螺栓M8×25Bolt M8×252154L68-150001-3喷油器回油套Injector fuel return cover 1164L68-150002 回油管Fuel return pipe 3174B26-141000第一缸高压油管部件1st cylinder high pressure fuel pipe 1184B26-142000第二缸高压油管部件e 2nd cylinder high pressure fuel pipe 1194B26-143000第三缸高压油管部件 3rd cylinder high pressure fuel pipe 1204B26-144000第四缸高压油管部件 4th cylinder high pressure fuel pipe 1No.Part No.名 称Name of part Quantity 14L88-160002集滤器垫片Suction strainer Gasket 124L88-160000A 机油集滤器总成Oil suction strainer 13GB/T859-87垫圈8Washer 834GB/T5782-2000螺栓M8×40Bolt M8×4025GB/T5782-2000螺栓M8×25Bolt M8×251No.Part No.名 称Name of part Quantity 1N390T-21002张紧轮支架Tension pulley bracket 12N390T-21004张紧轮轴Tension pulley shaft 13N390T-21003套圈Bush ring 24N390T-21001张紧轮Tension pulley 15GB/T276-94轴承6302E-2RS Bearing 6302E-2RS 16GB/T893.1-86挡圈42Thrust ring 4217GB/T93-87垫圈12Washer 1218GB/T6170-2000螺母M12Nut M1219GB/T5789-2000螺栓M8×18Bolt M8×182Part No.名 称Name of part Quantity 1N485Q-26000(B)机油滤清器总成Lubricating oil filter 12N485Q-30000(B)起动电机总成Starting motor 13ZN490QA-29000(A)充电发电机总成Charging generator 14N485Q-29100(C)真空泵进油管部件Vacuum pump oil intake pipe assembly 15N485Q-29200(F)真空泵出油管部件Vacuum pump oil return pipe assembly 16空气滤清器总成Air filter 17消声器总成Silencer 1No.Part No.名 称Name of part Quantity张紧轮部件(图13)EGR System (Fig.15)Tension pulley assembly (Fig.13)机滤机滤、、空滤空滤、、发电机发电机、、起动电机起动电机、、消声器(图14)Oil Filter/Air Filter/Generator/Starting Motor/Silencer (Fig.14)EGR 系统(图15)机油集滤器总成机油集滤器总成（（图12）Oil Suction Strainer Assembly （Fig.12）1ZN390TE-35010EGR阀EGR valve1 2GB/T12732.1-2000六角法兰面螺母M8Hexagon flange nuts M82 34L88-350005EGR法兰垫片EGR flange gasket2 4ZN390TE-35200EGR管EGR pipe assembly1 5GB/T5783-2000螺栓M8×30Bolt M8×302 64L88-350600水温传感器Water temperature sensor1 74L88-350500转速传感器Speed sensor1 8GB/T5783-2000螺栓M8×25Bolt M8×254 94L88-351000真空电磁阀Vacuum Solenoid Valve1 104L88-350300ECU Electronic cotrol unit ECU Electronic cotrol unit1 11Q40105垫圈5Washer 52 12Q40405垫圈5Washer 52 13Q2140512螺钉M5×12Screw M5×122 144L88-350700油门位置传感器Throttle position sensor1 15ZN390TE-35002真空胶管Vacuum pip1 16ZN390TE-35003真空胶管Vacuum pip1 17ZN390TE-35100-1EGR线束EGR harness1。

