PHOENIX CONTACT GmbH & Co. KGPage 1 / 5http://www.phoenixcontact.de

Apr 12, 2008Extract from the onlinecatalog GMVSTBR 2,5/ 8-STOrder No.: 1737767The figure shows a 10-position version of the producthttp://eshop.phoenixcontact.de/phoenix/treeViewClick.do?UID=1737767 Plug component, nominal current: 12 A, rated voltage: 500 V, pitch:7.5 mm, no. of positions: 8, type of connection: Screw connection Commercial dataEAN4017918028008Pack50 Pcs.Customs tariff85366990Weight/Piece0.02018 KGCatalog page informationPage 236 (CC-2007)Product notesWEEE/RoHS-compliant since:01/01/2003http://www.download.phoenixcontact.comPlease note that the data givenhere has been taken from theonline catalog. For comprehensiveinformation and data, please referto the user documentation. TheGeneral Terms and Conditions ofUse apply to Internet downloads.Technical dataDimensions / positionsPitch7.5 mmDimension a52.5 mmNumber of positions8Screw threadM 3Tightening torque, min0.5 Nm元器件交易网www.cecb2b.comGMVSTBR 2,5/ 8-STOrder No.: 1737767http://eshop.phoenixcontact.de/phoenix/treeViewClick.do?UID=1737767

PHOENIX CONTACT GmbH & Co. KGPage 2 / 5http://www.phoenixcontact.deApr 12, 2008Technical dataInsulating material groupIRated surge voltage (III/3)6 kVRated surge voltage (III/2)6 kVRated surge voltage (II/2)6 kVRated voltage (III/2)630 VRated voltage (II/2)1000 VConnection in acc. with standardEN-VDENominal current IN12 ANominal voltage UN500 VNominal cross section2.5 mm2Maximum load current12 AInsulating materialPAInflammability class acc. to UL 94V0Internal cylindrical gageA3Stripping length7 mmConnection dataConductor cross section solid min.0.2 mm2Conductor cross section solid max.2.5 mm2Conductor cross section stranded min.0.2 mm2Conductor cross section stranded max.2.5 mm2Conductor cross section stranded, with ferrulewithout plastic sleeve min.0.25 mm2Conductor cross section stranded, with ferrulewithout plastic sleeve max.2.5 mm2Conductor cross section stranded, with ferrulewith plastic sleeve min.0.25 mm2Conductor cross section stranded, with ferrulewith plastic sleeve max.2.5 mm2Conductor cross section AWG/kcmil min.24Conductor cross section AWG/kcmil max122 conductors with same cross section, solid min.0.2 mm22 conductors with same cross section, solid max.1 mm22 conductors with same cross section, strandedmin.0.2 mm2元器件交易网www.cecb2b.comGMVSTBR 2,5/ 8-STOrder No.: 1737767http://eshop.phoenixcontact.de/phoenix/treeViewClick.do?UID=1737767

PHOENIX CONTACT GmbH & Co. KGPage 3 / 5http://www.phoenixcontact.deApr 12, 20082 conductors with same cross section, strandedmax.1.5 mm22 conductors with same cross section, stranded,ferrules without plastic sleeve, min.0.25 mm22 conductors with same cross section, stranded,ferrules without plastic sleeve, max.1 mm22 conductors with same cross section, stranded,TWIN ferrules with plastic sleeve, min.0.5 mm22 conductors with same cross section, stranded,TWIN ferrules with plastic sleeve, max.1 mm2Certificates / Approvals CSANominal voltage UN300 VNominal current IN10 AAWG/kcmil28-12CULNominal voltage UN300 VNominal current IN10 AAWG/kcmil30-12ULNominal voltage UN300 VNominal current IN10 AAWG/kcmil30-12CertificationCB, CSA, CUL, GOST, UL, VDE-PZIAccessoriesItemDesignationDescriptionMarking1051993B-STIFTMarker pen, for manual labeling of unprinted Zack strips, smear-proof and waterproof, line thickness 0.5 mm元器件交易网www.cecb2b.comGMVSTBR 2,5/ 8-STOrder No.: 1737767http://eshop.phoenixcontact.de/phoenix/treeViewClick.do?UID=1737767

PHOENIX CONTACT GmbH & Co. KGPage 4 / 5http://www.phoenixcontact.deApr 12, 20080804455SK 7,5/3,8:FORTL.ZAHLENMarker card, self-adhesive, 10-section marker strip, 12 identicaldecades marked 1-10, 11-20 etc. up to 91-100, sufficient for 120terminal blocks0805137SK 7,5/3,8:SOMarker card, special printing, self-adhesive, labeled acc. tocustomer requirements, 12 identical marker strips per card, max.25-position labeling per strip, color: whitePlug/Adapter1734634CP-MSTBCoding profile, is inserted into the slot on the plug or invertedheader, red insulating materialTools1205053SZS 0,6X3,5Screwdriver, bladed, matches all screw terminal blocks up to 4.0mm² connection cross section, blade: 0.6 x 3.5 mm, without VDEapprovalAdditional productsItemDesignationDescriptionGeneral1766071GMSTB 2,5/ 8-GHeader, nominal current: 12 A, rated voltage: 400 V, pitch: 7.5mm, no. of positions: 8, mounting: Soldering1766408GMSTBA 2,5/ 8-GHeader, nominal current: 12 A, rated voltage: 400 V, pitch: 7.5mm, no. of positions: 8, mounting: Soldering1766518GMSTBV 2,5/ 8-GHeader, nominal current: 12 A, rated voltage: 400 V, pitch: 7.5mm, no. of positions: 8, mounting: Soldering1766725GMSTBVA 2,5/ 8-GHeader, nominal current: 12 A, rated voltage: 400 V, pitch: 7.5mm, no. of positions: 8, mounting: SolderingDrawingsDimensioned drawing元器件交易网www.cecb2b.com
