PHOENIX CONTACT GmbH & Co. KGPage 1 / 4http://www.phoenixcontact.de

Mar 8, 2008Extract from the onlinecatalog MCDN 1,5/11-G1-3,5 RNP14THROrder No.: 1953295The figure shows a 10-position version of the producthttp://eshop.phoenixcontact.de/phoenix/treeViewClick.do?UID=1953295 Headers with engagement nose, 3.5 mm pitch, pin length 1,4 mm,plug-in direction parallel to the PCB Commercial dataEAN4017918918972Pack50 Pcs.Customs tariff85366990Weight/Piece0.00732 KGCatalog page informationPage 147 (CC-2007)Product notesWEEE/RoHS-compliant since:01/01/2003http://www.download.phoenixcontact.comPlease note that the data givenhere has been taken from theonline catalog. For comprehensiveinformation and data, please referto the user documentation. TheGeneral Terms and Conditions ofUse apply to Internet downloads.Technical dataDimensions / positionsLength13.3 mmHeight15.2 mmPitch3.5 mmDimension a35 mmNumber of positions11元器件交易网www.cecb2b.comMCDN 1,5/11-G1-3,5 RNP14THROrder No.: 1953295http://eshop.phoenixcontact.de/phoenix/treeViewClick.do?UID=1953295

PHOENIX CONTACT GmbH & Co. KGPage 2 / 4http://www.phoenixcontact.deMar 8, 2008Pin dimensions0,8 x 0,8 mmPin spacing3.5 mmHole diameter1.4 mmTechnical dataInsulating material groupIIIaRated surge voltage (III/3)2.5 kVRated surge voltage (III/2)2.5 kVRated surge voltage (II/2)2.5 kVRated voltage (III/2)160 VRated voltage (II/2)250 VConnection in acc. with standardEN-VDENominal current IN8 ANominal voltage UN160 VMaximum load current8 A (per position)Insulating materialLCPInflammability class acc. to UL 94V0Certificates / ApprovalsApproval logoCULNominal voltage UN150 VNominal current IN8 AULNominal voltage UN150 VNominal current IN8 ACertificationCUL, UL元器件交易网www.cecb2b.comMCDN 1,5/11-G1-3,5 RNP14THROrder No.: 1953295http://eshop.phoenixcontact.de/phoenix/treeViewClick.do?UID=1953295

PHOENIX CONTACT GmbH & Co. KGPage 3 / 4http://www.phoenixcontact.deMar 8, 2008AccessoriesItemDesignationDescriptionMarking0805030SK 3,5/2,8:SOMarker card, special printing, self-adhesive, labeled acc. tocustomer requirements, 14 identical marker strips per card, max.25-position labeling per strip, color: White0804109SK 3,81/2,8:FORTL.ZAHLENMarker card, printed horizontally, self-adhesive, 10-section markerstrip, 14 identical decades marked 1-10, 11-20 etc. up to 91-(99)100, sufficient for 140 terminal blocksPlug/Adapter1734634CP-MSTBCoding profile, is inserted into the slot on the plug or invertedheader, red insulating materialDrawingsDrilling diagram*) ≤ 8-pos. = 1.3 / > 8-pos. = 1.4Dimensioned drawing元器件交易网www.cecb2b.comMCDN 1,5/11-G1-3,5 RNP14THROrder No.: 1953295http://eshop.phoenixcontact.de/phoenix/treeViewClick.do?UID=1953295

PHOENIX CONTACT GmbH & Co. KGPage 4 / 4http://www.phoenixcontact.deMar 8, 2008AddressPHOENIX CONTACT GmbH & Co. KGFlachsmarktstr. 832825 Blomberg,GermanyPhone +49 5235 3 00Fax +49 5235 3 41200http://www.phoenixcontact.de© 2008 Phoenix ContactTechnical modifications reserved;元器件交易网www.cecb2b.com