目录前言 01．柴油机高压共轨系统原理介绍 (1)1.1 高压共轨的基本概念1.2 燃油系统的构成及工作原理1.3 电控系统的构成及工作原理1.4 系统功能1.5 4JB1欧3机型电控高压共轨系统构成2．柴油机高压共轨系统传感器作用及特性 (10)2.1 进气压力传感器2.2 水温传感器2.3 转速传感器2.4 相位传感器2.5 空气流量传感器2.6 真空调节器2.7 预热控制器2.8 电控单元ECU2.9 轨压传感器2.10 喷油器3．柴油机高压共轨系统故障诊断及排除 (31)3.1 系统诊断仪使用说明3.2 系统错误代码、亮灯方式及可能原因4．EOL设备 (48)4.1 EOL设备的必要性4.2 EOL设备的基本功能5．柴油机高压共轨系统OBD功能 (49)5.1 车载诊断系统(OBD)概述5.2 OBD的作用5.3 故障及相关信息的存储5.4 故障及相关信息的读取5.5 故障灯5.6 故障列表6．柴油机高压共轨系统注意事项及故障实例 (52)6.1 系统装配过程注意事项6.2 一般使用注意事项6.3 一般维修注意事项6.4 维修过程注意事项6.5 常见故障模式及处理方法7．附录 (55)附录1：增压机型ECU针脚原理图附录2：增压中冷机型ECU针脚原理图附录3：低压油路规则附录4：各传感器安装及特殊要求前言随着我国国民经济的发展，全国汽车保有量在不断增加，同时环保法规也在不断地加严。

按照中华人民共和国国家标准的规定，对于最大总质量3500kg 以上的车辆从2007年1月1日起已施行第三阶段的排放法规，（适用于GB 17691－2005《车用压燃式、气体燃料点燃式发动机与汽车排气污染物排放限值及测量方法（中国Ⅲ、Ⅳ、Ⅴ阶段）》），对于最大总质量3500kg以下的车辆从2007年7月1日起也已施行国三的排放法规（适用于GB18352.3-2005《轻型汽车污染物排放限值及测量方法（III、IV）》）。

整车品牌车型批产日发动机喷油器号备注轻卡08.084DA1-2B/2B1/2B20 445 110 335瑞风03.084DA1-2B 0 445 110 343瑞鹰10.08云内D19 TCI-Eu30 445 110 318轻卡10.06云内D19 0 445 110 318阁瑞斯08.11新晨4cyl._2.5L 0 445 110 317海狮-H210.10新晨4cyl._2.5L 0 445 110 317轻卡10.06云内YN30CR 0 445 110 359轻卡、皮卡06.07福田4JB1_2.8L 0 445 110 313轻客、蒙派克12.07福田4JB1_2.8L 0 445 110 313轻卡10.08全柴4D22E 0 445 110 347轻卡106905.08扬柴4cyl._3.7L 0 445 110 345Auman/Aumark 11.08Cummins ISF3.80 445 120 134Aumark/MPX01.10Cummins ISF2.80 445 110 376依维柯都灵07.06Sofim 8140.430 445 120 002哈佛、风骏08.06长城4cyl._2.8L TC 0 445 110 293哈佛、风骏08.06长城4cyl._2.8L TC 0 445 110 332风骏、皮卡07.10长城CRS1.3_2.8LTC 0 445 110 404德龙09.06潍柴WP120 445 120 127德龙08.08潍柴WP100 445 120 086德龙08.08潍柴WP100 445 120 087德龙06.06潍柴WP60 445 120 150德龙06.06潍柴WD100 445 120 149德龙06.06潍柴WD100 445 120 169德龙06.06潍柴WD100 445 120 170德龙06.06潍柴WD100 445 120 129德龙06.06潍柴WD100 445 120 130德龙10.08潍柴WP120 445 120 166尼桑帕拉丁、皮卡11.08新晨4cyl._2.5L 0 445 110 317巴士10.06玉柴YC4E 0 445 120 110巴士07.07玉柴YC6M 0 445 120 160巴士09.07玉柴YC6J_EU40 445 120 165巴士12.07玉柴YC6L 0 445 120 156巴士01.08玉柴YC6JA 0 445 120 164巴士11.07玉柴YC6G 0 445 120 163长丰猎豹/先锋/皮卡07.09新晨4cyl._2.5L 0 445 110 317上汽/依维柯/红岩杰狮重卡03.09上菲红Cursor90 445 120 157长城陕汽金龙江淮华晨福田博世共轨喷油器CRIN＆CRI应用一览表巴士04.07康明斯ISLe_EU30 445 120 121巴士04.07康明斯ISLe_EU30 445 120 122巴士06.07康明斯ISDe_EU30 445 120 123巴士06.08康明斯ISBe_EU40 445 120 060江铃卡车08.08朝柴4D47_EU30 445 110 334江淮/福田/宇通卡车08.08朝柴4102H_EU30 445 110 333卡车01.08东风十堰4cyl._H 0 445 120 183天龙05.06东风十堰Dci11_MS6.30 445 120 084天龙05.06东风十堰Dci11_EDC70 445 120 106江淮/东风卡车03.07朝柴4102TCI_EU30 445 120 102轻卡08.06一汽CA4DC 0 445 110 291皮卡08.09一汽CA4DC0 445 110 386扬子皮卡08.08一汽四环CA4D28CR2L 0 445 110 355红塔轻卡01.10一汽四环4DW(B35)0 445 110 395金杯轻卡01.10一汽锡柴4DX(A37）0 445 110 396黄海/金龙巴士06.06一汽锡柴6DF 0 445 120 081一汽解放轻卡06.06一汽锡柴4DF 0 445 120 081卡车J5/J605.07一汽锡柴6DN10 445 120 117卡车J5/J612.08一汽锡柴6DM20 445 120 215卡车J504.08一汽锡柴6DL10 445 120 078卡车J5/J603.06一汽锡柴6DL20 445 120 078江铃皮卡10.06江铃4JB1 TC 0 445 110 305中兴皮卡12.08江铃2.5L VM_JE4D25A 0 445 110 321长风SUV 12.07江铃2.5L VM_JE4D25A 0 445 110 059B1412.07奇瑞1.9DTi 0 445 110 304B1105.08奇瑞1.9DTi 0 445 110 304江淮/福田/宇通卡车/巴士10.09朝柴4102L_EU30 445 110 383东风柳汽风行凌智03.09云内D19 TCI-Eu30 445 110 318皮卡Y4307.10东风轻发ZD30-K 0 445 110 284卡车凯普斯达03.09东风轻发ZD30-K 0 445 110 284安源客车巴士11.09朝柴4850 445 110 397少林客车巴士11.09朝柴4850 445 110 397厦门金龙巴士12.08玉柴4F0 445 110 356 华建水泥搅拌机三菱扶桑6M700 445 120 006雷诺270,32001.01Dci 110 445 120 014/Kerax,Premium系列0 445 120 015雷诺370,42004.01Dci 11 14101/141020 445 120 020/Kerax,Premium系列0 445 120 010一汽解放奇瑞雷诺东风哈尔滨郑州日产宇通/金龙整车品牌车型批产日发动机高压泵号备注轻卡03.08 4cyl._2.8L 0 445 010 200瑞风08.08 4cyl._2.8L 0 445 010 200瑞鹰10.08云内D19 TCI-Eu30 445 010 186骏捷/尊驰10.06云内4cyl._1.9L 0 445 010 186阁瑞斯11.08新晨4cyl._2.5L 0 445 101 179海狮-H210.10新晨4cyl._2.5L 0 445 101 179轻卡10.06云内4cyl._3.0L 0 445 025 002轻卡、皮卡06.07福田4JB10 445 010 182轻客、蒙派克12.07福田4JB1_2.8L 0 445 010 182轻卡106905.08扬柴4cyl._3.7L 0 445 010 217轻卡10.08全柴4D22E 0 445 010 219Auman/Aumark 11.08Cummins ISF3.80 445 020 045Aumark/MPX 01.10Cummins ISF2.80 445 020 119Auman/Aumark 12.08OuliD40 445 120 192QiBing12.08OuliD60 445 120 192依维柯都灵07.06Sofim 81400 445 020 002哈佛、风骏08.06长城4cyl._2.8L TC 0 445 010 159哈佛、风骏08.06长城4cyl._2.8L TC 0 445 010 159尼桑帕拉丁、皮卡11.08新晨4cyl._2.5L 0 445 010 179德龙09.06潍柴WP120 445 020 064德龙08.08潍柴WP100 445 020 063德龙06.06潍柴WP60 445 020 071德龙06.06潍柴WD100 445 020 071巴士10.06玉柴YC4E 0 445 020 065巴士07.07玉柴YC6M 0 445 020 098巴士09.07玉柴YC6J_EU40 445 020 065巴士12.07玉柴YC6L 0 445 020 092巴士01.08玉柴YC6JA 0 445 020 065巴士11.07玉柴YC6G 0 445 020 065宇通/金龙巴士06.07康明斯ISDe_EU30 445 020 045卡车08.08朝柴4D470 445 010 199皮卡10.06江铃4JB1 TC JX4930 445 010 169卡车08.08朝柴4102H 0 445 010 198卡车/巴士10.09朝柴4102L 0 445 025 003卡车01.08东风十堰4cyl._H 0 445 020 111天龙05.06东风十堰Dci11_MS6.30 445 020 062天龙05.06东风十堰Dci11_EDC70 445 020 084安源客车巴士09.11朝柴4850 445 025 007江淮/福田/宇通东风长城陕汽金龙江铃江淮华晨福田博世共轨高压泵CP应用一览表少林客车巴士09.11朝柴4850 445 025 007江淮卡车卡车10.03朝柴4850 445 025 007江淮/东风卡车03.07朝柴4102TCI_EU30 445 020 085哈尔滨轻卡08.06一汽CA4DC 0 445 010 158一汽哈尔滨轻卡11.08一汽四环2.8L/TCI 0 445 010 221扬子皮卡08.08一汽四环2.8L/TC 0 445 010 221金杯轻卡06.06一汽锡柴4DX(A37）0 445 025 004巴士06.06一汽锡柴6DF(470）0 445 020 061巴士01.09一汽锡柴6DF(470）0 445 010 102卡车J5/J605.07一汽锡柴6DN10 445 020 077卡车J5/J612.08一汽锡柴6DM20 445 020 077卡车J504.08一汽锡柴6DL10 445 020 058卡车J5/J603.06一汽锡柴6DL20 445 020 058轻卡06.06一汽锡柴4DF(470）0 445 020 078卡车J5/J601.10一汽锡柴6DL10 445 020 144卡车J5/J601.10一汽锡柴6DL20 445 020 144红塔轻卡06.06一汽锡柴4DW(B35)0 445 025 005中兴皮卡12.08江铃2.5L VM_JE4D25A 0 445 010 191长风SUV12.07江铃2.5L VM_JE4D25A 0 445 010 034长丰猎豹/先锋/皮卡07.09新晨4cyl._2.5L 0 445 010 179B1412.07奇瑞1.9DTi 0 445 010 165B1105.08奇瑞1.9DTi 0 445 010 165上汽/依维柯/红岩杰狮重卡03.09上菲红Cursor90 445 020 007东风柳汽风行凌智03.09云内D19 TCI-Eu30 445 010 186厦门金龙巴士11.08玉柴4F 0 445 025 0010 445 010 136/0 445 010 195 0 445 010 136/0 445 010 195 0 445 010 136/0 445 010 195 华建水泥搅拌机三菱扶桑6M70F01G00000V 雷诺270,32001.01Dci 110 445 020 012/Kerax,Premium系列0 445 020 035雷诺370,42004.01Dci 11 14101/141020 445 020 012/Kerax,Premium系列0 445 020 035奇瑞郑州日产东风股公司雷诺黄海/金龙一汽解放东风轻发ZD30-K12.10卡车T01皮卡Y43东风轻发ZD30-K 07.10卡车凯普斯达03.09东风轻发ZD30-K。

G300系列柴油机零件图册PARTS CATALOGUE FORG300SERIES DIESEL ENGINES宁波中策动力机电集团有限公司NINGBO C.S.I.POWER&MACHINERY GROUP CO.,LTD.简要说明1.本零件图册主要供用户订购G6300型柴油机零时查考,并提供机务人员了解柴油机零部件的结构及其装配关系之用。
